GAMBIT
USER MANUAL
Version 1.0, Date: 14.4.2019
Introduction
Welcome
Welcome to the Triple Seven Team! We are excited that you
have chosen to y the Gambit. Our CCC certied Gambit
is developed for maximum performance while remaining
comparatively easy to y. This glider is designed for top
level XC and competition ying. We wish you exciting
ying adventures!
Triple Seven Mission
Our company’s goal is to produce high quality products
and technologically innovative gliders of all types and
classes. We are striving to develop state of the art
paragliders, with the optimum compromise between
safety and performance.Your success is our inspiration;
our goal is your success.
Manual
This document contains complete product information
and instructions to familiarise you with the main
characteristics of your new glider. It contains instructions
on how to use and maintain the wing, however, its
purpose is not to serve as learning material to pilot this
kind of wing. As such, this is not a ying manual. Flying
can only be taught by ying schools and specially certied
instructors.
It is important that you take time to read this manual
carefully before the rst ight, as thorough knowledge of
your equipment enables you to y safely and to maximize
your full potential. If you sell, lend or give your glider to
another pilot, please pass this manual on with it.
If any use of Triple Seven equipment remains unclear
after having read this manual, please contact: your local
paragliding instructor, your Triple Seven importer or Triple
Seven. This product manual is subject to changes without
prior notice. Please check www.777gliders.com for the
latest information regarding our products.
4
6.1. First Flight 13
6.2. Preight check equipment 13
9.1. Technical data 26
9.2. Materials description 26
1. GAMBIT 1
2. High performance CCC 3
III. Introduction 4
III.i. Welcome 4
III.ii. Triple Seven Mission 4
4. Gambit 7
4.1. Designer’s thoughts 8
4.2. Who is this glider for? 9
4.3. Certication 9
5. Before ight 10
5.1. Elements, components 10
5.2. Assembly 10
5.3. Harness 11
5.4. Accelerator settings 11
5.5. Brakes’ adjustments 11
5.6. Weight range 12
5.7. Wing ination 12
5.8. Modications on the glider 12
5.9. Preight safety 12
6. Flying Gambit 13
6.3. Final preight check 14
6.4. Ination, control, take-off 14
6.5. Line knots or tangles 14
6.6. Normal ight, best glide 15
6.7. Minimum sink 15
6.8. Accelerated ight 15
6.9. Active ying 15
6.10. Flying in turbulence 16
6.11. Fast decent techniques 17
6.12. Winch launch 19
6.13. Aerobatics 19
6.14. Primary controls failure 19
6.15. Landing 19
7. Maintenance 20
7.1. General advice 20
7.2. PacGambit instructions 20
7.3. Storage 21
7.4. Cleaning 21
7.5. Repair 21
7.6. Checks and control 21
VIII. PacGambit Gambit 22
9. Technical data 24
9.3. Gambit risers arrangement 27
9.4. Line plan Gambit 28
9.5. Line lengths Gambit M 29
X. Safety and responsibility 30
XI. Guarantee 31
XII. Registration information 32
XIII. Get involved 32
XIV. Contact 33
5
6
» Reinforced leading edge (RLE), Smooth trailing edge reinforcements
(STE) together with (BPI) for greater stability and good gliding
performance on wide speed range
» BPI - back position intake technology for spin and stall resistance and
good stability at accelerated ight.
» Low induced drag wing tip (LDW), optimized washout with two
additional oating cells.
» Three liner concept, with considerable line reduction (LR)
» 5 cells diagonals (RLE) reinforced leading edge
» Good pitch stability and ease of piloting
» Trim speed optimized for good climbing
» Clean canopy with rened sail tensions
» Direct handling with precise control
» Full span distributed panels orientation streamlined to airow direction
» Improved double 3d shaping (ballooning) at the leading edge
» High top speed
» Easy launch control
» CCC certied, dedicated competition and cross country paraglider
7 7
Designer’s thoughts
“At this level, the one overriding concern is “can I win top-level
comps on this wing?” Only when I was certain that the answer
to this question was “yes” did we go for certication. But we
also wanted to make a competition glider that was a joy to y,
and we have succeeded. It is obviously not for everyone, but
in the right hands this is quite probably the greates paraglider
ever to have gone into mass production.”
Urban Valič
8
Who is this glider
for?
The Gambit is a CCC class wing designed for
advanced pilots. The stability at top speed,
and the glide ratio, makes it the perfect wing
for world-class pilots with the goal to win big
events.
The pilot of this wing should be comfortable
with the advanced active ying techniques
of controlling a glider in active air, naturally
preventing pitch or roll movements. As with any
glider, we recommend constantly improving
your basic and advanced ying skills.
9
Pilot prole
The Gambit is built for top-level competition
pilots who fly several big competitions every year.
10
Assembly
Before you rush to the rst take-off we recommend you take your
time to unpack and test your equipment on a training slope. In
this way you will have time and will not be distracted or rushed
to prepare your equipment, and you will be able to do your rst
pre-ight check properly.
The place should be at, free of obstacles, and with light wind.
This will enable you to nicely inate the wing and also familiarize
yourself with it while ground handling. Every glider has to be
checked by a Triple Seven dealer, however, as a pilot you want to
do a proper pre-ight check yourself.
First, prepare and spread out the glider like you would normally
do. While you are spreading out and walk along the glider, observe
the fabric material for any abnormalities. When you are done with
the inspection of the canopy, grab the risers and spread the lines,
check if the risers and maillons (carabiners) are properly closed.
Identify and disentangle the A1, A2, B risers
and the lines including the brake lines. Connect the risers’ main
attachment points correctly to the harness, watch for any twists
and make sure that the main carabiners are properly closed.
Harness
The Gambit has passed CCC certication testing using a GH ABS type harness. This certication allows the Gambit to be own
with most of the harnesses on the market, but keep in mind that
changing the harness greatly inuences the feeling of the glider,
depending on the effectiveness of the harness weight shift. Always
check whether your harness is of the proper type.
