TRENDnet TEWAO12O User Manual

Quick Installation Guide

TEW-AO12O

Table of Contents

Table of Contents

English ........................................................................................... ........................

1. Before You Start

2. Hardware Installation ......................................................... ...............

3. Mounting ........................................................................................................

Troubleshooting .....................................................................................................

....................................................................... .....................

.............

1

1
2
4

6

Version 10.04.2007

1. Before You Start

Notebooks with

Wireless PC Card

(TEW-441PC)

Workstation with

Wireless PCI Adapter

(TEW-443PI)

LMR400 Cable

(TEW-L406 / TEW-L412)

Internet

Cable/DSL
Modem

Notebook with

Wireless PC Card

(TEW-441PC)

Workstation with

Wireless PCI Adapter

(TEW-443PI)

Outdoor Arrestor Kit

(TEW-ASAK)

108Mbps
Wireless Router
(TEW-452BRP)

Notebooks with

Wireless PC Card

(TEW-441PC)

Workstation with

Wireless PCI Adapter

(TEW-443PI)

12dBi Outdoor Omni

Directional Antenna

(TEW-AO12O)

Package Contents

EW-AO12O

T

?

User’s Guide

?

Antenna Mounting Base

?

Mounting Kit

?

System Requirements

Wireless Router, Access Point or Wireless Adapter with detachable

?

antenna and reverse SMA male connector

?TEW-ASAK or TEW-ASAL1 (with TEW-455APBO)
?TEW-L406 or TEW-L412

Application

1

English

2. Hardware Installation

1. Unscrew the antenna from your
wireless access point or wireless
router.

2. Attach the blue sleeve (Reverse

SMA) end of the jumper cable
(provided with the TEW-ASAK) to
your wireless access point or
router.

3. Connect the black sleeve (N-type)

end of the jumper cable to the
TEW-ASAK.

4. Connect the other end of the
TEW-ASAK to the blue sleeve of
the antenna cable (TEW-L406 or
TEW-L412).

2

English

5. Run the antenna cable through the

mounting base.

6. Connect the black sleeve (N-type)

end of the antenna cable to the
TEW-AO12O.

7. Connect the antenna to the

antenna base and tighten the
screws.

3

English

3. Mounting

Wall Mounting

1. Slide the mounting brackets
through the Antenna base and
tighten the screws.

2. Place the antenna base on the
desired spot on a wall. Use a pen
to mark the spots at each of the
four holes.

3. Drill holes for the fastener plugs at
the marked positions on the wall.

4. Insert fastener plugs into the drilled
holes.

5. Use the provided wood screws to
screw the antenna to the fastener
plugs to the wall.

English

4

Pole Mounting

1. Slide the mounting brackets

through the Antenna base and
tighten the screws.

2. Slide the two provided u-clamps
around the pole. Place the pole
mounting bracket at the desire
height and position

3. Secure the mounting bracket to the
pole mounting bracket using the
nuts and washers provided.

To ensure the highest level of customer service and support, please take a moment to

register your product Online at: www.trendnet.com/register

Thank you for choosing TRENDnet

5

English

Register Your Product

Troubleshooting

I am unable to connect my antenna to my wireless router or access point.

Q1:

What should I do?

The connector type on your wireless router or access point must be reverse

A1:

SMA male. Contact the manufacturer of your wireless router or access point
regarding the antenna connector type.

Why do some of my wireless PCs receive a strong wireless signals, while

Q2:

other PCs receive a weaker signal?

The TEW-AO12O is an Omni directional antenna and can only send and

A2:

receive signals from a specified radius. You can adjust the position of the wireless
router or access point, extend your TEW-AO12O to an optimal location or move
those wireless PCs closer to the wireless access point or router.

My Access Point indicates that it is receiving power, and my laptop is within

Q3:

range of the TEW-AO12O. However, my laptop does not receive any signals from
my Access Point.

Make sure that you properly connect the antenna to the Access Point. (See 2.

A3:

hardware Installation)

Does the TEW-AO12O work with my IEEE 802.11a wireless router, access

Q4:

point or wireless adapter?

No. The TEW-AO12O is only compatible with IEEE 802.11/b/g wireless

A4:

devices.

Is it necessary to use the mounting kit that comes with the TEW-AO12O?

Q5:

It is only necessary if you decide to mount the TEW-AO12O at a permanent

A5:

location. Use discretion when attaching the mounting brackets to the
TEW-AO12O.

If you have any questions regarding the TEW-AO12O, please contact TRENDnet
Technical Support Department.

6

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.

Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.

ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
