Model #: SMART1500RMXL2UA
SmartPro 1.5kVA 1350W Line Interactive Sine Wave UPS, Extended-run & SNMPWEBCARD options, 2U
Rack/Tower, LCD, USB, RS232,EPO, 120V
Highlights
1.5kVA / 1500VA / 1350W line interactive 2U rack/tower UPS, Sine Wave
120V output, Corrects brownouts and overvoltages from 83V to 145V
0.9 Power Factor, Interactive LCD interface
Extended runtime options up to 1200W
4 post compatible mounting accessories
95% line-mode efficiency, 2 switched load banks
USB, RS232, EPO and slot for SNMPWEBCARD option
120V NEMA 5-15P input, 8 NEMA 5-15R outlets
Description
Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and
telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects
brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration
excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout
conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and
configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment
without interruption or reboot. 95% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support
communications via USB, RS-232 and optional SNMPWEBCARD network interface. HID-compliant USB interface enables integration with built-in
power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of
equipment load levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output
load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display
panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode
configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules.
Package Includes
SMART1500RMXL2UA UPS system
PowerAlert software with USB, Serial & EPO cabling
4 post installation kit
Owner's manual
Features
Tripp Lite SMART1500RMXL2UA line interactive 2U rack/tower UPS with 1500VA / 1.5kVA / 1350W capacity and extended runtime options
Line interactive UPS with Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages from 83 to 145V
NEMA 5-15P input plug; 8 NEMA 5-15R output receptacles, Two independently switched output load banks
Maintains uninterrupted operation of connected networking equipment during blackouts, surges, brownouts and overvoltages
High 95% efficiency rating in line-power mode offers reduced power consumption and BTU emisssions
Internal batteries offer 14 minutes at 50% load (675W) and 4.9 minutes at 100% load (1350W)
Extended runtime is available with optional BP36V15-2U (limit 1) OR BP36V42-3U (no limit), Output is reduced to 1200 watts maximum with
external battery packs
External battery configurations require the use of Tripp Lite's External Battery Configuration Software (see manual)
Hot-swappable, user-replaceable internal batteries and external battery packs can be replaced with no disruption to connected equipment
Front panel LCD monitoring screen with MODE and ENTER buttons reports operating mode with 5-bar battery charge graphic, plus 7
selectable screens of detailed UPS and site power information
LCD interface also supports a number of advanced user setup and operating preferences
Ships with 4 post rackmount installation hardware; Optional 2POSTRMKITWM enables 2 post rackmount/wallmount installation; Optional
2-9USTAND enables tower placement
Built-in USB, RS-232 and optional SNMPWEBCARD accessory monitoring options
HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
Included PowerAlert UPS monitoring software; Built-in Emergency Power Off (EPO) interface with cable
Specifications
OUTPUT
Output Volt Amp
Capacity (VA)
1500
Output kVA capacity
(kVA)
1.5
Output Watt Capacity
(watts)
1350
Output kW capacity 1.35
Output power factor 0.9
Output Capacity
Details
Output derates to 1200 watts in all external battery configurations
Nominal Output
Voltage(s) Supported
120V
Frequency
compatibility
60 Hz
Output voltage
regulation (line mode)
-14%, +6%
Output voltage
regulation (Battery
mode)
+/- 5%
Built-in UPS output
receptacles
8 5-15R outlet(s)
Built-in controllable
switched load banks
Two switchable two-outlet 5-15R load banks
Output AC waveform
(AC mode)
Sine wave
Output AC waveform
(battery mode)
Pure Sine wave
INPUT
Rated input current
(at maximum load)
12A
Nominal Input
Voltage(s) Supported
120V AC
UPS input
connection type
5-15P
Input circuit breaker 15A
UPS Input cord
length (ft.)
10
UPS Input cord
length (m)
3
Recommended
Electrical Service
15A 120V
BATTERY
Full load runtime
(minutes)
4.9 min. (1350w)
Half load runtime
(minutes)
14 min. (675w)
Expandable battery
runtime
Extended runtime supported via optional external battery packs
External battery pack
compatibility
BP36V15-2U (limit 1); BP36V42-3U (multi-pack compatible)
DC system voltage
(VDC)
36
Battery recharge rate
(included batteries)
Less than 4.5 hours from 10% to 90%
Replacement battery
cartridge (internal
UPS battery
replacement)
RBC93-2U
Battery Access Front panel battery access door
Battery replacement
description
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation
description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 145
Overvoltage
correction
Input voltages between 127 and 145 are reduced by 12%
Undervoltage
correction
Input voltages between 95 and 108 are boosted by 12%
Severe undervoltage
correction
Input voltages between 83 and 94 are boosted by 24%
LEDS ALARMS & SWITCHES
Front panel LCD
display
Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data,
plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual for
detailed LCD configuration and monitoring options)
Alarms Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions
Alarm cancel
operation
Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option
available
Switches 3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions
SURGE / NOISE SUPPRESSION
UPS AC suppression
joule rating
570
UPS AC suppression
response time
Instantaneous
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Installation form
factors supported
with included
accessories
4 post 19 inch rackmount (mounting rail kit included)
Included mounting
accessory description
Adjustable mounting rail kit included
Installation form
factors supported
with optional
accessories
2 post rackmount (2POSTRMKITWM); Wallmount (2POSTRMKITWM); Tower (2-9USTAND)
Primary form factor Rackmount
UPS / Power Module
dimensions in
primary form factor
(height x width x
depth / inches)
3.45 x 17.3 x 13.45
UPS / Power Module
dimensions in
primary form factor
(height x width x
depth / cm)
8.8 x 43.9 x 34.2
Rack Height 2U
Secondary form
factor
Tower (requires 2-9USTAND)
UPS / Power Module
weight (lbs)
46.5
UPS / Power Module
weight (kg)
21.1
UPS Shipping
dimensions (height x
width x depth /
inches)
7.9 x 22.9 x 19.4
UPS Shipping
dimensions (height x
width x depth / cm)
20.1 x 58.2 x 49.3
Shipping weight (lbs) 51.3
Shipping weight (kg) 23.3
Cooling method Fan
UPS housing material Steel
ENVIRONMENTAL
Operating
Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature
Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr.
(full load)
237
COMMUNICATIONS
Communications
interface
USB; DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface
Network monitoring
port description
Supports detailed monitoring of UPS and site power conditions
PowerAlert software Included
Communications
cable
USB and DB9 cabling included
WatchDog
compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time 4 milliseconds (AC to battery mode), 1 millisecond (Battery to AC mode)
Low voltage transfer
to battery power
(setpoint)
83
High voltage transfer
to battery power
(setpoint)
145
SPECIAL FEATURES
Grounding lug Back panel grounding lug
Cold Start (startup in
battery mode during
a power failure)
Cold-start operation supported
High availability UPS
features
Hot swappable batteries
Green & high
efficiency features
Greater than 95% efficiency - GREEN UPS; Individually controllable load banks
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI);
ROHS (Restriction of Hazardous Substances)
WARRANTY
Product Warranty
Period (Worldwide)
2-year warranty, 3 year with registration. Note: registration is required for 3-year warranty.
Connected
Equipment Insurance
(U.S., Canada &
Puerto Rico)
$250,000 Ultimate Lifetime Insurance
