TriBrer Lemon 3 User Manual

USER'S GUIDE

Fusion Splicer

WarningWarning

Any undefined change or modification of this manual will deprive you of the right to operate the equipment.

To reduce the risk of fire or electric shock, do not expose the equipment to rain or humidity.

To prevent electric shock, please do not open the shell, and it must be repaired by qualified personnel.

This product is designed for splicing the glass fiber of optical communications and cannot be used to splice other materials.

To reduce the risk of fire or electric shock, do not allow liquid such as water or metallic substances to enter the machine.

It is forbidden to use the fusion splicer in the flammable and explosive environment, otherwise it will lead to fire or explosion.

When the fusion splicer is working, do not touch the electrode, avoid the hurt caused by the discharge of the electrode. When replacing the electrode, you must turn off the power and disconnect the power cord.

Please follow the operation manual strictly to use the battery:

*Please do not charge the battery by using methods other than in the manual;

*Don't throw the battery into the fire;

*Don't reverse positive and negative poles;

*Do not charge or discharge under high temperature, fire or direct sunlight;

*Do not throw or impact the battery;

*If the battery electrolyte leaks out, please handle it carefully. If you contact the skin or eyes accidentally, please must clean it thoroughly and seek medical advice immediately. Please also inform the maintenance center of handling the battery.

1

CautionsCautions

Do not use and store the fusion splicer in a high temperature and humidity environment . Otherwise, it may cause damage to the equipment.

Do not touch the heat-shrinkable tube during the heating or just ending, because the heat shrink is hot and may cause burns.

Do not touch the fusion splicer, AC power cord and AC plug when wet hand, otherwise it may cause electric shock.

Do not use any chemicals other than alcohol to clean microscope lenses, V-grooves, LCD screen, etc., otherwise it may cause blurred images, stains, etc., and may even cause equipment's corrosion and damage.

In the dusty environment, dust-proof measures must be taken to prevent dust from entering the machine and causing trouble.

Do not allow the fusion splicer to be subjected to strong vibration and shocks, otherwise the machine will be damaged. Please use a dedicated carrier to transport or store the fusion splicer.

Using the battery

The equipment can use a disposable alkaline battery or rechargeable battery, and can not be mixed with different types or different capacity batteries. Only rechargeable batteries can be charged.

Avoiding condensation:

Sudden changes in temperature should be avoided. Do not use the device immediately after moving the device from the cold area to the hot area, or when the room suddenly heats up, because the device may have condensation phenomenon. If the temperature changes abruptly , stop using it and take out the battery, and the power can be switched on after at least an hour.

Storage

When the device is not used for a long time, please take out the battery to avoid the damage caused by battery leakage .

:

All is subjected to the physical products, the manual here is just only for reference.

:

2

Standard Package

Carrying case

AC/DC adaptor

Fiber cleaver

Fiber stripper

Spare electrode

User manual

3

Host

1 2

3

8

7

6

5

9

10

11

1312

14

1516

4

Electrode

1

Objective lens

2

Clamp slot

3

V-groove

4

5

Cooling tray

Multi-functional clamp

6

Heater V-groove

7

8

Heat shrinker cover

9

Electrode cover

10

USB connector

Power supply socket

11

Windshield cover

12

Optical fiber presser

13

LED

14

15

Battery

16

Anti-collision batten

4

ON/OFF Key

Power on/off

How to Use Keyboard

ENTER Key

Enter into the menu Save settings

HEAT Key

Start heating

LEFT/RIGHT Key

Modify settings

UP/DOWN Key

Move the cursor

X/Y Key

Back to previous menu Switch X/Y images

5

RESET Key

Motor reset

START Key

Start splicing

Splicing Operation

Confirming Splicing & Heating Mode

Placing protection sleeve over fiber

Stripping, Cleaning, Cleaving fiber

Loading fiber onto splicer

Start splicing

Visual inspection on LCD during splice

Taking out spliced fiber

Centering sleeve to spliced point

Centering sleeve in heater

Start heating

Turn on

Note: Place fiber between electrodes tip and V-groove end.

Hold

Pull

Marking

6

Main Menu

Press key to open the menu, then using navigation key to choose the different sub-menu, then press

key again to enter into the sub-menu.

Splice Mode Heating Mode Function Setting

System Setting

08:20

01.07.2017

History Record Maintain

Enter

7

Back

80%

Splice Mode

Press / key to choose the line, and use / key to set the detailed configuration.

Splice Mode

SM, MM, DS, NZDS...

