Tripp-Lite AVRT650U Data Sheet

650VA 480W Line-Interactive UPS with 6 Outlets ­AVR, 120V, 50/60 Hz, USB, Tower

MODEL NUMBER: AVRT650U

Line-interactive UPS provides basic battery backup with automatic voltage regulation for your office
computer or home theater setup.

Highlights

●

Protects equipment against
blackouts, brownouts,
overvoltages, surges and line
noise

●

AVR battery backup allows time
to save files and safely shut
down during blackouts

●

6 NEMA 5-15R outlets provide
power to PC, home theater or
digital signage equipment

●

Easy-to-see LEDs indicate
operating mode, low battery,
overload and other vital data

●

High >95% efficiency with low
BTU ratings saves power and
lowers your energy costs

Features

650VA/480W/120V Battery Backup for PCs, Home Theater or Digital SignageThis 120V UPS with

AVR protection provides reliable battery backup and AC power protection against blackouts, brownouts,
overvoltages, surges and line noise that can damage valuable electronics or destroy data. The six-outlet
120V battery backup is ideal protection for your home office, media center or commerce components,
including computers, routers, printers, HDTVs, Blu-ray players, game consoles, ATMs, security systems
and digital signage equipment.
Allows Time to Back Up Critical Files During a BlackoutBackup support allows you to work through
short power failures, and gives you enough time to safely save files and shut down your system in case of
a prolonged blackout. Backup time varies according to load, but the line-interactive UPS system should
keep an energy-efficient desktop computer with small LCD monitor powered as long as 45 minutes.
During normal operation, incoming utility power keeps the replaceable internal battery fully charged, so
backup power will always be available.
Connects Your Equipment to 6 NEMA 5-15R OutletsFour 5-15R outlets provide both battery backup
and surge protection for your computer, monitor and other crucial components. The other two 5-15R
outlets are surge-protected only for printers, scanners and other non-essential equipment. A high >95%
line mode efficiency rating reduces BTU emissions, energy consumption and, ultimately, your energy
costs.
Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage ConditionsAVR protects your
equipment from incremental hardware damage, data loss and performance problems caused by
brownouts and overvoltages. The AVRT650U can correct brownouts as low as 89V and overvoltages as
high as 145V back to nominal 120V power without drawing on the battery backup needed to support your
equipment during a blackout.
316 Joules Fight Back Against Unexpected Power SurgesA 316-joule surge suppression rating
protects connected components from the harmful effects of power surges.
Combats Electromagnetic Interference That Can Harm EquipmentVarious electromagnetic and radio
sources found in virtually every home and business can cause disruptive interference on the AC line.
Known as EMI (electromagnetic interference) and RFI (radio frequency interference), this line noise is a
common cause of performance problems and can lead to incremental hardware damage, data corruption
and audio/video transmission problems. The AVRT650U incorporates technology that filters out disruptive
line noise so that it won’t affect your equipment.
Easy-to-See LEDs Report Real Time UPS and Power StatusFront-panel LEDs provide UPS and site
power information when the AVRT650U is operating in either on-line or battery power mode. They indicate
operating mode, low battery, overload and fault condition. An audible alarm will sound in case of low
battery, excessive load and fault condition.

HID-Compliant USB Port Allows for Automatic Saves and ShutdownsThis port connects the

Applications

●

Protect your PC and other
sensitive electronics against
power surges, line noise,
brownouts, overvoltages and
blackouts

●

Operate essential equipment
during short-term power outages
using battery backup power

●

Shut down PCs, DVRs, routers
and other equipment without
data loss during long-term
power outages

Package Includes

●

AVRT650U 650VA 480W Line­Interactive UPS with 6 Outlets

●

USB cable

●

Owner’s manual

1 / 5

AVRT650U to a computer running Tripp Lite’s free downloadable PowerAlert® software to enable safe
unattended file saves and system shutdown in case of a prolonged power failure. USB cable is included.
The UPS works with Windows, Mac and Linux operating systems.
Tower Form Factor for Easy Placement in Your Workspace or Media CenterThe long-lasting ABS
housing fits easily on a desktop, shelf or anywhere else convenient to your workstation or home theater.
The five-foot power cord with NEMA 5-15P plug connects to a properly grounded AC wall outlet.

