TRICITY BENDIX
Better Products. Better Value.
Operating and Installation Instructions
Model No.
CAW1210
CONTENTS
TECHNICAL SPECIFICATIONS
DIMENSIONS Height 85 cm (33.5”)
Width 60 cm (23.6”) Depth 57 cm (22.4”)
POWER SUPPLY VOLTAGE 220-240 V/50 Hz TOTAL POWER ABSORBED 2550 W (13A)
WATER PRESSURE Minimum (hot) 005 psi (3.5 N/cm2)
Minimum (cold) 007 psi (4.8 N/cm2) Maximum 110 psi (76 N/cm2)
MAXIMUM RECOMMENDED Cotton, linen 4.5 kg (10 lb) LOAD Synthetics, delicate fabrics 2 kg (4.5 lb)
Wool 1 kg (2.2 lb)
SPIN SPEED Maximum 1200 rpm
This appliance complies with the following E.E.C. Directives:
- 73/23 EEC of 19.2.73 (Low Voltage Directive) and subsequent modifications;
- 89/336 EEC of 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.
2
IMPORTANT INFORMATION
It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is sup­plied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings.
These warnings have been provided in the interest of safety. You MUST read them carefully before installing or using the appliance.
INSTALLATION
■
This appliance is heavy. Care should be taken when moving it.
■
All packing and transit bolts must be removed before use. Serious damage can occur to the product and to property if this is not adhered to. See relevant section in instructions.
■
Any plumbing work required to install this appliance should be carried out by a qualified plumber or com­petent person.
■
Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
■
Care must be taken to ensure that the appliance does not stand on the electrical supply cable.
■
If the machine is situated on a carpeted floor, please adjust the feet in order to allow air to circulate freely.
USE
■
Always unplug the appliance and turn off the water after use.
■
Do not overload the appliance. See relevant section in instruction book.
■
Only wash fabrics which are designed to be machine washed. If in doubt, consult the care label on the clothes.
■
Before washing, ensure that all pockets are empty and buttons and zips are fastened. Avoid washing frayed or torn articles and treat stains such as paint, ink, rust, and grass before washing. Underwired bras must NOT be machine washed.
■
Any objects such as coins, safety pins, nails, screws, stones or any other hard, sharp material can cause extensive damage and must not be placed into the machine.
■
Garments which have been in contact with volatile petroleum products should not be machine washed. If volatile cleaning fluids are used, care should be taken to ensure that the fluid is removed from the garment before placing in the machine.
■
Wash small items such as socks, laces, washable belts etc in a washing bag or pillow case as it is pos­sible for such items to slip down between the tub and the inner drum.
■
Only use the advised quantities of fabric softener. Damage to the fabric can ensue if you over-fill. Refer to the manufacturer’s recommendations of quantities.
■
As some duvets and eiderdowns should be washed in large commercial machines because of their bulk, please check with the manufacturer of the item be­fore washing in a domestic machine.
■
The users should always check that they have not left their gas lighters (disposable or otherwise) in their clothing.
■
Leave the porthole door slightly ajar between washes to preserve the door seal.
SERVICE/REPAIR
■
Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexpe­rienced persons may cause injury or serious malfunc­tioning. Contact your local Tricity Bendix Service Centre. Always insist on genuine Tricity Bendix spare parts.
GENERAL SAFETY
■
It is dangerous to alter the specifications or attempt to modify this product in any way.
■
This appliance is designed to be operated by adults. Children should not be allowed to tamper with the controls or play with the product.
■
Pets and children have been known to climb into washing machines. Please check your drum before use.
■
The glass door becomes very hot during the washing cycle. Keep children away from the vicinity of the appliance whilst it is in operation.
■
When disposing of your old washing machine, the electric cable must be cut off and the door catch must be made unusable.
3
INSTALLATION
Unpacking
Before starting the machine up, the packing must be removed as follows.
You are advised to keep all the packaging for re-use in case the machine is to be transported again.
Using a spanner unscrew and remove the rear right bolt. Lay the machine gently on its back, making sure that the hoses are not squashed.
P0255
2
1
P0234
P0233
Positioning
Your new washing machine has been designed to be permanently plumbed in to your home’s water supply and drainage system. However, if this is not possible, it may be connected to suitable existing taps with the drain hose discharging into a sink.
The appliance has two inlet hoses, hot and cold, with female 3/4” BSP thread connectors. If this connection is not compatible with the plumbing of the existing installa­tion, a variety of connectors are available from good hardware stores and plumbers merchants to suit most domestic plumbing. Any alteration to your existing plum­bing must be carried out by a competent person, or qua­lified plumber.
Water inlet
The inlets on the back of the appliance are colour coded, blue for cold and red for hot.
Before connecting the hoses be sure to fit the mesh filters supplied as per diagram.
Remove the polystyrene block from the bottom of the machine.
Carefully slide out the right polythene bag (1), removing it toward the centre of the machine.
Repeat the operation for the left polythene bag (2), removing it toward the centre of the machine.
Remove the polystyrene base, set the machine upright and unscrew the two remaining rear bolts.
P0256
P0001
P0002
Slide out the 3 plastic spacers and plug the 3 holes with the 3 plastic plugs which you can find at the back of the machine.
P0003
If only a cold water supply is available, connect the two hoses to a cold water outlet by means of a «Y» connec­tion piece.
Installation should comply with local water authority and building regulations’ requirements.
The appliance must be given a separate cold water sup­ply and not be connected to a mixer tap, a single outlet water heater or a booster pump. A minimum water pres­sure of 7 psi is required for safe operation of the appli­ance.
If you cannot make the cold water connection direct from the rising mains, you may be able to operate the appli­ance from your cold water storage system.
