Page 1
OPERATING AND INSTALLATION INSTRUCTIONS
MODEL NO.
SB 422/423
31
Page 2
TECHNICAL DETAILS
MODEL NO. SB 422/423
Voltage: 230/240 Volts AC 50Hz
Wattage: 10.3/11.2kW
Height: 1290mm
Width: 550mm
Depth: 595mm
Weight: 54kg
This appliance complies with: European Council Directive 73/23/EEC.
EMC Directive 89/336/EEC.
CE Marking Directive 93/68/EEC.
2
Page 3
7
CONTENTS
Technical Details ................................................................................. 2
Contents
Preface
.........................................................................................
...........................................................................................
3
5
Safety
Introduction ...................................................................................... 8
Getting to know your Cooker
The Radiant Hob ................................................................................ 14
Deep Fat Frying
Preserving ....................................................................................... 15
.............................................................................................
Before Installation ........................................................................... 6
During Operation ........................................................................... 6
After Use ................................................................................... 7
General .................................................................................... 7
Rating Plate
Installation .................................................................................. 8
Reversible Main Oven Door ................................................................. 9
General Notes .............................................................................. 9
Condensation and Steam ................................................................... 9
Oven Furniture ............................................................................. 9
The Control Panel ......................................................................... 10
The Timer ................................................................................. 11
Recommended Saucepans ................................................................. 14
Hints and Tips ............................................................................. 14
................................................................................
....................................................................
.................................................................................
10
15
6
8
The Grill
The Main Fan Oven .............................................................................. 18
Defrost Feature .................................................................................. 22
.........................................................................................
Uses of the Grill ........................................................................... 16
Selecting the Grill .......................................................................... 16
The Grill Pan and Handle ................................................................... 16
Hints and Tips ............................................................................. 17
Grilling Chart .............................................................................. 17
Uses of the Fan Oven ...................................................................... 18
Selecting the Fan Oven .................................................................... 18
Things to Note ............................................................................. 18
To Fit the Oven Shelves ................................................................... 18
Hints and Tips ............................................................................. 19
Oven Cooking Chart ....................................................................... 20
Roasting Chart ............................................................................. 21
Uses of Defrost ........................................................................... 22
Selecting Defrost ......................................................................... 22
Things to Note ............................................................................ 22
Hints and Tips ............................................................................ 22
16
3
Page 4
CONTENTS
Care and Cleaning
Cleaning Materials ........................................................................ 23
Cleaning the Radiant Hob and Hotplate Trims .............................................. 23
Cleaning the Vitreous Enamel .............................................................. 23
Cleaning the Outside of the Cooker ........................................................ 23
Cleaning the Grill Deflector, Grill Pan, Grid and Oven Shelves ............................... 23
Cleaning Inside the Oven/Grill Compartments .............................................. 24
Care of Stayclean Surfaces ................................................................ 24
Hints and Tips ............................................................................ 24
Replacing the Oven Light Bulb ............................................................. 24
Something not Working?
Service and Spare Parts
Customer Service Centres ....................................................................... 27
Guarantee Conditions
...............................................................................
........................................................................
.........................................................................
...........................................................................
23
25
26
29
4
Page 5
PREFACE
Dear Customer,
Thank you for buying a Tricity Bendix cooker. With our 80 years experience in
developing and manufacturing the very best in U.K. cookers, you can be
assured that you have purchased a hard working, reliable, quality product.
Tricity Bendix cookers comply with British Standard safety and performance
requirements. They are covered by a 12 month parts and labour guarantee.
To get the best from your new Tricity Bendix cooker, we ask that you PLEASE
READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be
made to cooking times and temperatures which may differ from your previous
cooker.
It is most important that this instruction book is retained with the appliance for
future reference. Should the appliance be sold, or if you move house and
leave the appliance, always ensure that the book remains with the appliance.
This will enable the new owner to be acquainted with the functioning of the
appliance and the relevant warnings.
Please read the whole instruction book before attempting to use the appliance
ensuring you follow the recommendations given.
5
Page 6
SAFETY
THESE WARNINGS ARE PROVIDED IN
THE INTERESTS OF YOUR SAFETY.
ENSURE THAT YOU UNDERSTAND
THEM ALL BEFORE INSTALLING OR
USING THE COOKER.
PLEASE
READ
CAREFULLY
BEFORE INSTALLATION
This cooker is heavy and care must
be taken when moving it.
Ensure that all packaging, both
inside and outside the appliance,
has been removed before the
appliance is used.
This appliance is designed to be
operated by adults. Young children
must not be allowed to tamper with
the cooker or play with the controls.
Accessible parts especially around
the grill area may become hot when
the cooker is in use. Children should
be kept away until it has cooled.
Take great care when heating fats
and oils as they will ignite if they
become too hot.
This product has been designed for
cooking edible foodstuffs only, and
must not be used for any other
purposes.
Never place plastic or any other
material which may melt in the oven
or on the hob.
Do not try to move the appliance by
pulling the door handles.
The electrical installation work must
be undertaken by a qualified
electrician/ competent person.
It is dangerous to alter or modify
the specifications of the product in
any way.
DURING OPERATION
Do not use this cooker if it is in
contact with water. Never operate it
with wet hands.
Ensure cooking utensils are large
enough to contain foods to prevent
spillages and boil overs.
The handles of saucepans which are
smaller than the heated area on the
hob will become hot. Ensure your
hand is protected before handling the
pan.
Take care to follow the
recommendations given for tending
the food when grilling.
Do not leave the handle in position
when grilling as it will become hot.
Always use oven gloves to remove
and replace the grill pan handle
when grilling. Recommendations
given on page 16.
6
Page 7
Ensure that all vents are left
unobstructed to ensure ventilation of
the oven.
Ensure that the anti-tilt shelves are
put in place correctly. Refer to
instructions on page 18.
Never line any part of the appliance
with aluminium foil.
Always stand back from the
appliance when opening the oven
door to allow any build up of steam
or heat to release.
Do not place sealed cans or
aerosols inside the oven. They may
explode if they are heated.
GENERAL
Under no circumstances should
repairs be carried out by
inexperienced persons as this may
cause injury or serious malfunction.
This product should be serviced by
an authorised Service Engineer and
only genuine approved spare parts
should be used. Details of servicing
and repair arrangements are given on
page 26 of this book.
Do not stand on the appliance or on
the open oven door.
Do not hang towels, dishcloths or
clothes from the appliance or its
handle. They are a safety hazard.