Manual, Auto, Half-auto

Set current splicing program number Edit splicing parameters under current program No.

Clean tiny dust on fiber end by a short arc discharging

Set the limit value of fiber end surface angle

Splice Mode

Fiber type

Splice operate mode

Splice program No.

Edit splice program

Clean arc time

Surface angle threshold

SM

Manual Enter

SM-1

Enter

120ms

3.0

08:20

01.07.2017

Cutting angle threshold

Align offset threshold

Loss threshold

Compensation arc time

Fiber alignment mode

Fast splice mode

Forced splice mode

Enter

Back

1.0

0.4um

0.10dB

1.0s

Core align

Off

80%

Set fiber alignment limitation

Set fiber alignment offset threshold

Set splicing loss limit value Set compensation arc time

Fine align, Cladding align, Core align

On or Off

8

Heating Mode

Heating program No .

Casing type

Casing diameter

Heating temperature

Heating time

Auto heating

Heating Mode

6

40mm

4mm

150

19s

On

Select the protection sleeve type

Diameter of fiber protection sleeve

08:20

01.07.2017

Enter

Back

9

80%

Function Setting

Reset waiting time

Fast arc test mode

Tension test

Auto starting

Function Setting

6s

On

Only valid when "Tension test" is "Off"

If "On , splicer will auto adjust the discharge current"

If "On , it will execute tension test automatically

"

after splicing

If "On , it will auto start splicing"

08:20

01.07.2017

Enter

Back

80%

10

System Setting

Help information

Brightness adjustment

Language selection

Screen flip

Time setup

Restore factory settings

System Setting

Enter

100%

English

Flip

Enter

08:20

01.07.2017

Year

Month

Date

Hour

Minute

Time setup

Enter

2017

12

30

Back

7

1

80%

08:20

01.07.2017

Power saving mode

Silent mode

Enter

Back

Enter

Off

11

80%

Auto shutdown

08:20

01.07.2017

Auto sleep

Power saving mode

Enter

Off

10min

Back

80%

History Record

.Press key to enter into the detailed interface, while key to back to previous menu

History Record

Total arc number

Clear arc count

Total records

View records

Delete records

Query fault records

08:20

01.07.2017

Delete fault records

History Record

Enter

103

Enter

53

Enter

Back

Enter

No.

0001

0002

0003

0004

Total: 42

08:20

01.07.2017

80%

01.07.2017 12:30

Total: 42 Pages:11 Current: 1

08:20

01.07.2017

Date Angle LossFiber type

01.07.2017

Date / Clock No.

View records

0.0

Pages:11 Current: 1

Enter

Query fault records

Enter

SM

Back

0X00003115

Back

0.00

80%

12

Maintain

Arc correction

Help

1st: Place fiber and covering the wind cover. 2nd: Press 'ENTER' key and follow the prompts.

Maintain

Arc correction

Clean electrodes

Replace electrodes

Detect system parameters

Correct led

08:20

01.07.2017

Maintain

Enter

Back

13

80%

NOTE: Several times is needed. Please wait patiently.

08:20

01.07.2017

Manual SM-1 60-6mm

Discharge

Reset

08:20

01.07.2017

Enter

X

Y

Back

80%

Left

Fiber

Start

80%

Maintain-Clean Electrodes

Clean electrodes

Help

1st: Ensure that no fiber exist in the vision. 2nd: Press 'ENTER' key and follow the prompts.

08:20

01.07.2017

Note: To get the best splicing result, please don't touch the electrode tip with hard objects while cleaning.

Enter

14

Back

80%

Maintain-Replace Electrodes

Replace electrodes

Help

1st: Turn off and replace the old electrodes. 2nd: Ensure that no fiber exist in the vision. 3rd: Press 'ENTER' key and follow the prompts. NOTE: After the operation is completed, the number of discharge will be set to 0.

08:20

01.07.2017

Remove the electrode cover Loosen screws Remove the old electrode

Place the electrode cover

Enter

Tighten screws

15

Back

80%

Install the electrode cover

Maintain-Detect System Parameters

To get better splicing result, we suggest you under following situations:

System upgrade

1. ;

eplace or move electrodes;

2.R

3.Long-distance transportation and strong vibration;

4.

Continuous splicing failure or high loss;

5.

Continuous overshoot during alignment.

detect system parameter

Detect system parameters

Help

1st: Clean the V-grove, place fiber and covering the wind cover. 2nd: Press 'ENTER' key and follow the prompts. NOTE: This operation will last for a few minutes. Please wait patiently.

