T-Rex Fuel Tank Chameleon User manual

POWER IT ALL
SELECT, PLUG, AND PLAY
Congratulations on your purchase of Chameleon, the most versatile Fuel Tank power supply we’ve ever built.
Chameleon packs all the power you need to make your T-Rex pedals – and your playing – sound spectacular. And with 4 different voltage options, it will power just about any pedal that’s ever been dreamed up.
Chameleon is a powerhouse of versatility, but it doesn’t stop there. You get clean, quiet, isolated power outlets, an amazing 1.500 mA of total juice, and a big set of custom-made cables. And it’s incredibly easy to use.
Turn the page for a few tips on how to get the very most out of your new Fuel Tank Chameleon.
Getting started
Chameleon gives you 6 separate outlets for plugging your pedals into. Here’s how they work:
Outlets 1–3 can all be used to power either 9V or 12V pedals. For each outlet, just use the VOLTAGE SELECTOR switches to choose the voltage you need, plug in your pedal and go!
Outlets 5 and 6 may only be used one at a time. If you use them both at the same time, you might get some noise. Like outlets 1–3, outlet 5 gives you a choice between 9V and 12V. Outlet 6 is a 12V AC outlet for pedals that require AC power.
All the cables you need
Your new Chameleon comes with a full set of cables to help you keep your board clutter-free. Once you’ve selected your voltage options, just plug in and play!
POWER SAMPLE 1
POWER SAMPLE 1
POWER
SAMPLE 2
9-12V DC 12V DC
T-REX QUINT MACHINE T-REX SHAFTER WAH
BOSS RT-20
9V DC
TC FLASHBACK X4
9V DC9V DC
BOSS RC-30
9-12V DC
T-REX VULTURE DISTORTION
9V DC
STRYMON MOBIUS
T-REX DIVA DRIVE T-REX KARMA BOOST
9-12V DC
12V AC
18V DC
EVH 117 FLANGER
T-REX REPLICAT-REX REPLAYBOX
TECHNICAL SPECIFICATIONS
WARRANTY
Input mains voltage Switchable 115V or 230V
Connections The Fuel Tank Chameleon has 6 isolated outputs. All
9V and 12V outlets delivers 300mA. When outlet 4 is
switched to 18V DC it delivers 150mA.
All outlets are centre negative.
Dimensions (W x H x D) 160x38x80 mm / 6,3x1,5x3,2 inch
Weight (excl. packaging/cables) 0,790 kg/ 27,87 oz
All the cables you need:
Mains power cable
Black link cable with ve 2.1mm - 2.1mm connectors
Red 50 cm DC cable with 2.1mm - 2.5mm connectors for use on the 12V AC output port
Blue 50 cm AC cable with 2.5mm - 2.5mm connectors for use on the 12V AC output port
Black 50 cm DC cable with 2.1mm DC - 3.5mm mini-jack connectors
20 cm DC cables with 2.1mm - 2.1mm connectors
50 cm DC cables with 2.1mm - 2.1mm connectors
75 cm DC cables with 2.1mm - 2.1mm connectors
100 cm DC cables with 2.1mm - 2.1mm connectors
T-REX WARRANTY CONDITIONS
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a malfunction, please contact our technical support at service@t-rex-eects.com before sending us the product for repair. Read more about warrenty conditions at www.t-rex-eects.com/service.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Eects makes classic and signature eect pedals for the world’s best musicians. Our approach blends hi-tech innovation with old-world craftsmanship - always in the service of killer tone.
EU REGULATIONS · ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We nd these environment protecting regulations very good, and are happy to fol­low them.
REACh
RoHS
Made by T-REX Denmark, 2010
Lars Dahl-Jørgensen
Lars Dahl-Jørgensen & Sebastian Jensen
Founder & Owner of T-Rex Engineering ApS
Founder
Sebastian Jensen
Founder
1
st
edition 2016