AFTER USE
After installation, please dispose of
the packaging with due regard to
safety and the environment.
Ensure that all control knobs are in
the OFF position when not in use.
For hygiene and safety reasons this
appliance should be kept clean at all
times. A build-up of fats or other
foodstuffs could result in a fire,
especially in the grill pan.
Do not leave utensils containing
foodstuffs, e.g. fat or oil in or on the
appliance in case it is inadvertently
switched ON.
After allowing the cooker to cool
always switch OFF the cooker at its
power point before any maintenance
or cleaning work is carried out.
Only clean this cooker in accordance
with the instructions given in this
book.
Your safety is of paramount importance.
Therefore, if you are unsure about any of the
meanings of these WARNINGS contact the:
Consumer Care Department
Telephone (01635) 525542
Cookers and hobs become very hot,
and retain their heat for a long period
of time after use. Children should be
kept well away from the appliance
until it has cooled.
7
Page 8
INTRODUCTION
WARNING: THIS APPLIANCE MUST BE EARTHED
RATING PLATE
Record the model, product and serial numbers on the
back from the rating plate. This is situated on the
front frame of the appliance and can be seen upon
opening the oven door.
The appliance must be protected by a suitably rated
fuse or circuit breaker. The rating of the appliance is
given on the rating plate.
INSTALLATION
If your cooker has been damaged in transit, contact
your supplier immediately. DO NOT attempt to install
it.
The cable should be routed away from potentially hot
areas marked by X in the diagram below.
To move the cooker, open the main oven door and
lift the cooker by holding the inside top of the
compartment.
Your cooker left the factory fully packaged to protect
it from damage. If it is delivered without packaging
and damage has occurred, the manufacturer cannot
accept responsibility. Contact your supplier for
advice.
Once the packaging has been removed the cooker
should only be moved by hand. DO NOT use a sack
barrow or any other aid to lift the cooker as damage
may occur.
Connection to the electricity supply must be carried
out by a qualified electrician/competent person.
The electrical connection should be made using a
double pole isolating switch (cooker socket) with at
least 3mm contact separation. The cable must have
conductors of sufficiently high cross-sectional area to
prevent overheating and deterioration.
Six square millimetres (6.00mm²) is the recommended
cross-section area.
This is a type Y appliance which means it is
free-standing and can be fitted with cabinets on one
or both sides. It may also be fitted in a corner setting.
A nominal air gap of 2mm all around the cooker is
required to enable the cooker to be moved into
position.
Side walls which are above hob level should be
protected by heat resistant non-combustible material
and MUST NOT be nearer than 40mm to the hob
side.
Overhanging surfaces or a cooker hood should be a
minimum of 685mm above the hob.
It is important to ensure that the appliance is level
after installation. Levelling feet are fitted to the front
of the appliance to accommodate uneven floors.
8
Page 9
REVERSIBLE MAIN OVEN DOOR
OVEN FURNITURE
If you require the oven door to be hinged on the
opposite side, you will need to contact a qualified
Service Engineer. See page 27 for your nearest
Service Centre. PLEASE NOTE that a charge will be
made.
GENERAL NOTES ON USING YOUR
COOKER
We suggest that you run the oven elements for 10 15 minutes at 220°C to burn off any residue from
their surfaces.
During this period an odour may be emitted, it is
therefore advisable to open a window for ventilation.
ABOUT CONDENSATION AND STEAM
When food is heated it produces steam similar to a
boiling kettle. The ovens are vented to allow some of
this steam to escape. However, always stand back
from the appliance when opening the oven door to
allow any build up of steam or heat to release.
The following items of oven furniture have been
supplied with the cooker:
1 grill pan/meat tin
1 grill pan handle
1 grill pan grid
1 grill deflector
If the steam comes into contact with a cool surface
on the outside of the appliance, e.g. a trim, it will
condense and produce water droplets. This is quite
normal and is not caused by a fault on the appliance.
To prevent discolouration, regularly wipe away
condensation and also soilage from surfaces.
1 trivet
1 cranked shelf for
grilling
2 straight shelves
for main oven cooking
The grill deflector sits above the grill element and
prevents fat splashing onto the grill roof.
The deflector may be easily removed for cleaning.
9
Page 10
GETTING TO KNOW YOUR COOKER
THE CONTROL PANEL
A B C D E
FEATURES
A - Timer D - Dual Grill Control
B - Oven Temperature Control E - Hotplate Controls
C - Oven Indicator Neon
10
Page 11
THE TIMER
A START TIME SETTING KNOB
B SECOND HAND
C CLOCK SYMBOL
D CLOCK/MINUTE MINDER/LENGTH
OF COOKING TIME SETTING KNOB
E START TIME INDICATOR
F HOUR HAND
G DISPLAY WINDOW
H MANUAL SYMBOL
J MINUTE HAND
1. TO SET THE TIME OF DAY
The clock will operate when the cooker is
switched ON at the wall.
To set, pull out and turn setting knob (D)
clockwise until the right time of day is displayed,
e.g. 9 a.m. as Fig.1.
J
H
G
Fig. 1
A
B
C
D
E F
D
2. TO SET FOR MANUAL COOKING
Ensure the time of day has been set as above.
Push in and turn setting knob (A) in either
direction until the start time indicator (E) lines up
with the hour hand of the clock.
Push in and turn setting knob (D) clockwise until
the manual symbol (H) can be seen in window
(G) as Fig. 2.
The oven temperature control can now be
operated as required. The oven neon indicator
will glow.
3. TO SET THE MINUTE MINDER
Turn setting knob (D) clockwise, without pulling
it out. The selected minutes can be seen in the
window (G), e.g. 80 minutes as Fig. 3.
A period of up to 3 hours can be timed using the
minute minder. The minute minder cannot be
used when an automatic programme has been
set on the oven timer.
H
G
G
Fig. 2
70
80
90
A
D
At the end of the set time a continuous buzzer
will sound for up to 6 minutes.
Fig. 3
D
11
Page 12
4. TO CANCEL MINUTE MINDER/BUZZER
Turn setting knob (D) clockwise, without pulling
it out until "O" or the manual symbol appears in
the window (G) as Fig.4.
5. HOW TO SET THE OVEN TIMER
When using the oven timer for the very first time,
it is advisable to let it operate while you are at
home. The timer can be checked to show that it
is operating correctly and then you will then feel
confident to leave a meal to cook automatically in
the future.
