Version 1.3 79100A03

Triplex MPEG-4 DVR

OSD Setup Guide

79100A03

User’s Manual

Table of Content

Menu System Overview.....................................................................................................5

<Key Usage>................................................................................................................5

　 Key Usage in OSD Menu .......................................................................5

　 Key Usage in Virtual Keyboard...............................................................6

System Setup.....................................................................................................................7

<Version> .....................................................................................................................7

　 Hardware Version...................................................................................7

　 Software Version ....................................................................................7

　 Software Upgrade via Local Device .......................................................8

<Language> .................................................................................................................8

<Date / Time> ...............................................................................................................8

　 Date / Time Setting.................................................................................9

　 Date / Time Display ................................................................................9

　 Date Display Mode .................................................................................9

　 Time Display Mode.................................................................................9

　 Date/Time Order...................................................................................10

　 Daylight Saving Time............................................................................10

　 DST Start / End ....................................................................................10

　 DST Bias ..............................................................................................10

<Unit Name> ..............................................................................................................10

<Password>................................................................................................................ 11

　 Admin / User Password........................................................................ 11

　 Enable Password .................................................................................12

　 Load Factory Password........................................................................12

<Network Setup>........................................................................................................12

　 LAN Setup............................................................................................12

- DHCP......................................................................................13

- IP ............................................................................................13

- Netmask..................................................................................13

- Gateway..................................................................................13

- DNS ........................................................................................14

- Connect At Booting .................................................................14

- Network Restart ......................................................................14

　 Trigger Port ..........................................................................................14

　 DDNS Setup.........................................................................................14

- Enable DDNS ...............................................................................15

- Host Name....................................................................................15

User’s Manual

- DDNS Port ....................................................................................16

- Submit/ Update .............................................................................16

- ezDDNS........................................................................................16

　 <RS485 Setup>....................................................................................16

　 Unit ID ..................................................................................................17

　 Baud Rate ............................................................................................17

　 Bits .......................................................................................................17

　 Stop......................................................................................................17

　 Parity ....................................................................................................17

<Key Beep>................................................................................................................17

Monitor Setup...................................................................................................................17

<Show Camera Title> .................................................................................................18

<Monitor Brightness>..................................................................................................18

<Monitor Contrast>.....................................................................................................18

<Monitor Chrominance> .............................................................................................18

<Screen Center Adjust>..............................................................................................18

<Show Color Bar> ......................................................................................................19

<VGA Resolution> ......................................................................................................19

Camera Setup >................................................................................................................19

<Camera Select>........................................................................................................19

<Dome Protocol>........................................................................................................20

<Dome ID> .................................................................................................................20

<Camera Title>...........................................................................................................20

<Covert>.....................................................................................................................21

<Termination> .............................................................................................................21

<Brightness> ..............................................................................................................21

<Contrast>..................................................................................................................21

<Saturation> ...............................................................................................................21

<Hue>.........................................................................................................................22

Record Setup ...................................................................................................................22

<Record Mode>..........................................................................................................22

<Schedule Setup> ......................................................................................................23

　 Day/ Night Time Start ...........................................................................23

　 Day / Night Time End ...........................................................................23

　 Weekend Schedule ..............................................................................23

　 Weekend Start/ End .............................................................................24

<Preset Record Configuration> ..................................................................................24

<ezRecord Setup>......................................................................................................25

<Circular Recording>..................................................................................................26

<Purge Data> .............................................................................................................27

User’s Manual

　 Purge All Data ......................................................................................27

　 Purge All Event Data ............................................................................27

　 Purge Event Before ..............................................................................27

　 Start to Purge .......................................................................................27

Sequence Setup...............................................................................................................28

<Main / Call Monitor Dwell>........................................................................................28

<Main / Call Monitor Schedule>..................................................................................28

Event Setup......................................................................................................................29

<Internal Buzzer> .......................................................................................................29

<Event Icon> ..............................................................................................................29

<Alert Notification Setup> ...........................................................................................30

- Alert Configuration Set............................................................30

- Alert Notification......................................................................30

- Alert IP ....................................................................................30

- Alert Port.................................................................................30

<Event Duration>........................................................................................................30

<Per Channel Config> ................................................................................................31

　 Channel Select .....................................................................................31

　 Video Loss Detect ................................................................................31

　 Motion Detect .......................................................................................31

　 Detection Configuration........................................................................31

- Detected Area Setup...............................................................32

- Sensitivity................................................................................32

- Area Threshold .......................................................................32

- Detected Area Percentage ......................................................33

　 Alarm In................................................................................................33

　 Alarm Out .............................................................................................33

Database Setup................................................................................................................33

<Total / Free Size of HDD>.........................................................................................34

<Internal / External Disks>..........................................................................................34

Configuration...................................................................................................................35

<Load Factory Default> ..............................................................................................35

<Import Configuration> ...............................................................................................35

<Export Configuration>...............................................................................................36

　 Copy Destination ..................................................................................36

　 Configuration Name .............................................................................36

　 Begin Export.........................................................................................36

Shutdown .........................................................................................................................37

Appendix A: Technical Specifications ...........................................................................38

Appendix B: Record Duration.........................................................................................40

User’s Manual

Menu System Overview

The detailed functions and settings of Triplex MPEG-4 DVR can be set using the

hierarchical OSD menu. This chapter particularizes the items and options in the OSD

menu.

To enter the Main menu, press MENU and then enter Administrator or User password. The

default passwords are shown in the following table. The same default passwords are used

for entering the remote viewing software, DVRRemote.

Administrator Password User Password

1234 4321

It is strongly suggested to change the passwords to prevent unauthorized access to the

unit.

After entering the correct password, the Main menu is displayed.

Main Menu

1. System Setup

2. Monitor Setup

3. Camera Setup

4. Record Setup

5. Sequence Setup

6. Event Setup

7. Database Setup

8. Configuration

9. Shutdown

The key usage differs under the OSD Setup Menu and in the Virtual keyboard

(Next Page), which can be seen while setting some items, such as Unit Name

and IP Address in the OSD Setup Menu.

 Key Usage in OSD Menu

Below introduce some keys used frequently to set up the unit via the OSD

Setup Menu.

In the OSD menu, Direction keys are used to move the cursor to previous or

next fields. UP / DOWN are used to change the value in the selected field.

User’s Manual

<ENTER>

In OSD menu or selection interface, press the key to make selection or save

settings.

<ESC>

Press to cancel or exit from certain OSD menu without saving any changes.

 Key Usage in Virtual Keyboard

A virtual keyboard shows when edit the settings, such as camera title, etc.

The virtual keyboard displays as follows.

A B C D E F G H I J K L M

N O P Q R S T U V W X Y Z

a b c d e f g h i j k l m

n o p q r s t u v w x y z

0 1 2 3 4 5 6 7 8 9

# − _

◄ ► Backspace Delete

Cancel OK

Move the cursor by pressing Direction keys and press ENTER to select

characters.

Press MODE and LEFT / RIGHT simultaneously to move the cursor to left /

right in the title entry.

Select <Backspace> and press ENTER, or press MODE and UP

simultaneously.

Select <Delete> and press ENTER, or press MODE and DOWN

simultaneously.

Select <OK> and press ENTER to save the settings and exit, or press ESC to

exit without saving changes

User’s Manual

System Setup

Select <System Setup> from the Main Menu and press ENTER to enter the System Setup

menu.

