Thank you for buying a Tricity Bendix built-in oven. With our 80 years
experience in developing and manufacturing the very best in U.K. cookers,
you can be assured that you have purchased a hard working, reliable, quality
cooker.
In addition Tricity Bendix cookers comply with British Standard safety and
performance requirements. They have been approved by BEAB (British
Electrotechnical Approvals Board) and are covered by a 12 month parts and
labour guarantee.
In order that you get the best from your new Tricity Bendix cooker, the
following instructions have been prepared. PLEASE MAKE SURE YOU READ
THEM CAREFULLY. Particular attention should be paid to cooking times and
temperatures which may differ from your previous cooker.
It is most important that this instruction book should be retained with the
cooker for future reference. Should the cooker be sold, or transferred to
another owner, or should you move house and leave the cooker, always
ensure that the book remains with the cooker so that the new owner can be
acquainted with the functioning of the cooker and the relevant warnings.
Please read the whole instruction book before using the cooker ensuring you
follow the recommendations given.
5
SAFETY
THESE WARNINGS ARE PROVIDED IN
THE INTERESTS OF YOUR SAFETY.
ENSURE THAT YOU UNDERSTAND
THEM ALL BEFORE INSTALLING OR
USING THE COOKER.
PLEASE
READ
CAREFULLY
BEFORE INSTALLATION
This cooker is heavy and care must
be taken when moving it.
Ensure that all packaging, both
inside and outside the cooker has
been removed before the cooker is
used.
Do not try to move the cooker by
pulling the door handles. Refer to
installation instructions.
This cooker is designed to be
operated by adults and children
under supervision. Young children
must not be allowed to tamper with
the controls or play near or with the
cooker.
Caution accessible parts especially
around the grill area may become hot
when the cooker is in use. Children
should be kept away until it has
cooled.
Take great care when heating fats
and oils as they will ignite if they
become too hot.
This cooker has been designed for
cooking edible foodstuffs only, and
mustnot be used for any other
purposes.
Never place plastic or any other
material which may melt in or on the
oven.
Ensure cooking utensils are large
enough to contain foods to prevent
spillages and boil overs.
The cooker must be installed
according to the instructions
supplied. Any electrical installation
work must be undertaken by a
qualified
It is dangerous to alter the
specifications or modify the cooker
in any way.
After installation, please dispose of
the packaging with due regard to
safety and the environment.
electrician/competent person.
DURING OPERATION
Do not use this cooker if it is in
contact with water. Never operate it
with wet hands.
Take care to follow the
recommendations given for tending
the food when grilling. Use the
handle provided in the recommended
way (see page 18).
Do not leave the handle in position
when grilling as it will become hot.
Always use oven gloves to remove
and replace food in the oven.
Similarly always use oven gloves to
remove and replace the grill pan
handle when grilling.
Recommendations given on page 18.
6
Ensure that you support the grill pan
when it is in the withdrawn or partially
withdrawn position.
Ensure that all vents are left
unobstructed to ensure ventilation of
the oven cavity.
You must ensure that the grill
control is in the 'OFF' position when
the timer control has been set for
automatic cooking.
Ensure that the anti-tilt shelves are
put in place correctly. Refer to
instructions on pages 21 and 23.
Never line any part of the cooker
with aluminium foil. Do not allow
heatproof cooking material, e.g.
roasting bags to come into contact
with oven elements.
Do not leave utensils containing
foodstuffs, e.g. fat or oil in or on the
cooker in case it is inadvertently
switched ON.
Cookers and hobs become very hot,
and retain their heat for a long period
of time after use. Children should be
kept well away from the cooker until
it has cooled.
GENERAL
Under no circumstances should
repairs be carried out by
inexperienced persons as this may
cause injury or serious malfunction.
This cooker should be serviced by an
authorised Service Engineer and
only genuine approved spare parts
should be used. Details of servicing
and repair arrangements are
supplied on page 47 of this book.
AFTER USE
Always stand back from the cooker
when opening the oven door to allow
any build up of steam or heat to
release.
Stand clear when opening the drop
down oven door. Do not allow it to
fall open - support it using the door
handle until it is fully open.
Do not place sealed cans or
aerosols inside the oven. They may
explode if they are heated.