1
There should be a minimum distance of 5.02m (16
/
ft)
2
between the appliance’s inlet and the bottom of the tank. There will be sufficient pressure for the hot water supply
from the hot water cylinder if the height between the appliance’s inlet and the bottom of the cold water stor­age cistern (not between the appliance and hot water cylinder) is at least 2.74m (9ft).
Set the hoses correctly by loosening the ring nuts. After positioning the inlet hoses, be sure to tighten the ring nuts again to pre­vent leaks.
P0021
4
Water drainage
If you intend the drain hose from the machine to empty into a sink, make sure that the sink is empty and that the plug hole is not blocked.
If the machine is permanently plumbed in, hook the end of the hose into a standpipe installed for the purpose. The standpipe must have an internal diameter of at least 40 mm (1 1/2") in order that there is an air gap between the drain hose and the standpipe. Make sure, that it is designed in such a way, that the end of the drain hose cannot be covered with water.
3 pin
40 mm inside dia min
600 mm min
P0376
Important
Before connecting up the machine to new pipework or to pipework that has not been used for some time, run off a reasonable amount of water to flush out any debris that may have collected in the pipes.
Whether discharging into a sink or a standpipe check that the end of the drain hose is neither too high nor too low. The top of the curve in the hose’s end should be no more than 90 cm (35.4”), and no less than 60cm (23.6”) above floor level.
900 mm max
Warning
The machine should NOT be placed on deep pile car­peting.
Note
Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of a break­down.
All plumbing and electrical work required to install this appliance must be carried out by competent persons or qualified plumbers or electricians.
In the interest of the environment
Washing machines and dishwashers should be connec­ted to the FOUL drainage system, the water will then be taken to a sewage works for treatment before being discharged safely into a river. It is essential that these appliances are not connected to the surface water drainage system as this water is discharged directly into a river or stream and may cause pollution. If you require any further advice please contact your local authority drainage department.
Levelling
Level the washing ma­chine by raising or low­ering the feet. The feet may be tight to adjust as they incorporate a self locking nut, but the machi­ne MUST be level. Any necessary adjustment
P0850
prevents vibration, noise and displacement of the ma­chine during operation.
Some vibration is inevitable, especially if mounted on a wooden floor.
Sprung wooden floors are particularly susceptible to vibration. For advice, consult a builder. If possible, always place the machine on a solid floor.
Special conditions
If the floor is carpeted with a deep-pile carpet or covered with crumbly or soft material, insert a rigid support base under the feet to prevent noise, vibration or displace­ment. The base should protrude a few centimetres beyond the edges of the machine.
can be made with a span­ner. Accurate levelling
P0987
RAINWATER
'RUN-OFF'
SURFACE WA TER
DRAINS & SEWERS
UNTREATED DISCHARGE
RIVER
SHOWER
BATH
WASHING MACHINE
SINK TOILET
DISHWASHER
BIDET
FOUL DRAIN
FOUL SEWERS
SEWAGE
TREATMENT
WORKS
TREATED
DISCHARGE
RIVER
5
Electrical connections
WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this
safety measure not be observed.
If the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appro­priate plug fitted.
Remove the fuse from the cut off plug. The cut off plug should then be disposed of to prevent the hazard of shocks in case it should be plugged into a 13 Amp socket in another part of your home.
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Green and Yellow - Earth Blue - Neutral Brown - Live If you fit your own plug, the colours of the wires in the
mains lead of your appliance may not correspond with the markings identifying the terminals in your plug, pro­ceed as follows:
GREEN & YELLOW
BLUE
P0329
13 AMP FUSE
13 AMP
BROWN
CORD CLAMP
Connect the green and yellow (earth) wire to the terminal in the plug which is marked with the letter «E» or the earth symbol or coloured green and yellow.
Connect the blue (neutral) wire to the terminal in the plug which is marked with the letter «N» or coloured black.
Connect the brown (live) wire to the terminal in the plug which is marked with the letter «L» or coloured red.
The plug moulded on to the lead incorporates a fuse. For replacement, use a 13 Amp BS1362 fuse. Only ASTA or BSI approved fuses should be used.
The plug must not be used if the fuse cover/carrier is lost. The cover/carrier is indicated by the coloured insert at the base of the plug.
A replacement cover/carrier must be obtained from your local Tricity Bendix Service Centre. There is a list of these at the end of this instruction book.
6
GETTING TO KNOW YOUR MACHINE
Control panel
CAW 1210
1234
1 Detergent dispenser drawer
Symbols
Prewash Wash Fabric softener
MAINS
rpm
12OO
HALF LOAD
QUICK WASH
ON
SELECTOR
56
2 Mains-on light
This light illuminates when the machine starts working and goes out when the ON/OFF button is released.
3 ON/OFF button
By depressing this button the machine starts operating. When depressing it again, the machine stops.
C0022
4 Half load button
Select this button to reduce water consumption on the rinse cycle when washing a smaller load of cottons or linens (maximum load size = 2.25 kg).
5 Quick wash button
By depressing this button on programmes 2-3-4 and 6 the wash time will be reduced by approx. 20 mins. This is suitable only for garments which are lightly soiled.
6 Programme selector dial
With the programme selector dial you choose the de­sired washing programme. Turn it clockwise.
Before setting the knob to any position the machine must be switched off by depressing the ON/OFF button.
7
Washing hints
Do NOT overload the machine. Weigh the laundry the first few times you use the appliance.
