Page 1
Ready-To-Race
®
Fully Assembled
Ofcially Licensed Race Replica
Battery
& Charger
Included
Waterproof
Electronics
Edition
scott douglas | mike oberg
Short Course Off-Road Race Truck
Page 2
Scott Douglas began his racing career when he and brother Steve purchased an old
Ford F-150 race truck off a used car lot in 1980. The Douglas brothers entered it in
the Baja 500 and not only nished, but posted a fth-place nish in Class 8.
In 1990, Walker Evans tapped Scott to pilot a factory-backed Jeep
®
Cherokee.
The result was a class championship. Scott then moved to a Dodge
®
factory ride
and won championships in the SCORE, HDRA, and BITD series. In the mid-1990s,
Scott was a dominant force in the Short-Course Off-Road Drivers Association
(SODA) series. He moved to Pro 4WD in 1996, winning the championship
for Rampage Racing. He repeated the feat in 1997 and also won the
BorgWarner
®
Cup. In 2006, Scott teamed up with Pro Fab Motorsports
and AMSOIL
®
to win another Borg Warner Cup. 2007 saw numerous wins
and a second-place nish overall for the season in Pro 4WD. In 2008, Scott
Douglas and Bill Smith of Pro Fab designed and built a new F-150 tuned by
chief mechanic Jason Schampers. Scott quickly turned the new truck into a
competitive force on the track propelling
him into the top 3 in the 2008
point standings.
Mike Oberg kicked off his off-road racing career in 1993 behind the wheel of a used
buggy, but he soon built a stock truck and ran both classes—sometimes jumping
out of the buggy at the nish line to suit up in the truck back at the start! By 1997,
Mike was racing his truck full-time and took the Short-course Off-road Drivers
Association (SODA) Stock Truck championship, winning ve of the eight races
in the series. 1998 saw Mike win the Sportsman Stock Truck crown, and in 2001,
Mike earned the Sportsman 2WD championship title. For the 2002 season,
Mike partnered with Amsoil
®
to run in the Sportsman 2WD class and made the move
to Pro 2WD in 2006 with a brand new truck. The team worked hard to bring
the new machine up to speed, and Mike moved up steadily in points to
nish second, just two points behind rst place. But Mike’s
biggest win was yet to come — a rousing last-lap, come-
from-behind victory in the Jason Baldwin Memorial
Race. In 2007, Mike nished second in the WSORR
series and added a full championship racing schedule
in 2008. With over 40 wins in ve classes and four
championship rings in four different classes at the
legendary Crandon International Off-Road Raceway,
you can count on seeing many more wins from
Mike Oberg.
Scott douglas mike oberg
scott douglas | mike oberg edition
Page 3
Quick Release
Battery Doors
Waterproof
XL-2.5 ESC
Traxxas
High-Current
Connector
Titan 380 Motor
Fully Adjustable
GTR Shocks
™
Brushless Ready
Transmission
High quality construction with the heavy gauge wire and a
Traxxas High-Current Connector for high-power excitement.
Exclusive patent-pending Training Mode™ limits full throttle to just
50% for rst-time drivers. As driving skills improve, a simple prole
change unleashes full-power excitement.
• High current handling
• Forward/reverse/brake
• Integrated on-off button
• EZ-Set
®
push-button setup
• Thermal shutdown protection
• Smooth high-frequency control
• High efciency MOSFETs
• Three easy-to-program drive proles
• Backed by the Traxxas Lifetime
Electronics Warranty
Waterproof Electronic
Speed Control
Precision Hex
Hardware
Short-Course Racing Action
Power. Precision. Performance. That’s what it takes to win in short-course racing, where heavymetal machines with 900+ horsepower and giant suspension travel do battle with dirt-roosting
power slides, Supercross-style big-air jumps, and more than a little contact in the corners. Traxxas
knows: we race full-size Pro4WD short-course trucks, and now you can experience the thrill of shortcourse racing in 1/16 scale. At the track or in your own backyard, the 1/16 Slash 4WD brings
all the action home so you can experience the high-speed, head-to-head competition. Rip over
jumps, power-slide through turns, bump-and-run to the nish line — the 4-wheel independent
suspension has been carefully tuned to replicate the Pro4WD driving and handling experience.
The engineering innovation and manufacturing precision that goes into Traxxas’ largest models
also drives the 1/16 Slash 4WD. There’s simply nothing else like it. Power. Precision. Performance.
The 1/16 Slash 4WD delivers all three.
Incredible Revo-Spec Suspension
Provides Unheard of Suspension Travel
and Precision Tuned Performance
in a 1/16 Scale Truck.