Ensure that all control knobs are in
the OFF position when not in use.
For hygiene and safety reasons this
cooker should be kept clean at all
times. A build-up of fats or other
foodstuffs could result in a fire,
especially in the grill pan.
Do not stand on the cooker or on
the open oven door.
Do not hang towels, dishcloths or
clothes from the cooker or its handle.
They are a safety hazard.
Always allow the cooling fan to cool
the cooker down before switching off
at the wall prior to carrying out any
cleaning or maintenance work.
Only clean this cooker in accordance
with the instructions given on page
44.
Your safety is of paramount importance.
Therefore, if you are unsure about any of
the meanings of these WARNINGS
contact the:
Consumer Care Department
Telephone: (01582) 585858
7
INSTALLATION INSTRUCTIONS
THINGS YOU NEED TO KNOW
WARNINGS:
l
This cooker must be installed by a qualified
electrician/competent person. Safety may be
impaired if installation is not carried out in
accordance with these instructions.
l
This cooker must be earthed.
l
Do not remove the screws from the earth tab
extending from the oven mains terminal block
(Fig. 6).
l
Before connecting the cooker make sure that the
voltage of your electricity supply is the same as
that indicated on the rating plate. The rating plate
can be seen by opening the oven door and
looking below the oven door seal.
l
Do not alter the electrical circuitry of this cooker.
THINGS TO NOTE
l
This cooker is designed to be fitted in cabinets of
the recommended dimensions as shown in Fig.
2. If your cabinet interior dimension is between
565-570mm the oven may still be fitted. However
a minor modification to the cabinet will be
required.
a) By connecting the cooker to a cooker point
having a double pole isolating switch with at least
3mm contact separation in all poles and neutral,
and protected with a fuse or miniature circuit
breaker at your mains fuse box.
Subject to Regional Electricity Company
regulations if you wish to connect the oven
and hob to the power supply you may use
one of the following two methods:-
b) By connecting the cooker together with a hob box
directly to a cooker point(s). Having a double
pole isolating switch with at least 3mm contact
separation in all poles and neutral.
c) If you wish to connect an oven and a hob to a
cooker point you can by connecting the oven and
hob separately to the cooker point. Oven and hob
units should be separately connected to a control
panel. See Fig. 1.
l
The dimensions given provide adequate air
circulation around the unit within the cabinet,
ensuring compliance with BS EN60-335.
l
Enquiries regarding the installation of the cooker
point if required should be made to your Regional
Electricity Company to ensure compliance with
their regulations.
l
The cooker point should be within 2m of the
cooker to make it accessible to switch off the
cooker in case of an emergency.
l
To protect the hands wear gloves when lifting the
oven into its housing.
NOTE: HOUSE CIRCUIT
Earth leakage and continuity tests must be carried
out before the cooker is connected to the mains
supply and re-checked after fitting.
GETTING THINGS READY
CHOICE OF ELECTRICAL CONNECTION
l
There are three possible ways to connect your
cooker. In each case the cooker should be
operated using at least 6mm² twin core and earth
PVC insulated multicore cable. Please choose
from the most appropriate after reading the
descriptions:
Fig. 1
NOTE: It is good practice to:
l
Fit an Earth Leakage Circuit Breaker to your
house wiring.
l
Wire your appliance to the latest IEE regulations.
PREPARING CABINET FOR FITTING OVEN
l
Make sure the cabinet is the correct size for the
appliance to be fitted (Ref. Fig. 2).
l
If the size is between 565-570*mm, then the
cabinet should be modified so that at the screw
fixing points the recommended dimension of at
least 560-565mm is maintained. The modification
should ideally be localised to ensure that after
screw fitment the oven is securely fixed into
position.
l
The cabinet must be stable and level by firmly
securing it to the wall or floor. If necessary, make
arrangements to ensure the shelf upon which the
oven will rest is level.