The average weights of the most common items are listed below as a guide:
1000g = 1 kg
Sheet 700-1000 g Pillow case 100-200 g Tablecloth 400-500 g Serviette 50-100 g Tea towel 70-120 g Linen hand towel 100-150 g Towelling hand towel 150-250 g Towelling bath towel 700-1000 g Bath robe 1000-1500 g Man’s shirt 200-300 g
■
Some stains such as fruit, wine, grass, rust etc. are difficult to remove and should be treated before washing with specific products, which can be found in most household shops. In some cases it may help to soak the stain before washing with a special pre-soak product or biological detergent.
■
Only wool marked «Pure New Wool - washable, pre­shrunk» can be washed in the machine using the wool programme; other types of wool should be washed by hand or dry cleaned.
■
If you have used the machine to wash, rinse or spin only non-colour fast garments, there may be dye left in the sump. To ensure any subsequent wash is not contaminated with the dye, select and carry out a rinse and spin programme, without any garments, to ensure that any dye is removed from the sump.
■
Once you have finished using the machine, you are advised to unplug it and turn off the water taps.
Apron 150-200 g
■
Load the laundry loosely alternating large items with small ones.
■
Sort the laundry according to the type of fabric, colour-fastness and how dirty it is.
■
Avoid washing unhemmed or torn items as they may unravel.
■
Before washing, empty all pockets of small objects which may have been left inside (coins, keys, screws etc). as these could damage the drain pump.
■
When washing curtains, remove the hooks.
■
Close poppers and zips and fasten loose buttons.
■
It is essential to wash new coloured items separately when washing for the first time.
■
When washing fabrics requiring different wash tem­peratures together, always select the lowest tempera­ture.
■
White items should not be washed with coloured items.
■
Very small items (handkerchiefs, ribbons, socks etc) should be washed in a washing bag or a pillow case.
■
Use a good quality detergent suitable for automatic washing machines.
■
Use the correct quantities of detergent.
■
For wool, use gentle detergent only in small quanti­ties.
■
Bleach is very corrosive; it should be used with care and kept out of reach of children.
8
WASH CARE SYMBOLS
Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine.
WASHING SYMBOL
BLEACHING
IRONING
95
60
50
40
40
40
WASH ACTION FABRIC
Normal (Maximum)
Normal (Maximum)
Reduced (Medium)
Normal (Maximum)
Reduced (Medium)
Much Reduced (Minimum)
Hand wash only
Chlorine bleach may be used
White Cotton or Linen without Special Finishes
Cotton, Linen or Viscose without Special Finishes Colourfast at 60°C.
Nylon, Polyester/Cotton, Viscose with Special Finishes, Cotton/Acrylic Mix.
Cotton, Linen or Viscose Colourfast at 40°C but not 60°C.
Acrylics, Acetate, Triacetate, Wool mixes, Polyester/wool blends.
Wool, wool mixtures, Silks
Do not machine wash
DRY CLEANING
P
TUMBLE DRYING
X
IMPORTANT NOTES
Hot iron
Warm iron
Cool iron
May be dry cleaned. Other letters and/or a bar beneath the circle will indicate the required process to the dry cleaner.
May be tumble dried
with high heat setting
with low heat setting
A cross through any symbol means «DO NOT»
Cotten, Linen, Viscose
Polyester mixtures, Wool
Acrylic, Nylon, Polyester
For best results, always use the dispenser drawer for dispensing detergents and liquid additives.
Once the dispenser has been filled, close it by pushing it in gently. This is particularly important if you are using fabric conditioner to avoid the conditioner entering the machine prematurely.
When using liquid detergent and a prewash programme, place the detergent into the correct compartment in the dispenser drawer, after the prewash has finished.
9
Programmes for cotton and linen
Recommended load: max. 4.5 kg (10 lb)
Programmes
WHITES
WITH
PREWASH
WHITES
WITHOUT
PREWASH
FAST
COLOUREDS
NON FAST
COLOUREDS
Degree
of soil
Heavy
Normal
Normal
Normal
Compartments
to use ( if
required)
Programme dial position/ Temperature
1
95°
2
95°
3 (•)
60°
4
40°
Description
Prewash at 40°C Wash at 95 °C 4 rinses Spin
Wash at 95 °C 4 rinses Spin
Wash at 60 °C 4 rinses Spin
Wash at 40 °C 4 rinses Spin
SPIN 1200
Water filling: 30°/40°/50° programmes: cold water filling
Water filling: 60° programmes: hot and cold filling Water filling: 95° programmes: hot filling
(•) This 60° programme is the reference programme for the Energy label according to the article 2, paragraph 1 of the EEC Directive 92/75.
5
Spin at 1200 rpm
10
Programmes for synthetics, delicates and wool
Recommended load: max. 2 kg (4.5 lb); wool max. 1 kg (2.2 lb)
Programmes
MIXED
FABRICS
SYNTHETICS Normal
RINSES
SOFTENERS
DELICATE
WASH
Degree
of soil
Normal
Normal
Compartments
to use ( if
required)
Programme dial position/ Temperature
6
50°
7
40°
8
9
10
40°
Description
Wash at 50 °C 3 rinses Stop with water left in the tub
Wash at 40 °C 3 rinses Stop with water left in the tub
3 rinses, with fabric softener, if required Stop with water left in the tub
1 rinse, with fabric softener, if required Stop with water left in the tub
Wash at 40 °C 3 rinses Stop with water left in the tub
WOOL WASH
Normal
11
40°
12
QUICK & COOL
WASH
SPIN 650
DRAIN
Important! At the end of the last rinse, the washing machine stops without draining the water so that the garments do not crease. To drain the water, select programme 13 (short spin) or 14 (draining).
Light
30°
13
14
Wash at 40 °C 3 rinses Stop with water left in the tub
Wash at 30 °C 3 rinses Stop with water left in the tub
Draining of water and short spin at 650 rpm
Draining of water
11
WHICH DETERGENT TO USE?....
