Mentor CX
Mentor Automatic Changeover
User Guide
ISSUE 1.1
TRILOGY COMMUNICATIONS LIMITED
26 Focus Way
Andover
Hampshire
SP10 5NY
United Kingdom
Telephone. +44 (0) 1264 384000
www.trilogycomms.com
Page 2 of 43 Trilogy Communications
Mentor CX
The Copyright of the information and drawings in this document is
the property of Trilogy Communications Limited of Andover,
Hampshire and is neither to be reproduced in whole or in part, nor
disclosed to a third party, without the prior written consent of
Trilogy Communications Limited.
The information in this document has been carefully compiled and
checked for accuracy. However, Trilogy Communications Limited
accepts no responsibility for inaccuracies which may occur and,
further, reserves the right to make changes to specification or
design without prior notice.
Comments or correspondence concerning this manual should be
addressed to the Publications Manager at the address given at the
front of this User Guide.
DOCUMENT NUMBER 33190600.docx ISSUE 1.1
Issue
Date
Reason for Change
Approved
1.0
29 October 2018
Initial release
1.1
4 December 2018
Safety notice updated
Page 3 of 43 Trilogy Communications
Mentor CX
CONTENTS
1. APPLICATION ............................................................................................................... 5
1.1 I
NTRODUCTION ............................................................................................................................... 5
1.2 V
ECTOR - WEB BROWSER BASED MANAGEMENT .................................................................................. 5
1.3 R
ELATED DOCUMENTS ...................................................................................................................... 5
1.4 A
VAILABLE FEATURES AND OPTIONS ................................................................................................... 6
2. INSTALLATION ............................................................................................................. 7
2.1 U
NPACKING .................................................................................................................................... 7
2.2 R
ACK MOUNTING ............................................................................................................................ 7
2.3 E
ARTHING REQUIREMENTS ................................................................................................................ 7
2.4 M
AINS CONNECTION AND FUSING ...................................................................................................... 8
2.5 B
ATTERY ........................................................................................................................................ 8
2.6 R
EAR PANEL CONNECTIONS ............................................................................................................... 9
2.7 C
HANNEL INPUT AND OUTPUT ......................................................................................................... 10
2.8 AES
AND LTC IN FROM SPG A AND B ............................................................................................... 10
2.9 AES
AND LTC OUT ......................................................................................................................... 11
2.10 F
AULT LOOP ................................................................................................................................. 11
2.11 GPI
IN AND OUT ............................................................................................................................ 12
2.12 E
THERNET .................................................................................................................................... 13
3. OPERATION ............................................................................................................... 14
3.1 I
NTRODUCTION ............................................................................................................................. 14
3.2 F
RONT PANEL ............................................................................................................................... 15
3.3 C
ONTROLS .................................................................................................................................... 16
3.4 I
NDICATORS .................................................................................................................................. 17
4. USING VECTOR | WEB BROWSER BASED MANAGEMENT .......................................... 18
4.1 I
NTRODUCTION ............................................................................................................................. 18
4.2 G
ETTING STARTED.......................................................................................................................... 18
4.3 T
OP LEVEL MENU .......................................................................................................................... 19
4.4 V
ECTOR | STATUS .......................................................................................................................... 20
4.4.1 Vector | Status | Overview ............................................................................................... 20
4.4.2 Vector | Status | Channels ................................................................................................ 21
4.4.3 Vector | Status | Options .................................................................................................. 22
4.4.4 Vector | Status | Network ................................................................................................. 22
4.4.5 Vector | Status | Logging .................................................................................................. 22
4.5 V
ECTOR | SETUP ........................................................................................................................... 23
4.5.1 Vector | Setup | Channels ................................................................................................. 23
4.5.2 Vector | Setup | A/B Sync ................................................................................................. 24
4.6 V
ECTOR | CONTROL ....................................................................................................................... 25
4.7 V
ECTOR | ADMIN .......................................................................................................................... 26
4.7.1 Vector | Admin | System Settings ..................................................................................... 26
4.7.2 Vector | Admin | SNMP Settings ...................................................................................... 26
4.7.3 Vector | Admin | Password ............................................................................................... 27
4.7.4 Vector | Admin | Software Update ...................................................................................
27
4.7.5 Vector | Admin | Misc Actions .......................................................................................... 27
4.8 V
ECTOR | HELP ............................................................................................................................. 28
Page 4 of 43 Trilogy Communications
Mentor CX
5. MAIN CONTROLLER BOARD ....................................................................................... 30
5.1 I
NTRODUCTION ............................................................................................................................. 30
5.1.1 SDI Channels (1 - 2) ........................................................................................................... 30
5.1.2 Analogue Channels (3 – 6) ................................................................................................ 30
5.1.3 AES (balanced via D-type connectors) ............................................................................... 31
5.1.4 LTC (balanced via D-type connectors) ............................................................................... 31
6. OPTION: 331-20-00 UNIVERSAL OPTION MODULE ..................................................... 32
6.1 I
NTRODUCTION ............................................................................................................................. 32
6.2 S
IGNAL HANDLING ......................................................................................................................... 32
6.3 C
ONNECTORS ................................................................................................................................ 33
7. OPTION: 331-21-00 PASSIVE OPTION MODULE .......................................................... 34
8. OPTION: 331-22-00 SD/HD/3G SDI VIDEO OPTION MODULE ..................................... 35
9. SPECIFICATION .......................................................................................................... 36
9.1 G
ENERAL ...................................................................................................................................... 36
9.2 EMC
& SAFETY ............................................................................................................................. 36
9.3 P
OWER ........................................................................................................................................ 36
9.4 GPI
INPUT 1: REMOTE CHANGEOVER CONTROL ................................................................................. 37
9.5 GPI
INPUT 2 ................................................................................................................................. 37
9.6 GPI
OUTPUT 1: REMOTE CHANGEOVER OUTPUT ................................................................................ 37
9.7 GPI
OUTPUT 2: REMOTE ALARM OUTPUT ......................................................................................... 37
9.8 S
YSTEM BASE MODULE ................................................................................................................... 38
9.9 331-20-00
UNIVERSAL OPTION MODULE ......................................................................................... 41
9.10 331-21-00
PASSIVE OPTION MODULE ............................................................................................. 42
9.11 331-22-00
SD/HD/3G SDI VIDEO OPTION MODULE ........................................................................ 42
9.12 331-22-00
SD/HD/3G SDI VIDEO OPTION MODULE – FORMATS DETECTED AND REPORTED .................. 43
Page 5 of 43 Trilogy Communications
Mentor CX
1. APPLICATION
1.1 INTRODUCTION
The Trilogy 331-00-xx Mentor CX Changeover Unit is designed to complement the Trilogy RG
Reference Generator. The Mentor product family is suitable for any digital or mixed format
environment where a high quality digital SPG is required. Mentor CX provides a manual or automatic
changeover between a pair of Mentor RG generators, providing the maximum possible security for
on-air applications.
