PRODUCT DATA &

09/03/14

SPECIFICATIONS

OUTDOOR AIR COOLED CONDENSING UNITS

15 TO 100 HP HIGH AND MEDIUM

TEMPERATURE REFRIGERATION

15 TO 80 HP LOW TEMPERATURE REFRIGERATION

TV-LINE CONDENSING

UNITS

INCLUDES RATINGS FOR

Bulletin T40-TV-PDS-19

1073951

CONTENTS

Nomenclature............................................................................................................................................. 2

Features...................................................................................................................................................... 3 - 4

Capacity Ratings and Selection................................................................................................................ 4

Floating Head Pressure Control System.............................................................................. 5

STANDARD EFFICIENCY MODELS

Capacity Data.......................................... 6 - 34

TVS (Copeland Single Compressor )... 6 - 10

TVD (Copeland Dual Compressor)....... 11 - 18

TVS (Bitzer Single Compressor)........... 19 - 25

TVD (Bitzer Dual Compressor)............. 26 - 34

Electrical Data........................................ 35 - 38

TVS/TVD (Copeland Models)............... 35 - 36

TVS/TVD (Bitzer Models)..................... 37 - 38

Electrical Data (EC motors or ).. 39 - 42

TVS/TVD (Copeland Models)............... 39 - 40

TVS/TVD (Bitzer Models)..................... 41 - 42

Dimensional Data................................... 43 - 46

TVS (All Single Compressor Models)... 43 - 44

TVD (All Dual Compressor Models)..... 45 - 46

Specications.........................................47-48

TVS/TVD (All Copeland Models).......... 47

TVS/TVD (All Bitzer Models)................ 48

Wiring Diagrams (All Models).................................................................................................................. 49 - 54

Service Parts............................................................................................................................................. 98

Warranty..................................................................................................................................................... 99

Project Information.................................................................................................................................... 99

Capacity Data.......................................... 54 - 82

TVS (Copeland Single Compressor )... 54 - 61

TVD (Copeland Dual Compressor)....... 62 - 68

TVS (Bitzer Single Compressor)........... 69 - 75

TVD (Bitzer Dual Compressor)............. 76 - 82

Electrical Data........................................ 83 - 86

TVS/TVD (Copeland Models)............... 83 - 84

TVS/TVD (Bitzer Models)..................... 85 - 86

Electrical Data (EC motors or )..87-90

TVS/TVD (Copeland Models)............... 87 - 88

TVS/TVD (Bitzer Models)..................... 89 - 90

Dimensional Data................................... 91 - 94

TVS (All Single Compressor Models)... 91 - 92

TVD (All Dual Compressor Models)..... 93 - 94

Specications.........................................95-96

TVS/TVD (All Copeland Models).......... 95

TVS/TVD (All Bitzer Models)................ 96

HIGH EFFICIENCY MODELS

For the latest product updates and further information, visit www.trentonrefrigeration.com

NOMENCLATURE

09/03/14

T40-TV-PDS-19

- 2 -

TVS 040 M8 -H T4 B - A

Trenton Vertical Air Flow Condensing Unit

TVS = Single Compressor/Single Condenser Unit TVD = Dual Compressor/Dual Condenser Unit

Total HP

040 = If single, one 40 HP compressor. If dual, two 20 HP compressors.

High efciency models = Standard HP +1 (i.e.: 041 = 040 + 001)

Application

H = High Temp. M = Medium Temp. L = Low Temp. V = Extended Low Temp.

6 = R404A / R507 8 = R407A, R407C, R404A/R507, R22

Enclosure

H = Outdoor

FEATURES

Compressor

A = Copeland Discus Semi-Hermetic B = Bitzer Semi-Hermetic T = Bitzer 2 Stage Semi-Hermetic

Series Generation

B = 2nd Generation X = Special Custom Model (Deviates from catalog)

Electrical Designation

T3 = 208-230/3/60 T4 = 460/3/60 T5 = 575/3/60

* Subject to compressor availability

Electrical panel

Pre-formed

internal piping

Raceway for pressure control connections

Sub cooler circuit on medium and low temperature models

FEATURES - ALL MODELS

09/03/14

T40-TV-PDS-19

- 3 -

• Compatible with Low GWP Refrigerants

• Units are CUL

• Designed for use with various popular refrigerants.

• Energy efcient compressors with POE oil. Several

options to choose from: Copeland Discus, Bitzer

reciprocating.

• Single, dual and parallel-piped (optional) compressor

congurations available.

• ThermospanTM condenser core design eliminates tube sheet leaks and provides reliable operation.

• 3/8" condenser tubes reduces refrigerant charge.

• Generously sized condenser allows unit to operate at

higher than normal ambient conditions.

• Optional coating and n surfaces for condenser core

protection available.

• Specially designed, thermally protected and permanently lubricated ball bearing condenser fan

motor(s).

• Receivers (where used) are liberally sized and include

inlet as well as outlet service valves.

Listed.

• Subcooling circuit in condenser on all models

(except H8 models) increases overall system efciency and provides dependable compressor

operation.

• Utilizes pre-formed internal piping, eliminates welded joints and reduces chances of a leak.

• Electrical components are housed in a spacious

and conveniently located panel. In case of a

compressor trip, (except on air conditioning

models) a Lock-out relay de-energizes the liquid

line solenoid valve. In addition, SPDT contact is

provided for eld wired alarm circuit.

• End compartment panels allow unrestricted access to service the compressor(s) and all other components.

• Raceway for pressure control wiring and

connections provides neat appearance.

• Units are available with energy efcient

ThermosaverTM hot gas defrost option.

• Units are environmently friendly operating on less

power and refrigerant charge.

STANDARD EFFICIENCY MODELS

Standard features include:

•

Spring mount compressor with discharge

vibration eliminator

• Compressor head cooling fans on low

temperature models (except L8 units)

• Compressor crankcase heater

• Flexible hose on all compressor pressure

control connections

• Two valve adjustable (pre-set at factory)

Low Ambient head pressure control

• Condenser fan cycling control (pressure)

on two-fan models and up

• Fused condenser fan motors

HIGH EFFICIENCY MODELS

FEATURES

• Receiver inlet/outlet valves and safety

pressure relief valve

• Replaceable liquid line drier & sight glass

• Anti-short cycle time delay relay

• Oil failure control (non-electronic)

• Separate HP and LP compressor controls

• Part-winding start on all 30 HP and up,

operating on 208/230V-3Ph

• Lock out relay

• Sub-cooling circuit on medium and low

temperature units

• Electronic liquid injection on L8 units

FEATURES

• All Standard Efciency Model features

• Oversized condenser coils

OPTIONAL FEATURES

09/03/14

T40-TV-PDS-19

- 4 -

Factory installed Optional Features include:

• Suction line vibration eliminator

• Suction accumulator

(with or without heat exchanger)

• Replaceable suction lter

• Insulated suction lines.

• Crankcase Pressure Regulating valve

• Compressor capacity control (cylinder

unloading on 4D-6D-6F compressors or ModuloadTM on 3D compressor)

• Discharge line check valve

• Hot gas bypass tees / regulating valves /

de-superheating TXV

• Oil separator

• Discharge line thermostat

• Variable speed EC motors only as head

pressure control (see Bulletin T40-HPC-AG for details)

• Oversized receiver

• Heated and insulated receiver

• Thermosaver

• Disconnect switch (fused or non-fused).

• Compressor circuit breaker

• Electronic Oil failure control

• Voltage / Phase monitor

• Part-winding start (standard on 30HP and up

operating on 208/230-3)

• Defrost Time clock

• Defrost Heater / Evaporator Fan Contactors

with fuse block

• Single point electrical service hook up for evaporator and controls

• Limitrol+ Floating Head Pressure

Control System (see page 5 or Bulletin T40-HPC-AG for details)

defrost.

CAPACITY RATINGS AND SELECTION

RATING INFORMATION: 1. Ratings as shown are at saturated suction temperatures.

2. 60Hz capacity ratings are shown in imperial and metric units: MBH in bold type, (KW) in italics with in brackets.

3. Ratings may be interpolated but should not be extrapolated.

SELECTION PROCEDURE: Determine following requirements:

1. Ambient temperature, - °F / °C.

2. Total cooling load - MBH / (KW).

3. SST (saturated suction temperature) - °F / °C.

4. Refrigerant type

EXAMPLE SELECTION: GIVEN:

- Ambient temperature, 95°F / 35°C.

- Total cooling load 120MBH.

- SST, - 20°F/-28.8°C.

- Refrigerant, R404A.

METHOD:

- Go to the R404A low temperature capacity chart.

- Determine the capacity rating under 95°F ambient column and -20°F

SST row.

- Select the model with closest capacity requirement which is TVS030L6 with capacity 119.1 MBH.

SELECTION OF TWO-COMPRESSOR UNITS

TVD condensing units are double compressor units.

The ratings shown are the total capacity of two compressors operating simultaneously.

Standard TVD models are designed with two

independently operating systems, each with a

separate refrigeration circuit. Optional parallel

piped compressors (one total system) are available. Consult factory.

• Reduces compressor energy consumption and run time

09/03/14

T40-TV-PDS-19

- 5 -

• EC motor technology further saves energy and reduces electrical requirements

• Lowered environmental impact through reduced refrigerant use

• Stable system performance in lower ambients

What is Limitrol+? Limitrol+ combines various technologies into a responsive system that oats

head pressure, saving energy and reduces environmental impact. Unlike competitive systems, Limitrol+ combines variable speed EC motor technology, condenser portioning and various systems modications to provide the ultimate in performance and control. As a result, Limitrol+ functions in much colder ambients where previous systems have proven ineffective.

What does it do? Conventional head pressure control systems maintain a constant head pressure regardless of ambient temperatures. Limitrol+ intelligently responds to ambient conditions to oat head pressure without sacricing system performance at lower temperatures.

What are its applications?

• Condensing units over 5 HP

• Ideally suited and most effective in applications with uctuating ambients

• Perfect for installations where reduced refrigerant charges are desired or required.

How much can Limitrol+ save you?

Philadelphia,

MODEL

5 HP Cooler

7.5HPCooler

10 HP Cooler

15 HP Cooler

6 HP Freezer

7.5HPFreezer

13 HP Freezer

15 HP Freezer

* The above is a BIN Hour Analysis. Weather data was used from ASHRAE Weather Data Viewer and electrical rates for each city are based on June 2013 data from EIA (U.S. Energy Information Administration).

** Above numbers do not include refrigerant savings, and further cost savings can be expected.

% $ % $ % $ % $ % $ % $ % $ % $ % $

1,008

1,204

1,852

1,425

1,602

New York, NYBoston, MACharlotte, NCAtlanta, GA Los Angeles, CASt Louis, MOSt. Paul, MNToronto,

616

903

994

1,099

1,805

2,131

3,300

1,621

1,783

2,535

2,846

1,081

1,707

2,095

3,170

1,548

1,726

2,450

2,717

474

843

975

1,567

753

800

1,150

1,312

16 521 16

17 954 17

14 1,089 18

15 1,767 19

20 848 23

16 891 18

15 1,286 15

15 1,479 14

835

1,499

2,446

3,570

1,548

1,591

2,110

2,224

624

1,053

1,227

1,916

928

1,012

1,471

1,672

798

1,270

1,529

2,337

1,119

1,255

1,798

2,009

For more information, or to use our handy Energy Savings Calculator,

visit:

For more information on Head Pressure Control, please refer to our “Head Pressure Control Application Guide” (Bulletin T40-HPC-AG)

www.t-rp.com/limitrol

ONT

638

1,000

1,223

1,834

891

1,004

1,428

1,587

COPELAND

09/03/14

T40-TV-PDS-19

- 6 -

CAPACITY DATA -

HIGH TEMPERATURE

R407A

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS015H8-A

Compressor

3DS3R17ME

TVS022H8-A

Compressor

4DBNR20ME

TVS025H8-A

Compressor

4DHNR22ME

TVS030H8-A

Compressor

4DJNR28ME

TVS035H8-A

Compressor

6DHNR35ME

TVS040H8-A

Compressor

6DJNR40ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 45 (7.2) 215.9 (63.3) 207.6 (60.8) 199.3 (58.4) 191.2 (56) 183.2 (53.7) 175.4 (51.4) 40 (4.4) 198.0 (58) 190.6 (55.9) 183.1 (53.7) 175.8 (51.5) 168.5 (49.4) 161.4 (47.3) 35 (1.7) 180.9 (53) 174.2 (51.1) 167.5 (49.1) 160.9 (47.2) 154.4 (45.3) 147.8 (43.3) 45 (7.2) 280.9 (82.3) 270.6 (79.3) 260.4 (76.3) 250.2 (73.3) 239.9 (70.3) 229.7 (67.3) 40 (4.4) 256.0 (75) 246.6 (72.3) 237.2 (69.5) 227.7 (66.7) 218.4 (64) 209.0 (61.3) 35 (1.7) 232.7 (68.2) 224.1 (65.7) 215.5 (63.2) 206.9 (60.6) 198.2 (58.1) 189.6 (55.6) 45 (7.2) 300.6 (88.1) 289.0 (84.7) 277.1 (81.2) 265.2 (77.7) 253.3 (74.2) 241.3 (70.7) 40 (4.4) 277.5 (81.3) 266.6 (78.1) 255.6 (74.9) 244.4 (71.6) 233.3 (68.4) 222.2 (65.1) 35 (1.7) 254.4 (74.6) 244.3 (71.6) 234.0 (68.6) 223.8 (65.6) 213.5 (62.6) 203.2 (59.6) 45 (7.2) 350.7 (102.8) 337.3 (98.9) 323.6 (94.8) 309.6 (90.7) 295.5 (86.6) 281.0 (82.4) 40 (4.4) 322.9 (94.6) 310.5 (91) 297.8 (87.3) 284.9 (83.5) 271.7 (79.6) 258.4 (75.7) 35 (1.7) 295.8 (86.7) 284.3 (83.3) 272.7 (79.9) 260.8 (76.4) 248.7 (72.9) 236.6 (69.3) 45 (7.2) 439.0 (128.7) 425.1 (124.6) 410.9 (120.4) 395.9 (116) 380.3 (111.5) 363.9 (106.6) 40 (4.4) 400.1 (117.3) 387.2 (113.5) 373.9 (109.6) 360.2 (105.6) 345.7 (101.3) 330.5 (96.9) 35 (1.7) 364.8 (106.9) 353.0 (103.5) 340.7 (99.8) 328.0 (96.1) 314.8 (92.3) 300.7 (88.1) 45 (7.2) 523.1 (153.3) 502.2 (147.2) 481.0 (141) 459.6 (134.7) 438.1 (128.4) 416.4 (122) 40 (4.4) 478.1 (140.1) 459.6 (134.7) 440.9 (129.2) 422.0 (123.7) 403.0 (118.1) 383.8 (112.5) 35 (1.7) 436.5 (127.9) 420.3 (123.2) 403.9 (118.4) 387.2 (113.5) 370.5 (108.6) 353.6 (103.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 7 -

CAPACITY DATA -

R407A

MEDIUM TEMPERATURE

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS015M8-A

Compressor

Model

3DS3R17ME

TVS022M8-A

Compressor

Model

4DBNR20ME

TVS025M8-A

Compressor

Model

4DHNR22ME

TVS030M8-A

Compressor

Model

4DJNR28ME

TVS035M8-A

Compressor

Model

6DHNR35ME

TVS040M8-A

Compressor

Model

6DJNR40ME

TVS050M8-A

Compressor

Model

6DUNR49ME

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 164.5 (48.2) 158.6 (46.5) 152.5 (44.7) 146.5 (42.9) 140.6 (41.2) 134.6 (39.5) 25 (-3.9) 149.0 (43.7) 143.5 (42.1) 138.2 (40.5) 132.8 (38.9) 127.5 (37.4) 122.2 (35.8) 20 (-6.7) 134.3 (39.4) 129.5 (37.9) 124.5 (36.5) 119.7 (35.1) 114.8 (33.6) 109.9 (32.2) 15 (-9.4) 120.5 (35.3) 116.1 (34) 111.6 (32.7) 107.2 (31.4) 102.7 (30.1) 98.2 (28.8) 10 (-12.2) 107.5 (31.5) 103.5 (30.3) 99.5 (29.2) 95.3 (27.9) 91.1 (26.7) 86.9 (25.5)

5 (-15) 95.6 (28) 91.9 (26.9) 88.1 (25.8) 84.2 (24.7) 80.2 (23.5) 76.1 (22.3)

0 (-17.8) 84.5 (24.8) 81.0 (23.7) 77.4 (22.7) 73.6 (21.6) 69.7 (20.4) 65.8 (19.3) 30 (-1.1) 210.9 (61.8) 203.1 (59.5) 195.2 (57.2) 187.3 (54.9) 179.4 (52.6) 171.3 (50.2) 25 (-3.9) 190.6 (55.9) 183.4 (53.8) 176.3 (51.7) 169.2 (49.6) 162.0 (47.5) 155.0 (45.4) 20 (-6.7) 171.7 (50.3) 165.3 (48.4) 158.8 (46.5) 152.4 (44.7) 145.8 (42.7) 139.3 (40.8) 15 (-9.4) 154.1 (45.2) 148.4 (43.5) 142.6 (41.8) 136.7 (40.1) 130.9 (38.4) 125.1 (36.6) 10 (-12.2) 138.0 (40.4) 132.7 (38.9) 127.6 (37.4) 122.3 (35.8) 117.1 (34.3) 111.7 (32.7)

5 (-15) 123.0 (36) 118.3 (34.7) 113.6 (33.3) 109.0 (31.9) 104.3 (30.6) 99.4 (29.1)

0 (-17.8) 109.0 (31.9) 104.9 (30.7) 100.8 (29.5) 96.6 (28.3) 92.3 (27) 88.0 (25.8) 30 (-1.1) 231.7 (67.9) 222.4 (65.2) 213.0 (62.4) 203.5 (59.6) 194.0 (56.9) 184.6 (54.1) 25 (-3.9) 209.7 (61.5) 201.1 (58.9) 192.5 (56.4) 183.8 (53.9) 175.1 (51.3) 166.3 (48.7) 20 (-6.7) 188.3 (55.2) 180.6 (52.9) 172.7 (50.6) 164.9 (48.3) 157.1 (46) 149.1 (43.7) 15 (-9.4) 168.0 (49.2) 161.1 (47.2) 154.0 (45.1) 146.9 (43.1) 140.0 (41) 133.1 (39) 10 (-12.2) 149.0 (43.7) 142.8 (41.9) 136.5 (40) 130.2 (38.2) 124.1 (36.4) 118.1 (34.6)

5 (-15) 131.4 (38.5) 125.9 (36.9) 120.4 (35.3) 115.0 (33.7) 109.7 (32.2) 104.6 (30.6)

0 (-17.8) 115.5 (33.8) 110.8 (32.5) 106.2 (31.1) 101.5 (29.8) 97.0 (28.4) 92.8 (27.2) 30 (-1.1) 269.5 (79) 259.0 (75.9) 248.4 (72.8) 237.6 (69.6) 226.7 (66.4) 215.3 (63.1) 25 (-3.9) 244.3 (71.6) 234.8 (68.8) 225.2 (66) 215.5 (63.1) 205.6 (60.3) 195.3 (57.2) 20 (-6.7) 220.2 (64.5) 211.7 (62) 203.0 (59.5) 194.4 (57) 185.5 (54.4) 176.5 (51.7) 15 (-9.4) 197.3 (57.8) 189.6 (55.6) 182.0 (53.3) 174.4 (51.1) 166.7 (48.9) 159.2 (46.7) 10 (-12.2) 175.8 (51.5) 168.9 (49.5) 162.3 (47.6) 155.7 (45.6) 149.1 (43.7) 142.7 (41.8)

5 (-15) 155.5

0 (-17.8) 136.7 (40.1) 131.7 (38.6) 126.9 (37.2) 122.3 (35.8) 118.0 (34.6) 113.9 (33.4) 30 (-1.1) 332.9 (97.5) 322.0 (94.4) 310.8 (91.1) 299.3 (87.7) 287.1 (84.1) 274.3 (80.4) 25 (-3.9) 303.7 (89) 293.8 (86.1) 283.7 (83.1) 273.2 (80.1) 262.2 (76.8) 250.5 (73.4) 20 (-6.7) 276.8 (81.1) 268.0 (78.5) 258.8 (75.9) 249.5 (73.1) 239.6 (70.2) 229.1 (67.1) 15 (-9.4) 251.7 (73.8) 243.8 (71.5) 235.8 (69.1) 227.5 (66.7) 218.8 (64.1) 209.5 (61.4) 10 (-12.2) 227.7 (66.7) 221.0 (64.8) 214.0 (62.7) 206.9 (60.6) 199.3 (58.4) 191.2 (56)

5 (-15) 204.5 (59.9) 198.8 (58.3) 192.9 (56.5) 186.8 (54.7) 180.5 (52.9) 173.6 (50.9)

0 (-17.8) 181.4 (53.2) 176.7 (51.8) 171.9 (50.4) 167.0 (48.9) 161.7 (47.4) 156.1 (45.8) 30 (-1.1) 398.4 (1 25 (-3.9) 363.2 (106.4) 350.8 (102.8) 338.1 (99.1) 325.2 (95.3) 312.1 (91.5) 298.7 (87.5) 20 (-6.7) 330.6 (96.9) 319.6 (93.7) 308.3 (90.3) 296.6 (86.9) 284.9 (83.5) 272.9 (80) 15 (-9.4) 300.0 (87.9) 290.0 (85) 279.6 (81.9) 269.0 (78.8) 258.2 (75.7) 247.2 (72.4) 10 (-12.2) 270.7 (79.3) 261.2 (76.6) 251.5 (73.7) 241.5 (70.8) 231.2 (67.8) 220.7 (64.7)

5 (-15) 241.9 (70.9) 232.7 (68.2) 223.1 (65.4) 213.4 (62.5) 203.3 (59.6) 193.0 (56.6)

0 (-17.8) 213.0 (62.4) 203.6 (59.7) 193.9 (56.8) 183.9 (53.9) 173.6 (50.9) 163.2 (47.8) 30 (-1.1) 461.4 (135.2) 446.4 (130.8) 431.3 (126.4) 416.2 (122) 400.8 (117.5) 385.0 (112.8) 25 (-3.9) 422.2 (123.7) 408.6 (119.7) 394.8 (115.7) 380.8 (111.6) 366.5 (107.4) 351.6 (103.1) 20 (-6.7) 384.4 (112.7) 371.9 (109) 359.3 (105.3) 346.2 (101.5) 332.7 (97.5) 318.8 (93.4) 15 (-9.4) 348.2 (102) 336.6 (98.7) 324.8 (95.2) 312.5 (91.6) 299.8 (87.9) 286.3 (83.9) 10 (-12.2) 313.4 (91.9) 302.6 (88.7) 291.4 (85.4) 279.7 (82) 267.3 (78.3) 254.3 (74.5)

5 (-15) 280.1 (82.1) 269.9 (79.1) 259.0 (75.9) 247.7 (72.6) 235.5 (69) 222.6 (65.2)

0 (-17.8) 248.4 (72.8) 238.5 (69.9) 227.7 (66.7) 216.4 (63.4) 204.3 (59.9) 191.3 (56.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(45.6) 149.6 (43.9) 143.9 (42.2) 138.3 (40.5) 132.9 (39) 127.7 (37.4)

16.8) 384.2 (112.6) 369.8 (108.4) 355.1 (104.1) 340.4 (99.8) 325.5 (95.4)

R407A

AMBIENT TEMPERATURE °F (°C)

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

COPELAND

09/03/14

T40-TV-PDS-19

- 8 -

CAPACITY DATA -

LOW TEMPERATURE

R407A

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS010L8-A

Compressor

Model

3DS3F46KE

TVS015L8-A

Compressor

Model

4DHNF63KE

TVS022L8-A

Compressor

Model

4DJNF76KE

TVS027L8-A

Compressor

Model

6DHNF93KE

TVS030L8-A

Compressor

Model

6DJNF11ME

TVS040L8-A

Compressor

Model

6DUNF13ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 80.5 (23.6) 77.5 (22.7) 74.3 (21.8) 71.2 (20.9) 67.9 (19.9) 64.6 (18.9)

-5 (-20.6) 71.4 (20.9) 68.6 (20.1) 65.6 (19.2) 62.6 (18.3) 59.6 (17.5) 56.5 (16.6)

-10 (-23.3) 63.0 (18.5) 60.4 (17.7) 57.6 (16.9) 54.8 (16.1) 52.0 (15.2) 49.1 (14.4)

-15 (-26.1) 55.3 (16.2) 52.8 (15.5) 50.3 (14.7) 47.8 (14) 45.2 (13.2) 42.4 (12.4)

-20 (-28.9) 48.2 (14.1) 45.9 (13.4) 43.6 (12.8) 41.2 (12.1) 38.7 (11.4) 36.3 (10.6)

-25 (-31.7) 41.6 (12.2) 39.5 (11.6) 37.3 (10.9) 35.1 (10.3) 32.9 (9.6) 30.7 (9)

-30 (-34.4) 35.4 (10.4) 33.4 (9.8) 31.4 (9.2) 29.4 (8.6) 27.4 (8) 25.4 (7.4)

-35 (-37.2) 29.4 (8.6) 27.6 (8.1) 25.8 (7.6) 23.9 (7) 22.2 (6.5) 20.4 (6)

-40 (-40) 23.6 (6.9) 21.9 (6.4) 20.4 (6) 18.7 (5.5) 17.1 (5) 15.4 (4.5) 0 (-17.8) 107.2 (31.4) 102.6 (30.1) 98.1 (28.7) 93.6 (27.4) 88.9 (26.1) --- ---

-5 (-20.6) 96.1 (28.2) 92.0 (27) 87.9 (25.8) 83.8 (24.6) 79.6 (23.3) --- ---

-10 (-23.3) 85.6 (25.1) 81.9 (24) 78.1 (22.9) 74.4 (21.8) 70.7 (20.7) 66.9 (19.6)

-15 (-26.1) 75.6 (22.2) 72.3 (21.2) 68.9 (20.2) 65.5 (19.2) 62.1 (18.2) 58.6 (17.2)

-20 (-28.9) 66.3 (19.4) 63.2 (18.5) 60.2 (17.6) 57.1 (16.7) 54.0 (15.8) 50.8 (14.9)

-25 (-31.7) 57.4 (16.8) 54.7 (16) 52.0 (15.2) 49.1 (14.4) 46.3 (13.6) 43.4 (12.7)

-30 (-34.4) 49.2 (14.4) 46.8 (13.7) 44.3 (13) 41.7 (12.2) 39.1 (11.4) 36.4 (10.7)

-35 (-37.2) 41.8 (12.2) 39.5 (11.6) 37.2 (10.9) 34.9 (10.2) 32.3 (9.5) 29.9 (8.8)

-40 (-40) 34.9 (10.2) 32.9 (9.6) 30.7 (9) 28.5 (8.3) 26.1 (7.7) 23.8 (7) 0 (-17.8) 139.5 (40.9) 133.9 (39.2) 128.2 (37.6) 122.5 (35.9) 116.7 (34.2) --- ---

-5 (-20.6) 123.6 (36.2) 118.4 (34.7) 113.1 (33.1) 107.7 (31.6) 102.3 (30) 96.8 (28.4)

-10 (-23.3) 108.8 (31.9) 104.0 (30.5) 99.1 (29) 94.2 (27.6) 89.1 (26.1) 84.0 (24.6)

-15 (-26.1) 95.1 (27.9) 90.7 (26.6) 86.3 (25.3) 81.9 (24) 77.3 (22.6) 72.6 (21.3)

-20 (-28.9) 82.6 (24.2) 78.8 (23.1) 74.9 (21.9) 70.8 (20.7) 66.7 (19.5) 62.5 (18.3)

-25 (-31.7) 71.5 (21) 68.0 (19.9) 64.6 (18.9) 61.1 (17.9) 57.4 (16.8) 53.8 (15.8)

-30 (-34.4) 61.6 (18.1) 58.8 (17.2) 55.8 (16.3) 52.7 (15.4) 49.7 (14.6) 46.4 (13.6)

-35 (-37.2) 53.2 (15.6) 50.8 (14.9) 48.4 (14.2) 46.0 (13.5) 43.4 (12.7) 40.6 (11.9)

-40 (-40) 46.3 (13.6) 44.5 (13) 42.6 (12.5) 40.6 (11.9) 38.6 (11.3) 36.5 (10.7) 0 (-17.8) 169.3 (49.6) 162.8 (47.7) 155.7 (45.6) 148.4 (43.5) 140.7 (41.2) --- ---

-5 (-20.6) 147.5 (43.2) 141.6 (41.5) 135.5 (39.7) 128.9 (37.8) 122.0 (35.8) 1

-10 (-23.3) 128.9 (37.8) 123.7 (36.2) 118.1 (34.6) 112.2 (32.9) 105.9 (31) 99.4 (29.1)

-15 (-26.1) 112.9 (33.1) 108.2 (31.7) 103.1 (30.2) 97.8 (28.6) 92.1 (27) 86.1 (25.2)

-20 (-28.9) 98.9 (29) 94.6 (27.7) 89.9 (26.3) 84.9 (24.9) 79.8 (23.4) 74.2 (21.8)

-25 (-31.7) 86.3 (25.3) 82.2 (24.1) 77.9 (22.8) 73.3 (21.5) 68.4 (20) 63.2 (18.5)

-30 (-34.4) 74.6 (21.8) 70.6 (20.7) 66.4 (19.4) 61.8 (18.1) 57.2 (16.8) 52.4 (15.4)

-35 (-37.2) 62.8 (18.4) 58.8 (17.2) 54.6 (16) 50.3 (14.7) 45.8 (13.4) 41.1 (12)

-40 (-40) 50.4 (14.8) 46.4 (13.6) 42.2 (12.4) 37.9 (11.1) 33.4 (9.8) 28.8 (8.4) 0 (-17.8) 196.1 (57.5) 188.4 (55.2) 180.4 (52.9) 172.1 (50.4) 163.6 (47.9) --- ---

-5 (-20.6) 174.3 (51.1) 167.2 (49) 159.8 (46.8) 152.3 (44.6) 144.3 (42.3) --- ---

-10 (-23.3) 154.1 (45.2) 147.6 (43.3) 140.9 (41.3) 133.9 (39.2) 126.6 (37.1) 118.9 (34.8)

-15 (-26.1) 135.6 (39.7) 129.6 (38) 123.5 (36.2) 117.0 (34.3) 110.1 (32.3) 103.0 (30.2)

-20 (-28.9) 118.2 (34.6) 112.8 (33) 107.1 (31.4) 101.1 (29.6) 94.7 (27.8) 88.0 (25.8)

-25 (-31.7) 102.1 (29.9) 97.0 (28.4) 91.7 (26.9) 86.1 (25.2) 80.1 (23.5) 73.7 (21.6)

-30 (-34.4) 86.5 (25.4) 81.9 (24) 76.9 (22.5) 71.6 (21) 65.9 (19.3) 59.7 (17.5)

-35 (-37.2) 71.6 (21) 67.2 (19.7) 62.5 (18.3) 57.3 (16.8) 51.9 (15.2) 46.0 (13.5)

-40 (-40) 56.8 (16.6) 52.6 (15.4) 48.1 (14.1) 43.2 (12.6) 37.8 (11.1) 32.0 (9.4) 0 (-17.8) 222.8 (65.3) 214.9 (63) 207.1 (60.7) 199.2 (58.4) 191.0 (56) --- ---

-5 (-20.6) 200.6 (58.8) 193.4 (56.7) 186.1 (54.5) 178.7 (52.4) 171.0 (50.1) --- ---

-10 (-23.3) 178.7 (52.4) 172.1 (50.4) 165.3 (48.4) 158.3 (46.4) 151.1 (44.3) --- ---

-15 (-26.1) 157.5 (46.2) 151.3 (44.3) 145.0 (42.5) 138.5 (40.6) 131.6 (38.6) 124.4 (36.5)

-20 (-28.9) 137.2 (40.2) 131.5 (38.5) 125.5 (36.8) 119.3 (35) 112.7 (33) 105.7 (31)

-25 (-31.7) 118.2 (34.6) 112.8 (33) 107.1 (31.4) 101.1 (29.6) 94.7 (27.8) 87.9 (25.8)

-30 (-34.4) 100.7 (29.5) 95.6 (28) 90.1 (26.4) 84.2 (24.7) 77.9 (22.8) 71.2 (20.9)

-35 (-37.2) 85.2 (25) 80.1 (23.5) 74.7 (21.9) 68.9 (20.2) 62.6 (18.3) 55.9 (16.4)

-40 (-40) 71.6 (21) 66.6 (19.5) 61.2 (17.9) 55.3 (16.2) 49.0 (14.4) 42.2 (12.4)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

14.8 (33.6)

CAPACITY DATA -

09/03/14

T40-TV-PDS-19

- 9 -

COPELAND

CONDENSING

UNIT

MODEL

TVS015H8-A

Compressor

Model

3DS3R17ME

TVS022H8-A

Compressor

Model

4DBNR20ME

TVS025H8-A

Compressor

Model

4DHNR22ME

TVS030H8-A

Compressor

Model

4DJNR28ME

TVS035H8-A

Compressor

Model

6DHNR35ME

TVS040H8-A

Compressor

Model

6DJNR40ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 247.5 (72.5) 238.2 (69.8) 229.3 (67.2) 220.6 (64.7) 212.2 (62.2) 203.9 (59.8) 50 (10) 228.1 (66.8) 219.8 (64.4) 211.8 (62.1) 203.9 (59.8) 196.2 (57.5) 188.8 (55.3) 45 (7.2) 209.5 (61.4) 202.0 (59.2) 194.9 (57.1) 187.8 (55.1) 180.9 (53) 174.2 (51.1) 40 (4.4) 191.7 (56.2) 185.1 (54.3) 178.7 (52.4) 172.4 (50.5) 166.2 (48.7) 160.1 (46.9) 35 (1.7) 174.7 (51.2) 168.9 (49.5) 163.2 (47.8) 157.6 (46.2) 152.0 (44.6) 146.5 (42.9) 55 (12.8) 322.2 (94.4) 310.6 (91) 299.0 (87.6) 287.4 (84.2) 275.9 (80.9) 264.5 (77.5) 50 (10) 294.2 (86.2) 283.3 (83) 272.4 (79.8) 261.5 (76.6) 250.6 (73.5) 239.9 (70.3) 45 (7.2) 268.3 (78.6) 258.0 (75.6) 247.8 (72.6) 237.6 (69.6) 227.5 (66.7) 217.7 (63.8) 40 (4.4) 244.3 (71.6) 234.7 (68.8) 225.1 (66) 215.8 (63.2) 206.4 (60.5) 197.2 (57.8) 35 (1.7) 222.0 (65.1) 213.0 (62.4) 204.2 (59.9) 195.5 (57.3) 187.0 (54.8) 178.6 (52.3) 55 (12.8) 350.8 (102.8) 332.9 (97.5) 315.3 (92.4) 298.0 (87.3) 281.2 (82.4) 264.8 (77.6) 50 (10) 324.2 (95) 308.0 (90.3) 291.9 (85.5) 276.3 (81) 261.1 (76.5) 246.4 (72.2) 45 (7.2) 298.0 (87.3) 283.3 (83) 268.9 (78.8) 254.9 (74.7) 241.4 (70.7) 228.5 (67) 40 (4.4) 272.4 (79.8) 259.4 (76) 246.5 (72.3) 234.2 (68.6) 222.3 (65.1) 210.9 (61.8) 35 (1.7) 247.6 (72.6) 236.1 (69.2) 224.9 (65.9) 214.1 (62.7) 203.8 (59.7) 193.9 (56.8) 55 (12.8) 413.3 (121.1) 392.9 (115.2) 372.6 (109.2) 352.8 (103.4) 333.3 (97.7) --- --50 (10) 380.1 (111.4) 361.4 (105.9) 343.1 (100.6) 325.2 (95.3) 307.7 (90.2) 290.4 (85.1) 45 (7.2) 347.9 (101.9) 331.1 (97) 314.7 (92.2) 298.7 (87.5) 283.2 (83) 268.1 (78.6) 40 (4.4) 317.0 (92.9) 302.1 (88.5) 287.7 (84.3) 273.6 (80.2) 260.1 (76.2) 247.0 (72.4) 35 (1.7) 287.7 (84.3) 274.7 (80.5) 262.2 (76.8) 250.0 (73.3) 238.4 (69.9) 227.1 (66.6) 55 (12.8) 527.8 (154.7) 506.8 (148.5) 485.7 (142.4) 464.5 (136.1) 443.2 (129.9) --- --50 (10) 477.1 (139.8) 458.3 (134.3) 439.4 (128.8) 420.3 (123.2) 401.1 (117.6) 381.8 (111.9) 45 (7.2) 430.4 (126.1) 413.7 (121.2) 396.8 (116.3) 379.9 (111.3) 362.8 (106.3) 345.5 (101.2) 40 (4.4) 387.7 (113.6) 373.0 (109.3) 358.2 (105) 343.1 (100.6) 328.0 (96.1) 312.6 (91.6) 35 (1.7) 348.9 (102.3) 336.1 (98.5) 323.2 (94.7) 310.1 (90.9) 296.7 (87) 283.1 (83) 55 (12.8) 711.6 (208.5) 678.0 (198.7) 642.7 (188.4) 606.1 (177.6) 567.9 (166.4) --- --50 (10) 636.0 (186.4) 604.7 (177.2) 572.0 (167.6) 537.9 (157.6) 502.5 (147.3) 466.1 (136.6) 45 (7.2) 564.8 (165.5) 536.6 (157.2) 506.7 (148.5) 475.5 (139.4) 443.3 (129.9) 410.0 (120.2) 40 (4.4) 500.3 (146.6) 474.9 (139.2) 448.1 (131.3) 420.0 (123.1) 390.9 (114.6) 361.0 (105.8) 35 (1.7) 443.1 (129.9) 420.5 (123.2) 396.6 (116.2) 371.6 (108.9) 345.7 (101.3) 319.0 (93.5)

HIGH TEMPERATURE

CAPACITY MBH (KW)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

R407C

AMBIENT TEMPERATURE °F (°C)

60HzTVS-A

CAPACITY DATA -

R407C

MEDIUM TEMPERATURE

CONDENSING

UNIT

MODEL

TVS015M8-A

Compressor

Model

3DS3R17ME

TVS022M8-A

Compressor

Model

4DBNR20ME

TVS025M8-A

Compressor

Model

4DHNR22ME

TVS030M8-A

Compressor

Model

4DJNR28ME

TVS035M8-A

Compressor

Model

6DHNR35ME

TVS040M8-A

Compressor

Model

6DJNR40ME

TVS050M8-A

Compressor

Model

6DUNR49ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 158.8 (46.5) 153.6 (45) 148.6 (43.5) 143.5 (42.1) 138.5 (40.6) 133.5 (39.1) 25 (-3.9) 143.6 (42.1) 139.1 (40.8) 134.6 (39.5) 130.1 (38.1) 125.6 (36.8) 120.9 (35.4) 20 (-6.7) 129.5 (37.9) 125.5 (36.8) 121.5 (35.6) 117.4 (34.4) 113.2 (33.2) 108.8 (31.9) 15 (-9.4) 116.2 (34.1) 112.7 (33) 109.0 (31.9) 105.3 (30.9) 101.3 (29.7) 97.2 (28.5) 10 (-12.2) 104.0 (30.5) 100.7 (29.5) 97.3 (28.5) 93.9 (27.5) 90.1 (26.4) 86.0 (25.2) 30 (-1.1) 201.0 (58.9) 192.9 (56.5) 184.8 (54.2) 176.8 (51.8) 169.1 (49.5) 161.4 (47.3) 25 (-3.9) 181.3 (53.1) 173.9 (51) 166.5 (48.8) 159.3 (46.7) 152.3 (44.6) 145.4 (42.6) 20 (-6.7) 162.5 (47.6) 155.8 (45.7) 149.2 (43.7) 142.8 (41.9) 136.5 (40) 130.4 (38.2) 15 (-9.4) 144.6 (42.4) 138.5 (40.6) 132.6 (38.9) 126.9 (37.2) 121.5 (35.6) 116.1 (34) 10 (-12.2) 127.1 (37.2) 121.7 (35.7) 116.6 (34.2) 111.6 (32.7) 106.9 (31.3) 102.4 (30) 30 (-1.1) 224.0 (65.6) 213.9 (62.7) 204.2 (59.9) 194.9 (57.1) 185.9 (54.5) 177.5 (52) 25 (-3.9) 201.5 (59.1) 192.9 (56.5) 184.5 (54.1) 176.4 (51.7) 168.7 (49.5) 161.5 (47.3) 20 (-6.7) 180.4 (52.9) 173.0 (50.7) 165.9 (48.6) 159.0 (46.6) 152.4 (44.7) 146.3 (42.9) 15 (-9.4) 160.9 (47.1) 154.6 (45.3) 148.4 (43.5) 142.5 (41.8) 136.8 (40.1) 131.5 (38.5) 10 (-12.2) 142.9 (41.9) 137.4 (40.3) 132.2 (38.7) 126.9 (37.2) 122.0 (35.8) 117.3 (34.4) 30 (-1.1) 260.1 (76.2) 249.0 (73) 238.1 (69.8) 227.9 (66.8) 217.9 (63.9) 208.3 (61.1) 25 (-3.9) 234.5 (68.7) 224.9 (65.9) 215.8 (63.2) 207.0 (60.7) 198.6 (58.2) 190.6 (55.9) 20 (-6.7) 210.6 (61.7) 202.7 (59.4) 194.9 (57.1) 187.5 (55) 180.5 (52.9) 173.8 (50.9) 15 (-9.4) 188.7 (55.3) 181.9 (53.3) 175.4 (51.4) 169.2 (49.6) 163.3 (47.9) 157.6 (46.2) 10 (-12.2) 168.4 (49.4) 162.6 (47.7) 157.2 (46.1) 151.8 (44.5) 146.8 (43) 142.0 (41.6) 30 (-1.1) 314.1 (92) 302.9 (88.8) 291.7 (85.5) 280.2 (82.1) 268.5 (78.7) 256.5 (75.2) 25 (-3.9) 282.7 (82.8) 273.1 (80) 263.3 (77.2) 253.3 (74.2) 243.0 (71.2) 232.4 (68.1) 20 (-6.7) 254.4 (74.6) 246.1 (72.1) 237.5 (69.6) 228.7 (67) 219.6 (64.3) 210.1 (61.6) 15 (-9.4) 228.8 (67.1) 221.4 (64.9) 214.0 (62.7) 206.1 (60.4) 197.9 (58) 189.3 (55.5) 10 (-12.2) 205.2 (60.1) 198.7 (58.2) 191.8 (56.2) 184.7 (54.1) 177.2 (51.9) 169.3 (49.6) 30 (-1.1) 393.3 (115.3) 373.3 (109.4) 352.2 (103.2) 330.0 25 (-3.9) 350.3 (102.7) 332.6 (97.5) 314.1 (92) 294.7 (86.4) 274.9 (80.6) 254.8 (74.7) 20 (-6.7) 313.1 (91.8) 297.6 (87.2) 281.4 (82.5) 264.8 (77.6) 248.0 (72.7) 231.3 (67.8) 15 (-9.4) 280.8 (82.3) 267.2 (78.3) 253.3 (74.2) 239.2 (70.1) 225.4 (66.1) 212.1 (62.2) 10 (-12.2) 251.8 (73.8) 240.0 (70.3) 228.3 (66.9) 216.7 (63.5) 205.9 (60.3) 195.9 (57.4) 30 (-1.1) 452.3 (132.6) 429.1 (125.8) 405.4 (118.8) 381.2 (11 25 (-3.9) 403.7 (118.3) 382.8 (112.2) 361.5 (105.9) 340.1 (99.7) 318.7 (93.4) 297.6 (87.2) 20 (-6.7) 359.1 (105.2) 340.6 (99.8) 321.8 (94.3) 303.2 (88.9) 284.9 (83.5) 267.1 (78.3) 15 (-9.4) 318.8 (93.4) 302.5 (88.7) 286.4 (83.9) 270.7 (79.3) 255.6 (74.9) 241.4 (70.7) 10 (-12.2) 282.7 (82.8) 268.7 (78.7) 255.3 (74.8) 242.6 (71.1) 230.9 (67.7) 220.6 (64.7)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

(96.7) 307.1 (90) 283.8 (83.2)

1.7) 356.8 (104.6) 332.4 (97.4)

COPELAND

09/03/14

T40-TV-PDS-19

- 10 -

CONDENSING

UNIT

MODEL

TVS015H8-A

Compressor

3DS3R17ME

TVS022H8-A

Compressor

4DBNR20ME

TVS025H8-A

Compressor

4DHNR22ME

TVS030H8-A

Compressor

4DJNR28ME

TVS035H8-A

Compressor

6DHNR35ME

TVS040H8-A

Compressor

6DJNR40ME

TEMPERATURE

CAPACITY DATA -

R404A

R507

60HzTVS-A

HIGH TEMPERATURE

SATURATED

SUCTION

° F ° C

45 (7.2) 221.0 (64.8) 211.4 (62) 202.0 (59.2) 192.6 (56.4) 183.4 (53.7) 174.3 (51.1) 40 (4.4) 203.9 (59.8) 195.2 (57.2) 186.5 (54.7) 178.0 (52.2) 169.5 (49.7) 161.2 (47.2) 35 (1.7) 187.7 (55) 179.7 (52.7) 171.8 (50.3) 164.0 (48.1) 156.2 (45.8) 148.6 (43.6) 45 (7.2) 271.3 (79.5) 259.6 (76.1) 248.1 (72.7) 236.9 (69.4) 225.9 (66.2) 215.2 (63.1) 40 (4.4) 253.2 (74.2) 242.2 (71) 231.4 (67.8) 221.0 (64.8) 210.7 (61.7) 200.7 (58.8) 35 (1.7) 234.9 (68.8) 224.7 (65.9) 214.7 (62.9) 204.9 (60.1) 195.4 (57.3) 186.1 (54.5) 45 (7.2) 286.3 (83.9) 274.1 (80.3) 262.2 (76.8) 250.6 (73.4) 239.2 (70.1) 228.1 (66.8) 40 (4.4) 267.5 (78.4) 256.0 (75) 244.9 (71.8) 234.0 (68.6) 223.4 (65.5) 213.0 (62.4) 35 (1.7) 248.5 (72.8) 237.8 (69.7) 227.4 (66.6) 217.3 (63.7) 207.4 (60.8) 197.6 (57.9) 45 (7.2) 348.9 (102.3) 333.8 (97.8) 318.8 (93.4) 303.9 (89.1) 288.9 (84.7) 274.0 (80.3) 40 (4.4) 323.2 (94.7) 309.2 (90.6) 295.3 (86.5) 281.4 (82.5) 267.6 (78.4) 253.7 (74.4) 35 (1.7) 298.4 (87.5) 285.4 (83.6) 272.5 (79.9) 259.7 (76.1) 246.9 (72.4) 234.1 (68.6) 45 (7.2) 448.1 (131.3) 428.9 (125.7) 409.6 (120) 390.3 (114.4) 370.9 (108.7) 351.4 (103) 40 (4.4) 413.4 (121.2) 395.7 (116) 377.9 (110.8) 360.2 (105.6) 342.4 (100.3) 324.5 (95.1) 35 (1.7) 380.2 (111.4) 364.0 (106.7) 347.7 (101.9) 331.5 (97.2) 315.1 (92.3) 298.8 (87.6) 45 (7.2) 511.2 (149.8) 490.3 (143.7) 469.3 (137.5) 448.2 (131.4) 427.0 (125.1) 405.4 (118.8) 40 (4.4) 474.6 (139.1) 455.2 (133.4) 435.8 (127.7) 416.2 (122) 396.5 (116.2) 376.5 (110.3) 35 (1.7) 439.0 (128.7) 421.1 (123.4) 403.2 (118.2) 385.2 (112.9) 367.0 (107.6) 348.6 (102.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

CONDENSING

UNIT

MODEL

TVS015M8-A

Compressor

Model

3DS3R17ME

TVS022M8-A

Compressor

Model

4DBNR20ME

TVS025M8-A

Compressor

Model

4DHNR22ME

TVS030M8-A

Compressor

Model

4DJNR28ME

TVS035M8-A

Compressor

Model

6DHNR35ME

TVS040M8-A

Compressor

Model

6DJNR40ME

TVS050M8-A

Compressor

Model

6DUNR49ME

CAPACITY DATA -

R404A

R507

MEDIUM TEMPERATURE

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 172.1 (50.4) 164.9 (48.3) 157.7 (46.2) 150.6 (44.1) 143.6 (42.1) 136.7 (40.1) 25 (-3.9) 157.4 (46.1) 150.8 (44.2) 144.3 (42.3) 137.9 (40.4) 131.6 (38.6) 125.4 (36.8) 20 (-6.7) 143.4 (42) 137.5 (40.3) 131.7 (38.6) 125.9 (36.9) 120.2 (35.2) 114.6 (33.6) 15 (-9.4) 130.3 (38.2) 125.0 (36.6) 119.7 (35.1) 114.6 (33.6) 109.5 (32.1) 104.4 (30.6) 10 (-12.2) 117.9 (34.6) 113.2 (33.2) 108.5 (31.8) 103.9 (30.4) 99.3 (29.1) 94.8 (27.8)

5 (-15) 106.3 (31.2) 102.1 (29.9) 98.0 (28.7) 93.8 (27.5) 89.8 (26.3) 85.8 (25.1)

0 (-17.8) 95.6 (28) 91.8 (26.9) 88.1 (25.8) 84.4 (24.7) 80.8 (23.7) 77.2 (22.6) 30 (-1.1) 216.7 (63.5) 207.2 (60.7) 198.0 (58) 189.0 (55.4) 180.1 (52.8) 171.5 (50.3) 25 (-3.9) 198.8 (58.3) 190.0 (55.7) 181.5 (53.2) 173.2 (50.8) 165.0 (48.4) 157.1 (46) 20 (-6.7) 181.3 (53.1) 173.3 (50.8) 165.4 (48.5) 157.8 (46.2) 150.3 (44) 143.0 (41.9) 15 (-9.4) 164.4 (48.2) 157.1 (46) 149.9 (43.9) 143.0 (41.9) 136.1 (39.9) 129.4 (37.9) 10 (-12.2) 148.3 (43.5) 141.7 (41.5) 135.2 (39.6) 128.9 (37.8) 122.7 (36) 116.6 (34.2)

5 (-15) 133.3 (39.1) 127.3 (37.3) 121.5 (35.6) 115.7 (33.9) 110.1 (32.3) 104.6 (30.7)

0 (-17.8) 119.4 (35) 114.1 (33.4) 108.9 (31.9) 103.8 (30.4) 98.7 (28.9) 93.8 (27.5) 30 (-1.1) 229.6 (67.3) 219.7 (64.4) 210.0 (61.5) 200.6 (58.8) 191.3 (56.1) 182.3 (53.4) 25 (-3.9) 210.9 (61.8) 201.7 (59.1) 192.8 (56.5) 184.0 (53.9) 175.5 (51.4) 167.1 (49) 20 (-6.7) 192.5 (56.4) 184.1 (54) 175.9 (51.6) 167.9 (49.2) 160.0 (46.9) 152.3 (44.6) 15 (-9.4) 174.8 (51.2) 167.1 (49) 159.6 (46.8) 152.3 (44.6) 145.1 (42.5) 138.0 (40.4) 10 (-12.2) 157.8 (46.2) 150.8 (44.2) 144.1 (42.2) 137.4 (40.3) 130.9 (38.4) 124.4 (36.5)

5 (-15) 141.8 (41.6) 135.6 (39.7) 129.5 (38) 123.6 (36.2) 117.7 (34.5) 111.9 (32.8)

0 (-17.8) 127.1 (37.2) 121.6 (35.6) 116.2 (34.1) 110.9 (32.5) 105.7 (31) 100.5 (29.5) 30 (-1.1) 274.4 (80.4) 262.4 (76.9) 250.6 (73.4) 238.8 (70) 227.1 (66.6) 215.3 (63.1) 25 (-3.9) 251.3 (73.6) 240.3 (70.4) 229.5 (67.3) 218.7 (64.1) 208.0 (61) 197.3 (57.8) 20 (-6.7) 229.2 (67.2) 219.2 (64.2) 209.3 (61.3) 199.5 (58.5) 189.8 (55.6) 180.1 (52.8) 15 (-9.4) 208.1 (61) 199.0 (58.3) 190.1 (55.7) 181.3 (53.1) 172.5 (50.6) 163.7 (48) 10 (-12.2) 188.0 (55.1) 179.9 (52.7) 171.8 (50.3) 163.9 (48) 156.0 (45.7) 148.2 (43.4)

5 (-15) 169.1 (49.6) 161.8 (47.4) 154.6 (45.3) 147.6 (43.3) 140.6 (41.2) 133.6 (39.2)

0 (-17.8) 151.3 (44.3) 144.8 (42.4) 138.4 (40.6) 132.2 (38.7) 126.1 (37) 119.9 (35.1) 30 (-1.1) 348.6 (102.2) 333.8 (97.8) 319.0 (93.5) 304.1 (89.1) 289.2 (84.8) 274.3 (80.4) 25 (-3.9) 318.6 (93.4) 305.1 (89.4) 291.6 (85.5) 278.2 (81.5) 264.6 (77.5) 251.1 (73.6) 20 (-6.7) 290.2 (85) 278.0 (81.5) 265.8 (77.9) 253.6 (74.3) 241.3 (70.7) 229.0 (67.1) 15 (-9.4) 263.5 (77.2) 252.5 (74) 241.4 (70.7) 230.3 (67.5) 219.3 (64.3) 208.2 (61) 10 (-12.2) 238.5 (69.9) 228.5 (67) 218.5 (64) 208.5 (61.1) 198.5 (58.2) 188.4 (55.2)

5 (-15) 215.2 (63.1) 206.1 (60.4) 197.0 (57.7) 187.9 (55.1) 178.8 (52.4) 169.8 (49.8)

0 (-17.8) 193.6 (56.7) 185.2 (54.3) 176.9 (51.8) 168.6 (49.4) 160.4 (47) 152.2 (44.6) 30 (-1.1) 404.7 (118.6) 388.1 (113.7) 371.6 (108.9) 355.1 (104.1) 338.4 (99.2) 321.5 (94.2) 25 (-3.9) 371.6 (108.9) 356.4 (104.5) 341.2 (100) 326.1 (95.6) 310.8 (91.1) 295.3 (86.5) 20 (-6.7) 339.9 (99.6) 326.0 (95.5) 312.1 (91.5) 298.3 (87.4) 284.4 (83.3) 270.3 (79.2) 15 (-9.4) 309.7 (90.8) 296.9 (87) 284.3 (83.3) 271.7 (79.6) 259.1 (75.9) 246.4 (72.2) 10 (-12.2) 281.1 (82.4) 269.4 (79) 257.9 (75.6) 246.5 (72.2) 235.1 (68.9) 223.6 (65.5)

5 (-15) 254.1 (74.5) 243.5 (71.4) 233.0 (68.3) 222.7 (65.3) 212.5 (62.3) 202.1 (59.2)

0 (-17.8) 228.9 (67.1) 219.2 (64.2) 209.7 (61.5) 200.5 (58.8) 191.3 (56.1) 182.0 (53.3) 30 (-1.1) 471.5 (138.2) 452.6 (132.6) 433.5 (127) 414.3 (121.4) 395.0 (115.8) 375.7 (110.1) 25 (-3.9) 434.2 (127.3) 416.7 (122.1) 399.1 (117) 381.4 (111.8) 363.5 (106.5) 345.6 (101.3) 20 (-6.7) 397.7 (116.6) 381.6 (111.8) 365.4 (107.1) 349.0 (102.3) 332.5 (97.4) 316.0 (92.6) 15 (-9.4) 362.4 (106.2) 347.6 (101.9) 332.7 (97.5) 317.7 (93.1) 302.5 (88.7) 287.3 (84.2) 10 (-12.2) 328.8 (96.4) 315.3 (92.4) 301.7 (88.4) 287.9 (84.4) 274.0 (80.3) 260.1 (76.2)

5 (-15) 297.5 (87.2) 285.2 (83.6) 272.8 (79.9) 260.2 (76.3) 247.5 (72.5) 234.8 (68.8)

0 (-17.8) 269.1 (78.9) 257.9 (75.6) 246.5 (72.2) 235.0 (68.9) 223.5 (65.5) 212.0 (62.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 11 -

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS010L6-A

Compressor

Model

3DS3F46KE

TVS015L6-A

Compressor

Model

4DHNF63KE

TVS022L6-A

Compressor

Model

4DJNF76KE

TVS027L6-A

Compressor

Model

6DHNF93KE

TVS030L6-A

Compressor

Model

6DJNF11ME

TVS040L6-A

Compressor

Model

6DUNF13ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 89.1 (26.1) 85.6 (25.1) 82.1 (24.1) 78.6 (23) 75.1 (22) 71.7 (21)

-5 (-20.6) 80.6 (23.6) 77.4 (22.7) 74.2 (21.7) 71.1 (20.8) 68.0 (19.9) 64.9 (19)

-10 (-23.3) 72.5 (21.2) 69.7 (20.4) 66.8 (19.6) 64.0 (18.8) 61.1 (17.9) 58.3 (17.1)

-15 (-26.1) 64.9 (19) 62.3 (18.3) 59.8 (17.5) 57.2 (16.8) 54.6 (16) 52.1 (15.3)

-20 (-28.9) 57.7 (16.9) 55.4 (16.2) 53.1 (15.6) 50.8 (14.9) 48.4 (14.2) 46.1 (13.5)

-25 (-31.7) 50.9 (14.9) 48.9 (14.3) 46.8 (13.7) 44.7 (13.1) 42.6 (12.5) 40.5 (11.9)

-30 (-34.4) 44.7 (13.1) 42.9 (12.6) 41.0 (12) 39.1 (11.5) 37.1 (10.9) 35.2 (10.3)

-35 (-37.2) 39.0 (11.4) 37.3 (10.9) 35.6 (10.4) 33.8 (9.9) 32.0 (9.4) 30.2 (8.9)

-40 (-40) 33.7 (9.9) 32.2 (9.4) 30.6 (9) 28.9 (8.5) 27.2 (8) 25.5 (7.5) 0 (-17.8) 117.4 (34.4) 113.0 (33.1) 108.6 (31.8) 104.2 (30.5) 99.7 (29.2) 95.0 (27.8)

-5 (-20.6) 106.3 (31.2) 102.2 (30) 98.2 (28.8) 94.2 (27.6) 90.1 (26.4) 85.7 (25.1)

-10 (-23.3) 96.0 (28.1) 92.3 (27.1) 88.7 (26) 85.0 (24.9) 81.3 (23.8) 77.3 (22.7)

-15 (-26.1) 86.4 (25.3) 83.1 (24.4) 79.8 (23.4) 76.6 (22.4) 73.1 (21.4) 69.5 (20.4)

-20 (-28.9) 77.5 (22.7) 74.5 (21.8) 71.6 (21) 68.6 (20.1) 65.5 (19.2) 62.2 (18.2)

-25 (-31.7) 69.1 (20.3) 66.4 (19.5) 63.8 (18.7) 61.1 (17.9) 58.3 (17.1) 55.2 (16.2)

-30 (-34.4) 61.1 (17.9) 58.7 (17.2) 56.3 (16.5) 53.9 (15.8) 51.3 (15) 48.5 (14.2)

-35 (-37.2) 53.2 (15.6) 51.1 (15) 49.0 (14.4) 46.8 (13.7) 44.4 (13) 41.8 (12.3)

-40 (-40) 45.5 (13.3) 43.5 (12.7) 41.6 (12.2) 39.6 (11.6) 37.4 (11) 35.0 (10.3) 0 (-17.8) 144.1 (42.2) 137.7 (40.4) 131.6 (38.6) 125.8 (36.9) 120.3 (35.3) 115.1 (33.7)

-5 (-20.6) 131.0 (38.4) 125.2 (36.7) 119.6 (35.1) 114.3 (33.5) 109.2 (32) 104.3 (30.6)

-10 (-23.3) 118.6 (34.8) 113.3 (33.2) 108.2 (31.7) 103.3 (30.3) 98.6 (28.9) 94.1 (27.6)

-15 (-26.1) 106.8 (31.3) 102.0 (29.9) 97.4 (28.5) 92.9 (27.2) 88.5 (25.9) 84.2 (24.7)

-20 (-28.9) 95.6 (28) 91.3 (26.8) 87.1 (25.5) 82.9 (24.3) 78.8 (23.1) 74.8 (21.9)

-25 (-31.7) 84.9 (24.9) 81.0 (23.7) 77.2 (22.6) 73.3 (21.5) 69.5 (20.4) 65.7 (19.3)

-30 (-34.4) 74.6 (21.9) 71.2 (20.9) 67.6 (19.8) 64.1 (18.8) 60.4 (17.7) 56.7 (16.6)

-35 (-37.2) 64.8 (19) 61.7 (18.1) 58.4 (17.1) 55.1 (16.1) 51.6 (15.1) 48.0 (14.1)

-40 (-40) 55.3 (16.2) 52.5 (15.4) 49.4 (14.5) 46.3 (13.6) 42.9 (12.6) 39.3 (11.5) 0 (-17.8) 183.0 (53.6) 175.7 (51.5) 168.5 (49.4) 161.4 (47.3) 154.3 (45.2) 147.1 (43.1)

-5 (-20.6) 165.9 (48.6) 159.3 (46.7) 152.8 (44.8) 146.3 (42.9) 139.8 (41) 133.2 (39)

-10 (-23.3) 149.3 (43.8) 143.3 (42) 137.5 (40.3) 131.6 (38.6) 125.7 (36.8) 119.7 (35.1)

-15 (-26.1) 133.4 (39.1) 128.0 (37.5) 122.7 (36) 1

-20 (-28.9) 118.3 (34.7) 113.4 (33.2) 108.6 (31.8) 103.8 (30.4) 98.9 (29) 93.7 (27.5)

-25 (-31.7) 104.0 (30.5) 99.6 (29.2) 95.3 (27.9) 90.9 (26.6) 86.4 (25.3) 81.6 (23.9)

-30 (-34.4) 90.8 (26.6) 86.8 (25.4) 82.9 (24.3) 78.8 (23.1) 74.6 (21.9) 70.1 (20.5)

-35 (-37.2) 78.7 (23.1) 75.1 (22) 71.4 (20.9) 67.6 (19.8) 63.7 (18.7) 59.4 (17.4)

-40 (-40) 67.8 (19.9) 64.4 (18.9) 61.0 (17.9) 57.4 (16.8) 53.6 (15.7) 49.5 (14.5) 0 (-17.8) 200.8 (58.8) 192.0 (56.3) 183.3 (53.7) 174.7 (51.2) 166.4 (48.8) --- ---

-5 (-20.6) 181.9 (53.3) 173.9 (51) 166.1 (48.7) 158.3 (46.4) 150.8 (44.2) 143.4 (42)

-10 (-23.3) 163.8 (48) 156.7 (45.9) 149.6 (43.8) 142.6 (41.8) 135.8 (39.8) 129.1 (37.8)

-15 (-26.1) 146.7 (43) 140.3 (41.1) 134.0 (39.3) 127.7 (37.4) 121.5 (35.6) 115.4 (33.8)

-20 (-28.9) 130.6 (38.3) 124.9 (36.6) 119.1 (34.9) 113.4 (33.2) 107.8 (31.6) 102.3 (30)

-25 (-31.7) 115.5 (33.8) 110.3 (32.3) 105.1 (30.8) 99.9 (29.3) 94.8 (27.8) 89.7 (26.3)

-30 (-34.4) 101.4 (29.7) 96.7 (28.3) 92.0 (27) 87.2 (25.6) 82.4 (24.1) 77.7 (22.8)

-35 (-37.2) 88.3 (25.9) 84.0 (24.6) 79.7 (23.4) 75.2 (22) 70.7 (20.7) 66.2 (19.4)

-40 (-40) 76.3 (22.4) 72.3 (21.2) 68.2 (20) 63.9 (18.7) 59.6 (17.5) 55.2 (16.2) 0 (-17.8) 246.4 (72.2) 235.8 (69.1) 225.5 (66.1) 215.7 (63.2) 206.5 (60.5) - -

-5 (-20.6) 222.9 (65.3) 212.7 (62.3) 202.9 (59.5) 193.3 (56.7) 184.3 (54) 175.8 (51.5)

-10 (-23.3) 201.8 (59.1) 192.2 (56.3) 182.8 (53.6) 173.7 (50.9) 164.9 (48.3) 156.6 (45.9)

-15 (-26.1) 182.7 (53.5) 173.7 (50.9) 164.8 (48.3) 156.1 (45.7) 147.8 (43.3) 139.8 (41)

-20 (-28.9) 164.8 (48.3) 156.5 (45.9) 148.2 (43.4) 140.1 (41.1) 132.2 (38.7) 124.7 (36.5)

-25 (-31.7) 147.7 (43.3) 140.1 (41.1) 132.6 (38.9) 125.0 (36.6) 117.7 (34.5) 110.6 (32.4)

-30 (-34.4) 130.8 (38.3) 124.0 (36.3) 117.1 (34.3) 110.3 (32.3) 103.5 (30.3) 96.9 (28.4)

-35 (-37.2) 113.4 (33.2) 107.4 (31.5) 101.4 (29.7) 95.2 (27.9) 89.1 (26.1) 83.1 (24.4)

-40 (-40) 94.8 (27.8) 89.9 (26.3) 84.6 (24.8) 79.3 (23.2) 73.9 (21.7) 68.5 (20.1)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

17.4 (34.4) 112.0 (32.8) 106.5 (31.2)

COPELAND

09/03/14

T40-TV-PDS-19

- 12 -

CAPACITY DATA -

HIGH TEMPERATURE

R407A

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD030H8-A

Compressor

3DS3R17ME

TVD044H8-A

Compressor

4DBNR20ME

TVD050H8-A

Compressor

4DHNR22ME

TVD060H8-A

Compressor

4DJNR28ME

TVD070H8-A

Compressor

6DHNR35ME

TVD080H8-A

Compressor

6DJNR40ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 45 (7.2) 431.8 (126.5) 415.2 (121.7) 398.6 (116.8) 382.4 (112.1) 366.4 (107.4) 350.8 (102.8) 40 (4.4) 396.0 (116.1) 381.2 (111.7) 366.2 (107.3) 351.6 (103) 337.0 (98.8) 322.8 (94.6) 35 (1.7) 361.8 (106) 348.4 (102.1) 335.0 (98.2) 321.8 (94.3) 308.8 (90.5) 295.6 (86.6) 45 (7.2) 561.8 (164.6) 541.2 (158.6) 520.8 (152.6) 500.4 (146.7) 479.8 (140.6) 459.4 (134.6) 40 (4.4) 512.0 (150.1) 493.2 (144.5) 474.4 (139) 455.4 (133.5) 436.8 (128) 418.0 (122.5) 35 (1.7) 465.4 (136.4) 448.2 (131.4) 431.0 (126.3) 413.8 (121.3) 396.4 (116.2) 379.2 (111.1) 45 (7.2) 601.2 (176.2) 578.0 (169.4) 554.2 (162.4) 530.4 (155.4) 506.6 (148.5) 482.6 (141.4) 40 (4.4) 555.0 (162.7) 533.2 (156.3) 511.2 (149.8) 488.8 (143.3) 466.6 (136.7) 444.4 (130.2) 35 (1.7) 508.8 (149.1) 488.6 (143.2) 468.0 (137.2) 447.6 (131.2) 427.0 (125.1) 406.4 (119.1) 45 (7.2) 701.4 (205.6) 674.6 (197.7) 647.2 (189.7) 619.2 (181.5) 591.0 (173.2) 562.0 (164.7) 40 (4.4) 645.8 (189.3) 621.0 (182) 595.6 (174.6) 569.8 (167) 543.4 (159.3) 516.8 (151.5) 35 (1.7) 591.6 (173.4) 568.6 (166.6) 545.4 (159.8) 521.6 (152.9) 497.4 (145.8) 473.2 (138.7) 45 (7.2) 878.0 (257.3) 850.2 (249.2) 821.8 (240.8) 791.8 (232.1) 760.6 (222.9) 727.8 (213.3) 40 (4.4) 800.2 (234.5) 774.4 (227) 747.8 (219.2) 720.4 (211.1) 691.4 (202.6) 661.0 (193.7) 35 (1.7) 729.6 (213.8) 706.0 (206.9) 681.4 (199.7) 656.0 (192.3) 629.6 (184.5) 601.4 (176.3) 45 (7.2) 1046.2 (306.6) 1004.4 (294.4) 962.0 (281.9) 919.2 (269.4) 876.2 (256.8) 832.8 (244.1) 40 (4.4) 956.2 (280.2) 919.2 (269.4) 881.8 (258.4) 844.0 (247.4) 806.0 (236.2) 767.6 (225) 35 (1.7) 873.0 (255.9) 840.6 (246.4) 807.8 (236.7) 774.4 (227) 741.0 (217.2) 707.2 (207.3)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 13 -

CAPACITY DATA -

R407A

MEDIUM TEMPERATURE

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD030M8-A

Compressor

Model

3DS3R17ME

TVD044M8-A

Compressor

Model

4DBNR20ME

TVD050M8-A

Compressor

Model

4DHNR22ME

TVD060M8-A

Compressor

Model

4DJNR28ME

TVD070M8-A

Compressor

Model

6DHNR35ME

TVD080M8-A

Compressor

Model

6DJNR40ME

TVD100M8-A

Compressor

Model

6DUNR49ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 30 (-1.1) 329.1 (96.4) 317.1 (92.9) 304.9 (89.4) 293.0 (85.9) 281.2 (82.4) 269.2 (78.9) 25 (-3.9) 298.0 (87.3) 287.1 (84.1) 276.4 (81) 265.7 (77.9) 254.9 (74.7) 244.4 (71.6) 20 (-6.7) 268.6 (78.7) 258.9 (75.9) 249.1 (73) 239.4 (70.2) 229.5 (67.3) 219.9 (64.4) 15 (-9.4) 241.1 (70.7) 232.3 (68.1) 223.2 (65.4) 214.4 (62.8) 205.4 (60.2) 196.4 (57.5) 10 (-12.2) 215.0 (63) 207.1 (60.7) 199.1 (58.3) 190.7 (55.9) 182.3 (53.4) 173.9 (51)

5 (-15) 191.1 (56) 183.8 (53.9) 176.2 (51.6) 168.4 (49.4) 160.4 (47) 152.3 (44.6)

0 (-17.8) 169.1 (49.5) 161.9 (47.5) 154.8 (45.4) 147.2 (43.1) 139.4 (40.9) 131.7 (38.6) 30 (-1.1) 421.9 (123.6) 406.1 (119) 390.4 (114.4) 374.6 (109.8) 358.9 (105.2) 342.5 (100.4) 25 (-3.9) 381.2 (111.7) 366.9 (107.5) 352.6 (103.3) 338.3 (99.1) 324.0 (95) 310.0 (90.8) 20 (-6.7) 343.4 (100.6) 330.5 (96.9) 317.5 (93.1) 304.7 (89.3) 291.7 (85.5) 278.7 (81.7) 15 (-9.4) 308.3 (90.3) 296.7 (87) 285.2 (83.6) 273.4 (80.1) 261.9 (76.7) 250.1 (73.3) 10 (-12.2) 275.9 (80.9) 265.4 (77.8) 255.2 (74.8) 244.7 (71.7) 234.2 (68.6) 223.4 (65.5)

5 (-15) 245.9 (72.1) 236.7 (69.4) 227.2 (66.6) 218.0 (63.9) 208.5 (61.1) 198.9 (58.3)

0 (-17.8) 218.0 (63.9) 209.8 (61.5) 201.6 (59.1) 193.2 (56.6) 184.6 (54.1) 176.0 (51.6) 30 (-1.1) 463.5 (135.8) 444.8 (130.4) 426.1 (124.9) 407.0 (119.3) 388.1 (113.7) 369.2 (108.2) 25 (-3.9) 419.4 (122.9) 402.2 (117.9) 384.9 (112.8) 367.5 (107.7) 350.3 (102.7) 332.6 (97.5) 20 (-6.7) 376.5 (110.3) 361.2 (105.9) 345.5 (101.2) 329.7 (96.6) 314.2 (92.1) 298.2 (87.4) 15 (-9.4) 336.0 (98.5) 322.1 (94.4) 308.1 (90.3) 293.8 (86.1) 279.9 (82) 266.3 (78) 10 (-12.2) 298.0 (87.3) 285.6 (83.7) 273.0 (80) 260.4 (76.3) 248.2 (72.7) 236.3 (69.2)

5 (-15) 262.7 (77) 251.8 (73.8) 240.9 (70.6) 230.0 (67.4) 219.5 (64.3) 209.2 (61.3)

0 (-17.8) 231.0 (67.7) 221.6 (64.9) 212.3 (62.2) 203.1 (59.5) 194.0 (56.9) 185.6 (54.4) 30 (-1.1) 539.1 (158) 518.1 (151.8) 496.9 (145.6) 475.2 (139.3) 453.4 (132.9) 430.5 (126.2) 25 (-3.9) 488.7 (143.2) 469.6 (137.6) 450.5 (132) 430.9 (126.3) 411.2 (120.5) 390.6 (114.5) 20 (-6.7) 440.4 (129.1) 423.4 (124.1) 405.9 (119) 388.7 (113.9) 371.1 (108.7) 353.0 (103.5) 15 (-9.4) 394.6 (115.6) 379.3 (111.1) 363.9 (106.7) 348.8 (102.2) 333.5 (97.7) 318.4 (93.3) 10 (-12.2) 351.5 (103) 337.9 (99) 324.7 (95.1) 311.4 (91.3) 298.2 (87.4) 285.4 (83.6)

5 (-15) 311.0

0 (-17.8) 273.4 (80.1) 263.3 (77.2) 253.9 (74.4) 244.7 (71.7) 236.0 (69.2) 227.9 (66.8) 30 (-1.1) 665.7 (195.1) 644.1 (188.8) 621.6 (182.2) 598.5 (175.4) 574.1 (168.3) 548.5 (160.8) 25 (-3.9) 607.3 (178) 587.6 (172.2) 567.4 (166.3) 546.4 (160.1) 524.4 (153.7) 501.1 (146.8) 20 (-6.7) 553.6 (162.2) 535.9 (157.1) 517.7 (151.7) 499.0 (146.2) 479.2 (140.4) 458.2 (134.3) 15 (-9.4) 503.4 (147.5) 487.6 (142.9) 471.7 (138.2) 455.1 (133.4) 437.6 (128.3) 419.0 (122.8) 10 (-12.2) 455.5 (133.5) 442.1 (129.6) 428.0 (125.4) 413.7 (121.2) 398.6 (116.8) 382.4 (112.1)

5 (-15) 409.1 (1

0 (-17.8) 362.9 (106.3) 353.4 (103.6) 343.8 (100.7) 333.9 (97.9) 323.4 (94.8) 312.3 (91.5) 30 (-1.1) 796.7 (233.5) 768.4 (225.2) 739.6 (216.8) 710.2 (208.1) 680.8 (199.5) 651.0 (190.8) 25 (-3.9) 726.4 (212.9) 701.6 (205.6) 676.2 (198.2) 650.4 (190.6) 624.1 (182.9) 597.5 (175.1) 20 (-6.7) 661.3 (193.8) 639.2 (187.3) 616.6 (180.7) 593.3 (173.9) 569.7 (167) 545.8 (160) 15 (-9.4) 600.0 (175.8) 580.0 (170) 559.2 (163.9) 538.0 (157.7) 516.4 (151.3) 494.3 (144.9) 10 (-12.2) 541.4 (158.7) 522.5 (153.1) 503.0 (147.4) 483.0 (141.6) 462.4 (135.5) 441.4 (129.4)

