User Manual
9200B
300A AC TRMS Clamp
5 Commonwealth Ave
Woburn, MA 01801
TestEquipmentDepot.com
Page 2
Introduction
Congratulations on your purchase of the Triplett 9200B 300A True RMS AC
Current Clamp meter. The True RMS AC/ Current Clamp meter features:
3-3/4digit (4000 count) LCD display
White LED backlight
Data HOLD
Built-in non-contact AC voltage detector plus flashlight
Autoranging with auto power off
Safety
International Safety Symbols
This symbol, adjacent to another symbol or terminal, indicates the
user must refer to the manual for further information.
This symbol, adjacent to a terminal, indicates that, under normal use,
hazardous voltages may be present
Double Insulation
This meter has been designed to be safe in use, but the operator
must use caution in its operation. The rules listed below should be
carefully followed for safe operation.
SAFETY NOTES
Do not exceed the maximum allowable input range of any function.
When the instrument is not in use, press the ON/OFF key to turn off the
meter.
Remove the battery if meter is to be stored for longer than 60 days.
NEVER apply voltage or current to the meter that exceeds the specified
maximum:
Page 3
1. USE EXTREME CAUTION when working with voltages greater than
Input Limits
Function
Maximum Input
AC Current
300A
25VAC rms. These voltages are considered a shock hazard.
2. NEVER operate the meter unless the back cover and the
battery/fuse door are in place and fastened securely
Meter Description
1. Current Clamp
2. Clamp Trigger
3. Non-contact AC Voltage Indicator Sensor
4. Power Button
5. Data HOLD/Backlight Button
6. LCD Display
7. Wrist Lanyard
Display Description
Data Hold
Minus sign Negative reading display
0 to 3999 Measurement display digits
AUTO Auto Range mode
AC Alternating Current
Low battery
Page 4
Operation
WARNING: Risk of Electrocution. Before use, always test the
Voltage Detector on a known live circuit to verify proper
operation
AC Current Measurements
1) Set the Function switch to the ACA range.
2) Press the jaw trigger and clamp around,
a single conductor.
3) Do not allow a gap between the two halves of the
jaw.
4) Refer to the diagram at right for
The correct way to enclose a single conductor.
5) Read the ACA value on the LCD.
Non-Contact AC Voltage Measurements
1) Touch the probe tip to the hot conductor or insert into the hot side of
the electrical outlet.
2) If AC voltage is present, the detector light will illuminate.
NOTE: The conductors in electrical cord sets are often twisted. For best
results, rub the probe tip along a length of the cord to assure
placing the tip in close proximity to the live conductor.
NOTE: The detector is designed with high sensitivity. Static electricity or
other sources of energy may randomly trip the sensor. This is
normal operation
Page 5
Data Hold/ LCD Backlight Button
To freeze the LCD reading, press the HOLD button. While data hold is active,
the HOLD icon appears on the LCD. Press the HOLD button again to return
to normal operation.
LCD Backlight
Press and hold the “Hold Backlight” key for more than 2 seconds to turn on
the backlight. This will also activate the Data Hold function. To release the
Data Hold function and return the meter to normal operation, press the Data
Hold key momentarily. To turn off the backlight, press and hold the “Hold
Backlight” key for more than 2 seconds
Automatic Power OFF
In order to conserve battery life, the meter will automatically turn off after
approximately 15 minutes. To turn the meter on again, please press
“ON/OFF” key again.
ON/OFF BUTTON:
Power-On: Pressing the ON/OFF button momentarily will turn the meter on.
Power-Off: While the meter is on, pressing the ON/OFF button for more than
1 second turns the meter off.
Battery Replacement
1) When the low battery symbol appears on the LCD the batteries
must be replaced.
2) Power down and remove the rear battery compartment Phillips
screw.
3) Lift off the battery compartment cover and replace the two 1.5V AAA
cells.
4) Replace compartment cover and secure the screw.
Page 6
Maintenance
Cleaning and Storage
Periodically wipe the case with a damp cloth and mild detergent; do not use a
brasives or solvents. If the meter is not to be used for 60 days or more,
remove the battery and store it separately.
Battery Replacement
1. Remove the Phillips head screw that secures the rear battery door
2. Open the battery compartment
3. Replace the two AAA battery
4. Secure the battery compartment
Page 7
Specifications
Function
Range
Resolution
Accuracy (of reading)
AC Current (50 to
400Hz)
40.00A
0.01A
±(2.8% + 15 digits)
300.0A
0.1A
±(3.0% + 15 digits)
Non-Contact AC
Voltage
200VAC to 1000VAC 50/60Hz
General Specifications
Display: 3-3/4 (4000 count) Digit LCD with white LED backlight
Sampling Frequency: 3 samples per second
Battery: Two 1.5V AAA batteries
Low Battery indication “ ” displayed on the LCD
Auto OFF approx. 15 minutes
ACA Bandwidth: 50Hz to 400Hz
AC Response: True RMS
Operating conditions 32ºF to 86ºF (0ºC to 30ºC) 90%RH; 86ºF to 104ºF
Storage conditions - 14ºF to 140ºF (-30ºC to 60ºC); < 90% Relative
Humidity
Altitude Operate at less than 3000 meters
Standards IEC61010 Category III 300V,
(30ºC to 40ºC) 75%RH; 104ºF to 122ºF (40ºC to
50ºC) 45%RH
For not sinusoidal waveforms the frequency range is: 50Hz to 60Hz
Overload protection: 300A AC
Page 8
Warranty Information
Triplett / Jewell Instruments extends the following warranty to the original purchaser of
these goods for use. Triplett warrants to the original purchaser for use that the products sold
by it will be free from defects in workmanship and material for a period of (1) one year from
the date of purchase. This warranty does not apply to any of our products which have been
repaired or altered by unauthorized persons in any way or purchased from unauthorized
distributors so as, in our sole judgment, to injure their stability or reliability, or which have
been subject to misuse, abuse, misapplication, negligence, accident or which have had the
serial numbers altered, defaced, or removed. Accessories, including batteries are not
covered by this warranty
Copyright © 2022 Triplett