The following features and facilities are offered:
• Compact 1RU rack mounting package matching the Mentor RG
• Single or redundant dual power supplies
• Base Mentor CX provides:
o 4 channels which monitor and switch Black and burst,
Tri-Level-Sync, AES/DARS, word clock, 10 MHz and 27 MHz
o 2 channels which monitor and switch SDI – SD/HD/3G signals but do not detect or
report the standard
o Monitoring and switching of balanced AES and LTC signals
• Comprehensive range of expansion modules, up to a total of 18 channels
• Both actively monitored and passively switched channels for a range of signals
• Front panel control and status indication
• Vector web management, tightly integrated with Mentor RG provides full setup, monitoring
and control
In addition, an internal redundant power supply is available to increase MTBF, or to allow AC power
diversity in critical applications. An Ethernet port is provided for the Vector browser based
management feature and also facilitates software upgrades.
This User Guide concentrates on the operational aspects of the Mentor CX and includes a full
technical specification.
1.2 VECTOR - WEB BROWSER BASED MANAGEMENT
A web browser based configuration tool is provided, offering:
• Initial setup and management of Mentor CX
• Status overview of the entire reference chain comprising Mentor CX and the associated pair
of Mentor RG generators
• Control - including choice of manual and automatic modes
Please see section 4.2 of this manual for information on getting started with Vector.
1.3 RELATED DOCUMENTS
Document
Description
33190600
Mentor CX User Guide - This Document
36090602
Quick Start Guide: Mentor RG plus Mentor CX
36090600
Mentor RG User Guide
Page 6 of 43 Trilogy Communications
Mentor CX
1.4 AVAILABLE FEATURES AND OPTIONS
Six option card slots are available. The Mentor CX auto detects which type of option card is fitted
and presents the user with appropriate on-screen options within Vector.
A number of additional hardware options are available for the Mentor CX. At the time of writing in
July 2018, these are:
Part Code
Description
Note
331-00-00
Mentor CX Changeover unit
Inclusive of one PSU module and no option modules
331-20-00
Two channel Universal CO option module
331-21-00
Two channel Passive CO option module
331-22-00
Two channel SD/HD/3G video CO option
module
331-50-00
PSU module
1.5 TECHNICAL SUPPORT
UK & International
Please contact Trilogy at the UK headquarters.
Trilogy Communications Ltd
26 Focus Way
Andover
Hampshire
SP10 5NY
United Kingdom
E-mail: support@trilogycomms.com
Tel: +44 (0)1264 384000
Alternatively please contact your reseller. Contact details may be found at www.trilogycomms.com
.
1.6 WARRANTY
Conditions of the warranty may vary according to your terms of purchase. Please consult your sales
documentation or if in doubt, contact your original supplier or Trilogy, quoting date of purchase and
unit serial number.
Page 7 of 43 Trilogy Communications
Mentor CX
2. INSTALLATION
2.1 UNPACKING
Carefully unpack the unit from its transit material and check the unit for signs of damage. Check the
contents of the box against our despatch note and your original order to ensure that you have
received the correct parts.
In the event that the unit has been damaged or does not match your order, immediately contact
your supplier or Trilogy at the address given at the front of this guide.
2.2 RACK MOUNTING
The 1U rack frame has integral 19" mounting ears for direct mounting in a standard 19" rack.
Carefully place the unit in your rack and firmly attach it to the rack using four bolts.
IMPORTANT: Mentor CX has air intakes on the front of the chassis and fan assisted exhaust vents on
the rear of the chassis. Ensure that these have an unobstructed air flow, otherwise the unit may
overheat. Pay particular attention to ensure that any rack wiring or cable trays do not obstruct the
vent. 60mm of clear space should be allowed between the vents and any potential obstruction.
2.3 EARTHING REQUIREMENTS
The unit is provided with a single 4mm earthing stud on the rear panel. Incoming mains earth from
the IEC connector is internally bonded to both the chassis and technical 0V to meet safety
requirements and performance specifications. The stud allows the addition of an earth strap, if
required, in rack installations.
Page 8 of 43 Trilogy Communications
Mentor CX
2.4 MAINS CONNECTION AND FUSING
Important
Power Supply Cord(s) Used as Disconnect Means
CAUTION: THE POWER SUPPLY CORDS ARE USED AS THE MAIN DISCONNECT DEVICE.
ENSURE THAT THE SOCKET-OUTLETS ARE LOCATED / INSTALLED NEAR THE EQUIPMENT
AND ARE EASILY ACCESSIBLE.
THIS UNIT HAS MORE THAN ONE POWER SUPPLY CORD.
DISCONNECT TWO POWER SUPPLY CORDS BEFORE SERVICING TO AVOID ELECTRIC SHOCK.
ATTENTION: LES CORDONS D’ALIMENTATION SONT UTILISÉS COMME DISPOSITIF DE
DÉBRANCHEMENT PRINCIPAL. ASSUREZ-VOUS QUE LES PRISES DE SOCKET SONT SITUÉES /
INSTALLÉES PRÈS DE L’APPAREIL ET SONT FACILEMENT ACCESSIBLES.
CET APPAREIL COMPORTE PLUS D’UN CORDON D’ALIMENTATION.
AFIN DE PRÉVENIR LES CHOCS ÉLECTRIQUES, DEBRANCHER LES DEUX CORDONS D’ALIMENTATION
AVANT DE FAIRE LE DÉPANNAGE.
The power supplies within the unit are a switched mode design and will cope automatically with a
wide input voltage range (see specification, section 9.3).
The standard Mentor CX is fitted with a single mains power supply unit (PSU), with an option to fit a
second PSU. Each PSU has its own, dedicated, IEC mains plug on the rear of the Mentor CX. These
should be wired according to the instructions provided with a mating mains socket using suitable
cable. See above for earthing requirements.
Mains cable conductors are to be three-core (two-wire with ground), wire gauge 18 AWG (cross
sectional area 0.75mm²) Jacket to be type SJT.
Covers are only to be removed by trained personnel. Shock hazard exists with covers removed;
therefore disconnect mains supply before removal. See the warning notice above. Interconnection
between circuit boards and panels are all safety extra low voltage (SELV) as defined by
IEC/EN/CSA/UL 60950-1-200X. The equipment signal connections must only be connected to SELV
circuits to prevent hazards from improper connection.
2.5 BATTERY
Mentor CX is fitted with an internal lithium battery.