A) TO SWITCH THE OVEN ON AND OFF
AUTOMATICALLY
i) Make sure the electricity supply is switched
ON.
ii) Check the clock shows the right time of day
and the cooker is set in manual (see point 2).
Adjust as necessary as Fig. 5.
iii) Place food in oven.
iv) To set the length of time you want the food to
cook; turn setting knob (D) clockwise,
without pulling it out, until the required
cooking period can be seen in the window (G)
e.g. 160 minutes (2 hours 40 mins) as Fig. 6.
G
H
G
G
Fig. 4
Fig. 5
150
160
170
D
A
D
v) Set the start time, by pushing in and turning
setting knob (A) in either direction until
indicator (E) lines up with the time you want
the food to start cooking, e.g. 1.30 p.m. as
Fig. 7.
vi) Turn the oven temperature control to the
required setting. The oven indicator light
should be OFF.
vii)When automatic cooking starts the oven neon
indicator will cycle ON and OFF showing that
the oven temperature is being maintained.
viii)The start time indicator (E) will move with the
hour hand of the clock until the length of
cooking time is complete. A buzzer will sound
which can be cancelled by following point 4 as
Fig. 8.
ix) The maximum cooking time on automatic is 3
hours.
G
G
Fig. 6
150
160
170
Fig. 7
D
A
E
12
Fig. 8
Page 13
B) TO START COOKING NOW, THEN SWITCH
OFF AUTOMATICALLY
Follow the first 3 points under section 5. (A)
above, and then;
iv) To set the length of time you want the food to
cook; turn setting knob (D) clockwise,
without pulling it out, until the required
cooking period can be seen in window (G),
e.g. 120 minutes (2 hours) and Fig. 9.
v) Turn the oven temperature control to the
required setting. The oven neon indicator
should glow.
vi) The oven neon indicator will cycle ON and
OFF showing that the oven temperature is
being maintained.
vii)The start time indicator (E) will move with the
hour hand of the clock until the length of
cooking time is complete. A buzzer will sound
which can be cancelled by following point 4 as
Fig. 10.
G
110
120
130
D
Fig. 9
6. RETURNING THE COOKER TO
MANUAL OR TO CANCEL AN
AUTOMATIC PROGRAMME
Turn the oven temperature control OFF.
Ensure the start time indicator (E) lines up
with the hour hand of the clock by pushing in
and turning in either direction, setting knob
(A). Fig. 11.
The manual symbol (H) should be displayed
in window (G) by turning setting knob (D)
clockwise.
Turn the oven temperature control ON to
check that the oven operates manually. The
oven neon indicator should light.
7. THINGS TO NOTE
* If an automatic programme has been set on
the main oven, the grill WILL operate
manually.
* The delay time plus the cooking time MUST
NOT exceed 11 hours and 59 minutes.
G
Fig. 10
A
H
D
Fig. 11
13
Page 14
THE RADIANT HOB
l
To operate the hotplates turn the control knobs in
either direction to vary the heat setting. The
highest number represents the hottest setting
and the lowest the coolest setting.
RECOMMENDED SAUCEPANS
For speed and economy only good quality
saucepans with flat bases and close fitting lids are
recommended.
l
Avoid placing fish kettles or large preserving
pans across two hotplates as this may cause
damage.
The saucepan base should cover the hotplate as
much as possible. A base diameter of up to 225mm
(9") may be used on a 180mm (7") hotplate.
Pressure cookers, preserving pans, etc., should
comply with the recommendations given above.
HINTS AND TIPS
l
Lift, rather than slide saucepans on and off the
hob to help to reduce scratches and maintain the
efficiency of the hotplates.
l
Follow any guidelines provided by the
saucepan manufacturer.
l
To prolong the life of the hotplates:
l
Never use utensils with a skirt, e.g. a bucket
l
Never use an asbestos mat
l
Never line the spillage tray with aluminium foil
l
Never leave the hotplates ON when not covered
with a saucepan
l
For full details on deep fat frying and
preserving refer to instructions on page 15.
14
Page 15
DEEP FAT FRYING
SPECIAL FRYING NOTE:
For safety purposes when deep fat frying, fill the pan
one-third full of oil, DO NOT cover the pan with a lid
and DO NOT leave the pan unattended. In the
unfortunate event of a fire, switch OFF at the
electricity supply and cover the pan with a lid or
damp cloth to assist in smothering the flames.
DO NOT use water on the fire. Leave the pan to cool
for at least 30 minutes before moving it.
DO NOT leave the fat or oil in the frying pan on the
hob to store it in case the hob is inadvertently
switched ON.
6. Frying temperatures
Celsius Fahrenheit
Scale (
First frying of potatoes 170 340
Second frying of potatoes 190 375
Frying chicken and fish 195 380
o
C) Scale (oF)
150 300
175 350
180 360
200 390
PRESERVING
1. DO NOT use a pan that overlaps the perimeter of
the hob trim.
1. Preparing the food
Seal the food by coating with flour, egg and
breadcrumbs or batter. Do not use a basket with
batter coated foods as they will stick.
2. Amount of oil
For safety purposes fill the pan only one-third full
of oil.
3. Testing the temperature of the oil
It is advisable to use a thermometer to test the
temperature of the oil. Alternatively, drop a small
cube of bread into the oil which should brown in
just under a minute if the oil is at the correct
temperature of 190°C/375°F.
4. Cooking the food
Lower the food gently into the oil. Do not add
too much food at once or the temperature of the
oil will be reduced and may result in soggy,
greasy food.
Turn the food if necessary; doughnuts float to the
surface so will not brown on the upperside if not
turned. Once cooked, drain the food on
absorbent paper.
5. Double frying chips
Double frying will ensure good chips. First fry the
chips for a few minutes at 170°C/340°F to seal
the outside. Remove the chips from the oil.
Increase the temperature of the oil to
190°C/375°F to finish cooking and brown the
chips.
2. To allow for a full rolling boil, the pan should be
no more than one third full when all the
ingredients have been added. It is better to use
two pans rather than overfill one, or use half
quantities.
3. Use firm fruit or vegetables and wash well before
using.
4. Preserving sugar gives clear jam, however
granulated sugar is cheaper and gives equally
good flavour.
5. Crystallization may be caused if sugar is not
completely dissolved before bringing jam to the
boil. Over boiling will affect the flavour, setting
properties and colour of the jam.
6. To test jam for setting:
If a jam thermometer is available, boil jam to
104°C. Marmalade should be boiled to 106°C.
