USER'S GUIDE
Optical Multi Meter
EnglishEnglish
Page 2
WARNINGWARNING
You are cautioned that changes or modifications not espressly
approved in this document could void yout authority to operate this
equipment.
To reduce the risk of fire or electric shock,do not expose this
apparatus to rain or moisture.
To avoid electrical shock, do not open the cabinet. Refer servicing
to qualified personnel only.
NOTENOTE
As the laser is harmful to the eyes, do not attempt to disassemble
the cabinet.
CALSS I LASER PRODUCT
Precautions for Use
Use batteries
At the same time, can not use different style or different capacitance
batteries.
And only charge the rechargeable batteries.
Avoiding condensation problems
As much as possible, avoid sudden temperature changes. Do not
attempt to use the drive immediately after moving it from a cold to a
warm location, to raising the room temperature suddenly, as
condensation may form with in the drive. If the temperature changes
suddenly while using the drive,
Stop using it and take out batteries for at least an hour.
Storage
When long time no use,must take out the batteries to avoid
destroying the device.
1
Page 3
PERM
nm
REF
Save
1310nm
1KHz
Optical Mulit Meter
>2s PERM
Save
Laser
ON
Standard
2KHz
dBm
VLS
GLINT
VFL
Unit
REF
MOD
Host
USER'S GUIDE
Handheld measuring instrument
Optical power meter
Optical laser source
Optical mulit meter
Manual
EnglishEnglish
EnglishEnglish
EnglishEnglish
Bag
FC/SC Adapter
Optional
Chargeing
2
Page 4
10
Description
1
2
11
USB
12
13
PERM
nm
REF
Save
1310nm
1KHz
Optical Mulit Meter
>2s PERM
Save
Laser
ON
2KHz
dBm
VLS
GLINT
VFL
Unit
REF
MOD
14
1-VFL connector
2-OPM connector
3-LCD
4-OPM wavelength shift key
5-VFL on/off key
6-Unit shift key
7-Reference set/check key
8-Laser source modulation key
9-Laser source wavelength shift key
10-Laser Source connector
11- USB
12-Power key(Backlight key)
13-Data Save/Recall key
14-Laser source on/off key
3
3
4
5
6
7
8
9
Page 5
Set batteries
1.Press and push down
3.Place the batteries
2.Open the lid
4.Place the batteries
4
Page 6
Power on/off, auto power off
PERM
PERM
2KHz
nm
REF
Save
1310nm
Optical Mulit Meter
>2s PERM
Save
Laser
ON
Press the Power key to turn on the device with auto
dBm
VLS
GLINT
1KHz
VFL
Unit
REF
MOD
power off. After 10 minutes no key pressed,it will auto
power off.
Press Power key for 2 seconds when turn on the
device, the auto power off will be cancelled,and the LCD
will show PERM .
Also press it for 2 seconds to shut the device.
5
Page 7
Backlight
PERM
2KHz
nm
REF
dBm
VLS
GLINT
1KHz
VFL
Unit
REF
MOD
>2s PERM
Save
1310nm
Optical Mulit Meter
>2s PERM
Save
Laser
ON
When the device power on, press the power key
to turn on or turn off the backlight.
6
Page 8
Wavelength select
PERM
2KHz
nm
REF
Save
1310nm
Optical Mulit Meter
>2s PERM
Save
Laser
ON
When testing, you must select the right wavelength.
Press the key for shifting the wavelength from:
850nm,1300nm,1310nm,1490nm,1550nm,1625nm
dBm
VLS
GLINT
1KHz
VFL
Unit
REF
MOD
7
Page 9
Unit select
nW
mW
dBm
Unit
Press the key for shifting the unit from:dBm,
Unit
mW/uW, dB.
mW/uW: 1mW=1000uW, 1uW=1000nW
dBm: (dBm)=10*log(mW)
PERM
nm
REF
Save
1310nm
1KHz
Optical Mulit Meter
>2s PERM
Unit
Save
Laser
ON
GLINT
2KHz
dBm
VLS
VFL
REF
MOD
dB: (dB)=dBm-REF
8
Page 10
Reference
REF
REF
Press key to check the reference value
REF
PERM
nm
REF
Save
1310nm
1KHz
Optical Mulit Meter
>2s PERM
Unit
Save
Laser
ON
GLINT
2KHz
dBm
VLS
VFL
REF
MOD
you set last time.
And if keep pressing for 2 seconds, you can store the
current dBm as a new reference value. Then it automatically
shift to dB.
dB=dBm-REF
You can store the REF value for each wave.
