T-Rex The Sweeper User Manual

USER MANUAL
SWEEPER
CONGRATULATIONS
on your purchase of The Sweeper, our classic chorus pedal for the bass guitar.
The Sweeper is a premium-quality chorus pedal custom engineered for the BASS ONLY. This means that no matter what rate or depth you set, you’ll get a phenomenal-sounding chorus effect – in stereo. The Sweeper is intuitively designed and easy to use. Just turn the page to get started.
BACK TO BASSICS
The Sweeper has everything you need to get the full range of classic bass chorus sounds – using just a few simple controls.
DEPTH controls the amount of chorus effect. Turn it down for a subtle
chorus, crank it up for that great full sweep.
Use the R ATE control to set the speed of your sweep. A fast rate com­bined with a low depth level gives you a light shimmering sound, while the slower rate and higher depth creates a dramatic chorus effect.
VOLUME controls the overall output of The Sweeper, and the INPUT
LEVEL on the side of the unit helps you avoid overdrive distortion by
turning down the input signal. If the red overload light comes on, the input level is too high.
Note: If you’re in the studio or have a stereo live setup, try using The Sweeper’s stereo outputs for a truly mind-blowing stereo chorus!
TECHNICAL SPECIFICATIONS
Input Impedance@1KHz 470 KOhm
Output Impedance@1KHZ 35 Ohm
Power supply 9V DC (Power tool 9)
Minimum Power supply Voltage 8,5V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 90 mA
Maximum Input signal Vp/p Adjustable
Battery Type 9 V battery 6F22
Battery Life 30 - 60 min.
External connectors Input Jack. Output Jack, 9V DC
Jack
Controls On/Off, Modulation, Level, Time
Echo Repeat Fltter, Speed
Depth 120 mm
Width 100 mm
Height 55 mm
Weight (excl. battery) 0,430 kg
RoHS
REACh
T-REX WARRANTY CONDITIONS
ABOUT T-REX
T-Rex offers a 2-year warranty on all our products. In the unlikely event of a malfunction, please contact our technical support at info@t-rex­engineering.com before sending us the product for repair. When the product has been sent to us at sender’s cost, we will repair or replace your product and send it back to you - free of charge and usually within 3 weeks (shipping not included). The product needs to be accompanied by a copy of your receipt, serial number, return address, phone number, e-mail address and a brief explanation of the problem. Please note that we cannot replace a product until we have received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, mis­use, accident, or neglect; or if the product has been repaired or serviced by persons not authorized by T-Rex. Read more about warranty condi­tions at www. t-rex-engineering.com.
Based in Vejle, Denmark, T-Rex Engineering makes classic and signature effects pedals for the world’s best musicians. Our ap­proach blends hi-tech innovation with old-world craftsmanship – always in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We find these environment protecting regulations very good, and we are happy to follow them.
ISSUED IN VEJLE, 2008
Steen Meldgaard Laursen
Managing Director
Lars Dahl-Jørgensen
Development Director
T-Rex Engineering ApS, Tel.: +45 75 72 71 81, Fax: +45 75 72 71 98
www.t-rex-engineering.com mail: info@t-rex-engineering.com
Sebastian Jensen
Production Director