CAUTION:
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
ATTENTION
IL Y A RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UNE BATTERIE
DE TYPE INCORRECT.
METTRE AU REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS.
Page 9 of 43 Trilogy Communications
Mentor CX
2.6 REAR PANEL CONNECTIONS
Balanced AES channels
1 and 2.
Balanced LTC channels 1
and 2.
Option boards channels
7 - 18
Main and backup power
supply IEC inlets. Power
supplies are removed
from front of chassis.
GPI inputs and outputs
Main board channels
1 - 6
Ethernet
Page 10 of 43 Trilogy Communications
Mentor CX
2.7 CHANNEL INPUT AND OUTPUT
Mentor CX uses the ‘Micro BNC’ connector type, which is interchangeable with the Amphenol ‘HD
BNC’ range. Connector performance exceeds the requirements of SMPTE ST 2082-1 making them
suitable for composite and component video, 270 Mb/s SDI, uncompressed 1080i or 1080p HD-SDI
video and 4K UHD (2160P60) video up to 12GHz.The Micro BNC series is used to achieve a very high
density of connections on equipment rear panels and thus requires the use of a dedicated slim-line
fitting and removal tool to mate and un-mate the connector. Trilogy offers a short interconnect
cable for Mentor RG outputs to Mentor CX channel inputs – please contact your usual sales channel
for more information.
2.8 AES AND LTC IN FROM SPG A AND B
There are two male D9 plugs for AES inputs and two identical connectors for LTC signals. AES inputs
are the upper connectors and LTC inputs are the lower connectors.
From SPG A
From SPG B
AES in from SPG A: Chassis
D9 plug (male)
Pin
Description
1
AES 1 + (in)
2
AES 1 - (in)
3
n/c 4 n/c 5 n/c 6 n/c 7 AES 2 + (in)
8
AES 2 - (in)
9
n/c
LTC in from SPG A: Chassis D9
plug (male)
Pin
Description
1
LTC 1 + (in)
2
LTC 1 – (in)
3
n/c 4 Fault Loop + (in)
5
n/c 6 n/c 7 LTC 2 + (in)
8
LTC 2 – (in)
9
Fault Loop – (in)
Input pins are arranged to match the corresponding output pins of the Mentor RG, allowing 1:1
cabling to be installed.
The LTC input connectors also have provision to connect the fault loop general system failure signal
from each Mentor RG. This may be combined with system health data from Mentor CX to provide an
overall fault loop for the associated hardware (2 x Mentor RG plus 1 x Mentor CX). See section 2.10.
AES in from SPG B:
Chassis D9 plug
(male) - identical
LTC in from SPG B:
Chassis D9 plug
(male) - identical
Page 11 of 43 Trilogy Communications
Mentor CX
2.9 AES AND LTC OUT
There are two female D9 sockets for the output of AES and LTC channels. AES out is the upper
connector and LTC out is the lower connector.
AES out: Chassis D9 socket (female)
Pin
Description
1
AES 1 + (out)
2
AES 1 - (out)
3
Shield
4
Fault Loop + (out)
5
0V GND
6
Shield
7
AES 2 + (out)
8
AES 2 - (out)
9
Fault Loop - (out)
LTC out: Chassis D9 socket (female)
Pin
Description
1
LTC 1 + (out)
2
LTC 1 – (out)
3
Shield
4
TXD (see note 1)
5
0V GND
6
Shield
7
LTC 2 + (out)
8
LTC 2 – (out)
9
RXD (see note 1)
Note 1 – serial data is for internal debug purposes only.
2.10 FAULT LOOP
Mentor CX has a fault loop output indicating a combined general system failure when open. The
output is presented on the AES output connector as shown above. Electrically, the opto-isolated
output is identical to the GPI Outputs described in section 2.11.
A fault condition on one or more of the items listed causes the Mentor CX fault loop to open.
• Mentor CX Fan 1
• Mentor CX Fan 2
• Mentor CX PSU 1
• Mentor CX PSU 2
• Fault loop primary Mentor RG (SPG A)
• Fault loop secondary Mentor RG (SPG B)
Overall fault status from each associated Mentor RG is connected to the LTC input connectors on
Mentor CX to provide an overall fault loop for the entire reference system.
Page 12 of 43 Trilogy Communications
Mentor CX
2.11 GPI IN AND OUT
A D9 chassis mounted socket (female) provides GPI (general purpose interface) inputs and outputs.
GPI: Chassis D9 socket (female)
Pin
Description
1
GND
2
GPI input 1
3
GPI input 2
4
GPI out 2 -
5
+12VDC (fused 500 mA)
6
GPI out 1 +
7
GPI out 1 -
8
GPI out 2 +
9
GND
GPI Inputs 1 and 2
GPI input 1 is used to switch between A and B inputs when the unit is configured to use GPI to cause
the changeover. A floating input selects “A” inputs: closure to ground selects “B” inputs.
GPI input 2 is reserved for future use.
Connecting to GPI Inputs
GPI
Mentor CX
Mentor CX GPI inputs
comprise single ended
ground-to-operate inputs.
Maximum input voltage is
+60 V.
To assert a GPI input,
connect the input pin to
Mentor CX ground.
Page 13 of 43 Trilogy Communications
Mentor CX
GPI Outputs 1 and 2
Output 1 indicates which set of inputs are routed to the output. When open, “A” inputs are routed,
when closed “B” inputs are routed. GPI Output 1 is a latching mechanical relay and retains its setting
when power is removed from the unit.
Output 2 indicates if the A&B input sets signals differ or if there is a PSU failure. When open, inputs
A&B differ or a PSU failure has been detected: when closed A&B have equivalent signals and PSUs
are OK. PSU failure occurs when the PSU is detected as present but PSU DC voltage output is not OK
or PSU fan is not OK. GPI Output 2 is an opto-isolated, floating type.
Connecting to GPI Output 2
2.12 ETHERNET
The Mentor CX is equipped with a 10/100 Base-T Ethernet port. This port may be configured for
either dynamic (DHCP) address mode, or static address mode. In most instances, we recommend the
static mode. These options are located in the Admin menu. The Mentor CX should be connected to
the network in the same way as any other networked device (e.g. computer or laptop) using a 1:1
CAT 5 RJ45 cable (not provided).
If connected directly to a computer or laptop for initial configuration, either a crossover or straight
through style Ethernet cable may be used.
LOAD
PSU
Mentor CX
GPIO
+
-
GPI outputs comprise single ended
open collector outputs with a 30V /
190mA rating, 600mW dissipation.
To use an output, a load should be
connected between the output and
an external power supply, with the
negative end of the power supply
connected back to the ground pin on
the D type. As an alternative to an
external power supply, a +12V, 500
mA feed is available on pin 5 of the
D9 connector.