5 (-15) 483.8 (141.8) 465.4 (136.4) 446.3 (130.8) 426.7 (125.1) 406.6 (119.2) 386.0 (113.1)

0 (-17.8) 426.1 (124.9) 407.2 (119.3) 387.9 (113.7) 367.7 (107.8) 347.1 (101.7) 326.3 (95.6) 30 (-1.1) 922.7 (270.4) 892.7 (261.6) 862.7 (252.8) 832.4 (244) 801.6 (234.9) 770.1 (225.7) 25 (-3.9) 844.4 (247.5) 817.1 (239.5) 789.6 (231.4) 761.7 (223.2) 732.9 (214.8) 703.3 (206.1) 20 (-6.7) 768.8 (225.3) 743.8 (218) 718.6 (210.6) 692.4 (202.9) 665.5 (195) 637.6 (186.8)

15 (-9.4) 696.4 (204.1) 673.3 (197.3) 649.5 (190.4) 625.0 (183.2) 599.6 (175.7) 572.7 (167.8) 10 (-12.2) 626.9 (183.7) 605.2 (177.4) 582.8 (170.8) 559.4 (164) 534.7 (156.7) 508.6 (149.1)

5 (-15) 560.3 (164.2) 539.7 (158.2) 518.1 (151.8) 495.4 (145.2) 471.0 (138) 445.2 (130.5)

0 (-17.8) 496.9 (145.6) 476.9 (139.8) 455.5 (133.5) 432.8 (126.8) 408.7 (119.8) 382.6 (112.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(91.1) 299.3 (87.7) 287.7 (84.3) 276.6 (81.1) 265.9 (77.9) 255.4 (74.8)

19.9) 397.5 (116.5) 385.8 (113.1) 373.6 (109.5) 361.0 (105.8) 347.1 (101.7)

R407A

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 14 -

CAPACITY DATA -

LOW TEMPERATURE

R407A

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD020L8-A

Compressor

Model

3DS3F46KE

TVD030L8-A

Compressor

Model

4DL3F63KE

TVD044L8-A

Compressor

Model

4DT3F76KE

TVD054L8-A

Compressor

Model

6DL3F93KE

TVD060L8-A

Compressor

Model

6DT3F11ME

TVD080L8-A

Compressor

Model

6DUNF13ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 161.1 (47.2) 155.0 (45.4) 148.7 (43.6) 142.4 (41.7) 135.9 (39.8) 129.2 (37.8)

-5 (-20.6) 142.8 (41.9) 137.1 (40.2) 131.3 (38.5) 125.2 (36.7) 119.3 (35) 113.0 (33.1)

-10 (-23.3) 126.0 (36.9) 120.8 (35.4) 115.3 (33.8) 109.6 (32.1) 104.0 (30.5) 98.3 (28.8)

-15 (-26.1) 110.7 (32.4) 105.6 (31) 100.6 (29.5) 95.6 (28) 90.3 (26.5) 84.8 (24.9)

-20 (-28.9) 96.4 (28.2) 91.8 (26.9) 87.2 (25.5) 82.3 (24.1) 77.5 (22.7) 72.7 (21.3)

-25 (-31.7) 83.2 (24.4) 79.0 (23.1) 74.6 (21.8) 70.1 (20.6) 65.7 (19.3) 61.3 (18)

-30 (-34.4) 70.8 (20.7) 66.8 (19.6) 62.8 (18.4) 58.8 (17.2) 54.8 (16.1) 50.8 (14.9)

-35 (-37.2) 58.8 (17.2) 55.2 (16.2) 51.7 (15.1) 47.9 (14) 44.3 (13) 40.7 (11.9)

-40 (-40) 47.3 (13.8) 43.9 (12.9) 40.7 (11.9) 37.4 (11) 34.2 (10) 30.9 (9) 0 (-17.8) 214.4 (62.8) 205.2 (60.1) 196.1 (57.5) 187.1 (54.8) 177.9 (52.1) --- ---

-5 (-20.6) 192.2 (56.3) 184.0 (53.9) 175.8 (51.5) 167.6 (49.1) 159.2 (46.7) --- ---

-10 (-23.3) 171.2 (50.2) 163.8 (48) 156.2 (45.8) 148.9 (43.6) 141.3 (41.4) 133.8 (39.2)

-15 (-26.1) 151.2 (44.3) 144.7 (42.4) 137.8 (40.4) 131.0 (38.4) 124.1 (36.4) 117.2 (34.3)

-20 (-28.9) 132.5 (38.8) 126.4 (37) 120.3 (35.3) 114.2 (33.5) 107.9 (31.6) 101.6 (29.8)

-25 (-31.7) 114.9 (33.7) 109.4 (32.1) 104.0 (30.5) 98.3 (28.8) 92.6 (27.1) 86.7 (25.4)

-30 (-34.4) 98.5 (28.9) 93.7 (27.4) 88.6 (26) 83.4 (24.4) 78.1 (22.9) 72.9 (21.4)

-35 (-37.2) 83.6 (24.5) 79.0 (23.1) 74.3 (21.8) 69.7 (20.4) 64.7 (19) 59.9 (17.5)

-40 (-40) 69.7 (20.4) 65.7 (19.3) 61.3 (18) 56.9 (16.7) 52.3 (15.3) 47.7 (14) 0 (-17.8) 279.1 (81.8) 267.8 (78.5) 256.4 (75.1) 245.1 (71.8) 233.3 (68.4) --- ---

-5 (-20.6) 247.2 (72.4) 236.9 (69.4) 226.2 (66.3) 215.5 (63.1) 204.5 (59.9) 193.6 (56.7)

-10 (-23.3) 217.6 (63.8) 207.9 (60.9) 198.2 (58.1) 188.4 (55.2) 178.3 (52.3) 168.0 (49.2)

-15 (-26.1) 190.3 (55.8) 181.4 (53.2) 172.6 (50.6) 163.8 (48) 154.6 (45.3) 145.1 (42.5)

-20 (-28.9) 165.3 (48.4) 157.5 (46.2) 149.7 (43.9) 141.5 (41.5) 133.4 (39.1) 125.0 (36.6)

-25 (-31.7) 143.0 (41.9) 136.1 (39.9) 129.2 (37.8) 122.2 (35.8) 114.9 (33.7) 107.5 (31.5)

-30 (-34.4) 123.3 (36.1) 117.6 (34.5) 111.5 (32.7) 105.4 (30.9) 99.3 (29.1) 92.8 (27.2)

-35 (-37.2) 106.5 (31.2) 101.6 (29.8) 96.8 (28.4) 92.0 (27) 86.7 (25.4) 81.3 (23.8)

-40 (-40) 92.6 (27.1) 89.0 (26.1) 85.3 (25) 81.3 (23.8) 77.3 (22.6) 73.1 (21.4) 0 (-17.8) 338.5 (99.2) 325.5 (95.4) 311.4 (91.3) 296.7 (87) 281.4 (82.5) --- ---

-5 (-20.6) 295.1 (86.5) 283.3 (83) 270.9 (79.4) 257.9 (75.6) 244.0 (71.5) 229.5 (67.3)

-10 (-23.3) 257.9 (75.6) 247.4 (72.5) 236.3 (69.2) 224.5 (65.8) 211.9 (62.1) 198.9 (58.3)

-15 (-26.1) 225.8 (66.2) 216.3 (63.4) 206.2 (60.4) 195.5 (57.3) 184.2 (54) 172.2 (50.5)

-20 (-28.9) 197.8 (58) 189.2 (55.5) 179.8 (52.7) 169.9 (49.8) 159.6 (46.8) 148.5 (43.5)

-25 (-31.7) 172.6 (50.6) 164.4 (48.2) 155.8 (45.7) 146.6 (43) 136.7 (40.1) 126.4 (37)

-30 (-34.4) 149.1 (43.7) 141.1 (41.4) 132.7 (38.9) 123.7 (36.2) 1

-35 (-37.2) 125.6 (36.8) 117.6 (34.5) 109.2 (32) 100.6 (29.5) 91.6 (26.8) 82.1 (24.1)

-40 (-40) 100.8 (29.5) 92.8 (27.2) 84.4 (24.7) 75.8 (22.2) 66.8 (19.6) 57.5 (16.9) 0 (-17.8) 392.3 (115) 376.7 (110.4) 360.8 (105.7) 344.2 (100.9) 327.2 (95.9) --- ---

-5 (-20.6) 348.6 (102.2) 334.3 (98) 319.6 (93.7) 304.5 (89.2) 288.5 (84.6) --- ---

-10 (-23.3) 308.3 (90.3) 295.3 (86.5) 281.8 (82.6) 267.8 (78.5) 253.3 (74.2) 237.7 (69.7)

-15 (-26.1) 271.1 (79.5) 259.1 (75.9) 247.0 (72.4) 233.9 (68.6) 220.3 (64.6) 206.0 (60.4)

-20 (-28.9) 236.5 (69.3) 225.5 (66.1) 214.2 (62.8) 202.2 (59.3) 189.4 (55.5) 176.0 (51.6)

-25 (-31.7) 204.1 (59.8) 194.0 (56.9) 183.3 (53.7) 172.2 (50.5) 160.2 (47) 147.4 (43.2)

-30 (-34.4) 173.0 (50.7) 163.8 (48) 153.7 (45.1) 143.2 (42) 131.9 (38.7) 119.5 (35)

-35 (-37.2) 143.2 (42) 134.4 (39.4) 125.0 (36.6) 114.7 (33.6) 103.7 (30.4) 92.0 (27)

-40 (-40) 113.6 (33.3) 105.2 (30.8) 96.2 (28.2) 86.3 (25.3) 75.6 (22.2) 64.1 (18.8) 0 (-17.8) 445.6 (130.6) 429.9 (126) 414.1 (121.4) 398.4 (116.8) 382.0 (111.9) --- ---

-5 (-20.6) 401.1 (117.6) 386.8 (113.4) 372.1 (109.1) 357.4 (104.7) 342.1 (100.3) --- ---

-10 (-23.3) 357.4 (104.7) 344.2 (100.9) 330.5 (96.9) 316.7 (92.8) 302.2 (88.6) --- ---

-15 (-26.1) 315.0 (92.3) 302.6 (88.7) 290.0 (85) 277.0 (81.2) 263.1 (77.1) 248.9 (72.9)

-20 (-28.9) 274.5 (80.4) 262.9 (77.1) 251.0 (73.5) 238.6 (69.9) 225.3 (66) 211.5 (62)

-25 (-31.7) 236.5 (69.3) 225.5 (66.1) 214.2 (62.8) 202.2 (59.3) 189.4 (55.5) 175.8 (51.5)

-30 (-34.4) 201.4 (59) 191.1 (56) 180.2 (52.8) 168.4 (49.4) 155.8 (45.7) 142.4 (41.7)

-35 (-37.2) 170.3 (49.9) 160.2 (47) 149.3 (43.8) 137.8 (40.4) 125.2 (36.7) 111.7 (32.7)

-40 (-40) 143.2 (42) 133.1 (39) 122.4 (35.9) 110.7 (32.4) 98.1 (28.7) 84.4 (24.7)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

14.5 (33.5) 104.8 (30.7)

CAPACITY DATA -

09/03/14

T40-TV-PDS-19

- 15 -

COPELAND

CONDENSING

UNIT

MODEL

TVD030H8-A

Compressor

Model

3DS3R17ME

TVD044H8-A

Compressor

Model

4DBNR20ME

TVD050H8-A

Compressor

Model

4DHNR22ME

TVD060H8-A

Compressor

Model

4DJNR28ME

TVD070H8-A

Compressor

Model

6DHNR35ME

TVD080H8-A

Compressor

Model

6DJNR40ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 495.0 (145.1) 476.5 (139.6) 458.6 (134.4) 441.2 (129.3) 424.4 (124.4) 407.8 (119.5) 50 (10) 456.1 (133.7) 439.5 (128.8) 423.6 (124.1) 407.8 (119.5) 392.5 (115) 377.6 (110.7) 45 (7.2) 419.0 (122.8) 404.0 (118.4) 389.8 (114.2) 375.7 (110.1) 361.8 (106) 348.4 (102.1) 40 (4.4) 383.5 (112.4) 370.2 (108.5) 357.4 (104.7) 344.8 (101.1) 332.4 (97.4) 320.3 (93.9) 35 (1.7) 349.4 (102.4) 337.9 (99) 326.3 (95.6) 315.2 (92.4) 304.1 (89.1) 293.0 (85.9) 55 (12.8) 644.5 (188.9) 621.2 (182) 598.1 (175.3) 574.8 (168.4) 551.9 (161.7) 529.0 (155) 50 (10) 588.4 (172.4) 566.6 (166) 544.7 (159.6) 522.9 (153.2) 501.3 (146.9) 479.9 (140.6) 45 (7.2) 536.6 (157.2) 516.0 (151.2) 495.6 (145.2) 475.2 (139.3) 455.1 (133.4) 435.3 (127.6) 40 (4.4) 488.7 (143.2) 469.4 (137.6) 450.2 (132) 431.6 (126.5) 412.9 (121) 394.4 (115.6) 35 (1.7) 443.9 (130.1) 426.1 (124.9) 408.5 (119.7) 391.0 (114.6) 374.0 (109.6) 357.2 (104.7) 55 (12.8) 701.6 (205.6) 665.7 (195.1) 630.6 (184.8) 596.0 (174.7) 562.4 (164.8) 529.6 (155.2) 50 (10) 648.5 (190.1) 615.9 (180.5) 583.8 (171.1) 552.5 (161.9) 522.3 (153.1) 492.9 (144.4) 45 (7.2) 596.0 (174.7) 566.6 (166) 537.8 (157.6) 509.9 (149.4) 482.8 (141.5) 457.0 (133.9) 40 (4.4) 544.7 (159.6) 518.7 (152) 493.1 (144.5) 468.3 (137.2) 444.6 (130.3) 421.9 (123.6) 35 (1.7) 495.2 (145.1) 472.3 (138.4) 449.8 (131.8) 428.2 (125.5) 407.6 (119.5) 387.9 (113.7) 55 (12.8) 826.6 (242.2) 785.8 (230.3) 745.3 (218.4) 705.6 (206.8) 666.5 (195.3) - 50 (10) 760.2 (222.8) 722.8 (211.8) 686.3 (201.1) 650.4 (190.6) 615.3 (180.3) 580.9 (170.2) 45 (7.2) 695.7 (203.9) 662.1 (194.1) 629.4 (184.4) 597.5 (175.1) 566.4 (166) 536.1 (157.1) 40 (4.4) 634.0 (185.8) 604.2 (177.1) 575.4 (168.6) 547.3 (160.4) 520.2 (152.4) 493.9 (144.8) 35 (1.7) 575.4 (168.6) 549.4 (161) 524.4 (153.7) 500.0 (146.5) 476.7 (139.7) 454.2 (133.1) 55 (12.8) 1055.7 (309.4) 1013.7 (297.1) 971.5 (284.7) 929.0 (272.3) 886.4 (259.8) - 50 (10) 954.2 (279.7) 916.7 (268.6) 878.9 (257.6) 840.6 (246.4) 802.2 (235.1) 763.6 (223.8) 45 (7.2) 860.8 (252.3) 827.4 (242.5) 793.6 (232.6) 759.8 (222.7) 725.6 (212.6) 690.9 (202.5) 40 (4.4) 775.3 (227.2) 745.9 (218.6) 716.3 (209.9) 686.3 (201.1) 656.0 (192.3) 625.2 (183.2) 35 (1.7) 697.8 (204.5) 672.2 (197) 646.4 (189.4) 620.1 (181.7) 593.5 (173.9) 566.2 (165.9) 55 (12.8) 1423.2 (417.1) 1356.0 (397.4) 1285.4 (376.7) 1212.1 (355.2) 1135.9 (332.9) - 50 (10) 1272.0 (372.8) 1209.4 (354.4) 1144.1 (335.3) 1075.8 (315.3) 1005.1 (294.6) 932.2 (273.2) 45 (7.2) 1 40 (4.4) 1000.7 (293.3) 949.8 (278.4) 896.3 (262.7) 840.0 (246.2) 781.8 (229.1) 722.0 (211.6) 35 (1.7) 886.2 (259.7) 841.1 (246.5) 793.2 (232.5) 743.2 (217.8) 691.3 (202.6) 638.0 (187)

HIGH TEMPERATURE

CAPACITY MBH (KW)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

129.6 (331) 1073.1 (314.5) 1013.5 (297) 951.1 (278.7) 886.6 (259.8) 820.1 (240.3)

R407C

AMBIENT TEMPERATURE °F (°C)

60HzTVD-A

COPELAND

09/03/14

T40-TV-PDS-19

- 16 -

CAPACITY DATA -

R407C

MEDIUM TEMPERATURE

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD030M8-A

Compressor

Model

3DS3R17ME

TVD044M8-A

Compressor

Model

4DBNR20ME

TVD050M8-A

Compressor

Model

4DHNR22ME

TVD060M8-A

Compressor

Model

4DJNR28ME

TVD070M8-A

Compressor

Model

6DHNR35ME

TVD080M8-A

Compressor

Model

6DJNR40ME

TVD100M8-A

Compressor

Model

6DUNR49ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 317.5 (93.1) 307.2 (90) 297.2 (87.1) 287.1 (84.1) 277.0 (81.2) 266.9 (78.2) 25 (-3.9) 287.3 (84.2) 278.3 (81.5) 269.2 (78.9) 260.2 (76.3) 251.2 (73.6) 241.7 (70.8) 20 (-6.7) 258.9 (75.9) 251.0 (73.5) 243.0 (71.2) 234.8 (68.8) 226.4 (66.3) 217.6 (63.8) 15 (-9.4) 232.5 (68.1) 225.3 (66) 218.0 (63.9) 210.6 (61.7) 202.7 (59.4) 194.5 (57) 10 (-12.2) 207.9 (60.9) 201.4 (59) 194.7 (57.1) 187.7 (55) 180.2 (52.8) 172.0 (50.4) 30 (-1.1) 401.9 (117.8) 385.8 (113.1) 369.6 (108.3) 353.6 (103.6) 338.1 (99.1) 322.8 (94.6) 25 (-3.9) 362.7 (106.3) 347.8 (101.9) 333.1 (97.6) 318.6 (93.4) 304.5 (89.2) 290.9 (85.2) 20 (-6.7) 325.1 (95.3) 311.6 (91.3) 298.4 (87.5) 285.6 (83.7) 273.0 (80) 260.8 (76.4) 15 (-9.4) 289.2 (84.7) 277.0 (81.2) 265.2 (77.7) 253.9 (74.4) 243.0 (71.2) 232.3 (68.1) 10 (-12.2) 254.1 (74.5) 243.4 (71.3) 233.1 (68.3) 223.2 (65.4) 213.8 (62.7) 204.8 (60) 30 (-1.1) 447.9 (131.3) 427.8 (125.4) 408.5 (119.7) 389.8 (114.2) 371.7 (108.9) 354.9 (104) 25 (-3.9) 403.0 (118.1) 385.8 (113.1) 369.0 (108.1) 352.8 (103.4) 337.5 (98.9) 323.0 (94.7) 20 (-6.7) 360.8 (105.7) 346.1 (101.4) 331.8 (97.2) 317.9 (93.2) 304.7 (89.3) 292.5 (85.7) 15 (-9.4) 321.7 (94.3) 309.1 (90.6) 296.7 (87) 285.0 (83.5) 273.6 (80.2) 262.9 (77.1) 10 (-12.2) 285.8 (83.8) 274.9 (80.6) 264.4 (77.5) 253.9 (74.4) 244.0 (71.5) 234.6 (68.7) 30 (-1.1) 520.2 (152.4) 497.9 (145.9) 476.3 (139.6) 455.7 (133.6) 435.8 (127.7) 416.6 (122.1) 25 (-3.9) 468.9 (137.4) 449.8 (131.8) 431.6 (126.5) 413.9 (121.3) 397.1 (116.4) 381.2 (111.7) 20 (-6.7) 421.3 (123.5) 405.3 (118.8) 389.8 (114.2) 375.1 (109.9) 361.0 (105.8) 347.6 (101.9) 15 (-9.4) 377.4 (110.6) 363.7 (106.6) 350.7 (102.8) 338.3 (99.1) 326.6 (95.7) 315.2 (92.4) 10 (-12.2) 336.8 (98.7) 325.3 (95.3) 314.4 (92.1) 303.7 (89) 293.6 (86) 283.9 (83.2) 30 (-1.1) 628.1 (184.1) 605.9 (177.6) 583.4 (171) 560.5 (164.3) 537.0 (157.4) 513.0 (150.4) 25 (-3.9) 565.3 (165.7) 546.2 (160.1) 526.7 (154.4) 506.5 (148.4) 485.9 (142.4) 464.7 (136.2) 20 (-6.7) 508.8 (149.1) 492.2 (144.3) 475.0 (139.2) 457.4 (134) 439.1 (128.7) 420.2 (123.2) 15 (-9.4) 457.6 (134.1) 442.9 (129.8) 428.0 (125.4) 412.2 (120.8) 395.9 (116) 378.6 ( 111) 10 (-12.2) 410.3 (120.3) 397.3 (116.4) 383.7 (112.4) 369.4 (108.3) 354.5 (103.9) 338.5 (99.2) 30 (-1.1) 786.7 (230.5) 746.6 (218.8) 704.3 (206.4) 660.0 (193.4) 614.3 (180) 567.6 (166.4) 25 (-3.9) 700.6 (205.3) 665.3 (195) 628.1 (184.1) 589.5 (172.8) 549.8 (161.1) 509.7 (149.4) 20 (-6.7) 626.2 (183.5) 595.1 (174.4) 562.8 (164.9) 529.6 (155.2) 496.0 (145.4) 462.6 (135.6) 15 (-9.4) 561.5 (164.6) 534.5 (156.6) 506.5 (148.4) 478.4 (140.2) 450.9 (132.1) 424.2 (124.3) 10 (-12.2) 503.6 (147.6) 480.1 (140.7) 456.5 (133.8) 433.4 (127) 411.8 (120.7) 391.9 (114.8) 30 (-1.1) 904.7 (265.1) 858.3 (251.5) 810.8 (237.6) 762.3 (223.4) 713.6 (209.1) 664.9 (194.9) 25 (-3.9) 807.5 (236.6) 765.7 (224.4) 723.0 (21 20 (-6.7) 718.2 (210.5) 681.2 (199.7) 643.7 (188.6) 606.5 (177.7) 569.7 (167) 534.2 (156.6) 15 (-9.4) 637.6 (186.8) 605.0 (177.3) 572.9 (167.9) 541.4 (158.7) 511.1 (149.8) 482.8 (141.5) 10 (-12.2) 565.3 (165.7) 537.4 (157.5) 510.5 (149.6) 485.1 (142.2) 461.8 (135.3) 441.2 (129.3)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

1.9) 680.2 (199.3) 637.4 (186.8) 595.1 (174.4)

COPELAND

09/03/14

T40-TV-PDS-19

- 17 -

CAPACITY DATA -

HIGH TEMPERATURE

R404A

R507

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD030H8-A

Compressor

3DS3R17ME

TVD044H8-A

Compressor

4DBNR20ME

TVD050H8-A

Compressor

4DHNR22ME

TVD060H8-A

Compressor

4DJNR28ME

TVD070H8-A

Compressor

6DHNR35ME

TVD080H8-A

Compressor

6DJNR40ME

CONDENSING

UNIT

MODEL

TVD030M8-A

Compressor

Model

3DS3R17ME

TVD044M8-A

Compressor

Model

4DBNR20ME

TVD050M8-A

Compressor

Model

4DHNR22ME

TVD060M8-A

Compressor

Model

4DJNR28ME

TVD070M8-A

Compressor

Model

6DHNR35ME

TVD080M8-A

Compressor

Model

6DJNR40ME

TVD100M8-A

Compressor

Model

6DUNR49ME

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 442.0 (129.5) 422.8 (123.9) 404.0 (118.4) 385.2 (112.9) 366.8 (107.5) 348.6 (102.2) 40 (4.4) 407.8 (119.5) 390.4 (114.4) 373.0 (109.3) 356.0 (104.3) 339.0 (99.4) 322.4 (94.5) 35 (1.7) 375.4 (110) 359.4 (105.3) 343.6 (100.7) 328.0 (96.1) 312.4 (91.6) 297.2 (87.1) 45 (7.2) 542.6 (159) 519.2 (152.2) 496.2 (145.4) 473.8 (138.9) 451.8 (132.4) 430.4 (126.1) 40 (4.4) 506.4 (148.4) 484.4 (142) 462.8 (135.6) 442.0 (129.5) 421.4 (123.5) 401.4 (117.6) 35 (1.7) 469.8 (137.7) 449.4 (131.7) 429.4 (125.8) 409.8 (120.1) 390.8 (114.5) 372.2 (109.1) 45 (7.2) 572.6 (167.8) 548.2 (160.7) 524.4 (153.7) 501.2 (146.9) 478.4 (140.2) 456.2 (133.7) 40 (4.4) 535.0 (156.8) 512.0 (150.1) 489.8 (143.5) 468.0 (137.2) 446.8 (130.9) 426.0 (124.8) 35 (1.7) 497.0 (145.7) 475.6 (139.4) 454.8 (133.3) 434.6 (127.4) 414.8 (121.6) 395.2 (115.8) 45 (7.2) 697.8 (204.5) 667.6 (195.7) 637.6 (186.9) 607.8 (178.1) 577.8 (169.3) 548.0 (160.6) 40 (4.4) 646.4 (189.4) 618.4 (181.2) 590.6 (173.1) 562.8 (164.9) 535.2 (156.9) 507.4 (148.7) 35 (1.7) 596.8 (174.9) 570.8 (167.3) 545.0 (159.7) 519.4 (152.2) 493.8 (144.7) 468.2 (137.2) 45 (7.2) 896.2 (262.6) 857.8 (251.4) 819.2 (240.1) 780.6 (228.8) 741.8 (217.4) 702.8 (206) 40 (4.4) 826.8 (242.3) 791.4 (231.9) 755.8 (221.5) 720.4 (211.1) 684.8 (200.7) 649.0 (190.2) 35 (1.7) 760.4 (222.9) 728.0 (213.4) 695.4 (203.8) 663.0 (194.3) 630.2 (184.7) 597.6 (175.1) 45 (7.2) 1022.4 (299.6) 980.6 (287.4) 938.6 (275.1) 896.4 (262.7) 854.0 (250.3) 810.8 (237.6) 40 (4.4) 949.2 (278.2) 910.4 (266.8) 871.6 (255.4) 832.4 (244) 793.0 (232.4) 753.0 (220.7) 35 (1.7) 878.0 (257.3) 842.2 (246.8) 806.4 (236.3) 770.4 (225.8) 734.0 (215.1) 697.2 (204.3)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY DATA -

CAPACITY MBH (KW)

R404A R507

R404A

AMBIENT TEMPERATURE °F (°C)

R507

MEDIUM TEMPERATURE

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 344.2 (100.9) 329.8 (96.7) 315.4 (92.4) 301.2 (88.3) 287.2 (84.2) 273.4 (80.1) 25 (-3.9) 314.8 (92.3) 301.6 (88.4) 288.6 (84.6) 275.8 (80.8) 263.2 (77.1) 250.8 (73.5) 20 (-6.7) 286.8 (84.1) 275.0 (80.6) 263.4 (77.2) 251.8 (73.8) 240.4 (70.5) 229.2 (67.2) 15 (-9.4) 260.6 (76.4) 250.0 (73.3) 239.4 (70.2) 229.2 (67.2) 219.0 (64.2) 208.8 (61.2) 10 (-12.2) 235.8 (69.1) 226.4 (66.4) 217.0 (63.6) 207.8 (60.9) 198.6 (58.2) 189.6 (55.6)

5 (-15) 212.6 (62.3) 204.2 (59.8) 196.0 (57.4) 187.6 (55) 179.6 (52.6) 171.6 (50.3)

0 (-17.8) 191.2 (56) 183.6 (53.8) 176.2 (51.6) 168.8 (49.5) 161.6 (47.4) 154.4 (45.3) 30 (-1.1) 433.4 (127) 414.4 (121.4) 396.0 (116.1) 378.0 (110.8) 360.2 (105.6) 343.0 (100.5) 25 (-3.9) 397.6 (116.5) 380.0 (111.4) 363.0 (106.4) 346.4 (101.5) 330.0 (96.7) 314.2 (92.1) 20 (-6.7) 362.6 (106.3) 346.6 (101.6) 330.8 (96.9) 315.6 (92.5) 300.6 (88.1) 286.0 (83.8) 15 (-9.4) 328.8 (96.4) 314.2 (92.1) 299.8 (87.9) 286.0 (83.8) 272.2 (79.8) 258.8 (75.8) 10 (-12.2) 296.6 (86.9) 283.4 (83.1) 270.4 (79.2) 257.8 (75.6) 245.4 (71.9) 233.2 (68.3)

5 (-15) 266.6 (78.1) 254.6 (74.6) 243.0 (71.2) 231.4 (67.8) 220.2 (64.5) 209.2 (61.3)

0 (-17.8) 238.8 (70) 228.2 (66.9) 217.8 (63.8) 207.6 (60.8) 197.4 (57.9) 187.6 (55) 30 (-1.1) 459.2 (134.6) 439.4 (128.8) 420.0 (123.1) 401.2 (117.6) 382.6 (112.1) 364.6 (106.9) 25 (-3.9) 421.8 (123.6) 403.4 (118.2) 385.6 (113) 368.0 (107.8) 351.0 (102.9) 334.2 (97.9) 20 (-6.7) 385.0 (112.8) 368.2 (107.9) 351.8 (103.1) 335.8 (98.4) 320.0 (93.8) 304.6 (89.3) 15 (-9.4) 349.6 (102.5) 334.2 (97.9) 319.2 (93.5) 304.6 (89.3) 290.2 (85) 276.0 (80.9) 10 (-12.2) 315.6 (92.5) 301.6 (88.4) 288.2 (84.5) 274.8 (80.5) 261.8 (76.7) 248.8 (72.9)

5 (-15) 283.6 (83.1) 271.2 (79.5) 259.0 (75.9) 247.2 (72.4) 235.4 (69) 223.8 (65.6)

0 (-17.8) 254.2 (74.5) 243.2 (71.3) 232.4 (68.1) 221.8 (65) 211.4 (62) 201.0 (58.9) 30 (-1.1) 548.8 (160.8) 524.8 (153.8) 501.2 (146.9) 477.6 (140) 454.2 (133.1) 430.6 (126.2) 25 (-3.9) 502.6 (147.3) 480.6 (140.8) 459.0 (134.5) 437.4 (128.2) 416.0 (121.9) 394.6 (115.6) 20 (-6.7) 458.4 (134.3) 438.4 (128.5) 418.6 (122.7) 399.0 (116.9) 379.6 (111.2) 360.2 (105.6) 15 (-9.4) 416.2 (122) 398.0 (116.6) 380.2 (111.4) 362.6 (106.3) 345.0 (101.1) 327.4 (96) 10 (-12.2) 376.0 (110.2) 359.8 (105.4) 343.6 (100.7) 327.8 (96.1) 312.0 (91.4) 296.4 (86.9)

5 (-15) 338.2 (99.1) 323.6 (94.8) 309.2 (90.6) 295.2 (86.5) 281.2 (82.4) 267.2 (78.3)

0 (-17.8) 302.6 (88.7) 289.6 (84.9) 276.8 (81.1) 264.4 (77.5) 252.2 (73.9) 239.8 (70.3) 30 (-1.1) 697.2 (204.3) 667.6 (195.7) 638.0 (187) 608.2 (178.2) 578.4 (169.5) 548.6 (160.8) 25 (-3.9) 637.2 (186.7) 610.2 (178.8) 583.2 (170.9) 556.4 (163.1) 529.2 (155.1) 502.2 (147.2) 20 (-6.7) 580.4 (170.1) 556.0 (162.9) 531.6 (155.8) 507.2 (148.6) 482.6 (141.4) 458.0 (134.2) 15 (-9.4) 527.0 (154.4) 505.0 (148) 482.8 (141.5) 460.6 (135) 438.6 (128.5) 416.4 (122) 10 (-12.2) 477.0 (139.8) 457.0 (133.9) 437.0 (128.1) 417.0 (122.2) 397.0 (116.3) 376.8 (110.4)

5 (-15) 430.4 (126.1) 412.2 (120.8) 394.0 (115.5) 375.8 (110.1) 357.6 (104.8) 339.6 (99.5)

0 (-17.8) 387.2 (113.5) 370.4 (108.6) 353.8 (103.7) 337.2 (98.8) 320.8 (94) 304.4 (89.2) 30 (-1.1) 809.4 (237.2) 776.2 (227.5) 743.2 (217.8) 710.2 (208.1) 676.8 (198.3) 643.0 (188.4) 25 (-3.9) 743.2 (217.8) 712.8 (208.9) 682.4 (200) 652.2 (191.1) 621.6 (182.2) 590.6 (173.1) 20 (-6.7) 679.8 (199.2) 652.0 (191.1) 624.2 (182.9) 596.6 (174.8) 568.8 (166.7) 540.6 (158.4) 15 (-9.4) 619.4 (181.5) 593.8 (174) 568.6 (166.6) 543.4 (159.3) 518.2 (151.9) 492.8 (144.4) 10 (-12.2) 562.2 (164.8) 538.8 (157.9) 515.8 (151.2) 493.0 (144.5) 470.2 (137.8) 447.2 (131.1)

5 (-15) 508.2 (148.9) 487.0 (142.7) 466.0 (136.6) 445.4 (130.5) 425.0 (124.6) 404.2 (118.5)

0 (-17.8) 457.8 (134.2) 438.4 (128.5) 419.4 (122.9) 401.0 (117.5) 382.6 (112.1) 364.0 (106.7) 30 (-1.1) 943.0 (276.4) 905.2 (265.3) 867.0 (254.1) 828.6 (242.8) 790.0 (231.5) 751.4 (220.2) 25 (-3.9) 868.4 (254.5) 833.4 (244.2) 798.2 (233.9) 762.8 (223.6) 727.0 (213.1) 691.2 (202.6) 20 (-6.7) 795.4 (233.1) 763.2 (223.7) 730.8 (214.2) 698.0 (204.6) 665.0 (194.9) 632.0 (185.2) 15 (-9.4) 724.8 (212.4) 695.2 (203.7) 665.4 (195) 635.4 (186.2) 605.0 (177.3) 574.6 (168.4) 10 (-12.2) 657.6 (192.7) 630.6 (184.8) 603.4 (176.8) 575.8 (168.7) 548.0 (160.6) 520.2 (152.5)

5 (-15) 595.0 (174.4) 570.4 (167.2) 545.6 (159.9) 520.4 (152.5) 495.0 (145.1) 469.6 (137.6)

0 (-17.8) 538.2 (157.7) 515.8 (151.2) 493.0 (144.5) 470.0 (137.7) 447.0 (131) 424.0 (124.3)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 18 -

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD020L6-A

Compressor

Model

3DS3F46KE

TVD030L6-A

Compressor

Model

4DL3F63KE

TVD044L6-A

Compressor

Model

4DT3F76KE

TVD054L6-A

Compressor

Model

6DL3F93KE

TVD060L6-A

Compressor

Model

6DT3F1

1ME

TVD080L6-A

Compressor

Model

6DUNF13ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 178.2 (52.2) 171.2 (50.2) 164.2 (48.1) 157.2 (46.1) 150.2 (44) 143.4 (42)

-5 (-20.6) 161.2 (47.2) 154.8 (45.4) 148.4 (43.5) 142.2 (41.7) 136.0 (39.9) 129.8 (38)

-10 (-23.3) 145.0 (42.5) 139.4 (40.9) 133.6 (39.2) 128.0 (37.5) 122.2 (35.8) 116.6 (34.2)

-15 (-26.1) 129.8 (38) 124.6 (36.5) 119.6 (35.1) 114.4 (33.5) 109.2 (32) 104.2 (30.5)

-20 (-28.9) 115.4 (33.8) 110.8 (32.5) 106.2 (31.1) 101.6 (29.8) 96.8 (28.4) 92.2 (27)

-25 (-31.7) 101.8 (29.8) 97.8 (28.7) 93.6 (27.4) 89.4 (26.2) 85.2 (25) 81.0 (23.7)

-30 (-34.4) 89.4 (26.2) 85.8 (25.1) 82.0 (24) 78.2 (22.9) 74.2 (21.7) 70.4 (20.6)

-35 (-37.2) 78.0 (22.9) 74.6 (21.9) 71.2 (20.9) 67.6 (19.8) 64.0 (18.8) 60.4 (17.7)

-40 (-40) 67.4 (19.8) 64.4 (18.9) 61.2 (17.9) 57.8 (16.9) 54.4 (15.9) 51.0 (14.9) 0 (-17.8) 234.8 (68.8) 226.0 (66.2) 217.2 (63.7) 208.4 (61.1) 199.4 (58.4) 190.0 (55.7)

-5 (-20.6) 212.6 (62.3) 204.4 (59.9) 196.4 (57.6) 188.4 (55.2) 180.2 (52.8) 171.4 (50.2)

-10 (-23.3) 192.0 (56.3) 184.6 (54.1) 177.4 (52) 170.0 (49.8) 162.6 (47.7) 154.6 (45.3)

-15 (-26.1) 172.8 (50.6) 166.2 (48.7) 159.6 (46.8) 153.2 (44.9) 146.2 (42.8) 139.0 (40.7)

-20 (-28.9) 155.0 (45.4) 149.0 (43.7) 143.2 (42) 137.2 (40.2) 131.0 (38.4) 124.4 (36.5)

-25 (-31.7) 138.2 (40.5) 132.8 (38.9) 127.6 (37.4) 122.2 (35.8) 116.6 (34.2) 110.4 (32.4)

-30 (-34.4) 122.2 (35.8) 117.4 (34.4) 112.6 (33) 107.8 (31.6) 102.6 (30.1) 97.0 (28.4)

-35 (-37.2) 106.4 (31.2) 102.2 (30) 98.0 (28.7) 93.6 (27.4) 88.8 (26) 83.6 (24.5)

-40 (-40) 91.0 (26.7) 87.0 (25.5) 83.2 (24.4) 79.2 (23.2) 74.8 (21.9) 70.0 (20.5) 0 (-17.8) 288.2 (84.5) 275.4 (80.7) 263.2 (77.1) 251.6 (73.7) 240.6 (70.5) 230.2 (67.5)

-5 (-20.6) 262.0 (76.8) 250.4 (73.4) 239.2 (70.1) 228.6 (67) 218.4 (64) 208.6 (61.1)

-10 (-23.3) 237.2 (69.5) 226.6 (66.4) 216.4 (63.4) 206.6 (60.5) 197.2 (57.8) 188.2 (55.2)

-15 (-26.1) 213.6 (62.6) 204.0 (59.8) 194.8 (57.1) 185.8 (54.5) 177.0 (51.9) 168.4 (49.4)

-20 (-28.9) 191.2 (56) 182.6 (53.5) 174.2 (51.1) 165.8 (48.6) 157.6 (46.2) 149.6 (43.8)

-25 (-31.7) 169.8 (49.8) 162.0 (47.5) 154.4 (45.3) 146.6 (43) 139.0 (40.7) 131.4 (38.5)

-30 (-34.4) 149.2 (43.7) 142.4 (41.7) 135.2 (39.6) 128.2 (37.6) 120.8 (35.4) 113.4 (33.2)

-35 (-37.2) 129.6 (38) 123.4 (36.2) 116.8 (34.2) 110.2 (32.3) 103.2 (30.2) 96.0 (28.1)

-40 (-40) 110.6 (32.4) 105.0 (30.8) 98.8 (29) 92.6 (27.1) 85.8 (25.1) 78.6 (23) 0 (-17.8) 366.0 (107.3) 351.4 (103) 337.0 (98.8) 322.8 (94.6) 308.6 (90.4) 294.2 (86.2)

-5 (-20.6) 331.8 (97.2) 318.6 (93.4) 305.6 (89.6) 292.6 (85.8) 279.6 (81.9) 266.4 (78.1)

-10 (-23.3) 298.6 (87.5) 286.6 (84) 275.0 (80.6) 263.2 (77.1) 251.4 (73.7) 239.4 (70.2)

-15 (-26.1) 266.8 (78.2) 256.0 (75) 245.4 (71.9) 234.8 (68.8) 224.0 (65.6) 213.0 (62.4)

-20 (-28.9) 236.6 (69.3) 226.8 (66.5) 217.2 (63.7) 207.6 (60.8) 197.8 (58) 187.4 (54.9)

-25 (-31.7) 208.0 (61) 199.2 (58.4) 190.6 (55.9) 181.8 (53.3) 172.8 (50.6) 163.2 (47.8)

-30 (-34.4) 181.6 (53.2) 173.6 (50.9) 165.8 (48.6) 157.6 (46.2) 149.2 (43.7) 140.2 (41.1)

-35 (-37.2) 157.4 (46.1) 150.2 (44) 142.8 (41.9) 135.2 (39.6) 127.4 (37.3) 118.8 (34.8)

-40 (-40) 135.6 (39.7) 128.8 (37.7) 122.0 (35.8) 114.8 (33.6) 107.2 (31.4) 99.0 (29) 0 (-17.8) 401.6 (117.7) 384.0 (112.5) 366.6 (107.4) 349.4 (102.4) 332.8 (97.5) --- ---

-5 (-20.6) 363.8 (106.6) 347.8 (101.9) 332.2 (97.4) 316.6 (92.8) 301.6 (88.4) 286.8 (84.1)

-10 (-23.3) 327.6 (96) 313.4 (91.8) 299.2 (87.7) 285.2 (83.6) 271.6 (79.6) 258.2 (75.7)

-15 (-26.1) 293.4 (86) 280.6 (82.2) 268.0 (78.5) 255.4 (74.9) 243.0 (71.2) 230.8 (67.6)

-20 (-28.9) 261.2 (76.5) 249.8 (73.2) 238.2 (69.8) 226.8 (66.5) 215.6 (63.2) 204.6 (60)

-25 (-31.7) 231.0 (67.7) 220.6 (64.7) 210.2 (61.6) 199.8 (58.6) 189.6 (55.6) 179.4 (52.6)

-30 (-34.4) 202.8 (59.4) 193.4 (56.7) 184.0 (53.9) 174.4 (51.1) 164.8 (48.3) 155.4 (45.5)

-35 (-37.2) 176.6 (51.8) 168.0 (49.2) 159.4 (46.7) 150.4 (44.1) 141.4 (41.4) 132.4 (38.8)

-40 (-40) 152.6 (44.7) 144.6 (42.4) 136.4 (40) 127.8 (37.5) 119.2 (34.9) 110.4 (32.4) 0 (-17.8) 492.8 (144.4) 471.6 (138.2) 451.0 (132.2) 431.4 (126.4) 413.0 (121) --- ---

-5 (-20.6) 445.8 (130.7) 425.4 (124.7) 405.8 (118.9) 386.6 (113.3) 368.6 (108) 351.6 (103)

-10 (-23.3) 403.6 (118.3) 384.4 (112.7) 365.6 (107.1) 347.4 (101.8) 329.8 (96.7) 313.2 (91.8)

-15 (-26.1) 365.4 (107.1) 347.4 (101.8) 329.6 (96.6) 312.2 (91.5) 295.6 (86.6) 279.6 (81.9)

-20 (-28.9) 329.6 (96.6) 313.0 (91.7) 296.4 (86.9) 280.2 (82.1) 264.4 (77.5) 249.4 (73.1)

-25 (-31.7) 295.4 (86.6) 280.2 (82.1) 265.2 (77.7) 250.0 (73.3) 235.4 (69) 221.2 (64.8)

-30 (-34.4) 261.6 (76.7) 248.0 (72.7) 234.2 (68.6) 220.6 (64.7) 207.0 (60.7) 193.8 (56.8)

-35 (-37.2) 226.8 (66.5) 214.8 (63) 202.8 (59.4) 190.4 (55.8) 178.2 (52.2) 166.2 (48.7)

-40 (-40) 189.6 (55.6) 179.8 (52.7) 169.2 (49.6) 158.6 (46.5) 147.8 (43.3) 137.0 (40.2)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

--- Outside Operating Range

BITZER

09/03/14

T40-TV-PDS-19

- 19 -

CAPACITY DATA -

HIGH TEMPERATURE

R407A

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS015H8-B

Compressor

4PES-15

TVS020H8-B

Compressor

4NES-20

TVS025H8-B

Compressor

4HE-25

TVS030H8-B

Compressor

4GE-30

TVS035H8-B

Compressor

6HE-35

TVS040H8-B

Compressor

6GE-40

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 45 (7.2) 204.3 (59.9) 196.4 (57.5) 188.4 (55.2) 180.4 (52.9) 172.4 (50.5) 164.4 (48.2) 40 (4.4) 186.0 (54.5) 178.6 (52.3) 171.2 (50.2) 163.8 (48) 156.3 (45.8) 149.0 (43.7) 35 (1.7) 168.7 (49.5) 161.9 (47.5) 155.0 (45.4) 148.2 (43.4) 141.3 (41.4) 134.6 (39.5) 45 (7.2) 243.0 (71.2) 233.7 (68.5) 224.5 (65.8) 215.3 (63.1) 205.9 (60.3) 196.7 (57.6) 40 (4.4) 221.2 (64.8) 212.6 (62.3) 204.0 (59.8) 195.5 (57.3) 186.9 (54.8) 178.3 (52.3) 35 (1.7) 200.7 (58.8) 192.8 (56.5) 184.9 (54.2) 176.9 (51.9) 169.1 (49.5) 161.2 (47.2) 45 (7.2) 295.6 (86.6) 284.1 (83.3) 272.7 (79.9) 261.2 (76.6) 249.8 (73.2) 238.5 (69.9) 40 (4.4) 270.2 (79.2) 259.5 (76) 248.7 (72.9) 238.0 (69.8) 227.4 (66.7) 216.8 (63.5) 35 (1.7) 245.9 (72.1) 236.0 (69.2) 226.1 (66.3) 216.2 (63.4) 206.3 (60.5) 196.5 (57.6) 45 (7.2) 344.8 (101.1) 331.9 (97.3) 318.9 (93.5) 306.0 (89.7) 293.1 (85.9) 280.1 (82.1) 40 (4.4) 315.6 (92.5) 303.5 (88.9) 291.4 (85.4) 279.3 (81.9) 267.3 (78.3) 255.3 (74.8) 35 (1.7) 287.8 (84.3) 276.6 (81.1) 265.3 (77.8) 254.1 (74.5) 243.0 (71.2) 231.8 (67.9) 45 (7.2) 449.1 (131.6) 432.0 (126.6) 415.0 (121.6) 398.0 (116.6) 381.0 (111.7) 364.1 (106.7) 40 (4.4) 410.9 (120.4) 395.0 (115.8) 379.1 (111.1) 363.3 (106.5) 347.4 (101.8) 331.7 (97.2) 35 (1.7) 374.6 (109.8) 359.8 (105.5) 345.1 (101.1) 330.4 (96.8) 315.7 (92.5) 301.1 (88.3) 45 (7.2) 519.0 (152.1) 499.5 (146.4) 480.0 (140.7) 460.4 (134.9) 441.0 (129.2) 421.7 (123.6) 40 (4.4) 474.8 (139.2) 456.5 (133.8) 438.4 (128.5) 420.2 (123.2) 402.2 (117.9) 384.1 (112.6) 35 (1.7) 432.8 (126.8) 415.9 (121.9) 399.1 (117) 382.2 (112) 365.4 (107.1) 348.7 (102.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

BITZER

09/03/14

T40-TV-PDS-19

- 20 -

CAPACITY DATA -

R407A

MEDIUM TEMPERATURE

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS015M8-B

Compressor

Model

4PES-15

TVS020M8-B

Compressor

Model

4NES-20

TVS025M8-B

Compressor

Model

4HE-25

TVS030M8-B

Compressor

Model

4GE-30

TVS035M8-B

Compressor

Model

6HE-35

TVS040M8-B

Compressor

Model

6GE-40

TVS050M8-B

Compressor

Model

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 152.5 (44.7) 146.2 (42.8) 139.9 (41) 133.7 (39.2) 127.4 (37.3) 121.1 (35.5) 25 (-3.9) 137.3 (40.3) 131.6 (38.6) 125.8 (36.9) 120.0 (35.2) 114.2 (33.5) 108.6 (31.8) 20 (-6.7) 123.2 (36.1) 117.8 (34.5) 112.6 (33) 107.3 (31.4) 102.1 (29.9) 96.8 (28.4) 15 (-9.4) 109.9 (32.2) 105.1 (30.8) 100.4 (29.4) 95.6 (28) 90.8 (26.6) 86.0 (25.2) 10 (-12.2) 97.8 (28.6) 93.3 (27.4) 89.0 (26.1) 84.7 (24.8) 80.3 (23.5) 76.0 (22.3)

5 (-15) 86.4 (25.3) 82.4 (24.2) 78.5 (23) 74.7 (21.9) 70.7 (20.7) 66.8 (19.6)

0 (-17.8) 75.9 (22.2) 72.5 (21.2) 68.9 (20.2) 65.3 (19.1) 61.8 (18.1) 58.3 (17.1) 30 (-1.1) 181.4 (53.2) 174.2 (51.1) 167.0 (48.9) 159.7 (46.8) 152.4 (44.7) 145.1 (42.5) 25 (-3.9) 163.5 (47.9) 156.9 (46) 150.2 (44) 143.5 (42.1) 136.9 (40.1) 130.3 (38.2) 20 (-6.7) 146.7 (43) 140.7 (41.2) 134.6 (39.5) 128.5 (37.7) 122.4 (35.9) 116.4 (34.1) 15 (-9.4) 131.1 (38.4) 125.7 (36.8) 120.1 (35.2) 114.7 (33.6) 109.1 (32) 103.6 (30.4) 10 (-12.2) 116.8 (34.2) 111. 7 (32.7) 106.8 (31.3) 101.7 (29.8) 96.8 (28.4) 91.8 (26.9)

5 (-15) 103.4 (30.3) 98.9 (29) 94.4 (27.7) 89.9 (26.3) 85.4 (25) 80.9 (23.7)

0 (-17.8) 91.0 (26.7) 87.0 (25.5) 83.0 (24.3) 79.0 (23.1) 74.9 (21.9) 70.9 (20.8) 30 (-1.1) 223.1 (65.4) 213.9 (62.7) 204.6 (60) 195.5 (57.3) 186.4 (54.6) 177.2 (51.9) 25 (-3.9) 201.5 (59.1) 193.1 (56.6) 184.6 (54.1) 176.1 (51.6) 167.7 (49.1) 159.4 (46.7) 20 (-6.7) 181.3 (53.1) 173.5 (50.8) 165.7 (48.6) 158.0 (46.3) 150.3 (44) 142.6 (41.8) 15 (-9.4) 162.3 (47.6) 155.2 (45.5) 148.2 (43.4) 141.0 (41.3) 134.0 (39.3) 126.9 (37.2) 10 (-12.2) 144.7 (42.4) 138.2 (40.5) 131.7 (38.6) 125.3 (36.7) 118.9 (34.8) 112.5 (33)

5 (-15) 128.2 (37.6) 122.3 (35.8) 116.4 (34.1) 110.6 (32.4) 104.7 (30.7) 98.9 (29)

0 (-17.8) 112.9 (33.1) 107.5 (31.5) 102.2 (29.9) 96.9 (28.4) 91.7 (26.9) 86.4 (25.3) 30 (-1.1) 261.5 (76.6) 251.1 (73.6) 240.7 (70.5) 230.4 (67.5) 220.1 (64.5) 209.8 (61.5) 25 (-3.9) 236.7 (69.4) 227.1 (66.6) 217.6 (63.8) 208.0 (61) 198.6 (58.2) 189.1 (55.4) 20 (-6.7) 213.4 (62.5) 204.6 (60) 195.8 (57.4) 187.1 (54.8) 178.5 (52.3) 169.8 (49.8) 15 (-9.4) 191.5 (56.1) 183.5 (53.8) 175.6 (51.5) 167.6 (49.1) 159.7 (46.8) 151.8 (44.5) 10 (-12.2) 171.2 (50.2) 163.9 (48) 156.7 (45.9) 149.4 (43.8) 142.2 (41.7) 135.0 (39.6)

5 (-15) 152.1

0 (-17.8) 134.5 (39.4) 128.5 (37.7) 122.5 (35.9) 116.7 (34.2) 1 30 (-1.1) 340.3 (99.7) 326.7 (95.7) 313.0 (91.7) 299.4 (87.7) 285.8 (83.8) 272.4 (79.8) 25 (-3.9) 308.0 (90.3) 295.4 (86.6) 282.8 (82.9) 270.3 (79.2) 257.9 (75.6) 245.4 (71.9) 20 (-6.7) 277.5 (81.3) 266.0 (77.9) 254.5 (74.6) 243.0 (71.2) 231.6 (67.9) 220.3 (64.6) 15 (-9.4) 249.1 (73) 238.5 (69.9) 228.0 (66.8) 217.6 (63.8) 207.2 (60.7) 196.8 (57.7) 10 (-12.2) 222.4 (65.2) 212.8 (62.4) 203.3 (59.6) 193.7 (56.8) 184.3 (54) 174.8 (51.2)

5 (-15) 197.6 (57.9) 188.9 (55.4) 180.3 (52.8) 171.7 (50.3) 163.1 (47.8) 154.6 (45.3)

0 (-17.8) 174.5 (51.1) 166.6 (48.8) 158.8 (46.5) 151.0 (44.3) 143.2 (42) 135.6 (39.7) 30 (-1.1) 393.2 (115.2) 377.6 (110.7) 361.9 (106.1) 346.4 (101.5) 331.0 (97) 315.5 (92.5) 25 (-3.9) 355.8 (104.3) 341.5 (100.1) 327.1 (95.9) 312.8 (91.7) 298.5 (87.5) 284.3 (83.3) 20 (-6.7) 320.8 (94) 307.5 (90.1) 294.4 (86.3) 281.3 (82.4) 268.3 (78.6) 255.3 (74.8) 15 (-9.4) 287.9 (84.4) 275.8 (80.8) 263.9 (77.3) 251.9 (73.8) 240.0 (70.3) 228.2 (66.9) 10 (-12.2) 257.3 (75.4) 246.2 (72.2) 235.4 (69) 224.5 (65.8) 213.7 (62.6) 203.0 (59.5)

5 (-15) 228.6 (67) 218.7 (64.1) 208.8 (61.2) 199.0 (58.3) 189.2 (55.5) 179.4 (52.6)

0 (-17.8) 202.0 (59.2) 193.1 (56.6) 184.2 (54) 175.2 (51.4) 166.4 (48.8) 157.6 (46.2) 30 (-1.1) 452.4 (132.6) 434.3 (127.3) 416.1 (122) 398.0 (116.6) 379.9 (111.3) 361.9 (106.1) 25 (-3.9) 410.4 (120.3) 393.6 (115.4) 376.8 (110.4) 360.2 (105.5) 343.6 (100.7) 327.0 (95.8) 20 (-6.7) 370.9 (108.7) 355.3 (104.1) 340.0 (99.6) 324.7 (95.1) 309.3 (90.7) 294.2 (86.2) 15 (-9.4) 333.5 (97.7) 319.4 (93.6) 305.3 (89.5) 291.3 (85.4) 277.3 (81.3) 263.4 (77.2) 10 (-12.2) 298.5 (87.5) 285.7 (83.7) 272.8 (79.9) 260.1 (76.2) 247.4 (72.5) 234.8 (68.8)

5 (-15) 265.8 (77.9) 254.1 (74.5) 242.4 (71.1) 230.9 (67.7) 219.5 (64.3) 208.0 (61)

0 (-17.8) 235.2 (68.9) 224.6 (65.8) 214.1 (62.7) 203.7 (59.7) 193.3 (56.7) 182.9 (53.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(44.6) 145.5 (42.7) 139.0 (40.7) 132.4 (38.8) 125.9 (36.9) 119.5 (35)

R407A

AMBIENT TEMPERATURE °F (°C)

10.8 (32.5) 104.9 (30.7)

BITZER

09/03/14

T40-TV-PDS-19

- 21 -

CAPACITY DATA -

LOW TEMPERATURE

R407A

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS012L8-B

Compressor

Model

4NES-14

TVS015L8-B

Compressor

Model

4HE-18

TVS020L8-B

Compressor

Model

4GE-23

TVS025L8-B

Compressor

Model

6HE-28

TVS030L8-B

Compressor

Model

6GE-34

TVS040L8-B

Compressor

Model

6FE-44

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 83.4 (24.4) 79.5 (23.3) 75.6 (22.2) 71.7 (21) 67.8 (19.9) 64.1 (18.8)

-5 (-20.6) 73.4 (21.5) 69.8 (20.5) 66.4 (19.4) 62.9 (18.4) 59.4 (17.4) 56.0 (16.4)

-10 (-23.3) 64.2 (18.8) 60.9 (17.8) 57.8 (16.9) 54.6 (16) 51.6 (15.1) 48.4 (14.2)

-15 (-26.1) 55.5 (16.3) 52.7 (15.4) 49.9 (14.6) 47.0 (13.8) 44.2 (13) 41.5 (12.2)

-20 (-28.9) 47.6 (13.9) 45.0 (13.2) 42.5 (12.5) 40.0 (11.7) 37.5 (11) 35.1 (10.3)

-25 (-31.7) 40.3 (11.8) 38.0 (11.1) 35.7 (10.5) 33.5 (9.8) 31.3 (9.2) 29.1 (8.5)

-30 (-34.4) 33.5 (9.8) 31.5 (9.2) 29.4 (8.6) 27.4 (8) 25.4 (7.4) 23.5 (6.9)

-35 (-37.2) 27.2 (8) 25.4 (7.4) 23.6 (6.9) 21.7 (6.4) 20.1 (5.9) 18.3 (5.4)

-40 (-40) 21.4 (6.3) 19.7 (5.8) 18.2 (5.3) 16.5 (4.8) 14.9 (4.4) 13.3 (3.9) 0 (-17.8) 109.4 (32.1) 104.4 (30.6) 99.4 (29.1) 94.6 (27.7) 89.8 (26.3) 85.1 (24.9)

-5 (-20.6) 96.6 (28.3) 92.1 (27) 87.7 (25.7) 83.3 (24.4) 78.9 (23.1) 74.6 (21.8)

-10 (-23.3) 84.6 (24.8) 80.5 (23.6) 76.5 (22.4) 72.6 (21.3) 68.7 (20.1) 64.8 (19)

-15 (-26.1) 73.4 (21.5) 69.7 (20.4) 66.2 (19.4) 62.6 (18.3) 59.1 (17.3) 55.7 (16.3)

-20 (-28.9) 62.9 (18.4) 59.6 (17.5) 56.4 (16.5) 53.2 (15.6) 50.1 (14.7) 47.0 (13.8)

-25 (-31.7) 53.0 (15.5) 50.2 (14.7) 47.3 (13.8) 44.4 (13) 41.7 (12.2) 39.0 (11.4)

-30 (-34.4) 43.8 (12.8) 41.3 (12.1) 38.6 (11.3) 36.2 (10.6) 33.7 (9.9) 31.4 (9.2)

-35 (-37.2) 35.1 (10.3) 32.9 (9.6) 30.6 (9) 28.4 (8.3) 26.3 (7.7) 24.2 (7.1)

-40 (-40) 26.9 (7.9) 24.9 (7.3) 22.9 (6.7) 20.9 (6.1) 19.0 (5.6) 17.1 (5) 0 (-17.8) 132.9 (39) 127.3 (37.3) 121.7 (35.7) 116.1 (34) 110.7 (32.4) 105.2 (30.8)

-5 (-20.6) 117.6 (34.5) 112.6 (33) 107.4 (31.5) 102.5 (30) 97.5 (28.6) 92.6 (27.1)

-10 (-23.3) 103.3 (30.3) 98.7 (28.9) 94.2 (27.6) 89.7 (26.3) 85.3 (25) 81.0 (23.7)

-15 (-26.1) 90.0 (26.4) 85.9 (25.2) 81.8 (24) 77.8 (22.8) 73.8 (21.6) 69.9 (20.5)

-20 (-28.9) 77.5 (22.7) 73.8 (21.6) 70.2 (20.6) 66.7 (19.5) 63.2 (18.5) 59.7 (17.5)

-25 (-31.7) 65.8 (19.3) 62.6 (18.3) 59.4 (17.4) 56.3 (16.5) 53.1 (15.6) 50.2 (14.7)

-30 (-34.4) 54.9 (16.1) 52.1 (15.3) 49.2 (14.4) 46.4 (13.6) 43.8 (12.8) 41.1 (12)

-35 (-37.2) 44.6 (13.1) 42.1 (12.3) 39.6 (11.6) 37.2 (10.9) 34.9 (10.2) 32.4 (9.5)

-40 (-40) 34.9 (10.2) 32.7 (9.6) 30.5 (8.9) 28.4 (8.3) 26.3 (7.7) 24.3 (7.1) 0 (-17.8) 167.9 (49.2) 160.2 (47) 152.8 (44.8) 145.3 (42.6) 138.0 (40.4) 130.7 (38.3)

-5 (-20.6) 148.1 (43.4) 141.1 (41.4) 134.4 (39.4) 127.7 (37.4) 121.1 (35.5) 114.5 (33.5)

-10 (-23.3) 129.5 (37.9) 123.3 (36.1) 117.2 (34.3) 111

-15 (-26.1) 112.1 (32.9) 106.6 (31.2) 101.1 (29.6) 95.8 (28.1) 90.4 (26.5) 85.2 (25)

-20 (-28.9) 96.0 (28.1) 91.0 (26.7) 86.2 (25.3) 81.4 (23.8) 76.7 (22.5) 71.9 (21.1)

-25 (-31.7) 81.0 (23.7) 76.5 (22.4) 72.1 (21.1) 67.9 (19.9) 63.7 (18.7) 59.5 (17.4)

-30 (-34.4) 66.8 (19.6) 62.9 (18.4) 59.0 (17.3) 55.2 (16.2) 51.6 (15.1) 47.9 (14)

-35 (-37.2) 53.4 (15.7) 50.1 (14.7) 46.6 (13.7) 43.3 (12.7) 40.0 (11.7) 36.9 (10.8)

-40 (-40) 41.0 (12) 37.9 (11.1) 34.9 (10.2) 31.9 (9.4) 29.1 (8.5) 26.3 (7.7) 0 (-17.8) 188.6 (55.3) 180.1 (52.8) 171.6 (50.3) 163.3 (47.9) 155.1 (45.5) 147.0 (43.1)

-5 (-20.6) 166.6 (48.8) 159.0 (46.6) 151.3 (44.3) 143.9 (42.2) 136.4 (40) 129.0 (37.8)

-10 (-23.3) 146.2 (42.8) 139.2 (40.8) 132.3 (38.8) 125.6 (36.8) 118.9 (34.8) 112.2 (32.9)

-15 (-26.1) 126.9 (37.2) 120.6 (35.4) 114.6 (33.6) 108.5 (31.8) 102.5 (30) 96.6 (28.3)

-20 (-28.9) 108.9 (31.9) 103.3 (30.3) 97.9 (28.7) 92.4 (27.1) 87.0 (25.5) 81.9 (24)

-25 (-31.7) 92.0 (27) 87.0 (25.5) 82.1 (24.1) 77.4 (22.7) 72.7 (21.3) 68.0 (19.9)

-30 (-34.4) 76.1 (22.3) 71.7 (21) 67.4 (19.8) 63.1 (18.5) 59.0 (17.3) 54.9 (16.1)

-35 (-37.2) 61.1 (17.9) 57.3 (16.8) 53.4 (15.7) 49.7 (14.6) 46.0 (13.5) 42.4 (12.4)

-40 (-40) 47.0 (13.8) 43.6 (12.8) 40.2 (11.8) 36.9 (10.8) 33.6 (9.8) 30.6 (9) 0 (-17.8) 225.6 (66.1) 215.7 (63.2) 205.8 (60.3) 195.9 (57.4) 186.3 (54.6) 176.8 (51.8)

-5 (-20.6) 199.8 (58.6) 190.8 (55.9) 181.8 (53.3) 172.9 (50.7) 164.2 (48.1) 155.6 (45.6)

-10 (-23.3) 175.6 (51.5) 167.4 (49.1) 159.3 (46.7) 151.3 (44.3) 143.4 (42) 135.8 (39.8)

-15 (-26.1) 152.8 (44.8) 145.4 (42.6) 138.2 (40.5) 131.0 (38.4) 124.0 (36.3) 117.1 (34.3)

-20 (-28.9) 131.4 (38.5) 124.8 (36.6) 118.3 (34.7) 112.0 (32.8) 105.7 (31) 99.6 (29.2)

-25 (-31.7) 111.3 (32.6) 105.5 (30.9) 99.8 (29.2) 94.1 (27.6) 88.6 (26) 83.2 (24.4)

-30 (-34.4) 92.4 (27.1) 87.3 (25.6) 82.2 (24.1) 77.3 (22.6) 72.3 (21.2) 67.6 (19.8)

-35 (-37.2) 74.7 (21.9) 70.1 (20.6) 65.6 (19.2) 61.2 (17.9) 56.9 (16.7) 52.8 (15.5)

-40 (-40) 57.8 (16.9) 53.8 (15.8) 49.8 (14.6) 46.0 (13.5) 42.2 (12.4) 38.5 (11.3)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

.1 (32.6) 105.2 (30.8) 99.3 (29.1)

BITZER

09/03/14

T40-TV-PDS-19

- 22 -

CAPACITY DATA -

HIGH TEMPERATURE

R407C

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS015H8-B

Compressor

Model

4PES-15

TVS020H8-B

Compressor

Model

4NES-20

TVS025H8-B

Compressor

Model

4HE-25

TVS030H8-B

Compressor

Model

4GE-30

TVS035H8-B

Compressor

Model

6HE-35

TVS040H8-B

Compressor

Model

6GE-40

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 238.0 (69.8) 229.2 (67.2) 220.3 (64.6) 211.4 (61.9) 202.4 (59.3) 193.4 (56.7) 50 (10) 217.8 (63.8) 209.5 (61.4) 201.3 (59) 193.0 (56.6) 184.6 (54.1) 176.3 (51.7) 45 (7.2) 198.6 (58.2) 190.9 (55.9) 183.2 (53.7) 175.6 (51.5) 167.9 (49.2) 160.1 (46.9) 40 (4.4) 180.4 (52.9) 173.4 (50.8) 166.3 (48.7) 159.3 (46.7) 152.1 (44.6) 145.0 (42.5) 35 (1.7) 163.4 (47.9) 157.0 (46) 150.5 (44.1) 144.0 (42.2) 137.4 (40.3) 130.8 (38.3) 55 (12.8) 282.9 (82.9) 272.6 (79.9) 262.2 (76.8) 251.8 (73.8) 241.4 (70.7) 230.9 (67.7) 50 (10) 258.6 (75.8) 249.1 (73) 239.5 (70.2) 229.8 (67.4) 220.2 (64.5) 210.5 (61.7) 45 (7.2) 235.8 (69.1) 227.0 (66.5) 218.1 (63.9) 209.2 (61.3) 200.2 (58.7) 191.3 (56.1) 40 (4.4) 214.3 (62.8) 206.1 (60.4) 198.0 (58) 189.8 (55.6) 181.5 (53.2) 173.4 (50.8) 35 (1.7) 194.0 (56.9) 186.7 (54.7) 179.1 (52.5) 171.7 (50.3) 164.1 (48.1) 156.6 (45.9) 55 (12.8) 353.2 (103.5) 340.6 (99.8) 327.9 (96.1) 315.1 (92.3) 302.3 (88.6) 289.5 (84.8) 50 (10) 324.6 (95.1) 312.8 (91.7) 300.9 (88.2) 289.1 (84.7) 277.1 (81.2) 265.1 (77.7) 45 (7.2) 297.0 (87.1) 286.1 (83.9) 275.1 (80.6) 264.1 (77.4) 253.1 (74.2) 242.0 (70.9) 40 (4.4) 270.9 (79.4) 260.7 (76.4) 250.6 (73.5) 240.5 (70.5) 230.3 (67.5) 220.1 (64.5) 35 (1.7) 246.0 (72.1) 236.8 (69.4) 227.4 (66.7) 218.1 (63.9) 208.7 (61.2) 199.4 (58.4) 55 (12.8) 411.8 (120.7) 397.4 (116.5) 383.0 (112.3) 368.6 (108) 354.0 (103.7) 339.4 (99.5) 50 (10) 378.8 (111) 365.5 (107.1) 352.1 (103.2) 338.5 (99.2) 325.1 (95.3) 311.4 (91.3) 45 (7.2) 347.2 (101.8) 334.8 (98.1) 322.5 (94.5) 310.0 (90.8) 297.5 (87.2) 284.9 (83.5) 40 (4.4) 317.1 (92.9) 305.7 (89.6) 294.2 (86.2) 282.8 (82.9) 271.2 (79.5) 259.7 (76.1) 35 (1.7) 288.5 (84.6) 278.0 (81.5) 267.5 (78.4) 257.0 (75.3) 246.4 (72.2) 235.8 (69.1) 55 (12.8) 515.8 (151.2) 497.2 (145.7) 478.5 (140.2) 459.6 (134.7) 440.6 (129.1) 421.6 (123.6) 50 (10) 473.6 (138.8) 456.2 (133.7) 438.8 (128.6) 421.3 (123.5) 403.6 (118.3) 385.9 (113.1) 45 (7.2) 433.2 (127) 417.3 (122.3) 401.1 (117.6) 384.8 (112.8) 368.6 (108) 352.2 (103.2) 40 (4.4) 395.0 (115.8) 380.2 (111.4) 365.4 (107.1) 350.5 (102.7) 335.4 (98.3) 320.3 (93.9) 35 (1.7) 358.9 (105.2) 345.3 (101.2) 331.7 (97.2) 318.0 (93.2) 304.3 (89.2) 290.4 (85.1) 55 (12.8) 604.4 (177.1) 583.2 (170.9) 561.8 (164.6) 540.3 (158.4) 518.7 (152) 496.9 (145.6) 50 (10) 555.2 (162.7) 535.6 (157) 515.8 (151.2) 495.7 (145.3) 475.7 (139.4) 455.5 (133.5) 45 (7.2) 508.4 (149) 490.2 (143.7) 471.9 (138.3) 453.5 (132.9) 434.9 (127.5) 416.2 (122) 40 (4.4) 464.0 (136) 447.3 (131.1) 430.4 (126.1) 413.5 (121.2) 396.5 (116.2) 379.3 (11 35 (1.7) 422.0 (123.7) 406.8 (119.2) 391.3 (114.7) 375.9 (110.2) 360.3 (105.6) 344.6 (101)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

1.1)

BITZER

09/03/14

T40-TV-PDS-19

- 23 -

CAPACITY DATA -

R407C

MEDIUM TEMPERATURE

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS015M8-B

Compressor

Model

4PES-15

TVS020M8-B

Compressor

Model

4NES-20

TVS025M8-B

Compressor

Model

4HE-25

TVS030M8-B

Compressor

Model

4GE-30

TVS035M8-B

Compressor

Model

6HE-35

TVS040M8-B

Compressor

Model

6GE-40

TVS050M8-B

Compressor

Model

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 147.4 (43.2) 141.5 (41.5) 135.6 (39.7) 129.7 (38) 123.7 (36.2) 117.7 (34.5) 25 (-3.9) 132.5 (38.8) 127.2 (37.3) 121.8 (35.7) 116.3 (34.1) 110.9 (32.5) 105.4 (30.9) 20 (-6.7) 118.7 (34.8) 113.8 (33.4) 108.9 (31.9) 104.0 (30.5) 98.9 (29) 94.0 (27.5) 15 (-9.4) 105.7 (31) 101.3 (29.7) 96.9 (28.4) 92.4 (27.1) 87.9 (25.8) 83.4 (24.4) 10 (-12.2) 93.8 (27.5) 89.8 (26.3) 85.8 (25.1) 81.7 (23.9) 77.7 (22.8) 73.6 (21.6)

30 (-1.1) 175.2 (51.4) 168.4 (49.4) 161.6 (47.4) 154.7 (45.3) 147.8 (43.3) 140.9 (41.3) 25 (-3.9) 157.6 (46.2) 151.4 (44.4) 145.2 (42.6) 138.9 (40.7) 132.6 (38.9) 126.3 (37) 20 (-6.7) 141.2 (41.4) 135.6 (39.7) 130.0 (38.1) 124.3 (36.4) 118.5 (34.7) 112.9 (33.1) 15 (-9.4) 126.0 (36.9) 121.0 (35.4) 115.8 (33.9) 110.7 (32.4) 105.5 (30.9) 100.4 (29.4) 10 (-12.2) 111 .9 (32.8) 107.3 (31.4) 102.7 (30.1) 98.1 (28.7) 93.5 (27.4) 88.8 (26) 30 (-1.1) 222.6 (65.2) 214.1 (62.7) 205.6 (60.3) 197.0 (57.7) 188.5 (55.2) 179.9 (52.7) 25 (-3.9) 200.7 (58.8) 192.8 (56.5) 185.0 (54.2) 177.2 (51.9) 169.5 (49.7) 161.6 (47.4) 20 (-6.7) 180.0 (52.7) 172.9 (50.7) 165.8 (48.6) 158.7 (46.5) 151.6 (44.4) 144.5 (42.3) 15 (-9.4) 160.7 (47.1) 154.2 (45.2) 147.8 (43.3) 141.3 (41.4) 134.9 (39.5) 128.5 (37.7) 10 (-12.2) 142.7 (41.8) 136.9 (40.1) 131.0 (38.4) 125.2 (36.7) 119.4 (35) 113.6 (33.3) 30 (-1.1) 261.6 (76.7) 252.0 (73.9) 242.3 (71) 232.8 (68.2) 223.1 (65.4) 213.5 (62.6) 25 (-3.9) 236.1 (69.2) 227.4 (66.7) 218.7 (64.1) 210.0 (61.5) 201.2 (59) 192.4 (56.4) 20 (-6.7) 212.3 (62.2) 204.4 (59.9) 196.6 (57.6) 188.6 (55.3) 180.6 (52.9) 172.6 (50.6) 15 (-9.4) 190.1 (55.7) 182.9 (53.6) 175.8 (51.5) 168.5 (49.4) 161.4 (47.3) 154.1 (45.2) 10 (-12.2) 169.4 (49.6) 162.9 (47.7) 156.3 (45.8) 149.8 (43.9) 143.3 (42) 136.8 (40.1) 30 (-1.1) 324.9 (95.2) 312.6 (91.6) 300.1 (87.9) 287.6 (84.3) 275.0 (80.6) 262.4 (76.9) 25 (-3.9) 293.0 (85.9) 281.8 (82.6) 270.5 (79.3) 259.1 (75.9) 247.7 (72.6) 236.3 (69.2) 20 (-6.7) 263.2 (77.1) 253.1 (74.2) 242.9 (71.2) 232.6 (68.2) 222.3 (65.1) 211.9 (62.1) 15 (-9.4) 235.4 (69) 226.4 (66.3) 217.1 (63.6) 207.9 (60.9) 198.6 (58.2) 189.2 (55.5) 10 (-12.2) 209.7 (61.5) 201.5 (59.1) 193.2 (56.6) 184.8 (54.2) 176.5 (51.7) 168.1 (49.3) 30 (-1.1) 382.6 (112.1) 368.7 (108) 354.7 (103.9) 340.5 (99.8) 326.3 (95.6) 312.1 (91.5) 25 (-3.9) 345.7 (101.3) 333.1 (97.6) 320.4 (93.9) 307.5 (90.1) 294.6 (86.3) 281.7 (82.6) 20 (-6.7) 311.1 (91.2) 299.7 (87.8) 288.2 (84.5) 276.7 (81.1) 265.1 (77.7) 253.5 (74.3) 15 (-9.4) 278.9 (81.7) 268.7 (78.7) 258.4 (75.7) 248.0 (72.7) 237.6 (69.6) 227.1 (66.6) 10 (-12.2) 249.0 (73) 239.8 (70.3) 230.6 (67.6) 221.3 (64.9) 212.0 (62.1) 202.7 (59.4) 30 (-1.1) 437.4 (128.2) 420.7 (123.3) 404.0 (118.4) 387.1 (1 25 (-3.9) 395.5 (115.9) 380.4 (111.5) 365.2 (107) 349.8 (102.5) 334.4 (98) 318.9 (93.5) 20 (-6.7) 356.3 (104.4) 342.5 (100.4) 328.8 (96.3) 314.8 (92.3) 300.8 (88.2) 286.9 (84.1) 15 (-9.4) 319.4 (93.6) 307.0 (90) 294.6 (86.3) 282.1 (82.7) 269.5 (79) 256.9 (75.3) 10 (-12.2) 285.1 (83.5) 273.9 (80.3) 262.8 (77) 251.6 (73.7) 240.2 (70.4) 229.0 (67.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