Main Menu

1. System Setup

2. Monitor Setup

3. Camera Setup

System Setup

4. Record Setup

1. Version

5. Sequence Setup

2. Language

English

6. Event Setup

3. Date/Time

7. Database Setup

4. Unit Name

DVR

8. Configuration

5. Password

9. Shutdown

6. Network Setup

7. RS485 Setup

8. Key Beep

YES

The items in the System Setup menu are described in the following sections.

The Version menu allows user to view system information such as hardware and software

version. From the System Setup menu, select <Version> and press ENTER. The following

menu is displayed. The first three items, including <Model Name>, <Hardware> and

<Software>, are for read only, which CANNOT be changed.

Version

Model Name Hardware Software Software Upgrade via Local Device

*****

**.**.**

***.***.***.***

The items in this menu are described in the following subsections.

 Hardware Version

The item identifies the hardware version for this unit.

 Software Version

The item identifies the software version installed on this unit.

User’s Manual

 Software Upgrade via Local Device

This item is used for updating the Triplex MPEG-4 DVR software by

local device. The menu is displayed as follows.

Software Upgrade via Local Device

Upgrade Version xxxx-xxxx-xxxx-xxxx

Select

Connect an USB drive contains upgrade software to the unit; the available

upgrade files will be listed in the menu. To update the system, select a file

and use UP / DOWN keys to choose <YES>. Press ENTER to confirm the

selection and start the upgrade process. The Triplex MPEG-4 DVR uploads

the software, updates the system files, and reboots automatically.

The upgrade may take several minutes to save the changes in the memory of

the system. After reboot the unit, please check the software version again.

NOTE: No power interruption is allowed during the software update.

Ensure that no power interruption can occur until the unit is

completely rebooted.

NOTE: Do not remove the external USB

ThumbDrive®/CD-ROM/DVD+RW before the unit has completely

shut down (hard drive and fan are off). Removing the external USB

ThumbDrive®/CD-ROM/DVD+RW before shut down can cause the

system to update improperly.

The Language item allows user to select the language for the OSD menu and screen

messages. Language selection takes effect immediately when the selection is done. Press

UP / DOWN to select from listed languages and press ENTER to confirm.

User can set the current date, time and other OSD parameters in this menu. The

Administrator’s privileges are required for entering the submenu. In System Setup menu,

select <Date/Time> and press ENTER; the Date/Time menu displays as follows.

User’s Manual

Date/Time

1. Date

2. Time

3. Date/Time Display

4. Date Display Mode

5. Time Display Mode

6. Date/Time Order

7. Daylight Saving Time

8. DST Start

9. DST End

10. DST Bias

2005/02/21

PM10:39:26

1 Row

Y/M/D

24 HR

Date First

OFF Apr, 1 st Sun, 02:00 Apr, Last Sun, 02:00

60 Min

NOTE: The reset date / time setting applies to record new video, the

date and time of previously recorded video will not be changed.

NOTE: To avoid record database corruption, after changed

Date/Time setting, clear the database is recommended.

 Date / Time Setting

Select <Date> or <Time> and press ENTER for adjusting the settings. LEFT /

RIGHT keys are used to move the cursor to previous or next field, ENTER is

for selecting, and UP / DOWN are used to change the value in the selected

field.

 Date / Time Display

Users are allowed to choose to set the date / time OSD displays in 1 or 2

rows. Use the UP / DOWN keys to change the setting. The default is to

display the date / time OSD in one row.

 Date Display Mode

This function allows user to set the OSD display type of the date / time. There

are three options to select from: <Y/M/D>, <M/D/Y> or <D/M/Y>. “Y”

represents “Year”, “M” represents “Month” and “D” represents “Day”.

Use UP / DOWN keys to change the setting. The default setting is <Y/M/D> in

both NTSC / PAL formats.

 Time Display Mode

User can choose to set the time format to <12 hour> or <24 hour>. Use the

UP / DOWN keys to change the format. The default setting is <24 hour>.

User’s Manual

 Date/Time Order

The item is used to set the order of Date/Time display to <Date First> or

<Time First>. Select this item and press ENTER, then use UP / DOWN keys

to change the setting.

 Daylight Saving Time

The item is for people who live in certain regions to observe Daylight Saving

Time. Select <ON> to enable, or <OFF> to disable the function.

If the function is disabled, the DST Start / End time and DST Bias will be

grayed out and cannot be accessed. If this function is enabled, the date/time

information will be shown on the screen with a DST icon when playing back

recorded video or searching video in the event list. “S” indicates summer time

and “W” indicates wintertime.

 DST Start / End

The items are used to set the daylight saving duration. Use LEFT / RIGHT to

move the cursor to the next or previous field, UP / DOWN to change the

settings.

 DST Bias

The item allows user to set the amount of time to move forward from the

standard time for daylight saving time. Available options are <30>, <60>,

<90> and <120> minutes.

Users are allowed to assign a unit name, up to 11 characters, to the Triplex MPEG-4 DVR.

Follow the steps to edit the unit name.

• Select <Unit Name> from System Setup menu and press

ENTER. A virtual keyboard displays.

User’s Manual

Unit Name

A B C D E F G H I J K L M

N O P Q R S T U V W X Y Z

a b c d e f g h i j k l m

n o p q r s t u v w x y z

0 1 2 3 4 5 6 7 8 9

# − _

◄ ► Backspace Delete

Cancel OK

• Use Direction keys to move the cursor to the wanted character.

• Press ENTER to add the character to the entry field (up to 11 characters).

• When done, move the cursor to <OK> and press ENTER to save the settings

and exit.

The Password menu allows administrator to change the password settings

for accessing the unit. Select <Password> in System Setup menu and press

ENTER; the menu displays as follows.

Password

1. Admin Password

2. User Password

3. Enable Password

4. Load Factory Password

None

 Admin / User Password

Only the administrator is allowed to change the user and administrator

password to any 4~8 digit number. Use the UP / DOWN Direction keys to

select the desired account and press ENTER, the following menu is

displayed.

Admin Password

________

Press Channel Keys To Enter Password

(4-8 Digits)

Press ◄ To D e l e t e

Use CHANNEL keys to input the new password and confirm the new

User’s Manual

password. After setting the new password, press ENTER to save the settings

and exit.

 Enable Password

The item is used to determine if the password is required for accessing the

OSD menu. Select <YES> to demand entering password when accessing the

OSD menu; if not, select <NO>.

 Load Factory Password

This item allows the administrator to reload the factory password in case that

the administrator cannot remember the password. There are three options to

select from: <Admin> (reload the Admin password only), <User> (reload the

User password only), and <All> (reload the Admin and User passwords) and

<None>. The factory password is 1234 for administrator and 4321 for user.

The Network Setup menu allows the administrator to configure the network

by specifying the network related settings, such as IP address and Netmask,

etc.

See your network administrator and/or network service provider for more

specific information.

From the System Setup menu, select <Network Setup> and press ENTER.

The following menu displays.

Network Setup

1. LAN Setup

2. Trigger Port

3. DDNS Setup

Items in this menu are described in the following sections.

 LAN Setup

The network related settings in the LAN Setup menu should be associated

with the network service type.

Select <LAN Setup> in Network Setup menu and press ENTER for setting

the parameters; the menu displays as follows.