08:20

01.07.2017

16

Enter

Back

80%

Fusion Splicer Cleaning

V-groove

Fiber Presser

When cleaning, keep the device Off Use cotton swab moistened with purity alcohol

Objective Lens

The Heater

Do not touch the electrode tips Use dry swab to clean the excess alcohol

17

Battery Information

In lower right of the interface is the battery state and battery indicator. The battery will display different colors and

shapes in various states. Here are some examples of . Battery information can also be viewed in the system menu.

AutoMode SM-1 60-6mm

Splice

Reset

08:20

01.07.2017

icons

X

Place

Fiber

Y

Align to

splice

80%

100% 10% 50% 100%

Remain 100% less than 10%

Charging

Fully charging

shows red icon

18

Warning Information

Warning English hints()

Fiber cutting length is too short

Left / right / left and right fiber placement error

(LFPC / RFPC / LRFPC)

Left / right / left and right fiber disqualification

(LFNQ / RFNQ / LRFNQ)

Left / right / left and right fiber's end face disqualification (LFEANQ /

RFEANQ / LRFEANQ)

Optical fiber angle disqualification(FANQ)

Large loss

Lack of electricity

Replace electrodes

Record overrun

Alignment abnormal

The fiber placed in the V-groove has been broken

Fiber is not placed in the middle of the V-groove

Propulsion motor connection problem

Dust on the fiber's surface

Poor quality of cutting, core defect, cladding damage

Optical fiber end angle exceeds preset limit value

The angle error in both horizontal and vertical direction is greater than the set threshold value

Splicing loss exceeds the set upper limit or choose an unmatched optical fiber type fusion program.

Current battery power is less than 2%

The Arc count exceeds the upper limit

The splicing record exceeds the upper limit

Fiber end face has dust or quality is poor

The windshield cover is too tight and the brightness of LED lights is not suitable

Reason

Treatment method

Cut the fiber again and ensure the cutting length

Replace the fiber

Please detect system parameters

Use alcohol to clean fiber again

Remake the fusion fiber

Cut the fiber again, if the quality is poor, please replace the fiber cleaver

Replace the fiber on both sides

Please clean the V-groove, redo the discharge correction, and splice again

Please insert the adapter to charge

Replace electrode and detect system parameters

Please use the USB derive the original splicing record, then delete them

Please cut and clean the fiber again and make the alignment. If it doesn't work, please detect system parameters or restart the machine

19

Warning Information

Warning Reason Treatment method

Timeout abnormal

Field abnormal

Data abnormal

Light source abnormal

Detection abnormal

Heat Shrink abnormal

Storage abnormal

Image abnormal

Sense abnormal

Electrode abnormal

Long time during align splicing

Improper installation position of electrode

The mechanical structure was destroyed

The fusion splicer is working in the abnormal state

Improper setting of luminance of LED

Improper installation position of windshield cover

Failures in detecting system parameters

Heat shrinkable heater do not work properly

Data can't be saved

Communication anomaly, data has a packet loss

The camera may have been damaged or connector interface is loose

The abnormal working of the sensor built-in the fusion splicer

Abnormal installation of electrode on both sides

Restart align splicing

Detect system parameters first, if continue to prompt abnormal, please re-install the electrode

Continue to align splicing, and it have no affect

Please detect system parameters

Please check if the fiber is properly placed and the connection is in good condition

Restart the fusion splicer

Please contact the after-sales service

Restart the fusion splicer

This abnormal does not affect the normal working

Please ensure that electrodes of both sides are aligned when installed, also ensure that both sides are in the center of the V-groove

20

Specifications

Applicable fibers

Average splice loss

Fiber aligning method

Splicing time

Heating time

Electrode life

Battery capacity

Monitor

Storage of splice result

Tension test

Splicing mode

Protection sleeve length

Environmental conditions

Power supply

Size(H*W*D)

Weight

SM, MM, DS, NZDS, EDF

0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF)

Core alignment

Typical 8s with standard SM fiber

24s

2500

Typical 200 cycles (splicing and heating)

5.0 inches colorful LCD display

10000 results

2.0N (Standard)

Auto & Manual & Half Auto

40mm, 60mm or others

-10~+50 (operation temperature), 0~95% RH(humidity), 0~5000m(altitude)

Li-ion battery or AC/DC input: 13.5V

164mm * 141mm * 138mm

1.83kg

21

TriBrer Lemon 3 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