13.5) 370.2 (108.5) 353.2 (103.5)

BITZER

CONDENSING

UNIT

MODEL

TVS015H8-B

Compressor

4PES-15

TVS020H8-B

Compressor

4NES-20

TVS025H8-B

Compressor

4HE-25

TVS030H8-B

Compressor

4GE-30

TVS035H8-B

Compressor

6HE-35

TVS040H8-B

Compressor

6GE-40

CAPACITY DATA -

R404A

R507

60HzTVS-B

HIGH TEMPERATURE

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 210.3 (61.6) 201.2 (59) 192.1 (56.3) 183.2 (53.7) 174.3 (51.1) 165.4 (48.5) 40 (4.4) 193.1 (56.6) 184.6 (54.1) 176.2 (51.6) 167.8 (49.2) 159.5 (46.7) 151.2 (44.3) 35 (1.7) 176.8 (51.8) 168.9 (49.5) 161.0 (47.2) 153.2 (44.9) 145.5 (42.6) 137.8 (40.4) 45 (7.2) 251.7 (73.8) 241.1 (70.7) 230.6 (67.6) 220.1 (64.5) 209.7 (61.5) 199.4 (58.4) 40 (4.4) 231.3 (67.8) 221.4 (64.9) 211.6 (62) 201.8 (59.1) 192.1 (56.3) 182.5 (53.5) 35 (1.7) 211.8 (62.1) 202.7 (59.4) 193.5 (56.7) 184.5 (54.1) 175.4 (51.4) 166.5 (48.8) 45 (7.2) 306.7 (89.9) 293.7 (86.1) 280.9 (82.3) 268.0 (78.5) 255.2 (74.8) 242.4 (71) 40 (4.4) 283.6 (83.1) 271.6 (79.6) 259.5 (76.1) 247.5 (72.5) 235.5 (69) 223.5 (65.5) 35 (1.7) 261.6 (76.7) 250.4 (73.4) 239.1 (70.1) 227.9 (66.8) 216.7 (63.5) 205.6 (60.3) 45 (7.2) 351.3 (103) 336.3 (98.6) 321.3 (94.2) 306.3 (89.8) 291.4 (85.4) 276.4 (81) 40 (4.4) 325.1 (95.3) 311.1 (91.2) 297.1 (87.1) 283.1 (83) 269.1 (78.9) 255.1 (74.8) 35 (1.7) 300.0 (87.9) 287.0 (84.1) 273.9 (80.3) 260.9 (76.5) 247.9 (72.7) 234.9 (68.8) 45 (7.2) 452.6 (132.6) 433.8 (127.1) 415.0 (121.6) 396.3 (116.1) 377.6 (110.7) 358.9 (105.2) 40 (4.4) 418.4 (122.6) 400.8 (117.5) 383.2 (112.3) 365.7 (107.2) 348.2 (102) 330.7 (96.9) 35 (1.7) 385.7 (113) 369.3 (108.2) 352.9 (103.4) 336.6 (98.6) 320.3 (93.9) 304.0 (89.1) 45 (7.2) 514.4 (150.8) 492.4 (144.3) 470.4 (137.9) 448.4 (131.4) 426.5 (125) 404.6 (118.6) 40 (4.4) 476.1 (139.5) 455.6 (133.5) 435.0 (127.5) 414.6 (121.5) 394.1 (115.5) 373.7 (109.5) 35 (1.7) 439.4 (128.8) 420.3 (123.2) 401.2 (117.6) 382.2 (112) 363.2 (106.4) 344.2 (100.9)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BITZER

09/03/14

T40-TV-PDS-19

- 24 -

CAPACITY DATA -

MEDIUM TEMPERATURE

R404A

R507

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS015M8-B

Compressor

Model

4PES-15

TVS020M8-B

Compressor

Model

4NES-20

TVS025M8-B

Compressor

Model

4HE-25

TVS030M8-B

Compressor

Model

4GE-30

TVS035M8-B

Compressor

Model

6HE-35

TVS040M8-B

Compressor

Model

6GE-40

TVS050M8-B

Compressor

Model

6FE-50

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 161.3 (47.3) 154.0 (45.1) 146.7 (43) 139.4 (40.9) 132.3 (38.8) 125.1 (36.7) 25 (-3.9) 146.6 (43) 139.9 (41) 133.1 (39) 126.5 (37.1) 119.8 (35.1) 113.3 (33.2) 20 (-6.7) 132.8 (38.9) 126.6 (37.1) 120.4 (35.3) 114.3 (33.5) 108.2 (31.7) 102.1 (29.9) 15 (-9.4) 119.8 (35.1) 114.1 (33.4) 108.4 (31.8) 102.8 (30.1) 97.3 (28.5) 91.7 (26.9) 10 (-12.2) 107.6 (31.5) 102.4 (30) 97.2 (28.5) 92.1 (27) 87.1 (25.5) 82.0 (24)

5 (-15) 96.2 (28.2) 91.5 (26.8) 86.8 (25.4) 82.2 (24.1) 77.6 (22.7) 73.0 (21.4)

0 (-17.8) 85.5 (25.1) 81.3 (23.8) 77.1 (22.6) 72.9 (21.4) 68.7 (20.1) 64.6 (18.9) 30 (-1.1) 193.4 (56.7) 184.9 (54.2) 176.5 (51.7) 168.1 (49.3) 159.8 (46.8) 151.5 (44.4) 25 (-3.9) 176.0 (51.6) 168.2 (49.3) 160.4 (47) 152.7 (44.8) 145.0 (42.5) 137.4 (40.3) 20 (-6.7) 159.6 (46.8) 152.4 (44.7) 145.3 (42.6) 138.2 (40.5) 131.2 (38.5) 124.2 (36.4) 15 (-9.4) 144.2 (42.3) 137.6 (40.3) 131.1 (38.4) 124.7 (36.5) 118.2 (34.6) 111.8 (32.8) 10 (-12.2) 129.7 (38) 123.8 (36.3) 117.9 (34.6) 112.0 (32.8) 106.1 (31.1) 100.3 (29.4)

5 (-15) 116.2 (34.1) 110.9 (32.5) 105.5 (30.9) 100.2 (29.4) 94.9 (27.8) 89.6 (26.3)

0 (-17.8) 103.7 (30.4) 98.8 (29) 94.0 (27.5) 89.2 (26.1) 84.5 (24.8) 79.7 (23.4) 30 (-1.1) 240.5 (70.5) 230.1 (67.4) 219.7 (64.4) 209.3 (61.3) 198.9 (58.3) 188.5 (55.2) 25 (-3.9) 220.4 (64.6) 210.8 (61.8) 201.2 (59) 191.6 (56.2) 181.9 (53.3) 172.3 (50.5) 20 (-6.7) 201.3 (59) 192.5 (56.4) 183.6 (53.8) 174.8 (51.2) 165.9 (48.6) 157.1 (46) 15 (-9.4) 183.2 (53.7) 175.1 (51.3) 167.0 (48.9) 158.9 (46.6) 150.7 (44.2) 142.6 (41.8) 10 (-12.2) 166.0 (48.6) 158.6 (46.5) 151.2 (44.3) 143.8 (42.1) 136.4 (40) 129.0 (37.8)

5 (-15) 149.8 (43.9) 143.1 (41.9) 136.4 (40) 129.7 (38) 123.0 (36) 116.2 (34.1)

0 (-17.8) 134.6 (39.4) 128.6 (37.7) 122.5 (35.9) 116.4 (34.1) 110.3 (32.3) 104.2 (30.5) 30 (-1.1) 276.0 (80.9) 263.9 (77.3) 251.8 (73.8) 239.8 (70.3) 227.7 (66.7) 215.6 (63.2) 25 (-3.9) 253.1 (74.2) 242.0 (70.9) 230.8 (67.6) 219.7 (64.4) 208.5 (61.1) 197.4 (57.9) 20 (-6.7) 231.3 (67.8) 221.1 (64.8) 210.8 (61.8) 200.6 (58.8) 190.3 (55.8) 180.1 (52.8) 15 (-9.4) 210.6 (61.7) 201.3 (59) 191.9 (56.2) 182.5 (53.5) 173.2 (50.8) 163.8 (48) 10 (-12.2) 191.0 (56) 182.5 (53.5) 174.0 (51) 165.5 (48.5) 156.9 (46) 148.4 (43.5)

5 (-15) 172.5

0 (-17.8) 155.1 (45.5) 148.2 (43.4) 141.3 (41.4) 134.3 (39.4) 127.3 (37.3) 120.3 (35.3) 30 (-1.1) 354.5 (103.9) 339.3 (99.4) 324.1 (95) 308.9 (90.5) 293.7 (86.1) 278.6 (81.6) 25 (-3.9) 324.7 (95.2) 310.7 (91.1) 296.6 (86.9) 282.6 (82.8) 268.6 (78.7) 254.6 (74.6) 20 (-6.7) 296.5 (86.9) 283.6 (83.1) 270.6 (79.3) 257.7 (75.5) 244.8 (71.7) 231.9 (68) 15 (-9.4) 269.7 (79) 257.9 (75.6) 246.0 (72.1) 234.2 (68.6) 222.3 (65.1) 210.5 (61.7) 10 (-12.2) 244.4 (71.6) 233.6 (68.5) 222.8 (65.3) 212.0 (62.1) 201.2 (59) 190.3 (55.8)

5 (-15) 220.6 (64.7) 210.8 (61.8) 200.9 (58.9) 191.1 (56) 181.3 (53.1) 171.4 (50.2)

0 (-17.8) 198.2 (58.1) 189.3 (55.5) 180.4 (52.9) 171.5 (50.3) 162.6 (47.7) 153.7 (45) 30 (-1.1) 404.3 (118.5) 386.6 (113.3) 369.0 (108.1) 351.3 (103) 333.7 (97.8) 316.1 (92.6) 25 (-3.9) 370.8 (108.7) 354.5 (103.9) 338.2 (99.1) 322.0 (94.4) 305.8 (89.6) 289.5 (84.8) 20 (-6.7) 338.9 (99.3) 324.0 (95) 309.0 (90.6) 294.1 (86.2) 279.2 (81.8) 264.3 (77.5) 15 (-9.4) 308.6 (90.4) 295.0 (86.5) 281.4 (82.5) 267.8 (78.5) 254.1 (74.5) 240.5 (70.5) 10 (-12.2) 279.9 (82) 267.6 (78.4) 255.2 (74.8) 242.8 (71.2) 230.4 (67.5) 218.0 (63.9)

5 (-15) 252.9 (74.1) 241.7 (70.8) 230.5 (67.6) 219.3 (64.3) 208.1 (61) 196.8 (57.7)

0 (-17.8) 227.5 (66.7) 217.4 (63.7) 207.3 (60.8) 197.2 (57.8) 187.1 (54.8) 177.0 (51.9) 30 (-1.1) 470.9 (138) 450.0 (131.9) 429.0 (125.7) 408.0 (1 25 (-3.9) 433.6 (127.1) 414.3 (121.4) 395.0 (115.8) 375.6 (110.1) 356.3 (104.4) 336.9 (98.7) 20 (-6.7) 397.9 (116.6) 380.1 (111.4) 362.4 (106.2) 344.6 (101) 326.9 (95.8) 309.1 (90.6) 15 (-9.4) 363.7 (106.6) 347.5 (101.8) 331.3 (97.1) 315.1 (92.3) 298.9 (87.6) 282.6 (82.8) 10 (-12.2) 331.2 (97.1) 316.5 (92.8) 301.7 (88.4) 287.0 (84.1) 272.2 (79.8) 257.4 (75.4)

5 (-15) 300.2 (88) 287.0 (84.1) 273.6 (80.2) 260.3 (76.3) 246.9 (72.4) 233.4 (68.4)

0 (-17.8) 271.0 (79.4) 259.0 (75.9) 247.0 (72.4) 235.0 (68.9) 222.8 (65.3) 210.7 (61.7)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(50.6) 164.9 (48.3) 157.2 (46.1) 149.4 (43.8) 141.7 (41.5) 133.9 (39.2)

R404A R507

AMBIENT TEMPERATURE °F (°C)

19.6) 387.1 (113.4) 366.1 (107.3)

BITZER

09/03/14

T40-TV-PDS-19

- 25 -

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS012L6-B

Compressor

Model

4NES-14

TVS015L6-B

Compressor

Model

4HE-18

TVS020L6-B

Compressor

Model

4GE-23

TVS025L6-B

Compressor

Model

6HE-28

TVS030L6-B

Compressor

Model

6GE-34

TVS040L6-B

Compressor

Model

6FE-44

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 93.5 (27.4) 89.0 (26.1) 84.4 (24.7) 79.9 (23.4) 75.3 (22.1) 70.8 (20.7)

-5 (-20.6) 83.7 (24.5) 79.6 (23.3) 75.5 (22.1) 71.3 (20.9) 67.2 (19.7) 63.1 (18.5)

-10 (-23.3) 74.5 (21.8) 70.8 (20.7) 67.0 (19.6) 63.3 (18.6) 59.6 (17.5) 55.9 (16.4)

-15 (-26.1) 65.9 (19.3) 62.5 (18.3) 59.2 (17.3) 55.8 (16.4) 52.5 (15.4) 49.2 (14.4)

-20 (-28.9) 57.9 (17) 54.9 (16.1) 51.9 (15.2) 48.9 (14.3) 45.9 (13.5) 42.9 (12.6)

-25 (-31.7) 50.4 (14.8) 47.8 (14) 45.1 (13.2) 42.4 (12.4) 39.7 (11.6) 37.0 (10.8)

-30 (-34.4) 43.6 (12.8) 41.2 (12.1) 38.8 (11.4) 36.4 (10.7) 34.0 (10) 31.6 (9.3)

-35 (-37.2) 37.3 (10.9) 35.1 (10.3) 33.0 (9.7) 30.8 (9) 28.7 (8.4) 26.5 (7.8)

-40 (-40) 31.5 (9.2) 29.5 (8.6) 27.6 (8.1) 25.7 (7.5) 23.7 (6.9) 21.8 (6.4) 0 (-17.8) 124.9 (36.6) 119.2 (34.9) 113.5 (33.3) 107.8 (31.6) 102.1 (29.9) 96.4 (28.3)

-5 (-20.6) 112.7 (33) 107.5 (31.5) 102.3 (30) 97.1 (28.5) 92.0 (27) 86.8 (25.4)

-10 (-23.3) 101.2 (29.7) 96.5 (28.3) 91.8 (26.9) 87.1 (25.5) 82.4 (24.1) 77.7 (22.8)

-15 (-26.1) 90.2 (26.4) 86.0 (25.2) 81.8 (24) 77.6 (22.7) 73.3 (21.5) 69.2 (20.3)

-20 (-28.9) 80.0 (23.4) 76.2 (22.3) 72.4 (21.2) 68.6 (20.1) 64.8 (19) 61.1 (17.9)

-25 (-31.7) 70.3 (20.6) 66.9 (19.6) 63.5 (18.6) 60.1 (17.6) 56.8 (16.6) 53.4 (15.6)

-30 (-34.4) 61.2 (17.9) 58.2 (17.1) 55.2 (16.2) 52.2 (15.3) 49.2 (14.4) 46.2 (13.5)

-35 (-37.2) 52.8 (15.5) 50.1 (14.7) 47.4 (13.9) 44.7 (13.1) 42.0 (12.3) 39.4 (11.5)

-40 (-40) 44.9 (13.2) 42.5 (12.5) 40.1 (11.8) 37.7 (11) 35.3 (10.3) 32.9 (9.6) 0 (-17.8) 150.1 (44) 143.4 (42) 136.7 (40.1) 130.0 (38.1) 123.3 (36.1) 116.7 (34.2)

-5 (-20.6) 135.4 (39.7) 129.3 (37.9) 123.3 (36.1) 117.2 (34.3) 111.2 (32.6) 105.2 (30.8)

-10 (-23.3) 121.5 (35.6) 116.0 (34) 110.6 (32.4) 105.2 (30.8) 99.7 (29.2) 94.3 (27.6)

-15 (-26.1) 108.4 (31.8) 103.5 (30.3) 98.7 (28.9) 93.8 (27.5) 89.0 (26.1) 84.1 (24.6)

-20 (-28.9) 96.1 (28.2) 91.8 (26.9) 87.4 (25.6) 83.1 (24.4) 78.8 (23.1) 74.5 (21.8)

-25 (-31.7) 84.6 (24.8) 80.8 (23.7) 76.9 (22.5) 73.1 (21.4) 69.3 (20.3) 65.4 (19.2)

-30 (-34.4) 73.9 (21.7) 70.5 (20.7) 67.1 (19.7) 63.7 (18.7) 60.3 (17.7) 56.9 (16.7)

-35 (-37.2) 63.9 (18.7) 60.9 (17.8) 57.9 (17) 54.9 (16.1) 51.9 (15.2) 48.9 (14.3)

-40 (-40) 54.6 (16) 52.0 (15.2) 49.3 (14.4) 46.6 (13.7) 44.0 (12.9) 41.4 (12.1) 0 (-17.8) 189.3 (55.5) 180.8 (53) 172.2 (50.5) 163.7 (48) 155.2 (45.5) 146.8 (43)

-5 (-20.6) 170.4 (49.9) 162.7 (47.7) 154.9 (45.4) 147.2 (43.1) 139.5 (40.9) 131.8 (38.6)

-10 (-23.3) 152.6 (44.7) 145.6 (42.7) 138.6 (40.6) 131.7 (38.6) 124.7 (36.5) 117.7 (34.5)

-15 (-26.1) 135.9 (39.8) 129.6 (38) 123.3 (36.1) 117.0 (34.3) 1

-20 (-28.9) 120.3 (35.3) 114.6 (33.6) 108.9 (31.9) 103.3 (30.3) 97.6 (28.6) 92.0 (27)

-25 (-31.7) 105.6 (30.9) 100.6 (29.5) 95.5 (28) 90.4 (26.5) 85.4 (25) 80.3 (23.5)

-30 (-34.4) 92.0 (27) 87.5 (25.6) 82.9 (24.3) 78.4 (23) 73.9 (21.7) 69.3 (20.3)

-35 (-37.2) 79.3 (23.2) 75.3 (22.1) 71.2 (20.9) 67.1 (19.7) 63.1 (18.5) 59.0 (17.3)

-40 (-40) 67.6 (19.8) 63.9 (18.7) 60.3 (17.7) 56.6 (16.6) 53.0 (15.5) 49.3 (14.4) 0 (-17.8) 215.9 (63.3) 206.4 (60.5) 197.0 (57.7) 187.5 (55) 178.0 (52.2) 168.4 (49.4)

-5 (-20.6) 195.7 (57.4) 187.2 (54.9) 178.6 (52.3) 170.0 (49.8) 161.4 (47.3) 152.7 (44.8)

-10 (-23.3) 176.5 (51.7) 168.8 (49.5) 161.1 (47.2) 153.4 (45) 145.6 (42.7) 137.8 (40.4)

-15 (-26.1) 158.3 (46.4) 151.4 (44.4) 144.6 (42.4) 137.6 (40.3) 130.7 (38.3) 123.7 (36.3)

-20 (-28.9) 141.1 (41.4) 135.0 (39.6) 128.9 (37.8) 122.7 (36) 116.5 (34.1) 110.2 (32.3)

-25 (-31.7) 125.0 (36.6) 119.5 (35) 114.1 (33.4) 108.6 (31.8) 103.0 (30.2) 97.4 (28.5)

-30 (-34.4) 109.8 (32.2) 105.0 (30.8) 100.2 (29.4) 95.3 (27.9) 90.3 (26.5) 85.3 (25)

-35 (-37.2) 95.7 (28) 91.4 (26.8) 87.1 (25.5) 82.7 (24.2) 78.3 (22.9) 73.8 (21.6)

-40 (-40) 82.5 (24.2) 78.7 (23.1) 74.8 (21.9) 70.9 (20.8) 66.9 (19.6) 62.9 (18.4) 0 (-17.8) 256.4 (75.1) 245.0 (71.8) 233.6 (68.5) 222.1 (65.1) 210.7 (61.7) 199.2 (58.4)

-5 (-20.6) 232.4 (68.1) 222.0 (65.1) 211.7 (62) 201.3 (59) 190.9 (55.9) 180.5 (52.9)

-10 (-23.3) 209.4 (61.4) 200.1 (58.6) 190.8 (55.9) 181.4 (53.2) 172.0 (50.4) 162.6 (47.7)

-15 (-26.1) 187.6 (55) 179.3 (52.5) 170.9 (50.1) 162.4 (47.6) 154.0 (45.1) 145.5 (42.6)

-20 (-28.9) 167.0 (48.9) 159.5 (46.7) 152.0 (44.5) 144.4 (42.3) 136.8 (40.1) 129.1 (37.8)

-25 (-31.7) 147.6 (43.3) 140.9 (41.3) 134.1 (39.3) 127.3 (37.3) 120.4 (35.3) 113.5 (33.3)

-30 (-34.4) 129.3 (37.9) 123.3 (36.1) 117.2 (34.3) 111.1 (32.6) 104.9 (30.7) 98.7 (28.9)

-35 (-37.2) 112.2 (32.9) 106.8 (31.3) 101.3 (29.7) 95.7 (28) 90.1 (26.4) 84.5 (24.8)

-40 (-40) 96.2 (28.2) 91.3 (26.8) 86.2 (25.3) 81.2 (23.8) 76.1 (22.3) 70.9 (20.8)

CAPACITY MBH (KW)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

10.7 (32.4) 104.5 (30.6)

BITZER

09/03/14

T40-TV-PDS-19

- 26 -

CAPACITY DATA -

R404A

R507

EXTENDED LOW TEMPERATURE

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS008V6-B

Compressor

Model

S4N-8.2

TVS012V6-B

Compressor

Model

S4G-12.2

TVS016V6-B

Compressor

Model

S6J-16.2

TVS020V6-B

Compressor

Model

S6H-20.2

TVS025V6-B

Compressor

Model

S6G-25.2

TVS030V6-B

Compressor

Model

S6F-30.2

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

-25 (-31.7) 39.1 (11.5) 38.6 (11.3) 38.0 (11.1) 37.5 (11) 36.9 (10.8) 36.3 (10.6)

-30 (-34.4) 34.9 (10.2) 34.4 (10.1) 33.9 (9.9) 33.4 (9.8) 32.8 (9.6) 32.3 (9.5)

-35 (-37.2) 31.0 (9.1) 30.5 (8.9) 30.1 (8.8) 29.6 (8.7) 29.1 (8.5) 28.5 (8.4)

-40 (-40) 27.4 (8) 27.0 (7.9) 26.6 (7.8) 26.1 (7.6) 25.6 (7.5) 25.1 (7.4)

-45 (-42.8) 24.2 (7.1) 23.8 (7) 23.4 (6.9) 23.0 (6.7) 22.5 (6.6) 22.0 (6.4)

-50 (-45.6) 21.2 (6.2) 20.9 (6.1) 20.5 (6) 20.1 (5.9) 19.7 (5.8) 19.2 (5.6)

-55 (-48.3) 18.5 (5.4) 18.2 (5.3) 17.8 (5.2) 17.5 (5.1) 17.1 (5) 16.7 (4.9)

-60 (-51.1) 16.0 (4.7) 15.7 (4.6) 15.4 (4.5) 15.1 (4.4) 14.8 (4.3) 14.4 (4.2)

-25 (-31.7) 60.7 (17.8) 59.8 (17.5) 58.9 (17.3) 57.9 (17) 56.9 (16.7) 55.9 (16.4)

-30 (-34.4) 54.9 (16.1) 54.0 (15.8) 53.1 (15.6) 52.2 (15.3) 51.2 (15) 50.1 (14.7)

-35 (-37.2) 49.3 (14.4) 48.5 (14.2) 47.6 (14) 46.7 (13.7) 45.8 (13.4) 44.8 (13.1)

-40 (-40) 44.1 (12.9) 43.3 (12.7) 42.5 (12.5) 41.6 (12.2) 40.7 (11.9) 39.8 (11.7)

-45 (-42.8) 39.1 (11.5) 38.4 (11.3) 37.6 (11) 36.8 (10.8) 36.0 (10.6) 35.1 (10.3)

-50 (-45.6) 34.5 (10.1) 33.9 (9.9) 33.1 (9.7) 32.4 (9.5) 31.6 (9.3) 30.9 (9.1)

-55 (-48.3) 30.2 (8.9) 29.6 (8.7) 29.0 (8.5) 28.3 (8.3) 27.6 (8.1) 27.0 (7.9)

-60 (-51.1) 26.2 (7.7) 25.7 (7.5) 25.1 (7.4) 24.5 (7.2) 24.0 (7) 23.4 (6.9)

-25 (-31.7) 84.1 (24.6) 82.8 (24.3) 81.5 (23.9) 80.2 (23.5) 78.9 (23.1) 77.7 (22.8)

-30 (-34.4) 76.1 (22.3) 74.8 (21.9) 73.6 (21.6) 72.3 (21.2) 71.0 (20.8) 69.8 (20.5)

-35 (-37.2) 68.5 (20.1) 67.3 (19.7) 66.1 (19.4) 64.9 (19) 63.7 (18.7) 62.4 (18.3)

-40 (-40) 61.4 (18) 60.3 (17.7) 59.1 (17.3) 58.0 (17) 56.8 (16.6) 55.6 (16.3)

-45 (-42.8) 54.7 (16) 53.7 (15.7) 52.6 (15.4) 51.5 (15.1) 50.4 (14.8) 49.3 (14.4)

-50 (-45.6) 48.5 (14.2) 47.5 (13.9) 46.5 (13.6) 45.5 (13.3) 44.5 (13) 43.5 (12.7)

-55 (-48.3) 42.7 (12.5) 41.8 (12.3) 40.9 (12) 40.0 (11.7) 39.0 (11.4) 38.1 (11.2)

-60 (-51.1) 37.3 (10.9) 36.5 (10.7) 35.7 (10.5) 34.9 (10.2) 34.1 (10) 33.2 (9.7)

-25 (-31.7) 98.8 (29) 97.4 (28.5) 95.9 (28.1) 94.4 (27.7) 92.8 (27.2) 91.2 (26.7)

-30 (-34.4) 89.5 (26.2) 88.1 (25.8) 86.6 (25.4) 85.1 (24.9) 83.6 (24.5) 82.0 (24)

-35 (-37.2)

-40 (-40) 72.2 (21.2) 70.9 (20.8) 69.6 (20.4) 68.2 (20) 66.8 (19.6) 65.4 (19.2)

-45 (-42.8) 64.3 (18.8) 63.1 (18.5) 61.9 (18.1) 60.6 (17.8) 59.3 (17.4) 57.9 (17)

-50 (-45.6) 56.9 (16.7) 55.8 (16.4) 54.7 (16) 53.5 (15.7) 52.3 (15.3) 51.1 (15)

-55 (-48.3) 50.0 (14.7) 49.0 (14.4) 48.0 (14.1) 46.9 (13.7) 45.8 (13.4) 44.7 (13.1)

-60 (-51.1) 43.7 (12.8) 42.8 (12.5) 41.8 (12.3) 40.9 (12) 39.9 (11.7) 39.0 (11.4)

-25 (-31.7) 1

-30 (-34.4) 101.6 (29.8) 100.0 (29.3) 98.4 (28.8) 96.6 (28.3) 94.8 (27.8) 93.0 (27.3)

-35 (-37.2) 91.6 (26.8) 90.1 (26.4) 88.5 (25.9) 86.8 (25.4) 85.1 (24.9) 83.3 (24.4)

-40 (-40) 82.1 (24.1) 80.7 (23.7) 79.1 (23.2) 77.5 (22.7) 75.9 (22.2) 74.3 (21.8)

-45 (-42.8) 73.2 (21.5) 71.9 (21.1) 70.4 (20.6) 68.9 (20.2) 67.4 (19.8) 65.9 (19.3)

-50 (-45.6) 64.9 (19) 63.6 (18.6) 62.3 (18.3) 60.9 (17.8) 59.5 (17.4) 58.1 (17)

-55 (-48.3) 57.1 (16.7) 55.9 (16.4) 54.7 (16) 53.4 (15.6) 52.2 (15.3) 50.9 (14.9)

-60 (-51.1) 49.8 (14.6) 48.8 (14.3) 47.7 (14) 46.6 (13.7) 45.5 (13.3) 44.4 (13)

-25 (-31.7) 133.3 (39.1) 131.1 (38.4) 128.9 (37.8) 126.6 (37.1) 124.3 (36.4) 122.0 (35.8)

-30 (-34.4) 120.7 (35.4) 118.7 (34.8) 116.5 (34.1) 114.3 (33.5) 112.1 (32.9) 109.8 (32.2)

-35 (-37.2) 108.8 (31.9) 106.9 (31.3) 104.8 (30.7) 102.7 (30.1) 100.6 (29.5) 98.5 (28.9)

-40 (-40) 97.6 (28.6) 95.7 (28) 93.8 (27.5) 91.8 (26.9) 89.8 (26.3) 87.8 (25.7)

-45 (-42.8) 87.0 (25.5) 85.3 (25) 83.5 (24.5) 81.7 (23.9) 79.8 (23.4) 78.0 (22.9)

-50 (-45.6) 77.1 (22.6) 75.5 (22.1) 73.9 (21.7) 72.2 (21.2) 70.5 (20.7) 68.9 (20.2)

-55 (-48.3) 67.9 (19.9) 66.5 (19.5) 65.0 (19) 63.5 (18.6) 62.0 (18.2) 60.5 (17.7)

-60 (-51.1) 59.3 (17.4) 58.1 (17) 56.8 (16.6) 55.4 (16.2) 54.1 (15.9) 52.8 (15.5)

80.6 (23.6) 79.3 (23.2) 77.8 (22.8) 76.4 (22.4) 74.9 (22) 73.4 (21.5)

12.2 (32.9) 110.6 (32.4) 108.9 (31.9) 107.1 (31.4) 105.2 (30.8) 103.4 (30.3)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

BITZER

09/03/14

T40-TV-PDS-19

- 27 -

CAPACITY DATA -

HIGH TEMPERATURE

R407A

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD030H8-B

Compressor

4PES-15

TVD040H8-B

Compressor

4NES-20

TVD050H8-B

Compressor

4HE-25

TVD060H8-B

Compressor

4GE-30

TVD070H8-B

Compressor

6HE-35

TVD080H8-B

Compressor

6GE-40

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 408.7 (119.8) 392.7 (115.1) 376.7 (110.4) 360.8 (105.7) 344.8 (101.1) 328.9 (96.4) 40 (4.4) 371.9 (109) 357.2 (104.7) 342.3 (100.3) 327.6 (96) 312.7 (91.6) 298.0 (87.3) 35 (1.7) 337.5 (98.9) 323.8 (94.9) 310.0 (90.8) 296.3 (86.8) 282.7 (82.8) 269.2 (78.9) 45 (7.2) 485.9 (142.4) 467.5 (137) 449.0 (131.6) 430.5 (126.2) 411.8 (120.7) 393.3 (115.3) 40 (4.4) 442.5 (129.7) 425.3 (124.6) 408.0 (119.6) 391.0 (114.6) 373.8 (109.5) 356.6 (104.5) 35 (1.7) 401.3 (117.6) 385.6 (113) 369.8 (108.4) 353.9 (103.7) 338.1 (99.1) 322.4 (94.5) 45 (7.2) 591.2 (173.2) 568.3 (166.5) 545.4 (159.8) 522.5 (153.1) 499.6 (146.4) 476.9 (139.8) 40 (4.4) 540.3 (158.4) 518.9 (152.1) 497.5 (145.8) 476.1 (139.5) 454.9 (133.3) 433.7 (127.1) 35 (1.7) 491.8 (144.1) 472.1 (138.4) 452.1 (132.5) 432.4 (126.7) 412.7 (120.9) 392.9 (115.2) 45 (7.2) 689.6 (202.1) 663.8 (194.5) 637.8 (186.9) 611.9 (179.3) 586.1 (171.8) 560.3 (164.2) 40 (4.4) 631.3 (185) 606.9 (177.9) 582.8 (170.8) 558.6 (163.7) 534.7 (156.7) 510.5 (149.6) 35 (1.7) 575.6 (168.7) 553.1 (162.1) 530.7 (155.5) 508.2 (148.9) 485.9 (142.4) 463.7 (135.9) 45 (7.2) 898.2 (263.2) 863.9 (253.2) 829.9 (243.2) 795.9 (233.3) 762.1 (223.3) 728.3 (213.4) 40 (4.4) 821.7 (240.8) 790.0 (231.5) 758.1 (222.2) 726.6 (212.9) 694.9 (203.7) 663.4 (194.4) 35 (1.7) 749.3 (219.6) 719.7 (210.9) 690.3 (202.3) 660.9 (193.7) 631.5 (185.1) 602.3 (176.5) 45 (7.2) 1038.0 (304.2) 999.0 (292.8) 959.9 (281.3) 920.9 (269.9) 882.0 (258.5) 843.4 (247.2) 40 (4.4) 949.6 (278.3) 913.1 (267.6) 876.8 (256.9) 840.4 (246.3) 804.3 (235.7) 768.2 (225.1) 35 (1.7) 865.6 (253.7) 831.8 (243.8) 798.2 (233.9) 764.4 (224) 730.8 (214.2) 697.4 (204.4)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

BITZER

09/03/14

T40-TV-PDS-19

- 28 -

CAPACITY DATA -

R407A

MEDIUM TEMPERATURE

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD030M8-B

Compressor

Model

4PES-15

TVD040M8-B

Compressor

Model

4NES-20

TVD050M8-B

Compressor

Model

4HE-25

TVD060M8-B

Compressor

Model

4GE-30

TVD070M8-B

Compressor

Model

6HE-35

TVD080M8-B

Compressor

Model

6GE-40

TVD100M8-B

Compressor

Model

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 304.9 (89.4) 292.3 (85.7) 279.7 (82) 267.3 (78.3) 254.7 (74.7) 242.1 (71) 25 (-3.9) 274.7 (80.5) 263.1 (77.1) 251.6 (73.7) 240.0 (70.3) 228.5 (67) 217.1 (63.6) 20 (-6.7) 246.3 (72.2) 235.6 (69.1) 225.1 (66) 214.6 (62.9) 204.1 (59.8) 193.6 (56.7) 15 (-9.4) 219.9 (64.4) 210.2 (61.6) 200.8 (58.8) 191.1 (56) 181.7 (53.2) 172.0 (50.4) 10 (-12.2) 195.5 (57.3) 186.7 (54.7) 178.1 (52.2) 169.5 (49.7) 160.7 (47.1) 152.0 (44.6)

5 (-15) 172.8 (50.7) 164.9 (48.3) 157.1 (46) 149.3 (43.8) 141.3 (41.4) 133.6 (39.1)

0 (-17.8) 151.8 (44.5) 144.9 (42.5) 137.8 (40.4) 130.6 (38.3) 123.7 (36.2) 116.6 (34.2) 30 (-1.1) 362.9 (106.3) 348.4 (102.1) 333.9 (97.9) 319.4 (93.6) 304.7 (89.3) 290.2 (85.1) 25 (-3.9) 327.0 (95.8) 313.7 (91.9) 300.3 (88) 287.1 (84.1) 273.8 (80.3) 260.6 (76.4) 20 (-6.7) 293.4 (86) 281.4 (82.5) 269.2 (78.9) 257.0 (75.3) 244.9 (71.8) 232.9 (68.3) 15 (-9.4) 262.3 (76.9) 251.4 (73.7) 240.2 (70.4) 229.3 (67.2) 218.2 (63.9) 207.3 (60.7) 10 (-12.2) 233.5 (68.4) 223.4 (65.5) 213.6 (62.6) 203.5 (59.6) 193.6 (56.7) 183.5 (53.8)

5 (-15) 206.9 (60.6) 197.8 (58) 188.8 (55.3) 179.8 (52.7) 170.7 (50) 161.7 (47.4)

0 (-17.8) 182.1 (53.4) 174.1 (51) 165.9 (48.6) 157.9 (46.3) 149.7 (43.9) 141.8 (41.5) 30 (-1.1) 446.3 (130.8) 427.8 (125.4) 409.3 (120) 391.0 (114.6) 372.8 (109.2) 354.5 (103.9) 25 (-3.9) 403.0 (118.1) 386.2 (113.2) 369.2 (108.2) 352.2 (103.2) 335.4 (98.3) 318.8 (93.4) 20 (-6.7) 362.7 (106.3) 346.9 (101.7) 331.4 (97.1) 316.1 (92.6) 300.5 (88.1) 285.2 (83.6) 15 (-9.4) 324.7 (95.1) 310.4 (91) 296.3 (86.8) 282.0 (82.7) 268.0 (78.5) 253.9 (74.4) 10 (-12.2) 289.4 (84.8) 276.4 (81) 263.3 (77.2) 250.5 (73.4) 237.7 (69.7) 224.9 (65.9)

5 (-15) 256.4 (75.1) 244.7 (71.7) 232.9 (68.3) 221.1 (64.8) 209.4 (61.4) 197.8 (58)

0 (-17.8) 225.8 (66.2) 215.0 (63) 204.3 (59.9) 193.8 (56.8) 183.3 (53.7) 172.8 (50.7) 30 (-1.1) 522.9 (153.2) 502.1 (147.2) 481.3 (141.1) 460.7 (135) 440.2 (129) 419.6 (123) 25 (-3.9) 473.3 (138.7) 454.2 (133.1) 435.1 (127.5) 416.0 (121.9) 397.1 (116.4) 378.2 (110.8) 20 (-6.7) 426.7 (125.1) 409.3 (120) 391.7 (114.8) 374.2 (109.7) 357.0 (104.6) 339.6 (99.5) 15 (-9.4) 383.0 (112.3) 367.1 (107.6) 351.1 (102.9) 335.2 (98.2) 319.4 (93.6) 303.7 (89) 10 (-12.2) 342.3 (100.3) 327.8 (96.1) 313.3 (91.8) 298.8 (87.6) 284.3 (83.3) 270.1 (79.1)

5 (-15) 304.3

0 (-17.8) 269.0 (78.8) 257.0 (75.3) 245.1 (71.8) 233.3 (68.4) 221.6 (64.9) 209.8 (61.5) 30 (-1.1) 680.6 (199.5) 653.3 (191.5) 626.0 (183.5) 598.7 (175.5) 571.6 (167.5) 544.7 (159.6) 25 (-3.9) 615.9 (180.5) 590.7 (173.1) 565.5 (165.7) 540.5 (158.4) 515.8 (151.2) 490.8 (143.8) 20 (-6.7) 555.0 (162.7) 531.9 (155.9) 509.0 (149.2) 485.9 (142.4) 463.3 (135.8) 440.6 (129.1) 15 (-9.4) 498.1 (146) 476.9 (139.8) 455.9 (133.6) 435.1 (127.5) 414.3 (121.4) 393.5 (115.3) 10 (-12.2) 444.8 (130.4) 425.7 (124.8) 406.6 (119.2) 387.5 (1

5 (-15) 395.2 (115.8) 377.8 (110.7) 360.6 (105.7) 343.4 (100.6) 326.1 (95.6) 309.1 (90.6)

0 (-17.8) 349.0 (102.3) 333.3 (97.7) 317.5 (93.1) 302.0 (88.5) 286.4 (83.9) 271.1 (79.5) 30 (-1.1) 786.5 (230.5) 755.2 (221.3) 723.9 (212.1) 692.8 (203) 661.9 (194) 631.1 (184.9) 25 (-3.9) 711.7 (208.6) 682.9 (200.1) 654.2 (191.7) 625.6 (183.3) 597.0 (175) 568.7 (166.7) 20 (-6.7) 641.6 (188) 615.1 (180.3) 588.8 (172.6) 562.6 (164.9) 536.6 (157.2) 510.5 (149.6) 15 (-9.4) 575.8 (168.8) 551.7 (161.7) 527.7 (154.7) 503.8 (147.6) 480.1 (140.7) 456.3 (133.7) 10 (-12.2) 514.5 (150.8) 492.5 (144.3) 470.8 (138) 449.0 (131.6) 427.4 (125.2) 405.9 (119)

5 (-15) 457.2 (134) 437.4 (128.2) 417.7 (122.4) 398.0 (116.6) 378.4 (110.9) 358.9 (105.2)

0 (-17.8) 404.0 (118.4) 386.2 (113.2) 368.3 (107.9) 350.5 (102.7) 332.9 (97.5) 315.2 (92.4) 30 (-1.1) 904.9 (265.2) 868.6 (254.5) 832.2 (243.9) 795.9 (233.3) 759.8 (222.7) 723.9 (212.1) 25 (-3.9) 820.9 (240.6) 787.3 (230.7) 753.7 (220.9) 720.3 (211.1) 687.1 (201.4) 653.9 (191.7) 20 (-6.7) 741.7 (217.4) 710.6 (208.3) 680.0 (199.3) 649.3 (190.3) 618.7 (181.3) 588.4 (172.4) 15 (-9.4) 667.0 (195.5) 638.8 (187.2) 610.7 (179) 582.5 (170.7) 554.6 (162.5) 526.9 (154.4) 10 (-12.2) 597.0 (175) 571.4 (167.5) 545.6 (159.9) 520.2 (152.4) 494.8 (145) 469.6 (137.6)

5 (-15) 531.5 (155.8) 508.2 (148.9) 484.9 (142.1) 461.8 (135.3) 438.9 (128.6) 416.0 (121.9)

0 (-17.8) 470.4 (137.9) 449.2 (131.6) 428.2 (125.5) 407.4 (119.4) 386.6 (113.3) 365.8 (107.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(89.2) 291.1 (85.3) 278.0 (81.5) 264.8 (77.6) 251.8 (73.8) 239.0 (70)

R407A

AMBIENT TEMPERATURE °F (°C)

13.5) 368.6 (108) 349.7 (102.5)

BITZER

09/03/14

T40-TV-PDS-19

- 29 -

CAPACITY DATA -

LOW TEMPERATURE

R407A

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD024L8-B

Compressor

Model

4NES-14

TVD030L8-B

Compressor

Model

4HE-18

TVD040L8-B

Compressor

Model

4GE-23

TVD050L8-B

Compressor

Model

6HE-28

TVD060L8-B

Compressor

Model

6GE-34

TVD080L8-B

Compressor

Model

6FE-44

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 166.7 (48.9) 159.0 (46.6) 151.2 (44.3) 143.4 (42) 135.7 (39.8) 128.1 (37.5)

-5 (-20.6) 146.8 (43) 139.7 (40.9) 132.7 (38.9) 125.8 (36.9) 118.9 (34.8) 111.9 (32.8)

-10 (-23.3) 128.3 (37.6) 121.8 (35.7) 115.5 (33.8) 109.2 (32) 103.1 (30.2) 96.8 (28.4)

-15 (-26.1) 111.1 (32.6) 105.4 (30.9) 99.8 (29.2) 94.1 (27.6) 88.4 (25.9) 83.0 (24.3)

-20 (-28.9) 95.1 (27.9) 90.1 (26.4) 85.1 (24.9) 80.0 (23.4) 75.0 (22) 70.1 (20.6)

-25 (-31.7) 80.6 (23.6) 76.0 (22.3) 71.4 (20.9) 67.0 (19.6) 62.6 (18.3) 58.2 (17)

-30 (-34.4) 67.0 (19.6) 63.0 (18.5) 58.8 (17.2) 54.8 (16.1) 50.8 (14.9) 47.0 (13.8)

-35 (-37.2) 54.4 (15.9) 50.8 (14.9) 47.3 (13.8) 43.5 (12.7) 40.1 (11.8) 36.5 (10.7)

-40 (-40) 42.8 (12.6) 39.5 (11.6) 36.3 (10.6) 33.0 (9.7) 29.8 (8.7) 26.7 (7.8) 0 (-17.8) 218.8 (64.1) 208.7 (61.2) 198.9 (58.3) 189.2 (55.5) 179.6 (52.6) 170.1 (49.9)

-5 (-20.6) 193.2 (56.6) 184.2 (54) 175.4 (51.4) 166.5 (48.8) 157.7 (46.2) 149.1 (43.7)

-10 (-23.3) 169.3 (49.6) 161.1 (47.2) 153.1 (44.9) 145.1 (42.5) 137.3 (40.3) 129.6 (38)

-15 (-26.1) 146.8 (43) 139.4 (40.9) 132.3 (38.8) 125.2 (36.7) 118.2 (34.6) 111. 3 (32.6)

-20 (-28.9) 125.8 (36.9) 119.3 (35) 112.8 (33) 106.5 (31.2) 100.2 (29.4) 94.1 (27.6)

-25 (-31.7) 106.1 (31.1) 100.4 (29.4) 94.5 (27.7) 88.8 (26) 83.4 (24.4) 77.9 (22.8)

-30 (-34.4) 87.6 (25.7) 82.5 (24.2) 77.3 (22.6) 72.5 (21.2) 67.4 (19.8) 62.8 (18.4)

-35 (-37.2) 70.1 (20.6) 65.7 (19.3) 61.1 (17.9) 56.7 (16.6) 52.5 (15.4) 48.3 (14.2)

-40 (-40) 53.8 (15.8) 49.8 (14.6) 45.8 (13.4) 41.8 (12.2) 38.0 (11.1) 34.2 (10) 0 (-17.8) 265.9 (77.9) 254.5 (74.6) 243.4 (71.3) 232.3 (68.1) 221.3 (64.9) 210.4 (61.7)

-5 (-20.6) 235.2 (68.9) 225.1 (66) 214.8 (63) 205.0 (60.1) 195.1 (57.2) 185.2 (54.3)

-10 (-23.3) 206.6 (60.6) 197.4 (57.9) 188.4 (55.2) 179.3 (52.6) 170.5 (50) 161.9 (47.5)

-15 (-26.1) 180.0 (52.7) 171.8 (50.3) 163.6 (47.9) 155.6 (45.6) 147.6 (43.3) 139.9 (41)

-20 (-28.9) 155.0 (45.4) 147.6 (43.3) 140.5 (41.2) 133.4 (39.1) 126.4 (37) 119.5 (35)

-25 (-31.7) 131.7 (38.6) 125.2 (36.7) 118.9 (34.8) 112.6 (33) 106.3 (31.1) 100.4 (29.4)

-30 (-34.4) 109.8 (32.2) 104.2 (30.5) 98.5 (28.9) 92.8 (27.2) 87.6 (25.7) 82.1 (24.1)

-35 (-37.2) 89.3 (26.2) 84.2 (24.7) 79.2 (23.2) 74.3 (21.8) 69.7 (20.4) 64.9 (19)

-40 (-40) 69.7 (20.4) 65.3 (19.1) 60.9 (17.8) 56.7 (16.6) 52.5 (15.4) 48.5 (14.2) 0 (-17.8) 335.8 (98.4) 320.5 (93.9) 305.6 (89.5) 290.6 (85.2) 275.9 (80.9) 261.5 (76.6)

-5 (-20.6) 296.1 (86.8) 282.2 (82.7) 268.8 (78.8) 255.4 (74.8) 242.1 (71) 228.9 (67.1)

-10 (-23.3) 258.9 (75.9) 246.5 (72.3) 234.4 (68.7) 222.2 (65.1) 210.4 (61.7) 198.7 (58.2)

-15 (-26.1) 224.3 (65.7) 213.2 (62.5) 202.2 (59.3) 191.5 (56.1) 180.8 (53) 170.3 (49.9)

-20 (-28.9) 191.9 (56.3) 182.1 (53.4) 172.4 (50.5) 162.8 (47.7) 153.3 (44.9) 143.9 (42.2)

-25 (-31.7) 161.9 (47.5) 153.1 (44.9) 144.3 (42.3) 135.9 (39.8) 127.5 (37.4) 119.1 (34.9)

-30 (-34.4) 133.6 (39.1) 125.8 (36.9) 118.0 (34.6) 1

-35 (-37.2) 106.9 (31.3) 100.2 (29.4) 93.2 (27.3) 86.5 (25.4) 80.0 (23.4) 73.7 (21.6)

-40 (-40) 81.9 (24) 75.8 (22.2) 69.7 (20.4) 63.8 (18.7) 58.2 (17) 52.5 (15.4) 0 (-17.8) 377.2 (110.5) 360.2 (105.5) 343.1 (100.6) 326.6 (95.7) 310.2 (90.9) 294.0 (86.2)

-5 (-20.6) 333.3 (97.7) 317.9 (93.2) 302.6 (88.7) 287.7 (84.3) 272.8 (79.9) 258.1 (75.6)

-10 (-23.3) 292.3 (85.7) 278.5 (81.6) 264.6 (77.5) 251.2 (73.6) 237.7 (69.7) 224.5 (65.8)

-15 (-26.1) 253.9 (74.4) 241.3 (70.7) 229.1 (67.1) 216.9 (63.6) 205.0 (60.1) 193.2 (56.6)

-20 (-28.9) 217.8 (63.8) 206.6 (60.6) 195.7 (57.4) 184.8 (54.2) 174.1 (51) 163.8 (48)

-25 (-31.7) 184.0 (53.9) 174.1 (51) 164.2 (48.1) 154.8 (45.4) 145.3 (42.6) 136.1 (39.9)

-30 (-34.4) 152.3 (44.6) 143.4 (42) 134.8 (39.5) 126.2 (37) 118.0 (34.6) 109.8 (32.2)

-35 (-37.2) 122.2 (35.8) 114.7 (33.6) 106.9 (31.3) 99.3 (29.1) 92.0 (27) 84.8 (24.9)

-40 (-40) 94.1 (27.6) 87.2 (25.5) 80.4 (23.6) 73.7 (21.6) 67.2 (19.7) 61.1 (17.9) 0 (-17.8) 451.3 (132.3) 431.3 (126.4) 411.6 (120.6) 391.9 (114.8) 372.5 (109.2) 353.6 (103.6)

-5 (-20.6) 399.6 (117.1) 381.6 (111.8) 363.5 (106.5) 345.9 (101.4) 328.4 (96.3) 311.2 (91.2)

-10 (-23.3) 351.1 (102.9) 334.7 (98.1) 318.6 (93.4) 302.6 (88.7) 286.9 (84.1) 271.5 (79.6)

-15 (-26.1) 305.6 (89.5) 290.9 (85.2) 276.4 (81) 262.1 (76.8) 248.0 (72.7) 234.2 (68.6)

-20 (-28.9) 262.7 (77) 249.7 (73.2) 236.7 (69.4) 224.1 (65.7) 211.5 (62) 199.3 (58.4)

-25 (-31.7) 222.6 (65.2) 211.1 (61.9) 199.5 (58.5) 188.2 (55.1) 177.2 (51.9) 166.3 (48.7)

-30 (-34.4) 184.8 (54.2) 174.5 (51.1) 164.4 (48.2) 154.6 (45.3) 144.7 (42.4) 135.2 (39.6)

-35 (-37.2) 149.3 (43.8) 140.3 (41.1) 131.3 (38.5) 122.4 (35.9) 113.8 (33.4) 105.6 (31)

-40 (-40) 115.5 (33.8) 107.5 (31.5) 99.5 (29.2) 92.0 (27) 84.4 (24.7) 77.1 (22.6)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

10.5 (32.4) 103.1 (30.2) 95.8 (28.1)

BITZER

09/03/14

T40-TV-PDS-19

- 30 -

CAPACITY DATA -

HIGH TEMPERATURE

R407C

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD030H8-B

Compressor

Model

4PES-15

TVD040H8-B

Compressor

Model

4NES-20

TVD050H8-B

Compressor

Model

4HE-25

TVD060H8-B

Compressor

Model

4GE-30

TVD070H8-B

Compressor

Model

6HE-35

TVD080H8-B

Compressor

Model

6GE-40

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 55 (12.8) 476.1 (139.5) 458.4 (134.4) 440.6 (129.1) 422.7 (123.9) 404.9 (118.7) 386.8 (113.4) 50 (10) 435.5 (127.6) 419.0 (122.8) 402.6 (118) 386.0 (113.1) 369.2 (108.2) 352.6 (103.3) 45 (7.2) 397.1 (116.4) 381.8 (111.9) 366.5 (107.4) 351.1 (102.9) 335.8 (98.4) 320.3 (93.9) 40 (4.4) 360.8 (105.7) 346.7 (101.6) 332.6 (97.5) 318.6 (93.4) 304.3 (89.2) 290.0 (85) 35 (1.7) 326.8 (95.8) 314.0 (92) 300.9 (88.2) 287.9 (84.4) 274.9 (80.6) 261.7 (76.7) 55 (12.8) 565.7 (165.8) 545.2 (159.8) 524.4 (153.7) 503.6 (147.6) 482.8 (141.5) 461.8 (135.3) 50 (10) 517.2 (151.6) 498.1 (146) 479.0 (140.4) 459.7 (134.7) 440.4 (129.1) 421.1 (123.4) 45 (7.2) 471.7 (138.2) 454.0 (133.1) 436.2 (127.8) 418.3 (122.6) 400.5 (117.4) 382.6 (112.1) 40 (4.4) 428.6 (125.6) 412.2 (120.8) 396.1 (116.1) 379.7 (111.3) 363.1 (106.4) 346.7 (101.6) 35 (1.7) 388.1 (113.7) 373.4 (109.4) 358.3 (105) 343.4 (100.6) 328.2 (96.2) 313.1 (91.8) 55 (12.8) 706.4 (207) 681.2 (199.7) 655.8 (192.2) 630.2 (184.7) 604.6 (177.2) 579.0 (169.7) 50 (10) 649.1 (190.2) 625.6 (183.3) 601.9 (176.4) 578.1 (169.4) 554.2 (162.4) 530.3 (155.4) 45 (7.2) 594.1 (174.1) 572.3 (167.7) 550.2 (161.2) 528.2 (154.8) 506.1 (148.3) 484.1 (141.9) 40 (4.4) 541.8 (158.8) 521.4 (152.8) 501.3 (146.9) 480.9 (140.9) 460.5 (135) 440.2 (129) 35 (1.7) 492.0 (144.2) 473.6 (138.8) 454.9 (133.3) 436.2 (127.8) 417.5 (122.4) 398.8 (116.9) 55 (12.8) 823.6 (241.4) 794.9 (232.9) 766.1 (224.5) 737.1 (216) 707.9 (207.5) 678.7 (198.9) 50 (10) 757.7 (222.1) 731.0 (214.2) 704.1 (206.4) 677.0 (198.4) 650.2 (190.5) 622.9 (182.5) 45 (7.2) 694.5 (203.5) 669.7 (196.3) 644.9 (189) 619.9 (181.7) 594.9 (174.4) 569.7 (167) 40 (4.4) 634.2 (185.9) 611.3 (179.2) 588.4 (172.4) 565.5 (165.7) 542.4 (159) 519.3 (152.2) 35 (1.7) 577.1 (169.1) 556.1 (163) 535.1 (156.8) 514.1 (150.7) 492.9 (144.4) 471.7 (138.2) 55 (12.8) 1031.5 (302.3) 994.4 (291.4) 957.0 (280.5) 919.2 (269.4) 881.2 (258.2) 843.2 (247.1) 50 (10) 947.1 (277.6) 912.5 (267.4) 877.6 (257.2) 842.5 (246.9) 807.2 (236.6) 771.8 (226.2) 45 (7.2) 866.5 (253.9) 834.5 (244.6) 802.2 (235.1) 769.7 (225.6) 737.1 (216) 704.3 (206.4) 40 (4.4) 790.0 (231.5) 760.4 (222.9) 730.8 (214.2) 701.0 (205.4) 670.7 (196.6) 640.5 (187.7) 35 (1.7) 717.8 (210.4) 690.7 (202.4) 663.4 (194.4) 636.1 (186.4) 608.6 (178.4) 580.9 (170.2) 55 (12.8) 1208.8 (354.3) 1166.3 (341.8) 1123.5 (329.3) 1080.7 (316.7) 1037.4 (304) 993.7 (291.2) 50 (10) 1110.5 (325.4) 1071.2 (313.9) 1031.5 (302.3) 991.4 (290.6) 951.3 (278.8) 91 45 (7.2) 1016.8 (298) 980.5 (287.4) 943.7 (276.6) 907.0 (265.8) 869.8 (254.9) 832.4 (244) 40 (4.4) 928.0 (272) 894.6 (262.2) 860.8 (252.3) 827.0 (242.4) 793.0 (232.4) 758.5 (222.3) 35 (1.7) 844.0 (247.3) 813.5 (238.4) 782.7 (229.4) 751.8 (220.3) 720.5 (211.2) 689.2 (202)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

1.0 (267)

BITZER

09/03/14

T40-TV-PDS-19

- 31 -

CAPACITY DATA -

R407C

MEDIUM TEMPERATURE

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD030M8-B

Compressor

Model

4PES-15

TVD040M8-B

Compressor

Model

4NES-20

TVD050M8-B

Compressor

Model

4HE-25

TVD060M8-B

Compressor

Model

4GE-30

TVD070M8-B

Compressor

Model

6HE-35

TVD080M8-B

Compressor

Model

6GE-40

TVD100M8-B

Compressor

Model

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 294.8 (86.4) 283.1 (83) 271.1 (79.5) 259.4 (76) 247.4 (72.5) 235.4 (69) 25 (-3.9) 265.0 (77.7) 254.3 (74.5) 243.6 (71.4) 232.7 (68.2) 221.8 (65) 210.8 (61.8) 20 (-6.7) 237.3 (69.5) 227.6 (66.7) 217.8 (63.8) 207.9 (60.9) 197.8 (58) 188.0 (55.1) 15 (-9.4) 211.5 (62) 202.7 (59.4) 193.8 (56.8) 184.8 (54.2) 175.8 (51.5) 166.7 (48.9) 10 (-12.2) 187.5 (55) 179.6 (52.6) 171.6 (50.3) 163.4 (47.9) 155.4 (45.5) 147.2 (43.1)

30 (-1.1) 350.5 (102.7) 336.8 (98.7) 323.2 (94.7) 309.3 (90.7) 295.7 (86.7) 281.8 (82.6) 25 (-3.9) 315.2 (92.4) 302.8 (88.7) 290.4 (85.1) 277.8 (81.4) 265.2 (77.7) 252.6 (74) 20 (-6.7) 282.5 (82.8) 271.1 (79.5) 260.0 (76.2) 248.6 (72.9) 237.1 (69.5) 225.8 (66.2) 15 (-9.4) 252.0 (73.9) 241.9 (70.9) 231.6 (67.9) 221.3 (64.9) 211.1 (61.9) 200.8 (58.8) 10 (-12.2) 223.9 (65.6) 214.6 (62.9) 205.4 (60.2) 196.1 (57.5) 186.9 (54.8) 177.7 (52.1) 30 (-1.1) 445.2 (130.5) 428.2 (125.5) 411.2 (120.5) 394.0 (115.5) 377.0 (110.5) 359.7 (105.4) 25 (-3.9) 401.3 (117.6) 385.6 (113) 370.0 (108.4) 354.5 (103.9) 338.9 (99.3) 323.2 (94.7) 20 (-6.7) 359.9 (105.5) 345.9 (101.4) 331.6 (97.2) 317.3 (93) 303.2 (88.9) 289.0 (84.7) 15 (-9.4) 321.3 (94.2) 308.5 (90.4) 295.7 (86.7) 282.7 (82.8) 269.9 (79.1) 257.0 (75.3) 10 (-12.2) 285.4 (83.6) 273.8 (80.3) 262.1 (76.8) 250.3 (73.4) 238.8 (70) 227.2 (66.6) 30 (-1.1) 523.1 (153.3) 504.0 (147.7) 484.7 (142) 465.6 (136.4) 446.3 (130.8) 426.9 (125.1) 25 (-3.9) 472.3 (138.4) 454.9 (133.3) 437.4 (128.2) 420.0 (123.1) 402.4 (117.9) 384.7 (112.7) 20 (-6.7) 424.6 (124.4) 408.9 (119.8) 393.1 (115.2) 377.2 (110.5) 361.2 (105.9) 345.2 (101.2) 15 (-9.4) 380.1 (111.4) 365.8 (107.2) 351.5 (103) 337.1 (98.8) 322.8 (94.6) 308.3 (90.3) 10 (-12.2) 338.7 (99.3) 325.7 (95.5) 312.7 (91.6) 299.7 (87.8) 286.7 (84) 273.6 (80.2) 30 (-1.1) 649.7 (190.4) 625.2 (183.2) 600.2 (175.9) 575.2 (168.6) 550.0 (161.2) 524.8 (153.8) 25 (-3.9) 585.9 (171.7) 563.6 (165.2) 541.0 (158.5) 518.3 (151.9) 495.4 (145.2) 472.5 (138.5) 20 (-6.7) 526.5 (154.3) 506.1 (148.3) 485.7 (142.4) 465.2 (136.3) 444.6 (130.3) 423.8 (124.2) 15 (-9.4) 470.8 (138) 452.8 (132.7) 434.3 (127.3) 415.8 (121.9) 397.1 (116.4) 378.4 (110.9) 10 (-12.2) 419.4 (122.9) 403.0 (118.1) 386.4 (113.2) 369.6 (108.3) 353.0 (103.5) 336.2 (98.5) 30 (-1.1) 765.2 (224.3) 737.3 (216.1) 709.4 (207.9) 681.0 (199.6) 652.7 (191.3) 624.1 (182.9) 25 (-3.9) 691.3 (202.6) 666.1 (195.2) 640.7 (187.8) 615.1 (180.3) 589.3 (172.7) 563.4 (165.1) 20 (-6.7) 622.2 (182.4) 599.3 (175.6) 576.5 (168.9) 553.4 (162.2) 530.3 (155.4) 506.9 (148.6) 15 (-9.4) 557.8 (163.5) 537.4 (157.5) 516.8 (151.5) 496.0 (145.4) 475.2 (139.3) 454.2 (133.1) 10 (-12.2) 497.9 (145.9) 479.6 (140.6) 461.2 (135.2) 442.7 (129.7) 424.0 (124.3) 405.3 (118.8) 30 (-1.1) 874.9 (256.4) 841.5 (246.6) 808.1 (236.8) 774.3 (226.9) 740.5 (217) 706.4 (207) 25 (-3.9) 791.1 (231.8) 760.8 (223) 730.4 (214.1) 699.5 (205) 668.9 (196) 637.8 (186.9) 20 (-6.7) 712.5 (208.8) 685.0 (200.8) 657.5 (192.7) 629.6 (184.5) 601.7 (176.3) 573.7 (168.1) 15 (-9.4) 638.8 (187.2) 614.0 (180) 589.3 (172.7) 564.3 (165.4) 539.1 (158) 513.9 (150.6) 10 (-12.2) 570.2 (167.1) 547.9 (160.6) 525.6 (154) 503.2 (147.5) 480.5 (140.8) 458.0 (134.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

BITZER

CONDENSING

TVD030H8-B

TVD040H8-B

TVD050H8-B

TVD060H8-B

TVD070H8-B

TVD080H8-B

UNIT

MODEL

Compressor

4PES-15

Compressor

4NES-20

Compressor

4HE-25

Compressor

4GE-30

Compressor

6HE-35

Compressor

6GE-40

CAPACITY DATA -

R404A

R507

60HzTVD-B

HIGH TEMPERATURE

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 420.6 (123.3) 402.4 (117.9) 384.2 (112.6) 366.4 (107.4) 348.6 (102.2) 330.8 (96.9) 40 (4.4) 386.2 (113.2) 369.2 (108.2) 352.4 (103.3) 335.6 (98.4) 319.0 (93.5) 302.4 (88.6) 35 (1.7) 353.6 (103.6) 337.8 (99) 322.0 (94.4) 306.4 (89.8) 291.0 (85.3) 275.6 (80.8) 45 (7.2) 503.4 (147.5) 482.2 (141.3) 461.2 (135.2) 440.2 (129) 419.4 (122.9) 398.8 (116.9) 40 (4.4) 462.6 (135.6) 442.8 (129.8) 423.2 (124) 403.6 (118.3) 384.2 (112.6) 365.0 (107) 35 (1.7) 423.6 (124.1) 405.4 (118.8) 387.0 (113.4) 369.0 (108.1) 350.8 (102.8) 333.0 (97.6) 45 (7.2) 613.4 (179.8) 587.4 (172.1) 561.8 (164.6) 536.0 (157.1) 510.4 (149.6) 484.8 (142.1) 40 (4.4) 567.2 (166.2) 543.2 (159.2) 519.0 (152.1) 495.0 (145.1) 471.0 (138) 447.0 (131) 35 (1.7) 523.2 (153.3) 500.8 (146.8) 478.2 (140.1) 455.8 (133.6) 433.4 (127) 411.2 (120.5) 45 (7.2) 702.6 (205.9) 672.6 (197.1) 642.6 (188.3) 612.6 (179.5) 582.8 (170.8) 552.8 (162) 40 (4.4) 650.2 (190.6) 622.2 (182.3) 594.2 (174.1) 566.2 (165.9) 538.2 (157.7) 510.2 (149.5) 35 (1.7) 600.0 (175.8) 574.0 (168.2) 547.8 (160.5) 521.8 (152.9) 495.8 (145.3) 469.8 (137.7) 45 (7.2) 905.2 (265.3) 867.6 (254.3) 830.0 (243.2) 792.6 (232.3) 755.2 (221.3) 717.8 (210.4) 40 (4.4) 836.8 (245.2) 801.6 (234.9) 766.4 (224.6) 731.4 (214.4) 696.4 (204.1) 661.4 (193.8) 35 (1.7) 771.4 (226.1) 738.6 (216.5) 705.8 (206.8) 673.2 (197.3) 640.6 (187.7) 608.0 (178.2) 45 (7.2) 1028.8 (301.5) 984.8 (288.6) 940.8 (275.7) 896.8 (262.8) 853.0 (250) 809.2 (237.2) 40 (4.4) 952.2 (279.1) 911.2 (267) 870.0 (255) 829.2 (243) 788.2 (231) 747.4 (219) 35 (1.7) 878.8 (257.5) 840.6 (246.4) 802.4 (235.2) 764.4 (224) 726.4 (212.9) 688.4 (201.7)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

BITZER

09/03/14

T40-TV-PDS-19

- 32 -

CAPACITY DATA -

MEDIUM TEMPERATURE

R404A

R507

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD030M8-B

Compressor

Model

4PES-15

TVD040M8-B

Compressor

Model

4NES-20

TVD050M8-B

Compressor

Model

4HE-25

TVD060M8-B

Compressor

Model

4GE-30

TVD070M8-B

Compressor

Model

6HE-35

TVD080M8-B

Compressor

Model

6GE-40

TVD100M8-B

Compressor

Model

6FE-50

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 322.6 (94.5) 308.0 (90.3) 293.4 (86) 278.8 (81.7) 264.6 (77.5) 250.2 (73.3) 25 (-3.9) 293.2 (85.9) 279.8 (82) 266.2 (78) 253.0 (74.1) 239.6 (70.2) 226.6 (66.4) 20 (-6.7) 265.6 (77.8) 253.2 (74.2) 240.8 (70.6) 228.6 (67) 216.4 (63.4) 204.2 (59.8) 15 (-9.4) 239.6 (70.2) 228.2 (66.9) 216.8 (63.5) 205.6 (60.3) 194.6 (57) 183.4 (53.7) 10 (-12.2) 215.2 (63.1) 204.8 (60) 194.4 (57) 184.2 (54) 174.2 (51.1) 164.0 (48.1)

5 (-15) 192.4 (56.4) 183.0 (53.6) 173.6 (50.9) 164.4 (48.2) 155.2 (45.5) 146.0 (42.8)

0 (-17.8) 171.0 (50.1) 162.6 (47.7) 154.2 (45.2) 145.8 (42.7) 137.4 (40.3) 129.2 (37.9) 30 (-1.1) 386.8 (113.4) 369.8 (108.4) 353.0 (103.5) 336.2 (98.5) 319.6 (93.7) 303.0 (88.8) 25 (-3.9) 352.0 (103.2) 336.4 (98.6) 320.8 (94) 305.4 (89.5) 290.0 (85) 274.8 (80.5) 20 (-6.7) 319.2 (93.5) 304.8 (89.3) 290.6 (85.2) 276.4 (81) 262.4 (76.9) 248.4 (72.8) 15 (-9.4) 288.4 (84.5) 275.2 (80.7) 262.2 (76.8) 249.4 (73.1) 236.4 (69.3) 223.6 (65.5) 10 (-12.2) 259.4 (76) 247.6 (72.6) 235.8 (69.1) 224.0 (65.6) 212.2 (62.2) 200.6 (58.8)

5 (-15) 232.4 (68.1) 221.8 (65) 211.0 (61.8) 200.4 (58.7) 189.8 (55.6) 179.2 (52.5)

0 (-17.8) 207.4 (60.8) 197.6 (57.9) 188.0 (55.1) 178.4 (52.3) 169.0 (49.5) 159.4 (46.7) 30 (-1.1) 481.0 (141) 460.2 (134.9) 439.4 (128.8) 418.6 (122.7) 397.8 (116.6) 377.0 (110.5) 25 (-3.9) 440.8 (129.2) 421.6 (123.6) 402.4 (117.9) 383.2 (112.3) 363.8 (106.6) 344.6 (101) 20 (-6.7) 402.6 (118) 385.0 (112.8) 367.2 (107.6) 349.6 (102.5) 331.8 (97.2) 314.2 (92.1) 15 (-9.4) 366.4 (107.4) 350.2 (102.6) 334.0 (97.9) 317.8 (93.1) 301.4 (88.3) 285.2 (83.6) 10 (-12.2) 332.0 (97.3) 317.2 (93) 302.4 (88.6) 287.6 (84.3) 272.8 (79.9) 258.0 (75.6)

5 (-15) 299.6 (87.8) 286.2 (83.9) 272.8 (79.9) 259.4 (76) 246.0 (72.1) 232.4 (68.1)

0 (-17.8) 269.2 (78.9) 257.2 (75.4) 245.0 (71.8) 232.8 (68.2) 220.6 (64.7) 208.4 (61.1) 30 (-1.1) 552.0 (161.8) 527.8 (154.7) 503.6 (147.6) 479.6 (140.6) 455.4 (133.5) 431.2 (126.4) 25 (-3.9) 506.2 (148.4) 484.0 (141.8) 461.6 (135.3) 439.4 (128.8) 417.0 (122.2) 394.8 (115.7) 20 (-6.7) 462.6 (135.6) 442.2 (129.6) 421.6 (123.6) 401.2 (117.6) 380.6 (111.5) 360.2 (105.6) 15 (-9.4) 421.2 (123.4) 402.6 (118) 383.8 (112.5) 365.0 (107) 346.4 (101.5) 327.6 (96) 10 (-12.2) 382.0 (112) 365.0 (107) 348.0 (102) 331.0 (97) 313.8 (92) 296.8 (87)

5 (-15) 345.0

0 (-17.8) 310.2 (90.9) 296.4 (86.9) 282.6 (82.8) 268.6 (78.7) 254.6 (74.6) 240.6 (70.5) 30 (-1.1) 709.0 (207.8) 678.6 (198.9) 648.2 (190) 617.8 (181.1) 587.4 (172.1) 557.2 (163.3) 25 (-3.9) 649.4 (190.3) 621.4 (182.1) 593.2 (173.8) 565.2 (165.6) 537.2 (157.4) 509.2 (149.2) 20 (-6.7) 593.0 (173.8) 567.2 (166.2) 541.2 (158.6) 515.4 (151) 489.6 (143.5) 463.8 (135.9) 15 (-9.4) 539.4 (158.1) 515.8 (151.2) 492.0 (144.2) 468.4 (137.3) 444.6 (130.3) 421.0 (123.4) 10 (-12.2) 488.8 (143.3) 467.2 (136.9) 445.6 (130.6) 424.0 (124.3) 402.4 (117.9) 380.6 (11

5 (-15) 441.2 (129.3) 421.6 (123.6) 401.8 (117.8) 382.2 (112) 362.6 (106.3) 342.8 (100.5)

0 (-17.8) 396.4 (116.2) 378.6 (111 ) 360.8 (105.7) 343.0 (100.5) 325.2 (95.3) 307.4 (90.1) 30 (-1.1) 808.6 (237) 773.2 (226.6) 738.0 (216.3) 702.6 (205.9) 667.4 (195.6) 632.2 (185.3) 25 (-3.9) 741.6 (217.3) 709.0 (207.8) 676.4 (198.2) 644.0 (188.7) 611.6 (179.2) 579.0 (169.7) 20 (-6.7) 677.8 (198.6) 648.0 (189.9) 618.0 (181.1) 588.2 (172.4) 558.4 (163.7) 528.6 (154.9) 15 (-9.4) 617.2 (180.9) 590.0 (172.9) 562.8 (164.9) 535.6 (157) 508.2 (148.9) 481.0 (141) 10 (-12.2) 559.8 (164.1) 535.2 (156.9) 510.4 (149.6) 485.6 (142.3) 460.8 (135) 436.0 (127.8)

5 (-15) 505.8 (148.2) 483.4 (141.7) 461.0 (135.1) 438.6 (128.5) 416.2 (122) 393.6 (115.4)

0 (-17.8) 455.0 (133.3) 434.8 (127.4) 414.6 (121.5) 394.4 (115.6) 374.2 (109.7) 354.0 (103.7) 30 (-1.1) 941.8 (276) 900.0 (263.8) 858.0 (251.5) 816.0 (239.1) 774.2 (226.9) - 25 (-3.9) 867.2 (254.2) 828.6 (242.8) 790.0 (231.5) 751.2 (220.2) 712.6 (208.8) - 20 (-6.7) 795.8 (233.2) 760.2 (222.8) 724.8 (212.4) 689.2 (202) 653.8 (191.6) 618.2 (181.2) 15 (-9.4) 727.4 (213.2) 695.0 (203.7) 662.6 (194.2) 630.2 (184.7) 597.8 (175.2) 565.2 (165.6) 10 (-12.2) 662.4 (194.1) 633.0 (185.5) 603.4 (176.8) 574.0 (168.2) 544.4 (159.5) 514.8 (150.9)