User’s Manual

LAN Setup

1. DHCP

2. IP

3. Netmask

4. Gateway

5. DNS

6. Connect At Booting

7. Network Restart

ON 0 .0 .0 .0 0 .0 .0 .0 0 .0 .0 .0

192.168.10.1 YES

- DHCP

This item allows user to obtain a dynamic IP address from DHCP

(Dynamic Host Configuration Protocol) server during the unit boots up.

When using DHCP, the settings are dynamic and they will change every

time you power up and power off the unit; depending on your network's

setup.

If the item is enabled (ON), a dynamic IP will be assigned to Triplex MPEG-4 DVR. In this case, user does not need to configure a static IP

and the Ethernet settings including IP address, Netmask, Gateway, and

DNS settings will be read-only. The default setting is <ON>.

If you are using permanent addressing, set DHCP to <OFF> for setting

the IP Address, Netmask, Gateway, and DNS. See your network system

administrators or IT personnel for appropriate values for these settings.

- IP

The item is used to configure the IP (Internet Protocol) address of the

unit. The IP address is the identifier for your computer or device on a

TCP/IP LAN or WAN. Please note that to set a static IP address, DHCP

must be set to <OFF>.

- Netmask

A netmask is a 32-bit mask used to divide an IP address into subnets

and specify the networks available hosts. Its value is defined by your

network administrator. It takes the form as ***.***.***.***, for example,

255.255.255.255.

This item allows user to enter the value of the Netmask for the unit.

Please note that to configure the item, DHCP must be set to <OFF>.

- Gateway

Gateway is a node on a network that serves as an entrance to another

User’s Manual

network.

Users are allowed to specify the IP address of the gateway or router

associated with this unit. To configure this item, DHCP must be set to

<OFF>.

- DNS

DNS is the abbreviation for “Domain Name Server”, which is an Internet

service that translates domain names into IP addresses. Because

domain names are easier to remember.

The item allows user to specify the IP address of the Domain Name

System associated with the unit. To configure this item, DHCP must be

set to <OFF>.

If the server is unavailable when using DHCP, the unit searches for the

network server and boots up more slowly. This network search

continues until it times out.

- Connect At Booting

The unit is allowed to connect to the internet automatically when

powered up. Select <YES> to connect at booting, otherwise select

<NO>. The default setting is <YES>.

- Network Restart

Network restart is required after changing network settings. Select

<YES> to restart the network device.

 Trigger Port

To avoid the default service port (port 80) to be blocked, the item enables

user to change port 80 into another port.

To change the trigger port, move the cursor over <Trigger Port> and press

ENTER, then adjust the setting by UP / DOWN keys.

 DDNS Setup

Dynamic Domain Name System (DDNS) allows a DNS name to be constantly

synchronized with a dynamic IP address. In other words, it allows those using

a dynamic IP address to be associated to a static domain name so others can

connect to it by name.

User’s Manual

Once the setting is completed, the DDNS address will be:

http://yourhostname.ddns.iview-ddns.com

For example, if the chosen Host name is “*******”, then the address will be:

http://*******.ddns.iview-ddns.com

Select <DDNS Setup> from Network Setup and press ENTER. The menu

displays as the figure below.

DDNS Setup

1. Enable DDNS

2. Host Name

3. DDNS Port

4. Submit/Update

5. ezDDNS

XXXX_XXXXXX

80 No No

- Enable DDNS

The item is used to enable or disable the Dynamic Domain Name

Service. Select <YES> to enable the service, or <NO> to disable.

- Host Name

The item allows user to setup a domain name, which is used when

entering the MPEG-4 DVR series unit through the net on your remote PC.

To setup the Host Name of the unit, follow the steps.

• Select <Host Name> from DDNS Setup menu and press ENTER.

A virtual keyboard displays as the figure below.

Host Name

A B C D E F G H I J K L M

N O P Q R S T U V W X Y Z

a b c d e f g h i j k l m

n o p q r s t u v w x y z

0 1 2 3 4 5 6 7 8 9

# − _

◄ ► Backspace Delete

Cancel OK

• Use Direction keys to select character.

• Press ENTER to add the selected character to the password entry

field.

• When done, move the cursor to <OK> and press ENTER to save the

settings and exit.

User’s Manual

NOTE: No any two MPEG-4 DVR series units should be set the same

Host Name.

- DDNS Port

The item allows user to setup the port for DDNS. Press UP / DOWN

Direction keys to change the port.

- Submit/ Update

When done, move the cursor to this item and press ENTER to submit the

settings.

NOTE: If there are two MPEG-4 DVRs series units set the same domain

name, the later setting will not be submit successfully.

- ezDDNS

ezDDNS enables the users to register the host name automatically.

Press ENTER and select YES. The following screen will display:

ezDDNS Submit/update ok!

Host name is XXXX_XXXXXX

Press any key to return

NOTE: The DVR must be connected to the *Real IP address, or be

assigned a specific port using **Port Forwarding technique.

*A "Real IP" is one that is assigned to you by your ISP.

**A "Virtual IP" is one assigned either manually or through DHCP.

When the user is assigned a Virtual IP, the user must use Port

Forwarding technique to assign a specific port to the DVR.

 <RS485 Setup>

This menu allows setting up the parameters of the unit’s RS-485 communications port.

From the Main menu, select <RS485 Setup> and press ENTER. The following menu is

displayed.

RS485 Setup

1. Unit ID

2. Baud Rate

3. Bits

4. Stop

5. Parity

224

9600

8 1

None

User’s Manual

 Unit ID

This item is used to change the RS-485 ID address of the unit. The ID is in

the range of <1> to <255>. The default is <224>.

 Baud Rate

The Baud rate options for associated with the protocol are <2400>, <4800>,

<9600>, <19200> and <38400>. The default is <9600> baud.

 Bits

User can specify the bits in a word that are associated with this protocol. The

available options are <6>, <7> and <8> bits. The default is <8> bits.

 Stop

User can specify the stop bit associated with this protocol. Options are <1>

and <2> stop bits. The default is <1> stop bit.

 Parity

This item is used to specify the parity associated with this protocol. Options

are <ODD>, <EVEN>, and <NONE>. The default is <NONE>.

The item is used to enable or disable the key tone. Select <YES> to enable the key tone, or

<NO> to disable.

Monitor Setup

The Monitor Setup menu allows user to tune the quality of the displayed image. Select

<Monitor Setup> from the Main menu and press ENTER. The following menu is displayed.

Main Menu

1. System Setup

2. Monitor Setup

3. Camera Setup

4. Record Setup

5. Sequence Setup

Monitor Setup

6. Event Setup

1. Show Camera Title

YES

7. Database Setup

2. Monitor Brightness

8. Configuration

3. Monitor Contrast

9. Shutdown

4. Monitor Chrominance

5. Screen Center Adjust

6. Show Color Bar

Execute

7. VGA Resolution

800x600

The following sections describe the items found in the Monitor Setup menu.

User’s Manual

This item allows user to choose whether to display the camera title on the screen or not.

The default is <YES>, which displays the camera titles with the video.

The function allows user to adjust the brightness of image displayed on the monitor. Move

the cursor to the item then press ENTER, and use UP / DOWN keys to adjust the numeric

value. The range of brightness values is <-128> to <127>. The default setting is <0>.

The item is used to adjust the color contrast of image. The range of contrast values is

<-128> to <127>; the default setting is <0>.

