T-Rex Quint Machine User Manual

Congratulations
on your purchase of the QUINT MACHINE, a premium boutique octave divider from T-Rex Effects.
Your QUINT MACHINE gives you 3 different tones to en­hance your sound with—an octave up, an octave down, and a 5th up. And it lets you adjust each added tone in- dividually and even mix your effected sound with clean signal.
The possibilities are endless, so be sure to explore differ­ent setting combinations thoroughly.
QUINT MACHINE controls
Your QUINT MACHINE comes with 4 knobs. Three of these are used to add in the extra notes QUINT MACHINE generates.
The +1 OCTAVE knob adds a note that is 1 octave higher than the note you play on your guitar. The more you turn up the knob, the louder the octave-up note is compared to the note you play.
The -1 OCTAVE knob works the same way, but adds a note that is 1 octave lower than the note you play.
The +1 FIFTH knob also works the same way, but adds a note that is a fifth higher than the note you play on your guitar. So if you play an A, your QUINT MACHINE will add an E above the A you’ve played on your guitar.
The last control on your QUINT MACHINE is the MIX con­trol. This adjusts the balance between the natural signal coming from your guitar as you play it and the whole con­figuration of added octaves and fifths you have set up via the other knobs on your QUINT MACHINE. The more clean signal you add, the more natural your sound will be.
Input Impedance@1KHz Higher than 1M Ohm
RoHS
Output Impedance@1KHZ Lower than 1K Ohm
Power supply Voltage 9V DC Minimum 8V DC / Maximum 12,5V DC
Current Draw @ 9V DC 145 mA
Maximum Input signal Vp/p 3Vp/p
Battery Type / Battery Life 9V battery 6F22 / 30-60 min.
External connectors Input Jack, Output Jack, 9V DC jack
Controls ON/OFF switch, Mix,
+1 Octave, -1 Octave, +1 fifth
Pedal size incl. knobs (W x H x D) 60 x 50 x 117 mm / 2,4 x 2 x 4,6 inch
Weight excl. battery & packaging 0,210 kg / 7,4 oz
T-REX WARRANTY CONDITIONS
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a malfunction, please contact our technical support at service@t-rex-eects.com before sending us the product for repair. Read more about warrenty conditions at www.t-rex-eects.com/service.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Eects makes classic and signature eect pedals for the world’s best musicians. Our approach blends hi-tech innovation with old-world craftsmanship - always in the service of killer tone.
EU REGULATIONS · ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We nd these environment protecting regulations very good, and are happy to fol­low them.
REACh
