INSTALLATION AND OPERATING

INSTRUCTIONS

TRO EVOLUTION BH

Index

1.- PRESENTATION.................................................................................................................................................................................................4

2.- LIST OF COMPONENTS................................................................................................................................................................................5

3.- CONTROL COMPONENTS.........................................................................................................................................................................6

4.- INSTALLATION INSTRUCTIONS..................................................................................................................................................................7

LOCATION...........................................................................................................................................................................................................7

4.1.-

INSTALLATION A ND ELECTRICAL CONNECTION OF THE BOILER. ..............................................................................................................7

4.2.-

HYDRAULIC INSTALLATION...............................................................................................................................................................................7

4.3.-

ELECTRICAL CONNECTION.............................................................................................................................................................................8

4.4.-

FUEL INSTALLATION............................................................................................................................................................................................8

4.5.-

DRAINING THE BOILER......................................................................................................................................................................................8

4.6.-

PRECAUTIONS FOR PREVENTING NOISE DURING OPERATION ..................................................................................................................8

4.7.-

FILLING AND BLEEDING THE INSTALLATION...................................................................................................................................................8

4.8.-

5.- COMBUSTION PRODUCT REMOVAL...................................................................................................................................................9

COMBUSTION PRODUCT REMOVAL...............................................................................................................................................................9

5.1.-

Ø80 / Ø100 (TYPE C53) DUAL DUCT SYSTEM FOR COMBUSTION PRODUCT REMOVAL AND AIR INTAKE..................................10

5.2.-

CHANGING FROM DUAL DUCT FUME REMOVAL TO COAXIAL FUME REMOVAL...............................................................................11

5.3.-

CONCENTRIC HORIZONTAL DUCT FOR COMBUSTION PRODUCT REMOVAL AND AIR INTAKE Ø80-125 (TYPE C13)............12

5.4.-

CONCENTRIC VERTICAL DUCT FOR COMBUSTION PRODUCT REMOVAL AND AIR INTAKE Ø80-125 (TYPE C33)...................13

5.5.-

6.- OPERATION.....................................................................................................................................................................................................14

BOILER FUNCTIONING....................................................................................................................................................................................14

6.1.-

OPERATING WITH A SANIT HOT WATER TANK (OPTIONAL).....................................................................................................................14

6.2.-

7.- SAFETY CUT-OUTS........................................................................................................................................................................................14

EXCESSIVE TEMPERATURE SAFETY CUT-OUTS (THERMOSTAT TS) ............................................................................................................14

7.1.-

EXCESSIVE FUME TEMPERATURE SAFETY CUT-OUT (THERMOSTAT TH)...................................................................................................14

7.2.-

BURNER CUT-OUT............................................................................................................................................................................................14

7.3.-

8.- CLIMATE CONTROL (OPTIONAL) :.....................................................................................................................................................15

9.- SHUTTING DOWN THE BOILER...............................................................................................................................................................15

10.- START-UP........................................................................................................................................................................................................15

11.- FIRST START-UP............................................................................................................................................................................................15

12.- DELIVERY OF THE SYSTEM.....................................................................................................................................................................16

13.- BOILER MAINTENANCE..........................................................................................................................................................................16

CLEANING THE BOILER................................................................................................................................................................................16

13.1.-

BOILER WATER CHARACTERISTICS.............................................................................................................................................................17

13.2.-

CONDENSATE DRAIN-OFF..........................................................................................................................................................................18

13.3.-

14.- TECHNICAL CHARACTERISTICS........................................................................................................................................................19

15.- ELECTRICAL DIAGRAM.........................................................................................................................................................................20

16.- DIAGRAMS AND MEASUREMENTS..................................................................................................................................................21

17.- BURNER...........................................................................................................................................................................................................22

ASSEMBLY......................................................................................................................................................................................................22

17.1.-

BURNER START-UP.........................................................................................................................................................................................22

17.2.-

ADJUSTING THE COMBUSTION CONDITIONS..........................................................................................................................................22

17.3.-

PRIMARY AIR ADJUSTMENT.........................................................................................................................................................................23

17.4.-

COMBUSTION LINE ADJUSTMENT ..............................................................................................................................................................23

17.5.-

CORRECT POSITION OF ELECTRODES......................................................................................................................................................23

17.6.-

OIL PRESSURE ADJUSTMENT........................................................................................................................................................................24

17.7.-

O PIPE OPERATION .....................................................................................................................................................................................24

17.8.-

IL SUPPLY PIPING DIAGRAMS .....................................................................................................................................................................24

17.9.-

17.10.-

17.11.-

17.12.-

17.13.-

17.14.-

17.15.-

17.16.-

TECHNICAL SPECIFICATIONS...................................................................................................................................................................25

OPERATING CURVES.................................................................................................................................................................................26

RECOMMENDED NOZZLE AND PUMP PRESSURE..................................................................................................................................26

OIL FLOW VERSUS NOZZLE AND PUMP PRESSURE................................................................................................................................26

ELECTRICAL CONNECTION DIAGRAM..................................................................................................................................................27

QUICK CONNECTOR................................................................................................................................................................................28

BURNER CONTROL OPERATING SEQUENCE .........................................................................................................................................29

page -2

18.- TROUBLESHOOTING................................................................................................................................................................................30

BURNER ERROR CODE.................................................................................................................................................................................30

18.1.-

BOILER FAILURES...........................................................................................................................................................................................30

18.2.-

THERMOSTAT.................................................................................................................................................................................................31

18.3.-

19.- SPARES LIST...................................................................................................................................................................................................32

BURNER ..........................................................................................................................................................................................................32

19.1.-

BOILER............................................................................................................................................................................................................33

19.2.-

19.3.-

FRON ELECTRICS..............................................................................................................................................................................................34

page -3

1.- PRESENTATION

Thank you for choosing a TRIANCO heating boiler. You have chosen a boiler that, with a suitable hydraulic installation and using oil for fuel, will provide the ideal level of comfort for your home.

