tricity bendix SE305W, SE305S, SE305GR, SE305B, SE305C User Manual
OPERATING & INSTALLATION
INSTRUCTIONS
SLIP IN ELECTRIC COOKER
SE305
7
PLEASE READ THIS INSTRUCTION BOOKLET BEFORE USING THE APPLIANCE
TECHNICAL DETAILS
MODEL NO. SE 305
Voltage: 230-240 Volts AC 50Hz
Wattage: 9.3-10.2kW
Height: 900mm
Width: 500mm
Depth: 600mm
Weight: 50kg
This appliance complies with: European Council Directive 73/23/EEC.
EMC Directive 89/336/EEC.
CE Marking Directive 93/68/EEC
2
CONTENTS
Technical Details .................................................................................................................................... 2
Contents .................................................................................................................................................. 3
Preface ..................................................................................................................................................... 5
Safety ....................................................................................................................................................... 6
Before Installation ........................................................................................................................... 6
During Operation ............................................................................................................................. 6
After Use ......................................................................................................................................... 7
General ........................................................................................................................................... 7
Introduction ............................................................................................................................................. 8
Rating Plate .................................................................................................................................... 8
Installation ....................................................................................................................................... 8
General Notes on Using Your Appliance ........................................................................................ 9
Oven Indicator Neon ....................................................................................................................... 9
About Condensation and Steam ..................................................................................................... 9
Control Panel Indicator Neon .......................................................................................................... 9
Grill and Oven Furniture .................................................................................................................. 9
Getting to Know Your Appliance .......................................................................................................... 10
The Control Panel ........................................................................................................................... 10
The Sealed Hotplates ............................................................................................................................. 11
Recommended Saucepans ............................................................................................................ 11
Hints and Tips ................................................................................................................................. 11
Deep Fat Frying ...................................................................................................................................... 12
Preserving ............................................................................................................................................... 12
The Grill ................................................................................................................................................... 13
Uses of the Grill .............................................................................................................................. 13
Selecting the Grill ............................................................................................................................ 13
Things to Note ................................................................................................................................. 13
The Grill Pan and Handle ............................................................................................................... 13
Hints and Tips ................................................................................................................................. 14
Grilling Chart ................................................................................................................................... 14
The Fan Oven .......................................................................................................................................... 15
Uses of the Fan Oven ..................................................................................................................... 15
Selecting the Fan Oven .................................................................................................................. 15
Things to Note ................................................................................................................................. 15
To Fit the Oven Shelves ................................................................................................................. 15
Hints and Tips ................................................................................................................................. 16
Fan Oven Cooking Chart ....................................................................................................................... 17
Roasting Chart ........................................................................................................................................ 18
3
CONTENTS
Defrost Feature ....................................................................................................................................... 19
Uses of Defrost Feature .................................................................................................................. 19
Selecting Defrost ............................................................................................................................. 19
Things to Note ................................................................................................................................. 19
Hints and Tips ................................................................................................................................. 19
Care and Cleaning .................................................................................................................................. 20
Cleaning Materials .......................................................................................................................... 20
Cleaning the Outside of the Appliance ........................................................................................... 20
Cleaning the Sealed Hotplates and Hotplate Trims ........................................................................ 20
Things to Note ................................................................................................................................. 20
For Normal Soilage ......................................................................................................................... 20
For Heavy Soilage .......................................................................................................................... 20
Cleaning the Hotplates Trims ......................................................................................................... 20
Cleaning the Vitreous Enamel ........................................................................................................ 20
After Cleaning ................................................................................................................................. 20
Cleaning the Grill and Oven Furniture ............................................................................................ 21
Cleaning Inside the Oven/Grill Compartments ............................................................................... 21
Hints and Tips ................................................................................................................................. 21
Something not Working? ....................................................................................................................... 22
Service and Spare Parts ........................................................................................................................ 23
Guarantee Conditions ............................................................................................................................ 24
Notes ........................................................................................................................................................ 25
4
PREFACE
Dear Customer,
Thank you for buying a Tricity Bendix appliance. With our 80 years experience in
developing and manufacturing the very best in U.K. appliances, you can be
assured that you have purchased a hard working, reliable, quality product.