Sealed Waterproof Electronics
Fun in Water, Snow,
and Mud
The unique Revo®-Spec suspension geometry
multiplies the suspension travel to lengths
normally found on larger models. It provides
true progressive rate performance that’s light
over the small bumps and instantly tightens
when compressed to resist bottoming out
over large jumps.
Innovative linkage based suspension
geometry multiplies suspension travel and
increases spring and damping rates as the
shocks are compressed for instant smallbump compliance without compromising
shock-absorbing performance for big hits.
Slash 4WD’s super-smooth oil-lled shocks
damp the suspension and maintain control
no matter how rugged the terrain. They
are fully tuneable and include pressure
bladders for air/oil separation and threaded
spring pre-load collars for quick ride height
adjustments.
Full Ball
Bearings
Hex
Hardware
Traxxas
High-Current
Connector
Revo-Spec
Suspension
4-Channel
Micro Receiver
Oil-Filled
GTR Shocks
Wheel Travel
Progressive Rate Travel
Constant Rate Travel
Wheel Force
Progressive
Rate Travel
Ball-Bearing
Transmission With
Slipper Clutch
The 1/16 Traxxas Slash is built for extreme
Velineon® power (sold separately). The
single-speed Brushless Ready™ transmission
features interchangeable internal gears and
a Torque-Control™ slipper clutch to handle
the massive torque of high-performance
brushless motors.
Traxxas Power Cell Series 1
NiMH Battery Pack and A/C Wall
Charger Included!
Page 4
WARNING: This product contains chemicals which are
known to the State of California to cause cancer, birth
defects, or other reproductive harm.
Traxxas Plano, Texas Made in Taiwan
Copyright © Traxxas 2009 All rights reserved.
KD1059 Rev. 090315
Model 7005
Channel
Length
Front Track
Rear Track
Height (overall)
Wheelbase
Wheel Diameter
14" (356mm)
7.3" (185mm)
7.3" (185mm)
4.92" (125mm)
8.1" (206mm)
1.4" (35mm)
Motor
Transmission
Speed Control
Differential Type
Chassis Type
Radio System
Titan® 380
Internally Adjustable, Brushless Ready
XL-2.5 Waterproof ESC
Hardened Steel Bevel, Sealed, Limited Slip
Nylon-Composite
Traxxas TQ (2-Channel)
No Painting or Trimming Required.
Edition
scott douglas | mike oberg
Page 5
Model
7005
No previous experience with radio
controlled models is required.
Model requires a minimum of setup,
maintenance, or support equipment.
bluehighway font
1-888-TRAXXAS
IMPORTANT! THIS PRODUCT IS NOT DESIGNED FOR CHILDREN OR MINORS YOUNGER
THAN 14 YEARS OLD. RESPONSIBLE ADULT SUPERVISION IS REQUIRED DURING
OPERATION AND MAINTENANCE. The 1/16 Slash 4WD is a high-performance model which is NOT
intended for use on public roads or in congested areas where its operation may confl ict with or disrupt
pedestrian or vehicular traffi c. Read all enclosed information before operating. Fully illustrated, step-by-step
instructions describe adjustment, operation, and required maintenance procedures. Slash should not be
operated in a crowd, or without adequate space. The vehicle is fully assembled, ready to run, and requires 8 AA
alkaline batteries for operation. These items are available from your hobby dealer. In an effort to continually
upgrade our products, Traxxas reserves the right to make improvements and modifi cations to this model, which
may not be refl ected in the photographs and specifi cations printed on this box.
What You'll Need To Run
Your Slash 4WD:
Short-Course
Off-Road Race Truck
8 AA Alkaline Batteries
Traxxas Toll-Free Customer Ser vice*
Slash 4WD is backed with Traxxas Total Suppor t. You won’t fi nd it anywhere else.
Whether it’s a question about the motor, radio, replacement parts, or performance
upgrades, 1-888-TRAXXAS is your toll-free link to fast friendly solutions.
(*Toll-free in the U.S. only.) E-mail anytime to: support@Traxxas.com
• Two-channels
• High-power output
• Special comfort grip
• Excellent balance
• Retractable antenna
• Servo reversing
• Low-battery indicator
• Electronic trim controls
Included Radio System
What's In The Box:
AMSOIL® 1/16th Slash™ 4WD, Ready-To-Race® with Titan® 380 motor,
XL-2.5 electronic speed control, TQ radio system with 4-channel Micro
Receiver, full color Owner’s Manual, 7.2 volt NiMH battery, and charger.
Choose either
Scott Douglas or Mike Oberg
Both Decal Sets Included!
Page 6
Forward/Reverse
Waterproof Electronic
Speed Control
Waterproof Servo Titan
®
380 Motor
Short-Course
Off-Road
Race Truck
Included Battery Pack
and Charger
