Congratulations
on your purchase of the DIVA DRIVE, a premium boutique overdrive pedal from T-Rex Effects.
Built on a firm foundation of legendary JRC4558 IC gain,
the DIVA DRIVE is quite simply the most musical, versatile overdrive pedal we have ever produced.
To take full advantage of this versatility, take some time
to review this manual and get to know your DIVA con-
trols. The more you experiment with it, the more your
DIVA DRIVE will give you in return.
DIVA DRIVE controls
Your DIVA DRIVE comes with 4 control knobs, plus a LOW
RANGE selection switch.
The GAIN knob is the most important control on your
DIVA DRIVE. The more you turn it up, the more overdrive
you get.
The MIX knob lets you mix in as much clean sound as you
want, preserving your unique tone and the natural punch
of a cleaner guitar sound.
The TONE control knob lets you tune your overdrive
sound by backing off on the top end of your sound, while
the LEVEL knob is used to set the overall output volume
from your DIVA DRIVE.
Finally, the LOW RANGE selector switch on the side of
the unit lets tune your DIVA DRIVE to different guitars
by choosing which range of low frequencies are accentuated when you turn up the gain.
Input Impedance@1KHz Higher than 1M Ohm
RoHS
Output Impedance@1KHZ Lower than 1K Ohm
Power supply Voltage 9V DC Minimum 8V DC / Maximum 12,5V DC
Current Draw @ 9V DC 11 mA
Maximum Input signal Vp/p 3Vp/p
Battery Type / Battery Life 9V battery 6F22 / 11 hours
External connectors Input Jack, Output Jack, 9V DC jack
Controls ON/OFF switch, Gain, Level,
Mix, Tone, Voice switch
Pedal size incl. knobs (W x H x D) 60 x 50 x 117 mm / 2,4 x 2 x 4,6 inch
Weight excl. battery & packaging 0,215 kg / 7,6 oz
T-REX WARRANTY CONDITIONS
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a
malfunction, please contact our technical support at service@t-rex-eects.com
before sending us the product for repair. Read more about warrenty conditions
at www.t-rex-eects.com/service.
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Eects makes classic and signature eect pedals
for the world’s best musicians. Our approach blends hi-tech innovation with
old-world craftsmanship - always in the service of killer tone.
EU REGULATIONS · ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued by the EU. We
nd these environment protecting regulations very good, and are happy to follow them.
