FATIMA Board Specifications 2003/10/08
division explanation
main
chipset
North Bridge
Intel 865G
South Bridge
Intel 82801EB (ICH5)
bios
AMI Flash bios (4Mbit)
CPU support
- Intel Pentium4 mPGA 478 socket
- Support 400/533/800MHz
memory support
- 184-pin Non-ECC DDR SDRAM DIMM socket * 2
- Supports 266/333/400MHz DDR DRAM (Dual Channel)
- Maximum extension: 2.0GB
ON BOARD
sound
Audio Controller + CMI9739A Codec in Intel 82801EB(ICH5)
speaker
microphone
jack
line out jack line input jack
2 channels
external
microphone
external
speaker
external
playback device
5 or 6
channels
center or
woofer
Front left/right
speaker
surround
speaker
LAN
Intel 82562EZ
expansion
slot
AGP
8X support slot * 1
PCI
32bit, 33MHz bus speed * 2
support
port
serial port
9-pin connector * 1 pc
parallel port
25-pin connector * 1
PS/2
6-pin mini-DIN connector * 1 each keyboard/mouse
IEEE 1394
VIA6307 IEEE1394 (P1394a standard support) * 2ea (front)
USB
Back (2.0) * 2pcs, Front * 2pcs (optional)
memory stick
Memory stick connector (SD card/MMC card supported)
IDE
40 pins * 2
S-ATA
Serial ATA * 2
floppy
connector
34 pin * 1 pc
LAN
RJ45 Jack * 1
sound
- Rear: Speaker/Line In/Microphone * 1 each
- Front: Headphone/SPDIF/Microphone * 1 each
monitor
Connector for connecting monitor * 1
appearance
* Based on board part number 143285
FATIMA CPU Supported Specifications 2003/10/08
CPU specs
division explanation
type mPGA478 (FC-PGA2)
internal speed 400/533/800 MHz
etc 1.725V Core Voltage not supported.
Intel Celeron mPGA478 Processor
processor bus clock L2 cache
2.0 400 MHz 128KB
2.1 400 MHz 128KB
2.2 400 MHz 128KB
2.3 400 MHz 128KB
2.4 400 MHz 128KB
2.6 400 MHz 128KB
Intel Pentium4 mPGA478 Processor
processor bus clock L2 cache
1.8AG 400 MHz 512 KB
2.0AG 400 MHz 512 KB
2.2G 400 MHz 512 KB
2.26G 533 MHz 512 KB
2.4G 533 MHz 512 KB
2.4CG 800 MHz 512 KB (HT support)
2.53G 533 MHz 512 KB
2.6G 533 MHz 512 KB
2.6CG 800 MHz 512 KB (HT support)
2.66G 533 MHz 512 KB
2.8G 533 MHz
2.8CG 800 MHz 512 KB (HT support)
3.0G 800 MHz 512 KB (HT support)
3.06G 533 MHz 512 KB (HT support)
3.2G 800 MHz 512 KB (HT support)
▶ Terminology: HT function (Hyper-Threading) - Function that recognizes one physical CPU as two
CPUs and
operates more effectively during multitasking or 3D work.
FATIMA memory support specifications 2003/10/08
memory specifications
division explanation
standard Non-ECC DDR SDRAM DIMMs
type 266/333/400 MHz
socket 184 pins * 2
max extension 2.0GB
installable capacity
DIMM size Non-ECC Configuration
64MB 8Mbit x 64bit
128MB 16Mbit x 64bit
256MB 32Mbit x 64bit
512MB 64Mbit x 64bit
1.0 GB 128Mbit x 64bit
Notes for upgrading (CPU system bus support)
division 400 MHz CPU 533 MHz CPU 800 MHz CPU
266 MHz DDR O O X
333 MHz DDR X O O
400 MHz DDR X X O
Built-in memory for Dual Channel memory effect
A type B type
One 2 One 2
C type
One 2
▶ If the CPU system bus is 400/533MHz, even if the memory speed is 333/400MHz DDR, the speed
operates at 266/333MHz.
▶ In case of mixed use of memories with different operating speeds, operation is based on the low
memory operating speed.
FATIMA Jumper Settings 2003/10/08
jumper function 1-2 2-3
JBIOS1 CMOS update availability
Impossible (possible
when open)
-
JBAT1 CMOS initialization impossible possible
JSEL1 standby mode setting S1 & S3 S1