Move the cursor over the item and press ENTER for adjusting the chrominance of image

displayed on the monitor. Use UP / DOWN keys to adjust the numeric value. The range of

chrominance values is <-128> to <127>; the default setting is <0>.

The item is used to adjust the screen center of the main monitor display area. Follow the

steps to set the center point.

• Select <Screen Center Adjust> from the Monitor Setup menu and press

ENTER. The adjusting screen is as follows.

Screen Center Adjust

▲

◄ + ►

▼

• Position the screen center position using the Direction keys.

• Press ENTER to exit when finished.

User’s Manual

Choose this item to display a color bar pattern on the screen. The color bar helps to adjust

the monitor hue, saturation, text color, and display options. Press ESC to exit the color bar

pattern and return to the OSD menu.

The item allows user to select appropriate VGA resolution for the VGA monitor connected to the unit. The options are <800×600> (default), <1024×768> and <1280× 1024>.

NOTE: If the selected VGA resolution is too high for the monitor, the message “No

Signal’’ will be shown on screen. Then please press ESC on the front panel to

restore the original setting.

Camera Setup >

The items in the Camera Setup menu enable user to set camera parameters, including

camera title, dome protocol and ID for each connected camera. The menu is shown as

below.

Main Menu

1. System Setup

2. Monitor Setup

Camera Setup

3. Camera Setup

1. Camera Select CH3

4. Record Setup

2. Dome Protocol

None

5. Sequence Setup

3. Dome ID

6. Event Setup

4. Camera Title

CH3

7. Database Setup

5. Covert

8. Configuration

6. Termination

Yes

9. Shutdown

7. Brightness

8. Contrast

9. Saturation

10. Hue

Items in this menu are described in the following subsections.

The item is used to select a camera for setting the parameters. The related settings will

follow the selected camera, such as dome protocol and camera title. Move the cursor to

<Camera Select> and press ENTER, then select a channel using UP / DOWN keys.

User’s Manual

Select the communications protocol associated with your dome camera using the ENTER

and Direction keys. The available protocol includes <DynaColor>, <Pelco D>, <Pelco P>,

<AD422> and <None> (default).

This item is used to assign an ID number to the selected dome camera. Note that ID

number must match the ID address set by the dome.

This item allows the user to change the title of each camera connected to the unit. By

default, the titles of cameras are numbered from 1 through 16 respectively. The title is

displayed on screen after the changes of the titles are set.

Follow these steps to enter a new title for a camera.

• In the Camera setup Menu, move the cursor to Camera Title and press

ENTER. A virtual keyboard with alphanumeric characters is displayed.

Camera Title

A B C D E F G H I J K L M

N O P Q R S T U V W X Y Z

a b c d e f g h i j k l m

n o p q r s t u v w x y z

0 1 2 3 4 5 6 7 8 9

# − _

◄ ► Backspace Delete

Cancel OK

• Use Direction keys to position the cursor in the title entry field above the

virtual keyboard.

• Use Direction keys to move the cursor through the lists of characters to the

one you need. Press ENTER to select a character. Continue until the name is

established. Each title can contain up to 11 characters in it.

• After title entry is finished, move the cursor to <OK> and press ENTER;

otherwise, either press ESC, or move the cursor to <Cancel> and press

ENTER to abort.

User’s Manual

This function allows user to choose certain camera to be covert while the unit is continuing

recording video. Choosing <YES> means to cover the selected camera; and <NO> to

remain the selected camera non-covert. The default setting is <NO>.

To make a camera be covert, follow these steps:

• Select the channel that you want it to be covert from the <Channel Select>

item.

• After selecting the channel, move the cursor to <Covert> item and select

<YES>.

This item is used to enable / disable the 75-termination resistor inside the unit to adjust the

image quality of each camera. <YES>= termination resistor enabled (default), <NO> =

termination resistor disabled.

NOTE: If the camera loop-out connectors have not been used, the termination

resistor should be enabled for appropriate signal termination.

Move the cursor to the item and press ENTER for adjusting the brightness of the camera.

Use UP / DOWN keys to adjust the numeric value. The range of brightness values is

<-128> to <127>. The default setting is <0>.

Move the cursor to the item and press ENTER for adjusting the contrast of the camera. Use

UP / DOWN keys to adjust the value.

Move the cursor to the item and press ENTER to adjust the color saturation of the camera

using UP / DOWN keys. This value will be ignored on monochrome monitors. The range of

saturation values is <-128> to <127>. The default setting is <0>.

User’s Manual

<Hue>

Move the cursor to the item and press ENTER for adjusting the hue of the camera. Use UP

/ DOWN keys to adjust the value.

Record Setup

The following three factors will effect the total record time of Triplex MPEG-4 DVR:

• HDD capacity

• Recording Rate (Picture per Second)

• Image quality settings

The greater the recording rate and the higher the quality setting, the shorter the recording

time. Most of the related factors can be set here in this submenu.

The Record Setup menu allows user to set recording quality, recording schedules, and

other recording parameters. Administrator's password is required to access Record Setup

menu. In the Main menu, move the cursor to <Record Setup> and press ENTER. The

following menu is displayed.

Main Menu

1. System Setup

2. Monitor Setup

Record Setup

3. Camera Setup

1. Record Mode

720×240@120PPS

4. Record Setup

2. Schedule Setup

5. Sequence Setup

3. Preset Config

Standard

6. Event Setup

4. ezRecord Setup

7. Database Setup

5. Circular Recording

8. Configuration

6. Purge Data

9. Shutdown

The item is for selecting resolution and recording rate. The relative record settings, such as preset configuration, will follow the record mode setting. The options are <720 ×

480@30PPS>, <720 × 240@60PPS> and <360 × 240@120PPS> in NTSC (<720 ×

576@25PPS>, <720×288@50PPS>, <360×288@100PPS>in PAL).

Move the cursor to this item and press ENTER, then select a Record mode using UP /

DOWN keys.

User’s Manual

NOTE: After changing the Record Mode setting, the warning message “This will

FORMAT ALL HARDDISKS and LOAD THE FACTORY DEFAULT CONFIG!” will

be shown on the screen. Press ENTER to confirm the selection, then the unit

starts to format the hard disks and load the factory default settings, or press ESC

to abort.

We strongly recommend to backup your programmed configuration before making

any changes on Record Mode settings.

This submenu is used to set the day and night time, or weekend recording schedule.

The Night and Day schedules are used to define daytime and nighttime; the Weekend

schedule is tailored for weekends and holidays.

Select <Schedule Setup> from the Record Setup menu and press ENTER; the following

menu is displayed.

Schedule Setup

1. Day Time Start

2. Day Time End

3. Night Time Start

4. Night Time End

5. Weekend Schedule

6. Weekend Start

7. Weekend End

AM 06:00 PM 18:00 AM 06:00

PM 18:00

YES

Fri 18:00

Mon

06:00

 Day/ Night Time Start

The Day/Night Start Time determines the beginning of day/night recording

time. The time is indicated in 1-minute increments. The time display format in

this menu is based on the setting of Time Display Mode.

 Day / Night Time End

The Day/Night End Time determines the end point of day/night recording time.

The time is indicated in 1-minute increments. The time display format in this

menu is based on the setting of Time Display Mode.

 Weekend Schedule

The Weekend Schedule determines whether a weekend schedule is in effect.

Choose <YES> to take effect the related weekend settings.

