BF10
Resin Base Weights
Assembly and Operation Guide
Page 2
Thank you for your purchase of Treasure Garden’s BF10 Cross Base Weights.
Please remove all contents from the package, inspect and review checklist.
BF10 CHECKLIST
A - (4) resin base weights included
P r i o r t o A s s e m b l y
Select area to set AG Universal Cross Base Stand and place in desired location. Moving the
umbrella will be difficult once fully assembled. Be sure bottom pole stem is attached to cross
bar stand and cross bars are adjusted to 20” position.
S t e p 1
Remove 4 resin base weights from carton and lay on soft surface (Fig. 1). Remove caps
from each resin base weight by turning counter clockwise (Fig. 2) and fill with dry playground
sand (Fig. 3). The BF10 resin base weight holds up to 55 lbs. of sand, 220lbs for all 4.
NOTE: When filling the containers, it is necessary to wet down the sand after partial filling. After
wet down, fill each resin base weight with remaining sand. Place cap back onto cross base
weight and turn clockwise.
(Fig. 1)
S t e p 2
Place each resin base weight onto AG Universal
Cross Bar Stand. Hook each section together so
the resin base weights are secured in place (Fig. 4).
Begin with middle sections first and work your way
out (Fig. 5).
(Fig. 4)
(Fig. 2)
(Fig. 3)
(Fig. 5)
Page 3
BF10 on AG19 Cantilever
IMPORTANT: HANDLE WITH CARE
• Fully assembled, the AG19 umbrella weighs approximately 290 lbs. with BF10 resin
base weights. Moving the umbrella fully assembled will increase the risk of damage to
your umbrella and/or cause serious injury. We recommend a two-person team for
assembly and disassembly.
• AG Universal Cross Bar Stand will not support umbrella without proper weight. Using
the cross bar stand without weight will damage your umbrella and may cause injury.
DO NOT OPEN UMBRELLA UNTIL WEIGHTS ARE SECURED.
• Do not allow children to play on or with the base.
• Close the umbrella in windy conditions or when a storm approaches.
• No umbrella should be left unattended in the open position.
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from defects
in original materials and workmanship for a
period of 1 year from the date of purchase.
If a defect in the original material or
workmanship appears during the warranty
period; Treasure Garden will (at its option)
repair or replace the product without
Limited warranty against fabric
charge.
fading, depending on fabric.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can be
solved with a replacement part that can be
shipped directly to the dealer for
professional installation/repair.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the 1
year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped/billed
at your expense.
This warranty gives you specific legal rights,
and you may have other rights which vary
from state to state.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect of
reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but not
limited to wind, hurricanes, tornadoes, and
storms) are not covered by this warranty.