For most clothes and household textiles, CONVENTIONAL DETERGENTS will give good washing results. Conventional detergents are available in either a biological, such as Ariel, or a non-biological form, such as Fairy, and are particularly suitable for whites. Biological detergents provide improved stain removal, especially at lower temperatures.
For coloured clothes and household textiles, you should use COLOUR DETERGENTS, like Ariel Color, which are designed to maintain the original colour of these items, as well as providing excellent cleaning perform­ance. These are all biological detergents. They are par­ticularly suitable for matching and co-ordinated sets of lingerie, bedding or towels.
AND IN WHICH FORM?
Not only are there different types of detergent, but they are also available in different forms.
POWDERS OR LIQUIDS
Powders and their liquid equivalent provide similar clean­ing properties, although liquids dissolve faster when hand washing and at lower temperature washes.
BIOLOGICAL OR NON-BIOLOGICAL
All Biological detergents contain enzymes. Different types of enzymes assist with the removal of protein, starch and fat-based stains, such as blood, egg, chocolate and gravy. However, some people prefer non­biological detergents which do not contain enzymes.
LOW SUDS
In a front loading automatic washing machine, you should only use a low suds detergent. The majority of detergents are now low suds products.
For washing wool and silk, COLOUR DETERGENTS ARE NOT SUITABLE. For wool items, you should use a GENTLE/FINE WASH DETERGENT, such as Dreft, which has been tested and approved by the International Wool Secretariat and car­ries the ‘Woolmark’. A similar detergent should also be used for silk.
To maintain the appearance of your clothes and house­hold textiles and to make them last longer, you should use different types of detergent for different washes, whether for whites, colours or delicates. Although this may require buying two or three different products, you do not need to use any more powder, or liquid, than if you were buying just one.
«BIG BOX» OR COMPACT
Compared to their traditional «Big Box»equivalents, compacts (or concentrates as they are also known) have an improved performance and environmental profile, as well as requiring a smaller dosage level.
FABRIC CONDITIONERS
These are ideal for improving ‘softness’. They also re­duce static cling on synthetics and make ironing easier. Fabric Conditioners come in three forms:
Liquids (regular or concentrated) which work in the final rinse.
Sheets for use in the tumble dryer, and Combined Detergent and Fabric Softener
USE OF DETERGENT AND ADDITIVES
Choosing the Right Detergent
Always use a low lather powder or liquid. This is impor­tant as too much lather prevents the articles from being properly cleansed and may damage the machine.
Use of Powder Detergent
The washing powder should be placed in the appropriate compartments in the detergent dispenser drawer before starting the programme.
Use of Liquid Detergent
A liquid detergent can be used in the middle compart­ment of the dispenser drawer. Start the machine imme­diately upon placing the liquid in the dispenser drawer.
12
Use of Fabric Conditioners
Any liquid additives for softening or dressing the laundry must be poured into the appropriate compartment of the detergent dispenser drawer before starting the program­me.
The compartment with the symbol is for softeners and dressing agents; never exceed the MAX. Ievel.
When using super concentrated fabric conditioners, please follow the manufacturer’s instructions carefully.
USING YOUR MACHINE
WASHING 4.5 KG OF WHITE COTTON AT 95°C
Suppose you have 4.5 kg of normally dirty laundry to wash. It is white cotton and is suitable for high tempera­ture washing.
1 Load the laundry
Open the door by pulling the catch outward. Load the items one at a time and close the door.
P0004
2 Measure out the detergent
5 Select the required wash programme
Turn the programme selector dial clockwise to
2
P1006
the required programme.
6 Start the machine
Before starting up the machine check that:
■
the appliance is plugged in
■
the water supply taps are turned on
■
the drain hose is correctly and securely positioned
■
the door and the detergent dispenser drawer are closed.
Depress the ON/OFF but­ton: the mains-on light illu-
MAINS
ON
minates and the machine starts operating.
C0022
C0021
Pull out the detergent dispenser drawer from the control panel. Measure out the amount of detergent required and pour into the main wash compartment.
If you wish to carry out a programme with prewash, pour the amount of detergent required into the «prewash» compartment.
3 Add the fabric softener if required
Pour the fabric softener, if required, into the compart­ment marked .
Do not exceed the MAX level and then close the drawer gently.
C0020
4 Select the required options
Depress Half load and/or Quick wash, if desired.
T0006
7 At the end of the programme
The machine stops automatically. The door is controlled by a safety device which releases
2 minutes after the end of the programme. Switch the machine off by depressing the ON/OFF but-
ton again. The mains-on light goes out. When the programme has finished you are advised to
unplug the appliance and turn off the water taps.
13
WASHING 2 KG OF SYNTHETIC FABRICS AT 40°C
Suppose you have 2 kg of synthetic fabric laundry to wash. They are rather delicate fabrics and should not be washed at a high temperature.
1 Load the laundry
Open the door by pulling the catch outward.
Load the items one at a time and close the door.
P0004
2 Measure out the detergent
4 Select the required wash programme
Turn the programme selector dial clockwise to
7
M0018
the required programme.
5 Start the machine
Before starting up the machine check that:
■
the appliance is plugged in
■
the water supply taps are turned on
■
the drain hose is correctly and securely positioned
■
the door and the detergent dispenser drawer are closed.
Depress the ON/OFF but­ton: the mains-on light illu-
MAINS
ON
minates and the machine starts operating.
C0022
C0021
Pull out the detergent dispenser drawer from the control panel. Measure out the amount of detergent required and pour into the main wash compartment.
3 Add the fabric softener if required
Pour the fabric softener, if required, into the compart­ment marked .