The length of the harness chest strap affects the distance between
the main carabiners and the wing’s handling as well as your stability
in the harness. Tightening the chest strap increases your stability,
but greatly increases the risk of twisting after a collapse. A tight
setting also increases the tendency to maintain a deep spiral. As a
rule of thumb, a more opened chest strap gives you more feedback
from the glider, which is good for your climbing efciency and
increases safety in a ying incident. But we strongly recommend
adjusting the length of the harness chest strap according to the
lengths used during certication. This setting varies according to
the harness size from 42cm to 50cm.
Check the settings used during testing under the certication
specimen section. We recommend that your rst ight with the
Gambit is not also with a new harness. A rule of thumb is, if you
want to experience the feeling of new equipment, change only
one part of equipment at a time.
Weight range
Each size of the Gambit is certied for its own weight range.
This total weight includes the weight of the pilot and complete
paragliding equipment, together with the glider, harness,
all accessories and optional ballast. Every glider changes its
characteristics by changing the take-off weight. We recommend
that you always y your glider in the specied weight range.
To measure your take-off weight, step on a scale with all your
equipment packed in the rucksack.
11
Lower half of the weight range
Flying the Gambit, as any other glider, in the lower part of the
weight range, causes the agility of the glider to decrease, and
when ying through turbulence its tendency for collapses increases
relatively compared to ying it in the upper wing loading range.
However, reactions after a collapse are less dynamic and sink
rate improves. Therefore, if you mainly y in weak conditions, you
might prefer this weight range.
Upper half of the weight range
Again, as with any other glider, ying the Gambit in the upper part
of the weight range increases the stability and agility of the glider.
Consequently, there is a slight increase in the glider’s speed and
also gliding performance, especially when ying against the wind.
If you normally y in stronger conditions and you prefer relatively
more dynamic ying characteristics, you should set the take-off
weight in the higher weight range. Reactions after a collapse may
be more dynamic in the upper half of the weight range.
Wing ination
Still being on the training slope and having prepared and checked
everything, inate your wing and play with it to get a feel of your
new glider while ground handling. By doing this you are making a
nal check of the canopy and lines, and that everything is in order.
You will nd that the Gambit inates very easily and smoothly
without excessive energy and with minimum pressure while moving
forwards. For ination and lifting the glider you may use only the
A1 riser tab. Do not pull on the risers just with your hands, instead
use your whole harness. Your hands should only accompany the
rising movement of the wing. When the wing is above you, apply
correct pressure on the brake lines and the glider will stay above
you.
Modications on the glider
Any modications of the lines or risers’ speed system cause the
loss of the certication, similarly to ying the wing outside the
weight range.
12
Flying the Gambit
First Flight
Now that you have familiarised yourself with your new glider while
ground handling on a training slope, you are ready for your rst
ight. For the rst ight it is recommend that you choose
a familiar ying area and to y your new glider in calm conditions.
Preight check equipment
Before every ight you need to do a pre-ight check and inspection
of other equipment. This procedure may vary, depending on the
instructor, pilot or equipment settings. Some pilots have their
wing always connected to the harness. However you should have
a consistent method of checking and preparing your equipment
and doing your pre-ight check.
1.
After the arrival on take-off, assess the suitability of ying
conditions.
2.
While walking around the canopy preparing and spreading
out the wing, you should at the same time inspect the canopy.
3.
After you check the lines and connect the risers to the harness,
grab the lines and slide them through your ngers as you walk
towards the canopy. In this way you double check that the lines
are not tangled, stuck or damaged. If meanwhile the canopy
moves, walk around and correct it again.
4.
Inspect the harness, reserve, speed system and all connections.
13
Final preight check
1.
Strap into the harness. The leg straps should be the rst to be
connected on the take-off and the last ones to be released
after the ight. Make sure you are strapped in correctly and
wearing a helmet.
2.
Check the risers for twists and that the carabiners are properly
closed. Check if the speed system is not affecting your risers
– accelerating unintentionally.
3.
Check the lines. The A riser lines should be on top, and all
lines untangled. Check that none of the lines are lying over or
below the canopy.
4.
Check the canopy. The glider should be spread out in the
shape of an arch and all cells open.
5.
Check the wind, take-off and airspace. The wind should
be favourable for take-off and the pilot’s level of expertise.
Airspace should be cleared, together with the take-off area.
Ination, control, take-off
The Gambit has easy take-off behavior for its class, and does
not require any additional advice regarding the forward or reverse
launch. Try to divide and practice the take-off procedure in three
steps.
1. Inating and raising the glider
2. Controlling the wing and wing check
3. Accelerating and take-off
It is always advisable to practice and improve proper launching
techniques as this reduces unnecessary additional stress before
the take-off.
14
Wind speeds up to 25 to 30km/h are considered strong and extra
care is required for the ight. If you are launching in strong winds
we recommend the reverse launch technique, with your brakes
in the right hands at all times. Launch the glider with a gentle pull
and then walk towards it if necessary to reduce the relative wind
force. When the glider is above you, gently control the wing and
take off.
Line knots or tangles
If you fail to observe a line knot or you nd yourself ying with a
knot before being able to prevent the unintentional, uncontrolled
take-off, try to stay away from the ground or other pilots by ying
away from the mountain, before taking any corrective action on
the wing. This means that you weight shift and/or counter brake
the opposite side of the wing and control the ying direction with
the least amount of force needed for the wing to y straight away
from the mountain. Be careful not to apply too much brake or
to y too slowly to avoid a stall or spin. When you are at a safe
distance away from the mountain and you have gained relative
height by ying away, you may want to gently and briey pull the
lines that are tangled with the knot. If the knot is on the brake lines
you might want to gently and briey “pump” the appropriate brake
line. Please note that by pulling the lines, the knot may get stuck
in a worse position and the situation may escalate also to a stall
or spin. Therefore, if you estimate that you can control the wing
relatively safely and that the knot is not released by gently and
briey pulling the tangled lines, immediately y to the landing
zone and land safely.