8
RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES)
6
0
0
m
i
n
5
6
0
m
i
n
5
7
0
m
5
5
8
872
a
x
n
i
m
0
5
5
dedne
mm
oce
R0
002
5
Cross section
through
cabinet
978
-
588
5
4
6
7
8
8
showing oven
positioned
5
Fig.2 Built In Installation
540
5
9
HOW TO FINISH UNPACKING
TO REMOVE COVER OF MAINS TERMINAL
l
Place packed cooker next to the cabinet in which
it will be installed.
l
Remove the cooker packing except for bottom
tray which should be left in position until the
cooker is ready to be fitted into its cabinet.
l
Ensure the owner is given these operating
instructions.
TOOLS REQUIRED
The following tools will be needed and its helps to
assemble them before starting to install your oven:
A terminal screwdriver (3mm wide blade)
A pozidrive screwdriver
Pliers
Wirestrippers
Knife
Sidecutters
Adhesive Tape
Tape Measure
From the rear of the cooker, remove mains input
terminal cover to gain access to terminal block.
l
First remove retaining screw with pozidrive
screwdriver. See Fig. 3.
Pozidrive
Screwdriver
Fig.3
l
Prise cover loose using screwdriver in position
(1) then lever off with screwdriver in position (2)
at either side. See Fig. 4.
MAKING THE ELECTRICAL CONNECTIONS
Important: Switch off at mains, miniature
circuit breaker and, if appropriate, remove
fuse before commencing any electrical work.
PREPARING CABLE
We recommend you use a new length of cable to
ensure your safety.
l
Ensure you have the correct length of cable
appropriate to the wiring method you are using.
When fitting new cable allow sufficient cable for
removal of the unit at a later date, should it be
necessary.
l
Score, but do not cut through, around the
sheathing with a knife 100mm (4in) from each
end of the cable and break through to the
encased wires by bending the cable backwards
and forwards to fatigue the sheathing.
l
Carefully score down from each end of the cable
sheathing along the length of the bare earth wire
(if a cut was made along the length of the live
and neutral wires, it might cut into their
sheathing) to the cuts already made.
(2)
Terminal
Fig.4
l
Lift cover and remove screw from cable clamp.
See Fig. 5.
Screwdriver
(1)
Cable
Clamping
Block
l
Carefully prise open the sheathing at each end of
the cable to expose the encased wiring.
10
Fig.5
CONNECTING TO THE MAINS TERMINAL
NOTE: HOUSE CIRCUIT
Warning: This cooker must be earthed.
l
Make connection as shown in Fig. 6 by
proceeding as follows:-
Red or
Brown
Blue or
Black
5mm
Mains
Cable
Earth (Green or
Green/Yellow)
Earth Tab
Fig.6
l
Preform wires to the appropriate shape to suit
fitting into the mains terminal block.
l
Strip inner insulation on wires using wirestrippers.
l
Twist the bared wires using pliers.
l
Cut bared wires 10mm away from the end of the
inner insulation. Where uninsulated Earth wires
are used ensure they are suitably sheathed to
leave 10mm bare wire to fit into the terminal.
Earth leakage and continuity tests must be carried
out before the cooker is connected to the mains
supply and re-checked after fitting.
l
Clamp bare wires into the relevant terminal and
check they are held by tugging each one in turn.
l
Clamp the mains cable securely ensuring 5mm of
the outer insulation is inside the terminal block
and that the wires are not taught but not so slack
as to cause any fouling. See Fig. 6.
l
Place fuse/ miniature circuit breaker in circuit and
switch on at mains.
CONNECTING TO A HOB OR COOKER POINT
Warning: This cooker must be earthed.
l
Either follow in general terms the instructions for
connecting to the terminal block or refer to the
hob suppliers installation instructions.
Feed the cable through the cabinet and
arrange to route the cable away from the
cooker which may become hot.
CHECKING ELECTRICAL CONNECTIONS
l
Confirm the cooker is correctly connected by
switching on and observing the various oven
functions indicators.
l
The electronic timer will flash on and off.
11
FITTING INTO THE CABINET
IMPORTANT: Ensure that the oven is switched
off at the wall before any further work is carried
out.
l
Using a tape measure establish the internal width
of the cabinet. Refer to page 8 if greater than
565mm.
l
Position the cooker in front of the cabinet. See
Fig. 7.
