TriGem Ventura-M Quick Settings Guide

Ventura-M º¸µå ¼³¸í

* Ŭ¸&hibar;Çϸé Å©°Ô º¼ ¼ö ÀÖ½À´Ï´Ù.

°ü·Ã Á¤º¸ º¸±â

CPU Á¤º¸

CMOS SETUP

¸Þ¸ð¸® Á¤º¸

Á¡ÆÛ ¼³Á¤

Board History

º¸µå »ç¾ç

¸ÞÀÎĨ¼Â Intel FW82815
È®Àå ½½·Ô AGP - 1°³, PCI - 3°³
CPU Åö¿ø Intel Socket-370 (370pin PGA Socket)
¸Ã¨ solution 168 pin SDRAM 100/133MHz Áö¿ø
On Board SOUND (CS 4281), VIDEO (Intel i815)
¿Ü Çü 238mm * 238mm * 1.6t (4 Layers) : Micro ATX form factor

Ventura-M 점퍼 설정

점퍼 번호

설정

기능

1-2 (기본 설정)

2-3

J1 Enable Disable

PCI Audio 사용 기능

J3 Enable Disable

CMOS Setup 저장 기능

J4 Disable Enable CMOS Clear

J5 Enable Disable

Pass word 사용 기능

J6 Disable Enable

FDD 쓰기 금지 기능

Ventura-M CPU 지원

프로세서 타입 지원 가능 프로세서

Intel Socket-370

(370pin PPGA Socket)

Intel Celeron 400/433/466/500MHz 66MHZ Host clock

Intel Coppermine 500/550/600MHz 100MHZ Host clock

Intel Coppermine 667/733/933MHz 133MHZ Host clock

Ventura-M 메모리 지원

규 격 타 입 소 켓 최대 확장

3.3V SDRAM (168pin) SDRAM 100/133MHz

168Pin 3.3V 소켓 2개

512MB

DIMM Size Non-ECC DIMM Size Non-ECC

8MB 4 * (1M * 16bit) 64MB 8 * (8M * 8bit)

16MB 8 * (2M * 8bit) 64MB 4 * (8M * 16bit)

32MB 4 * (4M * 16bit) 128MB 8 * (16M * 8bit)

32MB 2 * (4M * 32bit)

BIOS Setup Utility

Main Advanced Security Power Boot Exit


System Time : [10:42:37]
System Date : [02/06/2001]

Legacy Diskette A : [1.44/1.25 MB 3 1/2]
Legacy Diskette B : [Disabled]


Primary Master [XXXX XXXX]
Primary Slave [None]
Secondary Master [XXX XXX XXX]

Secondary Slave [None]


System Memory : 640 KB
Extended Memory : XXXXX KB
Cache Ram XXX KB

BIOS Version 1.01

Item Specific Help

<Tab>, <Shift - Tab>, or

<Enter>, selects field.

F1 Help 상하 화살표 Select Item -/+ Change Values F9 Setup Defaults
ESC Exit 좌우 화살표 Select Menu Enter Select Sub-Menu F10 Save and Exit