Tricity Bendix appliances comply with British Standard safety and performance
requirements. They have been approved by BEAB (British Electrotechnical
Approvals Board) and are covered by a 12 month parts and labour guarantee.
To get the best from your new Tricity Bendix appliance, we ask that you PLEASE
READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made
to cooking times and temperatures, which may differ, from your previous
appliance.
It is most important that this instruction book is retained with the appliance for
future reference. Should the appliance be sold, or if you move house and leave
the appliance, always ensure that the book remains with the appliance. This will
enable the new owner to be acquainted with the functioning of the appliance and
the relevant warnings.
Please read the whole instruction book before attempting to use the appliance
ensuring you follow the recommendations given.
5
SAFET
Y
THESE WARNINGS ARE PROVIDED IN
THE INTERESTS OF YOUR SAFETY.
ENSURE THAT YOU UNDERSTAND
THEM ALL BEFORE INSTALLING OR
USING THE APPLIANCE.
PLEASE
READ
CAREFULLY
BEFORE INSTALLATION
This appliance is heavy and care
must be taken when moving it.
Ensure that all packaging, both
inside and outside the appliance
has been removed before the
appliance is used.
If the appliance is to be placed on
a base, measures must be taken
to prevent the appliance slipping
from the base.
DURING OPERATION
This appliance is not intended to
be operated by means of an
external timer or separate remote
control system.
Do not use this appliance if it is in
contact with water. Never operate
it with wet hands.
This appliance is designed to be
operated by adults. Young children
must not be allowed to tamper
with the appliance or play with the
controls.
During use the appliance becomes
Hot. Care should be taken to
avoid touching the heating
elements inside the oven.
'CAUTION': Accessible parts
may be hot when the grill is in
use. Young children should be
kept away.
Do not try to lift or move the
appliance by pulling the door
handles.
The electrical installation work
must be undertaken by a qualified
electrician/competent person.
It is dangerous to alter or modify
the specifications of the appliance
in any way.
Do not allow young children to
play with any part of the
packaging.
After installation, please dispose of
the packaging with due regard to
safety and the environment, your
local authority can arrange this.
Take great care when heating fats
and oils, as they will ignite if they
become too hot.
This appliance has been designed
for cooking edible foodstuffs only,
and must not be used for any
other purposes.
Never place plastic or any other
material which may melt in the
oven or on the hob.
Ensure cooking utensils are large
enough to contain foods to prevent
spillages and boil overs.
The handles of saucepans which
are smaller than the heated area
on the hob will become hot.
Ensure your hand is protected
before handling the pan.
6
Take care to follow the
recommendations given for
tending the food when grilling.
Always use oven gloves to
remove and replace food in the
oven.
Ensure that you support the grill
pan when it is in the withdrawn or
partially withdrawn position
Ensure that all vents are left
unobstructed to ensure ventilation
of the oven cavity.
Ensure the anti-tilt shelves are put
in place correctly. Refer to
instructions on page 15.
Never line any part of the
appliance with foil. Do not allow
heatproof cooking materials e.g.
roasting bags, to come into contact
with oven elements.
Always stand back from the
appliance when opening the oven
door to allow any build up of steam
or heat to release.
For hygiene and safety reasons
this appliance should be kept
clean at all times. A build-up of
fats or other foodstuffs could
result in a fire, especially in the
grill pan.
Do not leave utensils containing
foodstuffs, e.g. fat or oil in or on
the appliance in case it is
inadvertently switched ON.
Cookers and hobs become very
hot, and retain their heat for a long
period of time after use. Children
should be kept well away from the
appliance until it has cooled.
GENERAL
Under no circumstances should
any repairs be carried out by an
inexperienced person as this may
cause injury or serious
malfunction.
This appliance should be serviced
by an authorised service Engineer
and only genuine-approved spare
parts should be used. Details of
repair and servicing arrangements
are supplied on page 23 of this
book.
Do not stand on the appliance or
on the open oven door.
AFTER USE
Never leave the appliance
unattended when the door is
open.
Do not place sealed cans or
aerosols inside the oven. They
may explode if they are heated.
Do not leave the hotplates
switched ON for long periods when
not covered by a saucepan. The
controls and cabinets may
overheat.