Do not exceed the MAX level and then close the drawer gently.
C0020
T0006
6 At the end of the programme
The machine will stop after the last rinse with the water left in the wash tub, to prevent the fabric from creasing. To drain the water select programme 13 or 13.
The door is controlled by a safety device which releases 2 minutes after the end of the programme.
Switch the machine off by depressing the ON/OFF but­ton again. The mains-on light goes out.
When the programme has finished you are advised to unplug the appliance and turn off the water taps.
14
MAINTENANCE AND CLEANING
Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply.
Descaling
The water we normally use contains lime. It is a good idea to periodically use a water softening powder in the machine. Do this separately from any laundry washing, and according to the softening powder manufacturer's instructions. This will help to prevent the formation of lime deposits.
After each wash
Leave the door open for a while. This helps to prevent mould and stagnant smells forming inside the appliance. Keeping the door open after a wash will also help to pre­serve the door seal.
External cleaning
Clean the exterior cabinet of the appliance with soap and water only, and then dry thoroughly.
Cleaning the dispenser drawer
From time to time the washing powder and additive dispenser drawer should be cleaned.
Remove the drawer by pressing the catch downwards and by pulling it out. Flush it out under a tap, to remove any traces of accumulated powder.
The dangers of freezing
If the machine is exposed to temperatures below 0°C, certain precautions should be taken.
■
Turn off the water taps.
■
Select a wash programme and run for a few sec­onds.
■
Unscrew the inlet hoses.
■
Unhook the drain hose from the rear support and position the end in a bowl. Run the draining program­me for a few seconds.
■
When you intend to start the machine up again, make sure that the room temperature is above 0°C.
C0019
C0018
Cleaning the drawer recess
Having removed the drawer, use a small brush to clean the recess, en­suring that all washing powder residue is re­moved from the upper and lower part of the recess.
Replace the drawer and
P0038
any clothes in the drum.
run the rinse programme for a few minutes without
15
Cleaning the filter
The water drain filter
A clean filter is important for the correct functioning of the machine, and should therefore be cleaned after every wash.
Open the filter door and place a container under­neath to catch any spill­age. If the filter is blocked and the machine is unable to drain you will need to drain the water manually from the machine at this
P0011
standpipe or sink and hold the end of the hose over a bowl on the floor. The water should drain by gravity into the bowl. When the bowl is full, hook the hose back up and empty the bowl. Repeat the procedure until water stops flowing out.
Unscrew and remove the filter.
stage. To do this, unhook the drain hose from the
The water inlet filters
If your water is very hard or contains traces of lime de­posit, the water inlet filters may become clogged.
It is therefore a good idea to clean them from time to time.
Turn off the water taps. Unscrew the water inlet hoses. Remove and clean the filters using a hard bri­stle brush. Replace the fil­ters and tighten up the inlet hoses.
P0041
P0132
P0133
Clean carefully under a fast running tap.
P0040
Warning
When the appliance is in use and depending on the pro­gramme selected there can be hot water in the filter. Never remove the filter during a wash cycle, always wait until the appliance has finished the cycle, and is empty. When replacing the filter, ensure it is securely retight­ened so as to stop leaks and young children being able to remove it.
16
SER VICING
Before contacting your local Tricity Bendix Service Centre, please make the following checks:
The machine does not start up
■
The ON/OFF button has not been depressed
■
The door is not closed properly
■
No water is entering the machine (see: the machine does not fill)
■
The selector dial is not correctly positioned
The machine does not fill
■
The water taps are not turned on
■
The water supply has been disconnected
■
The inlet hoses are kinked
■
The water pressure is too low
■
The water inlet filters are clogged
■
The door is not closed properly
The machine empties as it fills
■
The end of the drain hose is too low
■
The end of the drain hose is submerged in water
■
Drain pipe has no vent-hole
If, after the above checks, there is still a fault, call your local Tricity Bendix Service Centre.
Please make sure you give the model and serial number of the appliance.
Rating plate
Mod. ..........
Prod. No. ...........
Ser. No. .........
This information can be found on the rating plate (see picture) or on the guarantee card.
Mod. ..........
Prod. No. ...........
P0042
Ser. No. .........
Original spare parts can be purchased from Tricity Bendix Service Centres.
In-guarantee customers should ensure that the above checks have been made as the engineer will make a charge if the fault is not a mechanical or electrical breakdown.
Please note that proof of purchase is required for any in-guarantee service calls.
The machine does not drain or spin
■
You have selected a gentle wash cycle
■
The drain filter is clogged
■
The drain hose is kinked
■
The drainage system pipes are blocked
■
The drain hose extension is incorrect
■
The wash load is unbalanced: redistribute the clothes inside the drum to allow the machine to spin
The machine leaks or overflows
■
Too much detergent
■
Unsuitable detergent
■
The inlet hose(s) is (are) loose
■
The detergent dispenser drawer or recess is clogged
■
The end of the drain hose is not securely positioned
■
The drainage system pipes are blocked
The machine vibrates or is noisy
■
The internal packing has not been removed
■
The machine is not level
■
The machine is in contact with the wall or furniture
■
The washing load is badly distributed
■
The machine is overloaded
The door does not open
■
The safety device has locked it
■
Water in the tub: the door cannot be opened if water is present in the tub
17
TRICITY BENDIX GUARANTEE CONDITIONS
We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this TRICITY BENDIX applian­ce or any part thereof is proved to be defective by rea­son only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF ANY CHARGE for labour, materials or carriage on condition that:
■
The appliance has been installed correctly and used only on the electricity supply stated on the rating plate.
■
The appliance has been used for normal domestic purposes only, and in accordance with the manufac­turer's operating and maintenance instructions.