If a jam thermometer is not available, remove
pan from heat, place sample of jam on a cold
dish and cool quickly (i.e. in a freezer or frozen
food storage compartment of a refrigerator).
When cold, it will crinkle and hold the mark of a
finger run through it, if it is at setting point.
7. The scum should be removed as soon as
possible after setting, but marmalade should be
allowed to cool before potting to prevent the peel
rising.
Chips may be kept for several hours after the first
frying before finishing off with the second frying.
15
Page 16
THE GRILL
USES OF THE GRILL
CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE
KEPT AWAY.
The grill is a dual circuit grill which means that the full area of the grill can be used or for economy purposes, the
centre section only can be used when cooking smaller quantities of food.
SELECTING THE GRILL
l
Turn the grill control clockwise for full grill or
anticlockwise for the centre section only. The
highest number represents the hottest setting
and the lowest the coolest setting.
NOTE
THE GRILL DOOR MUST BE LEFT OPEN DURING
GRILLING.
The cranked shelf MUST only be used in the grilling
compartment, but a straight shelf from the oven may
be used to provide alternative positions.
The outer grill element may appear to glow slightly
brighter than the inner element. This is quite normal.
THE GRILL PAN AND HANDLE
The grill pan is supplied with a removable handle.
To insert the handle, press the button on the handle
with the thumb and pivot the handle slightly upwards
inserting the lip into widest part of the bracket. Move
the handle towards the left, lower into position and
release the button.
When removing the handle, press the button on the
handle with the thumb and pivot the handle slightly
upwards and towards the right to remove from the
bracket.
Ensure your hand is protected when removing
the grill pan handle as the grill element can
become very hot.
ALWAYS REMOVE THE GRILL PAN HANDLE
DURING GRILLING.
Ensure the handle is positively located.
16
16
Page 17
To correctly locate the grill pan on the shelf, ensure
that the cut out on the underside of the handle
bracket locates over the front bar of the shelf.
l
Accompaniments such as tomatoes and
mushrooms may be placed underneath the grid
when grilling meats.
To check the progress of the food being grilled, the
grill pan should be withdrawn on the shelf to tend the
food during cooking, or the carrier shelf can be lifted
away from the cooker and rested on a heat resistant
work surface.
HINTS AND TIPS
l
Food should be thoroughly dried before
grilling to minimise splashing. Brush lean
meats and fish lightly with a little oil or melted
butter to keep them moist during cooking.
l
The use of the trivet beneath the grid when
grilling fatty food will keep fat splashing to a
minimum.
l
Place food on the grill pan grid in the grill pan
or on the trivet in the grill pan.
l
Preheat the grill on a full setting for a few
minutes before cooking. Adjust the heat setting
and the shelf as necessary during cooking.
l
Turn foods over during the cooking time as
required.
l
The outer grill element may appear to glow
slightly brighter than the inner element. This is
quite normal.
GRILLING CHART
FOOD SHELF GRILL TIME
Bacon Rashers
Beefburgers
Chicken Joints
Chops - Lamb
Pork
Fish - Whole
Trout/Mackerel
Fillets - Plaice/Cod
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2-3 each side
6-10 each side
15-20 each side
7-10 each side
10-15 each side
8-12 each side
4-6 each side
l
Adjust the grid and grill pan runner position to
allow for different heights of food.
l
When toasting bread use the cranked shelf in
position 2. Adjust the grill pan grid to suit.
Kebabs
Kidneys - Lamb/Pig
Liver - Lamb/Pig
Sausages
Steaks - Rare
Medium
Well Done
Toasted Sandwiches
crk. = cranked shelf
Shelf positions are counted from the bottom
upwards.
The times quoted above are given as a guide and
should be adjusted to suit personal taste.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
10-15 each side
4-6 each side
5-10 each side
10-15 each side
3-6 each side
6-8 each side
7-10 each side
1¼-1½ each
side
17
Page 18
THE MAIN FAN OVEN
USES OF THE FAN OVEN
PREHEATING
The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without
preheating, however, you may find you need to add an extra 5 - 10 minutes on the recommended cooking times.
For recipes needing high temperatures, e.g. bread, pastries, scones, soufflés, etc., best results are achieved if the
oven is preheated first.
COOKING TEMPERATURES
Fan oven cooking generally requires lower temperatures than conventional cooking. Follow the temperatures
recommended in the chart on page 20. As a guide reduce temperatures by about 20°C - 25°C for your own recipes.
BATCH BAKING
The fan oven cooks evenly on both shelf levels, especially useful when batch baking.
SELECTING THE FAN OVEN
l
Turn the oven temperature control to the required
setting.
THINGS TO NOTE
1. The main oven indicator neon will glow until the
oven has reached the desired temperature and
then go out. It will cycle ON and OFF periodically
during cooking showing that the temperature is
being maintained.
TO FIT THE MAIN OVEN SHELVES
The shelves should be fitted with the straight rods
uppermost on the frame and the forms towards the
back of the oven. If not fitted correctly the anti-tilt and
safety stop mechanism will be affected.
18
18
Page 19
HINTS AND TIPS
l
Arrange the shelves in the required positions
before switching the oven ON. Shelves are
numbered from the bottom upwards.
l
When cooking more than one dish in the fan
oven, place dishes centrally on different shelves
rather than cluster several dishes on one shelf.
This will allow the heat to circulate freely for the
best cooking results.
l
When batch baking one type of food, e.g. Victoria
sandwich cakes, those of similar size will be
cooked in the same time.
l
DO NOT use the cranked shelf from the grill in
the main oven.
l
It is recommended that when baking larger
quantities, the shelf positions should be evenly
spaced to suit the load being cooked. A slight
increase in cooking time may be necessary.
l
The use of excessively high temperatures can
cause uneven browning. It may be necessary to
reduce temperatures slightly. Refer to the
recommendations given in the oven cooking chart
on page 20.
19
Page 20
OVEN COOKING CHART
The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the
temperatures by 10° C to suit individual preferences and requirements.
Shelf positions are counted from the bottom of the oven.