User’s Manual

 Weekend Start/ End

The Weekend Start Time indicates the specific day and time that a weekend

begins, for example, FRI 18:00. The Weekend End Time indicates the

specific time and day that a weekend ends, for example, MON 06:00. Time is

indicated in 1-minute increments.

Note that the value you have set indicates when the regular Day and Night

scheduling ends, and Weekend recording begins.

The <Preset Config> is used to select the preset recording quality and frame rate. Different

default recording quality levels are offered for user to choose: <Best Quality>, <Standard>,

<Extended Record>, <ezRecord>, <Event Only>, <512Kbps DSL>, <256Kbps DSL> and

<128Kbps DSL>.

According to various Record modes, the preset configuration options for normal and event

status are described in terms of relative recording rate (PPS) and recording size for each

channel in the table below.

These preset conditions override any other quality and rate settings. The default Preset

Configuration setting is <Standard>.

Record Mode: Full-D1 mode (NTSC: 720×480@30PPS) (PAL: 720×576@25PPS)

Preset Configuration

Normal PPS Normal Size Event

PPS

Event

Size

Event Active

Best Quality

3.75 NTSC

(3.125 PAL)

20 KB

15 NTSC

(12.5 PAL)

20 KB

Both

(Alarm+Motion)

Standard (Default)

3.75 NTSC

(3.125 PAL)

14 KB

15 NTSC

(12.5 PAL)

20 KB Both

ezRecord Auto Auto Auto Auto Auto

Extended Record

3.75 NTSC

(3.125 PAL)

8 KB

15 NTSC

(12.5 PAL)

20 KB Both

Event Only N/A N/A

30 NTSC (25

PAL)

20 KB Both

512Kbps DSL

3 NTSC

(3 PAL)

3 KB

3 NTSC

(3 PAL)

3 KB Both

256Kbps DSL

3 NTSC

(3 PAL)

2 KB

3 NTSC

(3 PAL)

2 KB Both

128Kbps DSL

3 NTSC

(3 PAL)

1 KB

3 NTSC

(3 PAL)

1 KB Both

Record Mode: Half-D1 mode (NTSC: 720×240@60PPS) (PAL: 720×288@50PPS)

Preset Configuration

Normal PPS Normal Size Event

PPS

Event

Size

Event Active

Best Quality

3.75 NTSC

(3.125 PAL)

17 KB

15 NTSC

(12.5 PAL)

17 KB

Both

(Alarm+Motion)

User’s Manual

Standard (Default)

3.75 NTSC

(3.125 PAL)

11 KB

15 NTSC

(12.5 PAL)

17 KB Both

Extended Record

3.75 NTSC

(3.125 PAL)

5 KB

15 NTSC

(12.5 PAL)

17 KB Both

ezRecord Auto Auto Auto Auto Auto

Event Only N/A N/A

30 NTSC (25

PAL)

17 KB Both

512Kbps DSL

3 NTSC

(3 PAL)

3 KB

3 NTSC

(3 PAL)

3 KB Both

256Kbps DSL

3 NTSC

(3 PAL)

2 KB

3 NTSC

(3 PAL)

2 KB Both

128Kbps DSL

3 NTSC

(3 PAL)

1 KB

3 NTSC

(3 PAL)

1 KB Both

Record Mode: CIF mode (NTSC: 360×240@120PPS) (PAL: 360×288@100PPS)

Preset Configuration

Normal PPS Normal Size Event

PPS

Event

Size

Event Active

Best Quality

7.5 NTSC

(6.25 PAL)

14 KB

15 NTSC

(12.5 PAL)

14 KB

Both

(Alarm+Motion

)

Standard (Default)

7.5 NTSC

(6.25 PAL)

8 KB

15 NTSC

(12.5 PAL)

14 KB Both

Extended Record

7.5 NTSC

(6.25 PAL)

2 KB

15 NTSC

(12.5 PAL)

14 KB Both

ezRecord Auto Auto Auto Auto Auto

Event Only N/A N/A

30 NTSC (25

PAL)

14 KB Both

512Kbps DSL

3 NTSC

(3 PAL)

3 KB

3 NTSC

(3 PAL)

3 KB Both

256Kbps DSL

3 NTSC

(3 PAL)

2 KB

3 NTSC

(3 PAL)

2 KB Both

128Kbps DSL

3 NTSC

(3 PAL)

1 KB

3 NTSC

(3 PAL)

1 KB Both

NOTE: The total PPS is shared by 16 viewing windows, which means, even one

window hasn’t connected with a camera and displays no video, that window still

wastes pps. But if you select <ezRecord> for setting the unit, those windows with

no cameras connected to them will not be recorded, in other words, the pps will

not be wasted.

This item aims to avoid the complicated record settings, and to make the setup much

easier. Note that the item can be reached only when you select <ezRecord> as the option

for <Preset Config>.

Select <ezRecord Setup> from <Record Setup> and press ENTER, the sub-menu appears

as below figure:

User’s Manual

ezRecord Setup

How Many Days To Record Daytime Record Night Record Weekend Record

Average Normal PPS Average Normal Quality

2 Days

Yes Yes Yes

3.75

Best

To have the ezRecord Setup done, follow these steps:

• Select <How Many Days To Record> and press ENTER, then press

UP/DOWN to choose an option. The average normal PPS & Quality will be

adjusted automatically. The maximum of days depends of the size of your

HDD, in the other words, the larger the HDD installed, the more days the unit

can record.

• Move to <Daytime Record> and press ENTER. This item is for you to select

whether you want the DVR to record during daytime. If yes, using UP/DOWN

to select <Yes> as option; or, select <No> for not recording during daytime.

• Repeat the same procedures through the 3rd and 4th item, respectively. Note

that <Weekend Record> will be not accessible if you select <NO> for the item

<Weekend Schedule> in <Schedule Setup>.

• Select <Average Normal PPS> and press ENTER, then press UP/DOWN to

choose an option. The <How Many Days To Record> will be computed

automatically.

• Select <Average Normal Quality> and press ENTER, then press UP/DOWN

to choose an option. The <How Many Days To Record> will be computed

automatically.

NOTE: The current number of connected cameras will affect the

recording quality automatically calculated through the <ezRecord

Setup>. Therefore, once you disconnect cameras or connect more

cameras to the unit, you should reset the <ezRecord Setup>.

User can choose to record video in circular mode or in linear mode. If you choose to record

in circular mode, then the unit begins to overwrite the oldest recorded video; and stores

new video over the HDD spaces. If you choose to record in linear mode in stead, the unit

stops recording, and the internal buzzer starts beeping when the HDD is full.

From the Record Setup menu, move the cursor to <Circular Recording> and press ENTER,

then select <ON> / <OFF> using UP / DOWN keys.

Record Info

User’s Manual

This item is used to delete the Normal or Event recording video. In Record Setup menu,

move the cursor to <Purge Data> and press ENTER; the Purge Data menu is displayed.

Purge Data

1. Purge All Data

2. Purge All Event Data

3. Purge Event Before

4. Start to Purge

NO NO

2000/01/01

 Purge All Data

The item is used to delete all video from database(s). Using UP / DOWN keys

to select <YES> and start the deleting by setting the <Start to Purge> to

<YES>.

 Purge All Event Data

The item is used to delete all event video from database(s). Using UP /

DOWN keys to select <YES> and start the deleting by setting the <Start to

Purge> to <YES>.

