Traulsen RDH232WUT-HHS, RDH232WPUT-FHS, RDH232WPUT-HHS, ADH232WUT-FHS, ADH232WUT-HHS General Manual

Project Quantity Item #

Model Specied: CSI Section 11400

Reach-In/Pass-Thru Refrigerated-Heated

Models/Self-Contained

Includes Traulsen's patented

INTELA-TRAUL® control

Model RDH232WUT-FHS

(shown with standard left/right hinging)

Standard Product Features

• R-Series: Stainless Steel Exterior & Interior

• A-Series: Stainless Steel Exterior/Anodized Aluminum Interior

• INTELA-TRAUL® Microprocessor Control System

• One-Time Start-Up Temperature Adjustment Feature &

ON/OFF Switch (for heated compartment only)

• Balanced, Self-Contained Refrigeration System Using R-134a

• Scroll Blower Type Evaporator Fan & Biased Return Air Duct

• Full or Half Length Stainless Steel Doors With Locks

• Self-Closing Doors With Stay Open Feature At 120 Degrees

• Guaranteed For Life Cam-Lift Hinges & Door Handles

• Standard Door Hinging: 232W = Left/Right, F & R: 232WP =

Left/Right (other hingings available)

• Stainless Steel Breaker Caps

• Adjustable Wire Shelves (installed at the factory)

• Automatic Non-Electric Condensate Evaporator

• Magnetic Snap-In Door Gaskets

• Gasket Protecting Metal Door Liner

• Controllable Anti-Condensate Door Perimeter Heaters

• Stainless Steel One-Piece Louver Assembly & Heater Guards

• 9' Cord & Plug Attached

• Set of Four (4) 6" High Adjustable Stainless Steel Legs

• One Year Parts And Labor Warranty

• Two Year Control Warranty (parts and labor)

• Five Year Compressor Warranty

Listed by Underwriters Laboratories Inc.,

and classied by Underwriters Laboratories

Inc., in accordance with ANSI/NSF7.

Two Section Models, 32" Deep

Full Length Door Reach-In Model RDH232WUT-FHS

R

SERIES

Stainless Exterior

& Interior

A

SERIES

Stainless Exterior,

Anodized Alumi-

num Interior

The R & A Series represent Traulsen's Top-of-the-Line product offering. The
reach-in and pass-thru refrigerated/heated models are all designed to offer
maximum interior storage capacity. Each is supplied standard with such high
quality features as balanced refrigeration systems, microprocessor controls,
communications ability and stainless steel exteriors. Additionally, they of­fer the widest range of optional accessories to choose from, and can be

specied for use with many different applications, including: Foodservice,

Correctional, Institutional, Export, etc.

Half Length Door Reach-In Model RDH232WUT-HHS
Full Length Door Pass-Thru Model RDH232WPUT-FHS

Half Length Door Pass-Thru Model RDH232WPUT-HHS

Full Length Door Reach-In Model ADH232WUT-FHS
Half Length Door Reach-In Model ADH232WUT-HHS

Full Length Door Pass-Thru Model ADH232WPUT-FHS
Half Length Door Pass-Thru Model ADH232WPUT-HHS

Options & Accessories

• Stainless Steel Finished Back With Rear Louvers (reach-in
models only)

• Re-Hinging Feature For Door(s)

• No. 1 Type Tray Slides To Accommodate either (1) 18" x 26"

or (2) 14" x 18" Sheet Pans, Adjustable To 2" O.C.

• No. 2 Type Tray Slides To Accommodate (1) 18" x 26" Sheet

Pans, Adjustable To 2" O.C.

• No. 3 Type Tray Slides To Accommodate (2) 12" x 20" Steam

Table Pans, Adjustable To 2" O.C.

• No. 4 Type Tray Slides To Accommodate (1) 18" x 26" Sheet
Pans (chrome rod type, equips 1/2 section)

• Universal Type Tray Slides To Accommodate Either (1)

18" x 26" or (2) 14" x 18" Sheet Pans, or (2) 12" x 20" Steam

Table Pans, Adjustable To 4" O.C.