Page 14 of 43 Trilogy Communications
Mentor CX
3. OPERATION
3.1 INTRODUCTION
There are three basic principles which are key to operation of the Mentor CX.
1. An error or fault condition on a single channel causes, without exception, a total
changeover from the primary to secondary reference generator. Channels may be included
or excluded from the decision making using front panel controls or Vector management.
This allows the “faulty” generator to be isolated and removed from service for repair or
replacement without causing any further disturbance to the transmission.
2. The logic underpinning automatic changeover is fundamentally “one time only”. So, if an
error occurs, Mentor CX will switch from primary to secondary generator. A further switch
back to primary will not occur without manual intervention. This is to eliminate the
possibility of repeated back and fore switching which would be very disruptive. The most
common occurrence of this is a missing termination downstream of Mentor CX. This will
cause an “over amplitude” error and thus a changeover. However, in this case, the fault will
now be flagged on the reserve generator which will also display an error. The “one time
only” approach means that the reserve generator will now remain in service until the
problem is resolved and the Mentor CX is manually reset.
3. Changeover will only take place if the alternate generator is operating correctly. This means
that there are no errors and that the input signals are the same type.
A limited amount of information and key aspects of control are presented at the front panel and
these are described first. More complete operation and system setup are provided by Vector
management and this is described in section 4 - Using Vector | Web Browser Based Management.
Page 15 of 43 Trilogy Communications
Mentor CX
3.2 FRONT PANEL
Sync Status:
• Green =
synchronised
• Red = not
synchronised
PSU status
• Green = OK
• Red = fail
• Off = not fitted
Power Supply 1 and 2
Panel Lock:
• Press to lock /
unlock
• Long press for
configuration mode
Changeover alarm
• Normally green
• Flash Red after
changeover when
Mentor CX is in
manual or GPI
mode
Fault Reset
Input Status LED
• 2 per channel; top row
Generator A (primary),
bottom row Generator B
(secondary)
Operational Mode:
• Auto
• Manual
• GPI Control
Select buttons are used
to switch from
Reference Generator A
to B. Only active when
mode is set to Manual.
Fault LED
Page 16 of 43 Trilogy Communications
Mentor CX
3.3 CONTROLS
Panel controls are only active when the panel is unlocked. Control actions related to configuration
mode are shown in italics.
Button
Indicator
Panel Lock
Momentary press alternates between locked and
unlocked. When unlocked, if there is no user
input for 30 seconds, the panel will automatically
lock.
On = locked
Off = unlocked (normal mode)
5 second press to enter configuration mode –
momentary press to exit configuration mode.
When in configuration mode, if no action has
been performed on the switches used in
configuration mode (i.e. buttons A and B) then
after a 15 second timeout, the panel will go back
to normal mode.
Flashing = configuration mode
Operational
Mode
Three interlocked buttons:
• Automatic
• Manual
•
GPI Input control
On = mode currently selected
Select
Two interlocked buttons, only active in manual
operation mode:
• Select Reference Generator A
• Select Reference Generator B
On = currently selected –
displayed in all operational
modes
Button A – cycle through channels
Button B – enable / disable selected channel
Fault Reset
Momentary press to reset changeover alarm
Press and hold on power-up to set IP address to
factory default (192.168.1.252).
Page 17 of 43 Trilogy Communications
Mentor CX
3.4 INDICATORS
PSU1 and PSU2
• Green = PSU module in normal operational mode, AC input is applied, the DC voltage rail is
within specification and the fan is OK
• Red = There is an error with a PSU module (AC input is not applied; DC voltage is out of
range or fan fail.)
• Off = PSU module not fitted.
Reference Generator Sync Status, A (primary) and B (secondary)
• Green = Generator synchronised
• Red = Generator not synchronised.
Input status
There are individual LED indicators for each input, 2 per channel. They also have a secondary
purpose when Mentor CX is in configuration mode.
Normal mode
Configuration Mode
Green = input OK
Flashing Green = input in warning
Red = channel input in error
Yellow = inputs A and B are different format
and are not in error
Flashing Red = invalid state
Off = channel not enabled.
Green = channel is enabled
Red = channel is disabled.
Changeover Alarm
This translucent LED bar is located to the left side of the front panel.
• Green for normal operation
• Flashing red when a changeover has occurred when the unit is in auto or GPI control mode.
Page 18 of 43 Trilogy Communications
Mentor CX
4. USING VECTOR | WEB BROWSER BASED MANAGEMENT
4.1 INTRODUCTION
Vector, a web browser based configuration tool provides:
• Greatly simplified initial setup
• Online editing of Mentor CX configurations
• Visibility of your entire Trilogy Mentor reference system
• Partial or incremental updates without causing disruption (where possible)
• The ability to copy, backup and restore configuration data
4.2 GETTING STARTED
To start using Vector, follow these simple steps to set the Mentor CX IP address:
• Power up the Mentor CX while holding down the “Fault Reset” button on the front panel.
The IP address will return to factory default of 192.168.1.252.
• Connect the Ethernet port on the Mentor CX to a laptop, using a standard RJ-45 cable (not
supplied). Give the laptop a temporary IP address within the same subnet (e.g.192.168.1.20).
• Open your web browser and Navigate to the address http://192.168.1.252.
• Select Admin from the top menu and at the log-in screen, enter the default username admin
and password trilogy. The System Settings page will then be displayed.
• As a minimum, enter values for Default IP and Subnet Mask which are appropriate for your
in-house network. A Gateway address will be required if you intend to access the Mentor CX
across a wider network. Use of DHCP is not normally advised for technical equipment.
• A change of Default IP address will mean that you lose contact from the laptop. Once the
change has taken place you can disconnect the laptop and connect Mentor CX to your LAN.
• Log in again from a PC connected to your LAN.
Page 19 of 43 Trilogy Communications
Mentor CX
4.3 TOP LEVEL MENU
From the web browser, the top level menu is always displayed within the blue horizontal bar. The
selected item is indicated by a “pressed button” image.
The second navigation level is a vertical side-bar and the selected item, in this case “Overview”, is
repeated within the panel immediately to the right.
Here is the key:
Note:
1. Signal status or health is indicated by the “traffic
signal” colours.
2. A selected mode, or active state is indicated in
blue.
3. An inactive state is shown by a clear indicator.
Examples below show the optional power supply, PSU2.
PSU2 is present and operating correctly
PSU2 is fitted but has failed
PSU2 is not fitted
The content and features of each menu branch are explained later in this section of the manual.
Page 20 of 43 Trilogy Communications
Mentor CX
4.4 VECTOR | STATUS
The status menu has five branches, as shown in the first image below.
