USER MANUAL
TREMSTER
CONGRATULATIONS
on your purchase of Tremster, a full-featured tremolo that imitates
the buttery , secuctive tone from a vintage tube amp tremolo/vibrato.
Tremster is a masterpiece of simplicity. Its only controls are Depth,
Speed, Volume & Mode.
Turn the page to see how to work the controls.
TREMSTER CONTROLS
MODE allows you to switch between tremolo and vibrato ef-
fect. The tremolo effect works like a repeatedly radical change
in volume. The vibrato effect has a more subtle volume change.
DEPTH controls the depth of the volume-oscillation.
VOLUME sets the overall volume. In mid-position (twelve
o’clock) the volume level is 1:1. When turned full over (clockwise) the input signal is boosted 15dB.
SPEED determines the oscillation speed.
TECHNICAL SPECIFICATIONS
Input Impedance@1KHz
Output Impedance@1KHZ
Power supply 9V DC (FuelTank)
Minimum Power supply Voltage 8V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 7 mA
Maximum Input signal Vp/p 1,7Vp/p
Battery Type 9 V battery 6F22
Battery Life 12 to 16 Hour
External connectors Input Jack, Output Jack, 9V DC Jack
Controls On/Off, Volume, Speed, Depth, Mode
Higher than 1M Ohm
Lower than 1K Ohm
Pedal size incl. knobs (W x H x D) 100 x 55 x 120 mm
3,9 x 2,2 x 4,7 inch
Weight excl. battery and packaging 0,450 kg / 15,9 oz
RoHS
T-REX WARRANTY CONDITIONS
ABOUT T-REX
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a
malfunction, please contact our technical support at info@t-rex-eects.com
before sending us the product for repair. When the product has been sent to
us at sender’s cost, we will repair or replace your product and send it back to
you - free of charge and usually within 3 weeks (shipping not included). The
product needs to be accompanied by a copy of your receipt, serial number,
return address, phone number, e-mail address and a brief explanation of
the problem. Please note that we cannot replace a product until we have
received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse,
accident, or neglect; or if the product has been repaired or serviced by
persons not authorized by T-Rex. Read more about warranty conditions at
www.t-rex-eects.com.
Based in Vejle, Denmark, T-Rex Engineering makes classic and signature eects pedals for the world’s best musicians. Our approach
blends hi-tech innovation with old-world craftsmanship – always
in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued
by the EU. We nd these environment protecting regulations very
good, and we are happy to follow them.
REACh
ISSUED IN VEJLE, 2002
Lars Dahl-Jørgensen
Development Director
Sebastian Jensen
Production Director
T-Rex Engineering ApS
www.t-rex-eects.com