Mains
Fig.7
Cable
Pack Base
g) When the cooker is fully housed, screw the
stability screws (supplied with the cooker) into
the side of the cabinet taking care not to distort
the side trims (see Fig. 8). It is advisable to turn
each screw alternately to avoid damaging the
trims.
h) Switch on the cooker then refer to the operating
instructions in the following pages.
Fixing Points
for
Stability Screws
Fig.8
l
Take out all oven furniture before installation to
reduce the weight you need to lift. The oven door
should be taped up to keep it closed whilst lifting.
l
To place the cooker into the cabinetry follow the
procedure below:
l
N.B. Two people will be required to carry out the
lifting procedure.
a) Each person should squat either side of the
cooker.
b) Tilt the cooker so that your hands can support
the underside of the cooker.
c) Keeping your back straight, raise the appliance to
the cabinet by straightening at the knees.
d) Rest the rear underside of the cooker on the
cabinet floor while your hands support the front.
e) The cooker can be pushed fully into the cabinet.
Take care to avoid fouling the mains lead.
f) Ensure the cooker is central in the cabinet and
level.
12
INTRODUCTION
WARNING: THIS COOKER MUST BE EARTHED
This cooker complies with Radio interference requirements of the EEC Directive 87/308/EEC
GETTING TO KNOW YOUR OVEN (BD 921)
A B C D E F G H
A -Electronic Timer
B -Main Oven Indicator Neon
C -Second Oven Indicator Neon
D -Dual Grill Indicator Neon
E -Main Oven Temperature Control
F -Multifunction Selector
Fan Oven
Conventional Oven
Zoned Oven
Defrost
Oven Clean
Thermal Grilling
Oven Light
G -Second Oven Temperature Control
H -Dual Grill Control
13
GETTING TO KNOW YOUR OVEN (BD 931)
A B C D E
A -Electronic Timer
B -Main Oven Temperature Control
C -Multifunction Selector
Fan Oven
F
G
H
Conventional Oven
Zoned Oven
Defrost
Oven Clean
Thermal Grilling
Oven Light
D -Second Oven Temperature Control
E -Dual Grill Control
F -Main Oven Indicator Neon
G -Second Oven Indicator Neon
H -Dual Grill Indicator Neon
14
RATING PLATE
COOKWARE
Record the model and serial numbers of your cooker
on the back cover of this instruction book for future
reference. These numbers can be found on the
rating plate on the lower front frame of the cooker
upon opening the oven door.
The cooker must be protected by a suitably rated
fuse or circuit breaker. The rating of the cooker is
given on the rating plate.
GENERAL NOTES ON USING THE OVENS
We suggest that you run all the elements for a short
period to burn off any residue from their surfaces.
During this period an unpleasant odour may be
emitted, it is therefore advisable to open a window
for ventilation.
WHEN FIRST SWITCHING ON
The timer must be set to manual before the ovens
can be operated. See pages 36 and 39. This must
be done whenever the cooker is switched off at the
wall or when there has been a power failure.
Baking trays, oven dishes etc., should not be placed
directly against the grid covering the fan at the back
of the oven.
Do not use baking trays larger than 30cm x 35cm
(12" x 14") as they will restrict the circulation of heat
and may affect performance. Advice on the effect of
different materials and finishes of bakeware is given
in 'Hints and Tips' in the appropriate oven section.
THE TRIVET
When roasting do use the trivet in the meat tin. Fat
and meat juices will drain into the meat tin below and
can be used to make gravy. The trivet also prevents
splashes of fat from soiling the oven interior.
N.B. The meat tin should not be placed on a heated
hotplate as this may cause the enamel to crack.
THE SHELF POSITIONS
Recommended shelf positions have been shown in
the cooking chart on page 30.
If not fitted correctly the shelf will lie at an angle and
the safety stop will not be effective. To ensure that
the shelf has the correct side uppermost, the wire
stringers which make up the shelf should lie on top of
the surrounding frame.
If the oven indicator neons do not glow when the
controls are switched on, it is most likely that the
timer is set for automatic cooking.
ABOUT CONDENSATION AND STEAM
When food is heated it produces steam in the same
way as a boiling kettle does. The oven is vented to
allow some of this steam to escape. However,
always stand back from the cooker when opening the
oven door to allow any build up of steam or heat to
release.