9
Page 11
Data Storage
Save
PERM
2KHz
nm
REF
dBm
VLS
GLINT
1KHz
VFL
Unit
REF
MOD
Save
Save
1310nm
Optical Mulit Meter
>2s PERM
Save
Laser
ON
When in testing interface, user can press
to the History interface
key . And press the
key for 2 seconds .
to save current value
SAVE
SAVE
10
Page 12
Laser source on/off
PERM
2KHz
nm
REF
dBm
VLS
GLINT
1KHz
VFL
Unit
REF
MOD
Laser
ON
Save
1310nm
Optical Mulit Meter
>2s PERM
Save
Laser
ON
Press the key to turn on/off the laser source
output
11
Page 13
850nm
1300nm
1490nm
1310nm
1550nm 1625nm
Wavelength select
PERM
nm
REF
Save
GLINT
1310nm
1KHz
Optical Mulit Meter
>2s PERM
Unit
Save
Laser
ON
2KHz
dBm
VLS
VFL
REF
MOD
Press the key to shift the wavelength.
12
Page 14
Frequency select
PERM
2KHz
nm
REF
Save
1310nm
Optical Mulit Meter
>2s PERM
Save
Laser
ON
dBm
VLS
GLINT
1KHz
VFL
Unit
REF
MOD
270Hz
1KHz
2KHz
MOD
Press the key to shift from CW, 270Hz, 1KHz,
MOD
2KHz.
13
Page 15
Visual Fault Locator (optional)
PERM
2KHz
nm
REF
VLS
GLINT
1KHz
Optical Mulit Meter
Unit
dBm
VFL
REF
MOD
>2s PERM
Save
Laser
ON
Save
1310nm
The device can build in a optional VFL module, press
the VFL key to shift the conditions: on-> glint->off
VLS
GLINT
VFL
14
Page 16
Battery energy detect
PERM
2KHz
nm
REF
dBm
VLS
GLINT
1KHz
Optical Mulit Meter
VFL
Unit
REF
MOD
Remain80%---100%
Remain40%---80%
Remain20%---40%
Remain less than20%
>2s PERM
Save
Laser
ON
Save
1310nm
If the energy is too low, the beep will be on and device
will auto power off.
15
Page 17
Battery charge
First you must use the rechargeable batteries. When
the energy is less than 20%, you should charge the
batteries.
Long time low energy, the life of the batteries will be
short. When charging, the battery indication on LCD
will flash. After charging fully, the indication will stop
flashing and show full. Don't charge for more than 24 hours.
If charging while using the device, the time will be longer.
The rechargeable batteries must be in device when you
use the AC/DC adaptor for charging. And do not charge
the non-rechargeable batteries, or the device will be
destroyed and also lose theguarantee.
PERM
2KHz
nm
REF
dBm
Save
5V_500mA
1310nm
1KHz
Optical Mulit Meter
>2s PERM
Save
Laser
ON
VLS
GLINT
VFL
Unit
REF
MOD
16
Page 18
Measuring range
Calibrated
wavelengths
Resolution
Accuracy
Linearity
PD Type
Connector
Data Storage
Detailed
T M C
-70~+10dBm -60~+18dBm -50~+26dBm
850nm,1300nm,1310nm,1490nm,1550nm,1625nm
+6~-60dBm(0.01dB)
-60~-70dBm(0.1dB)
+16~-50dBm(0.01dB)
-50~-60dBm(0.1dB)
0.2dB
2%
InGaAs
FC (or SC) & 2.5mm UPP
Yes
+26~-40dBm(0.01dB)
-40~-50dBm(0.1dB)
Wavelength
Spectral width
Output power
Laser type
Frequency
Connector
VFL part
Wavelength
Output power
1~3 wavelengths of 850/1300/1310/1490/1550/1625
850nm,1300nm,1310nm,1550nm@10nm
1490nm,1625nm@5nm
850nm>-10dBm
1300nm,1310nm,1550nm,1490nm,1625nm>-6dBm
850nm,1300nm,1310nm,1550nm@FP
1490nm,1625nm@DFB
270Hz/1KHz/2KHz
FC/PC or customize
650nm
1mW or 10mW
17
Page 19
Power supply
Battery life
Operating temp
Storage temp
Size(H*W*D)
Weight
Detailed
AAX2
>50H
-10 ~ +50 ,<90%RH
-20 ~ +60 ,<90%RH
170mm*97mm*38mm
About 380g
