SmartRack 116
User Guide
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright ©2012 Tripp Lite. All rights reserved.
SMARTRACK 116 SWITCH
Table of Contents
1. Welcome................................................................................................................................ 3
2. Introduction........................................................................................................................... 4
2.1 Features............................................................................................................................................. 4
2.2 Compatibility..................................................................................................................................... 4
3. System components............................................................................................................. 5
3.1 Hardware kit contents....................................................................................................................... 5
3.2 Pre-installation guidelines................................................................................................................ 6
3.3 Avoiding general rack mounting problems..................................................................................... 6
3.4 Connecting to a rack......................................................................................................................... 7
3.5 Using the medium or longer bracket ............................................................................................... 9
3.6 Connecting the KVM Switch 116.................................................................................................... 11
4. The SmartRack 116 system configuration.........................................................................12
4.1 The KVM Switch 116 ....................................................................................................................... 13
4.1.1.1 Connector table...................................................................................................................... 13
4.2 Connecting ROCs to servers.......................................................................................................... 13
4.2.1 Connecting a ROC PS/2.............................................................................................................. 14
4.2.2 Connecting a ROC USB .............................................................................................................. 14
4.3 Connecting the CAT5 cables.......................................................................................................... 15
4.4 Connecting the power supply ........................................................................................................ 15
4.5 Cascading the SmartRack 116 ....................................................................................................... 15
5. Operating the SmartRack 116 system................................................................................16
5.1 The keyboard hotkeys .................................................................................................................... 16
5.2 Displaying the OSD......................................................................................................................... 17
5.2.1 Navigating the OSD..................................................................................................................... 17
5.2.2 Selecting a computer................................................................................................................... 17
5.2.3 The OSD settings (F2)................................................................................................................. 17
5.2.4 The General settings ................................................................................................................... 18
5.2.4.1 Security.................................................................................................................................. 18
5.2.4.2 Administrator (Status A) ......................................................................................................... 18
5.2.4.3 Supervisor (Status S) ............................................................................................................. 19
5.2.4.4 User (Status U) ...................................................................................................................... 19
5.2.4.5 Activating password protection............................................................................................... 19
5.2.4.6 Displaying the OSD of cascaded switches.............................................................................. 20
5.2.4.7 Autoskip................................................................................................................................. 20
5.2.4.8 Serial port............................................................................................................................... 20
5.2.4.9 Changing the Keyboard language .......................................................................................... 21
5.2.4.10 Editing the Switch name....................................................................................................... 21
5.2.5 F7 Defaults.................................................................................................................................. 21
5.2.6 The Ports settings........................................................................................................................ 21
5.2.6.1 Editing the computer name..................................................................................................... 21
5.2.6.2 Keyboard (KB)........................................................................................................................ 22
5.2.6.3 (HKEY) hotkey - Cascading.................................................................................................... 22
5.2.7 The Time settings........................................................................................................................ 23
5.2.7.1 Scan (SCN) - Label (LBL) - Time out (T/O)............................................................................. 23
USER GUIDE
5.2.8 Users........................................................................................................................................... 23
5.2.9 Security ....................................................................................................................................... 24
5.2.10 The OSD HELP window – F1..................................................................................................... 25
5.2.11 Scanning computers– F4........................................................................................................... 25
5.2.12 Tuning – F5 ............................................................................................................................... 26
5.2.13 Moving the label – F6................................................................................................................. 26
5.2.14 DDC – F10................................................................................................................................. 26
5.2.14.1 Updating the DDC information.............................................................................................. 27
6. Upgrading the SmartRack 116 firmware............................................................................27
6.1 System requirements for the SmartRack 116 Update software ................................................... 27
6.2 Connecting the SmartRack 116 system......................................................................................... 27
6.3 Installing the software .................................................................................................................... 27
6.3.1 Connecting the RS232 Download cable....................................................................................... 28
6.4 Starting and configuring the SmartRack 116 Update ................................................................... 28
6.4.1 Verifying the version numbers...................................................................................................... 30
6.4.1.1 OSD version number.............................................................................................................. 30
6.4.1.2 ROC version number.............................................................................................................. 30
6.4.2 Obtaining new firmware............................................................................................................... 31
6.4.3 Updating the firmware.................................................................................................................. 31
7. Troubleshooting the Update software ...............................................................................32
7.1.1 Setting default values for the OSD............................................................................................... 32
7.1.2 Communication Error message.................................................................................................... 32
7.1.3 Electricity failure........................................................................................................................... 32
8. USB / SUN Combo keys ......................................................................................................33
9. Technical specifications .....................................................................................................34
9.1 Video resolution and refresh rates ................................................................................................ 36
9.2 Safety............................................................................................................................................... 36
9.3 User guide feedback.............................................................................. Error! Bookmark not defined.