5 (-15) 600.4 (176) 574.0 (168.2) 547.2 (160.4) 520.6 (152.6) 493.8 (144.7) 466.8 (136.8)

0 (-17.8) 542.0 (158.8) 518.0 (151.8) 494.0 (144.8) 470.0 (137.7) 445.6 (130.6) 421.4 (123.5)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(101.1) 329.8 (96.7) 314.4 (92.1) 298.8 (87.6) 283.4 (83.1) 267.8 (78.5)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

1.5)

BITZER

09/03/14

T40-TV-PDS-19

- 33 -

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD024L6-B

Compressor

Model

4NES-14

TVD030L6-B

Compressor

Model

4HE-18

TVD040L6-B

Compressor

Model

4GE-23

TVD050L6-B

Compressor

Model

6HE-28

TVD060L6-B

Compressor

Model

6GE-34

TVD080L6-B

Compressor

Model

6FE-44

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 187.0 (54.8) 178.0 (52.2) 168.8 (49.5) 159.8 (46.8) 150.6 (44.1) 141.6 (41.5)

-5 (-20.6) 167.4 (49.1) 159.2 (46.7) 151.0 (44.3) 142.6 (41.8) 134.4 (39.4) 126.2 (37)

-10 (-23.3) 149.0 (43.7) 141.6 (41.5) 134.0 (39.3) 126.6 (37.1) 119.2 (34.9) 111.8 (32.8)

-15 (-26.1) 131.8 (38.6) 125.0 (36.6) 118.4 (34.7) 111.6 (32.7) 105.0 (30.8) 98.4 (28.8)

-20 (-28.9) 115.8 (33.9) 109.8 (32.2) 103.8 (30.4) 97.8 (28.7) 91.8 (26.9) 85.8 (25.1)

-25 (-31.7) 100.8 (29.5) 95.6 (28) 90.2 (26.4) 84.8 (24.9) 79.4 (23.3) 74.0 (21.7)

-30 (-34.4) 87.2 (25.6) 82.4 (24.1) 77.6 (22.7) 72.8 (21.3) 68.0 (19.9) 63.2 (18.5)

-35 (-37.2) 74.6 (21.9) 70.2 (20.6) 66.0 (19.3) 61.6 (18.1) 57.4 (16.8) 53.0 (15.5)

-40 (-40) 63.0 (18.5) 59.0 (17.3) 55.2 (16.2) 51.4 (15.1) 47.4 (13.9) 43.6 (12.8) 0 (-17.8) 249.8 (73.2) 238.4 (69.9) 227.0 (66.5) 215.6 (63.2) 204.2 (59.8) 192.8 (56.5)

-5 (-20.6) 225.4 (66.1) 215.0 (63) 204.6 (60) 194.2 (56.9) 184.0 (53.9) 173.6 (50.9)

-10 (-23.3) 202.4 (59.3) 193.0 (56.6) 183.6 (53.8) 174.2 (51.1) 164.8 (48.3) 155.4 (45.5)

-15 (-26.1) 180.4 (52.9) 172.0 (50.4) 163.6 (47.9) 155.2 (45.5) 146.6 (43) 138.4 (40.6)

-20 (-28.9) 160.0 (46.9) 152.4 (44.7) 144.8 (42.4) 137.2 (40.2) 129.6 (38) 122.2 (35.8)

-25 (-31.7) 140.6 (41.2) 133.8 (39.2) 127.0 (37.2) 120.2 (35.2) 113.6 (33.3) 106.8 (31.3)

-30 (-34.4) 122.4 (35.9) 116.4 (34.1) 110.4 (32.4) 104.4 (30.6) 98.4 (28.8) 92.4 (27.1)

-35 (-37.2) 105.6 (30.9) 100.2 (29.4) 94.8 (27.8) 89.4 (26.2) 84.0 (24.6) 78.8 (23.1)

-40 (-40) 89.8 (26.3) 85.0 (24.9) 80.2 (23.5) 75.4 (22.1) 70.6 (20.7) 65.8 (19.3) 0 (-17.8) 300.2 (88) 286.8 (84.1) 273.4 (80.1) 260.0 (76.2) 246.6 (72.3) 233.4 (68.4)

-5 (-20.6) 270.8 (79.4) 258.6 (75.8) 246.6 (72.3) 234.4 (68.7) 222.4 (65.2) 210.4 (61.7)

-10 (-23.3) 243.0 (71.2) 232.0 (68) 221.2 (64.8) 210.4 (61.7) 199.4 (58.4) 188.6 (55.3)

-15 (-26.1) 216.8 (63.5) 207.0 (60.7) 197.4 (57.9) 187.6 (55) 178.0 (52.2) 168.2 (49.3)

-20 (-28.9) 192.2 (56.3) 183.6 (53.8) 174.8 (51.2) 166.2 (48.7) 157.6 (46.2) 149.0 (43.7)

-25 (-31.7) 169.2 (49.6) 161.6 (47.4) 153.8 (45.1) 146.2 (42.8) 138.6 (40.6) 130.8 (38.3)

-30 (-34.4) 147.8 (43.3) 141.0 (41.3) 134.2 (39.3) 127.4 (37.3) 120.6 (35.3) 113.8 (33.4)

-35 (-37.2) 127.8 (37.5) 121.8 (35.7) 115.8 (33.9) 109.8 (32.2) 103.8 (30.4) 97.8 (28.7)

-40 (-40) 109.2 (32) 104.0 (30.5) 98.6 (28.9) 93.2 (27.3) 88.0 (25.8) 82.8 (24.3) 0 (-17.8) 378.6 ( 111) 361.6 (106) 344.4 (100.9) 327.4 (96) 310.4 (91) 293.6 (86)

-5 (-20.6) 340.8 (99.9) 325.4 (95.4) 309.8 (90.8) 294.4 (86.3) 279.0 (81.8) 263.6 (77.3)

-10 (-23.3) 305.2 (89.4) 291.2 (85.3) 277.2 (81.2) 263.4 (77.2) 249.4 (73.1) 235.4 (69)

-15 (-26.1) 271.8 (79.7) 259.2 (76) 246.6 (72.3) 234.0 (68.6) 221.4 (64.9) 209.0 (61.3)

-20 (-28.9) 240.6 (70.5) 229.2 (67.2) 217.8 (63.8) 206.6 (60.5) 195.2 (57.2) 184.0 (53.9)

-25 (-31.7) 21

-30 (-34.4) 184.0 (53.9) 175.0 (51.3) 165.8 (48.6) 156.8 (46) 147.8 (43.3) 138.6 (40.6)

-35 (-37.2) 158.6 (46.5) 150.6 (44.1) 142.4 (41.7) 134.2 (39.3) 126.2 (37) 118.0 (34.6)

-40 (-40) 135.2 (39.6) 127.8 (37.5) 120.6 (35.3) 113.2 (33.2) 106.0 (31.1) 98.6 (28.9) 0 (-17.8) 431.8 (126.5) 412.8 (121) 394.0 (115.5) 375.0 (109.9) 356.0 (104.3) 336.8 (98.7)

-5 (-20.6) 391.4 (114.7) 374.4 (109.7) 357.2 (104.7) 340.0 (99.6) 322.8 (94.6) 305.4 (89.5)

-10 (-23.3) 353.0 (103.5) 337.6 (98.9) 322.2 (94.4) 306.8 (89.9) 291.2 (85.3) 275.6 (80.8)

-15 (-26.1) 316.6 (92.8) 302.8 (88.7) 289.2 (84.8) 275.2 (80.7) 261.4 (76.6) 247.4 (72.5)

-20 (-28.9) 282.2 (82.7) 270.0 (79.1) 257.8 (75.6) 245.4 (71.9) 233.0 (68.3) 220.4 (64.6)

-25 (-31.7) 250.0 (73.3) 239.0 (70) 228.2 (66.9) 217.2 (63.7) 206.0 (60.4) 194.8 (57.1)

-30 (-34.4) 219.6 (64.4) 210.0 (61.5) 200.4 (58.7) 190.6 (55.9) 180.6 (52.9) 170.6 (50)

-35 (-37.2) 191.4 (56.1) 182.8 (53.6) 174.2 (51.1) 165.4 (48.5) 156.6 (45.9) 147.6 (43.3)

-40 (-40) 165.0 (48.4) 157.4 (46.1) 149.6 (43.8) 141.8 (41.6) 133.8 (39.2) 125.8 (36.9) 0 (-17.8) 512.8 (150.3) 490.0 (143.6) 467.2 (136.9) 444.2 (130.2) 421.4 (123.5) 398.4 (116.8)

-5 (-20.6) 464.8 (136.2) 444.0 (130.1) 423.4 (124.1) 402.6 (118) 381.8 (111.9) 361.0 (105.8)

-10 (-23.3) 418.8 (122.7) 400.2 (117.3) 381.6 (111.8) 362.8 (106.3) 344.0 (100.8) 325.2 (95.3)

-15 (-26.1) 375.2 (110) 358.6 (105.1) 341.8 (100.2) 324.8 (95.2) 308.0 (90.3) 291.0 (85.3)

-20 (-28.9) 334.0 (97.9) 319.0 (93.5) 304.0 (89.1) 288.8 (84.6) 273.6 (80.2) 258.2 (75.7)

-25 (-31.7) 295.2 (86.5) 281.8 (82.6) 268.2 (78.6) 254.6 (74.6) 240.8 (70.6) 227.0 (66.5)

-30 (-34.4) 258.6 (75.8) 246.6 (72.3) 234.4 (68.7) 222.2 (65.1) 209.8 (61.5) 197.4 (57.9)

-35 (-37.2) 224.4 (65.8) 213.6 (62.6) 202.6 (59.4) 191.4 (56.1) 180.2 (52.8) 169.0 (49.5)

-40 (-40) 192.4 (56.4) 182.6 (53.5) 172.4 (50.5) 162.4 (47.6) 152.2 (44.6) 141.8 (41.6)

1.2 (61.9) 201.2 (59) 191.0 (56) 180.8 (53) 170.8 (50.1) 160.6 (47.1)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BITZER

09/03/14

T40-TV-PDS-19

- 34 -

CAPACITY DATA -

R404A

R507

EXTENDED LOW TEMPERATURE

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD016V6-B

Compressor

Model

S4N-8.2Y

TVD024V6-B

Compressor

Model

S4G-12.2Y

TVD032V6-B

Compressor

Model

S6J-16.2Y

TVD040V6-B

Compressor

Model

S6H-20.2Y

TVD050V6-B

Compressor

Model

S6G-25.2Y

TVD060V6-B

Compressor

Model

S6F-30.2Y

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

-25 (-31.7) 78.2 (22.9) 77.2 (22.6) 76.0 (22.3) 75.0 (22) 73.8 (21.6) 72.6 (21.3)

-30 (-34.4) 69.8 (20.5) 68.8 (20.2) 67.8 (19.9) 66.8 (19.6) 65.6 (19.2) 64.6 (18.9)

-35 (-37.2) 62.0 (18.2) 61.0 (17.9) 60.2 (17.6) 59.2 (17.3) 58.2 (17.1) 57.0 (16.7)

-40 (-40) 54.8 (16.1) 54.0 (15.8) 53.2 (15.6) 52.2 (15.3) 51.2 (15) 50.2 (14.7)

-45 (-42.8) 48.4 (14.2) 47.6 (14) 46.8 (13.7) 46.0 (13.5) 45.0 (13.2) 44.0 (12.9)

-50 (-45.6) 42.4 (12.4) 41.8 (12.3) 41.0 (12) 40.2 (11.8) 39.4 (11.5) 38.4 (11.3)

-55 (-48.3) 37.0 (10.8) 36.4 (10.7) 35.6 (10.4) 35.0 (10.3) 34.2 (10) 33.4 (9.8)

-60 (-51.1) 32.0 (9.4) 31.4 (9.2) 30.8 (9) 30.2 (8.9) 29.6 (8.7) 28.8 (8.4)

-25 (-31.7) 121.4 (35.6) 119.6 (35.1) 117.8 (34.5) 115.8 (33.9) 113.8 (33.4) 111 .8 (32.8)

-30 (-34.4) 109.8 (32.2) 108.0 (31.7) 106.2 (31.1) 104.4 (30.6) 102.4 (30) 100.2 (29.4)

-35 (-37.2) 98.6 (28.9) 97.0 (28.4) 95.2 (27.9) 93.4 (27.4) 91.6 (26.8) 89.6 (26.3)

-40 (-40) 88.2 (25.8) 86.6 (25.4) 85.0 (24.9) 83.2 (24.4) 81.4 (23.9) 79.6 (23.3)

-45 (-42.8) 78.2 (22.9) 76.8 (22.5) 75.2 (22) 73.6 (21.6) 72.0 (21.1) 70.2 (20.6)

-50 (-45.6) 69.0 (20.2) 67.8 (19.9) 66.2 (19.4) 64.8 (19) 63.2 (18.5) 61.8 (18.1)

-55 (-48.3) 60.4 (17.7) 59.2 (17.3) 58.0 (17) 56.6 (16.6) 55.2 (16.2) 54.0 (15.8)

-60 (-51.1) 52.4 (15.4) 51.4 (15.1) 50.2 (14.7) 49.0 (14.4) 48.0 (14.1) 46.8 (13.7)

-25 (-31.7) 168.2 (49.3) 165.6 (48.5) 163.0 (47.8) 160.4 (47) 157.8 (46.2) 155.4 (45.5)

-30 (-34.4) 152.2 (44.6) 149.6 (43.8) 147.2 (43.1) 144.6 (42.4) 142.0 (41.6) 139.6 (40.9)

-35 (-37.2) 137.0 (40.2) 134.6 (39.4) 132.2 (38.7) 129.8 (38) 127.4 (37.3) 124.8 (36.6)

-40 (-40) 122.8 (36) 120.6 (35.3) 118.2 (34.6) 116.0 (34) 113.6 (33.3) 111.2 (32.6)

-45 (-42.8) 109.4 (32.1) 107.4 (31.5) 105.2 (30.8) 103.0 (30.2) 100.8 (29.5) 98.6 (28.9)

-50 (-45.6) 97.0 (28.4) 95.0 (27.8) 93.0 (27.3) 91.0 (26.7) 89.0 (26.1) 87.0 (25.5)

-55 (-48.3) 85.4 (25) 83.6 (24.5) 81.8 (24) 80.0 (23.4) 78.0 (22.9) 76.2 (22.3)

-60 (-51.1) 74.6 (21.9) 73.0 (21.4) 71.4 (20.9) 69.8 (20.5) 68.2 (20) 66.4 (19.5)

-25 (-31.7) 197.6 (57.9) 194.8 (57.1) 191.8 (56.2) 188.8 (55.3) 185.6 (54.4) 182.4 (53.5)

-30 (-34.4) 179.0 (52.5) 176.2 (51.6) 173.2 (50.8) 170.2 (49.9) 167.2 (49) 164.0 (48.1)

-35 (-37.2)

-40 (-40) 144.4 (42.3) 141.8 (41.6) 139.2 (40.8) 136.4 (40) 133.6 (39.2) 130.8 (38.3)

-45 (-42.8) 128.6 (37.7) 126.2 (37) 123.8 (36.3) 121.2 (35.5) 118.6 (34.8) 115.8 (33.9)

-50 (-45.6) 1

-55 (-48.3) 100.0 (29.3) 98.0 (28.7) 96.0 (28.1) 93.8 (27.5) 91.6 (26.8) 89.4 (26.2)

-60 (-51.1) 87.4 (25.6) 85.6 (25.1) 83.6 (24.5) 81.8 (24) 79.8 (23.4) 78.0 (22.9)

-25 (-31.7) 224.4 (65.8) 221.2 (64.8) 217.8 (63.8) 214.2 (62.8) 210.4 (61.7) 206.8 (60.6)

-30 (-34.4) 203.2 (59.6) 200.0 (58.6) 196.8 (57.7) 193.2 (56.6) 189.6 (55.6) 186.0 (54.5)

-35 (-37.2) 183.2 (53.7) 180.2 (52.8) 177.0 (51.9) 173.6 (50.9) 170.2 (49.9) 166.6 (48.8)

-40 (-40) 164.2 (48.1) 161.4 (47.3) 158.2 (46.4) 155.0 (45.4) 151.8 (44.5) 148.6 (43.6)

-45 (-42.8) 146.4 (42.9) 143.8 (42.1) 140.8 (41.3) 137.8 (40.4) 134.8 (39.5) 131.8 (38.6)

-50 (-45.6) 129.8 (38) 127.2 (37.3) 124.6 (36.5) 121.8 (35.7) 119.0 (34.9) 116.2 (34.1)

-55 (-48.3) 114.2 (33.5) 111.8 (32.8) 109.4 (32.1) 106.8 (31.3) 104.4 (30.6) 101.8 (29.8)

-60 (-51.1) 99.6 (29.2) 97.6 (28.6) 95.4 (28) 93.2 (27.3) 91.0 (26.7) 88.8 (26)

-25 (-31.7) 266.6 (78.1) 262.2 (76.8) 257.8 (75.6) 253.2 (74.2) 248.6 (72.9) 244.0 (71.5)

-30 (-34.4) 241.4 (70.7) 237.4 (69.6) 233.0 (68.3) 228.6 (67) 224.2 (65.7) 219.6 (64.4)

-35 (-37.2) 217.6 (63.8) 213.8 (62.7) 209.6 (61.4) 205.4 (60.2) 201.2 (59) 197.0 (57.7)

-40 (-40) 195.2 (57.2) 191.4 (56.1) 187.6 (55) 183.6 (53.8) 179.6 (52.6) 175.6 (51.5)

-45 (-42.8) 174.0 (51) 170.6 (50) 167.0 (48.9) 163.4 (47.9) 159.6 (46.8) 156.0 (45.7)

-50 (-45.6) 154.2 (45.2) 151.0 (44.3) 147.8 (43.3) 144.4 (42.3) 141.0 (41.3) 137.8 (40.4)

-55 (-48.3) 135.8 (39.8) 133.0 (39) 130.0 (38.1) 127.0 (37.2) 124.0 (36.3) 121.0 (35.5)

-60 (-51.1) 118.6 (34.8) 116.2 (34.1) 113.6 (33.3) 110.8 (32.5) 108.2 (31.7) 105.6 (30.9)

161.2 (47.2) 158.6 (46.5) 155.6 (45.6) 152.8 (44.8) 149.8 (43.9) 146.8 (43)

13.8 (33.4) 111. 6 (32.7) 109.4 (32.1) 107.0 (31.4) 104.6 (30.7) 102.2 (30)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

ELECTRICAL DATA -

09/03/14

T40-TV-PDS-19

- 35 -

60HzTVS-A

COPELAND

CONDENSING UNIT

MODEL

TVS015H8-

TVS022H8-

TVS025H8-

TVS030H8-

TVS035H8-

TVS040H8-

TVS015M8-

TVS022M8-

TVS025M8-

TVS030M8-

TVS035M8-

TVS040M8-

TVS050M8- HT4B

TVS010L 6/8 -

TVS015L 6/8 -

TVS022L 6/8 -

TVS027L6/8-

TVS030L 6/8 -

TVS040L 6/8 - HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 2 3700 6.2 86.1 125

* 6DJ only available in 230V

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 3700 13.2 87.7 125 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 3700 6.2 42.5 70 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 2 3700 5.0 34.5 50 HT3B -A 4DBNR20ME-TSK 208-230/3/60 85.7 374 2 3700 13.2 120.3 200 HT4B -A 4DBNR20ME-TSK 460/3/60 42.9 187 2 3700 6.2 59.8 100 HT5B -A 4DBNR20ME-TSE 575/3//60 33.6 135 2 3700 5.0 47.0 80 HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 2 3700 13.2 147.1 250 HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 2 3700 6.2 73.2 125 HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 2 3700 5.0 53.5 90 HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 2 3700 13.2 156.1 250 HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 2 3700 6.2 77.6 125 HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 2 3700 5.0 66.6 11 0 HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 3 5550 19.8 196.6 300 HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 3 5550 9.3 97.7 150 HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 3 5550 7.5 74.5 125 HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 3 5550 19.8 218.1 350 HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 3 5550 9.3 108.4 175 HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 3 5550 7.5 88.8 150 HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 3700 13.2 87.7 125 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 3700 6.2 42.5 70 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 2 3700 5.0 34.5 50 HT3B -A 4DBNR20ME-TSK 208-230/3/60 72.1 374 2 3700 13.2 103.3 175 HT4B -A 4DBNR20ME-TSK 460/3/60 36.1 187 2 3700 6.2 51.3 80 HT5B -A 4DBNR20ME-TSE 575/3//60 31.4 135 2 3700 5.0 44.3 70 HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 2 3700 13.2 115.8 175 HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 2 3700 6.2 57.6 90 HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 2 3700 5.0 48.0 80 HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 2 3700 13.2 145.0 250 HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 2 3700 6.2 72.1 11 0 HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 2 3700 5.0 60.1 100 HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 3 5550 19.8 176.2 300 HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 3 5550 9.3 87.6 150 HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 3 5550 7.5 61.4 100 HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 3 5550 HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 3 5550 9.3 98.6 150 HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 3 5550 7.5 72.6 11 0

-A 6DUNR49ME-AWD 460/3/60 84.2 482 3 5550 9.3 114.6 175

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 1 1850 6.6 58.4 90 HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 1 1850 3.1 26.4 40 HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 1 1850 2.5 22.8 35 HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 1 1850 6.6 72.4 110 HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 1 1850 3.1 36.0 60 HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 11 3 1 1850 2.5 28.6 45 HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 2 3700 13.2 93.6 150 HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 2 3700 6.2 46.3 70 HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 2 3700 5.0 41.4 70 HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 2 3700 13.2 114.1 175 HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 2 3700 6.2 56.7 90 HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 2 3700 5.0 45.6 70 HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 2 3700 13.2 132.7 225 HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 2 3700 6.2 66.0 11 0 HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 2 3700 5.0 54.5 90

SINGLE COMPESSOR MODELS

COMPRESSOR

MODEL NO.

POWER SUPPLY

COMPRESSOR

RLA LRA QTY WATTS FLA MCA MOP

CONDENSER

FAN MOTOR

UNIT

19.8 198.4 300

ELECTRICAL DATA -

09/03/14

T40-TV-PDS-19

- 36 -

60HzTVD-A

COPELAND

CONDENSING UNIT

MODEL

TVD030H8-

TVD044H8-

TVD050H8-

TVD060H8-

TVD070H8-

TVD080H8-

TVD030M8-

TVD044M8-

TVD050M8-

TVD060M8-

TVD070M8-

TVD080M8-

TVS100M8- HT4B -A 6DUNR49ME-AWD 460/3/60 84.2 482 6 1110 0 18.6 208.1 250

TVD020L 6/8 -

TVD030L 6/8 -

TVD044L 6/8 -

TVD054L 6/8 -

TVD060L 6/8 -

TVS080L 6/8 - HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 4 7400 12.4 156.2 200

* 6DJ only available in 230V

HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 4 7400 26.4 283.6 350 HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 4 7400 12.4 140.9 175 HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 4 7400 10.0 120.9 150 HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 6 111 0 0 39.6 357.8 450 HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 6 111 00 18.6 177.7 225 HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 6 11100 15.0 135.6 175 HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 6 111 00 39.6 396.5 500 HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 6 11100 18.6 197.0 250 HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 6 111 0 0 15.0 161.3 225 HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 7400 26.4 160.5 200 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 7400 12.4 77.7 100 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 4 7400 10.0 63.1 80 HT3B -A 4DBNR20ME-TSK 208-230/3/60 72.1 374 4 7400 26.4 188.6 250 HT4B -A 4DBNR20ME-TSK 460/3/60 36.1 187 4 7400 12.4 93.6 125 HT5B -A 4DBNR20ME-TSE 575/3//60 31.4 135 4 7400 10.0 80.7 110 HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 4 7400 26.4 211.1 250 HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 4 7400 12.4 104.9 125 HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 4 7400 10.0 87.4 11 0 HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 4 7400 26.4 263.6 350 HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 4 7400 12.4 131.0 175 HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 4 7400 10.0 109.2 150 HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 6 111 0 0 39.6 321.1 400 HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 6 111 00 18.6 159.5 200 HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 6 11100 15.0 112.0 150

HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 6 111 00 HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 6 11100 18.6 HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 6 111 0 0 15.0 132.2 175

HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 4 7400 26.4 208.0 250 HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 4 7400 12.4 103.3 125 HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 4 7400 10.0 83.1 110 HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 4 7400 26.4 241.5 300 HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 4 7400 12.4 120.0 150

HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 4 7400 10.0 99.1 125

DOUBLE COMPESSOR MODELS

COMPRESSOR

MODEL NO.

POWER SUPPLY

COMPRESSOR

RLA LRA QTY WATTS FLA MCA MOP

CONDENSER

FAN MOTOR

UNIT

39.6 361.1 500

179.3 250

BITZER

09/03/14

T40-TV-PDS-19

- 37 -

CONDENSING UNIT

MODEL

TVS015H8-

TVS020H8-

TVS025H8-

TVS030H8-

TVS035H8-

TVS040H8-

TVS015M8-

TVS020M8-

TVS025M8-

TVS030M8-

TVS035M8-

TVS040M8-

TVS050M8-

TVS012L 6/8 -

TVS015L 6/8 -

TVS020L 6/8 -

TVS025L 6/8 -

TVS030L 6/8 -

TVS040L6 6/8-

TVS008V6-

TVS012V6-

TVS016V6-

TVS020V6-

TVS025V6-

TVS030V6-

ELECTRICAL DATA -

60HzTVS-B

SINGLE COMPESSOR MODELS

COMPRESSOR

HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 2 3700 13.2 88.2 125 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 2 3700 6.2 40.1 60 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 2 3700 5.0 32.3 50 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 2 3700 5.0 37.9 60 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 2 3700 13.2 129.7 200 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 2 3700 6.2 58.8 100 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 2 3700 5.0 47.0 80 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 2 3700 13.2 151.5 250 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 2 3700 6.2 68.7 11 0 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 2 3700 5.0 55.0 90 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 3 5550 19.8 181.7 300 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 3 5550 9.3 82.6 125 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 3 5550 7.5 65.5 110 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 3 5550 19.8 237.1 400 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 3 5550 9.3 107.6 175 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 3 5550 7.5 86.1 125 HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 2 3700 13.2 88.2 125 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 2 3700 6.2 40.1 60 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 2 3700 5.0 32.3 50 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 2 3700 5.0 37.9 60 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 2 3700 13.2 129.7 200 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 2 3700 6.2 58.8 100 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 2 3700 5.0 47.0 80 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 2 3700 13.2 151.5 250 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 2 3700 6.2 68.7 11 0 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 2 3700 5.0 55.0 90 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 3 5550 19.8 181.7 300 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 3 5550 9.3 82.6 125 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 3 5550 7.5 65.5 110 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 3 5550 19.8 237.1 400 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 3 5550 9.3 107.6 175 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 3 5550 7.5 86.1 125 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 3 5550 19.8 240.9 400 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 3 5550 9.3 109.3 175 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 3 5550 7.5 87.0 150 HT3B -B 4NES-14-2NU-Y HT4B -B 4NES-14-2NU-Y 460/3/60 22.1 126 1 1850 3.1 30.7 50 HT5B -B 4NES-14-5PU-Y 575/3//60 17.7 101 1 1850 2.5 24.6 40 HT3B -B 4HE-18-2NU-Y 208-230/3/60 66.7 352 1 1850 6.6 90.0 150 HT4B -B 4HE-18-2NU-Y 460/3/60 30.1 176 1 1850 3.1 40.7 70 HT5B -B 4HE-18-5PU-Y 575/3//60 24.1 140 1 1850 2.5 32.6 50 HT3B -B 4GE-23-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4GE-23-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4GE-23-5PU-Y 575/3//60 25.7 140 2 3700 5.0 37.1 60 HT3B -B 6HE-28-2NU-Y 208-230/3/60 95.6 490 2 3700 13.2 132.7 225 HT4B -B 6HE-28-2NU-Y 460/3/60 43.2 245 2 3700 6.2 60.2 100 HT5B -B 6HE-28-5PU-Y 575/3//60 34.6 196 2 3700 5.0 48.3 80 HT3B -B 6GE-34-2NU-Y 208-230/3/60 104.3 490 2 3700 13.2 143.6 225 HT4B -B 6GE-34-2NU-Y 460/3/60 47.1 245 2 3700 6.2 65.1 11 0 HT5B -B 6GE-34-5PU-Y 575/3//60 37.1 196 2 3700 5.0 51.4 80 HT3B -B 6FE-44-2NU-Y 208-230/3/60 120.1 700 2 3700 13.2 163.3 250 HT4B -B 6FE-44-2NU-Y 460/3/60 54.3 350 2 3700 6.2 74.1 125 HT5B -B 6FE-44-5PU-Y 575/3//60 43.6 280 2 3700 5.0 59.5 100 HT3B -B S4N-8.2-2NU-Y 208-230/3/60 31.0 180 1 1850 6.6 45.4 70 HT4B -B S4N-8.2-2NU-Y 460/3/60 14.7 90 1 1850 3.1 21.5 35 HT5B -B S4N-8.2-5PU-Y 575/3//60 11.2 72 1 1850 2.5 16.5 25 HT3B -B S4G-12.2-2NU-Y 208-230/3/60 44.2 252 1 1850 6.6 61.9 100 HT4B -B S4G-12.2-2NU-Y 460/3/60 21.0 126 1 1850 3.1 29.4 50 HT5B -B S4G-12.2-5PU-Y 575/3//60 16.0 101 1 1850 2.5 22.5 35 HT3B -B S6J-16.2-2NU-Y 208-230/3/60 66.3 294 1 1850 6.6 89.5 150 HT4B -B S6J-16.2-2NU-Y 460/3/60 31.5 147 1 1850 3.1 42.5 70 HT5B -B S6J-16.2-5PU-Y 575/3//60 24.0 117 1 1850 2.5 32.5 50 HT3B -B S6H-20.2-2NU-Y 208-230/3/60 75.2 352 2 3700 13.2 107.2 175 HT4B -B S6H-20.2-2NU-Y 460/3/60 35.7 176 2 3700 6.2 50.8 80 HT5B -B S6H-20.2-5PU-Y 575/3//60 27.1 140 2 3700 5.0 38.9 60 HT3B

-B S6G-25.2-2NU-Y 208-230/3/60 91.6 436 2 3700 13.2 127.7 200 HT4B -B S6G-25.2-2NU-Y 460/3/60 43.1 218 2 3700 6.2 60.1 100 HT5B -B S6G-25.2-5PU-Y 575/3//60 33.1 174 2 3700 5.0 46.4 70 HT3B -B S6F-30.2-2NU-Y 208-230/3/60 106.2 490 2 3700 13.2 146.0 250 HT4B -B S6F-30.2-2NU-Y 460/3/60 50.4 245 2 3700 6.2 69.2 110 HT5B -B S6F-30.2-5PU-Y

MODEL NO.

POWER

SUPPLY

208-230/3/60 49.0 252 1 1850 6.6 67.9 11 0

575/3//60 38.2 196 2 3700 5.0 52.8 90

COMPRESSOR CONDENSER FAN MTR. UNIT RLA LRA QTY WATTS FLA MCA MOP

BITZER

09/03/14

T40-TV-PDS-19

- 38 -

CONDENSING UNIT

MODEL

TVD030H8-

TVD040H8-

TVD050H8-

TVD060H8-

TVD070H8-

TVD080H8-

TVD030M8-

TVD040M8-

TVD050M8-

TVD060M8-

TVD070M8-

TVD080M8-

TVD100M8-

TVD024L 6/8 -

TVD030L 6/8 -

TVD040L 6/8 -

TVD050L 6/8 -

TVD060L 6/8 -

TVD080L 6/8 -

TVD016V6-

TVD024V6-

TVD032V6-

TVD040V6-

TVD050V6-

TVD060V6-

ELECTRICAL DATA -

60HzTVD-B

DOUBLE COMPESSOR MODELS

COMPRESSOR

HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 4 7400 26.4 161.4 200 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 4 7400 12.4 73.4 100 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 11 7 4 7400 10.0 59.1 80 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 4 7400 26.4 186.4 250 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 4 7400 12.4 84.6 11 0 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 4 7400 10.0 69.2 90 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 4 7400 26.4 236.1 300 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 4 7400 12.4 107.1 125 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 4 7400 10.0 85.6 11 0 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 4 7400 26.4 275.3 350 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 4 7400 12.4 124.9 150 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 4 7400 10.0 100.0 125 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 6 1110 0 39.6 331.0 450 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 6 11100 18.6 150.5 200 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 6 11100 15.0 119.4 150 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 6 11100 39.6 430.7 600 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 6 111 00 18.6 195.5 250 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 6 111 00 15.0 156.5 200 HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 4 7400 26.4 161.4 200 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 4 7400 12.4 73.4 100 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 11 7 4 7400 10.0 59.1 80 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 4 7400 26.4 186.4 250 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 4 7400 12.4 84.6 11 0 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 4 7400 10.0 69.2 90 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 4 7400 26.4 236.1 300 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 4 7400 12.4 107.1 125 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 4 7400 10.0 85.6 11 0 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 4 7400 26.4 275.3 350 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 4 7400 12.4 124.9 150 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 4 7400 10.0 100.0 125 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 6 1110 0 39.6 331.0 450 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 6 11100 18.6 150.5 200 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 6 11100 15.0 119.4 150 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 6 11100 39.6 430.7 600 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 6 111 00 18.6 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 6 111 00 15.0 156.5 200 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 6 1110 0 39.6 437.6 600 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 6 11100 18.6 198.6 250 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 6 11100 15.0 158.1 200 HT3B -B 4NES-14-2NU-Y 208-230/3/60 49.0 252 2 3700 13.2 123.5 150 HT4B -B 4NES-14-2NU-Y 460/3/60 22.1 126 2 3700 6.2 55.9 70 HT5B -B 4NES-14-5PU-Y 575/3//60 17.7 101 2 3700 5.0 44.8 60 HT3B -B 4HE-18-2NU-Y 208-230/3/60 66.7 352 2 3700 13.2 163.3 225 HT4B -B 4HE-18-2NU-Y 460/3/60 30.1 176 2 3700 6.2 73.9 100 HT5B -B 4HE-18-5PU-Y 575/3//60 24.1 140 2 3700 5.0 59.2 80

HT3B -B 4GE-23-2NU-Y 208-230/3/60 71.1 352 4 7400 26.4 186.4 250 HT4B -B 4GE-23-2NU-Y 460/3/60 32.1 176 4 7400 12.4 84.6 11 0 HT5B -B 4GE-23-5PU-Y 575/3//60 25.7 140 4 7400 10.0 67.8 90 HT3B -B 6HE-28-2NU-Y 208-230/3/60 95.6 490 4 7400 26.4 241.5 300 HT4B -B 6HE-28-2NU-Y 460/3/60 43.2 245 4 7400 12.4 109.6 150 HT5B -B 6HE-28-5PU-Y 575/3//60 34.6 196 4 7400 10.0 87.9 11 0 HT3B -B 6GE-34-2NU-Y 208-230/3/60 104.3 490 4 7400 26.4 261.1 350 HT4B -B 6GE-34-2NU-Y 460/3/60 47.1 245 4 7400 12.4 118.4 150 HT5B -B 6GE-34-5PU-Y 575/3//60 37.1 196 4 7400 10.0 93.5 125 HT3B -B 6FE-44-2NU-Y 208-230/3/60 120.1 700 4 7400 26.4 296.6 400 HT4B -B 6FE-44-2NU-Y 460/3/60 54.3 350 4 7400 12.4 134.6 175 HT5B -B 6FE-44-5PU-Y 575/3//60 43.6 280 4 7400 10.0 108.1 150 HT3B -B S4N-8.2-2NU-Y 208-230/3/60 31.0 180 2 3700 13.2 83.0 11 0 HT4B -B S4N-8.2-2NU-Y 460/3/60 14.7 90 2 3700 6.2 39.3 50 HT5B -B S4N-8.2-5PU-Y 575/3//60 11.2 72 2 3700 5.0 30.2 40 HT3B -B S4G-12.2-2NU-Y 208-230/3/60 44.2 252 2 3700 13.2 112.7 150 HT4B -B S4G-12.2-2NU-Y 460/3/60 21.0 126 2 3700 6.2 53.5 70 HT5B -B S4G-12.2-5PU-Y 575/3//60 16.0 101 2 3700 5.0 41.0 50 HT3B -B S6J-16.2-2NU-Y 208-230/3/60 66.3 294 2 3700 13.2 162.4 225 HT4B -B S6J-16.2-2NU-Y 460/3/60 31.5 147 2 3700 6.2 77.1 100 HT5B -B S6J-16.2-5PU-Y 575/3//60 24.0 11 7 2 3700 5.0 59.0 80 HT3B -B S6H-20.2-2NU-Y 208-230/3/60 75.2 352 4 7400 26.4 195.6 250 HT4B -B S6H-20.2-2NU-Y 460/3/60 35.7 176 4 7400 12.4 92.7 125 HT5B -B S6H-20.2-5PU-Y 575/3//60 27.1 140 4 7400 10.0 71.0 90 HT3B

-B S6G-25.2-2NU-Y 208-230/3/60 91.6 436 4 7400 26.4 232.5 300 HT4B -B S6G-25.2-2NU-Y 460/3/60 43.1 218 4 7400 12.4 109.4 150 HT5B -B S6G-25.2-5PU-Y 575/3//60 33.1 174 4 7400 10.0 84.5 110 HT3B -B S6F-30.2-2NU-Y HT4B -B S6F-30.2-2NU-Y 460/3/60 50.4 245 4 7400 12.4 125.8 175 HT5B -B S6F-30.2-5PU-Y 575/3//60 38.2 196 4 7400 10.0 96.0 125

MODEL NO.

POWER SUPPLY

208-230/3/60 106.2 490 4 7400 26.4 265.4 350

COMPRESSOR CONDENSER FAN MTR. UNIT RLA LRA QTY WATTS FLA MCA MOP

195.5 250

TVS-A

09/03/14

T40-TV-PDS-19

- 39 -

COPELAND

ELECTRICAL DATA -

SINGLE COMPESSOR MODELS

with EC Motors only or

EC MOTORS

60Hz

CONDENSING UNIT

MODEL

TVS015H8-

TVS022H8-

TVS025H8-

TVS030H8-

TVS035H8-

TVS040H8-

TVS015M8-

TVS022M8-

TVS025M8-

TVS030M8-

TVS035M8-

TVS040M8-

TVS050M8- HT4B

TVS010L 6/8 -

TVS015L 6/8 -

TVS022L 6/8 -

TVS027L6/8-

TVS030L 6/8 -

TVS040L 6/8 - HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 2 3500 6.2 86.1 125

* 6DJ only available in 230V

**=575Vunitsusea230Vmotorwithatransformer

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 3500 12.4 86.9 125 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 3500 4.6 40.9 60 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 2 3500 5.0 34.5 50 HT3B -A 4DBNR20ME-TSK 208-230/3/60 85.7 374 2 3500 12.4 119.5 200 HT4B -A 4DBNR20ME-TSK 460/3/60 42.9 187 2 3500 4.6 58.2 100 HT5B -A 4DBNR20ME-TSE 575/3//60 33.6 135 2 3500 5.0 47.0 80 HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 2 3500 12.4 146.3 250 HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 2 3500 4.6 71.6 125 HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 2 3500 5.0 53.5 90 HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 2 3500 12.4 155.3 250 HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 2 3500 4.6 76.0 125 HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 2 3500 5.0 66.6 11 0 HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 3 5250 18.6 195.4 300 HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 3 5250 6.9 95.3 150 HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 3 5250 7.5 74.5 125 HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 3 5250 18.6 216.9 350 HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 3 5250 6.9 106.0 175 HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 3 5250 7.5 88.8 150 HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 3500 12.4 86.9 125 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 3500 4.6 40.9 60 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 2 3500 5.0 34.5 50 HT3B -A 4DBNR20ME-TSK 208-230/3/60 72.1 374 2 3500 12.4 102.5 150 HT4B -A 4DBNR20ME-TSK 460/3/60 36.1 187 2 3500 4.6 49.7 80 HT5B -A 4DBNR20ME-TSE 575/3//60 31.4 135 2 3500 5.0 44.3 70 HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 2 3500 12.4 115.0 175 HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 2 3500 4.6 56.0 90 HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 2 3500 5.0 48.0 80 HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 2 3500 12.4 144.2 225 HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 2 3500 4.6 70.5 11 0 HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 2 3500 5.0 60.1 100 HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 3 5250 18.6 175.0 300 HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 3 5250 6.9 85.2 125 HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 3 5250 7.5 61.4 100 HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 3 5250 HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 3 5250 6.9 96.2 150 HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 3 5250 7.5 72.6 11 0

-A 6DUNR49ME-AWD 460/3/60 84.2 482 3 5250 6.9 112.2 175

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 1 1750 6.6 58.4 90 HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 1 1750 3.1 26.4 40 HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 1 1750 2.5 22.8 35 HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 1 1750 6.6 72.4 110 HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 1 1750 3.1 36.0 60 HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 11 3 1 1750 2.5 28.6 45 HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 2 3500 12.4 92.8 150 HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 2 3500 4.6 44.7 70 HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 2 3500 5.0 41.4 70 HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 2 3500 12.4 113.3 175 HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 2 3500 4.6 55.1 90 HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 2 3500 5.0 45.6 70 HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 2 3500 12.4 131.9 225 HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 2 3500 4.6 64.4 11 0 HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 2 3500 5.0 54.5 90

COMPRESSOR

MODEL NO.

POWER SUPPLY

COMPRESSOR

RLA LRA QTY WATTS FLA MCA MOP

CONDENSER

FAN MOTOR **

UNIT

18.6 197.2 300

ELECTRICAL DATA -

09/03/14

T40-TV-PDS-19

- 40 -

EC MOTORS

TVD-A

COPELAND

DOUBLE COMPESSOR MODELS

with EC Motors only or

CONDENSING UNIT

MODEL

TVD030H8-

TVD044H8-

TVD050H8-

TVD060H8-

TVD070H8-

TVD080H8-

TVD030M8-

TVD044M8-

TVD050M8-

TVD060M8-

TVD070M8-

TVD080M8-

TVS100M8- HT4B -A 6DUNR49ME-AWD 460/3/60

TVD020L 6/8 -

TVD030L 6/8 -

TVD044L 6/8 -

TVD054L 6/8 -

TVD060L 6/8 -

TVS080L 6/8 - HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 4 7000 9.2 153.0 200

* 6DJ only available in 230V

**=575Vunitsusea230Vmotorwithatransformer

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 7000 24.8 158.9 200 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 7000 9.2 74.5 100 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 4 7000 10.0 63.1 80 HT3B -A 4DBNR20ME-TSK 208-230/3/60 85.7 374 4 7000 24.8 217.6 300 HT4B -A 4DBNR20ME-TSK 460/3/60 42.9 187 4 7000 9.2 105.7 125 HT5B -A 4DBNR20ME-TSE 575/3//60 33.6 135 4 7000 10.0 85.6 110 HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 4 7000 24.8 265.8 350 HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 4 7000 9.2 129.8 175 HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 4 7000 10.0 97.3 125 HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 4 7000 24.8 282.0 350 HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 4 7000 9.2 137.7 175 HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 4 7000 10.0 120.9 150 HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 6 10500 37.2 355.4 450 HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 6 10500 13.8 172.9 225 HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 6 10500 15.0 135.6 175 HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 6 10500 37.2 394.1 500 HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 6 10500 13.8 192.2 250 HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 6 10500 15.0 161.3 225 HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 7000 24.8 158.9 200 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 7000 9.2 74.5 100 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 4 7000 10.0 63.1 80 HT3B -A 4DBNR20ME-TSK 208-230/3/60 72.1 374 4 7000 24.8 187.0 250 HT4B -A 4DBNR20ME-TSK 460/3/60 36.1 187 4 7000 9.2 90.4 125 HT5B -A 4DBNR20ME-TSE 575/3//60 31.4 135 4 7000 10.0 80.7 110 HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 4 7000 24.8 209.5 250 HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 4 7000 9.2 101.7 125 HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 4 7000 10.0 87.4 11 0 HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 4 7000 24.8 262.0 350 HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 4 7000 9.2 127.8 175 HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 4 7000 10.0 109.2 150 HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 6 10500 37.2 318.7 400 HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 6 10500 13.8 154.7 200 HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 6 10500 15.0 112.0 150 HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 6 10500 HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 6 10500 13.8 174.5 225 HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 6 10500 15.0 132.2 175

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 2 3500 12.4 105.6 125 HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 2 3500 4.6 46.5 60 HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 2 3500 5.0 41.5 50 HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 2 3500 12.4 130.8 175 HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 2 3500 4.6 63.8 90 HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 11 3 2 3500 5.0 52.0 70 HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 4 7000 24.8 169.5 225 HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 4 7000 9.2 81.4 110 HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 4 7000 10.0 75.5 100 HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 4 7000 24.8 206.4 250 HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 4 7000 9.2 100.1 125 HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 4 7000 10.0 83.1 110 HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 4 7000 24.8 239.9 300 HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 4 7000 9.2 116.8 150 HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 4 7000 10.0 99.1 125

COMPRESSOR

MODEL NO.

POWER

SUPPLY

COMPRESSOR

RLA LRA QTY WATTS FLA MCA MOP

84.2 482 6 10500 13.8 203.3 250

CONDENSER

FAN MOTOR **

37.2 358.7 500

60Hz

UNIT

TVS-B

09/03/14

T40-TV-PDS-19

- 41 -

BITZER

ELECTRICAL DATA -

SINGLE COMPESSOR MODELS

with EC Motors only or

EC MOTORS

60Hz

CONDENSING UNIT

MODEL

TVS015H8-

TVS020H8-

TVS025H8-

TVS030H8-

TVS035H8-

TVS040H8-

TVS015M8-

TVS020M8-

TVS025M8-

TVS030M8-

TVS035M8-

TVS040M8-

TVS050M8-

TVS012L 6/8 -

TVS015L 6/8 -

TVS020L 6/8 -

TVS025L 6/8 -

TVS030L 6/8 -

TVS040L6 6/8-

TVS008V6-

TVS012V6-

TVS016V6-

TVS020V6-

TVS025V6-

TVS030V6-

**=575Vunitsusea230Vmotorwithatransformer

HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 2 3500 12.4 87.4 125 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 2 3500 4.6 38.5 60 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 2 3500 5.0 32.3 50 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 2 3500 12.4 101.3 150 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 2 3500 4.6 44.7 70 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 2 3500 5.0 37.9 60 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 2 3500 12.4 128.9 200 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 2 3500 4.6 57.2 90 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 2 3500 5.0 47.0 80 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 2 3500 12.4 150.7 250 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 2 3500 4.6 67.1 110 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 2 3500 5.0 55.0 90 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 3 5250 18.6 180.5 300 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 3 5250 6.9 80.2 125 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 3 5250 7.5 65.5 110 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 3 5250 18.6 235.9 400 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 3 5250 6.9 105.2 175 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 3 5250 7.5 86.1 125 HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 2 3500 12.4 87.4 125 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 2 3500 4.6 38.5 60 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 2 3500 5.0 32.3 50 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 2 3500 12.4 101.3 150 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 2 3500 4.6 44.7 70 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 2 3500 5.0 37.9 60 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 2 3500 12.4 128.9 200 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 2 3500 4.6 57.2 90 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 2 3500 5.0 47.0 80 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 2 3500 12.4 150.7 250 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 2 3500 4.6 67.1 110 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 2 3500 5.0 55.0 90 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 3 5250 18.6 180.5 300 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 3 5250 6.9 80.2 125 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 3 5250 7.5 65.5 110 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 3 5250 18.6 235.9 400 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 3 5250 6.9 105.2 175 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 3 5250 7.5 86.1 125 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 3 5250 18.6 239.7 400 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 3 5250 6.9 106.9 175 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 3 5250 7.5 87.0 150 HT3B -B 4NES-14-2NU-Y HT4B -B 4NES-14-2NU-Y 460/3/60 22.1 126 1 1750 2.3 29.9 50 HT5B -B 4NES-14-5PU-Y 575/3//60 17.7 101 1 1750 2.5 24.6 40 HT3B -B 4HE-18-2NU-Y 208-230/3/60 66.7 352 1 1750 6.2 89.6 150 HT4B -B 4HE-18-2NU-Y 460/3/60 30.1 176 1 1750 2.3 39.9 70 HT5B -B 4HE-18-5PU-Y 575/3//60 24.1 140 1 1750 2.5 32.6 50 HT3B -B 4GE-23-2NU-Y 208-230/3/60 71.1 352 2 3500 12.4 101.3 150 HT4B -B 4GE-23-2NU-Y 460/3/60 32.1 176 2 3500 4.6 44.7 70 HT5B -B 4GE-23-5PU-Y 575/3//60 25.7 140 2 3500 5.0 37.1 60 HT3B -B 6HE-28-2NU-Y 208-230/3/60 95.6 490 2 3500 12.4 131.9 225 HT4B -B 6HE-28-2NU-Y 460/3/60 43.2 245 2 3500 4.6 58.6 100 HT5B -B 6HE-28-5PU-Y 575/3//60 34.6 196 2 3500 5.0 48.3 80 HT3B -B 6GE-34-2NU-Y 208-230/3/60 104.3 490 2 3500 12.4 142.8 225 HT4B -B 6GE-34-2NU-Y 460/3/60 47.1 245 2 3500 4.6 63.5 110 HT5B -B 6GE-34-5PU-Y 575/3//60 37.1 196 2 3500 5.0 51.4 80 HT3B -B 6FE-44-2NU-Y 208-230/3/60 120.1 700 2 3500 12.4 162.5 250 HT4B -B 6FE-44-2NU-Y 460/3/60 54.3 350 2 3500 4.6 72.5 125 HT5B -B 6FE-44-5PU-Y 575/3//60 43.6 280 2 3500 5.0 59.5 100 HT3B -B S4N-8.2-2NU-Y 208-230/3/60 31.0 180 1 1750 6.2 45.0 70 HT4B -B S4N-8.2-2NU-Y 460/3/60 14.7 90 1 1750 2.3 20.7 35 HT5B -B S4N-8.2-5PU-Y 575/3//60 11.2 72 1 1750 2.5 16.5 25 HT3B -B S4G-12.2-2NU-Y 208-230/3/60 44.2 252 1 1750 6.2 61.5 100 HT4B -B S4G-12.2-2NU-Y 460/3/60 21.0 126 1 1750 2.3 28.6 45 HT5B -B S4G-12.2-5PU-Y 575/3//60 16.0 101 1 1750 2.5 22.5 35 HT3B -B S6J-16.2-2NU-Y 208-230/3/60 66.3 294 1 1750 6.2 89.1 150 HT4B -B S6J-16.2-2NU-Y 460/3/60 31.5 147 1 1750 2.3 41.7 70 HT5B -B S6J-16.2-5PU-Y 575/3//60 24.0 117 1 1750 2.5 32.5 50 HT3B -B S6H-20.2-2NU-Y 208-230/3/60 75.2 352 2 3500 12.4 106.4 175 HT4B -B S6H-20.2-2NU-Y 460/3/60 35.7 176 2 3500 4.6 49.2 80 HT5B -B S6H-20.2-5PU-Y 575/3//60 27.1 140 2 3500 5.0 38.9 60 HT3B

-B S6G-25.2-2NU-Y 208-230/3/60 91.6 436 2 3500 12.4 126.9 200 HT4B -B S6G-25.2-2NU-Y 460/3/60 43.1 218 2 3500 4.6 58.5 100 HT5B -B S6G-25.2-5PU-Y 575/3//60 33.1 174 2 3500 5.0 46.4 70 HT3B -B S6F-30.2-2NU-Y 208-230/3/60 106.2 490 2 3500 12.4 145.2 250 HT4B -B S6F-30.2-2NU-Y 460/3/60 50.4 245 2 3500 4.6 67.6 110 HT5B -B S6F-30.2-5PU-Y

COMPRESSOR

MODEL NO.

POWER

SUPPLY

208-230/3/60 49.0 252 1 1750 6.2 67.5 110

575/3//60 38.2 196 2 3500 5.0 52.8 90

COMPRESSOR CONDENSER FAN MTR. ** UNIT

RLA LRA QTY WATTS FLA MCA MOP

TVD-B

09/03/14

T40-TV-PDS-19

- 42 -

BITZER

ELECTRICAL DATA -

DOUBLE COMPESSOR MODELS

with EC Motors only or

EC MOTORS

60Hz

CONDENSING UNIT

MODEL

TVD030H8-

TVD040H8-

TVD050H8-

TVD060H8-

TVD070H8-

TVD080H8-

TVD030M8-

TVD040M8-

TVD050M8-

TVD060M8-

TVD070M8-

TVD080M8-

TVD100M8-

TVD024L 6/8 -

TVD030L 6/8 -

TVD040L 6/8 -

TVD050L 6/8 -

TVD060L 6/8 -

TVD080L 6/8 -

TVD016V6-

TVD024V6-

TVD032V6-

TVD040V6-

TVD050V6-

TVD060V6-

**=575Vunitsusea230Vmotorwithatransformer

HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 4 7000 24.8 159.8 200 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 4 7000 9.2 70.2 90 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 4 7000 10.0 59.1 80 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 4 7000 24.8 184.8 250 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 4 7000 9.2 81.4 110 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 4 7000 10.0 69.2 90 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 4 7000 24.8 234.5 300 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 4 7000 9.2 103.9 125 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 4 7000 10.0 85.6 110 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 4 7000 24.8 273.7 350 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 4 7000 9.2 121.7 150 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 4 7000 10.0 100.0 125 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 6 10500 37.2 328.6 450 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 6 10500 13.8 145.7 200 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 6 10500 15.0 119.4 150 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 6 10500 37.2 428.3 600 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 6 10500 13.8 190.7 250 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 6 10500 15.0 156.5 200 HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 4 7000 24.8 159.8 200 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 4 7000 9.2 70.2 90 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 4 7000 10.0 59.1 80 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 4 7000 24.8 184.8 250 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 4 7000 9.2 81.4 110 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 4 7000 10.0 69.2 90 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 4 7000 24.8 234.5 300 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 4 7000 9.2 103.9 125 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 4 7000 10.0 85.6 110 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 4 7000 24.8 273.7 350 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 4 7000 9.2 121.7 150 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 4 7000 10.0 100.0 125 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 6 10500 37.2 328.6 450 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 6 10500 13.8 145.7 200 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 6 10500 15.0 119.4 150 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 6 10500 37.2 428.3 600 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 6 10500 13.8 190.7 250 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 6 10500 15.0 156.5 200 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 6 10500 37.2 435.2 600 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 6 10500 13.8 193.8 250 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 6 10500 15.0 158.1 200 HT3B -B 4NES-14-2NU-Y HT4B -B 4NES-14-2NU-Y 460/3/60 22.1 126 2 3500 4.6 54.3 70 HT5B -B 4NES-14-5PU-Y 575/3//60 17.7 101 2 3500 5.0 44.8 60 HT3B -B 4HE-18-2NU-Y 208-230/3/60 66.7 352 2 3500 12.4 162.5 225 HT4B -B 4HE-18-2NU-Y 460/3/60 30.1 176 2 3500 4.6 72.3 100 HT5B -B 4HE-18-5PU-Y 575/3//60 24.1 140 2 3500 5.0 59.2 80

HT3B -B 4GE-23-2NU-Y 208-230/3/60 71.1 352 4 7000 24.8 184.8 250 HT4B -B 4GE-23-2NU-Y 460/3/60 32.1 176 4 7000 9.2 81.4 110 HT5B -B 4GE-23-5PU-Y 575/3//60 25.7 140 4 7000 10.0 67.8 90 HT3B -B 6HE-28-2NU-Y 208-230/3/60 95.6 490 4 7000 24.8 239.9 300 HT4B -B 6HE-28-2NU-Y 460/3/60 43.2 245 4 7000 9.2 106.4 125 HT5B -B 6HE-28-5PU-Y 575/3//60 34.6 196 4 7000 10.0 87.9 110 HT3B -B 6GE-34-2NU-Y 208-230/3/60 104.3 490 4 7000 24.8 259.5 350 HT4B -B 6GE-34-2NU-Y 460/3/60 47.1 245 4 7000 9.2 115.2 150 HT5B -B 6GE-34-5PU-Y 575/3//60 37.1 196 4 7000 10.0 93.5 125 HT3B -B 6FE-44-2NU-Y 208-230/3/60 120.1 700 4 7000 24.8 295.0 400 HT4B -B 6FE-44-2NU-Y 460/3/60 54.3 350 4 7000 9.2 131.4 175 HT5B -B 6FE-44-5PU-Y 575/3//60 43.6 280 4 7000 10.0 108.1 150 HT3B -B S4N-8.2-2NU-Y 208-230/3/60 31.0 180 2 3500 12.4 82.2 110 HT4B -B S4N-8.2-2NU-Y 460/3/60 14.7 90 2 3500 4.6 37.7 50 HT5B -B S4N-8.2-5PU-Y 575/3//60 11.2 72 2 3500 5.0 30.2 40 HT3B -B S4G-12.2-2NU-Y 208-230/3/60 44.2 252 2 3500 12.4 111 . 9 150 HT4B -B S4G-12.2-2NU-Y 460/3/60 21.0 126 2 3500 4.6 51.9 70 HT5B -B S4G-12.2-5PU-Y 575/3//60 16.0 101 2 3500 5.0 41.0 50 HT3B -B S6J-16.2-2NU-Y 208-230/3/60 66.3 294 2 3500 12.4 161.6 225 HT4B -B S6J-16.2-2NU-Y 460/3/60 31.5 147 2 3500 4.6 75.5 100 HT5B -B S6J-16.2-5PU-Y 575/3//60 24.0 117 2 3500 5.0 59.0 80 HT3B -B S6H-20.2-2NU-Y 208-230/3/60 75.2 352 4 7000 24.8 194.0 250 HT4B -B S6H-20.2-2NU-Y 460/3/60 35.7 176 4 7000 9.2 89.5 125 HT5B -B S6H-20.2-5PU-Y 575/3//60 27.1 140 4 7000 10.0 71.0 90 HT3B

-B S6G-25.2-2NU-Y 208-230/3/60 91.6 436 4 7000 24.8 230.9 300 HT4B -B S6G-25.2-2NU-Y 460/3/60 43.1 218 4 7000 9.2 106.2 125 HT5B -B S6G-25.2-5PU-Y 575/3//60 33.1 174 4 7000 10.0 84.5 11 0 HT3B -B S6F-30.2-2NU-Y HT4B -B S6F-30.2-2NU-Y 460/3/60 50.4 245 4 7000 9.2 122.6 150 HT5B -B S6F-30.2-5PU-Y 575/3//60 38.2 196 4 7000 10.0 96.0 125

COMPRESSOR

MODEL NO.

POWER SUPPLY

208-230/3/60 49.0 252 2 3500 12.4 122.7 150

208-230/3/60 106.2 490 4 7000 24.8 263.8 350

COMPRESSOR CONDENSER FAN MTR. ** UNIT

RLA LRA QTY WATTS FLA MCA MOP

TVS

09/03/14

T40-TV-PDS-19

- 43 -

SINGLE COMPESSOR MODELS

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

REMOVEABLE ROOF SECTION

DIMENSIONAL DATA -

TOP VIEW

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

53 5/8

1361

HINGED SERVICE DOOR HINGED SERVICE DOOR

56 1/4 1429

69 1/8 1757

END CAPPED PIPE ( STANDARD ) SUCTION FILTER ( OPTIONAL ) ( REPLACEABLE CORE )

SIDE VIEW

23 3/8 593

BASE FRAME LENGTH

(SEE OPPOSITE PAGE)

222 3/8

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD ) ( REPLACEABLE CORE )

28 1/2

724

1397

508

127

REMOVEABLE ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HINGED SERVICE DOOR HINGED SERVICE DOOR

SIDE VIEW

TOP VIEW

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD ) ( REPLACEABLE CORE )

END CAPPED PIPE ( STANDARD ) SUCTION FILTER ( OPTIONAL ) ( REPLACEABLE CORE )

69 1/8 1757

23 3/8 593

53 5/8

1361

56 1/4 1429

222 3/8

TVS

09/03/14

T40-TV-PDS-19

- 44 -

DIMENSIONAL DATA -

SINGLE COMPESSOR MODELS

COMPRESSOR-END VIEW

HINGED SERVICE DOOR

ELECTRICAL K'OUTS

44 3/4 1137

TVS-A

COPELAND

CONDENSING

UNIT

MODEL

TVS015H8-H**B-A 167 3/8 4251

TVS022H8-H**B-A 167 3/8 4251

TVS025H8-H**B-A 167 3/8 4251

TVS030H8-H**B-A 167 3/8 4251

TVS035H8-H**B-A 222 3/8 5648

TVS040H8-H**B-A 222 3/8 5648

TVS015M8-H**B-A 167 3/8 4251

TVS022M8-H**B-A 167 3/8 4251

TVS025M8-H**B-A 167 3/8 4251

TVS030M8-H**B-A 167 3/8 4251

TVS035M8-H**B-A 222 3/8 5648

TVS040M8-H**B-A 222 3/8 5648

TVS050M8-H**B-A 222 3/8 5648

TVS010L 6/8 -H**B-A 112 3/8 2854

TVS015L 6/8 -H**B-A 112 3/8 2854

TVS022L 6/8 -H**B-A 167 3/8 4251

TVS027L 6/8 -H**B-A 167 3/8 4251

TVS030L 6/8 -H**B-A 167 3/8 4251

TVS040L 6/8 -H**B-A 167 3/8 4251

BASE FRAME

LENGTH

inches mm

TVS-B

BITZER

CONDENSING

UNIT

MODEL

TVS015H8-H**B-B 167 3/8 4251 TVS020H8-H**B-B 167 3/8 4251 TVS025H8-H**B-B 167 3/8 4251 TVS030H8-H**B-B 167 3/8 4251 TVS035H8-H**B-B 222 3/8 5648 TVS040H8-H**B-B 222 3/8 5648 TVS015M8-H**B-B 167 3/8 4251 TVS020M8-H**B-B 167 3/8 4251 TVS025M8-H**B-B 167 3/8 4251 TVS030M8-H**B-B 167 3/8 4251 TVS035M8-H**B-B 222 3/8 5648 TVS040M8-H**B-B 222 3/8 5648

TVS050M8-H**B-B 222 3/8 5648 TVS012L 6/8 -H**B-B 112 3/8 2854 TVS015L 6/8 -H**B-B 112 3/8 2854 TVS020L 6/8 -H**B-B 167 3/8 4251 TVS025L 6/8 -H**B-B 167 3/8 4251 TVS030L 6/8 -H**B-B 167 3/8 4251 TVS040L 6/8 -H**B-B 167 3/8 4251

TVS008V6-H**B-B 112 3/8 2854

TVS012V6-H**B-B 112 3/8 2854

TVS016V6-H**B-B 112 3/8 2854

TVS020V6-H**B-B 167 3/8 4251

TVS025V6-H**B-B 167 3/8 4251

TVS030V6-H**B-B 167 3/8 4251

BASE FRAME

inches mm

LENGTH

TVD

09/03/14

T40-TV-PDS-19

- 45 -

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

COMPRESSOR #1 REMOVEABLE ROOF SECTION

DIMENSIONAL DATA -

DOUBLE COMPESSOR MODELS

TOP VIEW

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

COMPRESSOR #2 REMOVEABLE ROOF SECTION

HINGED SERVICE DOOR HINGED SERVICE DOOR

CONDENSER FAN #1R

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD ) REPLACEABLE CORE

END CAPPED PIPE ( STANDARD ) SUCTION FILTER ( OPTIONAL ) ( REPLACEABLE CORE )

SIDE VIEW

CONDENSER FAN #2R

CONDENSER FAN #3R

28 1/2

724

1397

508

69 1/8 1757

23 3/8 593

222 3/8

BASE FRAME LENGTH

(SEE OPPOSITE PAGE)

127

69 1/8 1757

23 3/8 593

222 3/8

LIQUID FILTER DRIER ( STANDARD ) REPLACEABLE CORE

END CAPPED PIPE ( STANDARD ) SUCTION FILTER ( OPTIONAL ) ( REPLACEABLE CORE )

COMPRESSOR #1 REMOVEABLE ROOF SECTION

COMPRESSOR #2 REMOVEABLE ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #1R

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HINGED SERVICE DOOR HINGED SERVICE DOOR

SIDE VIEW

TOP VIEW

TVD

09/03/14

T40-TV-PDS-19

- 46 -

DIMENSIONAL DATA -

DOUBLE COMPESSOR MODELS

COMPRESSOR-END VIEW

ELECTRICAL K'OUTS

HINGED SERVICE DOOR COMPRESSOR #1

TVD-A

COPELAND

CONDENSING

UNIT

MODEL

TVD030H8-H**B-A 167 3/8 4251

TVD044H8-H**B-A 167 3/8 4251

TVD050H8-H**B-A 167 3/8 4251

TVD060H8-H**B-A 167 3/8 4251

TVD070H8-H**B-A 222 3/8 5648

TVD080H8-H**B-A 222 3/8 5648

TVD030M8-H**B-A 167 3/8 4251

TVD044M8-H**B-A 167 3/8 4251

TVD050M8-H**B-A 167 3/8 4251

TVD060M8-H**B-A 167 3/8 4251

TVD070M8-H**B-A 222 3/8 5648

TVD080M8-H**B-A 222 3/8 5648

TVD100M8-H**B-A 222 3/8 5648

TVD020L 6/8 -H**B-A 112 3/8 2854

TVD030L 6/8 -H**B-A 112 3/8 2854

TVD044L 6/8 -H**B-A 167 3/8 4251

TVD054L 6/8 -H**B-A 167 3/8 4251

TVD060L 6/8 -H**B-A 167 3/8 4251

TVD080L 6/8 -H**B-A 167 3/8 4251

BASE FRAME

LENGTH

inches mm

86 3/4 2203

HINGED SERVICE DOOR COMPRESSOR #2

TVD-B

BITZER

CONDENSING

UNIT

MODEL

TVD030H8-H**B-B 167 3/8 4251 TVD040H8-H**B-B 167 3/8 4251 TVD050H8-H**B-B 167 3/8 4251 TVD060H8-H**B-B 167 3/8 4251

TVD070H8-H**B-B 222 3/8 5648

TVD080H8-H**B-B 222 3/8 5648 TVD030M8-H**B-B 167 3/8 4251 TVD040M8-H**B-B 167 3/8 4251 TVD050M8-H**B-B 167 3/8 4251 TVD060M8-H**B-B 167 3/8 4251

TVD070M8-H**B-B 222 3/8 5648

TVD080M8-H**B-B 222 3/8 5648

TVD100M8-H**B-B 222 3/8 5648 TVD024L 6/8 -H**B-B 112 3/8 2854 TVD030L 6/8 -H**B-B 112 3/8 2854 TVD040L 6/8 -H**B-B 167 3/8 4251 TVD050L 6/8 -H**B-B 167 3/8 4251 TVD060L 6/8 -H**B-B 167 3/8 4251 TVD080L 6/8 -H**B-B 167 3/8 4251

TVD016V6-H**B-B 112 3/8 2854

TVD024V6-H**B-B 112 3/8 2854

TVD032V6-H**B-B 112 3/8 2854

TVD040V6-H**B-B 167 3/8 4251

TVD050V6-H**B-B 167 3/8 4251

TVD060V6-H**B-B 167 3/8 4251

BASE FRAME

inches mm

LENGTH

COPELAND

09/03/14

T40-TV-PDS-19

- 47 -

SPECIFICATIONS -

60HzTVS-A

SINGLE COMPESSOR MODELS

CONDENSING

UNIT

MODEL

TVS015H8-H**B-A 2 1 5/8 41 7/8 22 103 46.7 2155 979 TVS022H8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2385 1084 TVS025H8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2400 1091 TVS030H8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2500 1136 TVS035H8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3035 1379 TVS040H8-H**B-A 3 2 1/8 54 1 3/8 35 189 85.8 3165 1438 TVS015M8-H**B-A 2 1 5/8 41 7/8 22 103 46.7 2160 982 TVS022M8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2390 1086 TVS025M8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2405 1093 TVS030M8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2510 1141 TVS035M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3035 1379 TVS040M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3165 1438

TVS050M8-H**B-A 3 2 1/8 54 1 1/8 29 254 115.3 3285 1493 TVS010L 6/8 -H**B-A 1 1 3/8 35 5/8 16 70 31.8 1675 761 TVS015L 6/8 -H**B-A 1 1 5/8 41 7/8 22 82 37.2 1800 818 TVS022L 6/8 -H**B-A 2 2 1/8 54 7/8 22 103 46.7 2285 1039 TVS027L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2510 1141 TVS030L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2515 1143 TVS040L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2645 1202

CONDENSER

FANS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

UNIT CONNECTIONS

R404A

RECEIVER CAPACITY

90% FULL *

APPROX.

SHIPPING WEIGHT

SPECIFICATIONS -

60HzTVD-A

COPELAND

CONDENSING

UNIT

MODEL

TVD030H8-H**B-A 2 1 5/8 41 7/8 22 103 46.7 3865 1757 TVD044H8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4315 1916 TVD050H8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4345 1975 TVD060H8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4540 2063

TVD070H8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5510 2504

TVD080H8-H**B-A 3 2 1/8 54 1 3/8 35 189 85.8 5760 2618 TVD030M8-H**B-A 2 1 5/8 41 7/8 22 103 46.7 3875 1761 TVD044M8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4325 1966 TVD050M8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4355 1979 TVD060M8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4555 2070

TVD070M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5515 2506

TVD080M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5760 2618 TVD100M8-H**B-A 3 2 1/8 54 1 1/8 29 254 115.3 6005 2729

TVD020L 6/8 -H**B-A 1 1 3/8 35 5/8 16 70 31.8 2975 1352 TVD030L 6/8 -H**B-A 1 1 5/8 41 7/8 22 82 37.2 3225 1466 TVD044L 6/8 -H**B-A 2 2 1/8 54 7/8 22 103 46.7 4120 1872 TVD054L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4570 2077 TVD060L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4580 2082 TVD080L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4830 2195

CONDENSER

DOUBLE COMPESSOR MODELS

UNIT CONNECTIONS

FANS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

R404A

RECEIVER CAPACITY

90% FULL *

APPROX.

SHIPPING WEIGHT

* NOTE ON ALTERNATE REFRIGERANTS:

* PUBLISHED RECEIVER CAPACITY IS BASED ON

FOR ALERNATE REFRIGERANTS, MULTIPLY

R407A

1.10 1.10 1.00 1.15

R407C

R404A

ON MODELS USING “8” AS REFRIGERANT CODE.

VALUE BY THE APPROPRIATE VALUE BELOW:

R507

R22

SPECIFICATIONS -

09/03/14

T40-TV-PDS-19

- 48 -

BITZER

CONDENSING

UNIT

MODEL

TVS015H8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 2085 948 TVS020H8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 2175 989 TVS025H8-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 2400 1091 TVS030H8-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2505 1138 TVS035H8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 2990 1359 TVS040H8-H**B-B 3 2 1/8 54 1 3/8 35 189 85.8 3120 1418 TVS015M8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 2090 950 TVS020M8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 2170 986 TVS025M8-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 2400 1091 TVS030M8-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2515 1143 TVS035M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 2995 1361 TVS040M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 3115 1416

TVS050M8-H**B-B 3 2 1/8 54 1 1/8 29 254 115.3 3230 1468 TVS012L 6/8 -H**B-B 1 1 3/8 35 5/8 16 70 31.8 1580 718 TVS015L 6/8 -H**B-B 1 1 5/8 41 7/8 22 82 37.2 1750 795 TVS020L 6/8 -H**B-B 2 2 1/8 54 7/8 22 103 46.7 2250 1023 TVS025L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 2445 1111 TVS030L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 2470 1123 TVS040L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2600 1182

TVS008V6-H**B-B 1 1 1/8 29 1/2 13 70 31.8 1585 720 TVS012V6-H**B-B 1 1 3/8 35 5/8 16 82 37.2 1705 775 TVS016V6-H**B-B 1 1 5/8 41 5/8 16 82 37.2 1860 845 TVS020V6-H**B-B 2 2 1/8 54 5/8 16 124 56.3 2435 1107 TVS025V6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 2470 1123 TVS030V6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 2545 1157

CONDENSER

FANS

SINGLE COMPESSOR MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

R404A

RECEIVER CAPACITY

90% FULL *

60HzTVS-B

APPROX.

SHIPPING WEIGHT

SPECIFICATIONS -

BITZER

CONDENSING

UNIT

MODEL

TVD030H8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 3725 1693 TVD040H8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 3895 1770 TVD050H8-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 4340 1972 TVD060H8-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4550 2068

TVD070H8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5425 2466

TVD080H8-H**B-B 3 2 1/8 54 1 3/8 35 189 85.8 5670 2577 TVD030M8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 3735 1698 TVD040M8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 3880 1763 TVD050M8-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 4350 1977 TVD060M8-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4565 2075

TVD070M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5430 2468

TVD080M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5665 2575 TVD100M8-H**B-B 3 2 1/8 54 1 1/8 29 254 115.3 5895 2679

TVD024L 6/8 -H**B-B 1 1 3/8 35 5/8 16 70 31.8 2790 1268 TVD030L 6/8 -H**B-B 1 1 5/8 41 7/8 22 82 37.2 3120 1418 TVD040L 6/8 -H**B-B 2 2 1/8 54 7/8 22 103 46.7 4055 1843 TVD050L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 4440 2018 TVD060L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 4480 2036 TVD080L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4745 2157

TVD016V6-H**B-B 1 1 1/8 29 1/2 13 70 31.8 2795 1270

TVD024V6-H**B-B 1 1 3/8 35 5/8 16 82 37.2 3030 1377

TVD032V6-H**B-B 1 1 5/8 41 5/8 16 82 37.2 3345 1520

TVD040V6-H**B-B 2 2 1/8 54 5/8 16 124 56.3 4415 2007

TVD050V6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 4485 2038

TVD060V6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 4630 2104

* NOTE ON ALTERNATE REFRIGERANTS:* PUBLISHED RECEIVER CAPACITY IS

BASED ON

MULTIPLY

CONDENSER

FANS

R404A

DOUBLE COMPESSOR MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

ON MODELS USING “8” AS REFRIGERANT CODE.