4.4.1 Vector | Status | Overview
This page provides an overview of the entire Mentor reference system, i.e. the Mentor CX and the
two associated Mentor RG. The IP addresses of the linked Mentor RG should be entered on the
Admin | System Settings page – see section 4.7.
Page 21 of 43 Trilogy Communications
Mentor CX
4.4.2 Vector | Status | Channels
Channel status is provided on three pages.
All Channels
Main Channel Formats
Option Channel Formats
Page 22 of 43 Trilogy Communications
Mentor CX
4.4.3 Vector | Status | Options
Installed Option Modules are
denoted by a green indicator and
appropriate text to identify module
type.
4.4.4 Vector | Status | Network
This page provides read-only
information for the current network
settings. Any changes can be made
after logging in to the Admin page –
see section
4.7.
Links to the associated Mentor RG
Reference Generators will open in
new browser tabs.
4.4.5 Vector | Status | Logging
Page 23 of 43 Trilogy Communications
Mentor CX
4.5 VECTOR | SETUP
4.5.1 Vector | Setup | Channels
This screen allows channels to be included in or excluded from the
changeover decision making process.
Channel setup:
• Select which channels will be included in the changeover decision
making process
• A fail condition on any of the channels included in the changeover
decision making will cause the unit to changeover to the alternate
SPG
• If channels are not included in the decision making process, the
status of the inputs will not be monitored
Page 24 of 43 Trilogy Communications
Mentor CX
4.5.2 Vector | Setup | A/B Sync
The Mentor CX monitors the
status of linked Mentor RGs to
see if they are locked using
one of the approved
synchronisation method(s)
e.g. GPS, PTP, NTP etc. The list
of approved synchronisation
methods is configured on this
screen. The status of each
Mentor RG is monitored via
the network and reported
accordingly.
The following will cause a sync fail condition:
• The Mentor RG reports a synchronisation method not
approved in the configured list.
The following causes a sync warning :
• Both Mentor RG report a synchronisation method from
the approved configured list, but the synchronisation
methods differ.
The Mentor RG synchronisation methods are:
• GPS
• PTP (slave)
• NTP
• LTC
• VITC
• Internal oscillator
• External clock; and
• Genlock
The settings section is there to ensure we don’t get a period of
changeover when there are network stability issues.
Page 25 of 43 Trilogy Communications
Mentor CX
4.6 VECTOR | CONTROL
The control screen provides all elements of control.
• Changeover Mode:
o Auto = controlled by detecting errors on incoming signals from connected Mentor RG
o Manual = controlled on-screen or from front panel
o GPI = external control connected to GPI input. See section 2.11.
• Switch Actions:
o Select A / B causes an immediate changeover when in manual mode (above)
Fault Reset clears any existing fault alarms
Page 26 of 43 Trilogy Communications
Mentor CX
4.7 VECTOR | ADMIN
The Admin menu comprises five branches, as shown in the first image below.
4.7.1 Vector | Admin | System Settings
The Admin | System Settings page allows the Mentor CX IP address to be set correctly, to match
local network requirements. Although DHCP is supported, it is not normally appropriate in a
technical environment such as a broadcast studio.
The minimum values required for correct operation are Default IP and Subnet Mask. These values
alone will allow the Mentor CX to be accessed by an admin PC located on the same subnet. If you
plan to access the Mentor CX from a different subnet then a Gateway address must be entered.
Factory default IP address is 192.168.1.252 with subnet mask 255.255.255.0.
Each Mentor CX Changeover is normally connected to a pair of Mentor RG Reference Generators.
If the IP addresses of these linked reference generators are entered, the main status page will
display an overview of the status of the entire system. In depth status reporting and setup of the
Mentor RG is available by browsing directly to each unit.
4.7.2 Vector | Admin | SNMP Settings
Check the box to enable
SNMP notifications. A
maximum of three SNMP
managers may be added.
Page 27 of 43 Trilogy Communications
Mentor CX
4.7.3 Vector | Admin | Password
Factory defaults are:
Login name – admin
Password - trilogy
4.7.4 Vector | Admin | Software Update
Update files for Mentor CX
and option boards will be
supplied by Trilogy Technical
Support. Any software
update may be disruptive and
should be carefully
scheduled. Please contact
Trilogy for further details.
4.7.5 Vector | Admin | Misc Actions
Three miscellaneous actions are
presented. Network reset occurs as
soon as the button is clicked. The
interface is reset but settings are
retained.
This warning prompt is shown for the
“Reset” action.
This warning prompt is shown for the
“Factory Reset” action. Please read
the note carefully before proceeding.
Page 28 of 43 Trilogy Communications
Mentor CX
4.8 VECTOR | HELP
There are three items on the Help menu, as shown below. The info page has two tabs.
The info page provides a summary of
currently installed software for the
Mentor CX and any fitted option
boards. There are two tabs, General
and Technical Support. The General
tab presents an overview, in a user
friendly format.
If you contact Trilogy Technical
Support, our engineers will request
information from this screen to assist
in answering your question.
To make a copy of the complete
information:
• Place your cursor anywhere
within the text area
• Press <ctrl + A> to select all the
text
• Press <ctrl + C> to copy
• Create a new plain text (.txt) file
on your desktop and open the
file
• Place your cursor in the new text
file and press <ctrl + V> to paste
• Save the text file with an
appropriate filename
Page 29 of 43 Trilogy Communications
Mentor CX
PDF versions of the Mentor CX User
Guides can be downloaded from the
support website by clicking the short
links on this page. QR codes provide
an easy way for smartphone users to
download the documents.
Page 30 of 43 Trilogy Communications
Mentor CX
5. MAIN CONTROLLER BOARD
5.1 INTRODUCTION
In addition to providing overall control of the Mentor CX, the main controller board carries the
following channels which constitute the “base” unit:
• 2 x SDI - channels 1 - 2
• 4 x Analogue - channels 3 - 6
• 2 x AES (balanced via D-type connectors)
• 2 x LTC (balanced via D-type connectors)
The features of each channel type are described below.
5.1.1 SDI Channels (1 - 2)
The inputs monitor SDI – SD/HD/3G signals, but do not detect or report the format/standard.
The following error causes a failure condition:
• Signal level approx. <500 mV.
5.1.2 Analogue Channels (3 – 6)
There are 4 analogue channels which can monitor and switch the following signal types:
• Black and burst (BB)
• Tri-Level-Sync (TLS)
• AES/DARS (unbalanced via BNC)
• Word clock, 10 MHz, 27 MHz
Black and burst (BB)
Mentor CX monitors PAL and NTSC BB and reports the detected standard.
• Signal amplitude <180 mV causes a failure condition
• Signal amplitude <210 mV (double terminated) or >500 mV (un-terminated) causes a
warning condition.