This manual forms an essential part of the product and it must be given to the user. Read the warnings and recommendations in the manual carefully, as they contain important information on the safety, use and maintenance of the installation.

These boilers must be installed by qualified personnel only, in accordance with the legislation in force and following the manufacturer's instructions.

The start-up of these boilers and any maintenance operations must only be carried out by Official Technical Assistance Services of TRIANCO.

Incorrect installation of these boilers could result i n damage t o people, animals or property, and the manufacturer will hold no liability in such cases.

TRIANCO informs all parties concerned that, in compliance wit h section 1 of the first additional provision of Law 11/1997, the responsibility for deliveri ng packaging waste or used packaging for its proper environmental management will be t hat of the final owner of the product (Article

18.1 Royal Decree 782/1998). At the end of its useful life, the product must be taken to a selected collection point for electrical and electronic equipment or must be returned to the distributor at the time of purchasing a new equi v alent appli ance. For more detailed informati on on the collection schemes available, contact either the collection facilities of the local authority or the distributor where the purchase was made.

page -4

2.- LIST OF COMPONENTS

5

4

2

3

6

7

8

1

1. Blow-off valve.

2. Domestic sealed oil burner.

3. Bulb-holder sheath.

4. Automatic air bleed valve.

page -5

5. INOX Condenser output diam. 100.

6. Automatic air bleed valve.

7. Condensate siphon.

8. Cast body.

3.- CONTROL COMPONENTS

8 9 10 11 12

14151617

8. Climate control (optional):

It is an optional element which allows us to regulate the temperature of the installation according to the needs of the household and the outside temperature.

9. Thermometer:

Indicates the water temperature of the boiler.

10. Control thermostat.

With this we can select the operating temperature of the central heating, stopping the burner when the boiler temperature is equal to that selected or keeping it going when it is less.

11. Boiler safety thermostat:

This is a cut-out mechanism to ensure the boiler temperature does not exceed 110ºC.

12. Fume safety thermostat:

This safety thermostat operates when the temperature of the combustion products exceeds 110ºC, in order to protect the polypropylene duct.

13. Burner blocked pilot light:

When lit, it indicates that the boiler operation has been blocked due to blocking of the burner.

13

14. Blocked due to temperature pilot light:

When lit, it indicates that the boiler operation has been blocked due to excessive temperature (higher than 110ºC).

15. ON position pilot light:

When lit, it indicates that the boiler is in "normal operation (ON)" mode.

16. Master switch:

This lets us turn the boiler on and off by pressing the "O/I" swi tch. By pressing the "/☼" switch, we can select either summer service (DHW only) or Winter service (heating + DHW).

17. Manometer:

Indicates the water pressure of the installati on.

page -6

4.- INSTALLATION INSTRUCTIONS

The boiler must be installed by personnel authorised by the Department of Industry in accordance with the applicable regulations and standards in force. However, the following recommendations must be complied with when installing t he boiler:

4.1.- Location

The boiler must be installed in a sufficiently ventilated site. It is essential that the boiler is accessible from the side for maintenance purposes.

4.2.- Installation and electrical connection of the boiler.

The pictures below show the two burner assembly operations:

4.3.- Hydraulic Installation

Fit the flexible pipe.

Tighten the bracket.

Connect the electrical

connector.

The hydraulic installation must be made by qualified personnel. The applicable installation legislation is to be complied with, and the following recommendations should also be taken into account:

- The inside of the installation pi pi ng should be thoroughly cleaned before switching on the

boiler.

- We recommend inserting cut-off valves between the installation piping and the boiler to simplify maintenance tasks.

- Before starting up the unit, it is essential to i nstall the condensation siphon supplied with the boiler documentation, in the condensation drain tube on the back of the boiler.

- When the pressure of the domestic water supply exceeds 7 bars, a pressure reducer must be fitted.

page -7

- The condensation pipe must lead to a drain outlet, as the TRO Evolution BH is a condensing boiler and a large amount of water may be generated. This connection must be made in compliance with th e regulations for draini ng off condensation water t o the drainage system.

- Fill the siphon with water before starting up the unit, to prevent fumes coming out of it.

4.4.- Electrical Connection

The boiler is equipped for connection to 230 V in pins 1 and 2. Remember to earth the appliance.

The boiler has two terminals prepared for connecting the room thermostat (see wiring diagram). The bridge that joins the terminals must therefore be removed and the room thermostat connected there.