FOR ALERNATE REFRIGERANTS,

VALUE BY THE APPROPRIATE VALUE AT RIGHT:

RECEIVER CAPACITY

R404A

90% FULL *

R407A

1.10 1.10 1.00 1.15

R407C R507

APPROX. SHIPPING

60HzTVD-B

WEIGHT

R22

TVS/D

09/03/14

T40-TV-PDS-19

- 49 -

CONDENSING UNIT WIRING DIAGRAM -

COMPRESSOR #1

TVS/D

09/03/14

T40-TV-PDS-19

- 50 -

CONDENSING UNIT WIRING DIAGRAM -

COMPRESSOR #2

TVS/D

09/03/14

T40-TV-PDS-19

- 51 -

AIR DEFROST EVAP. WIRING DIAGRAM -

COMPRESSOR #1

TVS/D

09/03/14

T40-TV-PDS-19

- 52 -

AIR DEFROST EVAP. WIRING DIAGRAM -

COMPRESSOR #2

TVS/D

09/03/14

T40-TV-PDS-19

- 53 -

ELECTRIC DEFROST EVAP. WIRING DIAGRAM -

COMPRESSOR #1

TVS/D

09/03/14

T40-TV-PDS-19

- 54 -

ELECTRIC DEFROST EVAP. WIRING DIAGRAM -

COMPRESSOR #2

COPELAND

09/03/14

T40-TV-PDS-19

- 55 -

CAPACITY DATA -

R407A

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS016H8-A

Compressor

3DS3R17ME

TVS023H8-A

Compressor

4DBNR20ME

TVS026H8-A

Compressor

4DHNR22ME

TVS031H8-A

Compressor

4DJNR28ME

TVS036H8-A

Compressor

6DHNR35ME

TVS041H8-A

Compressor

6DJNR40ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 224.7 (65.9) 216.1 (63.3) 207.6 (60.8) 199.2 (58.4) 190.8 (55.9) 182.6 (53.5) 174.6 (51.2) 40 (4.4) 205.4 (60.2) 197.6 (57.9) 189.9 (55.7) 182.4 (53.5) 174.9 (51.3) 167.6 (49.1) 160.2 (46.9) 35 (1.7) 187.0 (54.8) 180.1 (52.8) 173.3 (50.8) 166.4 (48.8) 159.7 (46.8) 153.0 (44.8) 146.5 (42.9) 45 (7.2) 288.2 (84.5) 277.7 (81.4) 267.3 (78.3) 256.9 (75.3) 246.5 (72.2) 236.1 (69.2) 225.8 (66.2) 40 (4.4) 262.2 (76.8) 252.6 (74) 243.0 (71.2) 233.4 (68.4) 224.0 (65.6) 214.4 (62.8) 204.9 (60.1) 35 (1.7) 237.8 (69.7) 229.1 (67.1) 220.4 (64.6) 211.6 (62) 202.9 (59.5) 194.1 (56.9) 185.4 (54.3) 45 (7.2) 323.3 (94.7) 311.5 (91.3) 299.6 (87.8) 287.2 (84.2) 274.8 (80.5) 262.2 (76.8) 249.6 (73.2) 40 (4.4) 296.9 (87) 286.0 (83.8) 274.8 (80.5) 263.3 (77.2) 251.8 (73.8) 240.1 (70.4) 228.5 (67) 35 (1.7) 271.0 (79.4) 260.9 (76.5) 250.5 (73.4) 240.0 (70.3) 229.3 (67.2) 218.6 (64.1) 207.8 (60.9) 45 (7.2) 378.1 (110.8) 364.8 (106.9) 351.1 (102.9) 337.1 (98.8) 322.6 (94.5) 307.9 (90.2) 292.7 (85.8) 40 (4.4) 346.2 (101.5) 333.8 (97.8) 321.2 (94.1) 308.2 (90.3) 294.8 (86.4) 281.2 (82.4) 267.3 (78.3) 35 (1.7) 315.5 (92.5) 304.2 (89.2) 292.4 (85.7) 280.6 (82.2) 268.3 (78.6) 255.9 (75) 243.3 (71.3) 45 (7.2) 465.5 (136.4) 451.8 (132.4) 437.7 (128.3) 423.4 (124.1) 408.3 (119.7) 392.7 (115.1) 376.2 (110.3) 40 (4.4) 422.6 (123.9) 409.9 (120.1) 396.9 (116.3) 383.5 (112.4) 369.6 (108.3) 355.1 (104.1) 339.8 (99.6) 35 (1.7) 384.0 (112.5) 372.2 (109.1) 360.3 (105.6) 347.9 (102) 335.1 (98.2) 321.7 (94.3) 307.7 (90.2) 45 (7.2) 564.3 (165.4) 542.6 (159) 520.8 (152.6) 498.6 (146.1) 476.3 (139.6) 453.7 (133) 431.1 (126.3) 40 (4.4) 510.7 (149.7) 491.9 (144.2) 472.9 (138.6) 453.5 (132.9) 434.0 (127.2) 414.2 (121.4) 394.4 (115.6) 35 (1.7) 462.5 (135.5) 446.3 (130.8) 429.7 (125.9) 412.9 (121) 395.7 (116) 378.5 (110.9) 361.1 (105.8)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

HIGH EFFICIENCY MODELS

COPELAND

09/03/14

T40-TV-PDS-19

- 56 -

CAPACITY DATA -

R407A

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS016M8-A

Compressor

Model

3DS3R17ME

TVS023M8-A

Compressor

Model

4DBNR20ME

TVS026M8-A

Compressor

Model

4DHNR22ME

TVS031M8-A

Compressor

Model

4DJNR28ME

TVS036M8-A

Compressor

Model

6DHNR35ME

TVS041M8-A

Compressor

Model

6DJNR40ME

TVS051M8-A

Compressor

Model

6DUNR49ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 169.6 (49.7) 163.4 (47.9) 157.3 (46.1) 151.2 (44.3) 145.1 (42.5) 139.1 (40.8) 132.8 (38.9) 25 (-3.9) 153.1 (44.9) 147.6 (43.3) 142.2 (41.7) 136.7 (40.1) 131.3 (38.5) 125.8 (36.9) 120.5 (35.3) 20 (-6.7) 137.8 (40.4) 132.8 (38.9) 127.9 (37.5) 123.0 (36) 118.0 (34.6) 113.1 (33.1) 108.2 (31.7) 15 (-9.4) 123.3 (36.1) 118.9 (34.8) 114.5 (33.5) 109.9 (32.2) 105.4 (30.9) 100.9 (29.6) 96.3 (28.2) 10 (-12.2) 109.9 (32.2) 105.9 (31) 101.9 (29.8) 97.8 (28.6) 93.6 (27.4) 89.3 (26.2) 84.9 (24.9)

5 (-15) 97.5 (28.6) 93.9 (27.5) 90.1 (26.4) 86.2 (25.3) 82.2 (24.1) 78.2 (22.9) 74.0 (21.7)

0 (-17.8) 86.2 (25.3) 82.7 (24.2) 79.2 (23.2) 75.4 (22.1) 71.6 (21) 67.6 (19.8) 63.5 (18.6)

30 (-1.1) 215.3 (63.1) 207.3 (60.7) 199.3 (58.4) 191.3 (56.1) 183.4 (53.8) 175.5 (51.4) 167.3 (49) 25 (-3.9) 194.1 (56.9) 186.9 (54.8) 179.8 (52.7) 172.5 (50.6) 165.4 (48.5) 158.1 (46.3) 150.7 (44.2) 20 (-6.7) 174.6 (51.2) 168.2 (49.3) 161.7 (47.4) 155.2 (45.5) 148.7 (43.6) 142.1 (41.6) 135.6 (39.7) 15 (-9.4) 156.7 (45.9) 150.8 (44.2) 145.0 (42.5) 139.1 (40.8) 133.2 (39.1) 127.3 (37.3) 121.1 (35.5) 10 (-12.2) 140.0 (41) 134.7 (39.5) 129.6 (38) 124.3 (36.4) 119.0 (34.9) 113.6 (33.3) 108.3 (31.7)

5 (-15) 124.6 (36.5) 119.9 (35.1) 115.3 (33.8) 110.6 (32.4) 105.8 (31) 101.0 (29.6) 96.2 (28.2)

0 (-17.8) 110.4 (32.3) 106.3 (31.1) 102.2 (29.9) 97.9 (28.7) 93.7 (27.4) 89.3 (26.2) 84.8 (24.9) 30 (-1.1) 245.8 (72) 236.6 (69.3) 227.0 (66.5) 217.2 (63.7) 207.5 (60.8) 197.6 (57.9) 187.7 (55) 25 (-3.9) 221.4 (64.9) 212.9 (62.4) 204.2 (59.9) 195.4 (57.3) 186.4 (54.6) 177.5 (52) 168.4 (49.4) 20 (-6.7) 198.1 (58.1) 190.5 (55.8) 182.6 (53.5) 174.5 (51.1) 166.4 (48.8) 158.3 (46.4) 150.5 (44.1) 15 (-9.4) 176.1 (51.6) 169.3 (49.6) 162.1 (47.5) 154.9 (45.4) 147.6 (43.3) 140.5 (41.2) 133.5 (39.1) 10 (-12.2) 155.6 (45.6) 149.4 (43.8) 143.1 (41.9) 136.7 (40.1) 130.3 (38.2) 124.1 (36.4) 118.0 (34.6)

5 (-15) 136.7 (40.1) 131.3 (38.5) 125.8 (36.9) 120.2 (35.2) 114.7 (33.6) 109.3 (32) 104.2 (30.5)

0 (-17.8) 119.7 (35.1) 115.1 (33.7) 110.3 (32.3) 105.5 (30.9) 100.8 (29.5) 96.4 (28.2) 92.1 (27) 30 (-1.1) 286.2 (83.9) 275.8 (80.8) 265.1 (77.7) 254.2 (74.5) 243.1 (71.2) 231.8 (67.9) 220.6 (64.7) 25 (-3.9) 258.4 (75.7) 248.9 (72.9) 239.1 (70.1) 229.2 (67.2) 219.2 (64.3) 209.1

20 (-6.7) 231.9 (68) 223.2 (65.4) 214.5 (62.9) 205.7 (60.3) 196.8 (57.7) 187.7 (55) 178.6 (52.3) 15 (-9.4) 207.1 (60.7) 199.2 (58.4) 191.4 (56.1) 183.5 (53.8) 175.8 (51.5) 167.9 (49.2) 160.1 (46.9) 10 (-12.2) 183.6 (53.8) 176.7 (51.8) 169.8 (49.8) 163.0 (47.8) 156.2 (45.8) 149.6 (43.9) 143.0 (41.9)

5 (-15) 161.8 (47.4) 155.8 (45.7) 149.8 (43.9) 144.0 (42.2) 138.3 (40.5) 132.8 (38.9) 127.5 (37.4)

0 (-17.8) 141.8 (41.5) 136.5 (40) 131.5 (38.5) 126.6 (37.1) 122.0 (35.8) 117.7 (34.5) 113.6 (33.3) 30 (-1.1) 349.1 (102.3) 338.3 (99.1) 327.3 (95.9) 316.1 (92.6) 304.3 (89.2) 292.1 (85.6) 279.2 (81.8) 25 (-3.9) 317.4 (93) 307.5 (90.1) 297.6 (87.2) 287.4 (84.2) 276.7 (81.1) 265.7 (77.9) 253.9 (74.4) 20 (-6.7) 288.3 (84.5) 279.4 (81.9) 270.5 (79.3) 261.2 (76.6) 251.8 (73.8) 241.8 (70.9) 231.2 (67.8)

15 (-9.4) 261.2 (76.6) 253.3 (74.2) 245.4 (71.9) 237.2 (69.5) 228.8 (67.1) 220.0 (64.5) 210.6 (61.7) 10 (-12.2) 235.6 (69.1) 228.7 (67) 221.8 (65) 214.7 (62.9) 207.4 (60.8) 199.7 (58.5) 191.6 (56.2)

5 (-15) 210.7 (61.8) 204.9 (60) 199.0 (58.3) 193.0 (56.6) 186.9 (54.8) 180.4 (52.9) 173.5 (50.8)

0 (-17.8) 186.2 (54.6) 181.2 (53.1) 176.4 (51.7) 171.6 (50.3) 166.6 (48.8) 161.3 (47.3) 155.6 (45.6) 30 (-1.1) 419.2 (122.8) 405.1 (1 25 (-3.9) 380.0 (111.4) 367.7 (107.8) 355.2 (104.1) 342.3 (100.3) 329.1 (96.4) 315.7 (92.5) 302.2 (88.6) 20 (-6.7) 344.4 (100.9) 333.6 (97.8) 322.5 (94.5) 310.9 (91.1) 299.1 (87.7) 287.1 (84.1) 274.9 (80.6) 15 (-9.4) 311.6 (91.3) 301.8 (88.4) 291.7 (85.5) 281.2 (82.4) 270.4 (79.2) 259.4 (76) 248.1 (72.7) 10 (-12.2) 280.8 (82.3) 271.6 (79.6) 262.0 (76.8) 252.1 (73.9) 241.9 (70.9) 231.4 (67.8) 220.8 (64.7)

5 (-15) 251.1 (73.6) 242.0 (70.9) 232.7 (68.2) 222.9 (65.3) 212.8 (62.4) 202.5 (59.4) 192.2 (56.3)

0 (-17.8) 221.6 (64.9) 212.3 (62.2) 202.8 (59.4) 192.8 (56.5) 182.5 (53.5) 172.0 (50.4) 161.3 (47.3) 30 (-1.1) 488.4 (143.1) 472.8 (138.6) 457.4 (134) 441.9 (129.5) 426.4 (125) 410.7 (120.4) 394.6 (115.6) 25 (-3.9) 444.5 (130.3) 430.6 (126.2) 416.6 (122.1) 402.7 (118) 388.4 (113.8) 373.8 (109.5) 358.9 (105.2) 20 (-6.7) 403.0 (118.1) 390.4 (114.4) 377.8 (110.7) 365.0 (107) 351.8 (103.1) 338.1 (99.1) 323.9 (94.9) 15 (-9.4) 363.7 (106.6) 352.4 (103.3) 340.7 (99.9) 328.8 (96.3) 316.4 (92.7) 303.3 (88.9) 289.8 (84.9) 10 (-12.2) 326.7 (95.7) 316.2 (92.7) 305.2 (89.5) 293.9 (86.1) 282.0 (82.7) 269.5 (79) 256.3 (75.1)

5 (-15) 291.7 (85.5) 281.7 (82.6) 271.3 (79.5) 260.4 (76.3) 248.7 (72.9) 236.5 (69.3) 223.2 (65.4)

0 (-17.8) 258.6 (75.8) 249.1 (73) 238.9 (70) 228.1 (66.8) 216.4 (63.4) 203.9 (59.8) 190.6 (55.9)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 11 0 (43.3) 115 (46.1)

CAPACITY MBH (KW)

18.7) 390.7 (114.5) 376.0 (110.2) 361.1 (105.8) 345.9 (101.4) 330.5 (96.9)

R407A

AMBIENT TEMPERATURE °F (°C)

(61.3) 198.6 (58.2)

HIGH EFFICIENCY MODELS

COPELAND

09/03/14

T40-TV-PDS-19

- 57 -

CAPACITY DATA -

R407A

LOW TEMP. HIGH EFFICIENCY MODELS

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS011L8-A

Compressor

Model

3DS3F46KE

HIGH EFFICIENCY MODELS

TVS016L8-A

Compressor

Model

4DHNF63KE

TVS023L8-A

Compressor

Model

4DJNF76KE

TVS028L8-A

Compressor

Model

6DHNF93KE

TVS031L8-A

Compressor

Model

6DJNF11ME

TVS041L8-A

Compressor

Model

6DUNF13ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 82.1 (24.1) 79.1 (23.2) 75.9 (22.2) 72.8 (21.3) 69.5 (20.4) 66.2 (19.4) --- ---

-5 (-20.6) 72.8 (21.3) 69.8 (20.5) 67.0 (19.6) 63.9 (18.7) 60.9 (17.8) 57.9 (17) --- ---

-10 (-23.3) 64.2 (18.8) 61.4 (18) 58.8 (17.2) 56.0 (16.4) 53.1 (15.6) 50.3 (14.7) 47.4 (13.9)

-15 (-26.1) 56.3 (16.5) 53.8 (15.8) 51.2 (15) 48.7 (14.3) 46.1 (13.5) 43.4 (12.7) 40.6 (11.9)

-20 (-28.9) 49.0 (14.4) 46.7 (13.7) 44.4 (13) 42.0 (12.3) 39.6 (11.6) 37.1 (10.9) 34.7 (10.2)

-25 (-31.7) 42.3 (12.4) 40.1 (11.8) 38.0 (11.1) 35.8 (10.5) 33.6 (9.8) 31.3 (9.2) 29.0 (8.5)

-30 (-34.4) 36.0 (10.6) 34.0 (10) 32.0 (9.4) 29.9 (8.8) 27.9 (8.2) 25.9 (7.6) 23.8 (7)

-35 (-37.2) 29.9 (8.8) 28.0 (8.2) 26.3 (7.7) 24.5 (7.2) 22.6 (6.6) 20.8 (6.1) 18.9 (5.5)

-40 (-40) 24.0 (7) 22.4 (6.6) 20.7 (6.1) 19.0 (5.6) 17.4 (5.1) 15.8 (4.6) 14.2 (4.2) 0 (-17.8) 115.2 (33.8) 110.6 (32.4) 105.8 (31) 101.1 (29.6) 96.5 (28.3) 91.8 (26.9) 87.0 (25.5)

-5 (-20.6) 102.7 (30.1) 98.6 (28.9) 94.4 (27.7) 90.1 (26.4) 85.9 (25.2) 81.6 (23.9) 77.3 (22.6)

-10 (-23.3) 91.0 (26.7) 87.4 (25.6) 83.6 (24.5) 79.7 (23.4) 75.9 (22.2) 72.0 (21.1) 68.1 (20)

-15 (-26.1) 80.1 (23.5) 76.8 (22.5) 73.4 (21.5) 69.9 (20.5) 66.5 (19.5) 62.9 (18.4) 59.3 (17.4)

-20 (-28.9) 69.9 (20.5) 66.9 (19.6) 63.8 (18.7) 60.7 (17.8) 57.5 (16.9) 54.4 (15.9) 51.1 (15)

-25 (-31.7) 60.4 (17.7) 57.8 (16.9) 55.0 (16.1) 52.2 (15.3) 49.2 (14.4) 46.4 (13.6) 43.4 (12.7)

-30 (-34.4) 51.7 (15.1) 49.2 (14.4) 46.8 (13.7) 44.2 (13) 41.6 (12.2) 38.9 (11.4) 36.2 (10.6)

-35 (-37.2) 43.7 (12.8) 41.6 (12.2) 39.3 (11.5) 36.9 (10.8) 34.4 (10.1) 32.0 (9.4) 29.4 (8.6)

-40 (-40) 36.5 (10.7) 34.5 (10.1) 32.4 (9.5) 30.2 (8.9) 27.9 (8.2) 25.6 (7.5) 23.2 (6.8) 0 (-17.8) 143.9 (42.2) 138.3 (40.5) 132.6 (38.9) 126.8 (37.2) 121.0 (35.4) 115.0 (33.7) --- ---

-5 (-20.6) 127.3 (37.3) 122.1 (35.8) 116.8 (34.2) 111 .4 (32.6) 105.9 (31) 100.4 (29.4) --- ---

-10 (-23.3) 111.8 (32.8) 107.1 (31.4) 102.2 (29.9) 97.2 (28.5) 92.2 (27) 87.0 (25.5) 81.8 (24)

-15 (-26.1) 97.7 (28.6) 93.3 (27.4) 88.8 (26) 84.4 (24.7) 79.8 (23.4) 75.1 (22) 70.2 (20.6)

-20 (-28.9) 84.7 (24.8) 80.9 (23.7) 76.9 (22.5) 72.9 (21.4) 68.7 (20.1) 64.5 (18.9) 60.2 (17.6)

-25 (-31.7) 73.1 (21.4) 69.7 (20.4) 66.3 (19.4) 62.7 (18.4) 59.1 (17.3) 55.3 (16.2) 51.6 (15.1)

-30 (-34.4) 62.9 (18.4) 60.1 (17.6) 57.0 (16.7) 54.1 (15.8) 50.9 (14.9) 47.7 (14) 44.4 (13)

-35 (-37.2) 54.2 (15.9) 51.8 (15.2) 49.4 (14.5) 46.9 (13.8) 44.3 (13) 41.7 (12.2) 38.9 (11.4)

-40 (-40) 46.9 (13.8) 45.2 (13.2) 43.3 (12.7) 41.4 (12.1) 39.4 (11.5) 37.3 (10.9) 35.1 (10.3) 0 (-17.8) 172.4 (50.5) 166.0 (48.7) 159.1 (46.6) 151.9 (44.5) 144.3 (42.3) 136.3 (39.9) --- ---

-5 (-20.6) 150.0 (44) 144.3 (42.3) 138.2 (40.5) 131.8 (38.6) 125.0 (36.6) 1

-10 (-23.3) 130.9 (38.4) 125.8 (36.9) 120.3 (35.3) 114.6 (33.6) 108.4 (31.8) 101.9 (29.8) 95.0 (27.8)

-15 (-26.1) 114.6 (33.6) 109.9 (32.2) 105.0 (30.8) 99.6 (29.2) 94.1 (27.6) 88.1 (25.8) 81.9 (24)

-20 (-28.9) 100.4 (29.4) 96.1 (28.2) 91.5 (26.8) 86.6 (25.4) 81.4 (23.8) 75.9 (22.2) 70.1 (20.6)

-25 (-31.7) 87.6 (25.7) 83.5 (24.5) 79.2 (23.2) 74.6 (21.8) 69.7 (20.4) 64.7 (19) 59.3 (17.4)

-30 (-34.4) 75.6 (22.2) 71.6 (21) 67.4 (19.8) 63.1 (18.5) 58.5 (17.1) 53.6 (15.7) 48.5 (14.2)

-35 (-37.2) 63.7 (18.7) 59.7 (17.5) 55.7 (16.3) 51.3 (15) 46.8 (13.7) 42.1 (12.3) 37.2 (10.9)

-40 (-40) 51.3 (15) 47.3 (13.8) 43.1 (12.6) 38.7 (11.4) 34.2 (10) 29.5 (8.6) 24.8 (7.3) 0 (-17.8) 200.7 (58.8) 192.9 (56.5) 184.9 (54.2) 176.7 (51.8) 168.2 (49.3) --- --- --- ---

-5 (-20.6) 177.9 (52.1) 170.8 (50.1) 163.6 (47.9) 156.0 (45.7) 148.2 (43.4) 140.0 (41) --- ---

-10 (-23.3) 157.1 (46) 150.7 (44.2) 144.1 (42.2) 137.1 (40.2) 129.8 (38) 122.2 (35.8) --- ---

-15 (-26.1) 138.0 (40.4) 132.2 (38.7) 126.0 (36.9) 119.6 (35) 112.9 (33.1) 105.7 (31) --- ---

-20 (-28.9) 120.3 (35.3) 115.0 (33.7) 109.3 (32) 103.3 (30.3) 97.0 (28.4) 90.4 (26.5) 83.3 (24.4)

-25 (-31.7) 103.7 (30.4) 98.8 (29) 93.6 (27.4) 88.0 (25.8) 82.0 (24) 75.7 (22.2) 69.0 (20.2)

-30 (-34.4) 88.0 (25.8) 83.4 (24.4) 78.4 (23) 73.2 (21.4) 67.6 (19.8) 61.5 (18) 55.0 (16.1)

-35 (-37.2) 72.8 (21.3) 68.5 (20.1) 63.7 (18.7) 58.7 (17.2) 53.3 (15.6) 47.5 (13.9) 41.3 (12.1)

-40 (-40) 57.9 (17) 53.7 (15.7) 49.1 (14.4) 44.3 (13) 39.1 (11.4) 33.3 (9.8) 27.2 (8) 0 (-17.8) 230.7 (67.6) 222.8 (65.3) 214.9 (63) 206.9 (60.6) 198.8 (58.3) 190.6 (55.9) --- ---

-5 (-20.6) 207.2 (60.7) 199.9 (58.6) 192.7 (56.5) 185.3 (54.3) 177.8 (52.1) 170.0 (49.8) --- ---

-10 (-23.3) 184.3 (54) 177.7 (52.1) 170.9 (50.1) 164.0 (48.1) 156.9 (46) 149.5 (43.8) --- ---

-15 (-26.1) 162.1 (47.5) 156.0 (45.7) 149.7 (43.9) 143.3 (42) 136.6 (40) 129.5 (37.9) 122.1 (35.8)

-20 (-28.9) 141.1 (41.4) 135.5 (39.7) 129.6 (38) 123.5 (36.2) 117.0 (34.3) 110.1 (32.3) 102.9 (30.2)

-25 (-31.7) 121.5 (35.6) 1

-30 (-34.4) 103.5 (30.3) 98.5 (28.9) 93.1 (27.3) 87.4 (25.6) 81.2 (23.8) 74.6 (21.8) 67.5 (19.8)

-35 (-37.2) 87.6 (25.7) 82.6 (24.2) 77.4 (22.7) 71.6 (21) 65.5 (19.2) 58.9 (17.3) 51.7 (15.1)

-40 (-40) 73.7 (21.6) 68.9 (20.2) 63.5 (18.6) 57.9 (17) 51.7 (15.1) 44.8 (13.1) 37.6 (11)

CAPACITY MBH (KW)

16.1 (34) 110.6 (32.4) 104.7 (30.7) 98.5 (28.9) 91.8 (26.9) 84.6 (24.8)

R407A

AMBIENT TEMPERATURE °F (°C)

17.7 (34.5) --- ---

COPELAND

09/03/14

T40-TV-PDS-19

- 58 -

CAPACITY DATA -

R407C

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS016H8-A

Compressor

Model

3DS3R17ME

TVS023H8-A

Compressor

Model

4DBNR20ME

HIGH EFFICIENCY MODELS

TVS026H8-A

Compressor

Model

4DHNR22ME

TVS031H8-A

Compressor

Model

4DJNR28ME

TVS036H8-A

Compressor

Model

6DHNR35ME

TVS041H8-A

Compressor

Model

6DJNR40ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 258.2 (75.7) 248.4 (72.8) 238.9 (70) 229.7 (67.3) 220.8 (64.7) 212.1 (62.2) 203.7 (59.7) 50 (10) 237.0 (69.5) 228.3 (66.9) 219.8 (64.4) 211.5 (62) 203.5 (59.6) 195.7 (57.4) 188.1 (55.1) 45 (7.2) 216.8 (63.5) 209.1 (61.3) 201.5 (59.1) 194.1 (56.9) 187.0 (54.8) 180.1 (52.8) 173.1 (50.7) 40 (4.4) 197.7 (57.9) 190.8 (55.9) 184.2 (54) 177.7 (52.1) 171.3 (50.2) 165.1 (48.4) 158.9 (46.6) 35 (1.7) 179.7 (52.7) 173.6 (50.9) 167.7 (49.1) 162.0 (47.5) 156.3 (45.8) 150.7 (44.2) 145.1 (42.5) 55 (12.8) 331.2 (97.1) 319.3 (93.6) 307.4 (90.1) 295.6 (86.6) 283.8 (83.2) 272.2 (79.8) --- --50 (10) 302.0 (88.5) 290.7 (85.2) 279.6 (81.9) 268.5 (78.7) 257.5 (75.5) 246.5 (72.3) 235.7 (69.1) 45 (7.2) 275.0 (80.6) 264.5 (77.5) 254.1 (74.5) 243.7 (71.4) 233.4 (68.4) 223.2 (65.4) 213.3 (62.5) 40 (4.4) 250.0 (73.3) 240.2 (70.4) 230.6 (67.6) 220.9 (64.7) 211.5 (62) 202.0 (59.2) 192.8 (56.5) 35 (1.7) 226.8 (66.5) 217.8 (63.8) 208.8 (61.2) 199.9 (58.6) 191.2 (56) 182.6 (53.5) 174.2 (51.1) 55 (12.8) 394.2 (115.5) 373.6 (109.5) 353.4 (103.6) 333.6 (97.8) 314.3 (92.1) 295.5 (86.6) 277.3 (81.3) 50 (10) 359.9 (105.5) 341.5 (100.1) 323.4 (94.8) 305.8 (89.6) 288.5 (84.6) 271.8 (79.7) 255.8 (75) 45 (7.2) 327.1 (95.9) 310.7 (91.1) 294.7 (86.4) 279.1 (81.8) 264.0 (77.4) 249.3 (73.1) 235.3 (69) 40 (4.4) 295.8 (86.7) 281.5 (82.5) 267.5 (78.4) 253.8 (74.4) 240.6 (70.5) 227.9 (66.8) 215.8 (63.2) 35 (1.7) 266.4 (78.1) 253.9 (74.4) 241.8 (70.9) 230.0 (67.4) 218.5 (64) 207.5 (60.8) 197.1 (57.8) 55 (12.8) 467.8 (137.1) 443.8 (130.1) 420.4 (123.2) 397.5 (116.5) 375.1 (109.9) 353.1 (103.5) 331.8 (97.2) 50 (10) 424.3 (124.4) 402.9 (118.1) 382.0 (111.9) 361.6 (106) 341.8 (100.2) 322.5 (94.5) 303.7 (89) 45 (7.2) 383.5 (112.4) 364.6 (106.8) 346.2 (101.5) 328.2 (96.2) 310.9 (91.1) 294.0 (86.2) 277.7 (81.4) 40 (4.4) 345.5 (101.2) 329.0 (96.4) 312.9 (91.7) 297.4 (87.1) 282.3 (82.7) 267.8 (78.5) 253.8 (74.4) 35 (1.7) 310.2 (90.9) 296.0 (86.7) 282.1 (82.7) 268.8 (78.8) 256.0 (75) 243.6 (71.4) 231.7 (67.9) 55 (12.8) 576.7 (169) 554.3 (162.4) 531.8 (155.9) 509.3 (149.2) 486.7 (142.6) 463.9 (136) 441.1 (129.3) 50 (10) 516.0 (151.2) 496.2 (145.4) 476.4 (139.6) 456.4 (133.8) 436.4 (127.9) 416.2 (122) 395.9 (116) 45 (7.2) 461.3 (135.2) 443.9 (130.1) 426.5 (125) 409.0 (119.9) 391.3 (114.7) 373.5 (109.5) 355.4 (104.2) 40 (4.4) 412.1 (120.8) 397.1 (116.4) 381.9 (1 35 (1.7) 368.2 (107.9) 355.3 (104.1) 342.2 (100.3) 328.9 (96.4) 315.4 (92.4) 301.8 (88.4) 287.8 (84.3) 55 (12.8) 803.6 (235.5) 770.1 (225.7) 734.1 (215.1) 695.8 (203.9) 655.5 (192.1) 613.4 (179.8) 569.8 (167) 50 (10) 705.1 (206.6) 675.4 (197.9) 643.0 (188.4) 608.5 (178.3) 572.0 (167.6) 533.9 (156.5) 494.3 (144.9) 45 (7.2) 617.7 (181) 591.4 (173.3) 562.6 (164.9) 531.6 (155.8) 498.9 (146.2) 464.5 (136.1) 428.8 (125.7) 40 (4.4) 541.5 (158.7) 518.1 (151.8) 492.5 (144.3) 464.7 (136.2) 435.4 (127.6) 404.8 (118.6) 373.0 (109.3) 35 (1.7) 475.5 (139.4) 454.9 (133.3) 432.1 (126.6) 407.5 (119.4) 381.5 (111.8) 354.3 (103.8) 326.1 (95.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

11.9) 366.6 (107.4) 351.1 (102.9) 335.5 (98.3) 319.6 (93.7)

R407C

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 59 -

CAPACITY DATA -

R407C

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS016M8-A

Compressor

Model

3DS3R17ME

TVS023M8-A

Compressor

Model

4DBNR20ME

TVS026M8-A

Compressor

Model

4DHNR22ME

TVS031M8-A

Compressor

Model

4DJNR28ME

TVS036M8-A

Compressor

Model

6DHNR35ME

TVS041M8-A

Compressor

Model

6DJNR40ME

TVS051M8-A

Compressor

Model

6DUNR49ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 162.8 (47.7) 157.4 (46.1) 152.3 (44.6) 147.2 (43.1) 142.1 (41.6) 137.0 (40.2) 131.9 (38.7) 25 (-3.9) 146.8 (43) 142.2 (41.7) 137.7 (40.3) 133.1 (39) 128.6 (37.7) 124.0 (36.3) 119.2 (34.9) 20 (-6.7) 132.1 (38.7) 128.0 (37.5) 124.0 (36.3) 119.9 (35.1) 115.8 (33.9) 111.5 (32.7) 107.0 (31.4) 15 (-9.4) 118.3 (34.7) 114.8 (33.6) 111.2 (32.6) 107.5 (31.5) 103.6 (30.4) 99.5 (29.2) 95.2 (27.9) 10 (-12.2) 105.6 (31) 102.5 (30) 99.2 (29.1) 95.8 (28.1) 92.1 (27) 88.2 (25.8) 83.9 (24.6) 30 (-1.1) 205.2 (60.1) 196.9 (57.7) 188.7 (55.3) 180.5 (52.9) 172.6 (50.6) 164.7 (48.3) 157.2 (46.1) 25 (-3.9) 184.8 (54.2) 177.2 (51.9) 169.8 (49.8) 162.4 (47.6) 155.2 (45.5) 148.3 (43.5) 141.4 (41.5) 20 (-6.7) 165.5 (48.5) 158.7 (46.5) 151.9 (44.5) 145.3 (42.6) 138.9 (40.7) 132.7 (38.9) 126.7 (37.1) 15 (-9.4) 147.0 (43.1) 140.8 (41.3) 134.8 (39.5) 129.0 (37.8) 123.4 (36.2) 118.0 (34.6) 112.9 (33.1) 10 (-12.2) 128.9 (37.8) 123.6 (36.2) 118.3 (34.7) 113.3 (33.2) 108.5 (31.8) 103.8 (30.4) 99.5 (29.2) 30 (-1.1) 238.8 (70) 228.1 (66.8) 217.7 (63.8) 207.5 (60.8) 197.6 (57.9) 188.3 (55.2) 179.4 (52.6) 25 (-3.9) 213.0 (62.4) 204.0 (59.8) 195.1 (57.2) 186.4 (54.6) 178.1 (52.2) 170.1 (49.9) 162.6 (47.7) 20 (-6.7) 189.4 (55.5) 181.8 (53.3) 174.2 (51.1) 166.8 (48.9) 159.7 (46.8) 153.0 (44.8) 146.7 (43) 15 (-9.4) 167.8 (49.2) 161.4 (47.3) 155.0 (45.4) 148.7 (43.6) 142.6 (41.8) 136.8 (40.1) 131.5 (38.5) 10 (-12.2) 148.4 (43.5) 142.9 (41.9) 137.4 (40.3) 132.0 (38.7) 126.7 (37.1) 121.7 (35.7) 117.0 (34.3) 30 (-1.1) 277.8 (81.4) 265.7 (77.9) 254.0 (74.4) 242.7 (71.1) 231.7 (67.9) 221.3 (64.9) 211.4 (61.9) 25 (-3.9) 248.2 (72.7) 237.9 (69.7) 228.1 (66.8) 218.5 (64) 209.5 (61.4) 200.8 (58.8) 192.5 (56.4) 20 (-6.7) 221.3 (64.9) 212.7 (62.3) 204.4 (59.9) 196.5 (57.6) 188.9 (55.4) 181.7 (53.2) 174.7 (51.2) 15 (-9.4) 197.0 (57.7) 189.7 (55.6) 182.8 (53.6) 176.2 (51.6) 169.8 (49.8) 163.7 (48) 158.0 (46.3) 10 (-12.2) 174.9 (51.3) 168.8 (49.5) 163.0 (47.8) 157.3 (46.1) 151.9 (44.5) 146.8 (43) 142.0 (41.6) 30 (-1.1) 329.3 (96.5) 318.2 (93.2) 306.9 (89.9) 295.4 (86.6) 283.7 (83.1) 271.7 (79.6) 259.5 (76) 25 (-3.9) 294.6 (86.3) 285.2 (83.6) 275.5 (80.7) 265.5 (77.8) 255.4 (74.8) 244.9 (71.8) 234.0 (68.6) 20 (-6.7) 263.9 (77.3) 255.8 (75) 247.4 (72.5) 238.8 15 (-9.4) 236.4 (69.3) 229.3 (67.2) 222.0 (65.1) 214.3 (62.8) 206.3 (60.5) 198.0 (58) 189.3 (55.5) 10 (-12.2) 211.5 (62) 205.2 (60.1) 198.7 (58.2) 191.7 (56.2) 184.4 (54) 176.7 (51.8) 168.6 (49.4) 30 (-1.1) 419.2 (122.8) 400.8 (117.5) 380.6 (1 25 (-3.9) 371.2 (108.8) 354.8 (104) 336.9 (98.7) 317.8 (93.1) 297.8 (87.3) 277.2 (81.2) 256.4 (75.1) 20 (-6.7) 330.2 (96.8) 315.6 (92.5) 299.8 (87.9) 283.2 (83) 266.0 (77.9) 248.6 (72.9) 231.3 (67.8) 15 (-9.4) 294.8 (86.4) 281.8 (82.6) 268.0 (78.5) 253.7 (74.3) 239.2 (70.1) 225.0 (65.9) 211.4 (61.9) 10 (-12.2) 263.4 (77.2) 251.8 (73.8) 239.7 (70.3) 227.7 (66.7) 216.0 (63.3) 205.0 (60.1) 195.0 (57.1) 30 (-1.1) 489.6 (143.5) 466.8 (136.8) 442.9 (129.8) 418.1 (122.5) 392.7 (115.1) 367.0 (107.5) 341.3 (100) 25 (-3.9) 434.2 (127.2) 413.5 (121.2) 392.0 (114.9) 369.9 (108.4) 347.4 (101.8) 325.0 (95.2) 302.8 (88.7) 20 (-6.7) 384.0 (112.5) 365.4 (107.1) 346.3 (101.5) 326.9 (95.8) 307.4 (90.1) 288.3 (84.5) 269.9 (79.1) 15 (-9.4) 338.9 (99.3) 322.5 (94.5) 305.7 (89.6) 289.1 (84.7) 272.7 (79.9) 257.0 (75.3) 242.4 (71.1) 10 (-12.2) 298.7 (87.5) 284.3 (83.3) 270.1 (79.1) 256.2 (75.1) 243.2 (71.3) 231.2 (67.8) 220.7 (64.7)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 11 0 (43.3) 115 (46.1)

CAPACITY MBH (KW)

11.5) 358.8 (105.1) 335.9 (98.4) 312.1 (91.5) 287.6 (84.3)

R407C

AMBIENT TEMPERATURE °F (°C)

(70) 229.7 (67.3) 220.5 (64.6) 210.8 (61.8)

HIGH EFFICIENCY MODELS

COPELAND

CONDENSING

TVS016H8-A

3DS3R17ME

TVS023H8-A

4DBNR20ME

TVS026H8-A

4DHNR22ME

TVS031H8-A

4DJNR28ME

TVS036H8-A

6DHNR35ME

TVS041H8-A

6DJNR40ME

UNIT

MODEL

Compressor

CAPACITY DATA -

R404A

R507

60HzTVS-A

HIGH TEMP. HIGH EFFICIENCY MODELS

SATURATED

SUCTION

TEMPERATURE

° F ° C 45 (7.2) 231.5 (67.8) 221.6 (64.9) 211.7 (62) 202.0 (59.2) 192.4 (56.4) 182.9 (53.6) 173.5 (50.8) 40 (4.4) 212.9 (62.4) 203.8 (59.7) 194.8 (57.1) 185.9 (54.5) 177.2 (51.9) 168.5 (49.4) 159.9 (46.9) 35 (1.7) 195.3 (57.2) 187.0 (54.8) 178.8 (52.4) 170.7 (50) 162.7 (47.7) 154.8 (45.4) 147.0 (43.1) 45 (7.2) 279.7 (82) 267.5 (78.4) 255.6 (74.9) 244.0 (71.5) 232.7 (68.2) 221.6 (64.9) 210.8 (61.8) 40 (4.4) 260.5 (76.3) 249.1 (73) 238.0 (69.8) 227.2 (66.6) 216.7 (63.5) 206.4 (60.5) 196.3 (57.5) 35 (1.7) 241.3 (70.7) 230.7 (67.6) 220.4 (64.6) 210.4 (61.7) 200.6 (58.8) 191.0 (56) 181.7 (53.3) 45 (7.2) 310.7 (91.1) 297.1 (87.1) 283.9 (83.2) 271.1 (79.5) 258.7 (75.8) 246.6 (72.3) 234.7 (68.8) 40 (4.4) 288.9 (84.7) 276.3 (81) 264.0 (77.4) 252.1 (73.9) 240.5 (70.5) 229.2 (67.2) 218.2 (63.9) 35 (1.7) 267.2 (78.3) 255.5 (74.9) 244.1 (71.5) 233.0 (68.3) 222.3 (65.1) 211.8 (62.1) 201.6 (59.1) 45 (7.2) 381.3 (111.7) 365.0 (107) 348.9 (102.3) 332.9 (97.6) 317.0 (92.9) 301.1 (88.2) 285.3 (83.6) 40 (4.4) 351.3 (103) 336.2 (98.5) 321.3 (94.2) 306.5 (89.8) 291.8 (85.5) 277.1 (81.2) 262.5 (76.9) 35 (1.7) 322.5 (94.5) 308.6 (90.4) 294.9 (86.4) 281.3 (82.4) 267.7 (78.5) 254.3 (74.5) 240.8 (70.6) 45 (7.2) 487.6 (142.9) 467.3 (137) 447.0 (131) 426.7 (125.1) 406.2 (119) 385.7 (113) 365.1 (107) 40 (4.4) 447.0 (131) 428.5 (125.6) 409.9 (120.1) 391.3 (114.7) 372.6 (109.2) 353.8 (103.7) 335.0 (98.2) 35 (1.7) 408.7 (119.8) 391.8 (114.8) 374.9 (109.9) 357.9 (104.9) 340.9 (99.9) 323.7 (94.9) 306.6 (89.9) 45 (7.2) 551.9 (161.7) 529.9 (155.3) 508.0 (148.9) 486.1 (142.5) 464.0 (136) 441.8 (129.5) 419.2 (122.9) 40 (4.4) 509.9 (149.4) 489.5 (143.5) 469.2 (137.5) 448.9 (131.6) 428.6 (125.6) 408.1 (119.6) 387.3 (113.5) 35 (1.7) 469.5 (137.6) 450.7 (132.1) 432.0 (126.6) 413.3 (121.1) 394.5 (115.6) 375.6 (110.1) 356.5 (104.5)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 60 -

CAPACITY DATA -

R404A

R507

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS016M8-A

Compressor

Model

3DS3R17ME

TVS023M8-A

HIGH EFFICIENCY MODELS

Compressor

Model

4DBNR20ME

TVS026M8-A

Compressor

Model

4DHNR22ME

TVS031M8-A

Compressor

Model

4DJNR28ME

TVS036M8-A

Compressor

Model

6DHNR35ME

TVS041M8-A

Compressor

Model

6DJNR40ME

TVS051M8-A

Compressor

Model

6DUNR49ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 30 (-1.1) 178.5 (52.3) 171.0 (50.1) 163.6 (47.9) 156.3 (45.8) 149.1 (43.7) 141.9 (41.6) 134.9 (39.5) 25 (-3.9) 162.7 (47.7) 156.0 (45.7) 149.3 (43.8) 142.7 (41.8) 136.2 (39.9) 129.7 (38) 123.4 (36.2) 20 (-6.7) 147.8 (43.3) 141.8 (41.6) 135.8 (39.8) 129.9 (38.1) 124.0 (36.3) 118.3 (34.7) 112.6 (33) 15 (-9.4) 133.9 (39.2) 128.5 (37.7) 123.1 (36.1) 117.8 (34.5) 112.6 (33) 107.5 (31.5) 102.4 (30) 10 (-12.2) 120.9 (35.4) 116.0 (34) 111.3 (32.6) 106.6 (31.2) 101.9 (29.9) 97.3 (28.5) 92.8 (27.2)

5 (-15) 108.8 (31.9) 104.5 (30.6) 100.2 (29.4) 96.0 (28.1) 91.9 (26.9) 87.8 (25.7) 83.8 (24.6)

0 (-17.8) 97.5 (28.6) 93.7 (27.5) 89.9 (26.3) 86.2 (25.3) 82.5 (24.2) 78.9 (23.1) 75.3 (22.1) 30 (-1.1) 222.3 (65.1) 212.5 (62.3) 202.9 (59.5) 193.7 (56.8) 184.6 (54.1) 175.8 (51.5) 167.1 (49) 25 (-3.9) 203.5 (59.6) 194.5 (57) 185.8 (54.5) 177.2 (51.9) 168.9 (49.5) 160.7 (47.1) 152.7 (44.8) 20 (-6.7) 185.3 (54.3) 177.1 (51.9) 169.0 (49.5) 161.2 (47.2) 153.5 (45) 146.1 (42.8) 138.7 (40.6) 15 (-9.4) 167.8 (49.2) 160.3 (47) 152.9 (44.8) 145.8 (42.7) 138.8 (40.7) 132.0 (38.7) 125.3 (36.7) 10 (-12.2) 151.1 (44.3) 144.3 (42.3) 137.7 (40.4) 131.3 (38.5) 124.9 (36.6) 118.7 (34.8) 112.6 (33)

5 (-15) 135.5 (39.7) 129.4 (37.9) 123.5 (36.2) 117.7 (34.5) 112.0 (32.8) 106.4 (31.2) 100.9 (29.6)

0 (-17.8) 121.2 (35.5) 115.8 (33.9) 110.5 (32.4) 105.4 (30.9) 100.3 (29.4) 95.2 (27.9) 90.3 (26.5) 30 (-1.1) 245.7 (72) 234.9 (68.8) 224.4 (65.8) 214.2 (62.8) 204.2 (59.8) 194.6 (57) 185.1 (54.2) 25 (-3.9) 224.7 (65.9) 214.7 (62.9) 205.0 (60.1) 195.7 (57.4) 186.5 (54.7) 177.6 (52) 168.9 (49.5) 20 (-6.7) 204.2 (59.8) 195.1 (57.2) 186.3 (54.6) 177.7 (52.1) 169.4 (49.6) 161.2 (47.2) 153.2 (44.9) 15 (-9.4) 184.5 (54.1) 176.2 (51.6) 168.2 (49.3) 160.5 (47) 152.9 (44.8) 145.5 (42.6) 138.2 (40.5) 10 (-12.2) 165.8 (48.6) 158.4 (46.4) 151.2 (44.3) 144.2 (42.3) 137.4 (40.3) 130.7 (38.3) 124.1 (36.4)

5 (-15) 148.4 (43.5) 141.8 (41.6) 135.4 (39.7) 129.2 (37.9) 123.1 (36.1) 117.0 (34.3) 111.0 (32.5)

0 (-17.8) 132.3 (38.8) 126.5 (37.1) 120.9 (35.4) 115.4 (33.8) 110.1 (32.3) 104.7 (30.7) 99.3 (29.1) 30 (-1.1) 295.0 (86.5) 282.2 (82.7) 269.6 (79) 257.2 (75.4) 244.8 (71.7) 232.5 (68.1) 220.2 (64.5) 25 (-3.9) 268.7 (78.7) 257.1 (75.3) 245.6 (72) 234.2 (68.6) 223.0 (65.4) 211.8 20 (-6.7) 243.8 (71.5) 233.2 (68.3) 222.8 (65.3) 212.5 (62.3) 202.3 (59.3) 192.2 (56.3) 182.1 (53.4) 15 (-9.4) 220.2 (64.5) 210.7 (61.7) 201.3 (59) 192.0 (56.3) 182.8 (53.6) 173.7 (50.9) 164.7 (48.3) 10 (-12.2) 198.0 (58) 189.4 (55.5) 181.0 (53) 172.7 (50.6) 164.5 (48.2) 156.4 (45.8) 148.3 (43.5)

5 (-15) 177.2 (51.9) 169.6 (49.7) 162.1 (47.5) 154.7 (45.3) 147.4 (43.2) 140.3 (41.1) 133.1 (39)

0 (-17.8) 157.9 (46.3) 151.1 (44.3) 144.4 (42.3) 137.9 (40.4) 131.6 (38.6) 125.3 (36.7) 119.0 (34.9) 30 (-1.1) 372.6 (109.2) 357.3 (104.7) 341.9 (100.2) 326.4 (95.7) 311.0 (91.1) 295.4 (86.6) 279.8 (82) 25 (-3.9) 338.7 (99.3) 324.8 (95.2) 310.9 (91.1) 296.9 (87) 282.9 (82.9) 268.8 (78.8) 254.7 (74.6) 20 (-6.7) 307.1 (90) 294.5 (86.3) 281.9 (82.6) 269.2 (78.9) 256.5 (75.2) 243.8 (71.5) 231.1 (67.7) 15 (-9.4) 277.6 (81.4) 266.2 (78) 254.8 (74.7) 243.4 (71.3) 231.9 (68) 220.5 (64.6) 209.0 (61.3) 10 (-12.2) 250.2 (73.3) 239.9 (70.3) 229.6 (67.3) 219.3 (64.3) 208.9 (61.2) 198.6 (58.2) 188.3 (55.2)

5 (-15) 224.9 (65.9) 215.6 (63.2) 206.2 (60.4) 196.8 (57.7) 187.5 (55) 178.2 (52.2) 168.9 (49.5)

0 (-17.8) 201.7 (59.1) 193.1 (56.6) 184.5 (54.1) 176.0 (51.6) 167.6 (49.1) 159.1 (46.6) 150.7 (44.2) 30 (-1.1) 430.8 (126.3) 413.5 (121.2) 396.2 (1 25 (-3.9) 393.9 (115.4) 377.9 (110.8) 362.2 (106.1) 346.5 (101.5) 330.8 (96.9) 315.0 (92.3) 299.0 (87.6) 20 (-6.7) 358.8 (105.2) 344.2 (100.9) 329.8 (96.7) 315.4 (92.4) 301.2 (88.3) 286.8 (84.1) 272.3 (79.8) 15 (-9.4) 325.7 (95.5) 312.3 (91.5) 299.1 (87.7) 286.1 (83.8) 273.2 (80.1) 260.2 (76.3) 247.0 (72.4) 10 (-12.2) 294.6 (86.3) 282.3 (82.7) 270.3 (79.2) 258.5 (75.8) 246.8 (72.3) 235.1 (68.9) 223.2 (65.4)

5 (-15) 265.4 (77.8) 254.2 (74.5) 243.3 (71.3) 232.6 (68.2) 222.1 (65.1) 211.6 (62) 201.0 (58.9)

0 (-17.8) 238.4 (69.9) 228.1 (66.8) 218.2 (63.9) 208.6 (61.1) 199.1 (58.4) 189.7 (55.6) 180.2 (52.8) 30 (-1.1) 506.6 (148.5) 487.3 (142.8) 467.7 (137.1) 447.9 (131.3) 427.9 (125.4) 407.8 (119.5) 387.5 (113.6) 25 (-3.9) 464.2 (136) 446.5 (130.9) 428.4 (125.6) 410.2 (120.2) 391.8 (114.8) 373.2 (109.4) 354.5 (103.9) 20 (-6.7) 423.2 (124) 406.9 (119.3) 390.3 (114.4) 373.6 (109.5) 356.6 (104.5) 339.5 (99.5) 322.3 (94.5) 15 (-9.4) 383.9 (112.5) 369.0 (108.1) 353.8 (103.7) 338.5 (99.2) 322.9 (94.6) 307.3 (90.1) 291.5 (85.4) 10 (-12.2) 346.8 (101.6) 333.3 (97.7) 319.4 (93.6) 305.4 (89.5) 291.2 (85.3) 276.9 (81.2) 262.5 (76.9)

5 (-15) 312.6 (91.6) 300.2 (88) 287.6 (84.3) 274.8 (80.5) 261.9 (76.8) 248.8 (72.9) 235.7 (69.1)

0 (-17.8) 281.6 (82.5) 270.3 (79.2) 258.9 (75.9) 247.2 (72.4) 235.5 (69) 223.6 (65.5) 211.7 (62)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 11 0 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A R507

16.1) 379.1 (111.1) 361.9 (106.1) 344.6 (101) 327.1 (95.9)

AMBIENT TEMPERATURE °F (°C)

(62.1) 200.6 (58.8)

COPELAND

09/03/14

T40-TV-PDS-19

- 61 -

CAPACITY DATA -

R404A

R507

LOW TEMP. HIGH EFFICIENCY MODELS

60HzTVS-A

CONDENSING

UNIT

MODEL

TVS011L6-A

Compressor

Model

3DS3F46KE

TVS016L6-A

Compressor

Model

4DHNF63KE

TVS023L6-A

Compressor

Model

4DJNF76KE

TVS028L6-A

Compressor

Model

6DHNF93KE

TVS031L6-A

Compressor

Model

6DJNF11ME

TVS041L6-A

Compressor

Model

6DUNF13ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 91.1 (26.7) 87.5 (25.6) 84.0 (24.6) 80.4 (23.6) 76.9 (22.5) 73.5 (21.5) 70.1 (20.5)

-5 (-20.6) 82.2 (24.1) 79.0 (23.2) 75.8 (22.2) 72.6 (21.3) 69.4 (20.3) 66.3 (19.4) 63.3 (18.6)

-10 (-23.3) 73.8 (21.6) 71.0 (20.8) 68.1 (20) 65.2 (19.1) 62.4 (18.3) 59.5 (17.4) 56.8 (16.6)

-15 (-26.1) 65.9 (19.3) 63.4 (18.6) 60.8 (17.8) 58.2 (17.1) 55.6 (16.3) 53.1 (15.6) 50.5 (14.8)

-20 (-28.9) 58.5 (17.1) 56.3 (16.5) 54.0 (15.8) 51.6 (15.1) 49.3 (14.4) 46.9 (13.7) 44.6 (13.1)

-25 (-31.7) 51.6 (15.1) 49.6 (14.5) 47.6 (14) 45.4 (13.3) 43.3 (12.7) 41.1 (12) 39.1 (11.5)

-30 (-34.4) 45.3 (13.3) 43.5 (12.7) 41.6 (12.2) 39.6 (11.6) 37.7 (11) 35.7 (10.5) 33.8 (9.9)

-35 (-37.2) 39.4 (11.5) 37.8 (11.1) 36.0 (10.6) 34.2 (10) 32.4 (9.5) 30.6 (9) 28.8 (8.4)

-40 (-40) 34.1 (10) 32.6 (9.6) 30.9 (9.1) 29.3 (8.6) 27.6 (8.1) 25.8 (7.6) 24.1 (7.1) 0 (-17.8) 126.4 (37) 121.4 (35.6) 116.7 (34.2) 112.1 (32.9) 107.5 (31.5) 102.9 (30.2) 98.2 (28.8)

-5 (-20.6) 113.8 (33.4) 109.2 (32) 104.9 (30.7) 100.8 (29.5) 96.7 (28.3) 92.5 (27.1) 88.1 (25.8)

-10 (-23.3) 102.2 (30) 98.1 (28.8) 94.2 (27.6) 90.5 (26.5) 86.8 (25.4) 83.0 (24.3) 78.9 (23.1)

-15 (-26.1) 91.6 (26.8) 87.9 (25.8) 84.4 (24.7) 81.0 (23.7) 77.7 (22.8) 74.2 (21.7) 70.5 (20.7)

-20 (-28.9) 81.7 (23.9) 78.4 (23) 75.3 (22.1) 72.3 (21.2) 69.3 (20.3) 66.2 (19.4) 62.7 (18.4)

-25 (-31.7) 72.6 (21.3) 69.6 (20.4) 66.8 (19.6) 64.1 (18.8) 61.4 (18) 58.5 (17.1) 55.4 (16.2)

-30 (-34.4) 63.8 (18.7) 61.2 (17.9) 58.7 (17.2) 56.3 (16.5) 53.9 (15.8) 51.2 (15) 48.3 (14.2)

-35 (-37.2) 55.5 (16.3) 53.1 (15.6) 50.9 (14.9) 48.7 (14.3) 46.5 (13.6) 44.0 (12.9) 41.3 (12.1)

-40 (-40) 47.2 (13.8) 45.1 (13.2) 43.1 (12.6) 41.2 (12.1) 39.1 (11.5) 36.8 (10.8) 34.2 (10) 0 (-17.8) 149.5 (43.8) 142.7 (41.8) 136.3 (39.9) 130.2 (38.2) 124.3 (36.4) 118.8 (34.8) 113.6 (33.3)

-5 (-20.6) 135.5 (39.7) 129.4 (37.9) 123.6 (36.2) 118.0 (34.6) 112.6 (33) 107.5 (31.5) 102.7 (30.1)

-10 (-23.3) 122.3 (35.8) 116.8 (34.2) 111.5 (32.7) 106.4 (31.2) 101.5 (29.7) 96.8 (28.4) 92.3 (27.1)

-15 (-26.1) 109.9 (32.2) 104.9 (30.7) 100.1 (29.3) 95.5 (28) 91.0 (26.7) 86.6 (25.4) 82.3 (24.1)

-20 (-28.9) 98.1 (28.8) 93.7 (27.5) 89.3 (26.2) 85.1 (24.9) 80.9 (23.7) 76.8 (22.5) 72.7 (21.3)

-25 (-31.7) 86.9 (25.5) 82.9 (24.3) 79.0 (23.2) 75.1 (22) 71.3 (20.9) 67.4 (19.8) 63.5 (18.6)

-30 (-34.4) 76.2 (22.3) 72.7 (21.3) 69.2 (20.3) 65.6 (19.2) 61.9 (18.1) 58.2 (17.1) 54.4 (15.9)

-35 (-37.2) 66.1 (19.4) 62.9 (18.4) 59.7 (17.5) 56.3 (16.5) 52.8 (15.5) 49.2 (14.4) 45.5 (13.3)

-40 (-40) 56.3 (16.5) 53.5 (15.7) 50.5 (14.8) 47.3 (13.9) 43.9 (12.9) 40.4 (11.8) 36.6 (10.7) 0 (-17.8) 187.0 (54.8) 179.5 (52.6) 172.2 (50.5) 165.0 (48.4) 157.8 (46.2) 150.6 (44.1) - -

-5 (-20.6) 169.2 (49.6) 162.4 (47.6) 155.8 (45.7) 149.3 (43.8) 142.8 (41.9) 136.2 (39.9) 129.4 (37.9)

-10 (-23.3) 152.0 (44.5) 145.9 (42.8) 140.0 (41) 134.1 (39.3) 128.1 (37.5) 122.1 (35.8) 115.8 (33.9)

-15 (-26.1) 135.6 (39.7) 130.1 (38.1) 124.8 (36.6) 1

-20 (-28.9) 120.1 (35.2) 115.1 (33.7) 110.3 (32.3) 105.5 (30.9) 100.5 (29.5) 95.4 (28) 90.1 (26.4)

-25 (-31.7) 105.5 (30.9) 101.0 (29.6) 96.7 (28.3) 92.3 (27.1) 87.7 (25.7) 83.0 (24.3) 78.0 (22.9)

-30 (-34.4) 92.0 (27) 88.0 (25.8) 84.0 (24.6) 79.9 (23.4) 75.7 (22.2) 71.3 (20.9) 66.5 (19.5)

-35 (-37.2) 79.7 (23.4) 76.0 (22.3) 72.3 (21.2) 68.5 (20.1) 64.6 (18.9) 60.4 (17.7) 55.8 (16.4)

-40 (-40) 68.6 (20.1) 65.2 (19.1) 61.7 (18.1) 58.2 (17.1) 54.4 (15.9) 50.3 (14.7) 45.8 (13.4) 0 (-17.8) 206.3 (60.5) 197.2 (57.8) 188.3 (55.2) 179.6 (52.6) 171.0 (50.1) 162.6 (47.7) --- ---

-5 (-20.6) 186.4 (54.6) 178.3 (52.3) 170.2 (49.9) 162.3 (47.6) 154.6 (45.3) 147.0 (43.1) --- ---

-10 (-23.3) 167.5 (49.1) 160.2 (46.9) 153.1 (44.9) 145.9 (42.8) 139.0 (40.7) 132.1 (38.7) 125.5 (36.8)

-15 (-26.1) 149.7 (43.9) 143.2 (42) 136.8 (40.1) 130.4 (38.2) 124.1 (36.4) 117.9 (34.6) 111.9 (32.8)

-20 (-28.9) 133.0 (39) 127.2 (37.3) 121.4 (35.6) 115.7 (33.9) 109.9 (32.2) 104.3 (30.6) 98.8 (29)

-25 (-31.7) 117.4 (34.4) 112.2 (32.9) 107.0 (31.4) 101.8 (29.8) 96.5 (28.3) 91.4 (26.8) 86.3 (25.3)

-30 (-34.4) 102.9 (30.2) 98.3 (28.8) 93.5 (27.4) 88.7 (26) 83.9 (24.6) 79.1 (23.2) 74.3 (21.8)

-35 (-37.2) 89.6 (26.3) 85.3 (25) 80.9 (23.7) 76.4 (22.4) 71.9 (21.1) 67.4 (19.8) 62.8 (18.4)

-40 (-40) 77.3 (22.7) 73.4 (21.5) 69.2 (20.3) 64.9 (19) 60.6 (17.8) 56.2 (16.5) 51.8 (15.2) 0 (-17.8) 259.0 (75.9) 247.8 (72.6) 236.9 (69.4) 226.3 (66.3) 216.2 (63.4) 206.7 (60.6) - -

-5 (-20.6) 233.9 (68.5) 223.2 (65.4) 212.8 (62.4) 202.7 (59.4) 193.0 (56.6) 183.7 (53.8) - -

-10 (-23.3) 211.3 (61.9) 201.3 (59) 191.5 (56.1) 181.9 (53.3) 172.6 (50.6) 163.7 (48) 155.2 (45.5)

-15 (-26.1) 190.7 (55.9) 181.4 (53.2) 172.2 (50.5) 163.2 (47.8) 154.4 (45.3) 145.9 (42.8) 137.9 (40.4)

-20 (-28.9) 171.5 (50.3) 163.0 (47.8) 154.5 (45.3) 146.1 (42.8) 137.9 (40.4) 129.9 (38.1) 122.3 (35.8)

-25 (-31.7) 153.2 (44.9) 145.5 (42.6) 137.8 (40.4) 130.0 (38.1) 122.4 (35.9) 115.0 (33.7) 107.8 (31.6)

-30 (-34.4) 135.1 (39.6) 128.3 (37.6) 121.4 (35.6) 114.4 (33.5) 107.4 (31.5) 100.6 (29.5) 93.9 (27.5)

-35 (-37.2) 116.7 (34.2) 110.8 (32.5) 104.7 (30.7) 98.5 (28.9) 92.2 (27) 86.0 (25.2) 79.9 (23.4)

-40 (-40) 97.2 (28.5) 92.3 (27.1) 87.1 (25.5) 81.7 (23.9) 76.2 (22.3) 70.7 (20.7) 65.2 (19.1)

CAPACITY MBH (KW)

R404A

19.4 (35) 114.0 (33.4) 108.5 (31.8) 102.7 (30.1)

AMBIENT TEMPERATURE °F (°C)

R507

HIGH EFFICIENCY MODELS

COPELAND

09/03/14

T40-TV-PDS-19

- 62 -

CAPACITY DATA -

R407A

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD031H8-A

Compressor

3DS3R17ME

TVD045H8-A

Compressor

4DBNR20ME

TVD051H8-A

Compressor

4DHNR22ME

TVD061H8-A

Compressor

HIGH EFFICIENCY MODELS

4DJNR28ME

TVD071H8-A

Compressor

6DHNR35ME

TVD081H8-A

Compressor

6DJNR40ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 449.4 (131.7) 432.2 (126.7) 415.2 (121.7) 398.4 (116.8) 381.6 (111.8) 365.2 (107) 349.2 (102.3) 40 (4.4) 410.8 (120.4) 395.2 (115.8) 379.8 (111.3) 364.8 (106.9) 349.8 (102.5) 335.2 (98.2) 320.4 (93.9) 35 (1.7) 374.0 (109.6) 360.2 (105.6) 346.6 (101.6) 332.8 (97.5) 319.4 (93.6) 306.0 (89.7) 293.0 (85.9)

45 (7.2) 576.4 (168.9) 555.4 (162.8) 534.6 (156.7) 513.8 (150.6) 493.0 (144.5) 472.2 (138.4) 451.6 (132.4) 40 (4.4) 524.4 (153.7) 505.2 (148.1) 486.0 (142.4) 466.8 (136.8) 448.0 (131.3) 428.8 (125.7) 409.8 (120.1) 35 (1.7) 475.6 (139.4) 458.2 (134.3) 440.8 (129.2) 423.2 (124) 405.8 (118.9) 388.2 (113.8) 370.8 (108.7) 45 (7.2) 646.6 (189.5) 623.0 (182.6) 599.2 (175.6) 574.4 (168.3) 549.6 (161.1) 524.4 (153.7) 499.2 (146.3) 40 (4.4) 593.8 (174) 572.0 (167.6) 549.6 (161.1) 526.6 (154.3) 503.6 (147.6) 480.2 (140.7) 457.0 (133.9) 35 (1.7) 542.0 (158.8) 521.8 (152.9) 501.0 (146.8) 480.0 (140.7) 458.6 (134.4) 437.2 (128.1) 415.6 (121.8) 45 (7.2) 756.2 (221.6) 729.6 (213.8) 702.2 (205.8) 674.2 (197.6) 645.2 (189.1) 615.8 (180.5) 585.4 (171.6) 40 (4.4) 692.4 (202.9) 667.6 (195.7) 642.4 (188.3) 616.4 (180.6) 589.6 (172.8) 562.4 (164.8) 534.6 (156.7) 35 (1.7) 631.0 (184.9) 608.4 (178.3) 584.8 (171.4) 561.2 (164.5) 536.6 (157.3) 511.8 (150) 486.6 (142.6) 45 (7.2) 931.0 (272.8) 903.6 (264.8) 875.4 (256.6) 846.8 (248.2) 816.6 (239.3) 785.4 (230.2) 752.4 (220.5) 40 (4.4) 845.2 (247.7) 819.8 (240.3) 793.8 (232.6) 767.0 (224.8) 739.2 (216.6) 710.2 (208.1) 679.6 (199.2) 35 (1.7) 768.0 (225.1) 744.4 (218.2) 720.6 (211.2) 695.8 (203.9) 670.2 (196.4) 643.4 (188.6) 615.4 (180.4) 45 (7.2) 1128.6 (330.8) 1085.2 (318) 1041.6 (305.3) 997.2 (292.2) 952.6 (279.2) 907.4 (265.9) 862.2 (252.7) 40 (4.4) 1021.4 (299.3) 983.8 (288.3) 945.8 (277.2) 907.0 (265.8) 868.0 (254.4) 828.4 (242.8) 788.8 (231.2) 35 (1.7) 925.0 (271.1) 892.6 (261.6) 859.4 (251.9) 825.8 (242) 791.4 (231.9) 757.0 (221.9) 722.2 (211.7)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 63 -

CAPACITY DATA -

R407A

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD031M8-A

Compressor

Model

3DS3R17ME

TVD045M8-A

Compressor

Model

4DBNR20ME

TVD051M8-A

Compressor

Model

4DHNR22ME

TVD061M8-A

Compressor

Model

4DJNR28ME

TVD071M8-A

Compressor

Model

6DHNR35ME

TVD081M8-A

Compressor

Model

6DJNR40ME

TVD101M8-A

Compressor

Model

6DUNR49ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 30 (-1.1) 339.2 (99.4) 326.8 (95.8) 314.6 (92.2) 302.4 (88.6) 290.2 (85.1) 278.3 (81.5) 265.7 (77.9) 25 (-3.9) 306.2 (89.7) 295.3 (86.5) 284.3 (83.3) 273.4 (80.1) 262.5 (76.9) 251.6 (73.7) 241.1 (70.7) 20 (-6.7) 275.5 (80.7) 265.7 (77.9) 255.8 (75) 245.9 (72.1) 236.0 (69.2) 226.2 (66.3) 216.3 (63.4) 15 (-9.4) 246.5 (72.3) 237.7 (69.7) 228.9 (67.1) 219.9 (64.4) 210.8 (61.8) 201.8 (59.1) 192.6 (56.4) 10 (-12.2) 219.9 (64.4) 211.9 (62.1) 203.7 (59.7) 195.5 (57.3) 187.1 (54.8) 178.5 (52.3) 169.9 (49.8)

5 (-15) 195.1 (57.2) 187.7 (55) 180.2 (52.8) 172.4 (50.5) 164.4 (48.2) 156.5 (45.9) 148.1 (43.4)

0 (-17.8) 172.4 (50.5) 165.5 (48.5) 158.3 (46.4) 150.8 (44.2) 143.2 (42) 135.2 (39.6) 127.1 (37.2) 30 (-1.1) 430.5 (126.2) 414.5 (121.5) 398.6 (116.8) 382.6 (112.1) 366.9 (107.5) 350.9 (102.8) 334.5 (98) 25 (-3.9) 388.3 (113.8) 373.8 (109.5) 359.5 (105.4) 345.0 (101.1) 330.8 (96.9) 316.3 (92.7) 301.4 (88.3) 20 (-6.7) 349.2 (102.3) 336.4 (98.6) 323.4 (94.8) 310.4 (91) 297.4 (87.1) 284.1 (83.3) 271.1 (79.5) 15 (-9.4) 313.3 (91.8) 301.6 (88.4) 290.0 (85) 278.3 (81.5) 266.5 (78.1) 254.5 (74.6) 242.1 (71) 10 (-12.2) 279.9 (82) 269.4 (79) 259.1 (75.9) 248.6 (72.9) 237.9 (69.7) 227.2 (66.6) 216.5 (63.5)

5 (-15) 249.3 (73.1) 239.8 (70.3) 230.6 (67.6) 221.1 (64.8) 211.7 (62) 202.0 (59.2) 192.4 (56.4)

0 (-17.8) 220.7 (64.7) 212.5 (62.3) 204.3 (59.9) 195.7 (57.4) 187.3 (54.9) 178.5 (52.3) 169.7 (49.7) 30 (-1.1) 491.6 (144.1) 473.1 (138.7) 454.0 (133.1) 434.5 (127.3) 415.0 (121.6) 395.2 (115.8) 375.5 (110) 25 (-3.9) 442.9 (129.8) 425.9 (124.8) 408.5 (119.7) 390.8 (114.5) 372.8 (109.2) 354.9 (104) 336.8 (98.7) 20 (-6.7) 396.3 (116.1) 380.9 (111.6) 365.2 (107) 349.0 (102.3) 332.9 (97.5) 316.7 (92.8) 300.9 (88.2) 15 (-9.4) 352.2 (103.2) 338.5 (99.2) 324.2 (95) 309.8 (90.8) 295.3 (86.5) 281.0 (82.3) 266.9 (78.2) 10 (-12.2) 311.2 (91.2) 298.8 (87.6) 286.2 (83.9) 273.4 (80.1) 260.6 (76.4) 248.2 (72.7) 236.0 (69.2)

5 (-15) 273.4 (80.1) 262.5 (76.9) 251.6 (73.7) 240.5 (70.5) 229.3 (67.2) 218.6 (64.1) 208.3 (61.1)

0 (-17.8) 239.4 (70.2) 230.2 (67.5) 220.5 (64.6) 211.1 (61.9) 201.6 (59.1) 192.8 (56.5) 184.2 (54) 30 (-1.1) 572.5 (167.8) 551.7 (161.7) 530.3 (155.4) 508.4 (149) 486.2 (142.5) 463.7 (135.9) 441.2 (129.3) 25 (-3.9) 516.8 (151.5) 497.7 (145.9) 478.2 (140.1) 458.4 (134.4) 438.5 (128.5) 418.1 20 (-6.7) 463.9 (136) 446.5 (130.8) 429.0 (125.7) 411.4 (120.6) 393.5 (1 15 (-9.4) 414.1 (121.4) 398.4 (116.8) 382.8 (112.2) 367.1 (107.6) 351.5 (103) 335.8 (98.4) 320.3 (93.9) 10 (-12.2) 367.3 (107.6) 353.4 (103.6) 339.6 (99.5) 325.9 (95.5) 312.5 (91.6) 299.3 (87.7) 286.0 (83.8)

5 (-15) 323.6 (94.8) 311.6 (91.3) 299.7 (87.8) 287.9 (84.4) 276.6 (81.1) 265.7 (77.9) 254.9 (74.7)

0 (-17.8) 283.5 (83.1) 273.0 (80) 262.9 (77.1) 253.3 (74.2) 244.0 (71.5) 235.4 (69) 227.2 (66.6) 30 (-1.1) 698.3 (204.6) 676.6 (198.3) 654.6 (191.8) 632.1 (185.2) 608.6 (178.4) 584.2 (171.2) 558.4 (163.6) 25 (-3.9) 634.8 (186) 615.1 (180.3) 595.1 (174.4) 574.8 (168.4) 553.4 (162.2) 531.3 (155.7) 507.8 (148.8) 20 (-6.7) 576.7 (169) 558.8 (163.8) 541.0 (158.5) 522.5 (153.1) 503.6 (147.6) 483.6 (141.7) 462.4 (135.5) 15 (-9.4) 522.5 (153.1) 506.5 (148.4) 490.8 (143.8) 474.4 (139) 457.6 (134.1) 440.0 (128.9) 421.3 (123.5) 10 (-12.2) 471.2 (138.1) 457.4 (134) 443.5 (130) 429.5 (125.9) 414.8 (121.6) 399.4 (117.1) 383.3 (112.3)

5 (-15) 421.5 (123.5) 409.7 (120.1) 398.0 (116.6) 386.0 (113.1) 373.8 (109.5) 360.8 (105.7) 346.9 (101.7)

0 (-17.8) 372.3 (109.1) 362.5 (106.2) 352.8 (103.4) 343.1 (100.6) 333.3 (97.7) 322.6 (94.5) 311.2 (91.2) 30 (-1.1) 838.3 (245.7) 810.2 (237.4) 781.4 (229) 752.0 (220.4) 722.2 (211.7) 691.7 (202.7) 661.1 (193.7) 25 (-3.9) 760.0 (222.7) 735.4 (215.5) 710.4 (208.2) 684.6 (200.6) 658.1 (192.9) 631.5 (185.1) 604.4 (177.1) 20 (-6.7) 688.8 (201.9) 667.2 (195.5) 644.9 (189) 621.8 (182.2) 598.3 (175.3) 574.1 (168.3) 549.8 (161.1) 15 (-9.4) 623.3 (182.7) 603.5 (176.9) 583.4 (171) 562.4 (164.8) 540.8 (158.5) 518.7 (152) 496.2 (145.4) 10 (-12.2) 561.5 (164.6) 543.3 (159.2) 524.0 (153.6) 504.2 (147.8) 483.8 (141.8) 462.8 (135.6) 441.6 (129.4)

5 (-15) 502.1 (147.2) 484.1 (141.9) 465.4 (136.4) 445.8 (130.7) 425.7 (124.8) 405.1 (118.7) 384.3 (112.6)

0 (-17.8) 443.1 (129.9) 424.6 (124.4) 405.5 (118.8) 385.6 (113) 365.0 (107) 344.0 (100.8) 322.6 (94.5) 30 (-1.1) 976.7 (286.2) 945.6 (277.1) 914.8 (268.1) 883.9 (259) 852.8 (249.9) 821.3 (240.7) 789.2 (231.3) 25 (-3.9) 888.9 (260.5) 861.2 (252.4) 833.3 (244.2) 805.4 (236) 776.8 (227.7) 747.6 (219.1) 717.8 (210.4) 20 (-6.7) 806.0 (236.2) 780.8 (228.8) 755.6 (221.4) 730.0 (213.9) 703.5 (206.2) 676.2 (198.2) 647.9 (189.9) 15 (-9.4) 727.4 (213.2) 704.8 (206.5) 681.5 (199.7) 657.5 (192.7) 632.7 (185.4) 606.7 (177.8) 579.6 (169.9) 10 (-12.2) 653.3 (191.5) 632.3 (185.3) 610.5 (178.9) 587.8 (172.3) 564.1 (165.3) 539.1 (158) 512.6 (150.2)

