User Manual

version:1.0

Body Scale

GBS-1269-B

Contains FCC ID: OU9AW8001-LS

GUANGDONG TRANSTEK MEDICAL ELECTRONICS CO., LTD

Zone A, No.105, Dongli Road, Torch Development District, Zhongshan, Guangdong, 528437, China

TEL:86-760-88282982 www.transtek.cn

Thank you very much for selecting the Transtek Body Scale GBS-1269-B.

Please do read the user manual carefully and thoroughly so as to ensure the safe usage of this product, and keep the manual well for further reference in case you have problems.

Table of Contents

Symbol Meaning

Safety Information

Your Scale and Its Environment

Efficient Use of Your Scale

Overview

General Instructions

Device Components

LCD Display

Initial Start-Up

Insert the Batteries

Install App and Pair-up

Start Measuring

Select Measurement Unit

Daily Measurement

Data Management

Data Transmission

Troubleshooting

Error Prompt

When Measuring

When Data Transmitting

Specifications

Maintenance

Warranty

FCC Regulations .......................................................................................................................... 14

......................................................................................................................................

.........................................................................................................................

.............................................................................................

.................................................................................................................

..............................................................................................................................

...................................................................................................................

............................................... ...........................................................

............................................... ............................................................

...................................................................................................................

....................................................................................................................

.............................................................................................................................

..................................................................................................................

........................................................................................................

............................................................................................................................

...............................................................................................................................

Symbol Meaning Safety Information

Symbol Meaning

The warning signs and symbols are essential to ensure your correct and safe use of this product and protect you and others from injury. Please kindly find the meanings of the warning signs and symbols, which you may encounter in the label and user manual, as follows:

Symbol for “THE OPERATION GUIDE MUST BE READ”

The Bluetooth Combination Mark

Symbol for “SERIAL NUMBER”

Symbol for “DIRECT CURRENT”

Symbol for “MANUFACTURER”

Symbol for “TYPE BF APPLIED PARTS”

Symbol for “ENVIRONMENT PROTECTION – Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice”

Your Scale and Its Environment

To ensure your safety as well as the service life of your scale, please avoid using

the scale under the following circumstances:

Slippery floor such as tile floor

Jumping onto the platform immediately after bath or with wet hands

Near a cell phone or microwave oven

Avoid storage in the following locations:

Where there is water

Where the device may be exposed to extreme temperatures, humidity, moisture, direct sunlight, dust, or salt air

Where there is risk of shock or drop

Where you store chemicals or full of corrosive gases

Where in reach of the infants or children

Efficient Use of Your Scale

To ensure the accuracy of measurement, please follow below instructions when

you start measurement.

Place the scale on a flat, hard surface. Soft surface such as carpet will affect the performance of the scale.

Start measurement at least two hours after Getting up or Dinning.

Avoid measurement immediately after strenuous exercise, sauna or bath, drinking, and dinning.

Always start measurement in the same time slot and on the same scale located on the same flat, hard surface.

2 3

Overview

General Instructions

Transtek Body Scale GBS-1269BT applies SENSE ON technology. It’s not necessary to turn on or turn off the scale, just stand on the scale for measurement. It is delicate and trendy, convenience for using.

Device Components

LCD display

UNIT and activation Button

Overview

LCD Display

List

1. Body Scale GBS-1269-B

2. Three AAA-size Batteries (1.5V each)

3. User Manual

Battery Compartment

Kilogram

Pound

Bioelectrical Impedance Analysis

Data transmitting

Data pending to transmit to wireless wellness system

Low Battery

Initial Start-Up Initial Start-Up

Insert the Batteries

Open the battery door in the back of the scale.

Insert the batteries (3 x 1.5V AAA) into the battery compartment according to the polarity indications marked inside the compartment.

* The digits “8888” will be shown on the LCD.

Close the battery door and wait until the digits “0.0kg” are shown on the LCD.

CAUTION

When the symbol appears, the device will power off in four seconds. Then you shall replace with a new set of batteries. Please replace all three batteries at the same time. Do NOT mix the old batteries with the new one. Worn batteries are hazardous waste. Do NOT dispose of them together with the household garbage. Please refer to the local ordinances and recycling instructions regarding disposal of the worn batteries.

Install App and Pair-Up

With the advanced Bluetooth 4.0 technology applied, the mobile or portable equipments, which are equipped with Bluetooth function in line with BLE Technical Specifications as well as BLP Protocol established by global organization Bluetooth SIG, are capable to receive your personal health data.

Just simply install the specially-designed app and pair up your scale with your mobile or portable equipments. Then you may enjoy the comprehensive health solution provided by Transtek. Note: It is only available for the device which supports Bluetooth 4.0 technology.

You may search and install the app in your smartphone.

Turn on Bluetooth and App. Make sure both are ON when pair-up is

proceeding.

Press and hold “UNIT” button in the back of the scale to start pair-up.

Symbol and symbol will be shown on the LCD alternatively, indicating pair-up is proceeding.

If SUCCEED, symbol will be shown on the LCD.

If FAIL, symbol “E1” will be shown on the LCD.

Select Measurement Unit

With batteries correctly installed, press “UNIT” button in the back of the scale to select measurement unit. The default measurement unit is “kg”. You may press “UNIT” button to choose between kilogram and pound.