FOOD
Biscuits
Flapjacks
Shortbread
Bread
Bread rolls/buns
Casseroles - beef
Chicken casserole
Cakes: Small & Queen
Victoria sandwich
Gingerbread
Madeira
Rich fruit
Christmas
Meringues
Convenience Foods Follow instructions on the pack
Fish 3 180-190 20-30
Fish pie (potato topped)
Shepherds pie
Fruit pies and crumbles
Milk puddings
Pastry: Choux- Chocolate eclairs
Profiteroles
Shortcrust- Mince pies
Flaky/Puff pies
Quiche Lorraine/tarts/flan
Meat pie
Plate tarts/pies 2 and 5 200-210 30-45
Scones
Soufflés
Roasting Meat and Poultry 1 180-200 See Roasting Chart
Pasta e.g. Lasagne 3 200 30-40
Vegetable dishes
Baked jacket potatoes
Baked stuffed marrow
Baked stuffed tomatoes
Roast potatoes
Yorkshire puddings: (large)
(individual)
MAIN OVEN
SHELF
POSITIONS
4 and 5
5
3
1 and 5 210-220 20-30
3
3
2 and 5
2 and 5
3
3
3
2
2
3 200-210 20-25
4
2
2 and 5
2 and 5
2 and 5
3
5 200-210 30-45
2 and 5
3
2 and 4
5
3
5
5
2 and 5
COOKING
TEMP (°C)
190-200
180-190
150-160
140-150
180-190
180-190
180-190
150-160
170-180
150-160
140-150
90-100
210-220
150-160
190-200
180-190
200-210
220-230
230-240
200
200
200
190
200-220
230
230
APPROXIMATE
COOK
TIME (MINS)
10-20
25-30
45-65
2-3 hours
1½ hours
20-25
20-25
1¼-1½ hours
1-1¼ hours
3
2¼-2
/4 hours
Depending on size 3-4½h
2½-3 hours
40-45
1½-2 hours
30-35
20-30
15-20
30-40
8-12
30-40
1-1½ hours
30-35
20-25
1-1½ hours
35-40
35-40
20
Page 21
ROASTING CHART
TEMPERATURES (°C)
MEAT MAIN OVEN
Beef
Beef, boned
Mutton and Lamb
Pork and veal
Ham
Chicken
Turkey and goose
180-200
180-200
180-200
180-200
180-200
180-200
180-200
COOKING TIME
20-35 minutes per ½kg (1lb)
and 20-35 minutes over
25-35 minutes per ½kg (1lb)
and 25-35 minutes over
25-35 minutes per ½kg (1lb)
and 25-35 minutes over
30-40 minutes per ½kg (1lb)
and 30-40 minutes over
30-40 minutes per ½kg (1lb)
and 30-40 minutes over
15-20 minutes per ½kg (1lb)
and 20 minutes over
15-20 minutes per ½kg (1lb) up
to 3½kg (7lb) then 15 minutes
per ½kg (1lb)
Duck
Pheasant
Rabbit
Potatoes with
meat
Potatoes without
meat
180-200
180-200
180-200
180-200
190-200
25-35 minutes per ½kg (1lb)
and 25-35 minutes over
35-40 minutes per ½kg (1lb)
and 35-40 minutes over
20 minutes per ½kg (1lb)
and 20 minutes over
according to size
according to size
21
Page 22
DEFROST FEATURE
USES OF DEFROST FEATURE
This fan oven function defrosts most foods faster
than more conventional methods. It is particularly
suitable for delicate frozen foods which are to be
served cold e.g. cream filled gateaux, cakes covered
with icings or frostings, cheesecakes, biscuits,
scones etc.
It is preferable to thaw fish, meat and poultry slowly
in the fridge. However, this process can be
accelerated by using the defrost function.
SELECTING DEFROST
Small or thin fish fillets, frozen peeled prawns, cubed
or minced meat, liver, thin chops, steaks etc., can be
thawed in 1 - 2 hours.
A 1kg/2¼lb oven ready chicken will be thawed in
approximately 5 hours. Remove the giblets as soon
as possible during the thawing process.
Joints of meat up to 2kg/4½lb in weight can be
thawed using the defrost function.
ALL JOINTS OF MEAT AND POULTRY MUST BE
THAWED THOROUGHLY BEFORE COOKING.
ALWAYS COOK THOROUGHLY IMMEDIATELY
AFTER THAWING.
l
Turn the oven temperature control to the defrost
setting.
l
When defrost is selected, the oven indicator neon
may come ON. It will stay ON until the oven
reaches room temperature and then go OFF.
l
It may cycle ON and OFF periodically during
defrosting to maintain a steady room
temperature, inside the oven.
THINGS TO NOTE
Care must always be taken when handling foods
in the home. Always follow the basic rules of food
hygiene to prevent bacterial and microbial growth
and cross contamination when defrosting,
preparing, cooking, cooling and freezing foods.
22
22
HINTS AND TIPS
l
Place the frozen food in a single layer where
possible and turn it over half way through the
defrosting process.
l
The actual speed of defrosting is influenced by
room temperature. On warm days defrosting will
be faster than on cooler days.
l
DO NOT leave food at room temperature once it
is defrosted. Cook raw food immediately or store
cooked food in the fridge.
Page 23
CARE AND CLEANING
ALWAYS SWITCH OFF THE ELECTRICITY
SUPPLY AND ALLOW THE COOKER TO COOL
BEFORE CLEANING
CLEANING MATERIALS
Before using any cleaning materials on your cooker,
check that they are suitable and that their use is
recommended by the manufacturer.
Cleaners that contain bleach should NOT be used as
they may dull the surface finishes. Harsh abrasives
should also be avoided.
CLEANING THE RADIANT HOB AND
HOTPLATE TRIMS
Clean the hob surface with liquid detergent or mildly
abrasive cream cleaner.
The hotplate trims are removable for cleaning, and
can be washed in the dishwasher. The chrome
hotplate supports should not be removed.
The spillage tray below the hotplates can be cleaned
using a soap impregnated steel wool pad.
CLEANING THE OUTSIDE OF THE
COOKER
DO NOT use abrasive cleaning materials, or
scourers on the outside of the cooker as some of the
finishes are painted and damage may occur.
Regularly wipe over the control panel, splashback,
oven door and cooker sides using a soft cloth and
liquid detergent.
DO NOT ATTEMPT TO REMOVE ANY OF
THE CONTROL KNOBS FROM THE
PANEL
AS THIS MAY CAUSE DAMAGE AND IS A
SAFETY HAZARD
For convenience, the hob is hinged and can be
supported using the hob stay rod during cleaning.
CLEANING THE VITREOUS ENAMEL
Use a clean damp cloth or scourer made for nonstick saucepans with 'Jif' or cream cleaner.
AFTER CLEANING
To maintain the appearance of the hotplates
occasionally apply a little salt free vegetable oil or
commercial restorative agent e.g. '4 Hob' or use a
'Minky' Hotplate Cleaning Cloth.
