Treblab Z2 User Manual

BLUETOOTH® HEADPHONES
ACTIVE NOISE CANCELLATION

USER MANUAL

Please read this manual before using the product.

TREBLAB Z2 CARRYING CASE + CARABINER

CHARGING CORD

AUX-IN CABLE

Thank you for choosing TREBLAB Z2 headphones
with Bluetooth® 4.2 technology and Active Noise
Cancellation (ANC).

FUNCTION

Play / Pau se

Answer phone call

End ph one call (Han g up)

Turn ON Goo gle Voice S earch®

Turn ON Siri®

OPERATION

Short press PHONE button
Short press PHONE button
Short press PHONE button
Long press PHON E button
Long press PHON E button

VOLUM E

NEXT

POWER

PL AY/PAU SE

PHONE

VOLUM E

+

PREVIOUS

LED

-

PORT

AUX-I N

PORT

MICUSB

LED

ANC

SWITCH

FUNCTION

Power ON

Power OFF

Play / Pau se

Volume +

Volume -

Answer phone call

Reject phone call

End ph one call (Han g up)

Redial

Next tr ack

Previous track

ANC

AUX

OFF ON

ANC

OPERATION

Long press POWER button for 3 sec.
Long press POWER button for 5 sec
Short press PLAY/PAUSE button
Short press Volume + button
Short press Volume - button
Short press PHONE button
Long press PHON E button for 2 sec
Short press PHONE button
Short press PHONE button twice quickly
Short press NEXT button
Short press BACK button
Move the AN C switch to ON position

TREBLAB Z2 has two operation modes, Bluetooth®
(wireless) and Line-in (connected with AUX cable)

I. BLUETOOTH MODE

WIRELESS PAIRING

Make sure TREBL AB Z2 is fully charged, and the AUX cable is not plugged in.

Turn ON your headset by long-pressing POWER button for 3 seconds.
You will hear the “Power on” sound clue. Do not release the button , until

you hear “Pair ing” voice prompt , and the LED will start flashing B LUE,

indicating Z2 is in pairing mode.

1. Activate Bluetooth® function on your device and keep it within 3
feet / 1 meter while pairing.

2. Using your device, scan/search for available Bluetooth® devices.

3. Select TREBLAB Z2 from the device list.

4. If prompted the password, enter “0000”

5. Once Z2 is successfully paired and connected, the LED will start

flashing BLUE slowly.

After the connection is lost, the Z2 will try to reconnect automatically
to the last paired device. If reconnection does not happen
automatically, the headset will start looking for the previously paired
device within effective distance range. The headphones can
remember 8 recent devices.

If automatic reconnection has failed , please follow the pairing
instructions above, to connect the headphones manually.

AUDIO CONTROLS

To pause and resume playback when connected via the wireless
connection, short press the PLAY button.
To adjust volume, short press the Volume+ button to turn the volume
up and Volume- button to turn the volume down.
To change tracks, long press the NEXT button to play the next track
and PREVIOUS but ton to play the previous track.

ANC FUNCTION

TREBLAB Z2 headphones are equipped with Active Noise Cancellation
(ANC) technology.
The headphones cancel background noise in your environment for an
optimal acoustic experience .
To turn the ANC f unction ON, move the AN C switch on the left earphone to
the ON position. The LED indicator located next to the switch will turn RED.
You can also use TREBLAB Z 2 for noise-isolation without music playback
by having ANC ON.

PHONE CALLS

TREBLAB Z2 can be used to make and receive phone calls when
connected wirelessly. Audio playback will be paused during calls.

To Answer/End Call: Short press the PHONE button.
To Redial: Short press PHONE button twice quickly.

SIRI®

TREBLAB Z2 headphones are Siri® -compatible. To use Siri® while
in Bluetooth® mode, just activate it on your device.

Google Voice Search®

TREBLAB Z2 headphones are compatible with Google Voice
Search ®. To use GVS® while in Bluetooth® mode, just activate it on
your device.

II. LINE-IN MODE

You can connect TREBLAB Z2 to compatible devices using the
supplied AUX audio cable.
Plug one end of the 3.5 mm audio cable into the LINE-IN port on the
right headphone and plug the other end into the AUX jack on your
device.

AUDIO CONTROLS

The change track functions N EXT and PREVIO US are not supported
when using the AUX cable. Volume control and phone calls
management using the PHON E button located on the right
headphone are also not available.
You will need to make those adjustments using your device.

1. iOS devices

You can star t the iTunes player by short-pressing the PHON E button
located on AUX-IN cable. Short-press PHONE button on the cable to
PLAY or PAUSE the music, while iTunes is on.

2. Android & Windows devices

You can star t the last used music player by short-pressing the
PHON E button located on AUX-IN cable.

Short-press PHONE button to PLAY or PAUSE the music, while the
music player is on.

ANC FUNCTION

TREBLAB Z2 headphones are equipped with Active Noise
Cancellation (ANC) technology.
The headphones cancel background noise in your environment for an
optimal acoustic experience .
To turn the ANC f unction ON, move the AN C switch on the left
earphone to the O N position. The LED indicator located next to the
switch will turn RED.
You can also use TREBLAB Z 2 for noise-isolation without music
playback by having ANC ON.

PHONE CALLS

TREBLAB Z2 can be used to make and receive phone calls in Line-in
mode. Audio playback will be paused during calls.
To Answer/End Call: Short press the PHONE button located on cable.