 Purge Event Before

The item is used to delete event video before a specific date. Use LEFT /

RIGHT keys to move the cursor to next or previous field, ENTER to select the

item and UP / DOWN to adjust the value.

 Start to Purge

After selecting the video you want to delete or setting the date for deletion,

set this item to <YES> for start the deleting or choose <NO> to cancel.

User’s Manual

Sequence Setup

The Sequence Setup menu allows setting the camera sequence schedule and dwell time

for main and call monitor. Select <Sequence Setup> in Main menu and press ENTER; the

menu displays as follows.

Main Menu

1. System Setup

2. Monitor Setup

Sequence Setup

3. Camera Setup

1. Main Monitor Dwell 5 Sec

4. Record Setup

2. Main Monitor Schedule

5. Sequence Setup

3. Call Monitor Dwell

5 Sec

6. Event Setup

4. Call Monitor Schedule

7. Database Setup

8. Configuration

9. Shutdown

Items in the Sequence Setup menu are described in the following subsections.

The Main / Call Monitor can be set to display full screen video of all installed cameras in

sequence. This item is used to set the Main / Call Monitor dwell time, which is the amount

of time elapsed between switching images. The dwell time is in the range of 1 to 120

seconds. The default value is 5 seconds.

This item is used to set the Main / Call Monitor camera sequence in full screen format.

Move the cursor to <Main Monitor Schedule> and press ENTER; the menu is displayed as

follows.

Main Monitor Schedule

_►_►_►_►_►_►_►_► _►_►_►_►_►_►_►_

Press 1-16 Key To Select Channel

Press ◄ To D e l e t e

Follow these steps to set a sequence:

• Press LEFT direction key to delete the original setting.

• Press the desired Channel keys to assign a camera to that location in the

sequence.

User’s Manual

• Continue the steps until the sequence is completed.

A sequence can have up to 16 entries. User can select fewer than 16 entries for camera

sequence and leave the remaining entries blank. The sequence can include a specific

camera or cameras multiple times.

Event Setup

This menu allows user to determine Triplex MPEG-4 DVR behavior in response to an

alarm event. In the Main menu, move the cursor to <Event Setup> and press ENTER. The

following menu is displayed.

Main Menu

1. System Setup

2. Monitor Setup

Event Setup

3. Camera Setup

1. Internal Buzzer ON

4. Record Setup

2. Event Icon

5. Sequence Setup

3. Alert Notification Setup

6. Event Setup

4. Event Duration

5 Sec

7. Database Setup

5. Per Channel Config

8. Configuration

9. Shutdown

Items in the Event Setup menu are described in the following subsections.

This item allows user to enable / disable the Triplex MPEG-4 DVR internal buzzer. If set to

<ON>, the buzzer is activated in response to an alarm. If set to <OFF>, the buzzer is not

activated. The default setting is <ON>.

The item enables (ON) / disables (OFF) the display of Event Icon on the main monitor

when an alarm event occurs. The default setting is <ON> (enable).

The event types are represented by a character respectively; the descriptions are as below

table.

Event type Description

Alarm in event

Motion detection event

Video loss event

User’s Manual

This function allows the user to send alert notifications through the CMS

program. For detailed setup instruction, please refer to the CMS user’s

manual.

Alert Notification Setup

1. Alert Configuration Set 1

2. Alert Notification OFF

3. Alert IP 0.0.0.0

4. Alert Port 80

- Alert Configuration Set

Alert Configuration Set provides 3 combinations of Alert Notification, IP,

and Port.

- Alert Notification

4 options are included in this item; OFF, Event, Alive, and Both.

<OFF>: The Alert Notification is OFF.

<Event>: When the alarm is triggered, the DVR will send an alert

message to the CMS.

<Alive>: The DVR will send an alert message to the CMS every 2

minutes which also indicates that the connections between

the DVR and CMS is in effect.

<Both>: This enables the DVR to send both Event and Alive alert

package to the CMS.

- Alert IP

The Alert IP must match the IP address of the computer.

- Alert Port

The ports for both DVR and the CMS Alert must be the same.

This item determines the duration of the buzzer and Alarm Out relay function

after an alarm is triggered. The available event duration range is from 1

second to 100 seconds. The default setting is 20 seconds.

User’s Manual

This menu is used to set the Video Loss Detect, Motion Detect and Alarm In /

Out function for each channel. The menu is displayed as below.

Per Channel Config

1. Channel Select

2. Video Loss Detect

3. Motion Detect

4. Detection Config

5. Alarm In

6. Alarm Out

CH1 OFF OFF

OFF

None

 Channel Select

The item is used to select a desired channel for setting the parameters. Move

the cursor to <Channel Select> and press ENTER, then select a channel

using UP / DOWN keys. Press ENTER again to confirm the setting.

 Video Loss Detect

This item allows user to enable / disable Video Loss as an alarm event.

Select <ON> to enable Video Loss alarm events, <OFF> to disable. The

default setting is <ON>.

 Motion Detect

To detect motions, the users can choose from these options: <OFF>, <ALL>,

<Night & Weekend>, <Day & Weekend>, <Weekend>, <Day & Night>,

<Night>, and <Day>.

The Day, Night, and Weekend is defined in <Schedule Setup> section.

If motion detection function is enabled, it is required to define the motion

detection parameters such as detection area and sensitivity settings.

 Detection Configuration

If motion detection function is enabled, it is required to define the motion

detection parameters such as detection area and sensitivity settings. Select a

channel for setting the parameters, move the cursor to <Detection Config>,

and press ENTER. The Detection Configuration menu displays as follows.

User’s Manual

Detection Config

1. Detected Area Setup

2. Sensitivity

3. Area Threshold

88%

----- Detected Area Percentage ----40%

▲

- Detected Area Setup

The Detect Area is displayed as follows after selecting this item. The detection area consists of 273 (21×13) detection grids in NTSC video

format or 336 (21×16) grids in PAL format.

■

■ ■ ■

■ ■ ■ ■ ■ ■ ■ ■ ■ ■

■ ■ ■

Use the Direction keys to move the cursor and press ENTER to enable

or disable a grid. Press MODE to select all of the grids for detection;

press MODE again to de-select all of the grids.

- Sensitivity

The item is used to set the sensitivity of detection grids for the camera. A

greater value indicates more sensitive motion detection. A motion alarm

will be triggered, once the amount of motion detected exceeds the

Threshold value

Move the cursor to <Sensitivity> and press ENTER, and then use UP /

DOWN keys to adjust the value. The value is indicated in 4% increment.

- Area Threshold

<Area Threshold> means the motion alarm triggered level; if the

percentage of triggered grids to total detection area is greater than the

set value, the motion alarm will be triggered.

For example, if 10 grids are selected and the < Area Threshold > value

is 70%, the motion alarm will be triggered when 7 grids are motion

detected.

User’s Manual

Move the cursor to < Area Threshold > and press ENTER, and then use

UP / DOWN keys to adjust the value. The value is indicated in 4%

increment.

- Detected Area Percentage

The part shows the percentage and variation of the detected volume.

 Alarm In

This item allows user to enable / disable alarm input detection. According to

your application, select <N/O> (Normal Open) or <N/C> (Normal Close) to

enable the alarm input detection or select <OFF> to disable the detection.

The default setting is <OFF>.

