Trend SNAP/ASA/2 User guide

90°
Angle Attachment
MK2
For Direct
Drive and
Insert Bits.
Max
Torque
60Nm
High load gears.
Improved handle.
For use with
impact screwdriver.
**
SNAP/ASA/2
Angle Screwdriver Attachment 90º MK2
How to Fix the Handle
WARNING
Fix the handle securely to one of the tapped holes.
1. Two location holes are covered with cap screws.
2. Remove cap screw of chosen location hole using a flat head
screwdriver, then fix the handle securely.
3. Leave unused location hole covered with cap screw so that
it cannot become clogged with dust.
How to Hold the Angle Screwdriver Attachment
The Angle Screwdriver Attachment can be used with or without the side handle, however for best performance we advise the side handle is used.
Without handle
Hold body and handle of Angle Screwdriver Attachment tightly. Handle is merely auxiliary. Do not hold handle only. The thumb depression on the top of the tool allows more pressure to be applied.
With handle
How to use the Angle Screwdriver Attachment
WARNING
Never switch on the drill without holding the Angle Screwdriver Attachment, otherwise the attachment body rotates dangerously.
Place the bit securely in the screw head groove and perpendicular to component being screwed in.
Safety Steps
1. Never switch on the drill without holding the attachment otherwise the
Angle Screwdriver Attachment body rotates dangerously.
2. When changing bits make sure the drill is switched off.
3. Make sure Angle Screwdriver Attachment is securely attached to drill.
4. Secure that the bit is in the chuck properly before operation.
5. Never mis-use the Angle Screwdriver Attachment.
6. Do not over-load the Angle Screwdriver Attachment as it may result in
serious injury or breakage.
7. Place the bit securely in the screw head groove and perpendicular to
component being screwed in.
All Trend tooling is guaranteed against any defects in either workmanship or material, except tools that have been damaged due to improper use or maintenance.
Our policy of continuous improvements mean that specifications may change without notice. Trend Machinery & Cutting Tools Ltd.cannot be held liable for any material rendered unusable, or for any form of consequential loss.
Patent Pending
GB
Accessories
DE
Zubehörteile Accessoires
FR NL
Accessoires
MK2
For Direct Drive and Insert Bits.
ES
Accesorios
SE
Tillbehör
IT
Accessori
PT
Acessórios
DK
Tibehør
NO
Tilleggsutstyr
FI
Tarvikeet
INSERT BIT
instructions
More
inside
Can be used with Impact Drivers
Trend Machinery & Cutting Tools Ltd.
Tel: 0044(0)1923 249911 technical@trendm.co.uk www.trend-uk.com/snappy
DIRECT DRIVE
**
Can be used with impact screw drivers to
follow maximum specification. Voltage - 12V
Torque load - 80 Nm Rotation - 2000 rpm Impacts per minute - 2500 ipm
Not suitable for use with nutsetters or sockets
SNAP/ASA/2
PP C/SN/ASA/2 v1.0