5 (-15) 583.4 (171) 563.4 (165.1) 542.6 (159) 520.8 (152.6) 497.5 (145.8) 472.9 (138.6) 446.5 (130.8)

0 (-17.8) 517.2 (151.6) 498.1 (146) 477.8 (140) 456.1 (133.7) 432.8 (126.8) 407.8 (119.5) 381.2 (11

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 11 0 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

15.3) 375.5 (110) 357.2 (104.7)

HIGH EFFICIENCY MODELS

(122.5) 397.1 (116.4)

1.7)

COPELAND

09/03/14

T40-TV-PDS-19

- 64 -

CAPACITY DATA -

R407A

LOW TEMP. HIGH EFFICIENCY MODELS

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD021L8-A

Compressor

Model

3DS3F46KE

HIGH EFFICIENCY MODELS

TVD031L8-A

Compressor

Model

4DHNF63KE

TVD045L8-A

Compressor

Model

4DJNF76KE

TVD055L8-A

Compressor

Model

6DHNF93KE

TVD061L8-A

Compressor

Model

6DJNF11ME

TVD081L8-A

Compressor

Model

6DUNF13ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 164.2 (48.1) 158.1 (46.3) 151.8 (44.5) 145.5 (42.7) 139.0 (40.7) 132.3 (38.8) --- ---

-5 (-20.6) 145.5 (42.7) 139.7 (40.9) 134.0 (39.3) 127.9 (37.5) 121.8 (35.7) 115.7 (33.9) --- ---

-10 (-23.3) 128.3 (37.6) 122.9 (36) 117.6 (34.5) 111.9 (32.8) 106.3 (31.1) 100.6 (29.5) 94.7 (27.8)

-15 (-26.1) 112.6 (33) 107.5 (31.5) 102.5 (30) 97.4 (28.6) 92.2 (27) 86.7 (25.4) 81.3 (23.8)

-20 (-28.9) 98.1 (28.7) 93.5 (27.4) 88.8 (26) 84.0 (24.6) 79.2 (23.2) 74.1 (21.7) 69.3 (20.3)

-25 (-31.7) 84.6 (24.8) 80.2 (23.5) 76.0 (22.3) 71.6 (21) 67.2 (19.7) 62.6 (18.3) 58.0 (17)

-30 (-34.4) 72.0 (21.1) 68.0 (19.9) 64.1 (18.8) 59.9 (17.5) 55.9 (16.4) 51.9 (15.2) 47.7 (14)

-35 (-37.2) 59.9 (17.5) 56.1 (16.4) 52.5 (15.4) 48.9 (14.3) 45.2 (13.2) 41.6 (12.2) 37.8 (11.1)

-40 (-40) 48.1 (14.1) 44.7 (13.1) 41.4 (12.1) 38.0 (11.1) 34.9 (10.2) 31.5 (9.2) 28.4 (8.3) 0 (-17.8) 230.4 (67.5) 221.1 (64.8) 211.7 (62) 202.2 (59.3) 193.0 (56.6) 183.5 (53.8) 174.1 (51)

-5 (-20.6) 205.4 (60.2) 197.2 (57.8) 188.8 (55.3) 180.2 (52.8) 171.8 (50.3) 163.2 (47.8) 154.6 (45.3)

-10 (-23.3) 182.1 (53.4) 174.7 (51.2) 167.2 (49) 159.4 (46.7) 151.8 (44.5) 144.1 (42.2) 136.3 (39.9)

-15 (-26.1) 160.2 (47) 153.5 (45) 146.8 (43) 139.9 (41) 132.9 (39) 125.8 (36.9) 118.7 (34.8)

-20 (-28.9) 139.9 (41) 133.8 (39.2) 127.7 (37.4) 121.4 (35.6) 115.1 (33.7) 108.8 (31.9) 102.3 (30)

-25 (-31.7) 120.8 (35.4) 115.5 (33.8) 110.0 (32.2) 104.4 (30.6) 98.5 (28.9) 92.8 (27.2) 86.7 (25.4)

-30 (-34.4) 103.3 (30.3) 98.5 (28.9) 93.7 (27.4) 88.4 (25.9) 83.2 (24.4) 77.7 (22.8) 72.5 (21.2)

-35 (-37.2) 87.4 (25.6) 83.2 (24.4) 78.5 (23) 73.7 (21.6) 68.9 (20.2) 64.1 (18.8) 58.8 (17.2)

-40 (-40) 73.1 (21.4) 69.1 (20.2) 64.9 (19) 60.5 (17.7) 55.9 (16.4) 51.2 (15) 46.4 (13.6) 0 (-17.8) 287.7 (84.3) 276.6 (81.1) 265.2 (77.7) 253.7 (74.3) 241.9 (70.9) 230.0 (67.4) --- ---

-5 (-20.6) 254.5 (74.6) 244.2 (71.6) 233.5 (68.4) 222.8 (65.3) 211.9 (62.1) 200.8 (58.8) --- ---

-10 (-23.3) 223.7 (65.5) 214.2 (62.8) 204.3 (59.9) 194.5 (57) 184.4 (54) 174.1 (51) 163.6 (47.9)

-15 (-26.1) 195.3 (57.2) 186.7 (54.7) 177.7 (52.1) 168.8 (49.5) 159.6 (46.8) 150.2 (44) 140.5 (41.2)

-20 (-28.9) 169.5 (49.7) 161.7 (47.4) 153.7 (45.1) 145.7 (42.7) 137.3 (40.3) 128.9 (37.8) 120.3 (35.3)

-25 (-31.7) 146.2 (42.8) 139.4 (40.9) 132.5 (38.8) 125.4 (36.7) 118.2 (34.6) 110.7 (32.4) 103.1 (30.2)

-30 (-34.4) 125.8 (36.9) 120.1 (35.2) 1

-35 (-37.2) 108.4 (31.8) 103.5 (30.3) 98.7 (28.9) 93.9 (27.5) 88.6 (26) 83.4 (24.4) 77.7 (22.8)

-40 (-40) 93.9 (27.5) 90.3 (26.5) 86.5 (25.4) 82.7 (24.2) 78.8 (23.1) 74.6 (21.8) 70.1 (20.6) 0 (-17.8) 344.8 (101.1) 332.0 (97.3) 318.2 (93.2) 303.9 (89.1) 288.5 (84.6) 272.6 (79.9) --- ---

-5 (-20.6) 300.1 (87.9) 288.5 (84.6) 276.4 (81) 263.6 (77.2) 249.9 (73.2) 235.4 (69) --- ---

-10 (-23.3) 261.9 (76.7) 251.6 (73.7) 240.7 (70.5) 229.1 (67.1) 216.7 (63.5) 203.7 (59.7) 190.1 (55.7)

-15 (-26.1) 229.1 (67.1) 219.9 (64.4) 210.0 (61.5) 199.3 (58.4) 188.2 (55.1) 176.2 (51.6) 163.8 (48)

-20 (-28.9) 200.8 (58.8) 192.2 (56.3) 182.9 (53.6) 173.3 (50.8) 162.8 (47.7) 151.8 (44.5) 140.3 (41.1)

-25 (-31.7) 175.1 (51.3) 167.0 (48.9) 158.3 (46.4) 149.1 (43.7) 139.4 (40.9) 129.4 (37.9) 118.7 (34.8)

-30 (-34.4) 151.2 (44.3) 143.2 (42) 134.8 (39.5) 126.2 (37) 117.0 (34.3) 107.1 (31.4) 97.0 (28.4)

-35 (-37.2) 127.5 (37.4) 119.5 (35) 111.3 (32.6) 102.7 (30.1) 93.7 (27.4) 84.2 (24.7) 74.3 (21.8)

-40 (-40) 102.7 (30.1) 94.5 (27.7) 86.1 (25.2) 77.5 (22.7) 68.5 (20.1) 59.0 (17.3) 49.6 (14.5) 0 (-17.8) 401.3 (117.6) 385.8 (113.1) 369.8 (108.4) 353.4 (103.6) 336.4 (98.6) --- --- --- ---

-5 (-20.6) 355.7 (104.3) 341.7 (100.1) 327.2 (95.9) 312.1 (91.5) 296.3 (86.8) 279.9 (82) --- ---

-10 (-23.3) 314.2 (92.1) 301.4 (88.3) 288.1 (84.4) 274.3 (80.4) 259.6 (76.1) 244.4 (71.6) --- ---

-15 (-26.1) 275.9 (80.9) 264.4 (77.5) 252.0 (73.9) 239.2 (70.1) 225.8 (66.2) 211.5 (62) --- ---

-20 (-28.9) 240.7 (70.5) 230.0 (67.4) 218.6 (64.1) 206.6 (60.6) 194.0 (56.9) 180.8 (53) 166.5 (48.8)

-25 (-31.7) 207.5 (60.8) 197.6 (57.9) 187.1 (54.8) 176.0 (51.6) 164.0 (48.1) 151.4 (44.4) 138.0 (40.4)

-30 (-34.4) 176.0 (51.6) 166.7 (48.9) 156.9 (46) 146.4 (42.9) 135.2 (39.6) 123.1 (36.1) 110.0 (32.2)

-35 (-37.2) 145.5 (42.7) 136.9 (40.1) 127.5 (37.4) 117.4 (34.4) 106.7 (31.3) 94.9 (27.8) 82.5 (24.2)

-40 (-40) 115.7 (33.9) 107.3 (31.4) 98.3 (28.8) 88.6 (26) 78.1 (22.9) 66.6 (19.5) 54.4 (15.9) 0 (-17.8) 461.4 (135.2) 445.6 (130.6) 429.9 (126) 413.7 (121.2) 397.5 (116.5) 381.2 (111.7) --- ---

-5 (-20.6) 414.3 (121.4) 399.8 (117.2) 385.4 (112.9) 370.7 (108.6) 355.5 (104.2) 340.0 (99.6) --- ---

-10 (-23.3) 368.6 (108) 355.3 (104.1) 341.9 (100.2) 328.0 (96.1) 313.7 (91.9) 299.0 (87.6) --- ---

-15 (-26.1) 324.2 (95) 312.1 (91.5) 299.5 (87.8) 286.7 (84) 273.2 (80.1) 258.9 (75.9) 244.2 (71.6)

-20 (-28.9) 282.2 (82.7) 270.9 (79.4) 259.1 (75.9) 247.0 (72.4) 233.9 (68.6) 220.3 (64.6) 205.8 (60.3)

-25 (-31.7) 243.0 (71.2) 232.3 (68.1) 221.1 (64.8) 209.4 (61.4) 197.0 (57.7) 183.5 (53.8) 169.3 (49.6)

-30 (-34.4) 207.1 (60.7) 197.0 (57.7) 186.3 (54.6) 174.7 (51.2) 162.3 (47.6) 149.1 (43.7) 135.0 (39.6)

-35 (-37.2) 175.1 (51.3) 165.3 (48.4) 154.8 (45.4) 143.2 (42) 131.0 (38.4) 117.8 (34.5) 103.3 (30.3)

-40 (-40) 147.4 (43.2) 137.8 (40.4) 127.1 (37.2) 115.7 (33.9) 103.3 (30.3) 89.7 (26.3) 75.2 (22)

CAPACITY MBH (KW)

14.0 (33.4) 108.2 (31.7) 101.9 (29.8) 95.3 (27.9) 88.8 (26)

R407A

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 65 -

CAPACITY DATA -

R407C

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD031H8-A

Compressor

Model

3DS3R17ME

TVD045H8-A

Compressor

Model

4DBNR20ME

TVD051H8-A

Compressor

Model

4DHNR22ME

TVD061H8-A

Compressor

Model

4DJNR28ME

TVD071H8-A

Compressor

Model

6DHNR35ME

TVD081H8-A

Compressor

Model

6DJNR40ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 55 (12.8) 516.4 (151.3) 496.9 (145.6) 477.8 (140) 459.5 (134.7) 441.6 (129.4) 424.2 (124.3) 407.4 (119.4) 50 (10) 474.0 (138.9) 456.5 (133.8) 439.5 (128.8) 422.9 (124) 407.0 (119.3) 391.4 (114.7) 376.1 (110.2) 45 (7.2) 433.7 (127.1) 418.1 (122.5) 403.0 (118.1) 388.3 (113.8) 374.0 (109.6) 360.2 (105.5) 346.3 (101.5) 40 (4.4) 395.4 (115.9) 381.6 (111.8) 368.3 (107.9) 355.3 (104.1) 342.5 (100.4) 330.1 (96.7) 317.7 (93.1)

35 (1.7) 359.3 (105.3) 347.1 (101.7) 335.4 (98.3) 324.0 (95) 312.7 (91.6) 301.4 (88.3) 290.2 (85.1) 55 (12.8) 662.3 (194.1) 638.6 (187.2) 614.9 (180.2) 591.2 (173.2) 567.6 (166.4) 544.3 (159.5) - 50 (10) 604.0 (177) 581.5 (170.4) 559.2 (163.9) 537.0 (157.4) 514.9 (150.9) 493.1 (144.5) 471.5 (138.2) 45 (7.2) 550.0 (161.2) 529.0 (155) 508.2 (148.9) 487.4 (142.8) 466.8 (136.8) 446.5 (130.8) 426.5 (125) 40 (4.4) 500.0 (146.5) 480.5 (140.8) 461.2 (135.2) 441.8 (129.5) 422.9 (124) 404.0 (118.4) 385.6 (113) 35 (1.7) 453.6 (132.9) 435.5 (127.6) 417.7 (122.4) 399.8 (117.2) 382.4 (112.1) 365.2 (107) 348.4 (102.1) 55 (12.8) 788.3 (231) 747.2 (219) 706.9 (207.2) 667.2 (195.5) 628.5 (184.2) 590.9 (173.2) 554.6 (162.5) 50 (10) 719.9 (211) 682.9 (200.1) 646.8 (189.6) 611.5 (179.2) 577.1 (169.1) 543.7 (159.3) 511.6 (149.9) 45 (7.2) 654.2 (191.7) 621.4 (182.1) 589.5 (172.8) 558.2 (163.6) 527.9 (154.7) 498.5 (146.1) 470.6 (137.9) 40 (4.4) 591.6 (173.4) 563.0 (165) 535.1 (156.8) 507.6 (148.8) 481.1 (141) 455.7 (133.6) 431.6 (126.5) 35 (1.7) 532.8 (156.1) 507.8 (148.8) 483.6 (141.7) 459.9 (134.8) 437.0 (128.1) 415.0 (121.6) 394.2 (115.5) 55 (12.8) 935.6 (274.2) 887.7 (260.1) 840.8 (246.4) 795.1 (233) 750.1 (219.8) 706.2 (207) 663.6 (194.5) 50 (10) 848.6 (248.7) 805.8 (236.1) 764.0 (223.9) 723.2 (212) 683.6 (200.3) 644.9 (189) 607.3 (178) 45 (7.2) 766.9 (224.8) 729.1 (213.7) 692.4 (202.9) 656.5 (192.4) 621.8 (182.2) 588.0 (172.3) 555.5 (162.8) 40 (4.4) 690.9 (202.5) 657.9 (192.8) 625.8 (183.4) 594.7 (174.3) 564.7 (165.5) 535.5 (156.9) 507.6 (148.8) 35 (1.7) 620.3 (181.8) 592.0 (173.5) 564.3 (165.4) 537.6 (157.6) 512.0 (150) 487.2 (142.8) 463.5 (135.8) 55 (12.8) 1153.3 (338) 1108.6 (324.9) 1063.7 (311.7) 1018.5 (298.5) 973.4 (285.3) 927.8 (271.9) 882.2 (258.5) 50 (10) 1031.9 (302.4) 992.5 (290.9) 952.8 (279.2) 912.9 (267.5) 872.8 (255.8) 832.4 (244) 791.7 (232)

45 (7.2) 922.5 (270.4) 887.9 (260.2) 853.0 (250) 818.0 (239.7) 782.7 (229.4) 747.0 (218.9) 710.9 (208.3) 40 (4.4) 824.3 (241.6) 794.2 (232.8) 763.8 (223.8) 733.1 (214.9) 702.2 (205.8) 671.0 (196.6) 639.2 (187.3) 35 (1.7) 736.5 (215.8) 710.6 (208.3) 684.4 (200.6) 657.7 (192.8) 630.8 (184.9) 603.5 (176.9) 575.6 (168.7) 55 (12.8) 1607.1 (471) 1540.1 (451.4) 1468.1 (430.3) 1391.7 (407.9) 1311.0 (384.2) 1226.8 (359.5) 1139.7 (334) 50 (10) 1410.2 (413.3) 1350.7 (395.9) 1286.0 (376.9) 1217.0 (356.7) 1 45 (7.2) 1235.4 (362.1) 1182.7 (346.6) 1125.2 (329.8) 1063.2 (311.6) 997.7 (292.4) 929.0 (272.3) 857.6 (251.3) 40 (4.4) 1083.0 (317.4) 1036.1 (303.7) 984.9 (288.6) 929.5 (272.4) 870.9 (255.2) 809.6 (237.3) 745.9 (218.6)

35 (1.7) 951.1 (278.7) 909.7 (266.6) 864.2 (253.3) 815.0 (238.9) 762.9 (223.6) 708.5 (207.7) 652.3 (191.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

144.1 (335.3) 1067.9 (313) 988.7 (289.8)

HIGH EFFICIENCY MODELS

COPELAND

09/03/14

T40-TV-PDS-19

- 66 -

CAPACITY DATA -

R407C

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD031M8-A

Compressor

Model

3DS3R17ME

TVD045M8-A

Compressor

Model

4DBNR20ME

HIGH EFFICIENCY MODELS

TVD051M8-A

Compressor

Model

4DHNR22ME

TVD061M8-A

Compressor

Model

4DJNR28ME

TVD071M8-A

Compressor

Model

6DHNR35ME

TVD081M8-A

Compressor

Model

6DJNR40ME

TVD101M8-A

Compressor

Model

6DUNR49ME

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 325.5 (95.4) 314.8 (92.3) 304.5 (89.2) 294.4 (86.3) 284.1 (83.3) 274.1 (80.3) 263.8 (77.3) 25 (-3.9) 293.6 (86) 284.3 (83.3) 275.3 (80.7) 266.3 (78) 257.3 (75.4) 248.0 (72.7) 238.4 (69.9) 20 (-6.7) 264.2 (77.4) 256.0 (75) 248.0 (72.7) 239.8 (70.3) 231.6 (67.9) 223.0 (65.4) 214.0 (62.7) 15 (-9.4) 236.7 (69.4) 229.5 (67.3) 222.4 (65.2) 215.0 (63) 207.3 (60.7) 199.1 (58.3) 190.5 (55.8) 10 (-12.2) 211.3 (61.9) 205.0 (60.1) 198.5 (58.2) 191.5 (56.1) 184.2 (54) 176.4 (51.7) 167.8 (49.2) 30 (-1.1) 410.3 (120.3) 393.8 (115.4) 377.4 (110.6) 361.0 (105.8) 345.2 (101.2) 329.5 (96.6) 314.4 (92.1) 25 (-3.9) 369.6 (108.3) 354.5 (103.9) 339.6 (99.5) 324.9 (95.2) 310.4 (91) 296.5 (86.9) 282.9 (82.9) 20 (-6.7) 331.0 (97) 317.3 (93) 303.9 (89.1) 290.6 (85.2) 277.8 (81.4) 265.4 (77.8) 253.5 (74.3) 15 (-9.4) 294.0 (86.2) 281.6 (82.5) 269.6 (79) 258.1 (75.6) 246.8 (72.3) 236.0 (69.2) 225.8 (66.2) 10 (-12.2) 257.9 (75.6) 247.2 (72.4) 236.7 (69.4) 226.6 (66.4) 216.9 (63.6) 207.7 (60.9) 199.1 (58.3) 30 (-1.1) 477.5 (140) 456.1 (133.7) 435.3 (127.6) 415.0 (121.6) 395.2 (115.8) 376.5 (110.3) 358.9 (105.2) 25 (-3.9) 426.1 (124.9) 408.0 (119.6) 390.2 (114.4) 372.8 (109.2) 356.2 (104.4) 340.2 (99.7) 325.3 (95.3) 20 (-6.7) 378.8 ( 111) 363.5 (106.5) 348.4 (102.1) 333.7 (97.8) 319.4 (93.6) 306.0 (89.7) 293.4 (86) 15 (-9.4) 335.6 (98.3) 322.8 (94.6) 310.0 (90.8) 297.4 (87.1) 285.2 (83.6) 273.6 (80.2) 262.9 (77.1) 10 (-12.2) 296.7 (87) 285.8 (83.8) 274.9 (80.6) 264.0 (77.4) 253.5 (74.3) 243.4 (71.3) 233.9 (68.6) 30 (-1.1) 555.7 (162.8) 531.3 (155.7) 508.0 (148.9) 485.3 (142.2) 463.5 (135.8) 442.7 (129.7) 422.7 (123.9) 25 (-3.9) 496.4 (145.5) 475.9 (139.5) 456.1 (133.7) 437.0 (128.1) 419.0 (122.8) 401.5 (117.7) 384.9 (112.8) 20 (-6.7) 442.7 (129.7) 425.5 (124.7) 408.9 (119.8) 392.9 (115.2) 377.8 (110.7) 363.3 (106.5) 349.4 (102.4) 15 (-9.4) 394.0 (115.5) 379.5 (111.2) 365.6 (107.1) 352.4 (103.3) 339.6 (99.5) 327.4 (95.9) 316.1 (92.6) 10 (-12.2) 349.9 (102.5) 337.7 (99) 325.9 (95.5) 314.6 (92.2) 303.9 (89.1) 293.6 (86) 283.9 (83.2) 30 (-1.1) 658.6 (193) 636.3 (186.5) 613.8 (179.9) 590.7 (173.1) 567.4 (166.3) 543.5 (159.3) 518.9 (152.1) 25 (-3.9) 589.3 (172.7) 570.4 (167.2) 551.0 (161.5) 531.1 (155.6) 510.7 (149.7) 489.7 (143.5) 468.1 (137.2) 20 (-6.7) 527.7 (154.7) 511.6 (149.9) 494.8 (145) 477.5 15 (-9.4) 472.7 (138.5) 458.6 (134.4) 443.9 (130.1) 428.6 (125.6) 412.7 (120.9) 396.1 (116.1) 378.6 ( 111 10 (-12.2) 422.9 (124) 410.3 (120.3) 397.3 (116.4) 383.5 (112.4) 368.8 (108.1) 353.4 (103.6) 337.3 (98.8) 30 (-1.1) 838.3 (245.7) 801.6 (234.9) 761.3 (223.1) 717.6 (210.3) 671.8 (196.9) 624.1 (182.9) 575.2 (168.6) 25 (-3.9) 742.4 (217.6) 709.6 (208) 673.9 (197.5) 635.7 (186.3) 595.6 (174.5) 554.4 (162.5) 512.8 (150.3) 20 (-6.7) 660.5 (193.6) 631.3 (185) 599.6 (175.7) 566.4 (166) 531.9 (155.9) 497.3 (145.7) 462.6 (135.6) 15 (-9.4) 589.7 (172.8) 563.6 (165.2) 535.9 (157.1) 507.4 (148.7) 478.4 (140.2) 450.0 (131.9) 422.7 (123.9) 10 (-12.2) 526.9 (154.4) 503.6 (147.6) 479.4 (140.5) 455.5 (133.5) 432.0 (126.6) 409.9 (120.1) 390.0 (114.3) 30 (-1.1) 979.2 (287) 933.7 (273.6) 885.8 (259.6) 836.2 (245.1) 785.4 (230.2) 734.0 (215.1) 682.5 (200) 25 (-3.9) 868.4 (254.5) 827.0 (242.4) 783.9 (229.7) 739.8 (216.8) 694.9 (203.7) 650.0 (190.5) 605.6 (177.5) 20 (-6.7) 768.0 (225.1) 730.8 (214.2) 692.6 (203) 653.7 (191.6) 614.9 (180.2) 576.7 (169) 539.7 (158.2) 15 (-9.4) 677.9 (198.7) 644.9 (189) 611.3 (179.2) 578.1 (169.4) 545.4 (159.8) 514.1 (150.7) 484.9 (142.1) 10 (-12.2) 597.5 (175.1) 568.7 (166.7) 540.1 (158.3) 512.4 (150.2) 486.4 (142.5) 462.4 (135.5) 441.4 (129.4)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 11 0 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

(140) 459.5 (134.7) 441.0 (129.2) 421.7 (123.6)

)

COPELAND

CONDENSING

UNIT

MODEL

TVD031H8-A

Compressor

3DS3R17ME

TVD045H8-A

Compressor

4DBNR20ME

TVD051H8-A

Compressor

4DHNR22ME

TVD061H8-A

Compressor

4DJNR28ME

TVD071H8-A

Compressor

6DHNR35ME

TVD081H8-A

Compressor

6DJNR40ME

TEMPERATURE

CAPACITY DATA -

R404A

R507

60HzTVD-A

HIGH TEMP. HIGH EFFICIENCY MODELS

SATURATED

SUCTION

° F ° C

45 (7.2) 463.0 (135.7) 443.2 (129.9) 423.4 (124.1) 404.0 (118.4) 384.8 (112.8) 365.8 (107.2) 347.0 (101.7) 40 (4.4) 425.8 (124.8) 407.6 (119.5) 389.6 (114.2) 371.8 (109) 354.4 (103.9) 337.0 (98.8) 319.8 (93.7) 35 (1.7) 390.6 (114.5) 374.0 (109.6) 357.6 (104.8) 341.4 (100.1) 325.4 (95.4) 309.6 (90.7) 294.0 (86.2) 45 (7.2) 559.4 (163.9) 535.0 (156.8) 511.2 (149.8) 488.0 (143) 465.4 (136.4) 443.2 (129.9) 421.6 (123.6) 40 (4.4) 521.0 (152.7) 498.2 (146) 476.0 (139.5) 454.4 (133.2) 433.4 (127) 412.8 (121) 392.6 (115.1) 35 (1.7) 482.6 (141.4) 461.4 (135.2) 440.8 (129.2) 420.8 (123.3) 401.2 (117.6) 382.0 (112) 363.4 (106.5) 45 (7.2) 621.4 (182.1) 594.2 (174.1) 567.8 (166.4) 542.2 (158.9) 517.4 (151.6) 493.2 (144.5) 469.4 (137.6) 40 (4.4) 577.8 (169.3) 552.6 (162) 528.0 (154.7) 504.2 (147.8) 481.0 (141) 458.4 (134.3) 436.4 (127.9) 35 (1.7) 534.4 (156.6) 511.0 (149.8) 488.2 (143.1) 466.0 (136.6) 444.6 (130.3) 423.6 (124.1) 403.2 (118.2) 45 (7.2) 762.6 (223.5) 730.0 (213.9) 697.8 (204.5) 665.8 (195.1) 634.0 (185.8) 602.2 (176.5) 570.6 (167.2) 40 (4.4) 702.6 (205.9) 672.4 (197.1) 642.6 (188.3) 613.0 (179.7) 583.6 (171) 554.2 (162.4) 525.0 (153.9) 35 (1.7) 645.0 (189) 617.2 (180.9) 589.8 (172.9) 562.6 (164.9) 535.4 (156.9) 508.6 (149.1) 481.6 (141.1) 45 (7.2) 975.2 (285.8) 934.6 (273.9) 894.0 (262) 853.4 (250.1) 812.4 (238.1) 771.4 (226.1) 730.2 (214) 40 (4.4) 894.0 (262) 857.0 (251.2) 819.8 (240.3) 782.6 (229.4) 745.2 (218.4) 707.6 (207.4) 670.0 (196.4) 35 (1.7) 817.4 (239.6) 783.6 (229.6) 749.8 (219.7) 715.8 (209.8) 681.8 (199.8) 647.4 (189.7) 613.2 (179.7) 45 (7.2) 1103.8 (323.5) 1059.8 (310.6) 1016.0 (297.8) 972.2 (284.9) 928.0 (272) 883.6 (259) 838.4 (245.7) 40 (4.4) 1019.8 (298.9) 979.0 (286.9) 938.4 (275) 897.8 (263.1) 857.2 (251.2) 816.2 (239.2) 774.6 (227) 35 (1.7) 939.0 (275.2) 901.4 (264.2) 864.0 (253.2) 826.6 (242.3) 789.0 (231.2) 751.2 (220.2) 713.0 (209)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

COPELAND

09/03/14

T40-TV-PDS-19

- 67 -

CAPACITY DATA -

R404A

R507

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD031M8-A

Compressor

Model

3DS3R17ME

TVD045M8-A

Compressor

Model

4DBNR20ME

TVD051M8-A

Compressor

Model

4DHNR22ME

TVD061M8-A

Compressor

Model

4DJNR28ME

TVD071M8-A

Compressor

Model

6DHNR35ME

TVD081M8-A

Compressor

Model

6DJNR40ME

TVD101M8-A

Compressor

Model

6DUNR49ME

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 357.0 (104.6) 342.0 (100.2) 327.2 (95.9) 312.6 (91.6) 298.2 (87.4) 283.8 (83.2) 269.8 (79.1) 25 (-3.9) 325.4 (95.4) 312.0 (91.4) 298.6 (87.5) 285.4 (83.6) 272.4 (79.8) 259.4 (76) 246.8 (72.3) 20 (-6.7) 295.6 (86.6) 283.6 (83.1) 271.6 (79.6) 259.8 (76.1) 248.0 (72.7) 236.6 (69.3) 225.2 (66) 15 (-9.4) 267.8 (78.5) 257.0 (75.3) 246.2 (72.2) 235.6 (69) 225.2 (66) 215.0 (63) 204.8 (60) 10 (-12.2) 241.8 (70.9) 232.0 (68) 222.6 (65.2) 213.2 (62.5) 203.8 (59.7) 194.6 (57) 185.6 (54.4)

5 (-15) 217.6 (63.8) 209.0 (61.3) 200.4 (58.7) 192.0 (56.3) 183.8 (53.9) 175.6 (51.5) 167.6 (49.1)

0 (-17.8) 195.0 (57.1) 187.4 (54.9) 179.8 (52.7) 172.4 (50.5) 165.0 (48.4) 157.8 (46.2) 150.6 (44.1) 30 (-1.1) 444.6 (130.3) 425.0 (124.6) 405.8 (118.9) 387.4 (113.5) 369.2 (108.2) 351.6 (103) 334.2 (97.9) 25 (-3.9) 407.0 (119.3) 389.0 (114) 371.6 (108.9) 354.4 (103.9) 337.8 (99) 321.4 (94.2) 305.4 (89.5) 20 (-6.7) 370.6 (108.6) 354.2 (103.8) 338.0 (99.1) 322.4 (94.5) 307.0 (90) 292.2 (85.6) 277.4 (81.3) 15 (-9.4) 335.6 (98.4) 320.6 (94) 305.8 (89.6) 291.6 (85.5) 277.6 (81.4) 264.0 (77.4) 250.6 (73.4) 10 (-12.2) 302.2 (88.6) 288.6 (84.6) 275.4 (80.7) 262.6 (77) 249.8 (73.2) 237.4 (69.6) 225.2 (66)

5 (-15) 271.0 (79.4) 258.8 (75.8) 247.0 (72.4) 235.4 (69) 224.0 (65.6) 212.8 (62.4) 201.8 (59.1)

0 (-17.8) 242.4 (71) 231.6 (67.9) 221.0 (64.8) 210.8 (61.8) 200.6 (58.8) 190.4 (55.8) 180.6 (52.9)

30 (-1.1) 491.4 (144) 469.8 (137.7) 448.8 (131.5) 428.4 (125.6) 408.4 (119.7) 389.2 (114.1) 370.2 (108.5) 25 (-3.9) 449.4 (131.7) 429.4 (125.8) 410.0 (120.2) 391.4 (114.7) 373.0 (109.3) 355.2 (104.1) 337.8 (99) 20 (-6.7) 408.4 (119.7) 390.2 (114.4) 372.6 (109.2) 355.4 (104.2) 338.8 (99.3) 322.4 (94.5) 306.4 (89.8) 15 (-9.4) 369.0 (108.1) 352.4 (103.3) 336.4 (98.6) 321.0 (94.1) 305.8 (89.6) 291.0 (85.3) 276.4 (81) 10 (-12.2) 331.6 (97.2) 316.8 (92.8) 302.4 (88.6) 288.4 (84.5) 274.8 (80.5) 261.4 (76.6) 248.2 (72.7)

5 (-15) 296.8 (87) 283.6 (83.1) 270.8 (79.4) 258.4 (75.7) 246.2 (72.2) 234.0 (68.6) 222.0 (65.1)

0 (-17.8) 264.6 (77.5) 253.0 (74.1) 241.8 (70.9) 230.8 (67.6) 220.2 (64.5) 209.4 (61.4) 198.6 (58.2)

30 (-1.1) 590.0 (172.9) 564.4 (165.4) 539.2 (158) 514.4 (150.8) 489.6 (143.5) 465.0 (136.3) 440.4 (129.1) 25 (-3.9) 537.4 (157.5) 514.2 (150.7) 491.2 (144) 468.4 (137.3) 446.0 (130.7) 423.6

20 (-6.7) 487.6 (142.9) 466.4 (136.7) 445.6 (130.6) 425.0 (124.6) 404.6 (118.6) 384.4 (1 15 (-9.4) 440.4 (129.1) 421.4 (123.5) 402.6 (118) 384.0 (112.5) 365.6 (107.1) 347.4 (101.8) 329.4 (96.5) 10 (-12.2) 396.0 (116.1) 378.8 ( 111) 362.0 (106.1) 345.4 (101.2) 329.0 (96.4) 312.8 (91.7) 296.6 (86.9)

5 (-15) 354.4 (103.9) 339.2 (99.4) 324.2 (95) 309.4 (90.7) 294.8 (86.4) 280.6 (82.2) 266.2 (78)

0 (-17.8) 315.8 (92.6) 302.2 (88.6) 288.8 (84.6) 275.8 (80.8) 263.2 (77.1) 250.6 (73.4) 238.0 (69.8) 30 (-1.1) 745.2 (218.4) 714.6 (209.4) 683.8 (200.4) 652.8 (191.3) 622.0 (182.3) 590.8 (173.1) 559.6 (164) 25 (-3.9) 677.4 (198.5) 649.6 (190.4) 621.8 (182.2) 593.8 (174) 565.8 (165.8) 537.6 (157.6) 509.4 (149.3) 20 (-6.7) 614.2 (180) 589.0 (172.6) 563.8 (165.2) 538.4 (157.8) 513.0 (150.3) 487.6 (142.9) 462.2 (135.5) 15 (-9.4) 555.2 (162.7) 532.4 (156) 509.6 (149.3) 486.8 (142.7) 463.8 (135.9) 441.0 (129.2) 418.0 (122.5) 10 (-12.2) 500.4 (146.7) 479.8 (140.6) 459.2 (134.6) 438.6 (128.5) 417.8 (122.4) 397.2 (116.4) 376.6 (110.4)

5 (-15) 449.8 (131.8) 431.2 (126.4) 412.4 (120.9) 393.6 (115.4) 375.0 (109.9) 356.4 (104.5) 337.8 (99)

0 (-17.8) 403.4 (118.2) 386.2 (113.2) 369.0 (108.1) 352.0 (103.2) 335.2 (98.2) 318.2 (93.3) 301.4 (88.3) 30 (-1.1) 861.6 (252.5) 827.0 (242.4) 792.4 (232.2) 758.2 (222.2) 723.8 (212.1) 689.2 (202) 654.2 (191.7)

25 (-3.9) 787.8 (230.9) 755.8 (221.5) 724.4 (212.3) 693.0 (203.1) 661.6 (193.9) 630.0 (184.6) 598.0 (175.3) 20 (-6.7) 717.6 (210.3) 688.4 (201.7) 659.6 (193.3) 630.8 (184.9) 602.4 (176.5) 573.6 (168.1) 544.6 (159.6) 15 (-9.4) 651.4 (190.9) 624.6 (183.1) 598.2 (175.3) 572.2 (167.7) 546.4 (160.1) 520.4 (152.5) 494.0 (144.8) 10 (-12.2) 589.2 (172.7) 564.6 (165.5) 540.6 (158.4) 517.0 (151.5) 493.6 (144.7) 470.2 (137.8) 446.4 (130.8)

5 (-15) 530.8 (155.6) 508.4 (149) 486.6 (142.6) 465.2 (136.3) 444.2 (130.2) 423.2 (124) 402.0 (117.8)

0 (-17.8) 476.8 (139.7) 456.2 (133.7) 436.4 (127.9) 417.2 (122.3) 398.2 (116.7) 379.4 (111.2) 360.4 (105.6)

30 (-1.1) 1013.2 (296.9) 974.6 (285.6) 935.4 (274.1) 895.8 (262.5) 855.8 (250.8) 815.6 (239) 775.0 (227.1) 25 (-3.9) 928.4 (272.1) 893.0 (261.7) 856.8 (251.1) 820.4 (240.4) 783.6 (229.6) 746.4 (218.7) 709.0 (207.8) 20 (-6.7) 846.4 (248.1) 813.8 (238.5) 780.6 (228.8) 747.2 (219) 713.2 (209) 679.0 (199) 644.6 (188.9) 15 (-9.4) 767.8 (225) 738.0 (216.3) 707.6 (207.4) 677.0 (198.4) 645.8 (189.3) 614.6 (180.1) 583.0 (170.9) 10 (-12.2) 693.6 (203.3) 666.6 (195.4) 638.8 (187.2) 610.8 (179) 582.4 (170.7) 553.8 (162.3) 525.0 (153.9)

5 (-15) 625.2 (183.2) 600.4 (176) 575.2 (168.6) 549.6 (161.1) 523.8 (153.5) 497.6 (145.8) 471.4 (138.2)

0 (-17.8) 563.2 (165.1) 540.6 (158.4) 517.8 (151.8) 494.4 (144.9) 471.0 (138) 447.2 (131.1) 423.4 (124.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 11 0 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

(124.1) 401.2 (117.6)

12.7) 364.2 (106.7)

HIGH EFFICIENCY MODELS

COPELAND

09/03/14

T40-TV-PDS-19

- 68 -

CAPACITY DATA -

R404A

R507

LOW TEMP. HIGH EFFICIENCY MODELS

60HzTVD-A

CONDENSING

UNIT

MODEL

TVD021L6-A

Compressor

Model

3DS3F46KE

HIGH EFFICIENCY MODELS

TVD031L6-A

Compressor

Model

4DHNF63KE

TVD045L6-A

Compressor

Model

4DJNF76KE

TVD055L6-A

Compressor

Model

6DHNF93KE

TVD061L6-A

Compressor

Model

6DJNF11ME

TVD081L6-A

Compressor

Model

6DUNF13ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 182.2 (53.4) 175.0 (51.3) 168.0 (49.2) 160.8 (47.1) 153.8 (45.1) 147.0 (43.1) 140.2 (41.1)

-5 (-20.6) 164.4 (48.2) 158.0 (46.3) 151.6 (44.4) 145.2 (42.6) 138.8 (40.7) 132.6 (38.9) 126.6 (37.1)

-10 (-23.3) 147.6 (43.3) 142.0 (41.6) 136.2 (39.9) 130.4 (38.2) 124.8 (36.6) 119.0 (34.9) 113.6 (33.3)

-15 (-26.1) 131.8 (38.6) 126.8 (37.2) 121.6 (35.6) 116.4 (34.1) 111.2 (32.6) 106.2 (31.1) 101.0 (29.6)

-20 (-28.9) 117.0 (34.3) 112.6 (33) 108.0 (31.7) 103.2 (30.2) 98.6 (28.9) 93.8 (27.5) 89.2 (26.1)

-25 (-31.7) 103.2 (30.2) 99.2 (29.1) 95.2 (27.9) 90.8 (26.6) 86.6 (25.4) 82.2 (24.1) 78.2 (22.9)

-30 (-34.4) 90.6 (26.6) 87.0 (25.5) 83.2 (24.4) 79.2 (23.2) 75.4 (22.1) 71.4 (20.9) 67.6 (19.8)

-35 (-37.2) 78.8 (23.1) 75.6 (22.2) 72.0 (21.1) 68.4 (20) 64.8 (19) 61.2 (17.9) 57.6 (16.9)

-40 (-40) 68.2 (20) 65.2 (19.1) 61.8 (18.1) 58.6 (17.2) 55.2 (16.2) 51.6 (15.1) 48.2 (14.1) 0 (-17.8) 252.8 (74.1) 242.8 (71.2) 233.4 (68.4) 224.2 (65.7) 215.0 (63) 205.8 (60.3) 196.4 (57.6)

-5 (-20.6) 227.6 (66.7) 218.4 (64) 209.8 (61.5) 201.6 (59.1) 193.4 (56.7) 185.0 (54.2) 176.2 (51.6)

-10 (-23.3) 204.4 (59.9) 196.2 (57.5) 188.4 (55.2) 181.0 (53) 173.6 (50.9) 166.0 (48.6) 157.8 (46.2)

-15 (-26.1) 183.2 (53.7) 175.8 (51.5) 168.8 (49.5) 162.0 (47.5) 155.4 (45.5) 148.4 (43.5) 141.0 (41.3)

-20 (-28.9) 163.4 (47.9) 156.8 (46) 150.6 (44.1) 144.6 (42.4) 138.6 (40.6) 132.4 (38.8) 125.4 (36.8)

-25 (-31.7) 145.2 (42.6) 139.2 (40.8) 133.6 (39.2) 128.2 (37.6) 122.8 (36) 117.0 (34.3) 110.8 (32.5)

-30 (-34.4) 127.6 (37.4) 122.4 (35.9) 117.4 (34.4) 112.6 (33) 107.8 (31.6) 102.4 (30) 96.6 (28.3)

-35 (-37.2) 111.0 (32.5) 106.2 (31.1) 101.8 (29.8) 97.4 (28.5) 93.0 (27.3) 88.0 (25.8) 82.6 (24.2)

-40 (-40) 94.4 (27.7) 90.2 (26.4) 86.2 (25.3) 82.4 (24.1) 78.2 (22.9) 73.6 (21.6) 68.4 (20) 0 (-17.8) 299.0 (87.6) 285.4 (83.6) 272.6 (79.9) 260.4 (76.3) 248.6 (72.9) 237.6 (69.6) 227.2 (66.6)

-5 (-20.6) 271.0 (79.4) 258.8 (75.8) 247.2 (72.4) 236.0 (69.2) 225.2 (66) 215.0 (63) 205.4 (60.2)

-10 (-23.3) 244.6 (71.7) 233.6 (68.5) 223.0 (65.4) 212.8 (62.4) 203.0 (59.5) 193.6 (56.7) 184.6 (54.1)

-15 (-26.1) 219.8 (64.4) 209.8 (61.5) 200.2 (58.7) 191.0 (56) 182.0 (53.3) 173.2 (50.8) 164.6 (48.2)

-20 (-28.9) 196.2 (57.5) 187.4 (54.9) 178.6 (52.3) 170.2 (49.9) 161.8 (47.4) 153.6 (45) 145.4 (42.6)

-25 (-31.7) 173.8 (50.9) 165.8 (48.6) 158.0 (46.3) 150.2 (44) 142.6 (41.8) 134.8 (39.5) 127.0 (37.2)

-30 (-34.4) 152.4 (44.7) 145.4 (42.6) 138.4 (40.6) 131.2 (38.5) 123.8 (36.3) 116.4 (34.1) 108.8 (31.9)

-35 (-37.2) 132.2 (38.7) 125.8 (36.9) 119.4 (35) 1

-40 (-40) 112.6 (33) 107.0 (31.4) 101.0 (29.6) 94.6 (27.7) 87.8 (25.7) 80.8 (23.7) 73.2 (21.5) 0 (-17.8) 374.0 (109.6) 359.0 (105.2) 344.4 (100.9) 330.0 (96.7) 315.6 (92.5) 301.2 (88.3) --- ---

-5 (-20.6) 338.4 (99.2) 324.8 (95.2) 311.6 (91.3) 298.6 (87.5) 285.6 (83.7) 272.4 (79.8) 258.8 (75.8)

-10 (-23.3) 304.0 (89.1) 291.8 (85.5) 280.0 (82.1) 268.2 (78.6) 256.2 (75.1) 244.2 (71.6) 231.6 (67.9)

-15 (-26.1) 271.2 (79.5) 260.2 (76.3) 249.6 (73.2) 238.8 (70) 228.0 (66.8) 217.0 (63.6) 205.4 (60.2)

-20 (-28.9) 240.2 (70.4) 230.2 (67.5) 220.6 (64.7) 211.0 (61.8) 201.0 (58.9) 190.8 (55.9) 180.2 (52.8)

-25 (-31.7) 211.0 (61.8) 202.0 (59.2) 193.4 (56.7) 184.6 (54.1) 175.4 (51.4) 166.0 (48.6) 156.0 (45.7)

-30 (-34.4) 184.0 (53.9) 176.0 (51.6) 168.0 (49.2) 159.8 (46.8) 151.4 (44.4) 142.6 (41.8) 133.0 (39)

-35 (-37.2) 159.4 (46.7) 152.0 (44.5) 144.6 (42.4) 137.0 (40.2) 129.2 (37.9) 120.8 (35.4) 111.6 (32.7)

-40 (-40) 137.2 (40.2) 130.4 (38.2) 123.4 (36.2) 116.4 (34.1) 108.8 (31.9) 100.6 (29.5) 91.6 (26.8) 0 (-17.8) 412.6 (120.9) 394.4 (115.6) 376.6 (110.4) 359.2 (105.3) 342.0 (100.2) 325.2 (95.3) --- ---

-5 (-20.6) 372.8 (109.3) 356.6 (104.5) 340.4 (99.8) 324.6 (95.1) 309.2 (90.6) 294.0 (86.2) --- ---

-10 (-23.3) 335.0 (98.2) 320.4 (93.9) 306.2 (89.7) 291.8 (85.5) 278.0 (81.5) 264.2 (77.4) 251.0 (73.6)

-15 (-26.1) 299.4 (87.7) 286.4 (83.9) 273.6 (80.2) 260.8 (76.4) 248.2 (72.7) 235.8 (69.1) 223.8 (65.6)

-20 (-28.9) 266.0 (78) 254.4 (74.6) 242.8 (71.2) 231.4 (67.8) 219.8 (64.4) 208.6 (61.1) 197.6 (57.9)

-25 (-31.7) 234.8 (68.8) 224.4 (65.8) 214.0 (62.7) 203.6 (59.7) 193.0 (56.6) 182.8 (53.6) 172.6 (50.6)

-30 (-34.4) 205.8 (60.3) 196.6 (57.6) 187.0 (54.8) 177.4 (52) 167.8 (49.2) 158.2 (46.4) 148.6 (43.6)

-35 (-37.2) 179.2 (52.5) 170.6 (50) 161.8 (47.4) 152.8 (44.8) 143.8 (42.1) 134.8 (39.5) 125.6 (36.8)

-40 (-40) 154.6 (45.3) 146.8 (43) 138.4 (40.6) 129.8 (38) 121.2 (35.5) 112.4 (32.9) 103.6 (30.4) 0 (-17.8) 518.0 (151.8) 495.6 (145.2) 473.8 (138.9) 452.6 (132.6) 432.4 (126.7) 413.4 (121.2) --- ---

-5 (-20.6) 467.8 (137.1) 446.4 (130.8) 425.6 (124.7) 405.4 (118.8) 386.0 (113.1) 367.4 (107.7) --- ---

-10 (-23.3) 422.6 (123.9) 402.6 (118) 383.0 (112.2) 363.8 (106.6) 345.2 (101.2) 327.4 (96) 310.4 (91)

-15 (-26.1) 381.4 (111.8) 362.8 (106.3) 344.4 (100.9) 326.4 (95.7) 308.8 (90.5) 291.8 (85.5) 275.8 (80.8)

-20 (-28.9) 343.0 (100.5) 326.0 (95.5) 309.0 (90.6) 292.2 (85.6) 275.8 (80.8) 259.8 (76.1) 244.6 (71.7)

-25 (-31.7) 306.4 (89.8) 291.0 (85.3) 275.6 (80.8) 260.0 (76.2) 244.8 (71.7) 230.0 (67.4) 215.6 (63.2)

-30 (-34.4) 270.2 (79.2) 256.6 (75.2) 242.8 (71.2) 228.8 (67.1) 214.8 (63) 201.2 (59) 187.8 (55)

-35 (-37.2) 233.4 (68.4) 221.6 (64.9) 209.4 (61.4) 197.0 (57.7) 184.4 (54) 172.0 (50.4) 159.8 (46.8)

-40 (-40) 194.4 (57) 184.6 (54.1) 174.2 (51.1) 163.4 (47.9) 152.4 (44.7) 141.4 (41.4) 130.4 (38.2)

CAPACITY MBH (KW)

R404A R507

12.6 (33) 105.6 (30.9) 98.4 (28.8) 91.0 (26.7)

AMBIENT TEMPERATURE °F (°C)

--- Outside Operating Range

BITZER

09/03/14

T40-TV-PDS-19

- 69 -

CAPACITY DATA -

R407A

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS016H8-B

Compressor

4PES-15

TVS021H8-B

Compressor

4NES-20

TVS026H8-B

Compressor

4HE-25

TVS031H8-B

Compressor

4GE-30

TVS036H8-B

Compressor

6HE-35

TVS041H8-B

Compressor

6GE-40

TVS051H8-B

Compressor

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 212.1 (62.2) 203.9 (59.8) 195.7 (57.4) 187.5 (55) 179.4 (52.6) 171.3 (50.2) 163.1 (47.8) 40 (4.4) 192.6 (56.4) 185.0 (54.2) 177.5 (52) 169.9 (49.8) 162.3 (47.6) 154.9 (45.4) 147.3 (43.2) 35 (1.7) 174.3 (51.1) 167.4 (49.1) 160.4 (47) 153.4 (45) 146.5 (42.9) 139.5 (40.9) 132.6 (38.9) 45 (7.2) 248.5 (72.8) 239.2 (70.1) 229.7 (67.3) 220.4 (64.6) 210.9 (61.8) 201.6 (59.1) 192.2 (56.3) 40 (4.4) 226.0 (66.2) 217.2 (63.7) 208.5 (61.1) 199.9 (58.6) 191.2 (56) 182.5 (53.5) 173.9 (51) 35 (1.7) 204.8 (60) 196.7 (57.6) 188.7 (55.3) 180.7 (53) 172.7 (50.6) 164.7 (48.3) 156.8 (45.9) 45 (7.2) 318.3 (93.3) 306.1 (89.7) 294.0 (86.2) 281.9 (82.6) 269.9 (79.1) 257.8 (75.5) 245.8 (72) 40 (4.4) 289.4 (84.8) 278.1 (81.5) 266.9 (78.2) 255.7 (74.9) 244.5 (71.7) 233.4 (68.4) 222.3 (65.1) 35 (1.7) 262.3 (76.9) 251.9 (73.8) 241.5 (70.8) 231.2 (67.8) 220.8 (64.7) 210.5 (61.7) 200.3 (58.7) 45 (7.2) 371.7 (108.9) 357.9 (104.9) 344.2 (100.9) 330.5 (96.9) 316.9 (92.9) 303.2 (88.9) 289.7 (84.9) 40 (4.4) 338.4 (99.2) 325.7 (95.5) 313.0 (91.7) 300.3 (88) 287.6 (84.3) 275.0 (80.6) 262.5 (76.9) 35 (1.7) 307.1 (90) 295.4 (86.6) 283.7 (83.1) 272.0 (79.7) 260.3 (76.3) 248.6 (72.9) 237.1 (69.5) 45 (7.2) 484.5 (142) 466.4 (136.7) 448.5 (131.4) 430.4 (126.1) 412.4 (120.9) 394.6 (115.6) 376.7 (110.4) 40 (4.4) 441.0 (129.2) 424.3 (124.4) 407.6 (119.5) 390.9 (114.6) 374.3 (109.7) 357.7 (104.8) 341.3 (100) 35 (1.7) 400.2 (117.3) 384.7 (112.7) 369.3 (108.2) 354.0 (103.7) 338.6 (99.2) 323.3 (94.7) 308.1 (90.3) 45 (7.2) 557.0 (163.2) 536.4 (157.2) 515.9 (151.2) 495.4 (145.2) 474.8 (139.2) 454.4 (133.2) 434.1 (127.2) 40 (4.4) 507.2 (148.6) 488.0 (143) 469.0 (137.5) 450.0 (131.9) 431.0 (126.3) 412.1 (120.8) 393.3 (115.3) 35 (1.7) 460.3 (134.9) 442.8 (129.8) 425.1 (124.6) 407.6 (119.5) 390.1 (114.3) 372.6 (109.2) 355.3 (104.1) 45 (7.2) 645.0 (189) 620.9 (182) 596.8 (174.9) 572.8 (167.9) 548.8 (160.8) 524.9 (153.8) 501.1 (146.8) 40 (4.4) 588.3 (172.4) 565.8 (165.8) 543.5 (159.3) 521.2 (152.8) 499.0 (146.2) 476.8 (139.7) 454.8 (133.3) 35 (1.7) 534.8 (156.7) 514.1 (150.7) 493.4 (144.6) 472.8 (138.6) 452.2 (132.5) 431.8 (126.5) 411.4 (120.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

HIGH EFFICIENCY MODELS

BITZER

09/03/14

T40-TV-PDS-19

- 70 -

CAPACITY DATA -

R407A

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS016M8-B

Compressor

Model

4PES-15

TVS021M8-B

HIGH EFFICIENCY MODELS

Compressor

Model

4NES-20

TVS026M8-B

Compressor

Model

4HE-25

TVS031M8-B

Compressor

Model

4GE-30

TVS036M8-B

Compressor

Model

6HE-35

TVS041M8-B

Compressor

Model

6GE-40

TVS051M8-B

Compressor

Model

6FE-50

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 157.3 (46.1) 150.9 (44.2) 144.5 (42.3) 138.1 (40.5) 131.7 (38.6) 125.3 (36.7) 119.0 (34.9) 25 (-3.9) 141.3 (41.4) 135.5 (39.7) 129.6 (38) 123.8 (36.3) 117.9 (34.6) 112.0 (32.8) 106.3 (31.1) 20 (-6.7) 126.5 (37.1) 121.2 (35.5) 115.8 (33.9) 110.5 (32.4) 105.2 (30.8) 99.9 (29.3) 94.5 (27.7) 15 (-9.4) 112.8 (33) 107.9 (31.6) 103.1 (30.2) 98.3 (28.8) 93.3 (27.4) 88.5 (25.9) 83.7 (24.5) 10 (-12.2) 100.1 (29.3) 95.7 (28) 91.2 (26.7) 86.9 (25.5) 82.5 (24.2) 78.1 (22.9) 73.7 (21.6)

5 (-15) 88.4 (25.9) 84.4 (24.7) 80.4 (23.6) 76.4 (22.4) 72.5 (21.2) 68.6 (20.1) 64.6 (18.9)

0 (-17.8) 77.6 (22.7) 74.0 (21.7) 70.5 (20.6) 66.9 (19.6) 63.2 (18.5) 59.7 (17.5) 56.2 (16.5) 30 (-1.1) 184.9 (54.2) 177.6 (52) 170.2 (49.9) 162.9 (47.7) 155.5 (45.6) 148.2 (43.4) 140.8 (41.3) 25 (-3.9) 166.3 (48.7) 159.6 (46.8) 152.9 (44.8) 146.3 (42.9) 139.5 (40.9) 132.8 (38.9) 126.1 (37) 20 (-6.7) 149.1 (43.7) 143.0 (41.9) 136.9 (40.1) 130.8 (38.3) 124.7 (36.6) 118.5 (34.7) 112.5 (33) 15 (-9.4) 133.1 (39) 127.6 (37.4) 122.1 (35.8) 116.6 (34.2) 111 .0 (32.5) 105.4 (30.9) 100.0 (29.3) 10 (-12.2) 118.4 (34.7) 113.4 (33.2) 108.4 (31.8) 103.3 (30.3) 98.3 (28.8) 93.3 (27.4) 88.3 (25.9)

5 (-15) 104.8 (30.7) 100.3 (29.4) 95.8 (28.1) 91.1 (26.7) 86.6 (25.4) 82.1 (24.1) 77.6 (22.7)

0 (-17.8) 92.2 (27) 88.2 (25.8) 84.1 (24.6) 80.0 (23.4) 75.9 (22.2) 71.8 (21) 67.8 (19.9) 30 (-1.1) 237.0 (69.5) 227.4 (66.7) 217.8 (63.8) 208.3 (61.1) 198.8 (58.3) 189.3 (55.5) 179.9 (52.7) 25 (-3.9) 213.3 (62.5) 204.5 (59.9) 195.7 (57.4) 186.9 (54.8) 178.2 (52.2) 169.6 (49.7) 160.9 (47.1) 20 (-6.7) 191.2 (56) 183.1 (53.7) 175.1 (51.3) 167.2 (49) 159.2 (46.7) 151.2 (44.3) 143.3 (42) 15 (-9.4) 170.7 (50) 163.4 (47.9) 156.0 (45.7) 148.7 (43.6) 141.4 (41.5) 134.2 (39.3) 127.1 (37.2) 10 (-12.2) 151.6 (44.4) 145.0 (42.5) 138.3 (40.5) 131.7 (38.6) 125.1 (36.6) 118.5 (34.7) 111.9 (32.8)

5 (-15) 134.0 (39.3) 128.0 (37.5) 121.9 (35.7) 115.9 (34) 109.9 (32.2) 104.0 (30.5) 98.1 (28.7)

0 (-17.8) 117.7 (34.5) 112.2 (32.9) 106.8 (31.3) 101.3 (29.7) 95.9 (28.1) 90.5 (26.5) 85.2 (25) 30 (-1.1) 237.0 (69.5) 227.4 (66.7) 217.8 (63.8) 208.3 (61.1) 198.8 (58.3) 189.3 (55.5) 179.9 (52.7) 25 (-3.9) 213.3 (62.5) 204.5 (59.9) 195.7 (57.4) 186.9 (54.8) 178.2 (52.2) 169.6 20 (-6.7) 191.2 (56) 183.1 (53.7) 175.1 (51.3) 167.2 (49) 159.2 (46.7) 151.2 (44.3) 143.3 (42) 15 (-9.4) 170.7 (50) 163.4 (47.9) 156.0 (45.7) 148.7 (43.6) 141.4 (41.5) 134.2 (39.3) 127.1 (37.2) 10 (-12.2) 151.6 (44.4) 145.0 (42.5) 138.3 (40.5) 131.7 (38.6) 125.1 (36.6) 118.5 (34.7) 111.

5 (-15) 134.0 (39.3) 128.0 (37.5) 121.9 (35.7) 115.9 (34) 109.9 (32.2) 104.0 (30.5) 98.1 (28.7)

0 (-17.8) 117.7 (34.5) 112.2 (32.9) 106.8 (31.3) 101.3 (29.7) 95.9 (28.1) 90.5 (26.5) 85.2 (25) 30 (-1.1) 361.9 (106.1) 347.8 (101.9) 333.6 (97.8) 319.4 (93.6) 305.3 (89.5) 291.3 (85.4) 277.3 (81.3) 25 (-3.9) 326.2 (95.6) 313.2 (91.8) 300.2 (88) 287.3 (84.2) 274.4 (80.4) 261.5 (76.6) 248.6 (72.9) 20 (-6.7) 293.0 (85.9) 281.1 (82.4) 269.2 (78.9) 257.4 (75.4) 245.5 (71.9) 233.7 (68.5) 222.1 (65.1) 15 (-9.4) 262.0 (76.8) 251.2 (73.6) 240.3 (70.4) 229.5 (67.3) 218.8 (64.1) 208.1 (61) 197.5 (57.9) 10 (-12.2) 233.2 (68.3) 223.4 (65.5) 213.6 (62.6) 203.8 (59.7) 194.0 (56.9) 184.4 (54) 174.7 (51.2)

5 (-15) 206.6 (60.6) 197.7 (57.9) 188.8 (55.3) 180.0 (52.7) 171.2 (50.2) 162.4 (47.6) 153.7 (45.1)

0 (-17.8) 182.0 (53.3) 173.9 (51) 165.9 (48.6) 157.9 (46.3) 150.0 (44) 142.1 (41.6) 134.3 (39.4) 30 (-1.1) 416.5 (122.1) 400.3 (117.3) 384.1 (112.6) 368.0 (107.9) 351.9 (103.1) 335.9 (98.4) 319.9 (93.8) 25 (-3.9) 375.6 (110.1) 360.7 (105.7) 345.9 (101.4) 331.1 (97) 316.4 (92.7) 301.7 (88.4) 287.1 (84.1) 20 (-6.7) 337.4 (98.9) 323.8 (94.9) 310.3 (90.9) 296.7 (87) 283.3 (83) 270.0 (79.1) 256.5 (75.2) 15 (-9.4) 301.9 (88.5) 289.5 (84.8) 277.2 (81.2) 264.9 (77.6) 252.6 (74) 240.5 (70.5) 228.4 (66.9) 10 (-12.2) 268.9 (78.8) 257.7 (75.5) 246.5 (72.3) 235.4 (69) 224.3 (65.7) 213.3 (62.5) 202.2 (59.3)

5 (-15) 238.4 (69.9) 228.2 (66.9) 218.1 (63.9) 208.0 (61) 198.0 (58) 188.1 (55.1) 178.1 (52.2)

0 (-17.8) 210.1 (61.6) 201.0 (58.9) 191.8 (56.2) 182.7 (53.5) 173.7 (50.9) 164.7 (48.3) 155.8 (45.7) 30 (-1.1) 484.6 (142) 465.5 (136.4) 446.5 (130.8) 427.5 (125.3) 408.6 (119.7) 389.7 (114.2) 371.0 (108.7) 25 (-3.9) 437.5 (128.2) 420.0 (123.1) 402.6 (118) 385.1 (112.9) 367.7 (107.8) 350.5 (102.7) 333.3 (97.7) 20 (-6.7) 393.5 (115.3) 377.5 (110.6) 361.5 (105.9) 345.7 (101.3) 329.8 (96.7) 314.0 (92) 298.3 (87.4) 15 (-9.4) 352.5 (103.3) 338.0 (99.1) 323.4 (94.8) 308.9 (90.5) 294.5 (86.3) 280.1 (82.1) 265.8 (77.9) 10 (-12.2) 314.4 (92.1) 301.1 (88.3) 287.9 (84.4) 274.8 (80.5) 261.7 (76.7) 248.6 (72.9) 235.7 (69.1)

5 (-15) 279.0 (81.8) 267.0 (78.3) 255.0 (74.7) 243.2 (71.3) 231.3 (67.8) 219.6 (64.3) 207.8 (60.9)

0 (-17.8) 246.1 (72.1) 235.3 (69) 224.6 (65.8) 213.8 (62.7) 203.2 (59.5) 192.6 (56.4) 182.0 (53.3)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 11 5 (46.1)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

(49.7) 160.9 (47.1)

9 (32.8)

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

BITZER

09/03/14

T40-TV-PDS-19

- 71 -

CAPACITY DATA -

R407A

LOW TEMP. HIGH EFFICIENCY MODELS

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS013L8-B

Compressor

Model

4NES-14

TVS016L8-B

Compressor

Model

4HE-18

TVS021L8-B

Compressor

Model

4GE-23

TVS026L8-B

Compressor

Model

6HE-28

TVS031L8-B

Compressor

Model

6GE-34

TVS041L8-B

Compressor

Model

6FE-44

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 85.5 (25) 81.5 (23.9) 77.5 (22.7) 73.6 (21.6) 69.7 (20.4) 65.8 (19.3) 62.1 (18.2)

-5 (-20.6) 75.1 (22) 71.5 (21) 67.9 (19.9) 64.4 (18.9) 60.9 (17.8) 57.4 (16.8) 54.0 (15.8)

-10 (-23.3) 65.5 (19.2) 62.3 (18.2) 59.1 (17.3) 55.9 (16.4) 52.7 (15.4) 49.7 (14.6) 46.5 (13.6)

-15 (-26.1) 56.7 (16.6) 53.8 (15.8) 50.9 (14.9) 48.1 (14.1) 45.3 (13.3) 42.4 (12.4) 39.7 (11.6)

-20 (-28.9) 48.5 (14.2) 45.9 (13.4) 43.4 (12.7) 40.8 (12) 38.3 (11.2) 35.8 (10.5) 33.4 (9.8)

-25 (-31.7) 41.1 (12) 38.6 (11.3) 36.4 (10.7) 34.1 (10) 31.8 (9.3) 29.6 (8.7) 27.5 (8.1)

-30 (-34.4) 34.1 (10) 32.0 (9.4) 29.9 (8.8) 27.9 (8.2) 25.9 (7.6) 23.9 (7) 22.1 (6.5)

-35 (-37.2) 27.7 (8.1) 25.8 (7.6) 23.9 (7) 22.2 (6.5) 20.4 (6) 18.6 (5.4) 16.9 (5)

-40 (-40) 21.7 (6.4) 20.1 (5.9) 18.5 (5.4) 16.8 (4.9) 15.2 (4.5) 13.7 (4) 12.1 (3.5) 0 (-17.8) 118.3 (34.7) 113.1 (33.1) 107.9 (31.6) 102.8 (30.1) 97.7 (28.6) 92.6 (27.1) 87.7 (25.7)

-5 (-20.6) 104.0 (30.5) 99.2 (29.1) 94.5 (27.7) 89.9 (26.3) 85.3 (25) 80.7 (23.7) 76.3 (22.4)

-10 (-23.3) 90.6 (26.6) 86.4 (25.3) 82.1 (24.1) 78.0 (22.9) 73.8 (21.6) 69.8 (20.5) 65.8 (19.3)

-15 (-26.1) 78.2 (22.9) 74.4 (21.8) 70.7 (20.7) 67.0 (19.6) 63.3 (18.6) 59.6 (17.5) 56.1 (16.4)

-20 (-28.9) 66.8 (19.6) 63.4 (18.6) 60.1 (17.6) 56.7 (16.6) 53.4 (15.7) 50.2 (14.7) 47.1 (13.8)

-25 (-31.7) 56.2 (16.5) 53.1 (15.6) 50.2 (14.7) 47.3 (13.8) 44.3 (13) 41.5 (12.2) 38.7 (11.4)

-30 (-34.4) 46.2 (13.5) 43.6 (12.8) 41.0 (12) 38.3 (11.2) 35.8 (10.5) 33.3 (9.8) 30.9 (9)

-35 (-37.2) 37.0 (10.8) 34.7 (10.2) 32.3 (9.5) 30.0 (8.8) 27.7 (8.1) 25.5 (7.5) 23.4 (6.9)

-40 (-40) 28.2 (8.3) 26.3 (7.7) 24.2 (7.1) 22.2 (6.5) 20.2 (5.9) 18.3 (5.4) 16.4 (4.8) 0 (-17.8) 137.2 (40.2) 131.5 (38.5) 125.7 (36.8) 120.0 (35.2) 114.5 (33.5) 108.9 (31.9) 103.4 (30.3)

-5 (-20.6) 121.2 (35.5) 115.9 (34) 110.8 (32.5) 105.6 (31) 100.6 (29.5) 95.7 (28) 90.7 (26.6)

-10 (-23.3) 106.2 (31.1) 101.5 (29.8) 96.9 (28.4) 92.3 (27) 87.8 (25.7) 83.4 (24.4) 79.0 (23.1)

-15 (-26.1) 92.3 (27) 88.1 (25.8) 84.0 (24.6) 79.9 (23.4) 75.9 (22.2) 71.9 (21.1) 68.0 (19.9)

-20 (-28.9) 79.4 (23.3) 75.6 (22.2) 72.0 (21.1) 68.4 (20) 64.8 (19) 61.3 (18) 57.9 (17)

-25 (-31.7) 67.3 (19.7) 64.1 (18.8) 60.8 (17.8) 57.6 (16.9) 54.5 (16) 51.3 (15) 48.4 (14.2)

-30 (-34.4) 56.1 (16.4) 53.1 (15.6) 50.3 (14.7) 47.5 (13.9) 44.7 (13.1) 42.0 (12.3) 39.4 (11.5)

-35 (-37.2) 45.5 (13.3) 42.9 (12.6) 40.4 (11.8) 38.0 (1

-40 (-40) 35.6 (10.4) 33.3 (9.8) 31.2 (9.1) 29.0 (8.5) 26.9 (7.9) 24.8 (7.3) 22.8 (6.7) 0 (-17.8) 171.6 (50.3) 163.9 (48) 156.2 (45.8) 148.7 (43.6) 141.2 (41.4) 133.9 (39.2) 126.6 (37.1)

-5 (-20.6) 151.1 (44.3) 144.1 (42.2) 137.2 (40.2) 130.4 (38.2) 123.7 (36.2) 117.1 (34.3) 110.6 (32.4)

-10 (-23.3) 132.0 (38.7) 125.7 (36.8) 119.5 (35) 113.4 (33.2) 107.3 (31.4) 101.4 (29.7) 95.6 (28)

-15 (-26.1) 114.1 (33.4) 108.6 (31.8) 103.0 (30.2) 97.5 (28.6) 92.1 (27) 86.8 (25.4) 81.6 (23.9)

-20 (-28.9) 97.7 (28.6) 92.6 (27.1) 87.7 (25.7) 82.7 (24.2) 78.0 (22.9) 73.3 (21.5) 68.7 (20.1)

-25 (-31.7) 82.2 (24.1) 77.7 (22.8) 73.4 (21.5) 69.0 (20.2) 64.8 (19) 60.6 (17.8) 56.5 (16.6)

-30 (-34.4) 67.8 (19.9) 63.8 (18.7) 60.0 (17.6) 56.2 (16.5) 52.4 (15.4) 48.7 (14.3) 45.2 (13.2)

-35 (-37.2) 54.3 (15.9) 50.8 (14.9) 47.4 (13.9) 44.0 (12.9) 40.6 (11.9) 37.5 (11) 34.3 (10.1)

-40 (-40) 41.6 (12.2) 38.4 (11.3) 35.5 (10.4) 32.4 (9.5) 29.5 (8.6) 26.7 (7.8) 23.9 (7) 0 (-17.8) 193.3 (56.7) 184.6 (54.1) 176.1 (51.6) 167.6 (49.1) 159.2 (46.7) 150.9 (44.2) 142.8 (41.9)

-5 (-20.6) 170.5 (50) 162.8 (47.7) 155.0 (45.4) 147.3 (43.2) 139.8 (41) 132.3 (38.8) 125.0 (36.6)

-10 (-23.3) 149.3 (43.8) 142.3 (41.7) 135.2 (39.6) 128.3 (37.6) 121.6 (35.6) 114.9 (33.7) 108.4 (31.8)

-15 (-26.1) 129.5 (37.9) 123.2 (36.1) 116.9 (34.2) 110.7 (32.4) 104.6 (30.6) 98.7 (28.9) 92.8 (27.2)

-20 (-28.9) 110.9 (32.5) 105.3 (30.9) 99.8 (29.2) 94.2 (27.6) 88.8 (26) 83.5 (24.5) 78.3 (23)

-25 (-31.7) 93.6 (27.4) 88.6 (26) 83.7 (24.5) 78.8 (23.1) 74.0 (21.7) 69.3 (20.3) 64.8 (19)

-30 (-34.4) 77.4 (22.7) 73.0 (21.4) 68.6 (20.1) 64.3 (18.8) 60.1 (17.6) 56.0 (16.4) 51.9 (15.2)

-35 (-37.2) 62.2 (18.2) 58.2 (17) 54.4 (15.9) 50.5 (14.8) 46.8 (13.7) 43.3 (12.7) 39.7 (11.6)

-40 (-40) 47.8 (14) 44.3 (13) 40.8 (12) 37.5 (11) 34.2 (10) 31.1 (9.1) 28.0 (8.2) 0 (-17.8) 235.9 (69.1) 225.5 (66.1) 215.4 (63.1) 205.3 (60.2) 195.2 (57.2) 185.3 (54.3) 175.7 (51.5)

-5 (-20.6) 208.2 (61) 198.9 (58.3) 189.6 (55.6) 180.5 (52.9) 171.5 (50.3) 162.5 (47.6) 153.8 (45.1)

-10 (-23.3) 182.3 (53.4) 174.0 (51) 165.7 (48.6) 157.5 (46.2) 149.3 (43.8) 141.4 (41.5) 133.6 (39.1)

-15 (-26.1) 158.2 (46.4) 150.8 (44.2) 143.3 (42) 136.0 (39.9) 128.7 (37.7) 121.7 (35.7) 114.8 (33.6)

-20 (-28.9) 135.8 (39.8) 129.0 (37.8) 122.5 (35.9) 116.0 (34) 109.5 (32.1) 103.3 (30.3) 97.1 (28.5)

-25 (-31.7) 1

-30 (-34.4) 95.2 (27.9) 90.0 (26.4) 84.7 (24.8) 79.7 (23.4) 74.8 (21.9) 69.8 (20.5) 65.1 (19.1)

-35 (-37.2) 76.8 (22.5) 72.1 (21.1) 67.6 (19.8) 63.1 (18.5) 58.7 (17.2) 54.5 (16) 50.3 (14.7)

-40 (-40) 59.4 (17.4) 55.3 (16.2) 51.3 (15) 47.4 (13.9) 43.5 (12.7) 39.8 (11.7) 36.1 (10.6)

14.8 (33.6) 108.9 (31.9) 103.0 (30.2) 97.2 (28.5) 91.6 (26.8) 86.0 (25.2) 80.6 (23.6)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

1.1) 35.6 (10.4) 33.2 (9.7) 31.0 (9.1)