Normal ight, best glide
Without any brake applied and without using the accelerator,
the wing ies at the so called “trim speed“. In calm air this is
theoretically the best glide speed. The best glide speed in real air
depends on the glider’s polar and air mass, vertical and horizontal
speed. We recommend reading more about the theory of the best
glide and McCready theory.
Minimum sink
If you apply brakes on both sides for about 10 -15 cm you will
slow the glider to the theoretical minimum sink speed. But we
do not recommend using this speed even for thermalling, as you
achieve much better climbing and control by letting the glider y
at “trim speed”. With a proper take-off weight you will nd that
the glider has great climb, reactions and agility.
Accelerated ight
We recommend that you avoid accelerated ight near the ground
and to be very careful using the accelerator in turbulent conditions.
Use a soft speed bar, which enables you to accelerate the glider
by using only one leg. To control the direction use weight shift.
To control the pitch change the amount of the speed bar. Do not
use or pull the brakes while using the speed bar. Use the speed
bar progressively when accelerating and instantly release when
you feel a slight loss of tension, pressure or even a collapse. If you
encounter a collapse while using the accelerator, release the speed
bar immediately before taking any other corrective action. Always
keep more distance to the ground when using the speed bar.
Active ying
This is a basic ying technique for any pilot. It implies permanent
control and the correction of pitch and roll movements together
with the prevention of any deations or collapses. In a nutshell this
means ying straight through active or turbulent air, so that the
pilot keeps the glider above their head at all times, compensating
and correcting any unwanted movements of the wing.
Once you feel comfortable ying the Gambit, you can start
practicing using the speed system, which will provide better
performance while gliding against the wind and through a sinking
air mass. The Gambit was designed to be stable through its entire
speed range, but this requires the use of active ying techniques.
Note that any glider becomes less stable while ying accelerated
and that the risk of a collapse is higher in accelerated ight.
Additionally, the reaction of the glider to a collapse in accelerated
ight is more radical in comparison with one which occurs at trim
speed.
Examples:
• While entering a strong thermal, the wing will stay a little bit
behind relative to the pilot. The pilot should let the brakes up
allowing the wing to y faster and to catch up.
•
If the wing surges in front of the pilot, the pilot should counter
brake until the surge is controlled and then release the brakes
to let it y normally.
•
If the pilot feels a loss of tension in the wing or a loss of
pressure on the brakes on one side of the wing, they should
smoothly apply the brake on the side with loss of pressure and/
15
or weight shift to the opposite side until the pressure returns.
After that, again release the brake and/or weight shift to the
neutral position and let the glider y normally.
The key in all cases is to avoid an over-correction and not to
maintain any correction longer than necessary. After each action
let the glider y normally again, to re-establish its required ying
speed. You can train or get a feeling for most of these movements
safely on the ground while ground handling your glider. Good
coordination of your movements and coordination with the wing
on the ground will enable you a quick progression when actively
ying in the air. The next step is to attend SIV courses where you
should also get a better understanding of the full brake range and
the glider’s speeds.
Flying in turbulence
Wing deations can occur in a strong turbulence. The Gambit is
designed and tested within CCC certication rules and needs pilot
input for faster rerecover from deations. To train and understand
all the manoeuvres described, attend SIV trainings.
Cascade events
Many reserve deployments are the result of a cascade of
over-corrections by the pilot. Over-corrections are usually not
problematic because of the input itself or its intensity; but due to
the length of time the pilot continues to over-handle. After every
input you have to allow the wing to re-establish its normal ying
speed. Note that over-corrections are often worse than no input
at all.
Asymmetric deflations
Strong turbulence may cause the wing to collapse asymmetrically.
Before this occurs the brake lines and the feeling of the harness
16
will transmit a loss of pressure to the pilot. This feedback is used
in active piloting to prevent a collapse. Once a collapse has
happened, avoid over-braking your wing’s still-open side. This
is normally enough to maintain your course and give the glider
enough time to recover the collapsed side by itself. To actively
reopen the collapsed side after course stabilization, pull the brake
line on the collapsed side rmly and release it. You can do this
several times with a smooth pumping motion. After the recovery,
release the brake lines for your glider to regain its trim speed. You
must be aware of the fact that asymmetric collapses are much
more radical when ying accelerated. This is due to the difference
in weight and the inertia of the canopy and the pilot hanging below.
Symmetric deflations
Symmetric or frontal deations will normally reopen immediately
by themselves without pilot’s input. The glider will then regain
its airspeed accompanied by a small surge forwards. To actively
control this event, apply both brakes slightly when the collapse
occurs and then instantly release the brakes to let the glider y.
Be prepared to compensate for the glider’s slight surge forward
while returning to normal ying.
Wing tangle, cravat
A cravat may occur after a severe deation or in a cascading
situation, when the wing tip gets caught in the glider’s lines. A pilot
should be familiar with the procedure of handling this situation with
any glider. If a cravat occurs, the rst thing to do is to try to keep
the glider ying on a straight course. Do this by weight shifting
and counter braking the open side. If normal corrective action
is not effective, a brief full stall will generally solve the problem,
provided you have sufcient altitude.
If you are in a situation where you have a cravat and you are low,
in rotation or even with twisted risers, then the only solution is
the reserve parachute.
Negative spin
In normal ight you are far from negative spin. But, certain
circumstances may lead to it. Should this occur, just release the
brake lines progressively and let the wing regain its ying speed.
Be prepared for the glider to surge forward, compensating the
surge with brake input if necessary.
Full stall
A full stall does not occur unintentionally – it happens if you pull
both brakes for 100% and hold them. The wing then performs a
so called full stall. Releasing the brakes improperly
may lead to massive surge of the glider with danger of falling into
the canopy. This is a complex manoeuvre and as such outside the
scope of this manual. You should practice and learn this
manoeuvre only on a SIV course under professional supervision.