SIRI®

TREBLAB Z2 headphones are Siri® -compatible. To turn Siri® ON while
using AUX-IN connection, long-press the PHONE button on the cable.

Google Voice Search®

TREBLAB Z2 headphones can work with Google Voice search. To turn
GVS® ON, long-press the PHONE but ton on the cable.

TROUBLESHOOTING

PROBLEM

Headphones
are not
turning on

Music is not
playing

Headphones
are not p airin g
with my
Bluetooth®
device

SOLUTION

Make sure the headphones are fully charged.
Charge for 4 hours, if necessary.
Long-press the POWER button again.

Make sure the headphones are fully charged.

Make sure the audio cable is correctly and firmly connected

to the headphones if you are using AUX mode.
Make sure the audio cable has been removed from the
headphones if you are using Bluetooth® connection.
Make sure the volume level is not set to a 0 level both in the
headphones and device.
Make sure that the distance between your device and the
headphones is less than 30 feet / 10 meters.
Make sure if your smar t device has the Bluetooth® mode
turned ON, and is not plugged in with any kind of wired
connection.

Make sure the AUX cable is not plugged in.
Make sure the headphones are not paired with any other
device, as it can only pair with one device at a time.
Make sure that the distance between your device and the
headphones is less than 30 feet / 10 meters.
Make sure that your smart device has Bluetooth® mode
turned ON, and is not plugged in with any kind of wired
connection.
Restart your device and headphones. Remove the Z2 from
your device’s pairing list. Try to pair again.

Headphones are
visib le on my dev ice,
but do not connect

Make sure the headphones are not paired with
any other device, as it can only pair with one
device at a time.
Make sure that the distance between your
device and the headphones is less than 30 feet
/ 10 meters.
Disconnect the headphones from your device.
Remove the Z2 from your device’s pairing list.
Try to pair again.

I could n ot find a

wireless driver for
my lapto p

Frequent
disco nnec tion and
noise

Make sure your laptop supports wireless
connection . If it doesn’t, you will need an
external wireless USB adapter compatible with
your laptop. For further details, consult with
your laptop manufacturer.

Ensure that the distance between your device
and the headphones is less than 30 feet / 10
meters.
Ensure that nothing is blocking the signal
between your device and the Z2.
Check if the music is paused.
Check if the volume level is set both on the
source device and on the headphones.
Check if the headphones are running out of
power.
Restart your device and headphones. Remove
the Z2 from your device’s pairing list. Pair again.

CHARGING AND BATTERY

To charge the headphones, plug in the supplied charging c able into
the Micro-USB charging port on the right headphone, and the other
end of the cable into a standard USB port. The LED light will turn
RED. Z2 takes up to 4 hours to fully charge. The RED light will turn
OFF when the headphones are fully charged.

One full battery charge provides up to 25 hours of playtime at
maximum volume, and up to 30 hours at medium volume. When the
batter y is running low, you will hear a “Bat tery low” voice prompt.

To maximize the battery lifespan charge your headphones through a
low voltage power source such as a computer’s USB port. If you’re
using an AC/DC adaptor or charger, be sure to use a 5V, 1A rated
USB charger and the supplied charging cable.

Unplug the Z2 f rom the charging cable and the cable itself from the
power source when not in use.

If left unused, a fully charged battery will lose its charge over time.
We recomme nd fully charging the Z2 twice a month to ensure

sufficient battery life.

SAFETY RULES

Don’t disassemble or modify your headphones for any reason. Doing
this may cause the headphones to malfunction or become
combustible . The damage to your device can void your
manufacturer’s warranty.

Do not let your device to get wet – liquids can cause serious damage.
Water damage to your device can void your manufacturer ’s warranty.

Make sure the headphones are completely dry before charging.

Avoid exposing TREB LAB Z2 to extreme temperatures (below 37°F /
3°C or above 112°F / 45°C). Extre me temperatures can cause
deformation of components, reduce batter y life and the lifespan of
your new headphones.

Don’t put the headphones’ LED lights close to human or animal eyes .

Do not use your headphones outdoors during a thunderstorm.
Thunderstorms can cause serious malfunction and increase the risk of
electric shock.

SPECIFICATONS

Bluetooth® version:

Receiver range:

Operating voltage:

Charging time:

Charging input:

Charging interface:

Standby time:

Operating time:

Operating voltage ( V) /
current (mA):

Frequency range (GHz):

Channel spacing (MHz):

Frequency stability:

Actual frequency range:

Transmit power (dBm):

Receiver sensitivity (dBm):

CSR 4.2

30 feet/ 10M

4.2V

3-4 hours

5V/1.0A

Micro USB

up to 550 hours (Bluetooth® function only)

up to 30 hours

3.7V / 40mA

2.402 - 2.480

2MHz

+/- 10ppm

2.40 - 2.48GHZ

4dBm (MAX)

-90dBm

THANK YOU

We truly appreciate that you chose TREBLAB as your trusted brand
of wireless headphones and sincerely hope you enjoy the superb
sound and seamless usability TREBLAB Z 2 provides.

We love making our customers happy by providing true value with
our products. If for any reason, you are not completely satisfied with
your purchase, or have any questions, please let us know by
contacting us at [email protected]. We care about our
customers more than anything and are always here to serve you.

1 YEAR WARRANTY

1 YEAR PARTS AND LABOR WARRANTY.

Please visit TREBLAB.COM to register
for your warranty and get a 10%OFF
coupon for your next purchase!

Manufactured by:
Productech Corp www.treblab.com

Contact us:
[email protected]

Made in China