If the steam comes into contact with a cool surface
on the outside of the cooker, e.g. a trim, it will
condense and produce water droplets. This is quite
normal and is not caused by a fault on the cooker.
To prevent discolouration, regularly wipe away
condensation and also soilage from surfaces.
15
PUSH TO TURN CONTROLS (BD 931 only)
GRILL AND OVEN FURNITURE
The control knobs must be pushed in towards the
panel before they can be turned or adjusted.
THE COOLING FAN FOR THE CONTROLS
The cooling fan comes on immediately when the grill
is switched on and after a short time when either of
the ovens are in use and switches off when cooking
is completed.
During the initial period the cooling fan may cycle ON
and OFF, this is quite normal.
It may run on after the ovens or grill are switched off
to keep the controls cool.
Always allow the cooling fan to cool the cooker down
before switching off at the wall prior to carrying out
any cleaning or maintenance work.
NOTE
The action of the cooling fan will depend on how long
the oven(s) or grill have been used and at what
temperature. It may not switch in at all at lower
temperature settings nor run on where the grill or
oven has only been used for a short time.
The following items of oven furniture have been
supplied with the cooker.
1 grill pan
1 grill pan handle
1 grill pan grid
1 grill deflector
CONTROL PANEL INDICATOR NEONS
These lights indicate whether the grill or ovens are
switched ON. In the case of the ovens, the neons
also indicate when the set temperature has been
reached. They will cycle on and off during use to
show that the temperature is being maintained.
If the neons do not operate as the instructions
indicate the controls have been incorrectly set.
Return all controls to zero and re-set following the
instructions for the required setting.
When the oven has been set for automatic cooking
the neon should remain unlit during OFF periods.
.
1 trivet
1 meat tin
2 straight shelves
1 cranked shelf for
grilling and top oven
cooking only
16
Scuffing of the Stayclean lining by the oven furniture
pack may occur during transit.
These marks will disappear after the oven elements
have been burnt off for the first time.
THE GRILL
USES OF THE DUAL GRILL
CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD
BE KEPT AWAY.
The grill is a dual circuit grill which means that the full area of the grill can be used or for economy purposes the
centre section only can be used when cooking smaller quantities of food.
SELECTING THE DUAL GRILL
BD 921
BD 931
l
Turn the grill control clockwise for full grill or
anticlockwise for the centre section only.
l
Ensure the second oven control is in the OFF
position 'O'.
l
The dual grill operates independently of the oven.
THINGS TO NOTE
THE GRILL DOOR MUST BE LEFT OPEN DURING
GRILLING
1. The cooling fan for the controls will operate
immediately in conjunction with the grill.
2. The grill indicator neon will illuminate.
3. The grill indicator window will illuminate.
4. Do not attempt to use the grill when the fan oven
has been set to automatic as overheating will
occur.
5. The outer grill element may appear to glow
slightly brighter than the inner element. This is
quite normal.
17
THE GRILL PAN AND HANDLE
The grill pan is supplied with a removable handle.
To insert the handle, press the button on the handle
with the thumb and pivot the handle slightly upwards
inserting the lip into widest part of the bracket. Move
the handle towards the left, lower into position and
release the button.
Ensure the handle is positively located.
To remove the handle, press the button on the
handle with the thumb and pivot the handle slightly
upwards and towards the right to remove from the
bracket.
To check the progress of the food being grilled, the
grill pan should be withdrawn on the shelf to attend to
food during cooking.
HINTS AND TIPS
Ensure your hand is protected when removing
the grill pan handle as the grill element can
become very hot.
ALWAYS REMOVE THE GRILL PAN HANDLE
DURING GRILLING.
To correctly locate the grill pan on the shelf, ensure
that the cut out on the underside of the handle
bracket locates over the front bar of the shelf.
l
Most foods should be placed on the grid in the
grill pan to allow maximum circulation of air to lift
the food out of the fats and juices. Food such as
fish, liver and kidneys may be placed directly on
the trivet in the grill pan if preferred.
l
Adjust the grid and grill pan runner position to
allow for different thicknesses of food. Position
the food close to the element for faster cooking
and further away for more gentle cooking.
18
Loading...
+ 39 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