■
The appliance has not been serviced, maintained, repaired, taken apart or tampered with, by any per­son not authorised by us.
All service work under this guarantee must be under­taken by a Tricity Bendix service representative or autho­rised agent. Any appliance or defective part replaced shall become our property. This guarantee is in addition to your statutory and other legal rights. Home visits are made between 8.30 am and 5.30 pm Monday to Friday. Visits may be available outside these hours in which case a charge will be made.
Exclusions
This guarantee does not cover:
■
Damage or calls resulting from transportation, impro­per use or neglect, the replacement of any light bulbs or removable parts of glass or plastic, or vacuum cleaner drive belts, brushes or dust bags.
■
Costs incurred for calls to put right an appliance which is improperly installed or calls to appliances outside the United Kingdom.
■
Appliances found to be in use within a commercial environment, plus those which are subject to rental agreements.
■
Products of Tricity Bendix manufacture which are not marketed by Tricity Bendix Ltd.
■
EU Countries. The standard guarantee is applicable but subject to the owner's responsibility and cost to ensure the appliance meets the standards set by the country to which the product is taken.
Proof of purchase may be required. Electrolux Aftersales Service in the country concerned, with whom Tricity Bendix have an arrangement, will be pleased to advise further.
18
Tricity Bendix Service Force
Postcode Cross Reference
Code Telephone Serv.Centre Code Telephone Serv.Centre Code Telephone Serv.Centre
AB 01224-696569 Aberdeen AL 0181-965-9699 Canvey B1-48, 0121-358-7076 Nuneaton 62-79 90-94 B 49,50,60 01527 512919 Redditch 61,80,95-98 BA 0117-9211876 Bristol BB 0161-4777758 Manchester BD 0113-2608511 Leeds BH 01705-667411 South Coast BL 0161-4777758 Manchester BN1-18 01273-694341 Tonbridge BN20-27 BR 0181 -658-9069 Tonbridge BS 0117-9211876 Bristol BT1-30 01232-746591 N/l East BT36-57 BT63-67 BT31-35 01861-510400 N/l West BT60-62 01861-510400 N/l West BT68-82 01861-510400 N/l West BT92-94 01861-510400 N/l West CA 01228-594747 Cumbria CB 0181-965-9699 Canvey CF 01222-460131 Cardiff CH 0151-2541724 Liverpool CM 01268-694144 Canvey CO 01268-694144 Canvey CR 0181-658-9069 Tonbridge CT 01732-357722 Tonbridge CV 01203-354424 Nuneaton CW 0151-2541724 Liverpool DA 01732-357722 Tonbridge DD 01250-876285 Dundee DE 0113-2608511 Leeds DG 01387-265166 Dumfries DH 01325-310400 Northern
0191-493-2025 Northern
DL 01325-301400 Northern
DN1-7,10-12 0113-2608511 Leeds
DN8,9 01472-267978 S.Humberside DN14 01482-585678 Hull DN15-20 01472-267978 S.Humberside DN21 Sub­codes1,2,5 01522-514603 Lincoln DN21 sub­codes 3, 4 01472-267978 S.Hurnberside DN31-40 01472-267978 S.Hurnberside DT 01705-667411 South Coast Dundee 01382-642828 Tayside
gas only Refrigeration
DY 0121-358-7076 Nuneaton E 0181 -443-3464 Canvev EC 0181-443-3464 Canvey EH 0141-647-4381 Glasgow EN 0181-443-3464 Canvey EX1-17 01626-65909
Newton Abbott
EX18 - 23 01271-328826 Barnstaple EX31 - 39 01271-328826 Barnstaple FK 0141-6474381 Glasgow FY 0151-2541724 Liverpool G 0141-647-4381 Glasgow GL 01527 512919 Redditch
GU1-35 01252-24505 Tonbridge Guernsey 01481- 46931 Guernsey Elec HA 0181 -965-9699 Canvey HD 0113-2608511 Leeds HG 0113-2608511 Leeds HP 0181-965-9699 Canvey HR 01432-340334 Hereford HU 01482-585678 Hull HX 0113-2608511 Leeds
HS9
isle of Barra 01871-890206 S. Zerfahs
IG 01268-694144 Canvey IM 01624-687794 Manx Electricity IP 01603-667017 Canvey IV1-39, 01463-792952 Higland 52-56 Appliances IV40-51 01855-821315 Inverness
G Ross
Jersey 01534-505050 Jersey Elec Co KA1-26, 0141-647-4381 Glasgow 28-30 KA27 01773-302909 Arran Domestics KT 0181-658-9069 Tonbridge KW15-17 01856-875457
Refrigeration
Sales & Service
KW1-14 01463-792952 Highland
Appliances
