TEW-WLC100
Wireless LAN Controller
TEW-WLC100 (v1.0R)
• Centralized AP management
• Built-in 5-port Gigabit Switch
• Manages up to 32 wireless access points
• Compatible with TEW-755AP, TEW-821DAP and TEW-825DAP
• Supports IEEE 802.11k radio resource management
TRENDnet's Wireless LAN Controller, model TEW-WLC100, lets you easily setup and manage access points across your network from a single
interface. Intelligent radio resource manamagement ensures your mobile wifi clients have optimal roaming conditions when wirelessly transitioning
between access points within the network. Simultaneously manage up to 32 access points, perform batch firmware upgrades, and monitor network
connection status.
TEW-WLC100
Centralized AP Management
Easily manage up to 32 access points (AP)
across your wireless network
Networking Solution
Hardware Design
Durable metal housing and rack mountable
design with built-in 5-port gigabit switch
Intelligent Radio Resource Management
Intelligent radio resource manamagement
ensures your mobile wifi clients have optimal
roaming conditions when wirelessly
transitioning between access points within the
network
TEW-WLC100
Centralized AP Management
Easily manage up to 32 access points (AP) across
your wireless network
Intelligent Radio Resource Management
Intelligent radio resource management ensures your
mobile wifi clients have optimal roaming conditions
when wirelessly transitioning between access points
within the network
Access Point Monitoring
View the status of online users or network devices
Simultaneously Upgrade Firmware
Select multiple access points to upgrade firmware at
the same time
Rack Mount Design
Standard 19” 1U design (brackets included)
Specifications
Standards
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3x
• IEEE 802.3ab
Device Interface
• 5 x Gigabit ports
• 1 x USB port
• On / Off Power button
• LED indicators
• Reset button
Data Transfer Rate
• Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
• Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
• Gigabit: 2000 Mbps (full duplex)
Management
• HTTP Web based GUI
• Local or online Firmware upgrade
• Internal log
• Configuration Backup / Restore
• NTP
Access Point Monitoring
• Manage up to 32 access points
• IP address, gateway, and DNS settings
• SSID / Network name
• Wireless channel
• Wireless encryption: WEP, WPA / WPA2-Personal, WPA / WPA2-Enterprise
802.1X
• 802.11 mode
• Channel width
• Transmit power
• SSID broadcast
• Bandwidth control (download limit per SSID & client, upload limit per client)
• Set RSSI scanning / threshold
TEW-WLC100
• Enable / disable 802.11k radio resource management
• Enable / disable Band steering
• Access point / client statistics monitoring
• Batch configuration deployment
• Batch firmware upgrade deployment
Access Point Compatibility
• TEW-755AP (Firmware Version: 1.03 or above)
• TEW-821DAP (Firmware Version: 1.05 or above)
• TEW-825DAP (Firmware Version: 1.01 or above)
Power
• Input: 100 – 240 V AC, 50 / 60 Hz
• Output: 12V DC, 1A external power adapter
• Consumption: 12 Watts (max.)
Operating Temperature
• 0 – 40°C (32 – 104°F)
Operating Humidity
• Max. 95 % non-condensing
Dimensions
• 215 x 130 x 44.45 mm (8.27 x 6.3 x 1.73 in.)
• Rack mountable 1U height
Weight
• 68 g (1.5 lbs.)
Certifications
• CE
• FCC
Warranty
• 3-year warranty
Package Contents
• TEW-WLC100
• Quick Installation Guide
• CD-ROM (User’s Guide)
• Power adapter (12V DC, 1A)
• Rack mount kit