Daily Measurement

Data ManagementStart Measuring

Data Transmission

With the scale successfully pair-up with your smartphone, the measurement data will be automatically transmitted to your mobile via Bluetooth.

With original SENSE ON patent technology, the scale

will automatically switch on as you step on the platform barefooted.

Stand still and keep full contact with the scale until the LCD displays the weight and stops blinking the unit.

When your scale is successfully paired with your smartphone and the Bluetooth is ON, it will process data transmission automatically.

(Please refer to Data Transmission for more details.)

The symbol will disappear after successful data transmission, and you may check your personal health data stored in your smartphone.

If the data transmission fails, the symbol will remain. The pending measurement data will be temporarily kept in the scale and transmitted to your smartphone when next measurement is complete.

Note: Whether the data transmission is successful , the device will shut down automatically 5 seconds later.

Data transmitting

Data ready to transmit to the App:

-If SUCCEED, the symbol disappears;

-If FAIL, the symbol remains.

Troubleshooting

Error Prompt

Error Description Solution

Overload.

Low Battery. The device will power off in four seconds.

Failure of pairing up your scale with your smartphone.

Or failure of activation.

There has data doesn’t upload. (The notebook icon will be displayed.)

Stop using this scale for

measurement.

Replace all three batteries at the same time. Please purchase the authorized batteries for replacement.

Please check below items:

-Bluetooth is ON.

-App is ON.

-Both devices are within the

transmission distance of Bluetooth.

Upload the data.

When Measuring ...

Problem Root Cause Solution

Install the batteries. (Please refer to Insert the

Batteries)

Replace all three batteries at the same time. Please purchase the authorized batteries for replacement.

No display on LCD when the device powers on.

The device

powers off automatically.

Batteries not yet installed.

Worn batteries.

Low battery.

When Data Transmitting ...

Problem Root Cause Solution

Turn ON the Bluetooth via the

settings.

Press the icon to turn ON your

app.

Data transmission

failed.

Bluetooth is OFF.

App is OFF.

Out of range of Bluetooth

transmission.

Place your smartphone closer to

the scale.

Specifications

Maintenance

Specifications

Product Name

Dimension

Net Weight

Display

Measurement Unit

Measurement Range

Division

Accuracy 2.5-100kg: ±0.2kg;

Working Environment

Storage Environment

Power Source

Auto-ON

Auto-OFF About 15 seconds after the weight data is locked

Accessories

Body Scale (GBS-1269-B)

Scale: 280x245x23mm (Approximately)

Approximately 1.46kg ( Excluding the dry cells)

Blue LCD with White Backlight V.A.: 81x41.6mm

Kilogram / Pound

2.5kg to 150kg / 5.6lb to 330lb

0.1kg / 0.2lb

100-150kg: ±0.3kg;

Temperature: 5 to 40

Temperature: -20 to 60

4.5V (Three AAA-size Batteries)

SENSE ON technology

1. Three AAA-size Batteries

2. User Manual

℃ ℃

Humidity: ≤93% RH

Maintenance

When carrying out usual maintenance, please ensure practice of the following Do’s and

Don’ts:

DO use a dry soft cloth to wipe the dust.

DO use a wet soft cloth, dipped into water and wrung out, to wipe the dirt. Then use a dry soft cloth to dry up the device.

DON’T wash the device with water or immerse it in water.

DON’T use propellant, abrasive or other chemicals to wipe the dirt in avoidance of discolor or malfunction.

DON’T disassemble this device. If you have any problems, please contact Transtek. (Please refer to Warranty for contact information)

Warranty

Transtek warrants its products free of defects in materials and workmanship in normal use for a period of FIVE years from the date of retail purchase. This warranty does NOT cover damages caused by misuse or abuse, including but not limited to:

Failure caused by unauthorized repairs or modifications; Damage caused by shock or drop during transportation; Failure caused by improper operation inconsistent with the instructions stated in this user manual; Malfunction or damage from failure to provide the recommended maintenance; Damage caused by improper use of power supply.

Should this device require maintenance (or replacement at our option) under warranty, please deliver the original package to GUANGDONG TRANSTEK MEDICAL ELECTRONICS CO., LTD prepaid. Please return the store receipt (with the retail purchase date) and a note with reasons to return on it as well.

Mode of Operation

About the Accuracy of This Product

This product passes strict inspection before delivery and therefore its accuracy is guaranteed by the manufacturer.

Please refer to the above table for the descriptions on accuracy.

WARNING: No modification of this equipment is allowed.

Continuous Operation

GUANGDONG TRANSTEK MEDICAL ELECTRONICS CO., LTD

Zone A, No.105, Dongli Road, Torch Development District, Zhongshan, Guangdong, 528437, China

Tel: 86-760-88282982 Website: http://www.transtek.cn

FCC Regulations

FCC User Guide Information

Radio Frequency Interface Requirements - FCC

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna; Increase the separation between the equipment and receiver; Connect the equipment into an outlet on a circuit different from that to which the receiver is connected; Consult the dealer or an experienced radio / TV technician for help.

Radio Transmitters (Part 15)

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

FCC RF Exposure Guidelines

Safety Information

Reducing RF Exposure - Use Properly

Only operate the device in accordance with the instructions supplied. This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possiblity of exceeding the FCC radio frequency exposure limits.