Deep stall
Generally when in deep stall, the wing has no forward motion and
at the same time high sink speed. When in deep stall the wing is
almost fully inated. With the Gambit it is very unlikely to get into
this situation unintentionally. This could possibly happen if you
are ying at a very low speed in turbulent conditions. Also the
porosity of the material and line stretch on a very old glider can
increase the possibility of the deep stall tendency. If you trained
this manoeuvre on a SIV course you would realize that it is very
hard to keep the Gambit in deep stall. If you apply the brakes a
little bit too much you enter the full stall. If you release the brakes
just a little bit too much the wing returns to normal ight. If you
want to practice the deep stall on SIV courses, you need to master
the full stall rst.
Fast decent techniques
Spiral dive
The spiral dive is the only effective way to lose altitude quickly. It
should be done in combination with a small drogue chute attached
to one main karabiner, and should only be trained gradually and
always at high altitude. The spiral dive should be practiced and
learned on a SIV course under professional supervision. To enter
the spiral, deploy the drogue chute, weight shift to the desired
side and gradually apply the brake on the same side. Then let the
wing accelerate for two turns and you will enter the spiral dive.
While in the spiral, you can control your descent rate and bank
angle by applying more or less inner brake. Depending on how
steep the spiral is you may need to use also outer brake. To exit
the spiral dive we recommend that the pilot is in the neutral weight
shift position. If you release the inner brake, the wing exits the
spiral dive by itself.
17
Winch launch
Landing
The Gambit is easy to launch using a winch and has no special
characteristics considering this kind of launching. To practice this
launching technique special training is needed and you have to
be aware of the procedures and dangers, which are specic for
winching. We do not recommend using any special towing device
which accelerates the glider during the winch launch.
Aerobatics
The Gambit was not designed for aerobatics, therefore, these may
not be performed and shoud be avoided, also increased stress
will have inuence in logh term glider prerformance on this glider.
In addition to this, any extreme manoeuvres place unnecessary
stress on the glider and shorten its lifespan.
Primary controls failure
If for any reason you cannot use the brake lines, you have to pilot
the wing to the landing place by using the B risers and weight
shift. Weight shift should be enough to safely land the glider.
Be careful not to over-handle the glider when using the B riser
technique when steering. By pulling the B risers too far you may
cause a stall or a spin.
Land your glider at trim speed without using the B risers, to avoid
over-handling the glider low above ground. We recommend using
weight shift.
Similarly to the take-off, the Gambit landing characteristics are
easy. In turbulent conditions it is advisable to apply about 15% of
brakes, to increase stability and the feeling of the glider.
Before landing, adopt the standing position as this is the most
effective and the safest way to compensate the touch down with
your legs. Always look for possible landing alternatives downwind.
18
Packing instructions
Maintenance
General advice
Careful maintenance of your glider and the following simple
guidelines will ensure a much longer airworthiness and performance
of your wing:
•
Pack your glider after you land and do not unnecessarily
expose it to UV radiation by leaving it on the landing site
unpacked. The sun’s UV radiation degrades the cloth and
lines material.
•
Fold your glider like recommended under the section “Packing
instructions”.
• If the glider is damp or wet when you pack it, partially unfold
it at home to allow it to dry. Do not dry it in direct sunlight.
•
Avoid exposing the glider to violent shocks, such as the leading
edge hitting the ground.
•
Avoid dragging the glider on the ground or through rocky
terrain as you might damage the lines or canopy.
• Avoid stepping on the lines or canopy, especially when they
are lying on a hard surface.
•
Avoid exposing the glider to salt water, as it damages the lines
and the canopy material (wash with fresh water).
• Avoid bending your lines, especially in a small radius.
•
Avoid opening your glider in strong winds without rst
untangling the lines.
•
In general, avoid exposing your glider to very hot or humid
environments, UV radiation or chemicals.
It is important to correctly pack your glider as this prolongs its
lifespan. We recommend that you fold the glider like a harmonica,
neatly aligning the cell walls with the leading edge reinforcements
side by side. The wing should then be folded in two parts or one
folds. The wing should be packed as loosely as possible. While
packing, be careful not to trap any grasshoppers inside your
canopy as they will tear the canopy cloth. Adhering to these
simple rules will make your glider last longer and ensure its best
performance.
Storage
Correctly packed, store your glider in a dry place at room
temperature. The glider should not be stored damp, wet, sandy,
salty or with objects inside the cells of the glider. Keep your
equipment away from any chemicals.
Cleaning
If necessary always clean your glider with fresh water and a cloth
only, without using any cleaning chemicals. This applies to both
lines and canopy. More importantly, always remove any stones or
sand from the canopy as they will gradually damage the material
and reduce the glider’s lifespan.
Repair
To repair small damages (less than 5cm) on the canopy cloth,
you can use rip stop tape. Greater damages, including stitches
19
and lines, must be repaired by a specialized repair shop. When
replacing a line it should always be compared with the counterpart
for adjusting the appropriate length. After the line was repaired,
the wing should be inated before ying, to ensure that everything
was done correctly. Major repairs, such as replacing panels, should
only be carried out by a Triple Seven distributor or Triple Seven. If
you are unsure about the damage or in any doubt please contact
Triple Seven.
Checks and control
To ensure the wing’s airworthiness the Gambit has to be periodically
serviced and checked to guarantee that the glider continues to
full the EN certication results and to extend your glider’s
lifespan. We recommend a line check and trim inspection every
100 hours or 12 months depending what happens rst. After that,
the glider needs to be fully checked after 150 hours or 24
months of usage, whichever comes earlier. This inspection includes
checGambit the suspension lines, line geometry, riser geometry
and the permeability of the canopy material. A certied inspector
can
then dene the check interval depending on the glider’s condition.
Please note that the condition of the glider can vary considerably
depending on the type of usage and environment. Salty coastal
air or dunes will considerably affect your wing’s material. For
more information please visit our website.
iuolulouoll
20
21
Technical data
4.
1.
