User manual
ToneBug
Booster
CONGRATULATIONS
on your purchase of Booster, part of our Tonebug series of eect
pedals that combine gorgeous T-Rex tone, cool retro design, and
aordable pricing.
Booster is the perfect solution for making sure your solos and
single-note lines are loud enough – without having to sacrice tone
on your rhythm parts or adjust your amp while you’re on stage.
With just a BOOST control and a subtle, tone-shaping SCOOP
control, Booster is one of the simplest pedals we make. But it’s one
you’re nd yourself using constantly.
To make sure you get the most out of your Booster, be sure to read
this brief user manual before getting started.
Enjoy!
ONE-STOMP VOLUME...
HOW IT WORKS
Using your Booster
1. Insert a 9V alkaline battery or connect to an electrical outlet using
a T-Rex Fuel Tank power supply (not included).
2. Plug your guitar into the INPUT jack, and run a lead from the
OUTPUT jack into your amp.
3. Use the BOOST knob to determine how loud you’d like your
boosted signal to be (set by comparing with your non-boosted
volume).
4. Try using the SCOOP knob to adjust the tone of your boosted
signal. This can help you cut through the mix in more subtle ways
than just increasing volume.
Your natural tone at any volume
Booster is as much about protecting your rhythm tone as turning up
the volume on your leads. A replacement for adjusting the volume
knob on your guitar, Booster lets you play rhythms at full volume –
and optimal tone – and then boost that same great sound when you
play leads or single-note rhythm parts.
What’s the SCOOP?
SCOOP is a control that alters the way your sound it equalized by
boosting the midrange frequencies while keeping your highs and
lows the same. Louder mids can help you cut through the mix using
tone or a combination of tone and volume instead of volume alone.
TECHNICAL SPECIFICATIONS:
Input Impedance @ 1KHz Higher than 1 M Ohm
Output Impedance @ 1KHz Lower than 1 K Ohm
Power supply 9V DC
Minimum Power supply Voltage 8,5V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 25 mA
Maximum input signal Vp/p 3,2 Vp/p
Battery Type 9V battery 6F22 Alkaline
Battery Life 8 to 12 Hours
External connectors Input Jack. Output Jack, 9V DC Jack (center
pin negative)
Controls On/O, Booster, Scoope
Depth 120 mm
Width 78 mm
Height 60 mm
Weight (excl. battery) 0,404 Kg
T-REX WARRANTY CONDITIONS
T-Rex offers a 2-year warranty on all our products. In the unlikely event of a malfunction,
please contact our technical support at info@t-rex-effects.com before sending us the product
for repair. When the product has been sent to us at sender’s cost, we will repair or replace
your product and send it back to you - free of charge and usually within 3 weeks (shipping
not included). The product needs to be accompanied by a copy of your receipt, serial number, return address, phone number, e-mail address and a brief explanation of the problem.
Please note that we cannot replace a product until we have received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse, accident, or
neglect; or if the product has been repaired or serviced by persons not authorized by T-Rex.
Read more about warranty conditions at www.t-rex-effects.com.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and signature effects pedals for the
world’s best musicians. Our approach blends hi-tech innovation with old-world craftsmanship – always in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We find these
environment protecting regulations very good, and we are happy to follow them.
ISSUED IN VEJLE 2011
Steen Meldgaard Laursen
Managing Director
Lars Dahl-Jørgensen
Development Director
T-Rex Engineering ApS
www.t-rex-eects.com
Sebastian Jensen
Production Director
