TRENDnet TU2-PCLINK Installation Guide

Quick Installation Guide

TU2-PCLINK

TU2-PMLINK

1.01

Table of Contents

English 1

1. Before You Start

2. How to Install 3

3. Using the Utility 4

4. Quick Reference Guide 6

Technical Specifications 9
Troubleshooting 10

1

Version 10.02.2009

1. Before You Start

Package Contents

TU2-PCLINK/TU2-PMLINK

?
?Multi-Language Quick Installation Guide

System Requirements

CPU: 300MHz or above / 800MHz or above (Windows Vista) /1GHz or above

?

(Windows 7)

?Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista)/1GB

RAM or above (Windows 7)

?Computer with an available USB 1.1 or 2.0 slot
?Windows 7/Vista(32/64-bit)/2000/XP(32/64-bit) (TU2-PCLINK)
?Windows 7/ Vista(32/64-bit)/ 2000/XP(32/64-bit), Mac OS X (10.4~10.6)

(TU2-PMLINK)

1

Application:

High-Speed PC-to-PC Share Cable

(TU2-PCLINK)

PC

High-Speed PC and Mac Share Cable

(TU2-PMLINK)

HD

PC

HD

PC or Mac

PC or Mac

2

2. How to Install

Hardware Installation

1. Connect the TU2-PCLINK/TU2-PMLINK to your
computer.

2. Drivers will install automatically.

3. Repeat steps 1-2 on a second computer.

Your installation is now complete.

Register Your Product

To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register

Thank you for choosing TRENDnet.

3

3. Using the Utility

For Window Users

1. Click Run ShareLink_PC.exe

(Windows Vista only).

2. Click here to start.

3. Use your mouse to drag and drop files from the

Local Host to the Remote Host. You can also
drag and drop files from the Remote Host to
the Local Host.

Note: For additional information regarding the ShareLink utility, please see section 4.
Quick Reference Guide.

4

For Mac Users

1. Double click on the ShareLink icon. This icon

will appear on the desktop.

2. Double click on the ShareLink_Mac icon.

3. Use your mouse to drag and drop files from the

Local Volume to the Remote Volume. You can
also drag and drop files from the Remote
Volume to the Local Volume.

Note: For additional information regarding the ShareLink utility please see section 4.
Quick Reference Guide.

5

4. Quick Reference Guide

For Window Users

USB Status Icons

Read Only

DescriptionIcon

If the USB port on the computer is 2.0, the USB 2.0 status icon
will illuminate and the USB 1.1 icon will be grayed out. If the
USB port on the computer is 1.1 the USB 1.1 icon will be active
and the USB 2.0 icon will be grayed out.

When this icon is active, Read Only mode is enabled.

TX/RX

Refresh

Cut

Copy

Paste

Delete

About

When data is being transferred between Local and Remote
computers, this icon will illuminate.

Refreshes the ShareLink windows.

Cut the selected file or folder

Copy the selected file or folder

Paste the copied file or folder

Delete the selected file or folder

Displays information about the ShareLink Utility

6

Menu Bar Options

System

Edit

View

Window

Help

Options

Setup

Exit

Cut

Copy

Paste

Delete

Toolbar

Status Bar

Large Icons

Small Icons

List

Details

Refresh

Cascade

Tile

Split

Local Host

Remote Host

About ShareLink Displays information about the ShareLink Utility

Description

Enable/Disable Read Only mode

Exit the ShareLink program

Cut the selected file or folder

Copy the selected file or folder

Paste the copied file or folder

Delete the selected file or folder

Show/Hide Toolbar

Show/Hide Status Bar

Displays files and folders in the Remote Host and
Local Host windows as Large icons.

Displays files and folders in the Remote Host and
Local Host windows as small icons.

Displays the Remote Host and Local Host in List
mode.

Displays the Remote Host and Local Host in
Detail mode.

Refreshes the Remote Host and Local Host windows.

Arranges your window so that the local and
remote window title bars are visible.

Tiles the Remote and Local windows side by side.

Splits the window into two parts so that you can
view the Remote and Local windows simultaneously.

Makes Local Host the active windows.

Makes Remote Host the active windows.

7

For Mac Users

Back

Forward

Local and Remote USB Icon

Data Transfer

New Folder

DescriptionIcon

Go Back

Go Forward

The left icon refers to the local computer. The right icon refers
to the remote computer. The icon will display 2.0 when the
TU2-PMLINK is connected to a USB 2.0 port.

When data is being transferred between local and remote
computers, this icon will be active. When no data is being
transferred between the local and remote computers, this
icon will be grayed out.

Create a new folder.

About

Menu Bar Options

ShareLink

Edit

Window

Displays information about the ShareLink Utility

Options

Setup

Exit

Cut

Copy

Paste

Delete

Select All

Minimize

Description

Enable/Disable Read Only mode

Exit the ShareLink program

Cut the selected file or folder

Copy the selected file or folder

Paste the copied file or folder

Moves the select files and folders to the Trash

Select all files in the active window

Minimizes the ShareLink program.

8

Technical Specifications

Interface

Standard

Power Mode

Data Rate

Diagnostic LEDs

Cable Length

Housing

Operating Systems

Power Consumption

Dimensions

Weight

Temperature

Humidity

Certifications

USB Type A Female

USB 2.0

USB Bus Powered

Up to 160Mbps

Green Solid Light: The TU2-PCLINK/TU2-PMLINK is connected to
at least one computer.
Green Flashing Light: Data is being transferred.

1.8m (6ft)

ABS (plastic)

TU2-PCLINK:Windows 2000/XP/Vista
TU2-PMLINK: Windows 2000/XP/Vista, Mac OS X (10.4~10.5)

1W

80 x 25 x 9 mm (3.14 x 0.98 x 0.35in.)

50g (1.76 oz.)

Operating: 0° C ~ 50° C (32° F ~ 122° F)
Storage: -40° C ~ 55° C (-40° F ~ 131° F)

10% ~ 95%, non-condensing

CE, FCC

9

Troubleshooting

The installation menu does not appear automatically after I connect the TU2-PCLINK/TU2­PMLINK to my computer. What should I do?

For Windows 2000/XP, if the installation menu does not appear automatically, double-click on
My Computer. Then double click on ShareLink. For Windows Vista/7, if the installation menu
does not appear automatically, double-click on Computer. Then double-click on ShareLink.

My computer does not detect the TU2-PCLINK/TU2-PMLINK. What should I do?

1.

Make sure your computer meets the minimum requirements as specified in Section 1 of
this quick installation guide.

2. Connect the TU2-PCLINK/TU2-PMLINK into a different USB port on your computer.

If you still encounter problems or have any questions regarding the TU2-PCLINK/TU2-PMLINK,
please contact TRENDnet's Technical Support Department.

10
