Page 1
INSTRUCTIONS
For Trend Worktop Jigs using a 30mm guide
bush and 1/2” (12.7mm) diameter cutter.
INTENDED USE
This accessory is intended to be used with
Trend Kitchen Worktop Jigs which use a
30mm guide bush and a 12.7mm diameter
cutter to mark the worktop offset of 8.65mm
using a spring loaded pencil. This is
especially useful if there is a joint at either
end of a worktop as it will make it easier to
mark out for the cut.
OPERATION
The Offset Scriber can be used to trace the
male cut on the worktop. The drawn line will
need to be on the side that the jig is to be
positioned for routing. For a right hand joint
the pencil line needs to be on the underside
of the male worktop. Eg. For a left hand joint
the pencil line needs to be on the top of the
male worktop.
Cut female joint as normal following the
instructions supplied with the worktop jig,
then lay male piece on top for right hand joint
or underneath for left hand joint.
Use the Offset Scriber to trace the female
cut by pushing the tool body down so the
spring loaded pencil contacts the worktop.
The pencil line on the centre worktop will
show the final cut line.
If the worktop is dark, place masking tape on
worktop and draw onto this.
Lay jig onto worktop and align the correct
edge of the slot on the jig to the pencil line,
clamp jig securely and then cut the male joint
following the instructions supplied with the
worktop jig.
Hint: Marking out is easier for left hand joints.
SAFETY
Users must be competent in using
woodworking equipment before using our
products. Consider working environment
before using tools. Ensure working position
is comfortable and component is clamped
securely.
Please keep children away from tools and
work area. All tools have a residual risk so
must therefore be handled with caution.
MAINTENANCE
Use only Trend original spare parts and
accessories.
Keep pencil sharp.
Regularly clean with a soft cloth. No
additional lubrication is required.
After use keep product assembled and
return it to its packaging for safe storage.
ENVIRONMENTAL
PROTECTION
Recycle raw materials instead of disposing
as waste. Packaging should be sorted for
environmental-friendly recycling. The
product and its accessories at the end of its
life should be sorted for environmental-
friendly recycling.
EURO SLOT
with tags
46.5mm
CREASE
PERFORATION
Product Ref.
M/KWS01
OFFSET
SCRIBER
For
Kitchen
Worktop
Jigs
■ Allows true
cutter path to
be drawn.
■ Scribes
directly onto
worktop.
■ For 30mm
guide bush &
1/2” router
cutter.
■ Spring loaded
pencil.
RECYCLABLE
DC/M/KWS01
CLAM.CP.BB
EURO SLOT
with tags
INSTRUCTIONS
For Trend Worktop Jigs using a 30mm guide
bush and 1/2” (12.7mm) diameter cutter.
INTENDED USE
This accessory is intended to be used with
Trend Kitchen Worktop Jigs which use a
30mm guide bush and a 12.7mm diameter
cutter to mark the worktop offset of 8.65mm
using a spring loaded pencil. This is
especially useful if there is a joint at either
end of a worktop as it will make it easier to
mark out for the cut.
OPERATION
The Offset Scriber can be used to trace the
male cut on the worktop. The drawn line will
need to be on the side that the jig is to be
positioned for routing. For a right hand joint
the pencil line needs to be on the underside
of the male worktop. Eg. For a left hand joint
the pencil line needs to be on the top of the
male worktop.
Cut female joint as normal following the
instructions supplied with the worktop jig,
then lay male piece on top for right hand joint
or underneath for left hand joint.
Use the Offset Scriber to trace the female
cut by pushing the tool body down so the
spring loaded pencil contacts the worktop.
The pencil line on the centre worktop will
show the final cut line.
If the worktop is dark, place masking tape on
worktop and draw onto this.
Lay jig onto worktop and align the correct
edge of the slot on the jig to the pencil line,
clamp jig securely and then cut the male joint
following the instructions supplied with the
worktop jig.
Hint: Marking out is easier for left hand joints.
SAFETY
Users must be competent in using
woodworking equipment before using our
products. Consider working environment
before using tools. Ensure working position
is comfortable and component is clamped
securely.
Please keep children away from tools and
work area. All tools have a residual risk so
must therefore be handled with caution.
www.trend-uk.com
DC/M/KWS01
MAINTENANCE
Tel: 0044(0)1923 249911
& Cutting Tools Ltd
Use only Trend original spare parts and
Trend Machinery
accessories.
Keep pencil sharp.
Regularly clean with a soft cloth. No
additional lubrication is required.
After use keep product assembled and
return it to its packaging for safe storage.
ENVIRONMENTAL
PROTECTION
Recycle raw materials instead of disposing
M/KWS01 Scriber
as waste. Packaging should be sorted for
Contents:
environmental-friendly recycling. The
product and its accessories at the end of its
life should be sorted for environmentalfriendly recycling.
M/KWS01