Ensure that all control knobs are
in the OFF position when not in
use.
Do not hang towels, dishcloths or
clothes from the appliance or its
handle. They are a safety hazard.
Always switch OFF the appliance
at its power point and allow the
appliance to cool before any
maintenance or cleaning work is
carried out.
Only clean this appliance in
accordance with the instructions
given in this book.
Your safety is of paramount importance.
Therefore, if you are unsure about any of
the meanings of these WARNINGS
contact the:
Customer Care Department
Telephone 0870 5 950950
7
INTRODUCTION
WARNING: THIS APPLIANCE MUST BE EARTHED
RATING PLATE
This is situated on the front frame of the appliance
and can be seen upon opening the door. Alternatively
the rating plate may also be found on the back or top
of some models (where applicable).
The appliance must be protected by a suitably rated
fuse or circuit breaker. The rating of the appliance is
given on the rating plate.
Do not remove the rating plate from the appliance
as this may invalidate the guarantee.
INSTALLATION
If your appliance has been damaged in transit,
contact your supplier immediately. DO NOT attempt
to install it.
Your appliance left the factory fully packaged to
protect it from damage. If it is delivered without
packaging and damage has occurred, the
manufacturer cannot accept responsibility. Contact
your supplier for advice.
The cable should be routed away from potentially hot
areas marked by X in the diagram below.
To move the appliance, open the fan oven door, and
lift the appliance by holding inside the top of the
compartment.
Once the packaging has been removed the appliance
should only be moved by hand. DO NOT use a sack
barrow or any other aid to lift the appliance as
damage may occur.
Connection to the electricity supply must be carried
out by a qualified electrician/competent person.
The electrical connection should be made using a
double pole isolating switch (cooker socket) with at
least 3mm contact separation in all poles. The cable
must have conductors of sufficiently high crosssectional area to prevent overheating and
deterioration.
The recommended cross-section area is six square
millimetres (6.00mm
2
).
This is a type X appliance, which means it is freestanding and can be fitted with cabinets on one or
both sides. It may also be fitted in a corner setting.
Side walls which are above hob level should be
protected by heat resistant non-combustible material
and MUST NOT be nearer than 40mm to the hob
side.
A nominal air gap of 2mm all around the appliance is
required to enable the appliance to be moved into
position. It is recommended that proprietary trims are
fitted to protect the worktops of either side of the
appliance. These are available from most DIY
stores.
Always ensure an air gap is maintained at hotplate
level. Tile or other forms of deep wall covering
should not obscure this gap.
Air gap
8
Note: Vapours from the oven vent may in time cause
discolouration of wallcoverings behind the appliance.
For ease of cleaning it may be preferable to tile
behind the appliance.
Overhanging surfaces or a cooker hood should be a
minimum of 685mm above the hob.
It is important to ensure that the appliance is level
after installation. Levelling feet are fitted to the
appliance to accommodate uneven floors.
GRILL AND OVEN FURNITURE
The following items of grill/oven furniture have been
supplied with the appliance:
1 grill pan
GENERAL NOTES ON USING YOUR
APPLIANCE
We suggest that you run the oven elements for 10 –
15 minutes at 220
their surfaces. The procedure should be repeated
with the grill for approximately 5 – 10 minutes.
During this period an odour may be emitted, it is
therefore advisable to open a window for ventilation.
o
C to burn off any residue from
ABOUT CONDENSATION AND STEAM
When food is heated it produces steam similar to a
boiling kettle. The oven is vented to allow some of
this steam to escape. However, always stand back
from the appliance when opening the oven door to
allow any build up of steam or heat to release.
If the steam comes into contact with a cool surface
on the outside of the appliance, e.g. a trim, it will
condense and produce water droplets. This is quite
normal and is not caused by a fault on the appliance.
1 grill pan handle
1 grill pan grid
1 straight shelf for grilling
only
To prevent discolouration, regularly wipe away
condensation and also soilage from surfaces.
CONTROL PANEL INDICATOR NEON
The light will indicate whether the oven is switched
on, the neon also indicates when the set temperature
has been reached. The neon will turn on and off
during use to show that the temperature is being
maintained.
2 straight shelves
for fan oven cooking
9
Loading...