CLEANING THE GRILL DEFLECTOR,
GRILL PAN, GRILL PAN GRID AND OVEN
SHELVES
All removable parts, except the grill pan handle, can
be washed in the dishwasher. The chrome hotplate
supports should NOT be removed.
The grill pan and grill deflector can be cleaned using
a soap impregnated steel wool pad. The grill pan grid
and oven shelves should be cleaned using hot soapy
water. Soaking first in soapy water will make cleaning
easier .
To apply vegetable oil, first heat the hotplate on a
medium setting for 30 seconds then turn OFF. Pour
a very small amount of oil onto kitchen paper, apply
the paper to the hotplate and wipe off any excess oil.
Heat the hotplate on a medium setting for 1 minute.
To apply restorative agent, apply a thin coating
of '4 Hob' or use a Minky cloth following the
manufacturers instructions.
23
Page 24
CLEANING INSIDE THE OVEN/GRILL
COMPARTMENTS
The Stayclean surfaces inside the ovens should not
be cleaned manually. See "Care of Stayclean
Surfaces".
The vitreous enamel oven base can be cleaned
using normal oven cleaners or aerosol oven cleaners
with care. Ensure that the manufacturers instructions
are followed and that all parts are well rinsed
afterwards.
Aerosol cleaners must not be used on Stayclean
surfaces and must not come into contact with
elements as this may cause damage.
l
Follow the recommendations below to keep oven
soilage to a minimum.
l
Cook at the recommended temperatures. Higher
temperatures during roasting will increase
soilage. Try cooking at lower temperatures for an
increased length of time, you will save energy
and often the joint is more tender.
l
Use minimal, if any, extra oil or fat when roasting
meat, potatoes only require brushing with fat
before cooking. Extra fat in the oven during
roasting will increase splashing and soilage.
l
It is NOT necessary to add water to the meat tin
when roasting. The water and the fat juices from
the joint create excessive splattering during
cooking - even at normal temperatures, as well
as causing condensation.
l
Covering joints during cooking will also prevent
splashing onto the interior surfaces. Removing
the covering for the last 20-30 minutes will allow
extra browning if required. Some large joints and
turkeys especially benefit by this method of
cooking, allowing the joint to cook through before
the outside is over-browned.
CARE OF STAYCLEAN SURFACES
Stayclean surfaces destroy splashes of food and fats
when the oven temperature is raised to around
220°C.
It is a good idea to run the oven for an hour or two
per week to ensure continued good performance
from the Stayclean finish.
Do use the trivet in the roasting tin. During roasting,
the fat from the joint will be contained beneath the
trivet and therefore prevent it from splashing onto the
stayclean finish.
HINTS AND TIPS
l
Manual cleaning of Stayclean IS NOT
recommended. Damage will occur if oven
sprays or abrasives of any kind are used.
l
Slight discolouration and polishing of the
Stayclean surface may occur in time. This
does not affect the Stayclean properties in
any way.
l
A good time to allow the oven to run on is after
the weekly roast. After removing the roast, turn
the oven up to 220°C and allow to run for an hour
or so. It is important NOT to allow a build-up of
soilage as this can prevent the Stayclean from
working.
REPLACING THE OVEN LIGHT BULB
(MODEL SB423 ONLY)
The type of bulb required is a 300C 25 watt small Edison
Screw. Part number 572 491 5431-00/1 (Available through
Tricity Bendix service centres).
CAUTION: Disconnect the appliance from the
electricity supply before replacing the bulb.
Open the door and remove the shelves to enable
easy access to the oven light assembly. Insert a flat
blade screwdriver between the oven side and the
glass which covers the bulb.
Support the glass with your hand and prise out
sufficiently to release the glass cover. Unscrew the
bulb in a anticlockwise direction until it is possible to
remove the bulb with ease.
Fit the new bulb by turning in a clockwise direction
until it is secure. Ensuring the indent to the flange is
pointing to the rear of the oven, replace the glass by
pushing it firmly into the hole to cover the bulb
assembly.
Replace the shelves. Restore the electricity supply
and adjust the time of day and clock, as necessary.
2424
Page 25
SOMETHING NOT WORKING?
We strongly recommend that you carry out the
following checks on your appliance before calling a
Service Engineer. It may be that the problem is a
simple one, which you can solve yourself without the
expense of a service call.
If our Service Engineer finds that the problem is
listed below you will be charged for the call whether
or not the appliance is under guarantee.
The cooker does not work at all:
* Check that the appliance has been wired in
and is switched on at the wall.
* Check that the main cooker fuse is working.
* Check that the timer is set to manual (see
page 11).
The oven is not cooking evenly or the side
opening door will not stay open:
* Check that the cooker is level.
The oven fan is noisy:
* Check that bakeware is not vibrating in
contact with the back panel.
* Check that the oven is level.
The oven light fails to illuminate:
(model SB423 only)
* Check that the cooker is not set for
automatic cooking. The light will illuminate
when the cook time begins.
The grill and hotplates work but the oven does
not:
* Check that the timer is set to manual
operation (see page 11).
The oven temperature is too high or low:
* Check that the recommended temperatures
are being used (see page 20). Be prepared
to adjust up or down by 10°C to achieve the
results you want.
The hotplates and oven work but the grill does
not:
* Check that you have carefully followed the
instructions for operation of the grill.
* If you have had your cooker for several
months you may need to replace the light
bulb (see page 24).
25
Page 26
SERVICE AND SPARE PARTS
HELP US TO HELP YOU
Please determine your type of enquiry before writing or telephoning.
SERVICE
It is a recommendation by the manufacturer that annual servicing of the product is done by the manufacturers
approved service organisation.
In the event of your appliance requiring service, or if you wish to purchase spare parts please contact your local
Tricity Bendix Service Force Centre by telephoning:
08705 929929
The address of your local Service Force Centre is detailed on the following pages headed Tricity Bendix
Service Force.
Before calling out an engineer, please ensure you have read the details under the heading 'Something Not
Working?' and have the model number and purchase date to hand.
Please note that all enquiries concerning service should be addressed to your local Service Centre.
