T-Rex Duck Tail User Manual

USER MANUAL
DUCK TAIL
CONGRATULATIONS
on your purchase of Duck Tail Delay, a classic T-Rex delay pedal descend­ed from our legendary Replica family of delay effects for guitar and bass.
Duck Tail Delay comes with everything you’d expect from a T-Rex pedal – gorgeous vintage tone, fine craftsmanship, and the perfect mix of con­trols, including the brilliant tap tempo control that has made our delays staples on pedal boards everywhere.
Plus, we’ve added a tape delay mode and a sophisticated ducking mode that lets you control your delay just by the way you pick.
Turn the page to get started.
USING YOUR DUCK TAIL DELAY
The main controls on your Duck Tail Delay are the DELAY, FEEDBACK, TIME and LEVEL knobs, while the TAP button, the MODE (DUCK,TAPE, CLASSIC) switch, and the SENSITIVITY knob provide further control.
DELAY determines the mix of direct and delayed signal. Turn it down for a subtler natural effect, and crank it up for doubling or freaky long delay effects.
The FEEDBACK knob lets you control the number of times a sound is repeated – from just once to an almost infinite loop.
TIME determines the rate of your delay repeats and can be adjusted from 10 to 1,000 ms. TIP: to experiment, try tuning in a classic 50s slap­back sound by combining a fast time with a low repeat value.
MODE switch lets you switch between the new DUCK mode, a vintage TAPE delay sound, and a CLASSIC delay effect.
DUCK mode lets you control how much delay you get dynamically, de­pending on how hard you pick the strings. Play with a light attack, and the delay is fully activated – making it perfect for quiet, more sensitive passages. Pick harder, and the delay effect decreases, so you can play heavy chords and sharp staccato lines without any echoing clutter.
The SENSITIVITY knob lets you control how hard you have to pick before the delay effect ramps out.
The TAP button activates your pedal’s TAP TEMPO function. To automati­cally adjust the tempo of your delay to match the tempo of the song you’re playing, just use your foot to tap the button along with the beat.
Note: The INPUT GAIN knob on the side of your Duck Tail Delay elimi­nates overdrive distortion caused by too high of an input signal. Keep it set just below where the red light comes on.
RoHS
REACh
TECHNICAL SPECIFICATIONS
Input Impedance@1KHz Higher than 1M Ohm
Output Impedance@1KHZ Lower than 1K Ohm
Power supply 9V DC (T-Rex FuelTank)
Minimum Power supply Voltage 8,5V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 90mA
Maximum Input signal Vp/p Adjustable
Battery Type 9V battery 6F22
Battery Life 0,5 to 1 Hour
External connectors Input Jack, Output Jack, 9V DC jack
Controls On/Off, Tap Tempo, Delay, Feedback, Time,
Pedal size incl. knobs (W x H x D) 100 x 55 x 120 mm / 3,9 x 2,2 x 4,7 inch
Weight (excl. battery and packaging) 0,420 kg / 14,8 oz
Input Gain, Mode, Level, Sensitivity
T-REX WARRANTY CONDITIONS
T-Rex Eects oers a two-year guarantee on all our products. In the unlikely event of a malfunction, please send your product to an Authorized T-Rex Ser­vice Center. It will then be repaired or replaced and send back to you.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and signature eects pedals for the world’s best musicians. Our approach blends hi-tech innovation with old-world craftsmanship – always in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We nd these environment protecting regulations very good, and we are happy to follow them.