Tri-Level Sync (TLS)
The following 22 standards are monitored, detected and reported (see exceptions listed).
Description
Description
(reports as)
1920x1080/60/p
1920x1080/30/sF
1920x1080/60/i
1920x1080/59.94/p
1920x1080/29.97/sF
1920x1080/59.94/i
1920x1080/50/p
1920x1080/25/sF
1920x1080/50/i
1920x1080/60/i
1280x720/60/p
1920x1080/59.94/i
1280x720/59.94/p
1920x1080/50/i
1280x720/50/p
1920x1080/30/p
1280x720/30/p
1920x1080/29.97/p
1280x720/29.97/p
1920x1080/25/p
1280x720/25/p
1920x1080/24/p
1280x720/24/p
1920x1080/23.98/p
1280x720/23.98/p
• Signal amplitude <180 mV causes a failure condition
• Signal amplitude <210 mV (double terminated) or >500 mV (un-terminated) causes a
warning condition but does not cause changeover to occur.
Page 31 of 43 Trilogy Communications
Mentor CX
AES/DARS (unbalanced via BNC)
AES signals from the Mentor RG can be transmitted as unbalanced via a 75Ω BNC output, or
balanced via a D-type connector. See section 5.1.3 for information about balanced connection.
Mentor CX supports AES with 32, 44.1, 48 and 96 kHz sampling frequencies.
The following errors cause a failure condition:
• Peak-to-peak signal level <320 mV
• Incorrect AES preamble.
Word Clock, 10 MHz and 27 MHz
The word clock, 10 MHz and 27 MHz signals from the Mentor RG are transmitted as 75 Ω BNC
outputs. The maximum amplitude the unit has to cope with is 10V peak to peak. The signal type is
automatically detected and reported.
The following error causes a failure condition:
• Peak-to-peak signal level <320 mV.
5.1.3 AES (balanced via D-type connectors)
AES signals from the Mentor RG can be transmitted as unbalanced via a 75Ω BNC output, or
balanced via a D-type connector. See section 5.1.2 for information about unbalanced connection.
Mentor CX supports AES with 32, 44.1, 48 and 96 kHz sampling frequencies.
The following errors cause a failure condition:
• Peak-to-peak signal level <200 mV
• Incorrect AES preamble.
5.1.4 LTC (balanced via D-type connectors)
LTC from the Mentor RG is transmitted as a balanced signal via a D-type connector.
The following errors cause a failure condition:
• Peak-to-peak signal level <500 mV
• Incorrect LTC sync word.
The following causes a warning condition but does not cause changeover to occur:
• Discontinuous timecode.
Page 32 of 43 Trilogy Communications
Mentor CX
6. OPTION: 331-20-00 UNIVERSAL OPTION MODULE
6.1 INTRODUCTION
This optional module is capable of handling the following signals:
• Black and burst (BB)
• Tri-Level-Sync (TLS)
• AES/DARS (unbalanced via BNC)
• Word clock, 10 MHz, 27 MHz
Each option module provides two changeover “channels”, where a channels comprises two inputs (A
and B) plus one switched output. The module may be fitted in any of the six available option slots.
6.2 SIGNAL HANDLING
Black and burst (BB)
Mentor CX monitors PAL and NTSC BB and reports the detected standard.
• Signal amplitude <180 mV causes a failure condition
• Signal amplitude <210 mV (double terminated) or >500 mV (un-terminated) causes a
warning condition.
Tri-Level Sync (TLS)
The following 22 standards are monitored, detected and reported (see exceptions listed).
Description
Description
(reports as)
1920x1080/60/p
1920x1080/30/sF
1920x1080/60/i
1920x1080/59.94/p
1920x1080/29.97/sF
1920x1080/59.94/i
1920x1080/50/p
1920x1080/25/sF
1920x1080/50/i
1920x1080/60/i
1280x720/60/p
1920x1080/59.94/i
1280x720/59.94/p
1920x1080/50/i
1280x720/50/p
1920x1080/30/p
1280x720/30/p
1920x1080/29.97/p
1280x720/29.97/p
1920x1080/25/p
1280x720/25/p
1920x1080/24/p
1280x720/24/p
1920x1080/23.98/p
1280x720/23.98/p
• Signal amplitude <180 mV causes a failure condition
• Signal amplitude <210 mV (double terminated) or >500 mV (un-terminated) causes a
warning condition but does not cause changeover to occur.
AES/DARS (unbalanced via BNC)
AES signals from the Mentor RG can be transmitted as unbalanced via a 75Ω BNC output, or
balanced via a D-type connector. See section 5.1.3 for information about balanced connection.
Mentor CX supports AES with 32, 44.1, 48 and 96 kHz sampling frequencies.
The following errors cause a failure condition:
• Peak-to-peak signal level <320 mV
• Incorrect AES preamble.
Page 33 of 43 Trilogy Communications
Mentor CX
Word Clock, 10 MHz and 27 MHz
The word clock, 10 MHz and 27 MHz signals from the Mentor RG are transmitted as 75 Ω BNC
outputs. The maximum amplitude the unit has to cope with is 10V peak to peak. The signal type is
automatically detected and reported.
The following error causes a failure condition:
• Peak-to-peak signal level <320 mV.
6.3 CONNECTORS
Each option module provides two changeover “channels”, where a channel comprises two inputs
(A and B) plus one switched output. The module may be fitted in any of the six available option slots.
Mentor CX uses the high density ‘Micro BNC’ connector type, which is interchangeable with the
Amphenol ‘HD BNC’ range. The image below shows the option module fitted in the last available
option slot, numbered 17/18.
Page 34 of 43 Trilogy Communications
Mentor CX
7. OPTION: 331-21-00 PASSIVE OPTION MODULE
This optional module is capable of changing over the following signals:
• Black and burst (BB)
• Tri-Level-Sync (TLS)
• AES/DARS (unbalanced via BNC)
• Word clock, 10 MHz, 27 MHz
• SD/HD/3G SDI video
There is no monitoring, detection or reporting capability.
Each option module provides two changeover “channels”, where a channel comprises two inputs
(A and B) plus one switched output. The module may be fitted in any of the six available option slots.
Mentor CX uses the high density ‘Micro BNC’ connector type, which is interchangeable with the
Amphenol ‘HD BNC’ range. The image below shows the option module fitted in the last available
option slot, numbered 17/18.
Page 35 of 43 Trilogy Communications
Mentor CX
8. OPTION: 331-22-00 SD/HD/3G SDI VIDEO OPTION MODULE
This optional module is capable of monitoring and changing over the following signals:
• SD/HD/3G SDI video
The signal format is automatically detected and reported. Formats detected are listed in the
Specifications – see section 9.12.