9.4 WEEE compliance........................................................................................................................... 36
SMARTRACK 116 SWITCH
1. Welcome
Thank you for buying the SmartRack 116 system. This system is produced by Minicom Advanced Systems Limited.
Technical precautions
This equipment generates radio frequency energy and if not installed in accordance with the manufacturer’s instructions, may cause radio frequency interference.
This equipment complies with Part 15, Subpart J of the FCC rules for a Class A computing device. This equipment also complies with the Class A limits for radio noise emission from digital apparatus set out in the Radio Interference Regulation of the Canadian Department of Communications. These above rules are designed to provide reasonable protection against such interference when operating the equipment in a commercial environment. If operation of this equipment in a residential area causes radio frequency interference, the user, and not Minicom Advanced Systems Limited, will be responsible.
Changes or modifications made to this equipment not expressly approved by Minicom Advanced Systems Limited could void the user’s authority to operate the equipment.
Minicom Advanced Systems Limited assumes no responsibility for any errors that appear in this document. Information in this document is subject to change without notice.
No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of Minicom Advanced Systems Limited.
Trademarks
PS/2 is a registered trademark of International Business Machines Corporation. All other trademarks and registered trademarks are the property of their respective owners.
USER GUIDE
2. Introduction
Access and control multiple multi-platform computers from one Keyboard Video Mouse (KVM) console with the SmartRack 116 Switch system. Connect up to 16 computers to the SmartRack 116.
The SmartRack 116 is based on Minicom’s innovative ROC technology in which each computer / server is directly connected to the switch via a ROC using standard CAT5 cable at a distance of up to 30m/100ft in a star configuration. No external power is needed at the remote ROCs.
To access servers, just slide out the drawer and flip up its top to display the large, high resolution 17” TFT LCD display.
The display is (VGA/SVGA/XGA/SXGA compatible) with front-panel high-quality controls and Touchpad for easy adjustment.
2.1 Features
Hot-Swap - disconnect and reconnect computers without rebooting Scan-mode operation with variable time interval 1U Rack mountable Operate the system using an On Screen Display (OSD) Create multi-level cascade arrangements. For example by cascading with the
Smart 116, connect up to up to 256 computers in the system
The computers can be placed up to 30m/100ft from the SmartRack 116 Multi-platform interface— supports PS/2, and USB computers/servers
2.2 Compatibility
The SmartRack 116 is compatible with:
PS/2, and USB computers/servers DOS, Windows, Linux, UNIX, Mac and all other major operating systems
SMARTRACK 116 SWITCH
3. System components
The SmartRack 116 system consists of:
SmartRack 116: Console + KVM Switch ROCs - PS/2, USB CAT5 cables (1.5m provided with ROCs) RS232 Download cable
3.1 Hardware kit contents
Rail with front and rear bracket x 2, for rack depth of 614 ~ 800 mm. Right and left sides are different.
Long bracket x 2. (For increased rack depth of 905 ~ 990mm)
Medium bracket x 2. (For increased rack depth of 800 ~ 905mm)
Short bracket x 2
Bracket attachment x 2 Note! The short bracket and bracket attachment for a rack depth of 504~ 614 mm and
without a KVM switch connected to the drawer.