If you set this item to <N/C> but did not install any device to the unit, the

alarm will be triggered and the Event Icon displayed continually until this item

is changed to <N/O>, <OFF> or install a device to the unit.

 Alarm Out

This item allows user to assign an alarm on certain channel to activate the

relays. These signals can be used to drive a light or siren to caution an alarm

event.

Select from the options: <A Only > indicates “Alarm Out A”, <B Only>

indicates “Alarm Out B”, <A+B> indicates “A and B Alarm Out” and <None>

indicates “No Alarm Out”. The default setting is <None>.

Database Setup

The menu displays information of internal and external disks. In the Main menu, move the

cursor to <Database Setup> and press ENTER. The following menu is displayed.

Main Menu

1. System Setup

2. Monitor Setup

Database Setup

3. Camera Setup

1. Total Size xxx GB

4. Record Setup

2. Free Size

xxx GB

5. Sequence Setup

3. Internal Disks

6. Event Setup

4. External Disks

7. Database Setup

8. Configuration

9. Shutdown

User’s Manual

NOTE: If the hard disk cannot be detected , the message “HDD fail” will display.

The Total Size of HDD shows the total capacity of HDD that has been added into database.

The Free Size of HDD indicates the free space for recording of the HDD added in database.

The information is read-only.

Select <Internal Disks> or <External Disks> to see information on the storage devices

connected to the unit. The submenu is displayed as below.

Internal Disks

Name xxx xxxxxxx-xxxxxx

ctive YES

Action

None

The information of built-in HDD and external storage device will be listed by model name

and status. If no storage device connects to the unit, the message “No Available Items!” will

show on screen.

NOTE: If the file system of the internal HDD is not compatible for the DVR, the system will format the internal HDD automatically without notice.

Active

The item indicates if the storage device is added into database or not. <YES>

means the device has been added into database.

Action

The item allows user to add storage device into database or remove device

from database.

The options are <None> (no action), <Add> (add the selected device into

database), <Remove> (remove the selected device from database),

<Format> (format the selected device).

NOTE: Before removing external devices from the unit, remember

to remove the device from database.

User’s Manual

Configuration

The Configuration menu can be used to restore the default factory settings, import and

export configuration.

Select <Configuration> from the Main menu and press ENTER. The following menu is

displayed.

Main Menu

1. System Setup

2. Monitor Setup

3. Camera Setup

4. Record Setup

Configuration

5. Sequence Setup

1. Load Factory Default

6. Event Setup

2. Import Config

7. Database Setup

3. Export Config

8. Configuration

9. Shutdown

Items in this menu are described in the following subsections.

This item is used to load the factory setting; select <YES> to recall the factory default setup

configuration from the read-only memory, or <NO> to cancel.

This item allows user to load a unit configuration that was saved in an external drive. To

import a configuration that was previously exported, make sure the device that saved the

configuration is connected to the unit. Select <Import Config> from the Configuration menu

and press ENTER. The following menu is displayed.

Import Config

Config Name xxxx-xxxx xxx-xx

Select

NO NO

Press UP / DOWN to select one of the listed available configuration files, and choose

<YES> to start import.

User’s Manual

NOTE: If the imported configuration has different record mode from the unit’s, the warning message “This config has different record mode. This will FORMAT ALL

HARDDISKS.” will show.

NOTE: Remove the ThumbDrive

used for importing configuration after the unit

restarts, or it will be formatted as well.

The Administrator is allowed to save a unit configuration by exporting it to an external drive,

such as a USB Flash Drive. Before exporting the configuration, make sure the device in

which the configuration will be saved is attached to the unit appropriately. Select <Export

Config> from the Configuration menu and press ENTER. The following menu is displayed.

Export Config

1. Copy Destination

2. Config Name

3. Begin Export

Items in this menu are described in the following sections.

 Copy Destination

Select this item to list available destinations (external memory devices) to

which the configuration can be exported. Press UP / DOWN to set a

destination. Please note that saving a different configuration to the same

copy destination with the same file name will overwrite the previous

configuration file without warning.

NOTE: Users are not allowed to select any CD-R/W or DVD+RW as

a copy destination, including built-in CD-R/W and DVD+RW.

 Configuration Name

This item allows user to assign the exported configuration file a name. Use

the virtual keyboard to enter the configuration file name. Note that the file

name can contain up to 15 characters, with no spaces.

 Begin Export

Select <YES> to begin exporting the configuration file, or <NO> to abort the

export.

User’s Manual

NOTE: We strongly recommend users to export configuration before

upgrading your system, and back it up routinely, just in case for

unexpected situation.

Shutdown

The item is used to shut down or reboot the unit. If you must shut down the Triplex MPEG-4 DVR for any reason, please use the proper shut down and power up procedures

to avoid damage to your unit.

To restart/ shutdown the unit, you have to enter the OSD setup menu with correct

Administrator Password, otherwise, the <Shutdown> menu will be unable to access.

Select <Shutdown> in Main menu and press ENTER to access the Shutdown menu, which

displays as follows.

Shutdown

1. Power Off

2. Reboot

Execute Execute

Power Off

Select this item to shut down the unit. Do not remove the power during shut

down until the message “You can safely turn off DVR now!” displays.

Reboot

Select this item to reboot the unit. The color bar and system checking

information are displayed on the monitor until the unit is completely restarted.

User’s Manual

Appendix A: Technical Specifications

All specifications are subject to change without notice.

Specifications 8CH Triplex MPEG-4 DVR 16CH Triplex MPEG-4 DVR

Video Operation System

Embedded (Linux)

Video Stand

NTSC/PAL switch selectable

Video Operation

Triplex+ (Live, Record, Playback, Remote, and Internet access)

Resolution- Live Video

NTSC: 720x480 pixels; PAL: 720x576 pixels

Input

BNCx16, 1.0Vp-p/75 ohm

Main Monitor

BNCx1, S-Videox1, 1.0Vp-p/75 ohm

Call Monitor

BNCx1, 1.0Vp-p/75 ohm

Outputs

Loop

BNCx8, 1.0Vp-p/75 ohm BNCx16, 1.0Vp-p/75 ohm

VGA Output

800x600, 1024x768, 1280x1024 pixels @ 60Hz (Optional)

Picture Refresh Rate

NTSC: 480PPS (16 CH); PAL: 400PPS (16CH)

Digital Zoom

2x2

Camera Installation

Plug & Play

Audio Input

RCAx1, Line-In

Output

RCAx1, Line-Out

Recording Mode

Always Real Time Record, Synchronized w/ Video

Compression Method

ADPCM, G.726

File Size

8KB/Sec

Operation

Remote + VCR mode

Playback

Only for Video Original Speed

Recording Compression Method

MPEG-4 Advanced Simple Profile

Recording Mode

Schedule, Alarm, Motion Detection

Resolution & Rate

NTSC: 30PPS@720x480 pixels; PAL: 25PPS@720x576 pixels

NTSC: 60PPS@720x240 pixels; PAL: 50PPS@720x288 pixels

NTSC: 120PPS@360x240 pixels; PAL: 100PPS@360x288 pixels

Recording Quality

5 levels presets, adjustable

Image Size

2K to 20K Byte/Picture

Storage Mode

Linear/Circular

Playback Playback

Play, Stop, Pause, Rewind, Forward, Search

Playback Speed Adjustment

Yes (1x, 2x, …32x)