Each option module provides two changeover “channels”, where a channel comprises two inputs
(A and B) plus one switched output. The module may be fitted in any of the six available option slots.
Mentor CX uses the high density ‘Micro BNC’ connector type, which is interchangeable with the
Amphenol ‘HD BNC’ range. The image below shows the option module fitted in the last available
option slot, numbered 17/18.
Page 36 of 43 Trilogy Communications
Mentor CX
9. SPECIFICATION
9.1 GENERAL
Width
482 mm (including rack ears)
19” rack mounting
Height
44 mm (1U)
Depth
433 mm (excluding connectors)
Weight
4kg with no option boards
5kg max. with all option boards
Operating temperature
range
0°C to 50°C
Storage temperature
range
-20°C to 60°C
Operating humidity
20% - 90% (non-condensing when operating at 40°C)
9.2 EMC & SAFETY
Emissions
EN 55032:2015
FCC CFR 47 Part 15.107 & 15.109 and ICES-003 Issue 6
EN 61000-3-2:2014, EN 61000-3-3:2013
Immunity
EN 55103-2:2009
Safety
IEC 60950-1:2005/A2:2013
NOTE: Immunity is specified to criterion B - the outputs may suffer some degradation during the
disturbance, but will recover on removal of the disturbance source and continue to operate as
intended.
9.3 POWER
Power Supplies
The Mentor CX can accommodate two PSU modules providing
the option to support PSU redundancy. PSU modules are load
sharing and hot swappable.
Mains input x 2
100-240VAC, 50/60Hz, auto select
Power consumption
80 W maximum (depending on number of option boards fitted)
Internal Fuse
3.15A
Page 37 of 43 Trilogy Communications
Mentor CX
9.4 GPI INPUT 1: REMOTE CHANGEOVER CONTROL
Type
Current sinking type (also referred to as ground closure type).
Purpose
Controls output selection when the system changeover mode
is configured for GPI.
Input activation
Selects secondary channel set
≤1.0 V (wrt interface system 0V)
≤6 k Ω (contact to interface system ground)
Input deactivation
Selects primary channel set
≥2.0 V (wrt interface system 0V)
Maximum input voltage
+ 60 V
9.5 GPI INPUT 2
Type
Current sinking type (also referred to as ground closure type).
Purpose
TBD
Input activation
≤1.0 V (wrt interface system 0V)
≤6 k Ω (contact to interface system ground)
Input deactivation
≥2.0 V (wrt interface system 0V)
Maximum input voltage
+ 60 V
9.6 GPI OUTPUT 1: REMOTE CHANGEOVER OUTPUT
Type
Relay contact -Latched
Purpose
Indicates current output channel set
(Retains indication when system loses power).
Sense
Open = Primary channel set selected
Closed = Secondary channel set selected
Max. load voltage
+30 VDC
Max. load current
1 A
9.7 GPI OUTPUT 2: REMOTE ALARM OUTPUT
Type
Opto-isolated floating type
Purpose
Indicates if primary and secondary channel set signals are
different format or if there is PSU module failure.
Note: PSU module present but not powered or PSU module fan
failure constitutes PSU module failure.
Sense
Floating = Alarm
Closed = OK
Max. load voltage
+60 VDC
Max. load current
250 mA
Max. power dissipation
450 mW
Page 38 of 43 Trilogy Communications
Mentor CX
9.8 SYSTEM BASE MODULE
Channel Set Type
Balanced AES/LTC
Number of Channel Sets
2 AES pairs/2 LTC pairs
Changeover Type
Latching relay
Retains selected channel set on power fail
Unselected channel terminated into 100 Ω.
Switching Time
Typically, <1.5 ms (max <3.0 ms)
Crosstalk
[Unselected input to output, channel to channel]
<-50dB 100kHz to 12MHz.
Fault detection condition
[LTC]
Fail condition
Signal low level threshold <500 mVpp
Incorrect LTC sync word
Warning condition
Discontinuous timecode.
Detected format difference (see Note 1 below)
[AES]
Fail condition
Signal low level threshold <200 mVpp
Incorrect AES preamble
Warning condition
Detected format difference (see Note 1 below)
Supports AES with 32, 44.1, 48 and 96 kHz sampling frequencies.
NOTE 1: Detection between different signal types – for example, between AES and LTC.
Page 39 of 43 Trilogy Communications
Mentor CX
SYSTEM BASE MODULE (CONT’D)
Channel Set Type
NTSC, PAL, Tri-level Sync (TLS), AES/DARS, word clock, clock 10 MHz,
clock 27 MHz
Number of Channel sets
4
Changeover Type
Latching relay
Retains selected channel set on power fail.
Unselected channel terminated into 75 Ω.
Switching Time
Typically, <1 ms (max <3 ms)
Return Loss
Better than -40dB to 6 MHz
Crosstalk
[Unselected input to output, channel to channel]
<-60dB, 100 kHz to 6 MHz
<-50dB, 6 MHz to 50 MHz
Fault detection condition
[NTSC, PAL, TLS]
Fail condition
Signal low level threshold <180 mV
Warning condition
Signal low level threshold <210 mV
Signal high level threshold >500 mV
Detected format difference
Format detection as detailed in section 5.1.2
[AES]
Fail condition
Signal low level threshold <320 mVpp
Incorrect AES preamble
Warning condition
Detected format difference
Supports AES with 32, 44.1, 48 and 96 kHz sampling frequencie
Page 40 of 43 Trilogy Communications
Mentor CX
SYSTEM BASE MODULE (CONT’D)
Channel Set Type
SD-SDI, HD-SDI, 3G-SDI
Number of channel sets
2
Changeover Type
HF 3 GHz latching relay
Retains selected channel set on power fail
Switching Time
Typically <1.5 ms (max <10 ms)
Return Loss
<-15dB 5 MHz to 1.5 GHz
<-10dB 1.5 GHz to 3 GHz
Crosstalk
[Unselected input to output, channel to channel]
<-55dB, 100 kHz to 900 MHz
<-30dB, 900 MHz to 3 GHz
Timing Jitter
[100% Colour bars]
< 0.20 UIpp [>10 Hz] - SD-SDI
< 0.30 UIpp [10 Hz-20 kHz] - HD-SDI
< 0.60 UIpp [10 Hz-20 kHz] - 3G-SDI
Alignment Jitter
[100% Colour bars]
< 0.20 UIpp [ 1kHz -27 MHz]
< 0.20 UIpp [0.1 -148.5 MHz]
< 0.30 UIpp [0.1 – 297 MHz]
Page 41 of 43 Trilogy Communications
Mentor CX
9.9 331-20-00 UNIVERSAL OPTION MODULE
Channel Set Type
NTSC, PAL, Tri-level, AES/DARS, word clock, clock 10 MHz,
clock 27 MHz
Number of channel sets
2
Changeover Type
Latching relay
Retains selected channel set on power fail.
