USER MANUAL
Congratulations
on your purchase of Play Back delay, the intuitive, amazing-sound­ing tap-controlled delay pedal from T-Rex.
As its name suggests, Play Back gives you two great advantages over other delay pedals. First, you get tap control of your delay tem­po – so you can adjust your tempo to fit any song, just by tapping along. Then, you get legendary T-Rex delay that you can fine tune via the Play Back BITE control.
In the T-Rex tradition, Play Back is quick to learn and easy to use. Just turn the page to get started.
Play Back Controls
Your Play Back has five delay controls, plus the TAP tempo button. The first three controls – DELAY, FEEDBACK, TINE and TIME – are standard delay pedal controls:
The BITE knob lets you tune the sonic character of your delayed signal to match the style of music you’re playing or your own tastes. Turn it up for a dirtier, analogue-style delay sound.
The DELAY lets you adjust how loud your delayed signal is com- pared to the original note or chord you play on your guitar.
The FEEDBACK knob determines how many repetitions your pedal produces, or how long the delay effect continues.
The TONE control lets you take the top of your delayed repeats for an even more authentic vintage tone.
The TIME control lets you set the tempo of your delayed repeti­tions – from short slap-back to a long “spacey-sounding” echo.
Finally, the TAP button (bottom right) is an alternative TIME control that lets you set the tempo of your delay by simply tap­ping along to the beat. It means you can say goodbye to having to reach down and manually adjust your pedal.
Technical Specification
Input Impedance @ 1KHz Higher than 1M Ohm
Output Impedance @ 1KHZ Lower than 1K Ohm
Power supply 9V DC (T-Rex FuelTank)
Power supply Voltage 9V DC
Current Draw @ 9V DC 85 mA
Maximum Input signal Vp/p 3Vp/p
Battery Type 9 V battery 6F22
Battery Life 30 - 60 min.
External connectors Input Jack, Output Jack, 9V DC Jack
Controls On/Off, Tap Tempo, Bite,
Delay, Feedback, Time
Pedal size incl. knobs (W x H x D) 100 x 55 x 120 mm
3,9 x 2,2 x 4,7 inch
Weight excl. battery and packaging 0,335 kg / 11,8 oz
T-REX WARRANTY CONDITIONS
T-Rex offers a 2-year warranty on all our products. In the unlikely event of a malfunction, please contact our technical support at service@t-rex-effects.com before sending us the product for repair. Read more about warranty conditions at www.t-rex-effects.com/ service
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and sig­nature effects pedals for the world’s best musicians. Our approach blends hi-tech innovation with old-world craftsmanship – always in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We find these environment protecting regulations very good, and we are happy to follow them.
REACh
RoHS
Lars Dahl-Jørgensen
& Sebastian Jensen Founder & Owner
T-Rex Engineering ApS
Made by T-REX Denmark 2014