HIGH EFFICIENCY MODELS

BITZER

09/03/14

T40-TV-PDS-19

- 72 -

CAPACITY DATA -

R407C

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS016H8-B

Compressor

Model

4PES-15

TVS021H8-B

Compressor

Model

HIGH EFFICIENCY MODELS

4NES-20

TVS026H8-B

Compressor

Model

4HE-25

TVS031H8-B

Compressor

Model

4GE-30

TVS036H8-B

Compressor

Model

6HE-35

TVS041H8-B

Compressor

Model

6GE-40

TVS051H8-B

Compressor

Model

6FE-50

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 247.5 (72.5) 238.5 (69.9) 229.3 (67.2) 220.2 (64.5) 211.1 (61.9) 201.8 (59.1) 192.6 (56.4) 50 (10) 225.9 (66.2) 217.5 (63.7) 209.0 (61.2) 200.4 (58.7) 191.9 (56.3) 183.4 (53.8) 174.8 (51.2) 45 (7.2) 205.4 (60.2) 197.6 (57.9) 189.8 (55.6) 182.1 (53.4) 174.2 (51.1) 166.3 (48.7) 158.3 (46.4) 40 (4.4) 186.3 (54.6) 179.1 (52.5) 171.9 (50.4) 164.7 (48.3) 157.5 (46.2) 150.3 (44) 142.9 (41.9) 35 (1.7) 168.3 (49.3) 161.8 (47.4) 155.2 (45.5) 148.6 (43.5) 142.0 (41.6) 135.3 (39.7) 128.6 (37.7) 55 (12.8) 289.6 (84.9) 279.1 (81.8) 268.7 (78.7) 258.1 (75.6) 247.6 (72.6) 237.0 (69.5) 226.3 (66.3) 50 (10) 264.4 (77.5) 254.7 (74.7) 245.0 (71.8) 235.3 (69) 225.4 (66.1) 215.7 (63.2) 205.8 (60.3) 45 (7.2) 240.7 (70.5) 231.7 (67.9) 222.8 (65.3) 213.8 (62.7) 204.8 (60) 195.7 (57.4) 186.6 (54.7) 40 (4.4) 218.4 (64) 210.2 (61.6) 202.0 (59.2) 193.7 (56.8) 185.4 (54.3) 177.0 (51.9) 168.7 (49.5) 35 (1.7) 197.6 (57.9) 190.1 (55.7) 182.6 (53.5) 174.9 (51.3) 167.4 (49.1) 159.7 (46.8) 152.0 (44.6) 55 (12.8) 381.8 (111.9) 368.4 (108) 355.0 (104) 341.6 (100.1) 328.1 (96.2) 314.6 (92.2) 301.0 (88.2) 50 (10) 348.6 (102.2) 336.2 (98.5) 323.9 (94.9) 311.4 (91.3) 298.9 (87.6) 286.4 (83.9) 273.9 (80.3) 45 (7.2) 317.3 (93) 306.0 (89.7) 294.5 (86.3) 283.1 (83) 271.6 (79.6) 260.1 (76.2) 248.5 (72.8) 40 (4.4) 287.9 (84.4) 277.5 (81.3) 267.0 (78.3) 256.5 (75.2) 246.0 (72.1) 235.4 (69) 224.8 (65.9) 35 (1.7) 260.4 (76.3) 250.8 (73.5) 241.3 (70.7) 231.6 (67.9) 222.0 (65.1) 212.3 (62.2) 202.7 (59.4) 55 (12.8) 445.7 (130.6) 430.6 (126.2) 415.4 (121.7) 400.2 (117.3) 384.8 (112.8) 369.5 (108.3) 354.1 (103.8) 50 (10) 407.4 (119.4) 393.4 (115.3) 379.5 (111.2) 365.4 (107.1) 351.2 (102.9) 337.1 (98.8) 322.8 (94.6) 45 (7.2) 371.3 (108.8) 358.5 (105.1) 345.6 (101.3) 332.6 (97.5) 319.6 (93.7) 306.6 (89.9) 293.5 (86) 40 (4.4) 337.4 (98.9) 325.6 (95.4) 313.7 (91.9) 302.0 (88.5) 290.0 (85) 278.0 (81.5) 266.1 (78) 35 (1.7) 305.6 (89.5) 294.8 (86.4) 284.0 (83.2) 273.2 (80.1) 262.3 (76.9) 251.4 (73.7) 240.5 (70.5) 55 (12.8) 557.3 (163.3) 538.1 (157.7) 518.6 (152) 499.0 (146.2) 479.1 (140.4) 459.2 (134.6) 439.1 (128.7) 50 (10) 508.6 (149.1) 490.8 (143.8) 472.8 (138.6) 454.7 (133.2) 436.4 (127.9) 417.9 (122.5) 399.3 (117) 45 (7.2) 462.8 (135.6) 446.5 (130.8) 429.9 (126) 413.2 (121.1) 396.4 (116.2) 379.4 (11 40 (4.4) 419.9 (123.1) 404.9 (118.7) 389.7 (114.2) 374.4 (109.7) 359.0 (105.2) 343.4 (100.6) 327.7 (96) 35 (1.7) 379.8 (111.3) 366.0 (107.3) 352.3 (103.2) 338.2 (99.1) 324.1 (95) 310.0 (90.8) 295.6 (86.6) 55 (12.8) 649.5 (190.4) 627.6 (183.9) 605.4 (177.4) 583.2 (170.9) 560.6 (164.3) 537.9 (157.6) 515.1 (151) 50 (10) 593.4 (173.9) 573.1 (168) 552.7 (162) 532.1 (156) 511.4 (149.9) 490.5 (143.7) 469.4 (137.6)

45 (7.2) 540.5 (158.4) 522.0 (153) 503.2 (147.5) 484.3 (141.9) 465.2 (136.3) 445.9 (130.7) 426.6 (125) 40 (4.4) 491.0 (143.9) 474.0 (138.9) 456.9 (133.9) 439.5 (128.8) 422.1 (123.7) 404.5 (118.5) 386.8 (113.4) 35 (1.7) 444.7 (130.3) 429.2 (125.8) 413.6 (121.2) 397.8 (116.6) 381.9 (111.9) 365.9 (107.2) 349.8 (102.5) 55 (12.8) 747.3 (219) 721.1 (211.3) 694.8 (203.6) 668.2 (195.8) 641.6 (188) 614.7 (180.1) 587.6 (172.2) 50 (10) 683.4 (200.3) 659.3 (193.2) 634.9 (186.1) 610.4 (178.9) 585.7 (171.6) 560.8 (164.4) 535.7 (157) 45 (7.2) 623.2 (182.6) 600.9 (176.1) 578.6 (169.6) 555.9 (162.9) 533.1 (156.2) 510.2 (149.5) 487.1 (142.8) 40 (4.4) 566.5 (166) 546.1 (160) 525.5 (154) 504.8 (148) 483.8 (141.8) 462.8 (135.6) 441.7 (129.5) 35 (1.7) 513.3 (150.4) 494.8 (145) 476.0 (139.5) 457.0 (133.9) 437.9 (128.3) 418.6 (122.7) 399.3 (117)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

1.2) 362.3 (106.2)

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

BITZER

09/03/14

T40-TV-PDS-19

- 73 -

CAPACITY DATA -

R407C

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS016M8-B

Compressor

Model

4PES-15

TVS021M8-B

Compressor

Model

4NES-20

TVS026M8-B

Compressor

Model

4HE-25

TVS031M8-B

Compressor

Model

4GE-30

TVS036M8-B

Compressor

Model

6HE-35

TVS041M8-B

Compressor

Model

6GE-40

TVS051M8-B

Compressor

Model

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 30 (-1.1) 151.6 (44.4) 145.6 (42.7) 139.7 (40.9) 133.6 (39.1) 127.6 (37.4) 121.5 (35.6) 115.3 (33.8) 25 (-3.9) 136.0 (39.9) 130.6 (38.3) 125.2 (36.7) 119.6 (35) 114.1 (33.4) 108.6 (31.8) 103.0 (30.2) 20 (-6.7) 121.6 (35.6) 116.7 (34.2) 111.7 (32.7) 106.7 (31.3) 101.7 (29.8) 96.7 (28.3) 91.6 (26.8) 15 (-9.4) 108.2 (31.7) 103.7 (30.4) 99.2 (29.1) 94.7 (27.8) 90.2 (26.4) 85.7 (25.1) 81.1 (23.8) 10 (-12.2) 95.9 (28.1) 91.8 (26.9) 87.8 (25.7) 83.7 (24.5) 79.6 (23.3) 75.5 (22.1) 71.3 (20.9)

30 (-1.1) 178.2 (52.2) 171.4 (50.2) 164.4 (48.2) 157.5 (46.2) 150.6 (44.1) 143.6 (42.1) 136.6 (40) 25 (-3.9) 160.0 (46.9) 153.8 (45.1) 147.6 (43.3) 141.3 (41.4) 135.0 (39.6) 128.6 (37.7) 122.2 (35.8) 20 (-6.7) 143.3 (42) 137.7 (40.3) 132.0 (38.7) 126.3 (37) 120.5 (35.3) 114.8 (33.6) 109.0 (31.9) 15 (-9.4) 127.7 (37.4) 122.6 (35.9) 117.5 (34.4) 112.4 (32.9) 107.2 (31.4) 102.0 (29.9) 96.7 (28.3) 10 (-12.2) 113.3 (33.2) 108.8 (31.9) 104.2 (30.5) 99.4 (29.1) 94.8 (27.8) 90.1 (26.4) 85.4 (25) 30 (-1.1) 234.7 (68.8) 226.0 (66.2) 217.2 (63.7) 208.4 (61.1) 199.6 (58.5) 190.8 (55.9) 182.0 (53.3) 25 (-3.9) 210.7 (61.8) 202.8 (59.4) 194.9 (57.1) 186.8 (54.7) 178.8 (52.4) 170.8 (50.1) 162.8 (47.7) 20 (-6.7) 188.5 (55.2) 181.2 (53.1) 174.0 (51) 166.7 (48.9) 159.5 (46.7) 152.1 (44.6) 144.9 (42.5) 15 (-9.4) 167.8 (49.2) 161.3 (47.3) 154.7 (45.3) 148.1 (43.4) 141.4 (41.5) 134.9 (39.5) 128.3 (37.6) 10 (-12.2) 148.7 (43.6) 142.7 (41.8) 136.7 (40.1) 130.7 (38.3) 124.8 (36.6) 118.9 (34.8) 113.0 (33.1) 30 (-1.1) 275.8 (80.8) 266.1 (78) 256.2 (75.1) 246.3 (72.2) 236.5 (69.3) 226.6 (66.4) 216.6 (63.5) 25 (-3.9) 248.1 (72.7) 239.2 (70.1) 230.4 (67.5) 221.3 (64.9) 212.4 (62.3) 203.4 (59.6) 194.4 (57) 20 (-6.7) 222.4 (65.2) 214.3 (62.8) 206.2 (60.4) 198.1 (58.1) 189.9 (55.7) 181.9 (53.3) 173.7 (50.9) 15 (-9.4) 198.5 (58.2) 191.1 (56) 183.9 (53.9) 176.5 (51.7) 169.2 (49.6) 161.8 (47.4) 154.5 (45.3) 10 (-12.2) 176.3 (51.7) 169.7 (49.7) 163.1 (47.8) 156.5 (45.9) 149.8 (43.9) 143.2 (42) 136.5 (40) 30 (-1.1) 342.4 (100.3) 329.9 (96.7) 317.3 (93) 304.6 (89.3) 291.8 (85.5) 278.8 (81.7) 265.9 (77.9) 25 (-3.9) 307.7 (90.2) 296.3 (86.8) 285.0 (83.5) 273.4 (80.1) 261.8 (76.7) 250.0 (73.3) 238.2 (69.8)

20 (-6.7) 275.4 (80.7) 265.2 (77.7) 254.9 (74.7) 244.4 (71.6) 233.9 (68.6) 223.3 (65.5) 212.7 (62.3) 15 (-9.4) 245.6 (72) 236.4 (69.3) 227.1 (66.6) 217.7 (63.8) 208.2 (61) 198.8 (58.3) 189.2 (55.5) 10 (-12.2) 218.0 (63.9) 209.8 (61.5) 201.4 (59) 193.0 (56.6) 184.5 (54.1) 176.0 (51.6) 167.4 (49.1) 30 (-1.1) 401.5 (117.7) 387.6 (113.6) 373.4 (109.4) 359.0 (105.2) 344.6 (101) 330.0 (96.7) 315.4 (92.4)

25 (-3.9) 361.4 (105.9) 348.8 (102.2) 336.0 (98.5) 323.0 (94.7) 310.0 (90.8) 296.7 (87) 283.5 (83.1)

20 (-6.7) 324.2 (95) 312.8 (91.7) 301.2 (88.3) 289.6 (84.9) 277.8 (81.4) 266.0 (77.9) 254.1 (74.5)

15 (-9.4) 289.8 (84.9) 279.6 (81.9) 269.2 (78.9) 258.7 (75.8) 248.1 (72.7) 237.5 (69.6) 226.9 (66.5)

10 (-12.2) 258.0 (75.6) 248.9 (72.9) 239.5 (70.2) 230.2 (67.5) 220.7 (64.7) 21

30 (-1.1) 463.8 (135.9) 446.8 (130.9) 429.7 (125.9) 412.4 (120.9) 395.0 (115.8) 377.5 (110.6) 359.9 (105.5)

25 (-3.9) 417.5 (122.4) 402.2 (117.9) 386.6 (113.3) 371.0 (108.7) 355.1 (104.1) 339.3 (99.4) 323.4 (94.8)

20 (-6.7) 374.4 (109.7) 360.6 (105.7) 346.5 (101.5) 332.4 (97.4) 318.2 (93.2) 303.9 (89.1) 289.5 (84.8)

15 (-9.4) 334.5 (98) 322.0 (94.4) 309.4 (90.7) 296.6 (86.9) 283.8 (83.2) 271.0 (79.4) 258.1 (75.6)

10 (-12.2) 297.5 (87.2) 286.3 (83.9) 275.0 (80.6) 263.6 (77.2) 252.1 (73.9) 240.6 (70.5) 229.0 (67.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

HIGH EFFICIENCY MODELS

1.3 (61.9) 201.7 (59.1)

BITZER

CONDENSING

UNIT

MODEL

TVS016H8-B

Compressor

4PES-15

TVS021H8-B

Compressor

4NES-20

TVS026H8-B

Compressor

4HE-25

TVS031H8-B

Compressor

4GE-30

TVS036H8-B

Compressor

6HE-35

TVS041H8-B

Compressor

6GE-40

TVS051H8-B

Compressor

6FE-50

CAPACITY DATA -

R404A

R507

60HzTVS-B

HIGH TEMP. HIGH EFFICIENCY MODELS

SATURATED

SUCTION

TEMPERATURE

° F ° C 45 (7.2) 219.7 (64.4) 210.3 (61.6) 200.9 (58.9) 191.6 (56.2) 182.4 (53.5) 173.2 (50.8) 164.1 (48.1) 40 (4.4) 201.3 (59) 192.5 (56.4) 183.8 (53.9) 175.1 (51.3) 166.5 (48.8) 157.9 (46.3) 149.5 (43.8) 35 (1.7) 183.8 (53.9) 175.6 (51.5) 167.5 (49.1) 159.5 (46.7) 151.5 (44.4) 143.6 (42.1) 135.7 (39.8) 45 (7.2) 258.5 (75.8) 247.7 (72.6) 236.9 (69.4) 226.2 (66.3) 215.6 (63.2) 205.0 (60.1) 194.5 (57) 40 (4.4) 237.1 (69.5) 227.0 (66.5) 217.0 (63.6) 207.1 (60.7) 197.2 (57.8) 187.3 (54.9) 177.5 (52) 35 (1.7) 216.8 (63.5) 207.5 (60.8) 198.2 (58.1) 189.0 (55.4) 179.8 (52.7) 170.7 (50) 161.6 (47.4) 45 (7.2) 333.3 (97.7) 319.7 (93.7) 306.0 (89.7) 292.4 (85.7) 278.7 (81.7) 265.1 (77.7) 251.5 (73.7) 40 (4.4) 306.8 (89.9) 294.1 (86.2) 281.4 (82.5) 268.7 (78.7) 256.0 (75) 243.3 (71.3) 230.6 (67.6) 35 (1.7) 281.6 (82.5) 269.8 (79.1) 258.0 (75.6) 246.2 (72.2) 234.4 (68.7) 222.7 (65.3) 210.9 (61.8) 45 (7.2) 383.2 (112.3) 367.4 (107.7) 351.5 (103) 335.5 (98.3) 319.6 (93.7) 303.7 (89) 287.8 (84.3) 40 (4.4) 352.8 (103.4) 338.1 (99.1) 323.3 (94.7) 308.5 (90.4) 293.7 (86.1) 278.9 (81.7) 264.1 (77.4) 35 (1.7) 323.9 (94.9) 310.2 (90.9) 296.6 (86.9) 282.9 (82.9) 269.1 (78.9) 255.4 (74.9) 241.7 (70.8) 45 (7.2) 492.3 (144.3) 472.3 (138.4) 452.3 (132.6) 432.4 (126.7) 412.5 (120.9) 392.6 (115.1) 372.8 (109.3) 40 (4.4) 452.9 (132.7) 434.3 (127.3) 415.7 (121.8) 397.1 (116.4) 378.6 (111 ) 360.1 (105.5) 341.7 (100.1) 35 (1.7) 415.4 (121.7) 398.2 (116.7) 381.0 (111.7) 363.8 (106.6) 346.6 (101.6) 329.4 (96.5) 312.3 (91.5) 45 (7.2) 557.7 (163.4) 534.3 (156.6) 511.0 (149.8) 487.7 (142.9) 464.5 (136.1) 441.3 (129.3) 418.1 (122.5) 40 (4.4) 513.6 (150.5) 491.9 (144.2) 470.3 (137.8) 448.7 (131.5) 427.1 (125.2) 405.5 (118.8) 384.0 (112.5) 35 (1.7) 471.7 (138.2) 451.7 (132.4) 431.7 (126.5) 411.7 (120.7) 391.7 (114.8) 371.7 (108.9) 351.8 (103.1) 45 (7.2) 653.0 (191.4) 625.1 (183.2) 597.2 (175) 569.3 (166.8) 541.4 (158.7) 513.6 (150.5) 485.7 (142.3) 40 (4.4) 603.2 (176.8) 577.3 (169.2) 551.4 (161.6) 525.5 (154) 499.6 (146.4) 473.7 (138.8) 447.8 (131.2) 35 (1.7) 555.7 (162.9) 531.7 (155.8) 507.8 (148.8) 483.8 (141.8) 459.8 (134.8) 435.8 (127.7) 411.8 (120.7)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

BITZER

09/03/14

T40-TV-PDS-19

- 74 -

CAPACITY DATA -

R404A

R507

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS016M8-B

Compressor

Model

4PES-15

TVS021M8-B

HIGH EFFICIENCY MODELS

Compressor

Model

4NES-20

TVS026M8-B

Compressor

Model

4HE-25

TVS031M8-B

Compressor

Model

4GE-30

TVS036M8-B

Compressor

Model

6HE-35

TVS041M8-B

Compressor

Model

6GE-40

TVS051M8-B

Compressor

Model

6FE-50

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 167.2 (49) 159.7 (46.8) 152.2 (44.6) 144.8 (42.4) 137.4 (40.3) 130.1 (38.1) 122.8 (36) 25 (-3.9) 151.7 (44.5) 144.7 (42.4) 137.8 (40.4) 131.0 (38.4) 124.2 (36.4) 117.4 (34.4) 110.7 (32.4) 20 (-6.7) 137.0 (40.2) 130.7 (38.3) 124.4 (36.5) 118.1 (34.6) 111.8 (32.8) 105.6 (30.9) 99.5 (29.2) 15 (-9.4) 123.3 (36.1) 117.5 (34.4) 111. 7 (32.7) 106.0 (31.1) 100.3 (29.4) 94.6 (27.7) 89.0 (26.1) 10 (-12.2) 110.5 (32.4) 105.2 (30.8) 100.0 (29.3) 94.8 (27.8) 89.6 (26.3) 84.4 (24.7) 79.3 (23.2)

5 (-15) 98.6 (28.9) 93.8 (27.5) 89.0 (26.1) 84.3 (24.7) 79.6 (23.3) 75.0 (22) 70.3 (20.6)

0 (-17.8) 87.5 (25.6) 83.2 (24.4) 78.9 (23.1) 74.6 (21.9) 70.4 (20.6) 66.2 (19.4) 62.1 (18.2) 30 (-1.1) 197.7 (57.9) 189.1 (55.4) 180.5 (52.9) 171.9 (50.4) 163.5 (47.9) 155.0 (45.4) 146.7 (43) 25 (-3.9) 179.6 (52.6) 171.7 (50.3) 163.8 (48) 155.9 (45.7) 148.1 (43.4) 140.4 (41.1) 132.7 (38.9) 20 (-6.7) 162.6 (47.7) 155.4 (45.5) 148.1 (43.4) 141.0 (41.3) 133.8 (39.2) 126.7 (37.1) 119.6 (35.1) 15 (-9.4) 146.7 (43) 140.1 (41.1) 133.5 (39.1) 126.9 (37.2) 120.4 (35.3) 113.9 (33.4) 107.5 (31.5) 10 (-12.2) 131.8 (38.6) 125.8 (36.9) 119.8 (35.1) 113.9 (33.4) 108.0 (31.7) 102.1 (29.9) 96.2 (28.2)

5 (-15) 117.9 (34.6) 112.5 (33) 107.1 (31.4) 101.8 (29.8) 96.4 (28.3) 91.1 (26.7) 85.8 (25.1)

0 (-17.8) 105.1 (30.8) 100.2 (29.4) 95.3 (27.9) 90.5 (26.5) 85.7 (25.1) 80.9 (23.7) 76.2 (22.3) 30 (-1.1) 257.6 (75.5) 246.8 (72.3) 235.9 (69.1) 225.0 (65.9) 214.1 (62.7) 203.2 (59.6) 192.3 (56.4) 25 (-3.9) 235.0 (68.9) 225.0 (65.9) 215.0 (63) 205.0 (60.1) 194.9 (57.1) 184.9 (54.2) 174.9 (51.3) 20 (-6.7) 213.6 (62.6) 204.5 (59.9) 195.3 (57.2) 186.1 (54.5) 176.9 (51.8) 167.7 (49.1) 158.5 (46.5) 15 (-9.4) 193.5 (56.7) 185.2 (54.3) 176.8 (51.8) 168.4 (49.4) 160.0 (46.9) 151.6 (44.4) 143.2 (42) 10 (-12.2) 174.6 (51.2) 167.1 (49) 159.5 (46.7) 151.8 (44.5) 144.2 (42.3) 136.5 (40) 128.9 (37.8)

5 (-15) 157.0 (46) 150.1 (44) 143.2 (42) 136.3 (39.9) 129.4 (37.9) 122.4 (35.9) 115.5 (33.8)

0 (-17.8) 140.5 (41.2) 134.3 (39.4) 128.1 (37.5) 121.9 (35.7) 115.6 (33.9) 109.3 (32) 103.1 (30.2) 30 (-1.1) 296.4 (86.9) 283.9 (83.2) 271.3 (79.5) 258.6 (75.8) 245.9 (72.1) 233.3 (68.4) 220.6 (64.7) 25 (-3.9) 270.5 (79.3) 258.9 (75.9) 247.4 (72.5) 235.7 (69.1) 224.1 (65.7) 212.4 20 (-6.7) 245.9 (72.1) 235.4 (69) 224.8 (65.9) 214.2 (62.8) 203.5 (59.6) 192.8 (56.5) 182.1 (53.4) 15 (-9.4) 222.9 (65.3) 213.3 (62.5) 203.7 (59.7) 194.0 (56.9) 184.3 (54) 174.5 (51.1) 164.7 (48.3) 10 (-12.2) 201.2 (59) 192.6 (56.4) 183.8 (53.9) 175.0 (51.3) 166.2 (48.7) 157.3 (46.1) 148.5 (43.5)

5 (-15) 181.0 (53) 173.2 (50.8) 165.3 (48.4) 157.3 (46.1) 149.3 (43.8) 141.3 (41.4) 133.3 (39.1)

0 (-17.8) 162.0 (47.5) 155.0 (45.4) 147.9 (43.3) 140.8 (41.3) 133.6 (39.2) 126.4 (37) 119.2 (34.9) 30 (-1.1) 380.0 (11 25 (-3.9) 346.5 (101.5) 331.9 (97.3) 317.2 (93) 302.6 (88.7) 287.9 (84.4) 273.3 (80.1) 258.7 (75.8) 20 (-6.7) 314.9 (92.3) 301.5 (88.4) 288.1 (84.4) 274.6 (80.5) 261.2 (76.5) 247.8 (72.6) 234.3 (68.7) 15 (-9.4) 285.2 (83.6) 272.9 (80) 260.7 (76.4) 248.4 (72.8) 236.1 (69.2) 223.9 (65.6) 211.6 (62) 10 (-12.2) 257.3 (75.4) 246.2 (72.2) 235.1 (68.9) 223.9 (65.6) 212.7 (62.3) 201.5 (59.1) 190.3 (55.8)

5 (-15) 231.2 (67.8) 221.2 (64.8) 211.1 (61.9) 201.0 (58.9) 190.8 (55.9) 180.7 (53) 170.5 (50)

0 (-17.8) 206.9 (60.6) 197.9 (58) 188.8 (55.3) 179.6 (52.6) 170.5 (50) 161.3 (47.3) 152.1 (44.6) 30 (-1.1) 431.9 (126.6) 413.5 (121.2) 395.1 (115.8) 376.6 (110.4) 358.2 (105) 339.8 (99.6) 321.4 (94.2) 25 (-3.9) 394.3 (115.6) 377.4 (110.6) 360.5 (105.7) 343.6 (100.7) 326.7 (95.7) 309.7 (90.8) 292.8 (85.8) 20 (-6.7) 358.7 (105.1) 343.3 (100.6) 327.9 (96.1) 312.4 (91.6) 296.9 (87) 281.5 (82.5) 266.0 (78) 15 (-9.4) 325.2 (95.3) 311.2 (91.2) 297.2 (87.1) 283.1 (83) 269.0 (78.8) 254.9 (74.7) 240.8 (70.6) 10 (-12.2) 293.8 (86.1) 281.1 (82.4) 268.4 (78.7) 255.6 (74.9) 242.9 (71.2) 230.1 (67.4) 217.3 (63.7)

5 (-15) 264.3 (77.5) 252.9 (74.1) 241.4 (70.7) 229.9 (67.4) 218.4 (64) 206.9 (60.6) 195.3 (57.2)

0 (-17.8) 236.8 (69.4) 226.6 (66.4) 216.3 (63.4) 205.9 (60.3) 195.6 (57.3) 185.2 (54.3) 174.7 (51.2) 30 (-1.1) 510.3 (149.6) 488.3 (143.1) 466.2 (136.6) 444.1 (130.2) 422.0 (123.7) 399.9 (117.2) 377.8 (110.7) 25 (-3.9) 467.2 (136.9) 447.0 (131) 426.8 (125.1) 406.5 (119.1) 386.2 (113.2) 365.9 (107.2) 345.5 (101.3) 20 (-6.7) 426.2 (124.9) 407.9 (119.5) 389.4 (114.1) 370.8 (108.7) 352.3 (103.2) 333.7 (97.8) 315.1 (92.3) 15 (-9.4) 387.5 (113.6) 370.8 (108.7) 354.0 (103.7) 337.2 (98.8) 320.3 (93.9) 303.3 (88.9) 286.4 (83.9) 10 (-12.2) 351.0 (102.9) 335.9 (98.4) 320.7 (94) 305.4 (89.5) 290.1 (85) 274.8 (80.5) 259.3 (76)

5 (-15) 316.7 (92.8) 303.1 (88.8) 289.4 (84.8) 275.6 (80.8) 261.8 (76.7) 247.9 (72.7) 233.9 (68.5)

0 (-17.8) 284.4 (83.3) 272.2 (79.8) 259.9 (76.2) 247.6 (72.6) 235.1 (68.9) 222.6 (65.2) 210.1 (61.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 11 5 (46.1)

CAPACITY MBH (KW)

1.4) 364.1 (106.7) 348.2 (102) 332.3 (97.4) 316.4 (92.7) 300.5 (88.1) 284.6 (83.4)

R404A R507

AMBIENT TEMPERATURE °F (°C)

(62.2) 200.7 (58.8)

BITZER

09/03/14

T40-TV-PDS-19

- 75 -

CAPACITY DATA -

R404A

R507

LOW TEMP. HIGH EFFICIENCY MODELS

60HzTVS-B

CONDENSING

UNIT

MODEL

TVS013L6-B

Compressor

Model

4NES-14

TVS016L6-B

Compressor

Model

4HE-18

TVS021L6-B

Compressor

Model

4GE-23

TVS026L6-B

Compressor

Model

6HE-28

TVS031L6-B

Compressor

Model

6GE-34

TVS041L6-B

Compressor

Model

6FE-44

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 96.3 (28.2) 91.6 (26.8) 87.0 (25.5) 82.4 (24.1) 77.7 (22.8) 73.1 (21.4) 68.5 (20.1)

-5 (-20.6) 86.0 (25.2) 81.8 (24) 77.6 (22.7) 73.4 (21.5) 69.2 (20.3) 65.0 (19) 60.8 (17.8)

-10 (-23.3) 76.3 (22.4) 72.6 (21.3) 68.8 (20.2) 65.0 (19) 61.2 (17.9) 57.4 (16.8) 53.7 (15.7)

-15 (-26.1) 67.4 (19.8) 64.0 (18.8) 60.6 (17.8) 57.2 (16.8) 53.8 (15.8) 50.4 (14.8) 47.0 (13.8)

-20 (-28.9) 59.0 (17.3) 56.0 (16.4) 53.0 (15.5) 49.9 (14.6) 46.9 (13.7) 43.9 (12.9) 40.8 (12)

-25 (-31.7) 51.4 (15.1) 48.7 (14.3) 45.9 (13.5) 43.2 (12.7) 40.5 (11.9) 37.8 (11.1) 35.1 (10.3)

-30 (-34.4) 44.3 (13) 41.9 (12.3) 39.5 (11.6) 37.0 (10.8) 34.6 (10.1) 32.2 (9.4) 29.8 (8.7)

-35 (-37.2) 37.8 (11.1) 35.7 (10.5) 33.5 (9.8) 31.3 (9.2) 29.2 (8.6) 27.0 (7.9) 24.9 (7.3)

-40 (-40) 31.9 (9.3) 30.0 (8.8) 28.0 (8.2) 26.0 (7.6) 24.1 (7.1) 22.2 (6.5) 20.3 (5.9) 0 (-17.8) 136.8 (40.1) 130.7 (38.3) 124.7 (36.5) 118.6 (34.8) 112.6 (33) 106.5 (31.2) 100.5 (29.5)

-5 (-20.6) 122.5 (35.9) 117.0 (34.3) 111.6 (32.7) 106.1 (31.1) 100.6 (29.5) 95.2 (27.9) 89.7 (26.3)

-10 (-23.3) 109.1 (32) 104.2 (30.5) 99.3 (29.1) 94.4 (27.7) 89.5 (26.2) 84.6 (24.8) 79.7 (23.4)

-15 (-26.1) 96.7 (28.3) 92.3 (27.1) 87.9 (25.8) 83.5 (24.5) 79.1 (23.2) 74.7 (21.9) 70.3 (20.6)

-20 (-28.9) 85.1 (24.9) 81.2 (23.8) 77.3 (22.7) 73.3 (21.5) 69.4 (20.3) 65.5 (19.2) 61.6 (18.1)

-25 (-31.7) 74.4 (21.8) 70.9 (20.8) 67.4 (19.8) 63.9 (18.7) 60.4 (17.7) 56.9 (16.7) 53.4 (15.6)

-30 (-34.4) 64.5 (18.9) 61.4 (18) 58.3 (17.1) 55.1 (16.1) 52.0 (15.2) 48.9 (14.3) 45.8 (13.4)

-35 (-37.2) 55.4 (16.2) 52.6 (15.4) 49.8 (14.6) 47.0 (13.8) 44.3 (13) 41.5 (12.2) 38.8 (11.4)

-40 (-40) 46.9 (13.7) 44.5 (13) 42.0 (12.3) 39.5 (11.6) 37.0 (10.8) 34.6 (10.1) 32.1 (9.4) 0 (-17.8) 155.8 (45.7) 149.0 (43.7) 142.2 (41.7) 135.3 (39.7) 128.5 (37.7) 121.6 (35.6) 114.8 (33.6)

-5 (-20.6) 140.1 (41.1) 133.9 (39.2) 127.8 (37.5) 121.6 (35.6) 115.4 (33.8) 109.3 (32) 103.1 (30.2)

-10 (-23.3) 125.3 (36.7) 119.8 (35.1) 114.3 (33.5) 108.7 (31.9) 103.2 (30.2) 97.7 (28.6) 92.1 (27)

-15 (-26.1) 111.4 (32.6) 106.5 (31.2) 101.6 (29.8) 96.7 (28.3) 91.7 (26.9) 86.8 (25.4) 81.9 (24)

-20 (-28.9) 98.5 (28.9) 94.2 (27.6) 89.8 (26.3) 85.4 (25) 81.0 (23.7) 76.6 (22.4) 72.3 (21.2)

-25 (-31.7) 86.5 (25.4) 82.7 (24.2) 78.8 (23.1) 74.9 (22) 71.0 (20.8) 67.1 (19.7) 63.3 (18.6)

-30 (-34.4) 75.4 (22.1) 72.0 (21.1) 68.5 (20.1) 65.1 (19.1) 61.7 (18.1) 58.3 (17.1) 54.9 (16.1)

-35 (-37.2) 65.1 (19.1) 62.1 (18.2) 59.0 (17.3) 56.0 (16.4) 53.0 (15.5) 50.0 (14.7) 47.0 (13.8)

-40 (-40) 55.6 (16.3) 52.9 (15.5) 50.2 (14.7) 47.5 (13.9) 44.8 (13.1) 42.2 (12.4) 39.6 (11.6)

0 (-17.8) 194.1 (56.9) 185.4 (54.3) 176.7 (51.8) 168.1 (49.3) 159.5 (46.7) 150.9 (44.2) 142.3 (41.7)

-5 (-20.6) 174.4 (51.1) 166.5 (48.8) 158.7 (46.5) 150.8 (44.2) 143.0 (41.9) 135.2 (39.6) 127.4 (37.3)

-10 (-23.3) 155.9 (45.7) 148.8 (43.6) 141.7 (41.5) 134.6 (39.4) 127.5 (37.4) 120.5 (35.3) 113.4 (33.2)

-15 (-26.1) 138.5 (40.6) 132.2 (38.7) 125.8 (36.9) 1

-20 (-28.9) 122.4 (35.9) 116.6 (34.2) 110.9 (32.5) 105.2 (30.8) 99.5 (29.2) 93.8 (27.5) 88.1 (25.8)

-25 (-31.7) 107.3 (31.4) 102.2 (30) 97.1 (28.5) 92.0 (27) 86.8 (25.4) 81.7 (23.9) 76.6 (22.4)

-30 (-34.4) 93.3 (27.3) 88.7 (26) 84.2 (24.7) 79.6 (23.3) 75.0 (22) 70.5 (20.7) 65.9 (19.3)

-35 (-37.2) 80.4 (23.6) 76.3 (22.4) 72.2 (21.2) 68.1 (20) 64.0 (18.8) 59.9 (17.6) 55.8 (16.4)

-40 (-40) 68.4 (20) 64.7 (19) 61.0 (17.9) 57.4 (16.8) 53.7 (15.7) 50.0 (14.7) 46.3 (13.6) 0 (-17.8) 222.1 (65.1) 212.5 (62.3) 202.9 (59.5) 193.2 (56.6) 183.6 (53.8) 173.9 (51) 164.1 (48.1)

-5 (-20.6) 200.8 (58.8) 192.1 (56.3) 183.5 (53.8) 174.8 (51.2) 166.0 (48.6) 157.3 (46.1) 148.4 (43.5)

-10 (-23.3) 180.6 (52.9) 172.9 (50.7) 165.1 (48.4) 157.3 (46.1) 149.5 (43.8) 141.6 (41.5) 133.6 (39.2)

-15 (-26.1) 161.7 (47.4) 154.7 (45.3) 147.8 (43.3) 140.8 (41.3) 133.8 (39.2) 126.7 (37.1) 119.5 (35)

-20 (-28.9) 143.8 (42.1) 137.7 (40.4) 131.5 (38.5) 125.3 (36.7) 119.0 (34.9) 112.7 (33) 106.3 (31.2)

-25 (-31.7) 127.1 (37.2) 121.7 (35.7) 116.2 (34.1) 110.6 (32.4) 105.0 (30.8) 99.4 (29.1) 93.7 (27.5)

-30 (-34.4) 111.6 (32.7) 106.7 (31.3) 101.8 (29.8) 96.9 (28.4) 91.9 (26.9) 86.9 (25.5) 81.8 (24)

-35 (-37.2) 97.0 (28.4) 92.7 (27.2) 88.4 (25.9) 84.0 (24.6) 79.6 (23.3) 75.1 (22) 70.5 (20.7)

-40 (-40) 83.6 (24.5) 79.7 (23.4) 75.8 (22.2) 71.9 (21.1) 67.9 (19.9) 63.9 (18.7) 59.7 (17.5) 0 (-17.8) 270.0 (79.1) 258.3 (75.7) 246.5 (72.2) 234.7 (68.8) 222.9 (65.3) 211.0 (61.8) 199.2 (58.4)

-5 (-20.6) 243.6 (71.4) 233.0 (68.3) 222.4 (65.2) 211.7 (62) 201.0 (58.9) 190.3 (55.8) 179.6 (52.6)

-10 (-23.3) 218.6 (64.1) 209.1 (61.3) 199.5 (58.5) 190.0 (55.7) 180.3 (52.8) 170.7 (50) 161.0 (47.2)

-15 (-26.1) 195.1 (57.2) 186.6 (54.7) 178.0 (52.2) 169.4 (49.6) 160.8 (47.1) 152.1 (44.6) 143.3 (42)

-20 (-28.9) 173.0 (50.7) 165.4 (48.5) 157.8 (46.2) 150.1 (44) 142.3 (41.7) 134.5 (39.4) 126.6 (37.1)

-25 (-31.7) 152.4 (44.7) 145.6 (42.7) 138.8 (40.7) 131.8 (38.6) 124.9 (36.6) 117.9 (34.6) 110.8 (32.5)

-30 (-34.4) 133.2 (39) 127.1 (37.2) 120.9 (35.4) 1

-35 (-37.2) 115.3 (33.8) 109.8 (32.2) 104.2 (30.5) 98.6 (28.9) 92.9 (27.2) 87.2 (25.6) 81.4 (23.9)

-40 (-40) 98.7 (28.9) 93.7 (27.5) 88.6 (26) 83.5 (24.5) 78.3 (22.9) 73.1 (21.4) 67.8 (19.9)

CAPACITY MBH (KW)

R404A

19.4 (35) 113.1 (33.1) 106.7 (31.3) 100.3 (29.4)

14.7 (33.6) 108.4 (31.8) 102.1 (29.9) 95.8 (28.1)

AMBIENT TEMPERATURE °F (°C)

R507

HIGH EFFICIENCY MODELS

BITZER

09/03/14

T40-TV-PDS-19

- 76 -

CAPACITY DATA -

R407A

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD031H8-B

Compressor

4PES-15

TVD041H8-B

Compressor

4NES-20

TVD051H8-B

Compressor

4HE-25

TVD061H8-B

Compressor

HIGH EFFICIENCY MODELS

4GE-30

TVD071H8-B

Compressor

6HE-35

TVD081H8-B

Compressor

6GE-40

TVD101H8-B

Compressor

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 45 (7.2) 424.2 (124.3) 407.8 (119.5) 391.4 (114.7) 375.1 (109.9) 358.9 (105.2) 342.5 (100.4) 326.1 (95.6) 40 (4.4) 385.1 (112.9) 370.0 (108.4) 354.9 (104) 339.8 (99.6) 324.7 (95.1) 309.8 (90.8) 294.6 (86.3) 35 (1.7) 348.6 (102.2) 334.7 (98.1) 320.9 (94) 306.8 (89.9) 293.0 (85.9) 279.1 (81.8) 265.2 (77.7) 45 (7.2) 497.1 (145.7) 478.4 (140.2) 459.5 (134.7) 440.8 (129.2) 421.9 (123.6) 403.2 (118.2) 384.3 (112.6) 40 (4.4) 451.9 (132.4) 434.5 (127.3) 417.1 (122.2) 399.8 (117.2) 382.4 (112.1) 365.0 (107) 347.8 (101.9) 35 (1.7) 409.5 (120) 393.3 (115.3) 377.4 (110.6) 361.4 (105.9) 345.5 (101.2) 329.5 (96.6) 313.5 (91.9) 45 (7.2) 636.5 (186.5) 612.2 (179.4) 588.0 (172.3) 563.9 (165.2) 539.7 (158.2) 515.6 (151.1) 491.6 (144.1) 40 (4.4) 578.8 (169.6) 556.3 (163) 533.8 (156.4) 511.4 (149.9) 489.1 (143.3) 466.8 (136.8) 444.6 (130.3) 35 (1.7) 524.6 (153.7) 503.8 (147.6) 483.0 (141.6) 462.4 (135.5) 441.6 (129.4) 421.1 (123.4) 400.7 (117.4) 45 (7.2) 743.4 (217.9) 715.9 (209.8) 688.4 (201.7) 661.1 (193.7) 633.8 (185.7) 606.5 (177.7) 579.4 (169.8) 40 (4.4) 676.8 (198.4) 651.4 (190.9) 626.0 (183.5) 600.6 (176) 575.2 (168.6) 550.0 (161.2) 525.0 (153.9) 35 (1.7) 614.3 (180) 590.7 (173.1) 567.4 (166.3) 543.9 (159.4) 520.6 (152.6) 497.3 (145.7) 474.2 (139) 45 (7.2) 968.9 (284) 932.8 (273.4) 896.9 (262.9) 860.8 (252.3) 824.9 (241.7) 789.2 (231.3) 753.5 (220.8) 40 (4.4) 882.0 (258.5) 848.6 (248.7) 815.2 (238.9) 781.8 (229.1) 748.7 (219.4) 715.5 (209.7) 682.5 (200) 35 (1.7) 800.3 (234.5) 769.4 (225.5) 738.6 (216.5) 707.9 (207.5) 677.3 (198.5) 646.6 (189.5) 616.1 (180.6) 45 (7.2) 1114.1 (326.5) 1072.9 (314.4) 1031.7 (302.4) 990.8 (290.4) 949.6 (278.3) 908.9 (266.4) 868.1 (254.4) 40 (4.4) 1014.3 (297.3) 976.1 (286.1) 938.1 (274.9) 900.1 (263.8) 862.1 (252.6) 824.3 (241.6) 786.7 (230.5) 35 (1.7) 920.6 (269.8) 885.6 (259.5) 850.3 (249.2) 815.2 (238.9) 780.2 (228.6) 745.3 (218.4) 710.6 (208.3) 45 (7.2) 1290.0 (378.1) 1241.7 (363.9) 1193.6 (349.8) 1145.6 (335.7) 1097.7 (321.7) 1049.8 (307.7) 1002.1 (293.7) 40 (4.4) 1176.6 (344.8) 1131.7 (331.7) 1087.0 (318.6) 1042.4 (305.5) 997.9 (292.5) 953.6 (279.5) 909.5 (266.6) 35 (1.7) 1069.5 (313.4) 1028.2 (301.3) 986.8 (289.2) 945.6 (277.1) 904.5 (265.1) 863.5 (253.1) 822.8 (241.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

BITZER

09/03/14

T40-TV-PDS-19

- 77 -

CAPACITY DATA -

R407A

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD031M8-B

Compressor

Model

4PES-15

TVD041M8-B

Compressor

Model

4NES-20

TVD051M8-B

Compressor

Model

4HE-25

TVD061M8-B

Compressor

Model

4GE-30

TVD071M8-B

Compressor

Model

6HE-35

TVD081M8-B

Compressor

Model

6GE-40

TVD101M8-B

Compressor

Model

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 314.6 (92.2) 301.8 (88.4) 289.0 (84.7) 276.2 (80.9) 263.3 (77.2) 250.5 (73.4) 237.9 (69.7) 25 (-3.9) 282.7 (82.8) 270.9 (79.4) 259.1 (75.9) 247.6 (72.6) 235.8 (69.1) 224.1 (65.7) 212.5 (62.3) 20 (-6.7) 253.1 (74.2) 242.3 (71) 231.6 (67.9) 220.9 (64.7) 210.4 (61.7) 199.7 (58.5) 189.0 (55.4) 15 (-9.4) 225.5 (66.1) 215.9 (63.3) 206.2 (60.4) 196.6 (57.6) 186.7 (54.7) 177.0 (51.9) 167.4 (49.1) 10 (-12.2) 200.1 (58.7) 191.3 (56.1) 182.5 (53.5) 173.9 (51) 165.1 (48.4) 156.2 (45.8) 147.4 (43.2)

5 (-15) 176.8 (51.8) 168.8 (49.5) 160.9 (47.1) 152.9 (44.8) 144.9 (42.5) 137.1 (40.2) 129.2 (37.8)

0 (-17.8) 155.2 (45.5) 148.1 (43.4) 140.9 (41.3) 133.8 (39.2) 126.4 (37) 119.5 (35) 112.4 (32.9) 30 (-1.1) 369.8 (108.4) 355.1 (104.1) 340.4 (99.8) 325.7 (95.5) 311.0 (91.1) 296.3 (86.8) 281.6 (82.5) 25 (-3.9) 332.6 (97.5) 319.2 (93.5) 305.8 (89.6) 292.5 (85.7) 279.1 (81.8) 265.7 (77.9) 252.2 (73.9) 20 (-6.7) 298.2 (87.4) 286.0 (83.8) 273.8 (80.3) 261.7 (76.7) 249.5 (73.1) 237.1 (69.5) 224.9 (65.9) 15 (-9.4) 266.3 (78) 255.2 (74.8) 244.2 (71.6) 233.1 (68.3) 222.0 (65.1) 210.8 (61.8) 199.9 (58.6) 10 (-12.2) 236.9 (69.4) 226.8 (66.5) 216.7 (63.5) 206.6 (60.6) 196.6 (57.6) 186.7 (54.7) 176.6 (51.8)

5 (-15) 209.6 (61.4) 200.6 (58.8) 191.5 (56.1) 182.3 (53.4) 173.3 (50.8) 164.2 (48.1) 155.2 (45.5)

0 (-17.8) 184.4 (54) 176.4 (51.7) 168.2 (49.3) 160.0 (46.9) 151.8 (44.5) 143.6 (42.1) 135.7 (39.8) 30 (-1.1) 474.0 (138.9) 454.9 (133.3) 435.5 (127.6) 416.6 (122.1) 397.5 (116.5) 378.6 (111 ) 359.7 (105.4) 25 (-3.9) 426.5 (125) 409.1 (119.9) 391.4 (114.7) 373.8 (109.5) 356.4 (104.4) 339.2 (99.4) 321.7 (94.3) 20 (-6.7) 382.4 (112.1) 366.2 (107.3) 350.3 (102.7) 334.3 (98) 318.4 (93.3) 302.4 (88.6) 286.7 (84) 15 (-9.4) 341.5 (100.1) 326.8 (95.8) 312.1 (91.5) 297.4 (87.1) 282.9 (82.9) 268.4 (78.7) 254.1 (74.5) 10 (-12.2) 303.2 (88.9) 290.0 (85) 276.6 (81.1) 263.3 (77.2) 250.1 (73.3) 237.1 (69.5) 223.9 (65.6)

5 (-15) 268.0 (78.5) 256.0 (75) 243.8 (71.5) 231.8 (67.9) 219.9 (64.4) 207.9 (60.9) 196.1 (57.5)

0 (-17.8) 235.4 (69) 224.5 (65.8) 213.6 (62.6) 202.7 (59.4) 191.7 (56.2) 181.0 (53.1) 170.3 (49.9) 30 (-1.1) 555.9 (162.9) 534.2 (156.6) 512.6 (150.2) 491.0 (143.9) 469.6 (137.6) 448.4 (131.4) 426.9 (125.1) 25 (-3.9) 501.1 (146.8) 481.3 (141.1) 461.6 (135.3) 441.8 (129.5) 422.1 (123.7) 402.6 20 (-6.7) 450.2 (132) 432.0 (126.6) 413.9 (121.3) 396.1 (116.1) 378.0 (1 15 (-9.4) 402.8 (118) 386.4 (113.2) 369.8 (108.4) 353.4 (103.6) 337.3 (98.8) 320.9 (94) 304.7 (89.3) 10 (-12.2) 358.7 (105.1) 343.8 (100.7) 328.9 (96.4) 314.2 (92.1) 299.3 (87.7) 284.6 (83.4) 269.9 (79.1)

5 (-15) 317.9 (93.2) 304.5 (89.2) 291.1 (85.3) 277.6 (81.4) 264.2 (77.4) 251.0 (73.5) 237.7 (69.7)

0 (-17.8) 280.4 (82.2) 268.2 (78.6) 256.0 (75) 243.8 (71.5) 231.8 (67.9) 219.9 (64.4) 207.9 (60.9) 30 (-1.1) 723.9 (212.1) 695.5 (203.8) 667.2 (195.5) 638.8 (187.2) 610.7 (179) 582.5 (170.7) 554.6 (162.5) 25 (-3.9) 652.5 (191.2) 626.4 (183.6) 600.4 (176) 574.6 (168.4) 548.7 (160.8) 522.9 (153.2) 497.3 (145.7) 20 (-6.7) 585.9 (171.7) 562.2 (164.8) 538.4 (157.8) 514.7 (150.8) 491.0 (143.9) 467.5 (137) 444.2 (130.2) 15 (-9.4) 524.0 (153.6) 502.3 (147.2) 480.7 (140.9) 459.1 (134.5) 437.6 (128.3) 416.2 (122) 395.0 (115.8) 10 (-12.2) 466.4 (136.7) 446.9 (131) 427.1 (125.2) 407.6 (119.5) 388.1 (113.7) 368.8 (108.1) 349.4 (102.4)

5 (-15) 413.3 (121.1) 395.4 (115.9) 377.6 (110.7) 359.9 (105.5) 342.3 (100.3) 324.9 (95.2) 307.4 (90.1)

0 (-17.8) 363.9 (106.7) 347.8 (101.9) 331.8 (97.2) 315.8 (92.6) 300.1 (87.9) 284.1 (83.3) 268.6 (78.7) 30 (-1.1) 833.1 (244.1) 800.5 (234.6) 768.2 (225.1) 736.1 (215.7) 703.7 (206.2) 671.8 (196.9) 639.9 (187.5) 25 (-3.9) 751.2 (220.1) 721.4 (211.4) 691.7 (202.7) 662.1 (194.1) 632.7 (185.4) 603.3 (176.8) 574.1 (168.3) 20 (-6.7) 674.7 (197.7) 647.6 (189.8) 620.6 (181.9) 593.5 (173.9) 566.6 (166) 539.9 (158.2) 513.0 (150.4) 15 (-9.4) 603.8 (176.9) 579.0 (169.7) 554.4 (162.5) 529.8 (155.3) 505.3 (148.1) 480.9 (140.9) 456.8 (133.9) 10 (-12.2) 537.8 (157.6) 515.3 (151) 493.1 (144.5) 470.8 (138) 448.6 (131.5) 426.5 (125) 404.5 (118.5)

5 (-15) 476.7 (139.7) 456.3 (133.7) 436.2 (127.8) 416.0 (121.9) 396.1 (116.1) 376.1 (110.2) 356.2 (104.4)

0 (-17.8) 420.2 (123.2) 401.9 (117.8) 383.7 (112.4) 365.4 (107.1) 347.3 (101.8) 329.5 (96.6) 311.6 (91.3) 30 (-1.1) 969.2 (284) 930.9 (272.8) 892.9 (261.7) 854.9 (250.5) 817.1 (239.5) 779.3 (228.4) - 25 (-3.9) 875.1 (256.5) 840.0 (246.2) 805.1 (236) 770.3 (225.7) 735.4 (215.5) 701.0 (205.4) 666.5 (195.3) 20 (-6.7) 787.1 (230.7) 755.0 (221.3) 723.0 (211.9) 691.3 (202.6) 659.6 (193.3) 627.9 (184) 596.6 (174.8) 15 (-9.4) 705.0 (206.6) 676.0 (198.1) 646.8 (189.6) 617.8 (181.1) 589.1 (172.6) 560.3 (164.2) 531.5 (155.8) 10 (-12.2) 628.7 (184.3) 602.3 (176.5) 575.8 (168.8) 549.6 (161.1) 523.3 (153.4) 497.3 (145.7) 471.5 (138.2)

5 (-15) 558.0 (163.5) 534.0 (156.5) 510.1 (149.5) 486.4 (142.5) 462.6 (135.6) 439.1 (128.7) 415.6 (121.8)

0 (-17.8) 492.2 (144.3) 470.6 (137.9) 449.2 (131.6) 427.6 (125.3) 406.4 (119.1) 385.1 (112.9) 363.9 (106.7)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 11 5 (46.1)

CAPACITY MBH (KW)

R407A

AMBIENT TEMPERATURE °F (°C)

10.8) 360.2 (105.5) 342.3 (100.3)

HIGH EFFICIENCY MODELS

(118) 383.0 (112.3)

BITZER

09/03/14

T40-TV-PDS-19

- 78 -

CAPACITY DATA -

R407A

LOW TEMP. HIGH EFFICIENCY MODELS

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD025L8-B

Compressor

Model

4NES-14

HIGH EFFICIENCY MODELS

TVD031L8-B

Compressor

Model

4HE-18

TVD041L8-B

Compressor

Model

4GE-23

TVD051L8-B

Compressor

Model

6HE-28

TVD061L8-B

Compressor

Model

6GE-34

TVD081L8-B

Compressor

Model

6FE-44

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 170.9 (50.1) 163.0 (47.8) 155.0 (45.4) 147.2 (43.1) 139.4 (40.9) 131.7 (38.6) 124.1 (36.4)

-5 (-20.6) 150.2 (44) 143.0 (41.9) 135.9 (39.8) 128.7 (37.7) 121.8 (35.7) 114.9 (33.7) 107.9 (31.6)

-10 (-23.3) 131.0 (38.4) 124.5 (36.5) 118.2 (34.6) 111. 7 (32.7) 105.4 (30.9) 99.3 (29.1) 93.0 (27.3)

-15 (-26.1) 113.4 (33.2) 107.5 (31.5) 101.9 (29.8) 96.2 (28.2) 90.5 (26.5) 84.8 (24.9) 79.4 (23.3)

-20 (-28.9) 97.0 (28.4) 91.8 (26.9) 86.7 (25.4) 81.7 (23.9) 76.7 (22.5) 71.6 (21) 66.8 (19.6)

-25 (-31.7) 82.1 (24.1) 77.3 (22.6) 72.9 (21.4) 68.3 (20) 63.6 (18.6) 59.2 (17.4) 55.0 (16.1)

-30 (-34.4) 68.3 (20) 64.1 (18.8) 59.9 (17.5) 55.9 (16.4) 51.9 (15.2) 47.9 (14) 44.1 (12.9)

-35 (-37.2) 55.4 (16.2) 51.7 (15.1) 47.9 (14) 44.3 (13) 40.7 (11.9) 37.2 (10.9) 33.8 (9.9)

-40 (-40) 43.5 (12.7) 40.1 (11.8) 37.0 (10.8) 33.6 (9.8) 30.5 (8.9) 27.3 (8) 24.2 (7.1) 0 (-17.8) 236.7 (69.4) 226.2 (66.3) 215.9 (63.3) 205.6 (60.3) 195.3 (57.2) 185.2 (54.3) 175.4 (51.4)

-5 (-20.6) 207.9 (60.9) 198.5 (58.2) 189.0 (55.4) 179.8 (52.7) 170.5 (50) 161.5 (47.3) 152.7 (44.7)

-10 (-23.3) 181.2 (53.1) 172.8 (50.7) 164.2 (48.1) 156.0 (45.7) 147.6 (43.3) 139.7 (40.9) 131.7 (38.6)

-15 (-26.1) 156.5 (45.9) 148.9 (43.6) 141.3 (41.4) 134.0 (39.3) 126.6 (37.1) 119.3 (35) 112.1 (32.9)

-20 (-28.9) 133.6 (39.1) 126.8 (37.2) 120.1 (35.2) 113.4 (33.2) 106.9 (31.3) 100.4 (29.4) 94.3 (27.6)

-25 (-31.7) 112.4 (32.9) 106.3 (31.1) 100.4 (29.4) 94.5 (27.7) 88.6 (26) 83.0 (24.3) 77.5 (22.7)

-30 (-34.4) 92.4 (27.1) 87.2 (25.5) 81.9 (24) 76.7 (22.5) 71.6 (21) 66.6 (19.5) 61.7 (18.1)

-35 (-37.2) 73.9 (21.7) 69.3 (20.3) 64.7 (19) 60.1 (17.6) 55.4 (16.2) 51.0 (15) 46.8 (13.7)

-40 (-40) 56.5 (16.6) 52.5 (15.4) 48.3 (14.2) 44.3 (13) 40.3 (11.8) 36.5 (10.7) 32.8 (9.6) 0 (-17.8) 274.5 (80.4) 262.9 (77.1) 251.4 (73.7) 240.0 (70.3) 228.9 (67.1) 217.8 (63.8) 206.9 (60.6)

-5 (-20.6) 242.3 (71) 231.8 (67.9) 221.6 (64.9) 211.3 (61.9) 201.2 (59) 191.3 (56.1) 181.4 (53.2)

-10 (-23.3) 212.3 (62.2) 203.1 (59.5) 193.8 (56.8) 184.6 (54.1) 175.6 (51.5) 166.7 (48.9) 157.9 (46.3)

-15 (-26.1) 184.6 (54.1) 176.2 (51.6) 168.0 (49.2) 159.8 (46.8) 151.8 (44.5) 143.9 (42.2) 136.1 (39.9)

-20 (-28.9) 158.8 (46.5) 151.2 (44.3) 144.1 (42.2) 136.7 (40.1) 129.6 (38) 122.6 (35.9) 115.7 (33.9)

-25 (-31.7) 134.6 (39.5) 128.1 (37.5) 121.6 (35.6) 115.3 (33.8) 109.0 (31.9) 102.7 (30.1) 96.8 (28.4)

-30 (-34.4) 112.1 (32.9) 106.3 (31.1) 100.6 (29.5) 94.9 (27.8) 89.5 (26.2) 84.0 (24.6) 78.8 (23.1)

-35 (-37.2) 90.9 (26.6) 85.9 (25.2) 80.9 (23.7) 76.0 (22.3) 71.2 (20.9) 66.4 (19.4) 62.0 (18.2)

-40 (-40) 71.2 (20.9) 66.6 (19.5) 62.4 (18.3) 58.0 (17) 53.8 (15.8) 49.6 (14.5) 45.6 (13.4) 0 (-17.8) 343.1 (100.6) 327.8 (96.1) 312.5 (91.6) 297.4 (87.1) 282.5 (82.8) 267.8 (78.5) 253.3 (74.2)

-5 (-20.6) 302.2 (88.6) 288.1 (84.4) 274.5 (80.4) 260.8 (76.4) 247.4 (72.5) 234.2 (68.6) 221.1 (64.8)

-10 (-23.3) 264.0 (77.4) 251.4 (73.7) 239.0 (70) 226.8 (66.5) 214.6 (62.9) 202.9 (59.5) 191.1 (56)

-15 (-26.1) 228.3 (66.9) 217.1 (63.6) 206.0 (60.4) 195.1 (57.2) 184.2 (54) 173.7 (50.9) 163.2 (47.8)

-20 (-28.9) 195.3 (57.2) 185.2 (54.3) 175.4 (51.4) 165.5 (48.5) 156.0 (45.7) 146.6 (43) 137.3 (40.3)

-25 (-31.7) 164.4 (48.2) 155.4 (45.5) 146.8 (43) 138.0 (40.4) 129.6 (38) 121.2 (35.5) 1

-30 (-34.4) 135.7 (39.8) 127.7 (37.4) 119.9 (35.1) 112.4 (32.9) 104.8 (30.7) 97.4 (28.6) 90.3 (26.5)

-35 (-37.2) 108.6 (31.8) 101.6 (29.8) 94.7 (27.8) 88.0 (25.8) 81.3 (23.8) 75.0 (22) 68.7 (20.1)

-40 (-40) 83.2 (24.4) 76.9 (22.5) 71.0 (20.8) 64.9 (19) 59.0 (17.3) 53.3 (15.6) 47.9 (14) 0 (-17.8) 386.6 (113.3) 369.2 (108.2) 352.2 (103.2) 335.2 (98.2) 318.4 (93.3) 301.8 (88.4) - -

-5 (-20.6) 341.0 (99.9) 325.5 (95.4) 310.0 (90.8) 294.6 (86.3) 279.5 (81.9) 264.6 (77.5) 249.9 (73.2)

-10 (-23.3) 298.6 (87.5) 284.6 (83.4) 270.5 (79.3) 256.6 (75.2) 243.2 (71.3) 229.7 (67.3) 216.7 (63.5)

-15 (-26.1) 258.9 (75.9) 246.3 (72.2) 233.7 (68.5) 221.3 (64.9) 209.2 (61.3) 197.4 (57.9) 185.6 (54.4)

-20 (-28.9) 221.8 (65) 210.6 (61.7) 199.5 (58.5) 188.4 (55.2) 177.7 (52.1) 167.0 (48.9) 156.7 (45.9)

-25 (-31.7) 187.1 (54.8) 177.2 (51.9) 167.4 (49.1) 157.5 (46.2) 148.1 (43.4) 138.6 (40.6) 129.6 (38)

-30 (-34.4) 154.8 (45.4) 146.0 (42.8) 137.1 (40.2) 128.5 (37.7) 120.1 (35.2) 111. 9 (32.8) 103.7 (30.4)

-35 (-37.2) 124.3 (36.4) 116.3 (34.1) 108.8 (31.9) 101.0 (29.6) 93.7 (27.4) 86.5 (25.4) 79.4 (23.3)

-40 (-40) 95.6 (28) 88.6 (26) 81.7 (23.9) 75.0 (22) 68.5 (20.1) 62.2 (18.2) 56.1 (16.4) 0 (-17.8) 471.9 (138.3) 451.1 (132.2) 430.7 (126.2) 410.6 (120.3) 390.4 (114.4) 370.7 (108.6) 351.3 (103)

-5 (-20.6) 416.4 (122) 397.7 (116.6) 379.3 (111.1) 361.0 (105.8) 342.9 (100.5) 325.1 (95.3) 307.7 (90.2)

-10 (-23.3) 364.6 (106.8) 348.0 (102) 331.4 (97.1) 315.0 (92.3) 298.6 (87.5) 282.9 (82.9) 267.1 (78.3)

-15 (-26.1) 316.5 (92.7) 301.6 (88.4) 286.7 (84) 272.0 (79.7) 257.5 (75.5) 243.4 (71.3) 229.5 (67.3)

-20 (-28.9) 271.5 (79.6) 258.1 (75.6) 245.1 (71.8) 232.1 (68) 219.0 (64.2) 206.6 (60.6) 194.3 (56.9)

-25 (-31.7) 229.5 (67.3) 217.8 (63.8) 206.0 (60.4) 194.5 (57) 183.1 (53.7) 172.0 (50.4) 161.3 (47.3)

-30 (-34.4) 190.5 (55.8) 180.0 (52.7) 169.5 (49.7) 159.4 (46.7) 149.5 (43.8) 139.7 (40.9) 130.2 (38.2)

-35 (-37.2) 153.5 (45) 144.3 (42.3) 135.2 (39.6) 126.2 (37) 117.4 (34.4) 109.0 (31.9) 100.6 (29.5)

-40 (-40) 118.9 (34.8) 1

CAPACITY MBH (KW)

10.7 (32.4) 102.7 (30.1) 94.7 (27.8) 86.9 (25.5) 79.6 (23.3) 72.2 (21.2)

R407A

AMBIENT TEMPERATURE °F (°C)

13.0 (33.1)

BITZER

09/03/14

T40-TV-PDS-19

- 79 -

CAPACITY DATA -

R407C

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD031H8-B

Compressor

Model

4PES-15

TVD041H8-B

Compressor

Model

4NES-20

TVD051H8-B

Compressor

Model

4HE-25

TVD061H8-B

Compressor

Model

4GE-30

TVD071H8-B

Compressor

Model

6HE-35

TVD081H8-B

Compressor

Model

6GE-40

TVD101H8-B

Compressor

Model

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 495.0 (145.1) 476.9 (139.8) 458.6 (134.4) 440.4 (129.1) 422.1 (123.7) 403.6 (118.3) 385.1 (112.9) 50 (10) 451.7 (132.4) 434.9 (127.5) 417.9 (122.5) 400.9 (117.5) 383.9 (112.5) 366.9 (107.5) 349.7 (102.5) 45 (7.2) 410.8 (120.4) 395.2 (115.8) 379.7 (111.3) 364.1 (106.7) 348.4 (102.1) 332.6 (97.5) 316.7 (92.8) 40 (4.4) 372.5 (109.2) 358.3 (105) 343.8 (100.7) 329.5 (96.6) 315.0 (92.3) 300.5 (88.1) 285.8 (83.8) 35 (1.7) 336.6 (98.7) 323.6 (94.8) 310.4 (91) 297.2 (87.1) 283.9 (83.2) 270.7 (79.3) 257.3 (75.4) 55 (12.8) 579.2 (169.7) 558.2 (163.6) 537.4 (157.5) 516.2 (151.3) 495.2 (145.1) 474.0 (138.9) 452.6 (132.6) 50 (10) 528.8 (155) 509.5 (149.3) 489.9 (143.6) 470.6 (137.9) 450.9 (132.1) 431.3 (126.4) 411.6 (120.6) 45 (7.2) 481.3 (141.1) 463.5 (135.8) 445.6 (130.6) 427.6 (125.3) 409.5 (120) 391.4 (114.7) 373.2 (109.4) 40 (4.4) 436.8 (128) 420.4 (123.2) 404.0 (118.4) 387.5 (113.5) 370.9 (108.7) 354.1 (103.8) 337.5 (98.9) 35 (1.7) 395.2 (115.8) 380.1 (111.4) 365.2 (107) 349.9 (102.5) 334.7 (98.1) 319.4 (93.6) 304.1 (89.1) 55 (12.8) 763.6 (223.8) 736.9 (216) 710.0 (208.1) 683.1 (200.2) 656.3 (192.3) 629.2 (184.4) 602.1 (176.4) 50 (10) 697.2 (204.3) 672.4 (197.1) 647.9 (189.9) 622.9 (182.5) 597.9 (175.2) 572.9 (167.9) 547.9 (160.6) 45 (7.2) 634.6 (186) 611.9 (179.3) 589.1 (172.6) 566.2 (165.9) 543.3 (159.2) 520.2 (152.4) 497.1 (145.7) 40 (4.4) 575.8 (168.8) 555.0 (162.7) 534.0 (156.5) 513.0 (150.4) 492.0 (144.2) 470.8 (138) 449.6 (131.8) 35 (1.7) 520.8 (152.6) 501.7 (147) 482.6 (141.4) 463.3 (135.8) 443.9 (130.1) 424.6 (124.4) 405.3 (118.8) 55 (12.8) 891.5 (261.3) 861.2 (252.4) 830.8 (243.5) 800.3 (234.5) 769.7 (225.6) 739.0 (216.6) 708.1 (207.5) 50 (10) 814.8 (238.8) 786.9 (230.6) 758.9 (222.4) 730.8 (214.2) 702.5 (205.9) 674.1 (197.6) 645.5 (189.2)

45 (7.2) 742.6 (217.6) 716.9 (210.1) 691.1 (202.5) 665.3 (195) 639.2 (187.3) 613.2 (179.7) 587.0 (172) 40 (4.4) 674.7 (197.7) 651.2 (190.9) 627.5 (183.9) 604.0 (177) 580.0 (170) 556.1 (163) 532.1 (156) 35 (1.7) 611.1 (179.1) 589.7 (172.8) 568.1 (166.5) 546.4 (160.1) 524.6 (153.7) 502.7 (147.3) 480.9 (140.9) 55 (12.8) 1114.7 (326.7) 1076.3 (315.4) 1037.2 (304) 997.9 (292.5) 958.2 (280.8) 918.3 (269.1) 878.2 (257.4) 50 (10) 1017.2 (298.1) 981.5 (287.7) 945.6 (277.1) 909.3 (266.5) 872.8 (255.8) 835.8 (244.9) 798.6 (234.1) 45 (7.2) 925.7 (271.3) 892.9 (261.7) 859.7 (252) 826.4 (242.2) 792.8 (232.3) 758.7 (222.4) 724.5 (212.3)

40 (4.4) 839.8 (246.1) 809.8 (237.3) 779.3 (228.4) 748.9 (219.5) 718.0 (210.4) 686.7 (201.3) 655.4 (192.1)

35 (1.7) 759.6 (222.6) 732.1 (214.5) 704.6 (206.5) 676.4 (198.2) 648.3 (190) 619.9 (181.7) 591.2 (173.2)

55 (12.8) 1299.1 (380.7) 1255.2 (367.9) 1210.9 (354.9) 1166.3 (341.8) 1121.2 (328.6) 1075.8 (315.3) 1030.3 (301.9)

50 (10) 1

45 (7.2) 1081.1 (316.8) 1043.9 (305.9) 1006.3 (294.9) 968.5 (283.8) 930.3 (272.6) 891.9 (261.4) 853.2 (250.1)

40 (4.4) 982.0 (287.8) 947.9 (277.8) 913.7 (267.8) 879.1 (257.6) 844.2 (247.4) 808.9 (237.1) 773.6 (226.7)

35 (1.7) 889.4 (260.6) 858.5 (251.6) 827.2 (242.4) 795.7 (233.2) 763.8 (223.8) 731.9 (214.5) 699.5 (205)

55 (12.8) 1494.6 (438) 1442.3 (422.7) 1389.6 (407.2) 1336.4 (391.7) 1283.1 (376) 1229.3 (360.3) 1175.2 (344.4)

50 (10) 1366.9 (400.6) 1318.6 (386.4) 1269.9 (372.2) 1220.7 (357.8) 1171.4 (343.3) 1121.6 (328.7) 1071.4 (314)

45 (7.2) 1246.4 (365.3) 1201.8 (352.2) 1157.1 (339.1) 1111 .7 (325.8) 1066.2 (312.5) 1020.4 (299) 974.2 (285.5)

40 (4.4) 1133.0 (332) 1092.2 (320.1) 1051.1 (308) 1009.7 (295.9) 967.7 (283.6) 925.7 (271.3) 883.5 (258.9)

35 (1.7) 1026.7 (300.9) 989.5 (290) 951.9 (279) 913.9 (267.8) 875.7 (256.6) 837.3 (245.4) 798.6 (234.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

186.7 (347.8) 1146.2 (335.9) 1105.4 (324) 1064.3 (311.9) 1022.7 (299.7) 980.9 (287.5) 938.7 (275.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

HIGH EFFICIENCY MODELS

BITZER

09/03/14

T40-TV-PDS-19

- 80 -

CAPACITY DATA -

R407C

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD031M8-B

Compressor

Model

4PES-15

TVD041M8-B

Compressor

Model

HIGH EFFICIENCY MODELS

4NES-20

TVD051M8-B

Compressor

Model

4HE-25

TVD061M8-B

Compressor

Model

4GE-30

TVD071M8-B

Compressor

Model

6HE-35

TVD081M8-B

Compressor

Model

6GE-40

TVD101M8-B

Compressor

Model

6FE-50

NOTES: - Above ratings are based on mean temperature. - To convert to dew point ratings, use 0.95 multplier.