4.5.- Fuel installation

The TRO Evolution BH boiler is supplied with a Domestic oil burner (see model in "Technical Characteristics"). For the fuel installation, proceed in accordance wi th the burner instruct ions enclosed with this manual (see "Burner" section). The oil line installation and start-up of the burner must be carried out by qualified, authorised personnel.

4.6.- Draining the boiler

The boiler is emptied by opening the drain tap located in the rear of the boiler. A flexible hose must be attached to this tap to direct it to a water outlet. After draining the boiler, the valve must be closed and the flexible tube removed.

4.7.- Precautions for preventing noise during operation

Ensure the flow and return pipes are not touching each other, or insulate them to prevent any vibration noise. The boiler must be correct ly seated on its base and lev elled. Before startup, make sure that the boiler and the system have been properly bled.

4.8.- Filling and bleeding the installation

To fill the installation, open th e fill valve unti l the manometer shows a pressure of 1 - 1.5 bars. The circuit should be filled slowly and with the automatic air bleed valve cap loose, to let the air out of the installation. The air should also be bled from the rest of the i nstallation using the air bleed valves provided. Close the fill valve after filling.

NOTE: Switching on the boiler with no water inside could result in serious damage.

page -8

5.- COMBUSTION PRODUCT REMOVAL

5.1.- Combustion product removal

The combustion product exhaust ducts must be installed by qualified personnel and must comply with current legislation and standards.

The TRO Evolution BH boilers are sealed oil-fired boilers, and the combustion products are therefore removed through an outlet pipe, with a separate air intake from outside. We recommend that the position of the outside exhaust duct is as shown in the figures and in the table below:

Removal pipe position

A under a cornice 300 B between two horizontal ducts 1000 C from an adjacent window 400 D between two vertical ducts 1500 E from an adjacent ventilation grille 600 F under a balcony (*) 300 G under a window 600 H under a ventilation grille 600 I from a recess in the building 300 J from a corner of the building 300 K from the ground 2500 L from a vertical or horizontal duct or outlet (**) 300 M from a frontal surface at a distance of 3 metres from the fume outlet 2000 N as above, but with an opening 3000

(*) Providing the width of the balcony is not over 2000 mm. (**) If the pipe is made of materials sensitive to the action of the flue gases, this distance should be over 500 mm. Note: Spanish l aw also stipulates that the end of the exhaust duct must be at a distance of at least 400 mm from

any air intake opening, and from the wall.

Minimum distance

mm

IMPORTANT: All accessories used for combustion product removal and air intake should be

those supplied by TRIANCO.

page -9



5.2.- ø80 / ø100 (type C53) dual duct system for combustion product removal and air intake

For this type of boiler, combustion product removal and air intake take place through separate Ø80/100 mm mm ducts, using the Ø80/100 Kit, code CGAS000265. TRO Evolution BH boilers come equipped with this type of extraction, by default.

15 metres is the maximum length of pipe that can be installed in the TRO Evolution BH model, which is the maximum when adding up the metres of the air intake duct and the metres of the combustion product removal duct. For every horizontal metre, the available length is reduced by 2 metres and for every 90° bend, or two 45º bends, it is reduced by 1m.

It is recommended to fit the removal pipe in a slightly upwardly-inclined direction, at around 2º - 3º, thus preventing any water and condensation from dripping out.

Double outlet duct kit 80/100

Code CGAS000265

1m pipe 80 Code CGAS000145

1m pipe 100 Code CGAS000268

NOTE: For this configuration the pipes and elbows of

Examples of installation:

90º bend 80 Code CGAS000147

90º bend 100 Code CGAS000267

45º bend 80 Code CGAS000148

45º bend 100 Code CGAS000266

80 are only for the intake of air.

page -10

5.3.- Changing from dual duct fume removal to coaxial fume removal

The TRO Evolution BH boiler has a Ø80 dual duct system for combustion product removal and air intake. If you prefer the combustion products to be removed by means of a Ø80/125 coaxial tube, you may use the Ø80/125 coaxial tube adaptor kit (supplied to order), code CGAS000213 + Code CGAS000222.

Adapter for coaxial pipe 80/125

ode CGAS000213 + Code CGAS000222

The changeover may be made with two different assembly configurations:

1. Output towards the back: simply remove the combustion air intake from the boiler,

unscrewing the three screws holding it in place, mount the adaptor on the fume outlet towards the rear, and use the flexible air inlet tube to connect it to the adaptor T.

2. Side or top output: the procedure is the same, but for side mounting of the adaptor kit a

90º Ø80 elbow (code CGAS000147) needs to be fitted before the adaptor at the fume outlet.

The two configurations are shown in the figures below:

Combustion air intake

Rear outlet

Side outlet

90º Ø100 elbow

Code CGAS000267

page -11

5.4.- Concentric horizontal duct for combustion product removal and air intake ø80-125 (type C13)

Combustion product removal and air intake can be made using concentric Ø80 mm pipes for combustion product removal and Ø125 mm pipes for air intake, using the 1m Ø80-125 horizontal outlet kit, code CGAS000189.

The maximum length in a horizontal direction from the boiler, including the kit terminal, is 8 metres (TRO Evolution 20 BH) and 6 metres (TRO Evolution 30 BH). Each 90° elbow, or two 45° elbows, will reduce the available length by 1 metre.

It is recommended to fit the pipe in a slightly upwardly-inclined directi on, at around 2º - 3º, to prevent any water or condensation from dripping out.