CUSTOMER CARE DEPARTMENT
For general enquiries concerning your Tricity Bendix cooker or for further information on Tricity Bendix
products, you are invited to contact our Customer Care Department by letter or telephone as follows:
Customer Care Department
Tricity Bendix
PO Box 47
Newbury
Berkshire
RG14 5XL
Tel: (01635) 525542
26
Page 27
TRICITY BENDIX SERVICE FORCE
To contact your local Tricity Bendix Service Centre telephone 08705 929929
CHANNEL ISLANDS
GUERNSEY Guernsey Electricity
JERSEY Jersey Electricity
PO Box 4
Vale , Guernsey
Channel Islands
Company
PO Box 45
Queens Road
St Helier
Jersey
Channel Islands
JE4 8NY
SCOTLAND
ABERDEEN
(M05)
AUCHTERMUCHY
(M03)
BLANTYRE
(M07)
DUMFRIES
(M01)
DUNOON
(M67)
GLASGOW
(M04)
INVERNESS
(M06)
ISLE OF ARRAN
(OWN SALES)
ISLE OF BARRA
(OWN SALES)
ISLE OF BUTE
(M66)
ISLE OF LEWIS
(M69)
KELSO
(M08)
8 Cornhill Arcade
Cornhill Drive
Aberdeen
AB2 5UT
33A Burnside
Auchtermuchy
Fife
KY14 7AJ
Unit 5
Block 2
Auchenraith Ind Estate
Rosendale Way
Blantyre
G72 0NJ
93 Irish Street
Dumfries
Scotland
DG1 2PQ
Briar Hill
7 Hill Street,
Dunoon
Argyll
PA23 7AL
20 Cunningham Road
Clyde Estate
Rutherglen,
Glasgow,
G73 1PP
Unit 3B
Smithton Indust. Est.
Smithton
Inverness
IV1 AJ
Arran Domestics
Unit 4 The Douglas
Centre
Brodick
Isle of Arran
KA27 8AJ
J Zerfah
244 Bruernish
Isle of Barra
Western Islands
HS9 5QY
Walker Engineering
Glenmhor
Upper Serpentine Road
Rothesay
Isle of Bute
PA20 9EH
ND Macleod
16 James Street
Stornoway
Isle of Lewis PA87 2QW
2-8 Wood Market
Kelso
Borders TD5 7AX
ORKNEY
(M65)
SHETLAND
(OWN SALES)
SHETLAND
(OWN SALES)
WHALSAY
(OWN SALES)
NORTHERN IRELAND
BELFAST
(M27)
WALES
CARDIFF
(M28)
CLYWD
(M14)
DYFED
(M77)
HAVERFORDWEST
(M75)
OSWESTRY
(M17)
Corsie Domestics
7 King Street
Kirkwall
Orkney KW15
Tait Electronic Systems
Ltd.
Holmsgarth Road
Lerwick
Shetland ZE1 0PW
Bolts Shetland Ltd
26 North Road
Lerwick
Shetland ZE1 0PE
Leask Electrical
Harlsdale
Symbister, Whalsay
Shetland ZE2 9AA
Owenmore House
Kilwee Industrial Estate
Upper Dunmury Lane
Belfast
BT17 0HD
Guardian Industrial
Estate
Clydesmuir Road
Tremorfa, Cardiff
CF2 2QS
Unit 6-7 Coed - Parc
Abergele Road
Rhuddlan
Clwyd
Wales
LL18 5UG
Maes Y Coen
High Mead
Llanybydder
Dyfed
SA40 9UL
Cromlech Lodge
Amerlston
Haverfordwest
SA62 5DS
Plas Ffynnon
Warehouse
Middleton Road
Oswestry
SY11 2PP
NORTH EAST
GATESHEAD
(M39)
GRIMSBY
(M42)
HULL
(M41)
LEEDS
(M37)
NEWTON AYCLIFFE
(M45)
SHEFFIELD
(M38)
NORTH WEST
BIRKENHEAD
(M11)
CARLISLE
(M10)
ISLE OF MAN
(M64)
LIVERPOOL
(M15)
MANCHESTER
(M09)
PRESTON
(M13)
STOCKPORT
(M16)
Unit 356a
Dukesway Court
Dukesway
Team Valley
Gateshead
NE11 0BH
Unit 2
Cromwell Road
Grimsby
South Humberside
DN31 2BN
Unit 1
Boulevard Industrial
Estate
Hull
HU3 4AY
64-66 Cross Gates Road
Leeds
LS15 7NN
Unit 16
Gurney Way
Aycliffe Ind Estate
Newton Aycliffe
DL5 6UJ
Pennine House
Roman Ridge Ind.
Roman Ridge Road
Sheffield
S9 1GB
1 Kelvin Park
Dock Road
Birkenhead
L41 1LT
Unit 8
South John Street
Carlisle
CA2 5AJ
South Quay Ind Estate
Douglas
Isle of Man
Unit 1
Honeys Green Precinct
Honeys Green Lane
Liverpool
L12 9JH
Unit 30, Oakhill Trading
Estate
Devonshire Road
Worsley
Manchester
M28 3PT
Unit 250
Dawson Place
Walton Summit
Bamber Bridge
Preston
Lancashire
PR5 8AL
Unit 20 Haigh Park
Haigh Avenue
Stockport
SK4 1QR
27
Page 28
TRICITY BENDIX SERVICE FORCE
To contact your local Tricity Bendix Service Centre telephone 08705 929929
MIDLANDS
BIRMINGHAM
(M18)
BOURNE
(M44)
BRIDGNORTH
(M72)
GLOUCESTER
(M23)
HEREFORD
(M31)
HIGHAM FERRERS
(M51)
ILKESTON
(M43)
LEICESTER
(M22)
LINCOLN
(M40)
NEWCASTLE UNDER
LYME
(M12)
NUNEATON
(M21)
REDDITCH
(M20)
TAMWORTH
(M19)
WORCESTER
(M73)
66 Birch Road East,
Wyrley Road Industrial
Estate
Witton
Birmingham
B6 7DB
Manning Road Ind Estate
Pinfold Road
Bourne
PE10 9HT
1 Underhill Street
Bridgnorth
Salop
WV16 4BB
101 Rycroft Street
Gloucester
GL1 4NB
Unit 3
Bank Buildings
Cattle Market
Hereford
HE4 9HX
30 High Street
Higham Ferrers
Northants
NN10 8BB
Unit 2
Furnace Road
Ilkeston
DE7 5EP
Unit 7 Oaks Industrial
Estate
Coventry Road
Narborough
Leicestershire
LE9 5GF
Unit 8 Stonefield Park
Clifton Street
Lincoln
LN5 8AA
18-21 Croft Road
Brampton Industrial
Estate
Newcastle under Lyme
Staffordshire
ST5 0TW
19 Ptarmigan Place
Townsend Drive
Nuneaton
CV11 6RX
13 Thornhill Road
North Moons Moat
Redditch
Worcestershire
B98 9ND
Unit 3
Sterling Park
Claymore
Tamworth
B77 5DO
Unit 1
Northbrook Close
Gregorys Mill Ind Estate
Worcester
WR3 8BP
LONDON & EAST ANGLIA
CHELMSFORD
(M47)
COLINDALE
(M53)
ENFIELD
(M49)
GRAVESEND
(M57)
HARPENDEN
(M46)
LETCHWORTH
(M50)
MAIDENHEAD
(M60)
MOLESEY
(M61)
NEWBURY
(M24)
IPSWICH
(M48)
NORWICH
(M52)
SUNBURY
(M63)
SYDENHAM
(M62)
WEST DRAYTON
(M76)
Hanbury Road
Widford Ind Estate
Chelmsford
Essex
CM12 3AE
Unit 14
Capitol Park
Capitol Way
Colindale
London NW9 0EQ
284 Alma Road
Enfield
London
EN3 7BB
Unit B4,
Imperial Business Estate
Gravesend
Kent
DA11 0DL
Unit 4
Riverside Estate
Coldharbour Lane
Harpenden
AL5 4UN
16-17 Woodside Ind Est.