Specifications

OVERVIEW

UPC Code 037332212924
UPS Type Line-Interactive

INPUT

Rated input current (Maximum Load) 6A
Nominal Input Voltage(s) Supported 110V AC; 115V AC; 120V AC
UPS Input Connection Type 5-15P
Input Circuit Breakers 7A
UPS Input Cord Length (ft.) 5
UPS Input Cord Length (m) 1.5
Recommended Electrical Service 15A 120V
Input Phase Single-Phase

OUTPUT

Output Volt Amp Capacity (VA) 650
Output Watt Capacity (Watts) 480
Power Factor 0.74
Nominal Voltage Details 120v nominal output in battery mode
Frequency Compatibility 50 / 60 Hz
Frequency Compatibility Details Automatic frequency selection
Output Voltage Regulation (Line

Mode)
Output Voltage Regulation (Battery

Mode)
UPS Output Receptacles (Surge

Suppression Only)
Hot-Swap PDU options PDUB15 (2U / 8 5-15R outlets)
Output AC Waveform (AC Mode) Sine wave
Output AC Waveform (Battery

Mode)

120V (+9% / -12%)

120V (±10%)

4 UPS outlets, 2 surge-only outlets

PWM sine wave

2 / 5

Nominal Output Voltage(s)
Supported

110V; 115V; 120V

Output Receptacles (6) 5-15R
Individually Controllable Load Banks No

BATTERY

Half Load Runtime (min.) 3.8 minutes (240w)
DC System Voltage (VDC) 12
Battery Recharge Rate (Included

Batteries)
Internal UPS Replacement Battery

Cartridge

8 hours from 10% to 90%

 <a class="productLink" href="// UPS-Replacement-Battery-Cartridge-Tripp-Lite-APC-Belkin-

Best-Powerware-Liebert-other-UPS~RBC51">RBC51</a>
Battery Access Includes bottom panel battery access door
Battery Replacement Description Replaceable internal battery (see manual)
Expandable Runtime No

VOLTAGE REGULATION

Voltage Regulation Description Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 89 to 145
Overvoltage Correction Input voltages between 129 and 145 are reduced by 15%
Undervoltage Correction Input voltages between 89 and 108 are boosted by 14%

USER INTERFACE, ALERTS & CONTROLS

Switches Power switch enables UPS on / off control
Audible Alarm Alarm reports low-battery, fault, overload and replace battery conditions; Alarm remains silent during battery mode

operation until low-battery status occurs
LED Indicators 3 LEDs indicate line power availability (green), battery power mode (yellow) and low battery, overload,

replace-battery and fault mode (red)

SURGE / NOISE SUPPRESSION

UPS AC Suppression Joule Rating 316
UPS AC Suppression Response

Time

Instantaneous

UPS Dataline Suppression N/A
EMI / RFI AC Noise Suppression Yes

PHYSICAL

Installation Form Factors Supported
with Included Accessories

Tower

Primary Form Factor Tower
Primary UPS Depth (mm) 345
Primary UPS Height (mm) 160

3 / 5

Primary UPS Width (mm) 122
Shipping Dimensions (hwd / in.) 9.80 x 7.20 x 16.30
Shipping Weight (kg) 5.99
UPS Housing Material ABS
UPS Power Module Dimensions

(hwd, in.)

6.3 x 4.8 x 13.6

UPS Power Module Weight (kg) 5.49
UPS Power Module Weight (lbs.) 12.1

ENVIRONMENTAL

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
Relative Humidity Up to 90%, non-condensing
AC Mode BTU / Hr. (Full Load) 43
AC Mode Efficiency Rating (100%

Load)

>95%

COMMUNICATIONS

PowerAlert Software For local monitoring via the UPS’s built-in USB communications port, download PowerAlert Local

software at http:// poweralert
Communications Cable USB interface cable included
WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
Network UPS Tools Compatibility
Communications Interface USB (HID enabled)

LINE / BATTERY TRANSFER

Transfer Time 6 milliseconds
Low Voltage Transfer to Battery

Power (Setpoint)
High Voltage Transfer to Battery

Power (Setpoint)

89

145

SPECIAL FEATURES

Cold Start (Startup in Battery Mode
During a Power Failure)

Cold-start operation supported

High Availability UPS Features Automatic Voltage Regulation (AVR); Surge/noise protection
Green Energy-Saving Features Greater than 95% efficiency - GREEN UPS

STANDARDS & COMPLIANCE

UPS Certifications Meets FCC Part 15 Category A (EMI); ROHS (Restriction of Hazardous Substances); Tested to CSA (Canada);

Tested to NOM (Mexico); Tested to UL1778 (USA)

4 / 5

Certification Details UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION

WARRANTY

Product Warranty Period (U.S. &
Canada)

Product Warranty Period (Latin
America)

Product Warranty Period
(International)

Product Warranty Period (Mexico) 3-year limited warranty
Connected Equipment Insurance

(U.S., Canada & Puerto Rico)

3-year limited warranty

3-year limited warranty

2-year limited warranty

$100,000 <a class="insuranceLink" href="// support/insurance-policy">Ultimate Lifetime

Insurance</a>