Coaxial 90º bend 80/125

Code CGAS000182

1m Horizontal duct kit 80/125

Code CGAS000189

1m coaxial tube 80/125

Examples of installation:

L  8 mt s . (TR O Evolution 20 BH) L  6 mt s . (TR O Evolution 30 BH)

Code CGAS000184

Coaxial 45º bend 80/125

Code CGAS000183

page -12

5.5.- Concentric vertical duct for combustion product removal and air intake ø80-125 (type C33)

The evacuation of the combustion products and the air intake may be accomplished by using Ø80 mm concentric tubes for the ev acuation of combustion products and Ø125 mm for the air intake, using the vertical output Ø80-125 Kit, code CGAS000231.

The maximum length in a vertical direction from the boiler, including the kit terminal, is 10 metres (TRO Evolution 20 BH) and 7 metres (TRO Evolution 30 BH).. Each 90° elbow, or two 45° elbows, will reduce the available length by 1 metre.

45º bend 80/125

Code CGAS000183

90º bend 80/125 Code CGAS000182

1m coaxial tube 80/125

Code CGAS000184

ertical duct kit 80/125

Code CGAS000231

Examples of installation:

Black tile 80/125

Code CGAS000074

L  10 mts. TRO Evolution 20 BH

L  7 mts. TRO Evolution 30 BH

Black tile 80/125

Code CGAS000075

page -13

6.- OPERATION

6.1.- Boiler functioning

Set the control thermostat and the room thermostat (if applicable) to the desired temperature. Move the main switch to the "I" position and the summer-winter switch to the Winter position "". The burner and the pump will begin to function until the installation reaches the pre-selected temperature of the control thermostat (or the room thermostat, if the unit has one). When the temperature in the installation drops, the burner will start up again, running the heating cycle.

6.2.- Operating with a Sanit hot water tank (optional)

The TRO Evolution BH boiler may be installed together with a hot water tank from the TRIANCO Sanit range, to obtain domestic hot water. For correct hydraulic installation,

carefully follow the assembly and connection instructions enclosed with the hot water tank. The boiler is provided with a switch to select summer position or winter position. Using this

switch we may choose:

- Summer Position ☼: in this position, the boiler only attends to the needs of DHW

production, lighting the burner and the hot water tank loading pump (summer pump) until the accumulated DHW temperature reaches the regulated temperature in the thermostat of the hot water tank. When the DHW temperature is reached, the burner and the summer pump will stop.

- Winter Position : in this position, the boiler attends to the needs of DHW and the heating

system, giving priority to DHW.

7.- SAFETY CUT-OUTS

The boiler has three types of safety cut-outs:

7.1.- Excessive temperature safety cut-outs (Thermostat TS)

This cut-out is indicated by the pilot light for blocking due to temperature. This occurs when the boiler exceeds a temperature of 110ºC. To restart, press the button on the safety thermostat after first removing the button cover.

7.2.- Excessive fume temperature safety cut-out (Thermostat TH)

This cut-out is indicated by the pilot light for blocking due to temperature. This occurs whenever the temperature of the fumes exceeds 110ºC. To restart, press the button on the safety thermostat after first removing the but ton cover.

7.3.- Burner cut-out

This cut-out is indicated by the pilot light for blocking of the burner. This occurs as a result of an anomaly in the burner or in the fuel installation. To unblock it, press the illuminated button that lights up on the burner.

NOTE: If any of these cut-outs occur repeatedly, call your nearest official Technical Assistance Service.

page -14

8.- CLIMATE CONTROL (OPTIONAL) :

The TRO Evolution BH boiler comes prepared for the installation of a Lago BVS climate control system.

B: Action on burner. V: Action on mixing valve. S: Action on domestic water.

The operating instructions and electrical connections are found in the packaging of the boiler.

9.- SHUTTING DOWN THE BOILER

To stop the boiler, simply turn the master switch to "O". To stop the central heating mode and leave only the DHW mode running, set the general

switch to the summer position "☼".

10.- START-UP

Before beginning the start-up process of the boiler, check that:

- The boiler is connected to the mains.

- The installation has been filled with water (the manometer should indicate a pressure of 1

- 5 bar).

- The fuel reaches the burner.

- The isolation valves are open, if there are any installed.

- The room thermostat is set to the desired temperature.

- The boiler room has effective and free ventilation (ventilation based on 0.5 dm

minimum).

To start-up the boiler, position the main switch and the room thermostat to the desired temperature.

2

11.- FIRST START-UP

For the guarantee to be valid, the boiler must be started up for the first time by an official TRIANCO Technical Assistance Service. Before beginning the start-up process, the following

must be complied with:

- The boiler must be connected to the mains.

- The installation must have been filled with water (the manometer should indicate a

pressure of 1 - 5 bar).

- The fuel must be reaching the burner at a pressure of no more than 0.5 bar.

page -15

12.- DELIVERY OF THE SYSTEM

After the initial start-up, the Technical Assistance Service will explain to the user how the boiler functions, making any observations they consider relevant.

The installer is responsible for clearly explaining to the user the functioning of any control or regulation device forming part of the installation but not supplied with the boiler.

13.- BOILER MAINTENANCE

To maintain the boiler in perfect working order, a yearly service should be performed by personnel authorised by TRIANCO.