1. Suspension lines
2. Risers
3. Main lines
4. Middle cascades
5. Upper cascades
6. Brake lines
5.
22
3.
6.
2.
5.
3.
6.
1.
4.
2.
1. Canopy
2. Bottom surface
3. Top surface
4. Leading edge
5. Trailing edge
6. Intake cell openings
23
Technical data Materials description
Gambit XS Gambit S Gambit M Gambit L
Cells Number 137 137 137 137
Flat Area m2 20.6 22.4 24.1 25.8
Span m 12.75 13.3 13.8 14.27
Aspect ratio 7.9 7.9 7.9 7.9
Projected Area m2 17.5 19.02 20.47 21.91
Span m 10.28 10.72 11.12 11.5
Risers A1 A2 A3 Stab (A4) B
Gambit Lenght mm 505 503 503 505 Standard
Lenght mm 365 505 Accelerated
Distance between pulleys 140 mm
CANOPY FABRIC CODE
Leading edge Dominico 30 DMF
Upper surface Porcher SKYTEX 32
Bottom surface Porcher SKYTEX 27
Proles Skytex 27 hard, Skytex 40 hard
Reinforcement Nitinol
SUSPENSION LINES FABRIC CODE
Upper cascades EDELRID A8000U (70, 50, 25)
Upper cascades Liros DC 35
Middle1 cascades Edelrid A8000U (130, 90, 70, 50, 25)
Middle1 cascades Liros DC 35
Middle 2 cascades Edelrid A8000U (90, 50, 25)
Middle 2 cascades Liros DC (301, 201, 161)
Main Edelrid A8000U 70
Main Liros DC (401, 201, 161)
Main stabilo EDELRID A9020-030
XS S M L
In ight Weight Minimum kg 85 90 101 110
Maximum kg 95 105 116 125
Certication CCC CCC CCC CCC
24
Brake upper Edelrid A8000U 25
Brake middle 1 Edelrid A8000U 25
Brake middle 2 Edelrid A8000U (25, 50, 130)
Brake main TSL 0190
RISERS FABRIC CODE
Material Liros 13 mm blyk nylon webbing
Pulleys 4x Harken PA18
Gambit risers arrangement
5.
1.
2.
3.
7.
8.
9.
4.
1. A0 riser
2. A1 riser, (Ears)
3. S stabilo
4. B0 riser
5. Maillons
6. Main attachment point
7. Speed bar attachment point
8. Speed bar pulleys
9. Speed limiter 140 mm
6.
25
br main
br main1
Line plan Gambit
A1
c4
d4
2a2
C1
a5
b5
br2
1br1
c5
1a3
a6
b6
2c2
1c3
1a4
c6
a7
b7
a8
b8
1c4
c7
br3
1br2
1a6
1a5
a9
a10
a11
b9
b10
b11
b12
1c5
c8
c9
c10
br4
2a1
1a2
c1
d1
c2
a2
b2
1c1
1d1
d2
1a1
a3
b3
1d2
a4
b4
2c1
1c2
c3
d3
1
a1
b1
br1
2br1
2a3
a12
2c3
1c6
c11
br5
A2
C2
a13
b13
c12
2br2
2a4
1a7
a14
b14
2c4
c13
1a8
a15
b15
1c7
c14
br6
1br3
3br1
a16
b16
1c8
c15
a17
b17
c16
br7
1br4
a18
b18
c17
1a9
a19
b19
br8
1a10
a20
b20
1c9
c18
2a5
a21
c19
A3
1c10
br9
3br2
2a6
1a11
a22
a23
2c5
c20
1a12
a24
c21
br10
1br5
C3
a25
2c6
1c11
1a13
a26
c22
c23
br11
1br6
1c12
a27
2a7
1a14
a28
c24
br12
A4
b21
a29
a30
b22
1s1
s1
s2
26
27
GAMBIT XS - Total line length with risers
All the measurements are to be done under the 5 kg load
A1 7976 B1 7956 C1 7946 BR1 8370
A2 7937 B2 7906 C2 7901 BR2 8049
A3 7858 B3 7831 C3 7790 BR3 7831
A4 7858 B4 7833 C4 7783 BR4 7825
A5 7832 B5 7806 C5 7756 BR5 7597
A6 7821 B6 7798 C6 7757 BR6 7511
A7 7876 B7 7848 C7 7835 BR7 7514
A8 7906 B8 7887 C8 7873 BR8 7609
A9 7816 B9 7794 C9 7745 BR9 7323
A10 7776 B10 7749 C10 7699 BR10 7281
A11 7685 B11 7659 C11 7587 BR11 7278
A12 7679 B12 7659 C12 7580 BR12 7429
A13 7622 B13 7600 C13 7530
A14 7609 B14 7590 C14 7521
A15 7634 B15 7613 C15 7561
A16 7654 B16 7642 C16 7590
A17 7526 B17 7513 C17 7417
A18 7488 B18 7469 C18 7348
A19 7403 B19 7387 C19 7256
A20 7388 B20 7378 C20 7252
A21 7324 B21 7024 C21 7184
A22 7313 B22 7059 C22 7172
A23 7317 C23 7180
A24 7336 C24 7215
A25 7143
A26 7112
A27 7061 D1 8047
A28 7060 D2 7999
A29 7010 D3 7886
A30 7031 D4 7877
GAMBIT S - Total line length with risers
All the measurements are to be done under the 5 kg load
A1 B1 C1 BR1
A2 B2 C2 BR2
A3 B3 C3 BR3
A4 B4 C4 BR4
A5 B5 C5 BR5
A6 B6 C6 BR6
A7 B7 C7 BR7
A8 B8 C8 BR8
A9 B9 C9 BR9
A10 B10 C10 BR10
A11 B11 C11 BR11
A12 B12 C12 BR12
A13 B13 C13
A14 B14 C14
A15 B15 C15
A16 B16 C16
A17 B17 C17
A18 B18 C18
A19 B19 C19
A20 B20 C20
A21 B21 C21
A22 B22 C22
A23 C23
A24 C24
A25
A26
A27 D1
A28 D2
A29 D3
A30 D4
28
