EP308 Specifications Manual
06E00079-001A
1
Version
Author
Approval
Approved
Change
DRN/DCN
A
A. Pasker
Initial Release
On-Board Validator Manual
date
by
Number
EP308 Specifications Manual
06E00079-001A
2
Contents
1 Overview ............................................................................................................................. 4
2 References ......................................................................................................................... 4
3 Acronyms ............................................................................................................................ 4
4 Electromagnetic Specifications ........................................................................................... 5
5 Environmental ..................................................................................................................... 6
5.1 Temperature ................................................................................................................ 6
5.2 Shock and Vibration ..................................................................................................... 6
5.3 Electrostatic Discharge ................................................................................................ 6
5.4 MTBF ........................................................................................................................... 6
5.5 Power Input.................................................................................................................. 6
5.6 Mechanical .................................................................................................................. 6
6 Connectors ......................................................................................................................... 7
6.1 Power .......................................................................................................................... 7
6.1.1 Connector ............................................................................................................. 7
6.1.2 Pinout ................................................................................................................... 7
6.2 Digital Input .................................................................................................................. 7
6.2.1 Connector ............................................................................................................. 7
6.2.2 Pinout ................................................................................................................... 7
6.3 J1708 ........................................................................................................................... 7
6.3.1 Connector ............................................................................................................. 7
6.3.2 Pinout ................................................................................................................... 7
6.4 Ethernet ....................................................................................................................... 9
6.4.1 Connector ............................................................................................................. 9
6.4.1 Pinout ................................................................................................................... 9
7 Card Interfaces ................................................................................................................... 9
7.1 Micro-SD Card Slot ...................................................................................................... 9
7.2 SIM Card Slot .............................................................................................................. 9
7.3 SAM Card Slots ........................................................................................................... 9
8 Interface Specifications/Recommendations ......................................................................... 9
8.1 J1708 ........................................................................................................................... 9
EP308 Specifications Manual
06E00079-001A
3
8.2 Digital Inputs ...............................................................................................................10
8.3 Audio ..........................................................................................................................10
8.4 GPS ............................................................................................................................10
8.5 Wi-Fi ...........................................................................................................................11
8.6 Ethernet ......................................................................................................................11
EP308 Specifications Manual
06E00079-001A
4
Acronym
Meaning
DC
Direct Current
EMI
Electromagnetic Interference
FCC
Federal Communications Commission
GPS
Global Positioning System
IEEE
Institute of Electrical and Electronic Engineers, Inc.
LAN
Local Area Network
MTBF
Mean Time Before Failure
RMS
Root mean square
USB
Universal Serial Bus
Wi-Fi
Wireless network based on IEEE 802.11

1 Overview

This document is to provide the specifications and recommendations for the interconnection of the EzeFare Validator.

2 References

[1] SAE J1708 Serial Data Communication Between Microcomputer Systems in Heavy-Duty
Vehicle Applications Aug 2004 [2] SAE 1939-11 Physical Layer, 250K bits/s, Twisted Shielded Pair Oct 1999 [3] Telit Jupiter JF2 Datasheet [4] IEEE 802.3

3 Acronyms

EP308 Specifications Manual
06E00079-001A
5

4 Electromagnetic Specifications

Note: This equipment has been tes ted and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the foll owing measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an output on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the manufacturer could void
the user’s authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation o f the dev i c e.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
EP308 Specifications Manual
06E00079-001A
6

5 Environmental

The EzeFare Validator is designed to meet the following specifications but is not tested to meet SAE J1455.

5.1 Temperature

Operating: -20°C - + 60°C Storage: -30°C - +70°C

5.2 Shock and Vibration

Swept Sinusoidal: 10 – 2000 Hz @ 2 g Survive and impact velocity of 1.75 m/s on all edges and corners

5.3 Electrostatic Discharge

Packaging and Handling: Tested to +/- 4kV direct contact discharge. In-Vehicle Operation: Tested to +/- 8kV direct contact discharge.