13.1.- Cleaning the boiler

To maintain the boiler in optimal operating conditions it is recommended that an annual cleaning be undertaken of the combustion chamber, the fume outlets and the condenser. A cleaning brush of a suitable size for cleaning the inside of the exhaust ducts i s supplied with the boiler for this purpose. This brush is located at the rear of the boiler, beside the condenser.

The combustion chamber and exhaust ducts should not be cleaned using chemical products or hard steel brushes. After any cleaning operation has been carried out, it is important to

run several ignition cycles to check all the elements are functioning correctly. For correct cleaning, the following recommendations should be carefully observed:

Cleaning the boiler body

- Open and remove the outer door of the boiler.

- Remove the burner by unscrewing the fixing nut on the top of the burner.

- Remove the combustion chamber door and the exhaust duct cover, unscrewing the six

fixing nuts around them.

- Clean the exhaust ducts on the cast body, using the cleaning brush supplied with the

boiler.

- Clean the boiler combustion chamber. We recommend using a soft brush for scrubbing

the combustion chamber surfaces, and a blower to remove the flakes.

- After cleaning, replace the combustion chamber door, the exhaust duct cover, the

burner and the outer door of the boiler.

Cleaning the condenser

- Open and remove the top cover of the boiler to access the condenser on the rear of the

boiler body.

- Open the top cover of the condenser to access its exhaust ducts. To open this cover,

release the two side closures, turn the locking plate anti-clockwise and pull the cover upwards to remove it.

- Remove the exhaust deflectors inside the exhaust outlets.

- Clean the exhaust ducts using the cleaning brush supplied with the boi ler. Any scale will

fall through the condensation drain and onto the lower condenser cover. It is advisable

page -16

to pour water into the top of the condenser for a more effective cleaning. This water will be automatically discharged through the condensation drain.

- To clean the outer part of the condenser cylinder, remove the three screws and then

remove the metal ring. Take out the seal and use the brush to clean it. Next, put the components back in place again and replace and tighten the three screws and the metal ring.

- If the lower condenser cover needs cleaning, remove the side cover of the boiler to

access it. Firstly remove the bracket holding it in place and pull on it to open it. Then pull the lower cover down to open and clean it.

- After cleaning, replace the fume deflectors, the top condenser cover and the top outer

cover of the boiler. Then put the cleaning brush back inside the boiler.

- The condensation siphon should be cleaned once a year. To do this, remove it and wash

it in soapy water. Replace the siphon after cleaning.

1

2

3 4

5 6

7

8

9

Cleaning brush

13.2.- Boiler water characteristics

In areas with water hardness over 25-30ºF, treated water must be used in the heating installation to avoid any lime scale deposits on the boiler. It should be noted that even a few millimetres of scale will greatly reduce the boiler's heat conductivi ty, causing a major drop in performance.

Treated water must be used in the heating circuit in the following cases:

- Very large circuits (containing a large amount of water).

- Frequent filling of the installation.

If repeated partial or total draining of the installation is necessary, we recommend filling it with treated water.

page -17

13.3.- Condensate drain-off

The drain for boiler condensate must not be altered and must be kept clear of obstructions. Annual maintenance of the condensate trap is recommended to avoid obstructions that hinder the discharge.

If a neutralisation system is installed i n the condensate drain, it is essent ial to conduct annual maintenance of the system, following the instructions of the manufacturer of the neutralisation system.

Fit the siphon, supplied in the documentation bag, as per the image

page -18

14.- TECHNICAL CHARACTERISTICS

TRO EVOLUTION BH 20 30

condensing

Boiler type -

Heating only Rated heat output P Useful heat output P4 Useful heat output (30%) P1 Seasonal energy efficiency of heating

kW 19 30

rated

kW kW

Ƞ

%

S

% (PCI)

19.0 28.7

6.1 8.5 90 91

96.55 97.96

Useful efficiency Ƞ4

% (PCS)

% (PCI)

91.04 92.38

103.82 103.45

Useful efficiency (30%) Ƞ1

Auxiliary electricity consumption at full load el Auxiliary electricity consumption at part load el

max

min

Auxiliary electricity consumption in standby mode PSB Heat loss in standby mode P

stby

Emissions of nitrogen oxides NOx

% (PCS)

mg/kWh

kW kW kW kW

97.90 97.55

0.226

0.078

0.001

0.127 0.135 92 118

Heating temperature regulation ºC 60 - 85 Maximum safety temperature ºC 110 Maximum operating pressure of heating bar 3 Heating expansion vessel capacity Lts 8 8 Heating water volume Lts 14 19.2 Water pressure drop mbar 96 163 Fume temperature ºC Volume on fume side m3 Maximum fume flow Kg/s Pressure drop of the fumes mbar Combustion chamber length mm Combustion chamber type -