Unselected channel terminated into 75 Ω.
Switching Time
Typically, <1 ms (max <3 ms)
Return Loss
Better than -40dB to 6 MHz
Crosstalk
[Unselected input to output, channel to channel]
<-60dB, 100 kHz to 6 MHz
<-50dB, 6 MHz to 50 MHz
Fault detection condition
[NTSC, PAL, Tri-level]
Fail condition
Signal low level threshold <180 mV
Warning condition
Signal low level threshold <210 mV
Signal high level threshold >50 0mV
Detected format difference
Format detection as detailed in section 6.2
[AES]
Fail condition
Signal low level threshold <320 mVpp
Incorrect AES preamble
Warning condition
Detected format difference
Supports AES with 32, 44.1, 48 and 96 kHz sampling frequencies.
[Word clock, 10 MHz clock, 27 MHz clock]
Fail condition
Signal low level threshold <320 mVpp
Warning condition
Detected format difference
Note for 27 MHz clock threshold accuracy margin increased to 25%.
Supports 10 MHz, 27 MHz and Word clock at the detected AES
sample rate.
Page 42 of 43 Trilogy Communications
Mentor CX
9.10 331-21-00 PASSIVE OPTION MODULE
Channel Set Type
Single-ended video up to 3 GHz
Number of channel sets
2
Changeover Type
HF 3 GHz latching relay
Retains selected channel set on power fail
Switching Time
Typically <1.5 ms (max <10 ms)
Return Loss
<-40dB up to 5 MHz
<-15dB 5 MHz to 1.5G Hz
<-10dB 1.5GHz to 3GHz
Crosstalk
[Unselected input to output, channel to channel]
<-55dB, 100 kHz to 900 MHz
<-30dB, 900 MHz to 3 GHz
Timing Jitter
[100% Colour bars]
< 0.20 UIpp [>10Hz] - SD-SDI
< 0.30 UIpp [10Hz-20kHz] - HD-SDI
< 0.60 UIpp [10Hz-20kHz] - 3G-SDI
Alignment Jitter
[100% Colour bars]
< 0.20 UIpp [1 kHz -27 MHz]
< 0.20 UIpp [0.1 -148.5 MHz]
< 0.30 UIpp [0.1 – 297 MHz]
Fault detection condition
None
9.11 331-22-00 SD/HD/3G SDI VIDEO OPTION MODULE
Channel Set Type
SD-SDI, HD-SDI, 3G-SDI
Number of channel sets
2
Changeover Type
HF 3GHz latching relay
Retains selected channel set on power fail
Switching Time
Typically <5ms (max <10ms)
Return Loss
<-15dB 5 MHz to 1.5 GHz
<-10dB 1.5GHz to 3GHz
Timing Jitter
[100% Colour bars]
< 0.20 UIpp [>10Hz] - SD-SDI
< 0.30 UIpp [10 Hz-20 kHz] - HD-SDI
< 0.60 UIpp [10 Hz-20 kHz] - 3G-SDI
Alignment Jitter
[100% Colour bars]
< 0.20 UIpp [1 kHz -27 MHz]
< 0.20 UIpp [0.1 -148.5 MHz]
< 0.30 UIpp [0.1 – 297 MHz]
Fault detection condition
Fail condition
No signal detected (carrier detect.
No signal lock
Warning condition
Cable length detected exceeds threshold
Format difference detected
Format detection as detailed in section
Page 43 of 43 Trilogy Communications
Mentor CX
9.12 331-22-00 SD/HD/3G SDI VIDEO OPTION MODULE – FORMATS DETECTED AND REPORTED
Physical
Hactive x Vactive/Frame rate Hz/scan type
3G
SMPTE 425-X
1920x1080/30/sF (note: will be reported as 1920x1080/60/i)
3G
SMPTE 425-X
1920x1080/29.97/sF (note: will be reported as 1920x1080/59.94/i)
3G
SMPTE 425-X
1920x1080/25/sF (note: will be reported as 1920x1080/50/i)
3G
SMPTE 425-X
1920x1080/24/sF (note: will be reported as 1920x1080/48/i)
3G
SMPTE 425-X
1920x1080/23.98/sF (note: will be reported as 1920x1080/47.95/i)
3G
SMPTE 425-X
1920x1080/60/p
3G
SMPTE 425-X
1920x1080/59.94/p
3G
SMPTE 425-X
1920x1080/50/p
3G
SMPTE 425-X
1920x1080/60/i
3G
SMPTE 425-X
1920x1080/59.94/i
3G
SMPTE 425-X
1920x1080/50/i
3G
SMPTE 425-X
1920x1080/30/p
3G
SMPTE 425-X
1920x1080/29.97/p
3G
SMPTE 425-X
1920x1080/25/p
3G
SMPTE 425-X
1920x1080/24/p
3G
SMPTE 425-X
1920x1080/23.98/p
HD
SMPTE 292
1920x1080/30/sF (note: will be reported as 1920x1080/60/i)
HD
SMPTE 292
1920x1080/29.97/sF (note: will be reported as 1920x1080/59.94/i)
HD
SMPTE 292
1920x1080/25/sF (note: will be reported as 1920x1080/50/i)
HD
SMPTE 292
1920x1080/24/sF (note: will be reported as 1920x1080/48/i)
HD
SMPTE 292
1920x1080/23.98/sF (note: will be reported as 1920x1080/47.95/i)
HD
SMPTE 292
1920x1080/60/i
HD
SMPTE 292
1920x1080/59.94/i
HD
SMPTE 292
1920x1080/50/i
HD
SMPTE 292
1920x1080/30/p
HD
SMPTE 292
1920x1080/29.97/p
HD
SMPTE 292
1920x1080/25/p
HD
SMPTE 292
1920x1080/24/p
HD
SMPTE 292
1920x1080/23.98/p
HD
SMPTE 292
1920x1035/59.94/i
HD
SMPTE 292
1920x1035/60/i
HD
SMPTE 292
1280x720/60/p
HD
SMPTE 292
1280x720/59.94/p
HD
SMPTE 292
1280x720/50/p
HD
SMPTE 292
1280x720/30/p
HD
SMPTE 292
1280x720/29.97/p
HD
SMPTE 292
1280x720/25/p
HD
SMPTE 292
1280x720/24/p
SD
SMPTE 292
1280x720/23.98/p
SD
SMPTE 259-C
720x576/50/i
SD
SMPTE 259-C
720x486/59.94/i
Loading...