• Additional Wire Shelves

• Locking Hasps (padlocks supplied by others)

• Export 220/50/1 Voltage

• Stainless Steel Shelves

• Kool Klad Exterior Laminate Decor

• Set of Four (4) 6" High Casters In Lieu of Legs

• Set of Four (4) 4-5/8" High Casters In Lieu of Legs

• 4-1/2" High Stainless Steel Base In Lieu of Legs

• 6" High Stainless Steel Kickplate (for use with standard legs)

• Prison/Correctional Facilities Options

• Remote Applications (see spec sheet TR35837 for details)

• Clear Glass Door(s) In Place Of One Or More Door(s)

• Two Year Service/Labor Warranty Available

Approval: __________________________________

TRAULSEN
4401 BLUE MOUND RD. FT. WORTH, TX 76106
PHONE [phone] FAX-MKTG. 1 [phone]
Website: www.traulsen.com

Elevation - R/ADH232WUT

Plan - R/ADH232WUT

Section - R/ADH232WUT

TRAULSEN
4401 BLUE MOUND RD. FT. WORTH, TX 76106
PHONE [phone] FAX-MKTG. 1 [phone]
Website: www.traulsen.com

Elevation - R/ADH232WPUT

Plan - R/ADT232WPUT

Section - R/ADH232WPUT

TRAULSEN
4401 BLUE MOUND RD. FT. WORTH, TX 76106
PHONE [phone] FAX-MKTG. 1 [phone]
Website: www.traulsen.com

Project Quantity Item #

Model Specied: CSI Section 11400

Specications

Construction, Hardware and Insulation

Cabinet exterior front, one piece sides, louver assembly and doors are constructed

of 20 gauge stainless steel with #4 nish. Cabinet interior and door liners are

constructed of stainless steel (anodized aluminum in the A-Series). The exterior
cabinet top, and bottom are constructed of heavy gauge aluminized steel. The exterior
cabinet back on reach-in models is constructed of heavy gauge aluminized steel. A
set of four (4) adjustable 6" high stainless steel legs are included.

Doors are equipped with a gasket protecting metal door pan, removable plug
cylinder locks and guaranteed for life cam-lift, gravity action, self-closing metal,
glide hinges with stay open feature at 120 degrees. Hinges include a concealed
switch to automatically activate the interior incandescent lighting. Guaranteed for

life, work ow door handles are mounted horizontally over recess in door which limits

protrusion from door face into aisleways. Doors have seamless, polished metal
corners.

Easily removable for cleaning, vinyl magnetic door gasket assures tight door seal.
Anti condensate heaters are located behind each door opening.

Both the cabinet and doors are insulated with an average of 2" thick high density,
non-CFC, foamed in place polyurethane.

DIMENSIONAL DATA R/ADH232WUT R/ADH232WPUT

Cabinet Type Reach-In Pass-Thru

Net capacity total cu. ft. 51.6 (1462 cu l) 54.2 (1535 cu l)

Length - overall in. 58 (147.3 cm) 58 (147.3 cm)

Depth - overall in. 35 (88.8 cm) 3715⁄16 (96.4 cm)

Depth - over body in. 32 (81.3 cm) 32 (81.3 cm)

Depth - door(s) open 90° in. 5711⁄

16

(146.5 cm) 833⁄8 (211.8 cm)

Clear door width in. 211⁄8 (53.6 cm) 211⁄8 (53.6 cm)

Clear half-door height in. 271⁄2 (69.9 cm) 271⁄2 (69.9 cm)

Clear full-door height in. 575⁄8 (146.3 cm) 575⁄8 (146.3 cm)
Height - overall on 6" legs 831⁄4 (211.5 cm) 831⁄4 (211.5 cm)

No. Standard Shelves 6 6

Shelf area total sq. ft.1 37.6 (3.49 sq m) 37.6 (3.49 sq m)

Shelf area refrigerator. sq. ft.1 18.8 (1.75 sq m) 18.8 (1.75 sq m)