69

0.094

0.0085

0.20 220

67

0.114

0.0132

0.20 300

wet + three exhaust ducts

Type of burner adjustment - ON/OFF Electrical supply - ~220-230 V - 50 Hz - 200 W Gross weight Kg 122 155

page -19

y

V

y

g p

15.- ELECTRICAL DIAGRAM

White

C

O/I

PON

1a

1

White

Brown

Red

PT

TC

1

Pink

C

TS

2b 2a

I

2

Gre

Brown

Yellow

C

21

T

1

PB

Black

Brown

1 2 3 4 5 6 7 8 9 10 11

HUM

2

X12

Brown

Orange

Black

Purple

C

TF3

21

White

Gre

Pink

Blue

Red

1

2

3

4

5

6

7

8

9

10

11

12

Brown

e

Oran

Brown

le

Pur

Blue

Black

Brown

Pink

Gre

Black

Green

12 13 14 15 16 17 18 19 20

220 V

Ph N

TA

Blue

Q

Black

bc7

Blue

BV

B: Burner. BV: Summer pump. BCM: Mixed circuit pump. BCD: Direct circuit pump M: Motor valve. O/I: Main on/off switch. V/I: Summer-Winter switch TA: Air thermostat. TC: Control thermostat (in boiler).

T

: Fume safety thermostat

HUM

BCD

Black Black

Blue

Black

Tacs

Blue

C

Brown

NONC

BCM

N

+-

M

TS: Safety thermostat (in boiler). TF3: 93º Anti-inertia thermostat (in boiler). Tacs: DHW thermostat. PON: "ON" pilot light. PB: Burner blocked pilot light. PT: Temp blocking pilot light. X12: 12 pole connector for climate

control (optional).

bc7: Terminal no.7 burner control.

page -20

16.- DIAGRAMS AND MEASUREMENTS

IC: Heating flow. RC: Heating Return. V: Drain valve SH: Fume exhaust duct, Ø100. SC: Condensate outlet, 1" H. EA: Combustion air intake, Ø80.

MODEL DC, RC L

TRO Evolution 20

BH

TRO Evolution 30

BH

3/4”M

1”M

540

640

page -21

17.- BURNER

17.1.- Assembly

Secure the burner support to the boiler. then fix the burner to the support. This will allow the correct tilt of the flame tube towards the combustion chamber. Fit the intake and return pipes.

17.2.- Burner start-up

First place a manometer and a vacuum gauge and prepare the combustion analyser. The "Domestic" burner is equipped with a self-extracting pump to enable fuel intake from a

tank installed at a lower level than the burner, providing that the pressure difference measured with the vacuum gauge at the pump does not exceed 0.4 bar (30 cmHg).

Make sure there is fuel in the tank, that the oil valves are open and that voltage is reaching the burner. Turn on the master switch. Unscrew the air bleed screw (manometer point). Then, when the valve opens, remove the photocell sensor and move i t towards a light source until the oil comes out. Disconnect the burner and screw the bleed screw back in.

17.3.- Adjusting the combustion conditions

As each particular installation has a different combustion circui t, it is essential to adjust the combustion conditions of each boiler. In order for the guarantee to be valid, the burner must be adjusted by an official TRIANCO Technical Assistance Service.

Observe the flame. If there is insufficient combustion air, it will be dark in colour and will produce smoke, rapidly obstructing the flue outlet.

On the contrary, if there is an excess of combustion air, the flame will be whitish or bluishwhite in colour. This will reduce the performance of the boiler and it will fail to comply with anti-pollution standards, and the excess air may also hinder the ignition process.

The flame should be orange in colour. If the shape of the boiler makes it difficult or i mpossible to observ e the flame, the combustion

air flow can be regulated by observing the smoke comi ng out of th e flue. If the smoke is dark in colour, more air will need to be provided to the burner, or if it is a very whitish colour, the air in the burner will need to be decreased until no smoke at all is observed.

If you have a device for determining t he composition of the combustion gases, this will be the best guide for flame adjustment. If not, simply follow the above indications.

To adjust the air and burner line conditions, carefully follow the instructio ns given below.

page -22

17.4.- Primary air adjustment

To adjust the primary combustion air, turn

0

10

the screw using a 6 mm. Allen key, as shown in the diagram. Turn it clockwise to increase the airflow, and anticlockwise to decrease it.

17.5.- Combustion line adjustment

To adjust the combustion line, loosen the combustion line blocking screw "BL". Turn the line regulator "RL" clockwise to increase the airflow and anticlockwise to decrease it. After adjustment, tighten the combustion line blocking screw "BL".

+

RL

1

0

BL

3 mm

17.6.- Correct position of electrodes

To ensure correct ignition of the "Domestic" burner, the measurements shown in the diagram must be observed. Also ensure the electrode fixing screws have been screwed in place before replacing the flame tube.

3 mm

2/3 mm

page -23

17.7.- Oil pressure adjustment

To adjust the oil pump pressure, turn the screw (1) clockwise to increase the pressure, and anticlockwise to decrease it.

1 - Pressure adjustment.

SUNTEC - MOD. AS47C K

DANFOSS - MOD. BFP 21 L3

2 – Vacuum gauge point. 3 - Valve. 4 - Manometer point. 5 - Nozzle outlet. 6 - Return.

3

2

1

4

5

1

3

4

5

2

7 - Intake.