5.4 MTBF

50K hours MTBF minimum

5.5 Power Input

Operating voltage range: 8 – 36V DC Current: Nominal value 500 mA @ 12V, 250 mA @ 24V
Peak value 2 A @ 12V, 1A @ 24V
Overvoltage (>36V) and reverse voltage protected.

5.6 Mechanical

Depth: 81 mm (3.19”) Width: 134 mm (5.28”) Length: 213 mm (8.39”)
EP308 Specifications Manual
06E00079-001A
7
Pin Number
Signal
Signal Type 1
VIN
Vehicle Battery +
2
GND
Chassis Ground
3
IGN_SENSE
Vehicle Ignition Sense
4
RFU
Reserved For Future Use
Pin Number
Signal
Signal Type 1
INPUT1
Discrete Input
2
INPUT2
Discrete Input
3
INPUT3
Discrete Input
4
INPUT4
Discrete Input
5
INPUT5
Discrete Input
Pin Number
Signal
Signal Type 1
J1708A
J1708A(-)

6 Connectors

6.1 Power

6.1.1 Connector

Connector: Molex 0306-2044 Mating Connector: Molex 0306-1043 or equivalent

6.1.2 Pinout

6.2 Digital Input

6.2.1 Connector

Connector: Unterminated

6.2.2 Pinout

6.3 J1708

6.3.1 Connector

Connector: Molex 0306-2032 Mating Connector: Molex 0306-1038 or equivalent

6.3.2 Pinout

EP308 Specifications Manual
06E00079-001A
8
Pin Number
Signal
Signal Type 2
N/C
N/A
3
J1708B
J1708B(+)
EP308 Specifications Manual
06E00079-001A
9
Pin Number
Signal
Signal Type 1
TPI+
Data In+
2
TPI-
Data In-
3
TPO-
Data Out-
4
TPO+
Data Out+
5
SHIELD
Ground

6.4 Ethernet

6.4.1 Connector

Connector: D-SUB 50 Male Mating Connector: D-SUB 50 Female, AMP 1658641-3 or equivalent

6.4.1 Pinout

7 Card Interfaces

7.1 Micro-SD Card Slot

One MicroSD card slot for removable memory storage.

7.2 SIM Card Slot

One Mini-SIM (2FF) card slot.

7.3 SAM Card Slots

Two Secure Access Module card (2FF) slots.

8 Interface Specifications/Recommendations

8.1 J1708

J1708 is a modified version of RS-485. J1708 specifies 18 gauge wire with 1 twist per inch with a total network length of 131 feet (40m) maximum. The minimum/maximum voltages on the bus are specified to be -7V – +12V. The data rate is 9600 baud. The standard node in the J1708 standard is shown in Figure 8-1.
Vdiff is defined as A – B. If A – B ≥ 200 mV then the data bit is a 1, -200 mv ≤ A – B ≤ 200 mV is undefined, A – B ≤ -200mV the data bit is a 0.
EP308 Specifications Manual
06E00079-001A
10
Channels
48
Sensitivity
To -163 dBm
Figure 8-1
Note: C1 and C2 are 0.0022 F. Caution: An RS-485 specified termination uses a 100 ohm resistors external to each node at
each end of the bus which if installed in a J1708 system can cause the network to fail/

8.2 Digital Inputs

VIL < 0.5V and VIH 1.2V. These inputs are protected with 47K of series resistance. Transients to 60V can be tolerated
with circuit damage becoming more likely above 60V.

8.3 Audio

The speaker is rated to 3W, 200 – 20,000 Hz.

8.4 GPS

The On-Board Validator uses an internal GPS antenna. Specifications taken from Telit J u p iter JF2 Datasheet [3].
EP308 Specifications Manual
06E00079-001A
11
Heading
0.01 deg
Velocity
0.01 m/s
Accuracy
2.5 m
Acquisition Rate
Cold start: 35s, average Hot start: 1s, average
Protocol
NMEA and O SP

8.5 Wi-Fi

The EzeFare Validator uses an internal Wi-Fi module and antenna. This supports 802.11 b/g/n and WPA2 encryption.

8.6 Ethernet

There is one 10/100 BASET port. Full details of the physical layer are found in the IEEE 802.3 Specification [4].