Shelf area heated section sq. ft.1 18.8 (1.75 sq m) 18.8 (1.75 sq m)

RDH Net Wt. lbs. 630 (286 kg) 685 (311 kg)

ADH Net Wt. lbs. 550 (249 kg) 605 (274 kg)

ELECTRICAL DATA

Voltage 208/115/60/1 208/115/60/1

Feed wires with Ground 4 4

Heater Wattage @ 208V 1500 1500

Full load amperes 13.5 13.5

REFRIGERATION DATA

Refrigerant R-134a R-134a

BTU/HR H.P.2 2220 (1⁄3 HP) 2220 (1⁄3 HP)

NOTE: Figures in parentheses reect metric equivalents.

1= Area of standard shelf compliment only, does not include storage area of additional shelves or
available on cabinet bottom.
2= Based on a 90 degree F ambient and 20 degree F evaporator.
3= For approximate remote weights deduct 40 lbs. from respective net or gross weight. For other
information on remote models, please refer to spec sheet TR35837.

NOTES

Refrigeration System

A top mounted, self-contained, balanced refri geration system using R-134a
refrigerant is conveniently located behind the one piece louver assembly. These
models feature an easy to clean front facing condenser, thermostatic expansion
valve, air-cooled hermetic compressor, plenum effect blower coil, large, high
humidity evaporator coil located outside the food zone and a top mounted non­electric condensate evaporator.

Biased return air duct protects against introduction of warm kitchen air, promoting

even temperature maintenance and efcient operation.

A 9' cord and plug is provided standard. Standard operating temperatures are 34 to
38°F for the refrigerator compartment and 135 to 180°F for the heated compartment.

Heating System

A low watt density, serpentine style, heater is employed for the generation of electric

heat. Low velocity air is forced across its large surface area to efciently move heat

radiating away from these through a down-air distribution duct, where it is then evenly
distributed throughout the cabinet, assuring the proper holding environment for hot
food product, without drying. A vent, located at the top of the cabinet, is included
for positive humidity control.

Controller

The easy to use water resistant INTELA-TRAUL® microprocessor control system
is supplied standard. Unit is NAFEM Data Protocol communication (NDP) ready.
Optional hardware required to be NDP compliant. Third party software required
for network connection. It includes a 3-Digit LED Display, Fahrenheit or Celsius
Temperature Scale Display Capability, and an RS485 data port. In addition it
includes audio/visual alarms for: Hi/Lo Cabinet Temperature, Door Open, Clean
Condenser, Evaporator Coil and Discharge Line Sensor Failures, and Power Sup­ply Interruption. A separate control is provided for both the refrigerated and heated
compartments.

Interior

Standard interior arrangements include three (3) wire shelves per section, mounted
on pilasters. Shelves are full-width, and do not have any large gaps between them
requiring the use of "bridge" or "junior shelves." Recommended load limit per shelf
should not exceed 225 lbs. Optional tray slides may bepurchased in combination
with, or in lieu of these. Both standard and optional interior arrangements are
completely installed at the factory.

Warranties

Both a one year parts and labor warranty and a ve year compressor warranty (self-

contained models only) are provided standard. An optional 2nd year extended parts
and labor warranty is also available. In addition the INTELA-TRAUL® controls are
warranted by a two year parts and labor warranty.

Equipped With One NEMA L14-20P Plug

NOTE: Full load amps and plug style may vary depending on
electrical options chosen and condensing unit employed.

In order to assure optimum performance, the condensing unit MUST have an adequate supply
of air for cooling purposes. Therefore, the operating location must either have a minimum of 12”

clearance overhead of the condensing unit or allow for unrestricted air ow at the back of the unit.

Clearance of at least 12” above is required in order to perform certain maintenance tasks.

REQUIRED CLEARANCES

NOTE: When ordering please specify: Voltage, Hinging, Door Size, Options and any ad­ditional warranties.

Continued product development may necessitate specication changes without notice.

Part No. TR35785 (revised 4/10)
