User manual
ToneBug
Reverb
CONGRATULATIONS
on your purchase of Reverb, part of a brand new series of greatsounding, pared-down pedals from T-Rex Engineering.
Reverb helps bring your sound to life by putting you up on the
stage. And we mean any stage – from a steamy blues club to a huge
outdoor stadium. No matter what settings you choose, though, you
can count on Reverb to sound great and give you all the incredible
tone you’d expect from a T-Rex pedal.
Using your Reverb is easy and intuitive. Just turn the page to get
started.
READY, SET, GO!
Using your ToneBug Reverb
Insert a 9 Volt alkaline battery or connect the pedal to one of the
T-Rex FuelTank power supplies (not included).
This pedal accepts both 9 and 12 Volt DC (see technical specs).
Plug your guitar into the INPUT jack, and run a lead from the OUTPUT jack into your amp.
Set the mode switch to MODERN for a contemporary reverb sound
or SPRING, for a more retro sound.
Adjust the DECAY setting to determine how long your reverb will
last, and the DEPTH setting to determine how “heavy” it will be.
TECHNICAL SPECIFICATIONS:
Input Impedance @ 1KHz Higher than 1 M Ohm
Output Impedance @ 1KHz Lower than 1 K Ohm
Power supply 9V DC
Minimum Power supply Voltage 8V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 75 mA
Maximum input signal Vp/p 2,5 Vp/p
Battery Type 9V battery 6F22 Alkaline
Battery Life 0,5 to 1 Hours
External connectors Input Jack. Output Jack, 9V DC Jack (center
pin negative)
Controls On/O, Decay, Modern/Spring, Depth
Depth 120 mm
Width 78 mm
Height 60 mm
Weight (excl. battery) 0,404 Kg
SAMPLE SETTINGS:
Simple Spring
MODE: SPRING
DECAY: 8 o’clock
DEPTH: 12 o’clock
Hot Rod
MODE: SPRING
DECAY: 1 o’clock
DEPTH: 5 o’clock
Medium Hall
MODE: MODERN
DECAY: 11 o’clock
DEPTH: 10 o’clock
Stadium Rock
MODE: MODERN
DECAY: 2 o’clock
DEPTH: 10 o’clock
T-REX WARRANTY CONDITIONS
T-Rex offers a 2-year warranty on all our products. In the unlikely event of a malfunction,
please contact our technical suppor t at info@t-rex-effects.com before sending us the product
for repair. When the product has been sent to us at sender’s cost, we will repair or replace
your product and send it back to you - free of charge and usually within 3 weeks (shipping
not included). The product needs to be accompanied by a copy of your receipt, serial number, return address, phone number, e-mail address and a brief explanation of the problem.
Please note that we cannot replace a product until we have received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse, accident, or
neglect; or if the product has been repaired or serviced by persons not authorized by T-Rex.
Read more about warranty conditions at www.t-rex-effects.com.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and signature effects pedals for the
world’s best musicians. Our approach blends hi-tech innovation with old-world craftsmanship – always in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We find these
environment protecting regulations very good, and we are happy to follow them.
ISSUED IN VEJLE 2009
Steen Meldgaard Laursen
Managing Director
Lars Dahl-Jørgensen
Development Director
T-Rex Engineering ApS
www.t-rex-eects.com
Sebastian Jensen
Production Director