6

7

17.8.- O Pipe operation

SUNTEC

Note: The screw is supplied in the bag with the documentation

17.9.- il supply piping diagrams

DANFOSS

2-Pipe operation:Screw (A) fitted. 1-Pipe operation: Without screw (A)

The diagrams and tables below correspond to installations without reductions and with a perfect hydraulic seal. It is recommended to use copper pipes. A pressure drop of 0.4 bar (30 cmHg) must not be exceeded (reading via a vacuum gauge).

page -24

Intake installation

H

Charging installation

H

Intake installation

H Pipe length

(m)

0.0 25 60

0.5 21 50

1.0 18 44

1.5 15 38

2.0 12 26

2.5 10 26

3.0 8 20

3.5 6 16

int 8 mm. int 10 mm.

Charging installation

H Pipe length

(m)

0.5 10 20

1.0 20 40

1.5 40 80

2.0 60 100

int 8 mm. int 10 mm.

Warning: Check periodically conditions of the flexible pipes. Using kerosene, the flexible pipes must be replaced at least every 2 years.

17.10.- Technical specifications

MODEL D-3 D-4 Minimum consumption Kg/h

Maximum consumption Kg/h Minimum power kW Maximum power kW

Fuel

Gas oil 35 sec max. viscosity 6 mm Kerosene 28 sec

Motor power at 2800 r.p.m. W Adjustment type Electric current Weight Kg Preheater

1,5 2,3

3 4,65 17,7 27,2 35,5 55,2

2

/s at 20ºC

200

On/Off

220 V - 50 Hz

12,5

YES

page -25

17.11.- Operating curves

mmH

2

O

15

10

OVERPRESSURE / FLOW

D-3

5

1

10200

11.8 23.72 47.44 35.58 59.3 Kw

2 3 4 5

20400 30600 40800 51000

D-4

Kg/h

Kcal/h

17.12.- Recommended nozzle and pump pressure

TRO Evolution BH boilers are supplied with the burner fitted, with th eir corresponding nozzle and with the standard pre-adjustment. The following table shows the nozzles and adjustments for each particular model:

MODEL Nozzle

TRO Evolution 20 BH TRO Evolution 30 BH

0.45/ 80º H 10 7 1

0.65/ 60º H 10 3,5 1

Burner pressure

(bar)

Air adjustment Line adjustment

17.13.- Oil flow versus nozzle and pump pressure

Nozzle

Kg/h

GPH

9 bar 10 bar 9 bar 10 bar

0,45 1,58 1,67 1,4 1,5 0,65 2,29 2,42 2,02 2,17

Oil

Kerosene

Kg/h

page -26

17.14.- Electrical connection diagram

1 2 5 6 8 10 11 123

4

MB EV1



B4 S3T2T1 N L1

EV2

7

Black

Brown

IG

F

TP

RP

Blue

Preheater

LB

FR

TR

TC

TS

B4: Hour meter contact. S3: Cut-out pilot light contact: TC: Control thermostat (in boiler).

TS: Safety thermostat (in boiler). CH: Hour meter. IG: Main on/off switch. F: Fuse. LB: Pilot light. LB': External cut-out pilot light.

Ph

N

LB'

CH

FR: Photocell.

TR: Transformer.

MB: Motor pump. EV: Valve. RP:Preheater element. Ph:Phase. N: Neutral. TP : Preheater thermostat.

page -27

17.15.- Quick connector

To connect and disconnect the red oil intake tube to the nozzle, proceed as follows:

- Press the connector ring in the direction of t he arrow, pulling on the red t ube at the same

time.

RED PIPE

PUSH

OIL

RING

QUIC K CONNEC T FITTING

page -28

17.16.- Burner control operating sequence

The burner's LMO14 control box has a reset button "EK", which is the key element for resetting the burner control and activating/deactivating the diagnostic functions. The multi-colour LED on the reset button is the indicator for visual diagnosis. The "EK" button and the LED are located under the transparent cover of the reset button. During normal functioning, the various operating statuses are indicated in the form of colour codes (see the colour code table below). During ignition, the indication is as shown in the following table:

Reset button

If the button is on, press to reset. If the button stays on, call the Te chnical Assistance Service.

page -29

18.- TROUBLESHOOTING

This section provides a list of the most common burner and boiler failures.

18.1.- Burner error code

We have already mentioned that the burner is equipped with a cut-out system, indicated by the reset button light. It may cut out accidentally, and in this case the steady red light on this button will come on. You may unblock it by pressing the button for approx. 1 second. When the burner is blocked and the steady red light is on, visual failure diagnosis may be activated, in accordance with the error code table. To enter visual failure diagnosi s mode, hold down the reset button for at least three seconds.

Error code table

Red flashing LED code "AL" on term.

10

Flashes 4 times On No flame established when ignition safety time ends.

Flashes 4 times On External light during burner ignition Flashes 7 times On Excessive flame loss during functioning (limited number of

Flashes 8 times On Supervision of fuel pre-heater time Flashes 10 times On Cabling fault or internal failure, output contacts, other

Possible cause

- Fuel valves defective or dirty

- Flame detector defective or dirty

- Burner maladjustment, no fuel

- Ignition unit defective

repetitions)

- Fuel valves defective or dirty

- Flame detector defective or dirty

- Burner maladjustment

failures

During the failure diagnosis time, the control outputs are disabled and the burner remains off. To exit failure diagnosis and activat e the burner again, reset the burner control. Hold down the reset button for approx. 1 second (<3 s).