USER GUIDE
Flat screws x 6 (for rail mount to console body)
Screws x 6
Bracket A with thumbscrew x 2
Screws x4
Keys x 2.
3.2 Pre-installation guidelines
Switch off all computers Place cables away from fluorescent lights, air conditioners, and machines that are
likely to generate electrical noise
Ensure that the maximum distance between each computer and the SmartRack
116 does not exceed 30m/100ft
3.3 Avoiding general rack mounting problems
Elevated operating ambient temperature
The operating ambient temperature of the rack environment may be greater than the room ambient when installing into a closed or multi-unit rack assembly. So install the equipment in an environment compatible with the maximum rated ambient temperature.
Reduced airflow
Install the equipment in a rack in such a way that the amount of airflow required for safe operation is not compromised.
Mechanical loading
Mount the equipment in the rack in such a way that a hazardous condition is not achieved due to uneven mechanical loading.
Circuit overloading
When connecting the equipment to the supply circuit, consider the effect that overloading of circuits might have on over-current protection and supply wiring.
SMARTRACK 116 SWITCH
Reliable earthing of rack-mounted equipment should be maintained. Give attention to supply connections other than direct connections to the branch circuit (e.g. use of power strips).
3.4 Connecting to a rack
Note! For increased rack depth of between 800 ~ 990mm, first change the bracket to the medium or long bracket, see section 3.5 on page 9.
Note! The illustrations below show the connections to one side of the SmartRack 116. The connections are the same for the other side.
1. Move the rail until two screws appear, see Figure 1.
Figure 1 Exposing the 2 screws
2. Loosen slightly the 7 screws as shown below.
Figure 2 Loosen 7 screws
3. Adjust the rear bracket to fit your cabinet, see below.
Figure 3 Adjusting the bracket
4. Install the front and rear bracket onto the cabinet, see figure below.
USER GUIDE
Figure 4 Installing front and rear bracket on cabinet
5. Tighten the 7 screws as shown below.
Figure 5 Tightening the 7 screws
6. Repeat the steps above to connect the other rail to the other side of the rack.
7. Slide the SmartRack console between the rails as shown below.
Figure 6 Sliding the SmartRack between the rails
8. Unlock and pull both left and right rail–lock switches together – see below – and push the console all the way into the rack.
SMARTRACK 116 SWITCH
Figure 7 Rail–lock switch
9. Connect three flat screws to the rear of the console on both sides. See figure below.
Figure 8 Connecting three flat screws to the rear of the console
The console now sits snugly in the rack, see Figure 9.
Figure 9 Console in the rack
3.5 Using the medium or longer bracket
For a rack depth of 800 ~ 905mm, use the medium bracket. For a rack depth of 905 ~ 990mm, use the longer bracket.
To replace the bracket with the medium or longer bracket:
1. Loosen the 7 screws as shown below.
USER GUIDE
10
Figure 10 Loosening the 7 screws
Remove the six (different) screws as shown below.
Figure 11 Removing the six screws
2. Take the rear bracket out, see below.
Figure 12 Taking the rear bracket out
3. Insert the medium/long bracket into the rail then adjust the bracket to fit your cabinet.
4. Tighten at least 2~3 screws along the length you need. Note! For medium bracket use the round screws , and for the long bracket use the flat screws . See
Figure 13.
SMARTRACK 116 SWITCH
11
Figure 13 Inserting and tightening the medium/long bracket
5. Repeat the above steps for the other side.
6. Go to section 3.4 Connecting to a rack.
3.6 Connecting the KVM Switch 116
1. Connect the bracket A to the sides of the Switch using the two 6mm screws provided see figure below.
Figure 14 Connecting the bracket A to the sides of the Switch
2. Slide the Switch 116 into the rail and into the back of the SmartRack console until you hear a click. See the figure below.
Figure 15 Slide switch into back of SmartRack
3. Secure the Switch 116 to the rail by inserting the thumbscrews through the bracket and into the rail and tightening them, see Figure 16.