KY 0141-647-4381 Glasgow L 0151-2541724 Liverpool LA 01772-316175 Lancaster LD 01432-340334 Hereford LE 01203-354424 Nuneaton LL 01745-591616 North Wales LN1,2,4-6 01522-514603 Lincoln LN3 sub­codes 4 & 501522-514603 Lincoln LN3 sub­code 6 only LN7,11-13 01472-267978 S Humberside LN8-10 01522-514603 Lincoln LS 0113-2608511 Leeds LU 0181-965-9699 Canvey M 0161-4777758 Manchester ME 01732-357722 Tonbridge MK 0181-965-9699 Canvey ML 0141-647-4381 Glasgow N 0181-443-3464 Canvey NE 0191 -493-2025 Northern NG1-22 & 25 0113-2608511 Leeds NG23, 24 01522-514603 Lincoln NG31-34 01522-514603 Lincoln NN 01203-354424 Nuneaton NP1-4,6, 9-44 01222-460131 Cardiff NP5,7,8 01432-340334 Hereford NR 01603-667017 Canvey NW 0181-443-3464 Canvey OL 0161-4777758 Manchester OX 01527 512919 Redditch
PA1-19, 0141-647-4381 Glasgow 21-23 PA20 01700-504777 D Mc Glashan PA24-61 01369-703161 Argylle PA62-75 01688-302262 B Hogg
Isle of Mull
PA 83-87 01851-705555 Isl. of Lewis PE14-19, 01603-667017 Canvey PE30-38 01603-667017 Canvey PE1-13, 01522-514603 Lincoln PE 20-25 01522-514603 Lincoln PH1-7 0141-647-4381 Glasgow PH8-18 01250-876285 Dundee PH19-26, 01463-792952 Highland 42-44 Appliances PH30-41 01855-821315 INVERNESS
George Ross
PL1-9, 16,19-21 01626-65909 Newton Abbott PL10-15 17,18 PL22-35 01209-314407 Redruth
PO1-22 01705-667411 South Coast PO30-41 01983-872552 Isle of Wight PR 0151-2541724 Liverpool RG 01252-24505 Tonbridge RH 01273-694341 Tonbridge RM 01268-694144 Canvey S 0113-2608511 Leeds SA1-18 01222-460131 Cardiff SA19,20 01222-461972 Cardiff SA21­32 01222-460131 Cardiff SA33-39 01437-710914 Haverfordwest SA40 01222-461972 Cardiff SA41-44 01437-710914
Haverfordwest
SA45-48 01222-461972 Cardiff SA61-73 01437-710914 Haverfordwest SE 0181-658-9069 Tonbridge SG 0181-965-9699 Canvey SHETLAND 01595-692225 Tait Electronics SHETLAND 01595-692855 Bolts SHETLAND 01806-566546
Leask Electrical
SHETLAN 01595 692915 G Robertson SK 0161-4777758 Manchester SL 01252-24505 Tonbridge SM 0181-658-9069 Tonbridge SN 01527 512919 Redditch
SO 01705-667411 South Coast SP 0117-9211876 Bristol SR 0191-493-2025 Northern SS 01268-694144 Canvey ST 0121-358-7076 Nuneaton SW 0181-658-9069 Tonbridge SY1-6 01743-450279 Shrewsbury SY7,18 01432-340334 Hereford SY8-17 01743-450279 Shrewsbury SY19-22 01743-450279 Shrewsbury SY23-25 01222-461972 Cardiff TA 0117-9211876 Bristol TD 01573-224411 Borders TF 01743-450279 Shrewsbury TN 01732-357722 Tonbridge TQ 01626-65909 Newton Abbott TR1-20 01209-314407 Redruth TR21 -25 0117-9211876 South Coast TR26,27 01209-314407 Redruth TS 01325-301400 Northern TW 0181 -658-9069 Tonbridge UB 0181 -965-9699 Canvey W 0181-443-3464 Canvey WA (Not 0151-2541724 Liverpool 14/15) WA14/15 0161-4777758 Manchester WC 0181-443-3464 Canvey WD 0181-965-9699 Canvey WF 0113-2608511 Leeds WN 0151-2541724 Liverpool WR (not 01527 512919 Redditch WR 15) WR 15 01203-354424 Nuneaton WS 0121-358-5051 Nuneaton WV 0121-358-5051 Nuneaton YO1-3 0113-2608511 Leeds YO5-8 0113-2608511 Leeds YO4 01482-585678 Hull YO11-18 01482-585678 Hull YO21, 22 01325-301400 Northern YO25 01482-585678 Hull
19
Tricity Bendix Service Force Addresses
CENTRE
ABERDEEN
ARGYLL
BARNSTAPLE
BORDERS
ADDRESS
Tricity Bendix Service Force Northeast Appliance Service 8 Cornhill Arcade Cornhill Drive Aberdeen AB2 5UT
Tricity Bendix Service Force T.D.C. Refrigeration Briar Hill 7 Hill Street Dunoon Argyll PA 23 7AL
Tricity Bendix Service Force McBain Refrigeration P.O. Box 12 Barnstaple North Devon EX31 2YB
Tricity Bendix Service Force James Stewart & Son 2-8 Wood Market Kelso Borders TD 5 7AX
CENTRE
DUNDEE
GLASGOW
GUERNSEY
HAVERFORDWEST
ADDRESS
Tricity Bendix Service Force I Brogan Domestics 41 Lesley Street Blairgowrie Perthshire PH 10 6AT
Tricity Bendix Service Force 20 Cunningham Road Clyde Estate Rutherglen Glasgow G73 1PP
Guernsey Electricity PO Box 4 Vale Guernsey Channel Island
Tricity Bendix Service Force C Butherway 1 Church Road Roch Haverfordwest Dyfed/Wales SA 62 6AG
BRISTOL
CANVEY
CARDIFF
CUMBRIA
DUMFRIES & GALLOWAY
Tricity Bendix Service Force Unit BE46 PO Box 372 Bristol BS 99 1UD
Tricity Bendix Service Force 2-4 Sandhurst Kings Road Canvey Island SS8 OQY
Tricity Bendix Service Force Guardian Industrial Estate Clydesmuir Road Tremorfa Cardiff CF2 2QS
Tricity Bendix Service Force E.T.B. Services Carlisle Enterprise Centre James Street Carlisle CA2 5AP
Tricity Bendix Service Force Allan Crossan (Service) 93 Irish Street Dumfries Scotland DG1 2PQ
HEREFORD
HULL
INVERNESS
INVERNESS
ISLE OF WIGHT
Tricity Bendix Service Force Domestic Repair Centre