GAMBIT M - Total line length with risers
All the measurements are to be done under the 5 kg load
A1 8615 B1 8593 C1 8583 BR1 9085
A2 8573 B2 8539 C2 8533 BR2 8738
A3 8486 B3 8458 C3 8413 BR3 8500
A4 8486 B4 8460 C4 8406 BR4 8494
A5 8459 B5 8431 C5 8376 BR5 8246
A6 8447 B6 8421 C6 8377 BR6 8153
A7 8506 B7 8476 C7 8461 BR7 8157
A8 8539 B8 8518 C8 8503 BR8 8259
A9 8441 B9 8418 C9 8369 BR9 7949
A10 8398 B10 8369 C10 8319 BR10 7903
A11 8299 B11 8270 C11 8197 BR11 7900
A12 8292 B12 8271 C12 8190 BR12 8065
A13 8230 B13 8207 C13 8136
A14 8217 B14 8196 C14 8127
A15 8244 B15 8221 C15 8170
A16 8266 B16 8253 C16 8202
A17 8126 B17 8114 C17 8014
A18 8085 B18 8064 C18 7939
A19 7993 B19 7976 C19 7842
A20 7977 B20 7966 C20 7838
A21 7907 B21 7582 C21 7761
A22 7896 B22 7620 C22 7748
A23 7899 C23 7757
A24 7921 C24 7795
A25 7711
A26 7677
A27 7621 D1 8692
A28 7620 D2 8640
A29 7567 D3 8517
A30 7589 D4 8508
GAMBIT L - Total line length with risers
All the measurements are to be done under the 5 kg load
A1 8885 B1 8863 C1 8852 BR1 9388
A2 8841 B2 8807 C2 8801 BR2 9029
A3 8752 B3 8723 C3 8676 BR3 8783
A4 8752 B4 8725 C4 8669 BR4 8777
A5 8724 B5 8695 C5 8638 BR5 8521
A6 8711 B6 8685 C6 8640 BR6 8425
A7 8773 B7 8742 C7 8727 BR7 8428
A8 8806 B8 8785 C8 8769 BR8 8534
A9 8705 B9 8681 C9 8626 BR9 8214
A10 8661 B10 8631 C10 8574 BR10 8167
A11 8558 B11 8529 C11 8448 BR11 8163
A12 8552 B12 8530 C12 8440 BR12 8333
A13 8488 B13 8463 C13 8384
A14 8474 B14 8452 C14 8374
A15 8502 B15 8478 C15 8419
A16 8524 B16 8511 C16 8452
A17 8380 B17 8368 C17 8258
A18 8338 B18 8316 C18 8180
A19 8242 B19 8225 C19 8077
A20 8226 B20 8214 C20 8073
A21 8154 B21 7818 C21 7996
A22 8142 B22 7857 C22 7983
A23 8146 C23 7992
A24 8168 C24 8032
A25 7951
A26 7916
A27 7859 D1 8965
A28 7857 D2 8910
A29 7802 D3 8784
A30 7825 D4 8774
29
CCC line calculations XS, S, M
LINE MATERIAL STRENGTH(daN) LEVEL 1(daN) LEVEL 2(daN) LEVEL 3(daN) LEVEL 4
a1 A-8000-70 63,1 126,2
a2 A-8000-50 51,8 103,6
a3 A-8000-50 51,8 103,6
a4 A-8000-50 51,8 103,6
a5 A-8000-50 51,8 103,6
a6 A-8000-50 51,8 103,6
a7 A-8000-50 51,8 103,6
a8 A-8000-70 63,1 126,2
a9 A-8000-70 63,1 126,2
a10 A-8000-50 51,8 103,6
a11 A-8000-50 51,8 103,6
a12 A-8000-50 51,8 103,6
a13 A-8000-50 51,8 103,6
a14 A-8000-50 51,8 103,6
a15 A-8000-50 51,8 103,6
a16 A-8000-50 51,8 103,6
a17 A-8000-50 51,8 103,6
a18 DC 35 35,0 70
a19 DC 35 35,0 70
a20 DC 35 35,0 70
a21 DC 35 35,0 70
a22 DC 35 35,0 70
a23 DC 35 35,0 70
a24 DC 35 35,0 70
a25 DC 35 35,0 70
a26 A-8000-25 22,7 45,5
a27 A-8000-25 22,7 45,5
a28 A-8000-25 22,7 45,5
a29 A-8000-25 22,7 45,5
a30 A-8000-25 22,7 45,5
b1 A-8000-70 63,1 126,2
b2 A-8000-50 51,8 103,6
b3 A-8000-50 51,8 103,6
b4 A-8000-50 51,8 103,6
b5 A-8000-50 51,8 103,6
b6 A-8000-50 51,8 103,6
b7 A-8000-50 51,8 103,6
b8 A-8000-70 63,1 126,2
b9 A-8000-70 63,1 126,2
b10 A-8000-50 51,8 103,6
b11 A-8000-50 51,8 103,6
b12 A-8000-50 51,8 103,6
b13 A-8000-50 51,8 103,6
b14 A-8000-50 51,8 103,6
b15 A-8000-50 51,8 103,6
b16 A-8000-50 51,8 103,6
b17 A-8000-50 51,8 103,6
b18 DC 35 35,0 70
b19 DC 35 35,0 70
b20 DC 35 35,0 76,0
b21 A-8000-25 22,7 45,5
b22 A-8000-25 22,7 45,5
c1 A-8000-50 51,8 103,6
c2 A-8000-50 51,8 103,6
c3 A-8000-50 51,8 103,6
c4 A-8000-50 51,8 103,6
c5 A-8000-50 51,8 103,6
c6 A-8000-50 51,8 103,6
c7 A-8000-50 51,8 103,6
c8 A-8000-50 51,8 103,6
c9 A-8000-50 51,8 103,6
c10 DC 35 35,0 70,0
c11 DC 35 35,0 70,0
c12 DC 35 35,0 70,0
c13 DC 35 35,0 70,0
c14 DC 35 35,0 70,0
c15 DC 35 35,0 70,0
c16 DC 35 35,0 70,0
c17 DC 35 35,0 70,0
c18 A-8000-25 22,7 45,5
c19 A-8000-25 22,7 45,5
c20 A-8000-25 22,7 45,5
c21 A-8000-25 22,7 45,5
c22 A-8000-25 22,7 45,5
c23 A-8000-25 22,7 45,5
c24 A-8000-25 22,7 45,5
d1 A-8000-25 22,7 45,5
