1. Before You Start

Installation Requirements

A computer with a network adapter properly installed
CAT 5e or 6 Network Cable
The surface must support at least 1.5 Kg for the Switch
The power outlet should be within 1.82 meters (6 feet) of the Switch
Visually inspect the DC power jack to make sure that it is securely

connected to the power adapter
Make sure that there is proper heat dissipation and adequate

ventilation around the Switch
Do not place heavy objects on the Switch

Application

Package Contents

TEG-S5/TEG-S8
Quick Installation Guide
AC Power Adapter

5/8-Port 10/100/1000Mbps Gigabit Switch

Workstation with Gigabit PCI Adapter

(TEG-PCITXR)

Laptop with Gigabit CardBus PC Card

(TEG-PCBUSR)

Gigabit 10/100Mbps

(TEG-S5 or TEG-S8)

10/100Mbps Multi-Port Print Server

(TE100-P21)

1

English

Server with Gigabit PCI Adapter

(TEG-PCITXR)

Printers

2. Hardware Installation

1. Connect the AC Power Adapter to
the TEG-S5/TEG-S8 and then
to a power outlet.

2. Connect a CAT-5e or CAT-6 RJ-45
network cable from the computer to
an available Ethernet port on the
TEG-S5/TEG-S8.

Your installation is now complete.

To ensure the highest level of customer service and support, please take a moment to

register your product Online at: www.TRENDnet.com/register

Register Your Product

Thank you for choosing TRENDnet

2

English

Technical Specifications

General

IEEE 802.3 10BASE-T Ethernet

Standards

IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet

Protocol

Data Transfer Rates

Topology

Network Cables

Number of Ports

LEDs

CSMA/CD

Ethernet:
10Mbps (Half-Duplex), 20Mbps (Full-Duplex)
Fast Ethernet:
100Mbps (Half-Duplex), 200Mbps (Full-Duplex)
Gigabit Ethernet:
2000Mbps (full-duplex)

Star

Ethernet: UTP/STP CAT-3, 4, 5
Fast Ethernet: UTP/STP CAT-5, 5E , 6
Gigabit : UTP/STP CAT-5e, CAT-6 (Recommended)

TEG-S5:
5 x 10/100Mbps Auto-negotiation, Auto-MDIX ports
TEG-S8:
8 x 10/100Mbps Auto-negotiation, Auto-MDIX ports

Per Port: LINK/ACT
Per Unit: PWR

3

DC inputs

Power Consumption

Temperature

Physical and Environmental

Switching Power: 5V DC, 2.5A
Linear Power: 12V DC, 1A

TEG-S5: 5.6W
TEG-S8: 8.5W

Operating: 0 ~ 50 C° °

Humidity

Dimensions (L x W x H)

Weight

Certification

Transmission Method

Packet Filtering/
Forwarding Rate

MAC Address Learning

Switch Fabric

Filtering Address Table

Operating: 10% ~ 90%

mm150 x 105 x 33

225g

CE, FCC

Performance

Store-and-Forward

10Mbps Ethernet: 14,880pps (packet per second)
100Mbps Fast Ethernet: 148,800pps
1000Mbps Gigabit Ethernet: 1,488,000pps

Automatic update

TEG-S5: 10Gbps Forwarding Capacity
TEG-S8: 16Gbps Forwarding Capacity

4K entries per device

4

Troubleshooting

After connecting the Switch to a power outlet, the LEDs do not turn

Q1:

on.

Check the connection of the external power adapter to the

A1:

TEG-S5/TEG-S8 and the power outlet. Also check that the power
outlet is receiving power.

When I connect a computer to the Switch port, the PWR and

Q2:

LINK/ACT LED turns on, but the 100/1000Mbps LED remains off or the
light is yellow.

When the 100/1000Mbps LED remains off or is yellow, the computer's

A2:

connection speed is 10Mbps and 100Mbps, respectively. First, check
the Ethernet Cable. Make sure you are using CAT-5e or CAT-6 Ethernet
Cables. Some CAT-5 cables are not rated to run in Gigabit. Second,
make sure that you have a Gigabit Ethernet Adapter installed on your
computer.

After I connect my PCs to the Switch, I am unable to share files.

Q3:

First, check the LEDs on the Switch. Make sure the LINK/ACT LED is

A3:

Second, check the network cable. The minimum length of the cable is

on.

1.5 meters and the maximum length of the cable is 100 meters. Third,
disable any software firewall program. Fourth, verify that you have file
sharing enabled. Please contact your operating system support for more
information.

After I connect my PCs to the Switch, I can only get onto the Internet

Q4:

from one computer.

The Switch was not designed to share Internet between multiple

A4:

computers. You need to get an Internet router, such as the
TW100-S4W1CA.

If you still encounter problems or have any questions regarding the
TEG-S5/TEG-S8 please contact Trendnet's Technical Support Department.