User’s Manual

Retrieve

Date/Time, Event

Storage Build-in Storage

X2 ATA 133/ UDMA 133 IDE, HDD/CD-RW

Built-in HDD

Up to 2 built-in HDDs

Export

X3 USB2.0 ports, support ThumbDrive

and CD-RW

Alarm Alarm Input

X16, Terminal Block

Alarm Detection

N.C./N.O., Programmable

Auditory Alert

Built-in Buzzer

Motion Detection

21x13 (NTSC), 21x16 (PAL) Grid Array,

Sensitivity, Trig Level Adjustable

Video Loss Detection

Programmable

Alarm Relay Output

X2, Terminal Block, 1.0A/24V (Programmable)

Communication Network Connectivity

Ethernet RJ-45 connector, 10/100Mbps, supports DHCP

Remote Control Software

DVRRemote

Access Control

2 Level Password

Remote Operation

Monitoring, Instant Recording, Dome Camera Control

RS485

Terminal Block

Dome Control Protocol

DynaColor, Pelco P, Pelco D, AD422

General Unit Dimension (WxHxD)

440x90x345mm (17.3x3.45x13.58 inches)

Unit Weight

5.7Kg (12.56 Ibs) w/ CD-RW

Package Dimension (WxHxD)

590x210x460 mm (23.2x8.27x18.1 inches)

Package Weight

8.2Kg (18.06 Ibs)

Operation Temperature

0°C - 40°C (32°F - 104°F)

Relative Humidity

5% - 85% Non-condensing

Power Consumption & Input

AC 100 ~ 240V, 50-60Hx, 80W

User’s Manual

Appendix B: Record Duration

The record duration relates to recording rate, image quality and HDD capacity. Refer to the

following table.

NOTE: Record duration times are based on actual tests and represent average

file sizes. Performance may vary depending on specific installations and use.

Audio recording requires 8 KB per second (or 0.7 GB per day) for data storage.

Number of Days of Recording @30PPS (without Audio)

Recording Rate Recording Picture Quality Mode

Low Fair Mid High Best

Total

Images Per

Second

NTSC

Total

Images Per

Second

PAL

NTSC

(8 KB)

PAL

(8 KB)

NTSC

(11 KB)

PAL

(11 KB)

NTSC

(14 KB)

PAL

(14 KB)

NTSC

(17 KB)

PAL

(17 KB)

NTSC

(20 KB)

PAL

(20 KB)

160 GB Internal Storage

30 25 7.5 9.0 5.5 6.6 4.3 5.2 3.6 4.3 3.0 3.7

15 12.5 15.0 18.0 11.0 13.2 8.7 10.4 7.2 8.6 6.1 7.3

7.5 6.25 29.9 35.9 21.9 26.3 17.3 20.8 14.3 17.2 12.2 14.6

300 GB Internal Storage

30 25 14.0 16.8 10.3 12.3 8.1 9.7 6.7 8.1 5.7 6.9

15 12.5 28.1 33.7 20.6 24.7 16.2 19.5 13.4 16.1 11.4 13.7

7.5 6.25 56.1 67.3 41.2 49.4 32.5 39.0 26.8 32.2 22.9 27.4

600 GB Internal Storage

30 25 28.1 33.7 20.6 24.7 16.2 19.5 13.4 16.1 11.4 13.7

15 12.5 56.1 67.3 41.2 49.4 32.5 39.0 26.8 32.2 22.9 27.4

7.5 6.25 112.2 134.7 82.3 98.8 65.0 78.0 53.7 64.4 45.7 54.9

User’s Manual

Number of Days of Recording @60PPS (without Audio)

Recording Rate Reco rding Picture Quality Mode

Low Fair Mid High Best

Total

Images Per

Second

NTSC

Total

Images Per

Second

PAL

NTSC

(5 KB)

PAL

(5 KB)

NTSC

(8 KB)

PAL

(8 KB)

NTSC

(11 KB)

PAL

(11 KB)

NTSC

(14 KB)

PAL

(14 KB)

NTSC

(17 KB)

PAL

(17 KB)

160 GB Internal Storage

60 50 5.9 7.1 3.7 4.5 2.7 3.3 2.2 2.6 1.8 2.1

30 25 11.8 14.1 7.5 9.0 5.5 6.6 4.3 5.2 3.6 4.3

15 12.5 23.5 28.2 15.0 18.0 11.0 13.2 8.7 10.4 7.2 8.6

7.5 6.25 47.0 56.4 29.9 35.9 21.9 26.3 17.3 20.8 14.3 17.2

300 GB Internal Storage

60 50 11.0 13.2 7.0 8.4 5.1 6.2 4.1 4.9 3.4 4.0

30 25 22.0 26.5 14.0 16.8 10.3 12.3 8.1 9.7 6.7 8.1

15 12.5 44.1 52.9 28.1 33.7 20.6 24.7 16.2 19.5 13.4 16.1

7.5 6.25 88.2 105.8 56.1 67.3 41.2 49.4 32.5 39.0 26.8 32.2

600 GB Internal Storage

60 50 22.0 26.5 14.0 16.8 10.3 12.3 8.1 9.7 6.7 8.1

30 25 44.1 52.9 28.1 33.7 20.6 24.7 16.2 19.5 13.4 16.1

15 12.5 88.2 105.8 56.1 67.3 41.2 49.4 32.5 39.0 26.8 32.2

7.5 6.25 176.4 211.6 112.2 134.7 82.3 98.8 65.0 78.0 53.7 64.4

Number of Days of Recording @120PPS (without Audio)

Recording Rate Reco rding Picture Quality Mode

Low Fair Mid High Best

Total

Images Per

Second

NTSC

Total

Images Per

Second

PAL

NTSC

(2 KB)

PAL

(2 KB)

NTSC

(5 KB)

PAL

(5 KB)

NTSC

(8 KB)

PAL

(8 KB)

NTSC

(11 KB)

PAL

(11 KB)

NTSC

(14 KB)

PAL

(14 KB)

160 GB Internal Storage

60 50 13.7 16.5 5.9 7.1 3.7 4.5 2.7 3.3 2.2 2.6

30 25 27.4 32.9 11.8 14.1 7.5 9.0 5.5 6.6 4.3 5.2

15 12.5 54.9 65.8 23.5 28.2 15.0 18.0 11.0 13.2 8.7 10.4

7.5 6.25 109.7 131.7 47.0 56.4 29.9 35.9 21.9 26.3 17.3 20.8

300 GB Internal Storage

60 50 25.7 30.9 11.0 13.2 7.0 8.4 5.1 6.2 4.1 4.9

30 25 51.4 61.7 22.0 26.5 14.0 16.8 10.3 12.3 8.1 9.7

15 12.5 102.9 123.5 44.1 52.9 28.1 33.7 20.6 24.7 16.2 19.5

7.5 6.25 205.8 246.9 88.2 105.8 56.1 67.3 41.2 49.4 32.5 39.0

User’s Manual

600 GB Internal Storage

60 50 51.4 61.7 22.0 26.5 14.0 16.8 10.3 12.3 8.1 9.7

30 25 102.9 123.5 44.1 52.9 28.1 33.7 20.6 24.7 16.2 19.5

15 12.5 205.8 246.9 88.2 105.8 56.1 67.3 41.2 49.4 32.5 39.0

7.5 6.25 411.5 493.8 176.4 211.6 112.2 134.7 82.3 98.8 65.0 78.0

Triplex MPEG-4 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
