T-Rex WHIRLY VERB User Manual

WHIRLY VERB
USER MANUAL
CONGRATULATIONS
on your purchase of Whirly Verb, a sweet-sounding reverb unit that also lets you get experimental with your sound.
Whirly Verb gives you an incredibly warm, rich small hall reverb that’s specially tuned for the electric guitar. You can shape your reverb by con­trolling the decay time – and you can warp it to create all kinds of thick, layered sounds.
Take a quick look at the overview of controls in this user manual to familiarize yourself with Whirly Verb and its surprising capabilities.
TECHNICAL SPECIFICATIONS
Input Impedance @ 1KHz Higher than 1M Ohm
Output Impedance @ 1KHZ Lower than 1K Ohm
Power supply 9V DC (T-Rex FuelTank)
Minimum Power supply Voltage 8,5V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 90 mA
Maximum Input signal Vp/p 2Vp/p
Battery Type 9 V battery 6F22
Battery Life 30 to 60 min.
External connectors Input Jack, Output Jack, 9V DC Jack
Controls On/Off, Volume, Reverb, Modula-
tion, Decay
Pedal size incl. knobs (W x H x D) 100 x 55 x 120 mm
3,9 x 2,2 x 4,7 inch
Weight excl. battery and packaging 0,335 kg / 11,8 oz
WHIRLY VERB CONTROLS
Your Whirly Verb features 4 separate controls, plus a MODULATON but­ton to activate the modulation effect.
The REVERB knob lets you adjust how heavy a reverb effect you get, while the DECAY knob determines the length of your reverb trail. Turn these controls up to simulate a large concert hall or other large space, and down to get a smaller club or room effect.
The LEVEL knob is used to set the overall output volume from your Whirly Verb pedal. At 12 o’clock your output is the same as your input volume.
The MODULATION button and control knob let you turn your Whirly Verb into an effect that’s much more dynamic and unusual than an ordi­nary reverb pedal. It can do everything from adding a slight lilt to your sound to creating weird, psycho effects that will take your guitar into another dimension.
The more you experiment with your Whirly Verb, the more you’ll zero in on the reverb sounds that are perfect for your personal style.
T-REX WARRANTY CONDITIONS
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a malfunction, please contact our technical support at info@t-rex-eects.com before sending us the product for repair. When the product has been sent to us at sender’s cost, we will repair or replace your product and send it back to you - free of charge and usually within 3 weeks (shipping not included). The product needs to be accompanied by a copy of your receipt, serial number, return address, phone number, e-mail address and a brief explanation of the problem. Please note that we cannot replace a product until we have received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse, accident, or neglect; or if the product has been repaired or serviced by persons not authorized by T-Rex. Read more about warranty conditions at www.t-rex-eects.com.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and sig­nature eects pedals for the world’s best musicians. Our approach blends hi-tech innovation with old-world craftsmanship – always in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We nd these environment protecting regulations very good, and we are happy to follow them.
RoHS
REACh
T-Rex Engineering ApS
www.t-rex-eects.com
Steen Meldgaard Laursen
Managing Director
ISSUED IN VEJLE, 2011
Lars Dahl-Jørgensen
Development Director
Sebastian Jensen
Production Director