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 303.2 (88.9) 291.3 (85.4) 279.3 (81.9) 267.1 (78.3) 255.2 (74.8) 243.0 (71.2) 230.6 (67.6) 25 (-3.9) 272.0 (79.7) 261.2 (76.6) 250.3 (73.4) 239.2 (70.1) 228.3 (66.9) 217.1 (63.6) 206.0 (60.4) 20 (-6.7) 243.2 (71.3) 233.3 (68.4) 223.4 (65.5) 213.4 (62.5) 203.5 (59.6) 193.4 (56.7) 183.1 (53.7) 15 (-9.4) 216.3 (63.4) 207.5 (60.8) 198.5 (58.2) 189.4 (55.5) 180.4 (52.9) 171.4 (50.2) 162.1 (47.5) 10 (-12.2) 191.7 (56.2) 183.5 (53.8) 175.6 (51.5) 167.4 (49.1) 159.2 (46.7) 151.0 (44.3) 142.6 (41.8)

30 (-1.1) 356.4 (104.4) 342.7 (100.4) 328.9 (96.4) 315.0 (92.3) 301.1 (88.3) 287.3 (84.2) 273.2 (80.1) 25 (-3.9) 320.0 (93.8) 307.7 (90.2) 295.3 (86.5) 282.7 (82.8) 270.1 (79.1) 257.3 (75.4) 244.4 (71.6) 20 (-6.7) 286.7 (84) 275.3 (80.7) 264.0 (77.4) 252.6 (74) 241.1 (70.7) 229.5 (67.3) 218.0 (63.9) 15 (-9.4) 255.4 (74.8) 245.3 (71.9) 235.0 (68.9) 224.7 (65.9) 214.4 (62.8) 203.9 (59.8) 193.4 (56.7) 10 (-12.2) 226.6 (66.4) 217.6 (63.8) 208.3 (61.1) 198.9 (58.3) 189.6 (55.6) 180.2 (52.8) 170.7 (50) 30 (-1.1) 469.4 (137.6) 451.9 (132.4) 434.5 (127.3) 416.9 (122.2) 399.2 (117) 381.6 (111.8) 363.9 (106.7) 25 (-3.9) 421.5 (123.5) 405.5 (118.8) 389.8 (114.2) 373.6 (109.5) 357.6 (104.8) 341.7 (100.1) 325.5 (95.4) 20 (-6.7) 377.0 (110.5) 362.5 (106.2) 348.0 (102) 333.5 (97.7) 319.0 (93.5) 304.3 (89.2) 289.8 (84.9) 15 (-9.4) 335.6 (98.3) 322.6 (94.5) 309.3 (90.7) 296.1 (86.8) 282.9 (82.9) 269.9 (79.1) 256.6 (75.2) 10 (-12.2) 297.4 (87.1) 285.4 (83.6) 273.4 (80.1) 261.5 (76.6) 249.7 (73.2) 237.7 (69.7) 226.0 (66.2) 30 (-1.1) 551.7 (161.7) 532.1 (156) 512.4 (150.2) 492.7 (144.4) 472.9 (138.6) 453.2 (132.8) 433.2 (127) 25 (-3.9) 496.2 (145.4) 478.4 (140.2) 460.7 (135) 442.7 (129.7) 424.8 (124.5) 406.8 (119.2) 388.7 (113.9) 20 (-6.7) 444.8 (130.4) 428.6 (125.6) 412.4 (120.9) 396.3 (116.1) 379.9 (111.3) 363.7 (106.6) 347.3 (101.8) 15 (-9.4) 396.9 (116.3) 382.2 (112) 367.7 (107.8) 353.0 (103.5) 338.3 (99.1) 323.6 (94.8) 308.9 (90.5)

10 (-12.2) 352.6 (103.3) 339.4 (99.5) 326.1 (95.6) 312.9 (91.7) 299.7 (87.8) 286.4 (83.9) 273.0 (80) 30 (-1.1) 684.8 (200.7) 659.8 (193.4) 634.6 (186) 609.2 (178.5) 583.6 (171) 557.6 (163.4) 531.7 (155.8) 25 (-3.9) 615.3 (180.3) 592.6 (173.7) 569.9 (167) 546.8 (160.3) 523.5 (153.4) 500.0 (146.5) 476.5 (139.6)

20 (-6.7) 550.8 (161.4) 530.5 (155.5) 509.9 (149.4) 488.9 (143.3) 467.9 (137.1) 446.7 (130.9) 425.5 (124.7) 15 (-9.4) 491.2 (144) 472.7 (138.5) 454.2 (133.1) 435.3 (127.6) 416.4 (122) 397.5 (116.5) 378.4 (110.9) 10 (-12.2) 436.0 (127.8) 419.6 (123) 402.8 (1 30 (-1.1) 803.0 (235.3) 775.1 (227.2) 746.8 (218.9) 718.0 (210.4) 689.2 (202) 660.0 (193.4) 630.8 (184.9) 25 (-3.9) 722.8 (211.8) 697.6 (204.5) 672.0 (196.9) 646.0 (189.3) 619.9 (181.7) 593.5 (173.9) 567.0 (166.2) 20 (-6.7) 648.5 (190.1) 625.6 (183.3) 602.5 (176.6) 579.2 (169.7) 555.7 (162.8) 531.9 (155.9) 508.2 (148.9) 15 (-9.4) 579.6 (169.9) 559.2 (163.9) 538.4 (157.8) 517.4 (151.6) 496.2 (145.4) 475.0 (139.2) 453.8 (133) 10 (-12.2) 516.0 (151.2) 497.7 (145.9) 479.0 (140.4) 460.3 (134.9) 441.4 (129.4) 422.5 (123.8) 403.4 (118.2) 30 (-1.1) 927.6 (271.8) 893.6 (261.9) 859.3 (251.8) 824.9 (241.7) 790.0 (231.5) 755.0 (221.3) 719.9 (211) 25 (-3.9) 835.0 (244.7) 804.3 (235.7) 773.2 (226.6) 741.9 (217.4) 710.2 (208.1) 678.5 (198.9) 646.8 (189.6) 20 (-6.7) 748.9 (219.5) 721.1 (211.3) 693.0 (203.1) 664.9 (194.9) 636.3 (186.5) 607.7 (178.1) 579.0 (169.7) 15 (-9.4) 669.1 (196.1) 644.1 (188.8) 618.9 (181.4) 593.3 (173.9) 567.6 (166.4) 542.0 (158.8) 516.2 (151.3) 10 (-12.2) 594.9 (174.4) 572.7 (167.8) 550.0 (161.2) 527.1 (154.5) 504.2 (147.8) 481.1 (141) 458.0 (134.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

18) 386.0 (113.1) 369.0 (108.1) 352.0 (103.1) 334.7 (98.1)

AMBIENT TEMPERATURE °F (°C)

BITZER

CONDENSING

UNIT

MODEL

TVD031H8-B

Compressor

4PES-15

TVD041H8-B

Compressor

4NES-20

TVD051H8-B

Compressor

4HE-25

TVD061H8-B

Compressor

4GE-30

TVD071H8-B

Compressor

6HE-35

TVD081H8-B

Compressor

6GE-40

TVD101H8-B

Compressor

6FE-50

CAPACITY DATA -

R404A

R507

60HzTVD-B

HIGH TEMP. HIGH EFFICIENCY MODELS

SATURATED

SUCTION

TEMPERATURE

° F ° C 45 (7.2) 439.4 (128.8) 420.6 (123.3) 401.8 (117.8) 383.2 (112.3) 364.8 (106.9) 346.4 (101.5) 328.2 (96.2) 40 (4.4) 402.6 (118) 385.0 (112.8) 367.6 (107.7) 350.2 (102.6) 333.0 (97.6) 315.8 (92.6) 299.0 (87.6) 35 (1.7) 367.6 (107.7) 351.2 (102.9) 335.0 (98.2) 319.0 (93.5) 303.0 (88.8) 287.2 (84.2) 271.4 (79.5) 45 (7.2) 517.0 (151.5) 495.4 (145.2) 473.8 (138.9) 452.4 (132.6) 431.2 (126.4) 410.0 (120.2) 389.0 (114) 40 (4.4) 474.2 (139) 454.0 (133.1) 434.0 (127.2) 414.2 (121.4) 394.4 (115.6) 374.6 (109.8) 355.0 (104) 35 (1.7) 433.6 (127.1) 415.0 (121.6) 396.4 (116.2) 378.0 (110.8) 359.6 (105.4) 341.4 (100.1) 323.2 (94.7) 45 (7.2) 666.6 (195.4) 639.4 (187.4) 612.0 (179.4) 584.8 (171.4) 557.4 (163.4) 530.2 (155.4) 503.0 (147.4) 40 (4.4) 613.6 (179.8) 588.2 (172.4) 562.8 (164.9) 537.4 (157.5) 512.0 (150.1) 486.6 (142.6) 461.2 (135.2) 35 (1.7) 563.2 (165.1) 539.6 (158.1) 516.0 (151.2) 492.4 (144.3) 468.8 (137.4) 445.4 (130.5) 421.8 (123.6) 45 (7.2) 766.4 (224.6) 734.8 (215.3) 703.0 (206) 671.0 (196.6) 639.2 (187.3) 607.4 (178) 575.6 (168.7) 40 (4.4) 705.6 (206.8) 676.2 (198.2) 646.6 (189.5) 617.0 (180.8) 587.4 (172.1) 557.8 (163.5) 528.2 (154.8) 35 (1.7) 647.8 (189.9) 620.4 (181.8) 593.2 (173.8) 565.8 (165.8) 538.2 (157.7) 510.8 (149.7) 483.4 (141.7) 45 (7.2) 984.6 (288.6) 944.6 (276.8) 904.6 (265.1) 864.8 (253.4) 825.0 (241.8) 785.2 (230.1) 745.6 (218.5) 40 (4.4) 905.8 (265.5) 868.6 (254.6) 831.4 (243.7) 794.2 (232.8) 757.2 (221.9) 720.2 (211.1) 683.4 (200.3) 35 (1.7) 830.8 (243.5) 796.4 (233.4) 762.0 (223.3) 727.6 (213.2) 693.2 (203.2) 658.8 (193.1) 624.6 (183.1) 45 (7.2) 1115.4 (326.9) 1068.6 (313.2) 1022.0 (299.5) 975.4 (285.9) 929.0 (272.3) 882.6 (258.7) 836.2 (245.1) 40 (4.4) 1027.2 (301) 983.8 (288.3) 940.6 (275.7) 897.4 (263) 854.2 (250.3) 811.0 (237.7) 768.0 (225.1) 35 (1.7) 943.4 (276.5) 903.4 (264.8) 863.4 (253) 823.4 (241.3) 783.4 (229.6) 743.4 (217.9) 703.6 (206.2) 45 (7.2) 1306.0 (382.7) 1250.2 (366.4) 1194.4 (350) 1138.6 (333.7) 1082.8 (317.3) 1027.2 (301) 971.4 (284.7) 40 (4.4) 1206.4 (353.6) 1154.6 (338.4) 1102.8 (323.2) 1051.0 (308) 999.2 (292.8) 947.4 (277.7) 895.6 (262.5) 35 (1.7) 1111 .4 (325.7) 1063.4 (311.7) 1015.6 (297.6) 967.6 (283.6) 919.6 (269.5) 871.6 (255.4) 823.6 (241.4)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BITZER

09/03/14

T40-TV-PDS-19

- 81 -

CAPACITY DATA -

R404A

R507

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD031M8-B

Compressor

Model

4PES-15

TVD041M8-B

Compressor

Model

4NES-20

TVD051M8-B

Compressor

Model

4HE-25

TVD061M8-B

Compressor

Model

4GE-30

TVD071M8-B

Compressor

Model

6HE-35

TVD081M8-B

Compressor

Model

6GE-40

TVD101M8-B

Compressor

Model

6FE-50

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 334.4 (98) 319.4 (93.6) 304.4 (89.2) 289.6 (84.9) 274.8 (80.5) 260.2 (76.3) 245.6 (72) 25 (-3.9) 303.4 (88.9) 289.4 (84.8) 275.6 (80.8) 262.0 (76.8) 248.4 (72.8) 234.8 (68.8) 221.4 (64.9) 20 (-6.7) 274.0 (80.3) 261.4 (76.6) 248.8 (72.9) 236.2 (69.2) 223.6 (65.5) 211.2 (61.9) 199.0 (58.3) 15 (-9.4) 246.6 (72.3) 235.0 (68.9) 223.4 (65.5) 212.0 (62.1) 200.6 (58.8) 189.2 (55.4) 178.0 (52.2) 10 (-12.2) 221.0 (64.8) 210.4 (61.7) 200.0 (58.6) 189.6 (55.6) 179.2 (52.5) 168.8 (49.5) 158.6 (46.5)

5 (-15) 197.2 (57.8) 187.6 (55) 178.0 (52.2) 168.6 (49.4) 159.2 (46.7) 150.0 (44) 140.6 (41.2)

0 (-17.8) 175.0 (51.3) 166.4 (48.8) 157.8 (46.2) 149.2 (43.7) 140.8 (41.3) 132.4 (38.8) 124.2 (36.4) 30 (-1.1) 395.4 (115.9) 378.2 (110.8) 361.0 (105.8) 343.8 (100.8) 327.0 (95.8) 310.0 (90.9) 293.4 (86) 25 (-3.9) 359.2 (105.3) 343.4 (100.6) 327.6 (96) 311.8 (91.4) 296.2 (86.8) 280.8 (82.3) 265.4 (77.8) 20 (-6.7) 325.2 (95.3) 310.8 (91.1) 296.2 (86.8) 282.0 (82.6) 267.6 (78.4) 253.4 (74.3) 239.2 (70.1) 15 (-9.4) 293.4 (86) 280.2 (82.1) 267.0 (78.2) 253.8 (74.4) 240.8 (70.6) 227.8 (66.8) 215.0 (63) 10 (-12.2) 263.6 (77.3) 251.6 (73.7) 239.6 (70.2) 227.8 (66.8) 216.0 (63.3) 204.2 (59.8) 192.4 (56.4)

5 (-15) 235.8 (69.1) 225.0 (65.9) 214.2 (62.8) 203.6 (59.7) 192.8 (56.5) 182.2 (53.4) 171.6 (50.3)

0 (-17.8) 210.2 (61.6) 200.4 (58.7) 190.6 (55.9) 181.0 (53) 171.4 (50.2) 161.8 (47.4) 152.4 (44.7) 30 (-1.1) 515.2 (151) 493.6 (144.7) 471.8 (138.3) 450.0 (131.9) 428.2 (125.5) 406.4 (119.1) 384.6 (112.7) 25 (-3.9) 470.0 (137.7) 450.0 (131.9) 430.0 (126) 410.0 (120.2) 389.8 (114.2) 369.8 (108.4) 349.8 (102.5) 20 (-6.7) 427.2 (125.2) 409.0 (119.9) 390.6 (114.5) 372.2 (109.1) 353.8 (103.7) 335.4 (98.3) 317.0 (92.9)

15 (-9.4) 387.0 (113.4) 370.4 (108.6) 353.6 (103.6) 336.8 (98.7) 320.0 (93.8) 303.2 (88.9) 286.4 (83.9) 10 (-12.2) 349.2 (102.3) 334.2 (97.9) 319.0 (93.5) 303.6 (89) 288.4 (84.5) 273.0 (80) 257.8 (75.6)

5 (-15) 314.0 (92) 300.2 (88) 286.4 (83.9) 272.6 (79.9) 258.8 (75.8) 244.8 (71.7) 231.0 (67.7)

0 (-17.8) 281.0 (82.4) 268.6 (78.7) 256.2 (75.1) 243.8 (71.5) 231.2 (67.8) 218.6 (64.1) 206.2 (60.4)

30 (-1.1) 592.8 (173.7) 568.8 (166.7) 545.0 (159.7) 521.2 (152.7) 497.4 (145.8) 473.6 (138.8) 450.0 (131.9)

25 (-3.9) 540.0 (158.3) 518.2 (151.9) 496.4 (145.5) 474.6 (139.1) 452.8 (132.7) 431.0 20 (-6.7) 490.2 (143.7) 470.2 (137.8) 450.4 (132) 430.6 (126.2) 410.8 (120.4) 391.0 (114.6) 371.2 (108.8) 15 (-9.4) 443.2 (129.9) 425.0 (124.6) 407.0 (119.3) 389.0 (1 10 (-12.2) 399.0 (116.9) 382.6 (112.1) 366.4 (107.4) 350.0 (102.6) 333.8 (97.8) 317.6 (93.1) 301.4 (88.3)

5 (-15) 357.6 (104.8) 343.0 (100.5) 328.2 (96.2) 313.6 (91.9) 299.0 (87.6) 284.4 (83.3) 269.8 (79.1)

0 (-17.8) 319.0 (93.5) 305.8 (89.6) 292.6 (85.8) 279.6 (81.9) 266.4 (78.1) 253.4 (74.3) 240.2 (70.4) 30 (-1.1) 760.0 (222.7) 728.2 (213.4) 696.4 (204.1) 664.6 (194.8) 632.8 (185.5) 601.0 (176.1) 569.2 (166.8) 25 (-3.9) 693.0 (203.1) 663.8 (194.5) 634.4 (185.9) 605.2 (177.4) 575.8 (168.7) 546.6 (160.2) 517.4 (151.6) 20 (-6.7) 629.8 (184.6) 603.0 (176.7) 576.2 (168.9) 549.2 (161) 522.4 (153.1) 495.6 (145.2) 468.6 (137.3) 15 (-9.4) 570.4 (167.2) 545.8 (160) 521.4 (152.8) 496.8 (145.6) 472.2 (138.4) 447.8 (131.2) 423.2 (124) 10 (-12.2) 514.6 (150.8) 492.4 (144.3) 470.2 (137.8) 447.8 (131.2) 425.4 (124.7) 403.0 (118.1) 380.6 (111.5)

5 (-15) 462.4 (135.5) 442.4 (129.7) 422.2 (123.7) 402.0 (117.8) 381.6 (111.8) 361.4 (105.9) 341.0 (99.9)

0 (-17.8) 413.8 (121.3) 395.8 (116) 377.6 (110.7) 359.2 (105.3) 341.0 (99.9) 322.6 (94.5) 304.2 (89.2) 30 (-1.1) 863.8 (253.2) 827.0 (242.4) 790.2 (231.6) 753.2 (220.7) 716.4 (210) 679.6 (199.2) 642.8 (188.4) 25 (-3.9) 788.6 (231.1) 754.8 (221.2) 721.0 (211.3) 687.2 (201.4) 653.4 (191.5) 619.4 (181.5) 585.6 (171.6) 20 (-6.7) 717.4 (210.2) 686.6 (201.2) 655.8 (192.2) 624.8 (183.1) 593.8 (174) 563.0 (165) 532.0 (155.9) 15 (-9.4) 650.4 (190.6) 622.4 (182.4) 594.4 (174.2) 566.2 (165.9) 538.0 (157.7) 509.8 (149.4) 481.6 (141.1) 10 (-12.2) 587.6 (172.2) 562.2 (164.8) 536.8 (157.3) 511.2 (149.8) 485.8 (142.4) 460.2 (134.9) 434.6 (127.4)

5 (-15) 528.6 (154.9) 505.8 (148.2) 482.8 (141.5) 459.8 (134.8) 436.8 (128) 413.8 (121.3) 390.6 (114.5)

0 (-17.8) 473.6 (138.8) 453.2 (132.8) 432.6 (126.8) 411.8 (120.7) 391.2 (114.6) 370.4 (108.6) 349.4 (102.4)

30 (-1.1) 1020.6 (299.1) 976.6 (286.2) 932.4 (273.3) 888.2 (260.3) 844.0 (247.4) 799.8 (234.4) - 25 (-3.9) 934.4 (273.8) 894.0 (262) 853.6 (250.2) 813.0 (238.3) 772.4 (226.4) 731.8 (214.5) 691.0 (202.5) 20 (-6.7) 852.4 (249.8) 815.8 (239.1) 778.8 (228.2) 741.6 (217.3) 704.6 (206.5) 667.4 (195.6) 630.2 (184.7) 15 (-9.4) 775.0 (227.1) 741.6 (217.3) 708.0 (207.5) 674.4 (197.6) 640.6 (187.7) 606.6 (177.8) 572.8 (167.9) 10 (-12.2) 702.0 (205.7) 671.8 (196.9) 641.4 (188) 610.8 (179) 580.2 (170) 549.6 (161.1) 518.6 (152)

5 (-15) 633.4 (185.6) 606.2 (177.7) 578.8 (169.6) 551.2 (161.5) 523.6 (153.5) 495.8 (145.3) 467.8 (137.1)

0 (-17.8) 568.8 (166.7) 544.4 (159.5) 519.8 (152.3) 495.2 (145.1) 470.2 (137.8) 445.2 (130.5) 420.2 (123.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 11 5 (46.1)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

(126.3) 409.4 (120)

14) 371.0 (108.7) 353.2 (103.5) 335.2 (98.2)

HIGH EFFICIENCY MODELS

BITZER

09/03/14

T40-TV-PDS-19

- 82 -

CAPACITY DATA -

R404A

R507

LOW TEMP. HIGH EFFICIENCY MODELS

60HzTVD-B

CONDENSING

UNIT

MODEL

TVD025L6-B

Compressor

Model

4NES-14

HIGH EFFICIENCY MODELS

TVD031L6-B

Compressor

Model

4HE-18

TVD041L6-B

Compressor

Model

4GE-23

TVD051L6-B

Compressor

Model

6HE-28

TVD061L6-B

Compressor

Model

6GE-34

TVD081L6-B

Compressor

Model

6FE-44

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 192.6 (56.4) 183.2 (53.7) 174.0 (51) 164.8 (48.3) 155.4 (45.5) 146.2 (42.8) 137.0 (40.2)

-5 (-20.6) 172.0 (50.4) 163.6 (47.9) 155.2 (45.5) 146.8 (43) 138.4 (40.6) 130.0 (38.1) 121.6 (35.6)

-10 (-23.3) 152.6 (44.7) 145.2 (42.6) 137.6 (40.3) 130.0 (38.1) 122.4 (35.9) 114.8 (33.6) 107.4 (31.5)

-15 (-26.1) 134.8 (39.5) 128.0 (37.5) 121.2 (35.5) 114.4 (33.5) 107.6 (31.5) 100.8 (29.5) 94.0 (27.5)

-20 (-28.9) 118.0 (34.6) 112.0 (32.8) 106.0 (31.1) 99.8 (29.2) 93.8 (27.5) 87.8 (25.7) 81.6 (23.9)

-25 (-31.7) 102.8 (30.1) 97.4 (28.5) 91.8 (26.9) 86.4 (25.3) 81.0 (23.7) 75.6 (22.2) 70.2 (20.6)

-30 (-34.4) 88.6 (26) 83.8 (24.6) 79.0 (23.2) 74.0 (21.7) 69.2 (20.3) 64.4 (18.9) 59.6 (17.5)

-35 (-37.2) 75.6 (22.2) 71.4 (20.9) 67.0 (19.6) 62.6 (18.3) 58.4 (17.1) 54.0 (15.8) 49.8 (14.6)

-40 (-40) 63.8 (18.7) 60.0 (17.6) 56.0 (16.4) 52.0 (15.2) 48.2 (14.1) 44.4 (13) 40.6 (11.9) 0 (-17.8) 273.6 (80.2) 261.4 (76.6) 249.4 (73.1) 237.2 (69.5) 225.2 (66) 213.0 (62.4) 201.0 (58.9)

-5 (-20.6) 245.0 (71.8) 234.0 (68.6) 223.2 (65.4) 212.2 (62.2) 201.2 (59) 190.4 (55.8) 179.4 (52.6)

-10 (-23.3) 218.2 (63.9) 208.4 (61.1) 198.6 (58.2) 188.8 (55.3) 179.0 (52.5) 169.2 (49.6) 159.4 (46.7)

-15 (-26.1) 193.4 (56.7) 184.6 (54.1) 175.8 (51.5) 167.0 (48.9) 158.2 (46.4) 149.4 (43.8) 140.6 (41.2)

-20 (-28.9) 170.2 (49.9) 162.4 (47.6) 154.6 (45.3) 146.6 (43) 138.8 (40.7) 131.0 (38.4) 123.2 (36.1)

-25 (-31.7) 148.8 (43.6) 141.8 (41.6) 134.8 (39.5) 127.8 (37.5) 120.8 (35.4) 113.8 (33.4) 106.8 (31.3)

-30 (-34.4) 129.0 (37.8) 122.8 (36) 116.6 (34.2) 110.2 (32.3) 104.0 (30.5) 97.8 (28.7) 91.6 (26.8)

-35 (-37.2) 110.8 (32.5) 105.2 (30.8) 99.6 (29.2) 94.0 (27.5) 88.6 (26) 83.0 (24.3) 77.6 (22.7)

-40 (-40) 93.8 (27.5) 89.0 (26.1) 84.0 (24.6) 79.0 (23.2) 74.0 (21.7) 69.2 (20.3) 64.2 (18.8) 0 (-17.8) 311.6 (91.3) 298.0 (87.3) 284.4 (83.3) 270.6 (79.3) 257.0 (75.3) 243.2 (71.3) 229.6 (67.3)

-5 (-20.6) 280.2 (82.1) 267.8 (78.5) 255.6 (74.9) 243.2 (71.3) 230.8 (67.6) 218.6 (64.1) 206.2 (60.4)

-10 (-23.3) 250.6 (73.4) 239.6 (70.2) 228.6 (67) 217.4 (63.7) 206.4 (60.5) 195.4 (57.3) 184.2 (54)

-15 (-26.1) 222.8 (65.3) 213.0 (62.4) 203.2 (59.6) 193.4 (56.7) 183.4 (53.7) 173.6 (50.9) 163.8 (48)

-20 (-28.9) 197.0 (57.7) 188.4 (55.2) 179.6 (52.6) 170.8 (50.1) 162.0 (47.5) 153.2 (44.9) 144.6 (42.4)

-25 (-31.7) 173.0 (50.7) 165.4 (48.5) 157.6 (46.2) 149.8 (43.9) 142.0 (41.6) 134.2 (39.3) 126.6 (37.1)

-30 (-34.4) 150.8 (44.2) 144.0 (42.2) 137.0 (40.2) 130.2 (38.2) 123.4 (36.2) 116.6 (34.2) 109.8 (32.2)

-35 (-37.2) 130.2 (38.2) 124.2 (36.4) 118.0 (34.6) 1

-40 (-40) 111.2 (32.6) 105.8 (31) 100.4 (29.4) 95.0 (27.8) 89.6 (26.3) 84.4 (24.7) 79.2 (23.2) 0 (-17.8) 388.2 (113.8) 370.8 (108.7) 353.4 (103.6) 336.2 (98.5) 319.0 (93.5) 301.8 (88.4) 284.6 (83.4)

-5 (-20.6) 348.8 (102.2) 333.0 (97.6) 317.4 (93) 301.6 (88.4) 286.0 (83.8) 270.4 (79.2) 254.8 (74.7)

-10 (-23.3) 311.8 (91.4) 297.6 (87.2) 283.4 (83.1) 269.2 (78.9) 255.0 (74.7) 241.0 (70.6) 226.8 (66.5)

-15 (-26.1) 277.0 (81.2) 264.4 (77.5) 251.6 (73.7) 238.8 (70) 226.2 (66.3) 213.4 (62.5) 200.6 (58.8)

-20 (-28.9) 244.8 (71.7) 233.2 (68.3) 221.8 (65) 210.4 (61.7) 199.0 (58.3) 187.6 (55) 176.2 (51.6)

-25 (-31.7) 214.6 (62.9) 204.4 (59.9) 194.2 (56.9) 184.0 (53.9) 173.6 (50.9) 163.4 (47.9) 153.2 (44.9)

-30 (-34.4) 186.6 (54.7) 177.4 (52) 168.4 (49.4) 159.2 (46.7) 150.0 (44) 141.0 (41.3) 131.8 (38.6)

-35 (-37.2) 160.8 (47.1) 152.6 (44.7) 144.4 (42.3) 136.2 (39.9) 128.0 (37.5) 119.8 (35.1) 111. 6 (32.7)

-40 (-40) 136.8 (40.1) 129.4 (37.9) 122.0 (35.8) 114.8 (33.6) 107.4 (31.5) 100.0 (29.3) 92.6 (27.1) 0 (-17.8) 444.2 (130.2) 425.0 (124.6) 405.8 (118.9) 386.4 (113.2) 367.2 (107.6) 347.8 (101.9) - -

-5 (-20.6) 401.6 (117.7) 384.2 (112.6) 367.0 (107.6) 349.6 (102.5) 332.0 (97.3) 314.6 (92.2) 296.8 (87)

-10 (-23.3) 361.2 (105.9) 345.8 (101.3) 330.2 (96.8) 314.6 (92.2) 299.0 (87.6) 283.2 (83) 267.2 (78.3)

-15 (-26.1) 323.4 (94.8) 309.4 (90.7) 295.6 (86.6) 281.6 (82.5) 267.6 (78.4) 253.4 (74.3) 239.0 (70)

-20 (-28.9) 287.6 (84.3) 275.4 (80.7) 263.0 (77.1) 250.6 (73.4) 238.0 (69.8) 225.4 (66.1) 212.6 (62.3)

-25 (-31.7) 254.2 (74.5) 243.4 (71.3) 232.4 (68.1) 221.2 (64.8) 210.0 (61.5) 198.8 (58.3) 187.4 (54.9)

-30 (-34.4) 223.2 (65.4) 213.4 (62.5) 203.6 (59.7) 193.8 (56.8) 183.8 (53.9) 173.8 (50.9) 163.6 (47.9)

-35 (-37.2) 194.0 (56.9) 185.4 (54.3) 176.8 (51.8) 168.0 (49.2) 159.2 (46.7) 150.2 (44) 141.0 (41.3)

-40 (-40) 167.2 (49) 159.4 (46.7) 151.6 (44.4) 143.8 (42.1) 135.8 (39.8) 127.8 (37.5) 119.4 (35) 0 (-17.8) 444.2 (130.2) 425.0 (124.6) 405.8 (118.9) 386.4 (113.2) 367.2 (107.6) 347.8 (101.9) - -

-5 (-20.6) 401.6 (117.7) 384.2 (112.6) 367.0 (107.6) 349.6 (102.5) 332.0 (97.3) 314.6 (92.2) 296.8 (87)

-10 (-23.3) 361.2 (105.9) 345.8 (101.3) 330.2 (96.8) 314.6 (92.2) 299.0 (87.6) 283.2 (83) 267.2 (78.3)

-15 (-26.1) 323.4 (94.8) 309.4 (90.7) 295.6 (86.6) 281.6 (82.5) 267.6 (78.4) 253.4 (74.3) 239.0 (70)

-20 (-28.9) 287.6 (84.3) 275.4 (80.7) 263.0 (77.1) 250.6 (73.4) 238.0 (69.8) 225.4 (66.1) 212.6 (62.3)

-25 (-31.7) 254.2 (74.5) 243.4 (71.3) 232.4 (68.1) 221.2 (64.8) 210.0 (61.5) 198.8 (58.3) 187.4 (54.9)

-30 (-34.4) 223.2 (65.4) 213.4 (62.5) 203.6 (59.7) 193.8 (56.8) 183.8 (53.9) 173.8 (50.9) 163.6 (47.9)

-35 (-37.2) 194.0 (56.9) 185.4 (54.3) 176.8 (51.8) 168.0 (49.2) 159.2 (46.7) 150.2 (44) 141.0 (41.3)

-40 (-40) 167.2 (49) 159.4 (46.7) 151.6 (44.4) 143.8 (42.1) 135.8 (39.8) 127.8 (37.5) 119.4 (35)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

12.0 (32.8) 106.0 (31.1) 100.0 (29.3) 94.0 (27.5)

ELECTRICAL DATA - SINGLE COMPRESSOR

09/03/14

T40-TV-PDS-19

- 83 -

60HzTVS-A

COPELAND

CONDENSING UNIT

MODEL

TVS016H8-

TVS023H8-

TVS026H8-

TVS031H8-

TVS036H8-

TVS041H8-

TVS016M8-

TVS023M8-

TVS026M8-

TVS031M8-

TVS036M8-

TVS041M8-

TVS051M8- HT4B -A 6DUNR49ME-AWD 460/3/60

TVS011L 6/8 -

TVS016L 6/8 -

TVS023L 6/8 -

TVS028L 6/8 -

TVS031L 6/8 -

TVS041L 6/8 - HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 3 5550 9.3 89.2 150

* 6DJ only available in 230V

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 3700 13.2 87.7 125 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 3700 6.2 42.5 70 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 2 3700 5.0 34.5 50 HT3B -A 4DBNR20ME-TSK 208-230/3/60 85.7 374 2 3700 13.2 120.3 200 HT4B -A 4DBNR20ME-TSK 460/3/60 42.9 187 2 3700 6.2 59.8 100 HT5B -A 4DBNR20ME-TSE 575/3//60 33.6 135 2 3700 5.0 47.0 80 HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 3 5550 19.8 153.7 250 HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 3 5550 9.3 76.3 125 HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 3 5550 7.5 56.0 90 HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 3 5550 19.8 162.7 250 HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 3 5550 9.3 80.7 125 HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 3 5550 7.5 69.1 11 0 HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 4 7400 26.4 203.2 300 HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 4 7400 12.4 100.8 150 HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 4 7400 10.0 77.0 125 HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 4 7400 26.4 224.7 350 HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 4 7400 12.4 111. 5 175 HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 4 7400 10.0 91.3 150 HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 3700 13.2 87.7 125 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 3700 6.2 42.5 70 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 2 3700 5.0 34.5 50 HT3B -A 4DBNR20ME-TSK 208-230/3/60 72.1 374 2 3700 13.2 103.3 175 HT4B -A 4DBNR20ME-TSK 460/3/60 36.1 187 2 3700 6.2 51.3 80 HT5B -A 4DBNR20ME-TSE 575/3//60 31.4 135 2 3700 5.0 44.3 70 HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 3 5550 19.8 122.4 200 HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 3 5550 9.3 60.7 100 HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 3 5550 7.5 50.5 80 HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 3 5550 19.8 151.6 250 HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 3 5550 9.3 75.2 125 HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 3 5550 7.5 62.6 100 HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 4 7400 26.4 182.8 300 HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 4 7400 12.4 90.7 150 HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 4 7400 10.0 63.9 100 HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 4 7400 HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 4 7400 12.4 101.7 150 HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 4 7400 10.0 75.1 125

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 1 1850 6.6 58.4 90 HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 1 1850 3.1 26.4 40 HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 1 1850 2.5 22.8 35 HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 2 3700 13.2 79.0 125 HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 2 3700 6.2 39.1 60 HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 11 3 2 3700 5.0 31.1 50 HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 2 3700 13.2 93.6 150 HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 2 3700 6.2 46.3 70 HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 2 3700 5.0 41.4 70 HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 2 3700 13.2 114.1 175 HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 2 3700 6.2 56.7 90 HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 2 3700 5.0 45.6 70 HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 2 3700 13.2 132.7 225 HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 2 3700 6.2 66.0 110 HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 2 3700 5.0 54.5 90

COMPRESSOR

MODEL NO.

HIGH EFFICIENCY MODELS

POWER

SUPPLY

COMPRESSOR

RLA LRA QTY WATTS FLA MCA MOP

84.2 482 4 7400 12.4 117.7 200

CONDENSER

FAN MOTOR

UNIT

26.4 205.0 300

HIGH EFFICIENCY MODELS

ELECTRICAL DATA - DOUBLE COMPRESSOR

09/03/14

T40-TV-PDS-19

- 84 -

COPELAND

CONDENSING UNIT

MODEL

TVD031H8-

TVD045H8-

TVD051H8-

HIGH EFFICIENCY MODELS

TVD061H8-

TVD071H8-

TVD081H8-

TVD031M8-

TVD045M8-

TVD051M8-

TVD061M8-

TVD071M8-

TVD081M8-

TVS101M8- HT4B -A 6DUNR49ME-AWD 460/3/60

TVD021L 6/8 -

TVD031L 6/8-

TVD045L 6/8-

TVD055L 6/8 -

TVD061L 6/8 -

TVS081L 6/8 - HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 6 111 00 18.6 162.4 225

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 7400 26.4 160.5 200 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 7400 12.4 77.7 100 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 4 7400 10.0 63.1 80 HT3B -A 4DBNR20ME-TSK 208-230/3/60 85.7 374 4 7400 26.4 219.2 300 HT4B -A 4DBNR20ME-TSK 460/3/60 42.9 187 4 7400 12.4 108.9 150 HT5B -A 4DBNR20ME-TSE 575/3//60 33.6 135 4 7400 10.0 85.6 110 HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 6 1110 0 39.6 280.6 350 HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 6 111 00 18.6 139.2 175 HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 6 111 00 15.0 102.3 125 HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 6 111 00 39.6 296.8 400 HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 6 111 00 18.6 147.1 200 HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 6 11100 15.0 125.9 175 HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 8 14800 52.8 371.0 500 HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 8 14800 24.8 183.9 250 HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 8 14800 20.0 140.6 175 HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 8 14800 52.8 409.7 500 HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 8 14800 24.8 203.2 250 HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 8 14800 20.0 166.3 225 HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 7400 26.4 160.5 200 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 7400 12.4 77.7 100 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 4 7400 10.0 63.1 80 HT3B -A 4DBNR20ME-TSK 208-230/3/60 72.1 374 4 7400 26.4 188.6 250 HT4B -A 4DBNR20ME-TSK 460/3/60 36.1 187 4 7400 12.4 93.6 125 HT5B -A 4DBNR20ME-TSE 575/3//60 31.4 135 4 7400 10.0 80.7 110 HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 6 11100 39.6 224.3 300 HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 6 111 00 18.6 111 .1 150 HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 6 111 00 15.0 92.4 125 HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 6 111 00 39.6 276.8 350 HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 6 111 00 18.6 137.2 175 HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 6 11100 15.0 114.2 150 HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 8 14800 52.8 334.3 450 HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 8 14800 24.8 165.7 225 HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 8 14800 20.0 117.0 150 HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 8 14800 HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 8 14800 24.8 185.5 250 HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 8 14800 20.0 137.2 175

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 2 3700 13.2 106.4 125 HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 2 3700 6.2 48.1 60 HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 2 3700 5.0 41.5 50 HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 4 7400 26.4 144.8 175 HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 4 7400 12.4 71.6 90 HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 11 3 4 7400 10.0 57.0 70 HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 4 7400 26.4 171.1 225 HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 4 7400 12.4 84.6 11 0 HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 4 7400 10.0 75.5 100 HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 4 7400 26.4 208.0 250 HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 4 7400 12.4 103.3 125 HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 4 7400 10.0 83.1 110 HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 4 7400 26.4 241.5 300 HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 4 7400 12.4 120.0 150 HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 4 7400 10.0 99.1 125

COMPRESSOR

HIGH EFFICIENCY MODELS

COMPRESSOR

RLA LRA QTY WATTS FLA MCA MOP

84.2 482 8 14800 24.8 214.3 250

MODEL NO.

POWER

SUPPLY

CONDENSER

FAN MOTOR

52.8 374.3 500

60HzTVD-A

UNIT

* 6DJ only available in 230V

BITZER

09/03/14

T40-TV-PDS-19

- 85 -

CONDENSING UNIT

MODEL

TVS016H8-

TVS021H8-

TVS026H8-

TVS031H8-

TVS036H8-

TVS041H8-

TVS051H8-

TVS016M8-

TVS021M8-

TVS026M8-

TVS031M8-

TVS036M8-

TVS041M8-

TVS051M8-

TVS013L 6/8 -

TVS016L 6/8 -

TVS021L 6/8 -

TVS026L 6/8 -

TVS031L 6/8 -

TVS041L 6/8 -

ELECTRICAL DATA - SINGLE COMPRESSOR

60HzTVS-B

HIGH EFFICIENCY MODELS

COMPRESSOR

HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 2 3700 13.2 88.2 125 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 2 3700 6.2 40.1 60 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 2 3700 5.0 32.3 50 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 2 3700 5.0 37.9 60 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 3 5550 19.8 136.3 225 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 3 5550 9.3 61.9 100 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 3 5550 7.5 49.5 80 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 3 5550 19.8 158.1 250 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 3 5550 9.3 71.8 11 0 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 3 5550 7.5 57.5 90 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 4 7400 26.4 188.3 300 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 4 7400 12.4 85.7 125 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 4 7400 10.0 68.0 110 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 4 7400 26.4 243.7 400 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 4 7400 12.4 110.7 175 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 4 7400 10.0 88.6 150 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 4 7400 26.4 247.5 400 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 4 7400 12.4 112.4 175 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 4 7400 10.0 89.5 150 HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 2 3700 13.2 88.2 125 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 2 3700 6.2 40.1 60 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 2 3700 5.0 32.3 50 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 2 3700 5.0 37.9 60 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 3 5550 19.8 136.3 225 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 3 5550 9.3 61.9 100 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 3 5550 7.5 49.5 80 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 3 5550 19.8 158.1 250 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 3 5550 9.3 71.8 11 0 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 3 5550 7.5 57.5 90 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 4 7400 26.4 188.3 300 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 4 7400 12.4 85.7 125 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 4 7400 10.0 68.0 110 HT3B -B 6GE-40-2NU-Y HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 4 7400 12.4 110.7 175 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 4 7400 10.0 88.6 150 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 4 7400 26.4 247.5 400 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 4 7400 12.4 112.4 175 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 4 7400 10.0 89.5 150 HT3B -B 4NES-14-2NU-Y 208-230/3/60 49.0 252 1 1850 6.6 67.9 110 HT4B -B 4NES-14-2NU-Y 460/3/60 22.1 126 1 1850 3.1 30.7 50 HT5B -B 4NES-14-5PU-Y 575/3//60 17.7 101 1 1850 2.5 24.6 40 HT3B -B 4HE-18-2NU-Y 208-230/3/60 66.7 352 2 3700 13.2 96.6 150 HT4B -B 4HE-18-2NU-Y 460/3/60 30.1 176 2 3700 6.2 43.8 70 HT5B -B 4HE-18-5PU-Y 575/3//60 24.1 140 2 3700 5.0 35.1 50 HT3B -B 4GE-23-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4GE-23-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4GE-23-5PU-Y 575/3//60 25.7 140 2 3700 5.0 37.1 60 HT3B -B 6HE-28-2NU-Y 208-230/3/60 95.6 490 2 3700 13.2 132.7 225 HT4B -B 6HE-28-2NU-Y 460/3/60 43.2 245 2 3700 6.2 60.2 100 HT5B -B 6HE-28-5PU-Y 575/3//60 34.6 196 2 3700 5.0 48.3 80 HT3B -B 6GE-34-2NU-Y 208-230/3/60 104.3 490 2 3700 13.2 143.6 225 HT4B -B 6GE-34-2NU-Y 460/3/60 47.1 245 2 3700 6.2 65.1 11 0 HT5B -B 6GE-34-5PU-Y 575/3//60 37.1 196 2 3700 5.0 51.4 80 HT3B -B 6FE-44-2NU-Y 208-230/3/60 120.1 700 3 5550 19.8 169.9 250 HT4B -B 6FE-44-2NU-Y 460/3/60 54.3 350 3 5550 9.3 77.2 125 HT5B -B 6FE-44-5PU-Y 575/3//60 43.6 280 3 5550 7.5 62.0 100

MODEL NO.

POWER SUPPLY

208-230/3/60 173.8 700 4 7400 26.4 243.7 400

COMPRESSOR CONDENSER FAN MTR. UNIT RLA LRA QTY WATTS FLA MCA MOP

HIGH EFFICIENCY MODELS

ELECTRICAL DATA - DOUBLE COMPRESSOR

09/03/14

T40-TV-PDS-19

- 86 -

BITZER

CONDENSING UNIT

MODEL

TVD031H8-

TVD041H8-

TVD051H8-

TVD061H8-

HIGH EFFICIENCY MODELS

TVD071H8-

TVD081H8-

TVD101H8-

TVD031M8-

TVD041M8-

TVD051M8-

TVD061M8-

TVD071M8-

TVD081M8-

TVD101M8-

TVD025L 6/8 -

TVD031L 6/8 -

TVD041L 6/8 -

TVD051L 6/8 -

TVD061L 6/8 -

TVD081L 6/8 -

HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 4 7400 26.4 161.4 200 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 4 7400 12.4 73.4 100 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 4 7400 10.0 59.1 80 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 4 7400 26.4 186.4 250 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 4 7400 12.4 84.6 11 0 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 4 7400 10.0 69.2 90 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 6 111 00 39.6 249.3 300 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 6 111 0 0 18.6 113.3 150 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 6 1110 0 15.0 90.6 11 0 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 6 11100 39.6 288.5 350 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 6 1110 0 18.6 131.1 175 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 6 111 00 15.0 105.0 125 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 8 14800 52.8 344.2 450 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 8 14800 24.8 156.7 200 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 8 14800 20.0 124.4 150 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 8 14800 52.8 443.9 600 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 8 14800 24.8 201.7 250 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 8 14800 20.0 161.5 200 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 8 14800 52.8 450.8 600 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 8 14800 24.8 204.8 250 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 8 14800 20.0 163.1 225 HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 4 7400 26.4 161.4 200 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 4 7400 12.4 73.4 100 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 117 4 7400 10.0 59.1 80 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 4 7400 26.4 186.4 250 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 4 7400 12.4 84.6 11 0 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 4 7400 10.0 69.2 90 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 6 111 00 39.6 249.3 300 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 6 111 0 0 18.6 113.3 150 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 6 1110 0 15.0 90.6 11 0 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 6 11100 39.6 288.5 350 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 6 1110 0 18.6 131.1 175 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 6 111 00 15.0 105.0 125 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 8 14800 52.8 344.2 450 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 8 14800 24.8 156.7 200 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 8 14800 20.0 124.4 150 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 8 14800 52.8 443.9 600 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 8 14800 24.8 201.7 250 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 8 14800 20.0 161.5 200 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 8 14800 52.8 450.8 600 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 8 14800 24.8 204.8 250 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 8 14800 20.0 163.1 225 HT3B -B 4NES-14-2NU-Y HT4B -B 4NES-14-2NU-Y 460/3/60 22.1 126 2 3700 6.2 55.9 70 HT5B -B 4NES-14-5PU-Y 575/3//60 17.7 101 2 3700 5.0 44.8 60 HT3B -B 4HE-18-2NU-Y 208-230/3/60 66.7 352 4 7400 26.4 176.5 225 HT4B -B 4HE-18-2NU-Y 460/3/60 30.1 176 4 7400 12.4 80.1 110 HT5B -B 4HE-18-5PU-Y 575/3//60 24.1 140 4 7400 10.0 64.2 80

COMPRESSOR

HIGH EFFICIENCY MODELS

MODEL NO.

60HzTVD-B

POWER SUPPLY

208-230/3/60 49.0 252 2 3700 13.2 123.5 150

COMPRESSOR CONDENSER FAN MTR. UNIT RLA LRA QTY WATTS FLA MCA MOP

TVS-A

09/03/14

T40-TV-PDS-19

- 87 -

COPELAND

ELECTRICAL DATA - SINGLE COMPRESSOR

HIGH EFFICIENCY MODELS

with EC Motors only or

EC MOTORS

60Hz

CONDENSING UNIT

MODEL

TVS016H8-

TVS023H8-

TVS026H8-

TVS031H8-

TVS036H8-

TVS041H8-

TVS016M8-

TVS023M8-

TVS026M8-

TVS031M8-

TVS036M8-

TVS041M8-

TVS051M8- HT4B -A 6DUNR49ME-AWD 460/3/60

TVS011L 6/8 -

TVS016L 6/8 -

TVS023L 6/8 -

TVS028L 6/8 -

TVS031L 6/8 -

TVS041L 6/8 - HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 3 5550 9.3 89.2 150

* 6DJ only available in 230V

**=575Vunitsusea230Vmotorwithatransformer

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 3700 13.2 87.7 125 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 3700 6.2 42.5 70 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 2 3700 5.0 34.5 50 HT3B -A 4DBNR20ME-TSK 208-230/3/60 85.7 374 2 3700 13.2 120.3 200 HT4B -A 4DBNR20ME-TSK 460/3/60 42.9 187 2 3700 6.2 59.8 100 HT5B -A 4DBNR20ME-TSE 575/3//60 33.6 135 2 3700 5.0 47.0 80 HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 3 5550 19.8 153.7 250 HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 3 5550 9.3 76.3 125 HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 3 5550 7.5 56.0 90 HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 3 5550 19.8 162.7 250 HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 3 5550 9.3 80.7 125 HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 3 5550 7.5 69.1 11 0 HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 4 7400 26.4 203.2 300 HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 4 7400 12.4 100.8 150 HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 4 7400 10.0 77.0 125 HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 4 7400 26.4 224.7 350 HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 4 7400 12.4 111. 5 175 HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 4 7400 10.0 91.3 150 HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 3700 13.2 87.7 125 HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 3700 6.2 42.5 70 HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 11 0 2 3700 5.0 34.5 50 HT3B -A 4DBNR20ME-TSK 208-230/3/60 72.1 374 2 3700 13.2 103.3 175 HT4B -A 4DBNR20ME-TSK 460/3/60 36.1 187 2 3700 6.2 51.3 80 HT5B -A 4DBNR20ME-TSE 575/3//60 31.4 135 2 3700 5.0 44.3 70 HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 3 5550 19.8 122.4 200 HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 3 5550 9.3 60.7 100 HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 3 5550 7.5 50.5 80 HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 3 5550 19.8 151.6 250 HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 3 5550 9.3 75.2 125 HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 3 5550 7.5 62.6 100 HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 4 7400 26.4 182.8 300 HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 4 7400 12.4 90.7 150 HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 4 7400 10.0 63.9 100 HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 4 7400 HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 4 7400 12.4 101.7 150 HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 4 7400 10.0 75.1 125

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 1 1850 6.6 58.4 90 HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 1 1850 3.1 26.4 40 HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 1 1850 2.5 22.8 35 HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 2 3700 13.2 79.0 125 HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 2 3700 6.2 39.1 60 HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 11 3 2 3700 5.0 31.1 50 HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 2 3700 13.2 93.6 150 HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 2 3700 6.2 46.3 70 HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 2 3700 5.0 41.4 70 HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 2 3700 13.2 114.1 175 HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 2 3700 6.2 56.7 90 HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 2 3700 5.0 45.6 70 HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 2 3700 13.2 132.7 225 HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 2 3700 6.2 66.0 110 HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 2 3700 5.0 54.5 90

COMPRESSOR

MODEL NO.

POWER SUPPLY

COMPRESSOR

RLA LRA QTY WATTS FLA MCA MOP

84.2 482 4 7400 12.4 117.7 200

CONDENSER

FAN MTR. **

UNIT

26.4 205.0 300

HIGH EFFICIENCY MODELS

ELECTRICAL DATA - DOUBLE COMPRESSOR

09/03/14

T40-TV-PDS-19

- 88 -

EC MOTORS

TVD-A

COPELAND

CONDENSING UNIT

MODEL

TVD031H8-

TVD045H8-

TVD051H8-

HIGH EFFICIENCY MODELS

TVD061H8-

TVD071H8-

TVD081H8-

TVD031M8-

TVD045M8-

TVD051M8-

TVD061M8-

TVD071M8-

TVD081M8-

TVS101M8- HT4B -A 6DUNR49ME-AWD 460/3/60

TVD021L 6/8 -

TVD031L 6/8-

TVD045L 6/8-

TVD055L 6/8 -

TVD061L 6/8 -

TVS081L 6/8 - HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 6 111 00 18.6 162.4 225

* 6DJ only available in 230V

**=575Vunitsusea230Vmotorwithatransformer

COMPRESSOR

HIGH EFFICIENCY MODELS

with EC Motors only or

COMPRESSOR

RLA LRA QTY WATTS FLA MCA MOP

84.2 482 8 14800 24.8 214.3 250

MODEL NO.

POWER SUPPLY

CONDENSER

FAN MTR. **

52.8 374.3 500

60Hz

UNIT

TVS-B

09/03/14

T40-TV-PDS-19

- 89 -

BITZER

ELECTRICAL DATA - SINGLE COMPRESSOR

HIGH EFFICIENCY MODELS

with EC Motors only or

EC MOTORS

60Hz

CONDENSING UNIT

MODEL

TVS016H8-

TVS021H8-

TVS026H8-

TVS031H8-

TVS036H8-

TVS041H8-

TVS051H8-

TVS016M8-

TVS021M8-

TVS026M8-

TVS031M8-

TVS036M8-

TVS041M8-

TVS051M8-

TVS013L 6/8 -

TVS016L 6/8 -

TVS021L 6/8 -

TVS026L 6/8 -

TVS031L 6/8 -

TVS041L 6/8 -

**=575Vunitsusea230Vmotorwithatransformer

HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 2 3700 13.2 88.2 125 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 2 3700 6.2 40.1 60 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 11 7 2 3700 5.0 32.3 50 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 2 3700 5.0 37.9 60 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 3 5550 19.8 136.3 225 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 3 5550 9.3 61.9 100 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 3 5550 7.5 49.5 80 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 3 5550 19.8 158.1 250 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 3 5550 9.3 71.8 110 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 3 5550 7.5 57.5 90 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 4 7400 26.4 188.3 300 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 4 7400 12.4 85.7 125 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 4 7400 10.0 68.0 110 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 4 7400 26.4 243.7 400 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 4 7400 12.4 110.7 175 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 4 7400 10.0 88.6 150 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 4 7400 26.4 247.5 400 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 4 7400 12.4 112.4 175 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 4 7400 10.0 89.5 150 HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 2 3700 13.2 88.2 125 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 2 3700 6.2 40.1 60 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 11 7 2 3700 5.0 32.3 50 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 2 3700 5.0 37.9 60 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 3 5550 19.8 136.3 225 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 3 5550 9.3 61.9 100 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 3 5550 7.5 49.5 80 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 3 5550 19.8 158.1 250 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 3 5550 9.3 71.8 110 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 3 5550 7.5 57.5 90 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 4 7400 26.4 188.3 300 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 4 7400 12.4 85.7 125 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 4 7400 10.0 68.0 110 HT3B -B 6GE-40-2NU-Y HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 4 7400 12.4 110.7 175 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 4 7400 10.0 88.6 150 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 4 7400 26.4 247.5 400 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 4 7400 12.4 112.4 175 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 4 7400 10.0 89.5 150 HT3B -B 4NES-14-2NU-Y 208-230/3/60 49.0 252 1 1850 6.6 67.9 110 HT4B -B 4NES-14-2NU-Y 460/3/60 22.1 126 1 1850 3.1 30.7 50 HT5B -B 4NES-14-5PU-Y 575/3//60 17.7 101 1 1850 2.5 24.6 40 HT3B -B 4HE-18-2NU-Y 208-230/3/60 66.7 352 2 3700 13.2 96.6 150 HT4B -B 4HE-18-2NU-Y 460/3/60 30.1 176 2 3700 6.2 43.8 70 HT5B -B 4HE-18-5PU-Y 575/3//60 24.1 140 2 3700 5.0 35.1 50 HT3B -B 4GE-23-2NU-Y 208-230/3/60 71.1 352 2 3700 13.2 102.1 150 HT4B -B 4GE-23-2NU-Y 460/3/60 32.1 176 2 3700 6.2 46.3 70 HT5B -B 4GE-23-5PU-Y 575/3//60 25.7 140 2 3700 5.0 37.1 60 HT3B -B 6HE-28-2NU-Y 208-230/3/60 95.6 490 2 3700 13.2 132.7 225 HT4B -B 6HE-28-2NU-Y 460/3/60 43.2 245 2 3700 6.2 60.2 100 HT5B -B 6HE-28-5PU-Y 575/3//60 34.6 196 2 3700 5.0 48.3 80 HT3B -B 6GE-34-2NU-Y 208-230/3/60 104.3 490 2 3700 13.2 143.6 225 HT4B -B 6GE-34-2NU-Y 460/3/60 47.1 245 2 3700 6.2 65.1 110 HT5B -B 6GE-34-5PU-Y 575/3//60 37.1 196 2 3700 5.0 51.4 80 HT3B -B 6FE-44-2NU-Y 208-230/3/60 120.1 700 3 5550 19.8 169.9 250 HT4B -B 6FE-44-2NU-Y 460/3/60 54.3 350 3 5550 9.3 77.2 125 HT5B -B 6FE-44-5PU-Y 575/3//60 43.6 280 3 5550 7.5 62.0 100

COMPRESSOR

MODEL NO.

POWER

SUPPLY

208-230/3/60 173.8 700 4 7400 26.4 243.7 400

COMPRESSOR CONDENSER FAN MTR. ** UNIT RLA LRA QTY WATTS FLA MCA MOP

HIGH EFFICIENCY MODELS

TVD-B

09/03/14

T40-TV-PDS-19

- 90 -

ELECTRICAL DATA - DOUBLE COMPRESSOR

BITZER

CONDENSING UNIT

MODEL

TVD031H8-

TVD041H8-

TVD051H8-

TVD061H8-

HIGH EFFICIENCY MODELS

TVD071H8-

TVD081H8-

TVD101H8-

TVD031M8-

TVD041M8-

TVD051M8-

TVD061M8-

TVD071M8-

TVD081M8-

TVD101M8-

TVD025L 6/8 -

TVD031L 6/8 -

TVD041L 6/8 -

TVD051L 6/8 -

TVD061L 6/8 -

TVD081L 6/8 -

**=575Vunitsusea230Vmotorwithatransformer

HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 4 7400 26.4 161.4 200 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 4 7400 12.4 73.4 100 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 11 7 4 7400 10.0 59.1 80 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 4 7400 26.4 186.4 250 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 4 7400 12.4 84.6 11 0 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 4 7400 10.0 69.2 90 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 6 111 00 39.6 249.3 300 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 6 11100 18.6 113.3 150 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 6 11100 15.0 90.6 110 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 6 111 0 0 39.6 288.5 350 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 6 111 00 18.6 131.1 175 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 6 111 0 0 15.0 105.0 125 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 8 14800 52.8 344.2 450 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 8 14800 24.8 156.7 200 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 8 14800 20.0 124.4 150 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 8 14800 52.8 443.9 600 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 8 14800 24.8 201.7 250 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 8 14800 20.0 161.5 200 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 8 14800 52.8 450.8 600 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 8 14800 24.8 204.8 250 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 8 14800 20.0 163.1 225 HT3B -B 4PES-15-2NU-Y 208-230/3/60 60.0 294 4 7400 26.4 161.4 200 HT4B -B 4PES-15-2NU-Y 460/3/60 27.1 147 4 7400 12.4 73.4 100 HT5B -B 4PES-15-5PU-Y 575/3//60 21.8 11 7 4 7400 10.0 59.1 80 HT3B -B 4NES-20-2NU-Y 208-230/3/60 71.1 352 4 7400 26.4 186.4 250 HT4B -B 4NES-20-2NU-Y 460/3/60 32.1 176 4 7400 12.4 84.6 11 0 HT5B -B 4NES-20-5PU-Y 575/3//60 26.3 140 4 7400 10.0 69.2 90 HT3B -B 4HE-25-2NU-Y 208-230/3/60 93.2 436 6 111 00 39.6 249.3 300 HT4B -B 4HE-25-2NU-Y 460/3/60 42.1 218 6 11100 18.6 113.3 150 HT5B -B 4HE-25-5PU-Y 575/3//60 33.6 174 6 11100 15.0 90.6 110 HT3B -B 4GE-30-2NU-Y 208-230/3/60 110.6 490 6 111 0 0 39.6 288.5 350 HT4B -B 4GE-30-2NU-Y 460/3/60 50.0 245 6 111 00 18.6 131.1 175 HT5B -B 4GE-30-5PU-Y 575/3//60 40.0 196 6 111 0 0 15.0 105.0 125 HT3B -B 6HE-35-2NU-Y 208-230/3/60 129.5 550 8 14800 52.8 344.2 450 HT4B -B 6HE-35-2NU-Y 460/3/60 58.6 275 8 14800 24.8 156.7 200 HT5B -B 6HE-35-5PU-Y 575/3//60 46.4 220 8 14800 20.0 124.4 150 HT3B -B 6GE-40-2NU-Y 208-230/3/60 173.8 700 8 14800 52.8 443.9 600 HT4B -B 6GE-40-2NU-Y 460/3/60 78.6 350 8 14800 24.8 201.7 250 HT5B -B 6GE-40-5PU-Y 575/3//60 62.9 280 8 14800 20.0 161.5 200 HT3B -B 6FE-50-2NU-Y 208-230/3/60 176.9 950 8 14800 52.8 450.8 600 HT4B -B 6FE-50-2NU-Y 460/3/60 80.0 425 8 14800 24.8 204.8 250 HT5B -B 6FE-50-5PU-Y 575/3//60 63.6 340 8 14800 20.0 163.1 225 HT3B -B 4NES-14-2NU-Y HT4B -B 4NES-14-2NU-Y 460/3/60 22.1 126 2 3700 6.2 55.9 70 HT5B -B 4NES-14-5PU-Y 575/3//60 17.7 101 2 3700 5.0 44.8 60 HT3B -B 4HE-18-2NU-Y 208-230/3/60 66.7 352 4 7400 26.4 176.5 225 HT4B -B 4HE-18-2NU-Y 460/3/60 30.1 176 4 7400 12.4 80.1 11 0 HT5B -B 4HE-18-5PU-Y 575/3//60 24.1 140 4 7400 10.0 64.2 80

COMPRESSOR

HIGH EFFICIENCY MODELS

with EC Motors only or

MODEL NO.

EC MOTORS

60Hz

POWER SUPPLY

208-230/3/60 49.0 252 2 3700 13.2 123.5 150

COMPRESSOR CONDENSER FAN MTR. ** UNIT RLA LRA QTY WATTS FLA MCA MOP

TVS

09/03/14

T40-TV-PDS-19

- 91 -

DIMENSIONAL DATA - SINGLE COMPRESSOR

HIGH EFFICIENCY MODELS

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

REMOVEABLE ROOF SECTION

56 1/4 1429

CONDENSER FAN #1

TOP VIEW

LIQUID FILTER DRIER ( STANDARD ) ( REPLACEABLE CORE )

END CAPPED PIPE ( STANDARD ) SUCTION FILTER ( OPTIONAL ) ( REPLACEABLE CORE )

SIDE VIEW

CONDENSER FAN #2

LIQUID LINE SIGHT GLASS ( STANDARD )

HIGH EFFICIENCY MODELS

CONDENSER FAN #3

53 5/8

1361

HINGED SERVICE DOOR HINGED SERVICE DOOR

69 1/8 1757

23 3/8 593

BASE FRAME LENGTH

222 3/8

(SEE OPPOSITE PAGE)

28 1/2

724

1397

508

127

REMOVEABLE ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HINGED SERVICE DOOR HINGED SERVICE DOOR

SIDE VIEW

TOP VIEW

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD ) ( REPLACEABLE CORE )

END CAPPED PIPE ( STANDARD ) SUCTION FILTER ( OPTIONAL ) ( REPLACEABLE CORE )

69 1/8 1757

23 3/8 593

53 5/8

1361

56 1/4 1429

222 3/8

TVS

09/03/14

T40-TV-PDS-19

- 92 -

DIMENSIONAL DATA - SINGLE COMPRESSOR

HIGH EFFICIENCY MODELS

COMPRESSOR-END VIEW

HIGH EFFICIENCY MODELS

TVS-A

COPELAND

HIGH EFFICIENCY MODELS

CONDENSING

UNIT

MODEL

TVS016H8-H**B-A 167 3/8 4251

TVS023M8-H**B-A 167 3/8 4251

TVS026H8-H**B-A 222 3/8 5648

TVS031H8-H**B-A 222 3/8 5648

TVS036H8-H**B-A 277 3/8 7045

TVS041H8-H**B-A 277 3/8 7045

TVS016M8-H**B-A 167 3/8 4251

TVS023M8-H**B-A 167 3/8 4251

TVS026M8-H**B-A 222 3/8 5648

TVS031M8-H**B-A 222 3/8 5648

TVS036M8-H**B-A 277 3/8 7045

TVS041M8-H**B-A 277 3/8 7045

TVS051M8-H**B-A 277 3/8 7045

TVS011L 6/8 -H**B-A 112 3/8 2854

TVS016L 6/8 -H**B-A 167 3/8 4251

TVS023L 6/8 -H**B-A 167 3/8 4251

TVS028L 6/8 -H**B-A 167 3/8 4251

TVS031L 6/8 -H**B-A 167 3/8 4251

TVS041L 6/8 -H**B-A 222 3/8 5648

BASE FRAME

LENGTH

inches mm

HINGED SERVICE DOOR

ELECTRICAL K'OUTS

44 3/4 1137

TVS-B

BITZER

HIGH EFFICIENCY MODELS

CONDENSING

UNIT

MODEL

TVS016H8-H**B-B 167 3/8 4251

TVS021H8-H**B-B 167 3/8 4251

TVS026H8-H**B-B 222 3/8 5648

TVS031H8-H**B-B 222 3/8 5648

TVS036H8-H**B-B 277 3/8 7045

TVS041H8-H**B-B 277 3/8 7045

TVS051H8-H**B-B 277 3/8 7045

TVS041L6-H**B-B 222 3/8 5648

TVS016M8-H**B-B 167 3/8 4251

TVS021M8-H**B-B 167 3/8 4251

TVS026M8-H**B-B 222 3/8 5648

TVS031M8-H**B-B 222 3/8 5648

TVS036M8-H**B-B 277 3/8 7045

TVS041M8-H**B-B 277 3/8 7045

TVS051M8-H**B-B 277 3/8 7045

TVS013L 6/8 -H**B-B 112 3/8 2854

TVS016L 6/8 -H**B-B 167 3/8 4251

TVS021L 6/8 -H**B-B 167 3/8 4251

TVS026L 6/8 -H**B-B 167 3/8 4251

TVS031L 6/8 -H**B-B 167 3/8 4251

BASE FRAME

inches mm

LENGTH

TVD

09/03/14

T40-TV-PDS-19

- 93 -

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

DIMENSIONAL DATA - SINGLE COMPRESSOR

HIGH EFFICIENCY MODELS

TOP VIEW

COMPRESSOR #1 REMOVEABLE ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

HIGH EFFICIENCY MODELS

COMPRESSOR #2 REMOVEABLE ROOF SECTION

HINGED SERVICE DOOR HINGED SERVICE DOOR

CONDENSER FAN #1R

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD ) REPLACEABLE CORE

END CAPPED PIPE ( STANDARD ) SUCTION FILTER ( OPTIONAL ) ( REPLACEABLE CORE )

SIDE VIEW

CONDENSER FAN #2R

CONDENSER FAN #3R

28 1/2

724

1397

508

69 1/8 1757

23 3/8 593

BASE FRAME LENGTH

222 3/8

(SEE OPPOSITE PAGE)

127

69 1/8 1757

23 3/8 593

222 3/8

LIQUID FILTER DRIER ( STANDARD ) REPLACEABLE CORE

END CAPPED PIPE ( STANDARD ) SUCTION FILTER ( OPTIONAL ) ( REPLACEABLE CORE )

COMPRESSOR #1 REMOVEABLE ROOF SECTION

COMPRESSOR #2 REMOVEABLE ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #1R

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HINGED SERVICE DOOR HINGED SERVICE DOOR

SIDE VIEW

TOP VIEW

DIMENSIONAL DATA - SINGLE COMPRESSOR

09/03/14

T40-TV-PDS-19

- 94 -

TVD

HIGH EFFICIENCY MODELS

COMPRESSOR-END VIEW

ELECTRICAL K'OUTS

HINGED SERVICE DOOR COMPRESSOR #1

TVD-A

COPELAND

HIGH EFFICIENCY MODELS

CONDENSING

UNIT

MODEL

TVD031H8-H**B-A 167 3/8 4251

TVD045M8-H**B-A 167 3/8 4251

TVD051H8-H**B-A 222 3/8 5648 TVD061H8-H**B-A 222 3/8 5648

TVD071H8-H**B-A 277 3/8 7045

TVD081H8-H**B-A 277 3/8 7045 TVD031M8-H**B-A 167 3/8 4251 TVD045M8-H**B-A 167 3/8 4251 TVD051M8-H**B-A 222 3/8 5648 TVD061M8-H**B-A 222 3/8 5648

TVD071M8-H**B-A 277 3/8 7045

TVD081M8-H**B-A 277 3/8 7045 TVD101M8-H**B-A 277 3/8 7045

TVD021L 6/8 -H**B-A 112 3/8 2854 TVD031L 6/8 -H**B-A 167 3/8 4251 TVD045L 6/8 -H**B-A 167 3/8 4251 TVD055L 6/8 -H**B-A 167 3/8 4251 TVD061L 6/8 -H**B-A 167 3/8 4251 TVD081L 6/8 -H**B-A 222 3/8 5648

BASE FRAME

LENGTH

inches mm

86 3/4 2203

HINGED SERVICE DOOR COMPRESSOR #2

TVD-B

BITZER

HIGH EFFICIENCY MODELS

CONDENSING

UNIT

MODEL

TVD031H8-H**B-B 167 3/8 4251 TVD041H8-H**B-B 167 3/8 4251 TVD051H8-H**B-B 222 3/8 5648 TVD061H8-H**B-B 222 3/8 5648

TVD071H8-H**B-B 277 3/8 7045

TVD081H8-H**B-B 277 3/8 7045

TVD101H8-H**B-B 277 3/8 7045 TVD031M8-H**B-B 167 3/8 4251 TVD041M8-H**B-B 167 3/8 4251 TVD051M8-H**B-B 222 3/8 5648 TVD061M8-H**B-B 222 3/8 5648

TVD071M8-H**B-B 277 3/8 7045

TVD081M8-H**B-B 277 3/8 7045 TVD101M8-H**B-B 277 3/8 7045

TVD025L 6/8 -H**B-B 112 3/8 2854 TVD031L 6/8 -H**B-B 167 3/8 4251 TVD041L 6/8 -H**B-B 167 3/8 4251 TVD051L 6/8 -H**B-B 167 3/8 4251 TVD061L 6/8 -H**B-B 167 3/8 4251 TVD081L 6/8 -H**B-B 222 3/8 5648

inches mm

BASE FRAME

LENGTH

SPECIFICATIONS - SINGLE COMPRESSOR

09/03/14

T40-TV-PDS-19

- 95 -

60HzTVS-A

COPELAND

CONDENSING

UNIT

MODEL

TVS016H8-H**B-A 2 1 5/8 41 7/8 22 124 56.3 2260 1027 TVS023H8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2500 1136 TVS026H8-H**B-A 3 2 1/8 54 1 1/8 29 157 71.2 2870 1304 TVS031H8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3020 1373 TVS036H8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 3660 1663 TVS041H8-H**B-A 4 2 1/8 54 1 3/8 35 254 115.3 3820 1736 TVS016M8-H**B-A 2 1 5/8 41 7/8 22 124 56.3 2265 1029 TVS023M8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2505 1138 TVS026M8-H**B-A 3 2 1/8 54 1 1/8 29 157 71.2 2875 1307 TVS031M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3030 1377 TVS036M8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 3660 1663 TVS041M8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 3815 1734 TVS051M8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 3835 1743

TVS011L 6/8 -H**B-A 1 1 3/8 35 5/8 16 124 56.3 1785 8 11 TVS016L 6/8 -H**B-A 2 1 5/8 41 7/8 22 124 56.3 2335 1061 TVS023L 6/8 -H**B-A 2 2 1/8 54 7/8 22 124 56.3 2385 1084 TVS028L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2610 1186 TVS031L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2625 1193 TVS041L 6/8 -H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3045 1384

CONDENSER

FANS

HIGH EFFICIENCY MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

R404A

RECEIVER CAPACITY

90% FULL *

APPROX.

SHIPPING WEIGHT

HIGH EFFICIENCY MODELS

SPECIFICATIONS - DOUBLE COMPRESSOR

TVD-A

COPELAND

CONDENSING

UNIT

MODEL

TVD031H8-H**B-A 2 1 5/8 41 7/8 22 124 56.3 4065 1847

TVD045H8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4445 2020

TVD051H8-H**B-A 3 2 1/8 54 1 1/8 29 157 71.2 5185 2357

TVD061H8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5475 2488

TVD071H8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 6615 3006

TVD081H8-H**B-A 4 2 1/8 54 1 3/8 35 254 115.3 6920 3145

TVD031M8-H**B-A 2 1 5/8 41 7/8 22 124 56.3 4075 1852

TVD045M8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4550 2068

TVD051M8-H**B-A 3 2 1/8 54 1 1/8 29 157 71.2 5195 2361

TVD061M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5490 2495

TVD071M8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 6620 3009

TVD081M8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 6915 3143

TVD101M8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 6960 3163

TVD021L 6/8 -H**B-A 1 1 3/8 35 5/8 16 124 56.3 3195 1452

TVD031L 6/8 -H**B-A 2 1 5/8 41 7/8 22 124 56.3 4220 1918

TVD045L 6/8 -H**B-A 2 2 1/8 54 7/8 22 124 56.3 4315 1961

TVD055L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4760 2163

TVD061L 6/8 -H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4795 2179

TVD081L 6/8 -H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5535 2516

CONDENSER

FANS

HIGH EFFICIENCY MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

R404A

RECEIVER CAPACITY

90% FULL *

60Hz

APPROX.

SHIPPING WEIGHT

* NOTE ON ALTERNATE REFRIGERANTS:

* PUBLISHED RECEIVER CAPACITY IS BASED ON

FOR ALERNATE REFRIGERANTS, MULTIPLY

R407A

1.10 1.10 1.00 1.15

R407C

R404A

ON MODELS USING “8” AS REFRIGERANT CODE.

VALUE BY THE APPROPRIATE VALUE BELOW:

R507

R22

SPECIFICATIONS - SINGLE COMPRESSOR

09/03/14

T40-TV-PDS-19

- 96 -

BITZER

CONDENSING

UNIT

MODEL

TVS016H8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2190 995 TVS021H8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2275 1034 TVS026H8-H**B-B 3 2 1/8 54 1 1/8 29 157 71.2 2870 1304 TVS031H8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 3025 1375 TVS036H8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 3615 1643 TVS041H8-H**B-B 4 2 1/8 54 1 3/8 35 254 115.3 3810 1732 TVS051H8-H**B-B 4 2 1/8 54 1 3/8 35 254 115.3 3815 1734

TVS016M8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2195 998

HIGH EFFICIENCY MODELS

TVS021M8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2270 1032 TVS026M8-H**B-B 3 2 1/8 54 1 1/8 29 157 71.2 2875 1307 TVS031M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 3035 1379 TVS036M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 3615 1643 TVS041M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 3770 1713

TVS051M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 3780 1718 TVS013L 6/8 -H**B-B 1 1 3/8 35 5/8 16 124 56.3 1695 770 TVS016L 6/8 -H**B-B 2 1 5/8 41 7/8 22 124 56.3 2285 1039 TVS021L 6/8 -H**B-B 2 2 1/8 54 7/8 22 124 56.3 2355 1070 TVS026L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2545 1157 TVS031L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2565 1166 TVS041L 6/8 -H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 3000 1363

CONDENS-

ER FANS

HIGH EFFICIENCY MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

R404A

RECEIVER CAPACITY

90% FULL *

SHIPPING WEIGHT

60HzTVS-B

APPROX.

SPECIFICATIONS - DOUBLE COMPRESSOR

60HzTVD-B

BITZER

CONDENSING

UNIT

MODEL

TVD031H8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 3925 1784 TVD041H8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 4095 1861 TVD051H8-H**B-B 3 2 1/8 54 1 1/8 29 157 71.2 5185 2357 TVD061H8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5485 2493

TVD071H8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 6530 2968

TVD081H8-H**B-B 4 2 1/8 54 1 3/8 35 254 115.3 6900 3136 TVD101H8-H**B-B 4 2 1/8 54 1 3/8 35 254 115.3 6920 3145 TVD031M8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 3935 1788 TVD041M8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 4080 1854 TVD051M8-H**B-B 3 2 1/8 54 1 1/8 29 157 71.2 5190 2359 TVD061M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5500 2500

TVD071M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 6535 2970

TVD081M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 6825 3102 TVD101M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 6845 3111

TVD025L 6/8 -H**B-B 1 1 3/8 35 5/8 16 124 56.3 3010 1368

TVD031L 6/8 -H**B-B 2 1 5/8 41 7/8 22 124 56.3 4115 1870 TVD041L 6/8 -H**B-B 2 2 1/8 54 7/8 22 124 56.3 4255 1934 TVD051L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4635 2107 TVD061L 6/8 -H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4675 2125 TVD081L 6/8 -H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5445 2475

CONDENS-

ER FANS

HIGH EFFICIENCY MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

R404A

RECEIVER CAPACITY

90% FULL *

APPROX. SHIPPING

WEIGHT

* NOTE ON ALTERNATE REFRIGERANTS:

* PUBLISHED RECEIVER CAPACITY IS BASED ON

FOR ALERNATE REFRIGERANTS, MULTIPLY

R407A

1.10 1.10 1.00 1.15

R407C R507

R404A

ON MODELS USING “8” AS REFRIGERANT CODE.

VALUE BY THE APPROPRIATE VALUE BELOW:

R22

TVS/D

09/03/14

T40-TV-PDS-19

- 97 -

WIRING DIAGRAMS

FOR WIRING DIAGRAMS

FOR HIGH EFFICIENCY MODELS,

REFER TO PAGES 49-54

HIGH EFFICIENCY MODELS

FOR SERVICE PARTS, VISIT

http://www.t-rp.com/serv_parts.htm

TVS/D

09/03/14

T40-TV-PDS-19

- 98 -

SERVICE PARTS

FOR SERVICE PARTS, VISIT

http://www.t-rp.com/serv_parts.htm

FINISHED GOODS WARRANTY

09/03/14

T40-TV-PDS-19

- 99 -

The terms and conditions as described below in the General Warranty Policy cover all products manufactured by National Refrigeration.

GENERAL WARRANTY POLICY

Subject to the terms and conditions hereof, the Company warrants all Products, including Service Parts, manufactured by the Company to be free of defects in material or workmanship, under normal use and application for a period of one (1) year from the original date of installation, or eighteen (18) months from the date of shipment from the Company, whichever occurs rst. Any replacement part(s) so supplied will be warranted for the balance of the product’s original warranty. The part(s) to

be replaced must be made available in exchange for the replacement part(s) and reasonable proof of the original installation date of the product must be presented in order to establish the effective

date of the warranty, failing which, the effective date will be based upon the date of manufacture plus thirty (30) days. Any labour, material, refrigerant, transportation, freight or other charges incurred in connection with the performance of this warranty will be the responsibility of the owner at the current rates and prices then in effect. This warranty may be transferred to a subsequent owner of the

product.

THIS WARRANTY DOES NOT COVER

(a) Damages caused by accident, abuse, negligence, misuse, riot, re, ood, or Acts of God (b) damages caused by operating the product in a corrosive atmosphere (c) damages caused by any unauthorized alteration or repair of the system affecting the product’s reliability or performance (d) damages caused by improper matching or application of the product or the product’s components (e) damages caused by

failing to provide routine and proper maintenance or service to the product (f) expenses incurred for the erecting, disconnecting, or dismantling the product (g) parts used in connection with normal maintenance,

such as lters or belts (h) products no longer at the site of the original installation (i) products installed

or operated other than in accordance with the printed instructions, with the local installation or building codes and with good trade practices (j) products lost or stolen.

No one is authorized to change this WARRANTY or to create for or on behalf of the Company any other obligation or liability in connection with the Product(s). There is no other representation, warranty or condition in any respect, expressed or implied, made by or binding upon the Company other than the above or as provided by provincial or state law and which cannot be limited or excluded by such law, nor will we be liable in any way for incidental, consequential, or special damages however caused.

The provisions of this additional written warranty are in addition to and not a modication of or subtraction from the statutory warranties and other rights and remedies provided by Federal, Provincial or State laws.

PROJECT INFORMATION

System

Model Number Date of Start-Up

Serial Number Service Contractor

Refrigerant Phone

Electrical Supply Fax

09/03/14

NATIONAL REFRIGERATION & AIR CONDITIONING CANADA CORP.

159 Roy Blvd.

Brantford Ontario Canada N3R 7K1

PHONE: (519) 751-0444 800-463-9517

FAX (519) 753-1140 www.t-rp.com

Due to National Refrigeration’s policy of continuous product improvement, we reserve the right to make changes without notice.

Trenton TVD016V6-B Installation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