d2 A-8000-25 22,7 45,5
d3 A-8000-25 22,7 45,5
d4 A-8000-25 22,7 45,5
1a1 A-8000-120 77,0 214
1a2 A-8000-90 90,2 180,4
1a3 A-8000-90 90,2 180,4
1a4 A-8000-120 77,0 214
1a5 A-8000-90 90,2 180,4
1a6 A-8000-90 90,2 180,4
1a7 A-8000-90 90,2 180,4
1a8 A-8000-90 90,2 180,4
1a9 A-8000-90 90,2 180,4
1a10 A-8000-70 63,1 126,2
1a11 A-8000-50 51,8 103,6
1a12 A-8000-50 51,8 103,6
1a13 A-8000-50 51,8 103,6
1a14 A-8000-25 22,7 45,5
s1 A-8000-25 22,7 45,5
s2 A-8000-25 22,7 45,5
1c1 A-8000-50 51,8 103,6
1c2 A-8000-50 51,8 103,6
1c3
1c4 A-8000-50 51,8 103,6
1c5 A-8000-50 51,8 103,6
1c6 A-8000-50 51,8 103,6
1c7 A-8000-50 51,8 103,6
1c8 A-8000-50 51,8 103,6
1c9 A-8000-50 51,8 103,6
1c10 DC 35 35,0 70,0
1c11 A-8000-25 22,7 45,5
1c12 A-8000-25 22,7 45,5
1d1 A-8000-50 51,8 103,6
1d2 A-8000-50 51,8 103,6
2a1 DC301 231,2 462,4
2a2 DC201 175,4 350,8
2a3 DC201 175,4 350,8
2a4 DC201 175,4 350,8
2a5 DC161 145,3 290,6
2a6 A-8000-90 90,2 180,4
2a7 A-8000-50 51,8 103,6
1s1 A-8000-25 22,7 45,5
2c1 A-8000-90 90,2 180,4
2c2 A-8000-90 90,2 180,4
2c3 A-8000-90 90,2 180,4
2c4 A-8000-90 90,2 180,4
2c5 A-8000-70 63,1 126,2
2c6 A-8000-50 51,8 103,6
A1 DC401 356,3 712,6
A2 DC401 356,3 712,6
A3 DC201 175,4 350,8
A4 A-8000-70 63,1 126,2
C1 DC201 175,4 350,8
C2 DC201 175,4 350,8
C3 A-8000-90 90,2 180,4
A-8000-50 51,8 103,6
LEVEL 1(daN) LEVEL 2(daN) LEVEL 3(daN) LEVEL 4
sum daN 2784,2 3086,3 3564,8 6745,1
norm 23g >level 1 >level 2 >level 3 >level 4
max weight per level 123,4 136,8 158,0 298,9
max Kg XS, S, M 123,4
CCC line calculations L
LINE MATERIAL STRENGTH(daN) LEVEL 1(daN) LEVEL 2(daN) LEVEL 3(daN) LEVEL 4
a1 A-8000-70 63,1 126,2
a2 A-8000-50 51,8 103,6
a3 A-8000-50 51,8 103,6
a4 A-8000-50 51,8 103,6
a5 A-8000-50 51,8 103,6
a6 A-8000-50 51,8 103,6
a7 A-8000-50 51,8 103,6
a8 A-8000-70 63,1 126,2
a9 A-8000-70 63,1 126,2
a10 A-8000-50 51,8 103,6
a11 A-8000-50 51,8 103,6
a12 A-8000-50 51,8 103,6
a13 A-8000-50 51,8 103,6
a14 A-8000-50 51,8 103,6
a15 A-8000-50 51,8 103,6
a16 A-8000-50 51,8 103,6
a17 A-8000-50 51,8 103,6
a18 DC 35 35,0 70
a19 DC 35 35,0 70
a20 DC 35 35,0 70
a21 DC 35 35,0 70
a22 DC 35 35,0 70
a23 DC 35 35,0 70
a24 DC 35 35,0 70
a25 DC 35 35,0 70
a26 A-8000-25 22,7 45,5
a27 A-8000-25 22,7 45,5
a28 A-8000-25 22,7 45,5
a29 A-8000-25 22,7 45,5
a30 A-8000-25 22,7 45,5
b1 A-8000-70 63,1 126,2
b2 A-8000-50 51,8 103,6
b3 A-8000-50 51,8 103,6
b4 A-8000-50 51,8 103,6
b5 A-8000-50 51,8 103,6
b6 A-8000-50 51,8 103,6
b7 A-8000-50 51,8 103,6
b8 A-8000-70 63,1 126,2
b9 A-8000-70 63,1 126,2
b10 A-8000-50 51,8 103,6
b11 A-8000-50 51,8 103,6
b12 A-8000-50 51,8 103,6
b13 A-8000-50 51,8 103,6
b14 A-8000-50 51,8 103,6
b15 A-8000-50 51,8 103,6
b16 A-8000-50 51,8 103,6
b17 A-8000-50 51,8 103,6
b18 DC 35 35,0 70
b19 DC 35 35,0 70
b20 DC 35 35,0 76,0
b21 A-8000-25 22,7 45,5
b22 A-8000-25 22,7 45,5
c1 A-8000-50 51,8 103,6
c2 A-8000-50 51,8 103,6
c3 A-8000-50 51,8 103,6
c4 A-8000-50 51,8 103,6
c5 A-8000-50 51,8 103,6
c6 A-8000-50 51,8 103,6
c7 A-8000-50 51,8 103,6
c8 A-8000-50 51,8 103,6
c9 A-8000-50 51,8 103,6
c10 DC 35 35,0 70,0
c11 DC 35 35,0 70,0
c12 DC 35 35,0 70,0
c13 DC 35 35,0 70,0
c14 DC 35 35,0 70,0
c15 DC 35 35,0 70,0
c16 DC 35 35,0 70,0
c17 DC 35 35,0 70,0
c18 A-8000-25 22,7 45,5
c19 A-8000-25 22,7 45,5
c20 A-8000-25 22,7 45,5
c21 A-8000-25 22,7 45,5
c22 A-8000-25 22,7 45,5
c23 A-8000-25 22,7 45,5
c24 A-8000-25 22,7 45,5
d1 A-8000-25 22,7 45,5
d2 A-8000-25 22,7 45,5
d3 A-8000-25 22,7 45,5
d4 A-8000-25 22,7 45,5
1a1 A-8000-120 77,0 214
1a2 A-8000-90 90,2 180,4
1a3 A-8000-90 90,2 180,4
1a4 A-8000-120 77,0 214
1a5 A-8000-90 90,2 180,4
1a6 A-8000-90 90,2 180,4
1a7 A-8000-90 90,2 180,4
1a8 A-8000-90 90,2 180,4
1a9 A-8000-90 90,2 180,4
1a10 A-8000-70 63,1 126,2