18.2.- Boiler failures

FAILURE CAUSE SOLUTION

- The pump is not turning Unblock the pump

RADIATOR

DOES NOT HEAT

UP

EXCESSIVE

NOISE

- Air in hydraulic circuit

- Burner badly adjusted Correctly adjust it

- Flue not correctly sealed Eliminate any leaks

- Flame unstable Examine the burner

- Flue not insulated Suitably insulate it

Drain the installation and the boiler (the automatic air bleed valve cap must always be loose)

page -30

18.3.- Thermostat

Boiler temperature safety thermostat (TS)

Fumes temperature safety thermostat (TH)

If the boiler goes into safety lockout due to overheating of the boiler (TS) or fumes (TH), reset by pressing the appropriate button on the thermostat. To access the buttons, unscrew the black cap.

page -31

19.- SPARES LIST

19.1.- Burner

16

18

19

20

21

Pos. Code Description

1

CTOR000006 Straight connector

2

CTOE000054 Line adjustment nut

3

CFER000032 Cable duct

4

CEXT000720 D4 end cover

5

CQUE000156 Siemens Photocell

(Jaka FD 30 Condens)

CQUE00050 Red Brahma Photocell

(Jaka FD 20 Condens)

6

CQUE000149 Photocell support

7

CQUE000054 Suntec valve coil cable CQUE000124 Danfoss valve coil cable

8

CQUE000089 Danfoss valve coil

9

CQUE000062 Suntec oil pump CQUE000088 Danfoss oil pump

10

CTOR000007 Elbow connector

11

CQUE000004 Pump motor coupling

12

CQUE000102 Motor

13

CTOE000065 Counter thread

14

CQUE000191 Oil hose

15

CQUE000169 LMO14 Control box

16

CQUE000005 Transformer

17

CQUE000129 LMO14 Control box base

23

22

25

24

26

17

15

14

13

11

28

29

27

30

31

32

33

12

Pos. Code Description

18

CQUE000173 Flange seal

19

SATQUE0001 Flange

20

CQUE000158 Flange support

21

Canon D4 silencer Ø54 (Jaka FD

20 Condens)

Canon D4 silencer Ø84x25 (Jaka

FD 30 Condens)

22

CQUE000018 Manifold

23

CQUE000151 D4 air regulating plate

24

CTOE000064 Air adjustment screw

25

CEXT000719 Air adjustment support

26

CQUE000044 Fan

27

CEXT000718 Motor support

28

CQUE000019 Set of electrodes

29

CQUE000155 Turbulator disc

30

CQUE000192 Nozzle OD-H 0.45-80º(Jaka FD 20

Cond.)

CQUE000077 Nozzle OD-H 0.65-60º(Jaka FD 30

Cond.)

31

CQUE000061 Preheater

32

CQUE000027 Pre-heater cable

33

CTOE000063 D4 burner line

34

CFER000033 Cable duct

34

10

9

8

7

6

5

4

3 2

1

page -32

19.2.- Boiler

7

8

9 11 1210 1413

3

1

2456

page -33

19.3.- Fron Electrics

22

23

24

21

20

Pos. Code Designation

1

GELEJAF003 Electrical board

2

TQDFPJ0005 Burner Jaka FD 20 Condens TQDFPJ0006 Burner Jaka FD 30 Condens

3

SEPO002302 Front panel

4

CFER000051 Extraflex burner tube

5

SEPO002307 Left side Jaka FD 20 Condens SEPO002325 Left side Jaka FD 30 Condens

6

SEPO002308 Left side cover

7

SEPO002305 Rear cover

8

SEPO002304 Rear

9

GCHAEV0010 Condenser Ø100

10

CFOV000024 Drain valve

11

SEPO002310 Top Jaka FD 20 Condens SEPO002326 Top Jaka FD 30 Condens

12

SEPO002306 Right side Jaka FD 20

Condens

SEPO002324 Right side Jaka FD 30

Condens

13

Rigidity

19

18

25

17

16

15

Pos. Code Designation

14

SEPO002309 Right side cover

15

CELEC000175

16

CELC000040 Amber pilot light

17

CELC000137 Manometer

18

CELC000178 Panel cover

19

CELC000171 Control panel

20

CELC000007 Control thermostat (TC)

21

CELC000034 Thermostat 93º (TF3)

22

MGALPL0006 Control box fastener

23

CELC000042 Weidmuller 12-pole terminal

24

CELC000022 Safety thermostat 110º (TS)

25

CELC000136 Thermometer

26

CELC000176 Dial

27

CELC000138 Small bipolar switch

28

CELC000039 Red pilot light

Control panel cover

strip

Fumes safety thermostat (TH)

26

27

28

page -34

NOTES:

..............................................................................................................................................................................................................

page -35

TR ENGINEERING LTD

Thorncliffe, Chapeltown,

Sheffield, S35 22PH

Tel: (0114) 2572300

Fax: (0114) 25714199

www.trianco.co.uk

Copyright in this brochure and the drawings and illustrations contained within are vested in TR Engineering

Ltd and neither the brochure or any part thereof may be reproduced without prior writen consent.

TR Engineering’s policy is one of conitnous reserarch and development. This may necessitate alterations to

this specification. Instructions correct at time of going to print.

*CDOC001622*

CDOC001622

04/17

Trianco TRO EVOLUTION BH Installation And Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