Unit 3 Bank Buildings Cattle Market Hereford HR4 9HX
Tricity Bendix Service Force John Sizer Unit 1, Boulevard Unit Factory Estate Hull HU3 4AY
Tricity Bendix Service Force Highland Appliances Unit 3B3 Smithton Industrial Estate Smithton Inverness IV 1 2PD
Tricity Bendix Service Force George Ross Electrical Forrestry Workshop Inchree Onich Invernesshire PH33 6SE
Tricity Bendix Service Force Wyatts Electrical Service 4 Forelands Road Bembridge Isle of Wight PO35 5XW
DUNDEE (gas only)
20
Tricity Bendix Service Force Tayside Refrigeration 3-7 Blackness Street Dundee DD1 5LR
ISLE OF BARRA
Tricity Bendix Service Force John Zerfahs 244 Bruemish Isle of Barra Western Islands HS9 5QY
Tricity Bendix Service Force Addresses
CENTRE
ISLE OF ARRAN
ISLE OF LEWIS
ISLE OF MAN
ISLE OF MULL
ADDRESS
Tricity Bendix Service Force Arran Domestics Unit 4 The Douglas Centre Brodick Isle of Arran KA27 8AJ
Tricity Bendix Service Force N D Macleod Churchhouse 16 James Street Stornoway Isle of Lewis, PA87 2QW
Tricity Bendix Service Force Manx Electricity Service Workshop North Quay Douglas Isle of Man
Tricity Bendix Service Force B Hogg Braeside Raeric Road Tobermory Isle of Mull PA75 6PU
CENTRE
NEWTON ABBOTT
NORTH WALES
NORTHERN
NORTHERN IRELAND EAST
ADDRESS
Tricity Bendix Service Force South West Domestic Service Unit 2 Zealley Industrial Estate Kingsteignton Newton Abbott South Devon, TQ12 3TD
Tricity Bendix Service Force GMS (Cymru) Unit 2 Coed - Parc Abergele Road Rhuddlan Clwyd, Wales, LL18 5UG
Tricity Bendix Service Force PO Box 40 Preston Road Aycliffe Industrial Estate Newton Aycliffe, Co Durham DL5 6XA
Tricity Bendix Service Force Unit C3 Edenderry Industrial Estate 326 Crumlin Road Belfast, BT14 7EE
JERSEY
LANCASTER
LEEDS
LINCOLN
LIVERPOOL
MANCHESTER
Jersey Electricity Company PO Box 45 Queens Road St Helier Jersey, Channel Islands JE4 8NY
Tricity Bendix Service Force NL Services Unit 333 Ranglet Road Walton Summit Bamber Bridge Preston, Lancashire, PR5 8AR
Tricity Bendix Service Force 64-66 Cross Gates Road Leeds, LS15 7NN
Tricity Bendix Service Force Brian Hudson Unit 8 Stonefield Park Clifton Street Lincoln, LN 5 8AA
Tricity Bendix Service Force Unit 1 Honeys Green Precinct Honeys Green Lane West Derby Liverpool, L12 9JH
Tricity Bendix Service Force Unit 30 Oakhill Trading Estate Devonshire Road Worsley Manchester, M28 3PT
NORTHERN IRELAND WEST
NUNEATON
ORKNEY
REDDITCH
REDRUTH
ROTHESAY
Tricity Bendix Service Force G & O (Armagh) Service Owenmore House Kilwee Business Park Upper Dunmurray Lane Belfast, BT17 0HD
Tricity Bendix Service Force Unit 23-24 Alliance Business Park Townsend Drive Nuneaton Warwickshire, CV11 6RX
Tricity Bendix Service Force Refrigeration Sales and Service Hatson Ind. Estate Kirkwall Orkney KW15 1RE
Tricity Bendix Service Force Heming Road Washford Redditch Worcestershire, B98 ODH
Tricity Bendix Service Force Cornwall Domestic Service Unit 7D Pool Industrial Estate Wilson Way Redruth, Cornwall TR15 3QW
Tricity Bendix Service Force D McGlashan Walker Engineering Glenmhor Upper Serpentine Rothesay, PA20
21
Tricity Bendix Service Force Addresses
CENTRE
SHETLAND
SHETLAND
SHETLAND
SHETLAND
ADDRESS
Tricity Bendix Service Force G. Robertson Ltd. 3/4 Carlton Place Lerwick Shetland ZE1 OED
Tricity Bendix Service Force Tait Electronic Systems Ltd Holmsgarth Road Lerwick Shetland ZE1 OPW
Tricity Bendix Service Force Bolts Shetland Ltd 26 North Road Lerwick Shetland ZE1 OPE
Tricity Bendix Service Force Leask Electrical Harlsdale Symbister Whalsay Shetland ZE2 9AA
SHREWSBURY
SOUTH COAST
SOUTH HUMBERSIDE
TONBRIDGE
Tricity Bendix Service Force BLI Service 6 Harlescott Barn Harlescott Lane Shrewsbury, Shropshire SY1 3SY
Tricity Bendix Service Force Limberline Road Hilsea Portsmouth Hampshire PO3 5JJ
Tricity Bendix Service Forcee John Robinson (Electrical) 81 Pasture Street Grimsby DN32 9EP
Tricity Bendix Service Force Unit 30 Deacon Trading Estate Morley Road Tonbridge Kent TN9 1RA
22
TRICITY BENDIX
124978220
Better Products. Better Value.
Tricity Bendix, 99 Oakley Road, Luton, Beds LU 4 9QQ
Model No.
CAW1210
A DIVISION OF EMACO LIMITED.
REGISTERED IN ENGLAND NO. 176547
Part No.
124978220
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