1a11 A-8000-50 51,8 103,6
1a12 A-8000-50 51,8 103,6
1a13 A-8000-50 51,8 103,6
1a14 A-8000-25 22,7 45,5
s1 A-8000-25 22,7 45,5
s2 A-8000-25 22,7 45,5
1c1 A-8000-50 51,8 103,6
1c2 A-8000-50 51,8 103,6
1c3
1c4 A-8000-50 51,8 103,6
1c5 A-8000-50 51,8 103,6
1c6 A-8000-50 51,8 103,6
1c7 A-8000-50 51,8 103,6
1c8 A-8000-50 51,8 103,6
1c9 A-8000-50 51,8 103,6
1c10 DC 35 35,0 70,0
1c11 A-8000-25 22,7 45,5
1c12 A-8000-25 22,7 45,5
1d1 A-8000-50 51,8 103,6
1d2 A-8000-50 51,8 103,6
2a1 DC301 231,2 462,4
2a2 DC201 175,4 350,8
2a3 DC201 175,4 350,8
2a4 DC201 175,4 350,8
2a5 DC161 145,3 290,6
2a6 A-8000-90 90,2 180,4
2a7 A-8000-50 51,8 103,6
1s1 A-8000-50 51,8 103,6
2c1 A-8000-90 90,2 180,4
2c2 A-8000-90 90,2 180,4
2c3 A-8000-90 90,2 180,4
2c4 A-8000-90 90,2 180,4
2c5 A-8000-70 63,1 126,2
2c6 A-8000-50 51,8 103,6
A1 DC401 356,3 712,6
A2 DC401 356,3 712,6
A3 DC201 175,4 350,8
A4 A-8000-90 90,2 180,4
C1 DC201 175,4 350,8
C2 DC201 175,4 350,8
C3 A-8000-90 90,2 180,4
A-8000-50 51,8 103,6
LEVEL 1(daN) LEVEL 2(daN) LEVEL 3(daN) LEVEL 4
sum daN 2838,4 3144,4 3564,8 6745,1
norm 23g >level 1 >level 2 >level 3 >level 4
max weight per level 125,8 139,4 158,0 298,9
max Kg L 125,8
Safety and responsibility
Paragliding is a dangerous and high risk activity, where safety depends on the person
practicing it. By purchasing and using this equipment you declare that you are a certied
paragliding pilot, and you accept all risks involved in paragliding activities, including serious
injury and death. Improper use or misuse of paragliding equipment considerably increases the
risks.
The designer, manufacturer, distributor, wholesaler and retailer cannot and will not guarantee
your safety when using this equipment, nor accept responsibility for any damage, injury or
death as a result of the use of this equipment. This equipment should only be used by qualied
and competent pilots. You must not use this equipment if you are not trained.
You alone as a qualied and competent pilot must take full responsibility to ensure that you
understand the correct and safe use and maintenance of this paragliding equipment, to use
it only for the purpose that it was designed for, and to practice all proper safety procedures
before and during its use.
3232
Guarantee
Triple Seven WARRANTY:
All Triple Seven products are fully warranted for 24 months, against material defects that are not
the result of normal wear or accidental damage.
33
Registration information
To fully use all Triple Seven maintenance and warranty services you need to register your glider
on our website. Wanting to provide good product support, we invite you to do so, even if you
bought your glider second-hand.
Triple Seven Warranty & Product registration:
http://www.777gliders.com/tripleseven/support
Get involved
As a new Triple Seven pilot we invite you to contact us in case of any technical or practical
issues regarding equipment or techniques. We also invite you to send us your ying photos,
videos or even postcards. We would like to hear from you and your exciting adventures with
your new glider! Finally, join our Facebook community and share the passion. Have fun!
34
34
Contact
Triple Seven Gliders
Company: 777 jadralna padala d.o.o.
Address: Ulica Ane Ziherlove 10
Postal Code / City: 1000 Ljubljana
Country: Slovenia
Tel.: +386 40 777 313
Email: info@777gliders.com
Online resources
For complete help, the latest news, product
information and support go to:
Official website:
www.777gliders.com
Facebook:
www.facebook.com/TripleSevenParagliders
Newsletter register:
www.777gliders.com/newsletter/subscriptions
Ask questions, make suggestions
General questions:
info@777gliders.com
35 35
Loading...
