1. Instalación de la antena exterior
Antes de la instalación, compruebe que tiene los productos requeridos y que
el contenido de cada producto está completo.
TEW-ASAK
• Protector de sobretensiones
TEW-L406/TEW-L412
TEW-L406 – Cable (6 metros)
TEW-L412 – Cable (12 Metros)
Una de las siguientes antenas.
TEW-AO10O
TEW-AO09D
1
Español
TEW-AO14D
TEW-AO19DTEW-AO08O
Page 4
1. Retire el guardapolvo de ambos
extremos del TEW-ASAK.
2. Desconecte la antena dipolo por
defecto de su punto de acceso o
enrutador inalámbrico.
3. Fije el extremo SMA reverso (funda
azul) del TEW-ASAK a su enrutador
inalámbrico o punto de acceso.
4. Conecte el extremo tipo N del
TEW-ASAK al extremo tipo N hembra
del cable de antena TEW-L406/
TEW-L412.
5. Conecte el extremo tipo N macho del
cable de antena TEW-L406/TEW-L412
a una antena exterior.
2
Español
Page 5
6. Envuelva la parte que rodea los
conectores con las cintas
impermeabilizadas suministradas.
7. Conecte el cable del conductor a tierra
a un objeto de la toma a tierra.
Ej. elemento conductor, sistema
eléctrico de toma a tierra, estructura
del edificio.
3
Español
Page 6
Montura De pared
1. Seleccione la ubicación deseada para
instalar el dispositivo. Utilice la
abrazadera tipo L suministrada como
patrón para marcar la ubicación de los
orificios y perfore dos orificios en las
posiciones marcadas.
2. Introduzca las clavijas de pared en los
orificios taladrados y luego utilice los
tornillos para madera suministrados
para fijar el soporte de sujeción a la
pared.
3. Afloje la tuerca y la arandela. Monte
el TEW-ASAK en la abrazadera L.
Luego apriete la tuerca y la arandela
para fijar el TEW-ASAK a la
abrazadera tipo L.
La instalación de la antena exterior ha finalizado.
4
Español
Page 7
2. Instalación de antena interior
Antes de la instalación, compruebe que tiene los productos requeridos y que
el contenido de cada producto está completo.
TEW-L202/TEW-L208
TEW-L202 – Cable (2 metros)
TEW-L208 – Cable (8 Metros)
Una de las siguientes antenas.
TEW-AO10O
TEW-AO09DTEW-AO08O
Nota: Las siguientes antenas interiores vienen con cables o se conectan
directamente a su dispositivo Wi-Fi. No requieren cables adicionales para el
ensamblado.
TEW-AI86DB
TEW-AI75OB
5
Español
Page 8
1. Desconecte la antena dipolo de su
punto de acceso o enrutador.
2. Conecte directamente el manguito azul
(SMA inverso) del cable interior
(TEW-L202/TEW-L208) al dispositivo
WiFi.
3. Conecte la parte restante del manguito
negro (tipo N) del cable de antena al
manguito azul de la antena (tipo N).
6
Español
Page 9
La instalación de antena interior ha finalizado.
Para asegurar los más altos niveles de servicio y apoyo al cliente, registre su producto
en línea en: www.trendnet.com/register