Works Road
Letchworth
Herts
SG6 1LA
Reform Road
Maidenhead
Berkshire
SL6 8BY
10 Island Farm Avenue
West Molesey
Surrey
KT8 2UZ
PO Box 5627
Newbury
Berkshire
RG14 5GF
Unit 2B
Elton Park Business
Centre
Hadleigh Road
Ipswich
IP2 0DD
2b Trafalgar Street
Norwich
NR1 3HN
Unit 1a
The Summit
Hanworth Road
Hanworth Ind Estate
Sunbury on Thames
TW16 5D
Unit 6
Metro Centre
Kangley Bridge Road
Sydenham
SE26
2 / 4 Royal Lane
Yiewsley
West Drayton
Middlesex
UB7 8DL
SOUTH EAST
ASHFORD
(M58)
FLEET
(M59)
HAYWARDS HEATH
(M55)
TONBRIDGE
(M56)
SOUTH WEST
BARNSTAPLE
(M30)
BOURNEMOUTH
(M26)
BRIDGEWATER
(M35)
BRISTOL
(M25)
EMSWORTH
(M33)
ISLE OF WIGHT
(M34)
NEWTON ABBOT
(M29)
PLYMOUTH
(M32))
REDRUTH
(M36)
Unit 2
Bridge Road Business
Bridge Road
Ashford
Kent
TN2 1BB
Unit 1
Redfields Industrial
Estate
Church Crookham
Fleet
Hampshire
GU13 0RD
21-25 Bridge Road
Haywards Heath
Sussex
RH16 1UA
Unit 30 Deacon Trading
Estate
Morley Road
Tonbridge
Kent
TN9 1RA
P.O. Box 12
Barnstaple
North Devon
EX31 2YB
63-65 Curzon Road
Bournemouth
Dorset
BH1 4PW
6 Hamp Industrial Estate
Bridgewater
Somerset
TA6 3NT
11 Eldon Way
Eldonwall Trading
Bristol
Avon
BS4 3QQ
266 Main Road
Southbourne
Emsworth
PO10 8JL
Unit 8
Enterprise Court
Ryde Business Park
Ryde
Isle of Wight
PO33 1DB
Unit 2 Zealley Industrial
Estate
Kingsteignton
Newton Abbot
S. Devon
TQ12 3TD
16 Faraday Mill
Cattledown
Plymouth
PL4 0ST
Unit 7D
Pool Industrial Estate
Wilson Way, Redruth,
Cornwall
TR15 3QW
Estate
28
Page 29
GUARANTEE CONDITIONS
Standard guarantee conditions
We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or
any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option
repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:
l
The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
l
The appliance has been used for normal domestic purposes only, and in accordance with the manufacturer's
instructions.
l
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any person not
authorised by us.
l
All service work under this guarantee must be undertaken by a Tricity Bendix service centre.
l
Any appliance or defective part replaced shall become the Company's property.
l
This guarantee is in addition to your statutory and other legal rights.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these hours
in which case a premium will be charged.
Exclusions
This guarantee does not cover:
l
Damage or calls resulting from transportation, improper use or neglect, the replacement of any light bulbs or
removable parts of glass or plastic.
l
Costs incurred for calls to put right an appliance which is improperly installed or calls to appliances outside the
United Kingdom.
l
Appliances found to be in use within a commercial environment, plus those which are subject to rental
agreements.
l
Products of Tricity Bendix manufacture which are not marketed by Tricity Bendix.
European Guarantee
If you should move to another country within Europe then your guarantee moves with you to your new home
subject to the following qualifications:
l
The guarantee starts from the date you first purchased your product.
l
The guarantee is for the same period and to the same extent for labour and parts as exists in the new country
of use for this brand or range of products.
l
This guarantee relates to you and cannot be transferred to another user.
l
Your new home is within the European Community (EC) or European Free Trade Area.
l
The product is installed and used in accordance with our instructions and is only used domestically, i.e. a
normal household.
l
The product is installed taking into account regulations in your new country.
Before you move please contact your nearest Customer Care centre, listed below, to give them details of your new
home. They will then ensure that the local Service Organisation is aware of your move and able to look after you
and your appliances.
France Senlis +33 (0)3 44 62 28 28
Germany Nürnberg +49 (0)911 323 2600
Italy Pordenone +39 (0)1678 47053
Sweden Stockholm +46 (0)20 78 77 50
UK Newbury +44 (0)1635 525 542
29
Page 30
SB 422/423- 311313704
Page 31
Page 32
RATING PLATE REFERENCE
MAKE AND MODEL NO. PRODUCT NO. SERIAL NO. DATE OF PURCHASE
IMPORTANT NOTICE
In line with our continuing policy of research and development, we reserve the right to alter models and
specifications without prior notice.
This handbook is accurate at the date of printing, but will be superseded and should be disregarded if
specifications or appearance are changed.
TRICITY BENDIX,PO BOX 47,NEWBURY,BERKSHIRE, RG14 5XL
TELEPHONE (01635) 525542
.
MODEL NO. PART NO.
SB 422/423
4
.
311313704
Loading...
