power on / off
blue: normal
red: abnormal
DC jack
charging indicator
(red: charging
green: charging finished)
lateral
inlet for the safety rope
bottom
anti-droping sensor
power switch
USB socket
blue: good status
red: abnormal
Device
Cable
Put th e clean mop the the pad flatly
5-6
clean water on the m op . Pl ea se
don’t make the mop a ll w et , an d do n ot s pr ay o n the upper part of the robot.
red
green
Cleaning path by pressing X1 button of remote
1. Put the product at the center of glass where is far away from the window
fram e, press the start button, the product will automatically move downward
and upward to detect the friction, then move to the left frame of glass and
consequently move upward to the top left corner.
2. Afte r reaching the top left corner, it will start to clean the glass by moving
the N- shaped curve from top to bottom.
3. The robot will stop nearby the starting place wh en finish cle aning work.
Cleaning path by pressing X2 button of remote
1. Put t he product at the center of glass where is far away from the window
fram e, press the start button, the product will automatically move downward
and upward to detect the friction, then move to the left frame of glass and
consequently move upward to the top left corner.
2. Afte r reaching the top left corner, it will start to clean the glass by moving
the N- shaped curve from top to bottom.
3. The robot arrived at the top right corner when finished N-sha pe cleaning ,
then move in Z-shape curve from top to bottom.
4. The robot will stop nearby the starting place wh en finish cle aning work.
Speaker / Alarm Indicator(on the handle and the bottom) Meaning Remark
alarm every 0.2s red lamp is always on no input from adaptor
stop alarming when adaptor is
connecting to electricty
always alarm red lamp is always on air leakage
stop alarming when no air
leakage
alarm 1 time when blue lamp binks blue lamp flashes 1 time and red lamp flashes 1 time gyroscope sensor error repeat alarming
alarm 1 time when blue lamp binks blue lamp flashes 1 time and red lamp flashes 2 times barometer error repeat alarming
alarm 1 time when blue lamp binks blue lamp flashes 1 time and red lamp flashes 3 times 2.4 G remote error repeat alarming
alarm 1 time when blue lamp binks blue lamp flashes 1 time and red lamp flashes 4 times no safety rope
alarm 1 time when blue lamp binks blue lamp flashes 1 time and red lamp flashes 5 times
robot cannot move due to
too much friction
normally don't repeat this
alarm every 0.2s and repeat 3 times red lamp flashes every 0.2s and repeat 3 times
fan calibration failure (too
slippery)
glass is too slippery
alarm 1 second and stop alarming /
arrives at the frame when
use remote control it
glass is too slippery
alarm every 1s and repeat 3 times / finished cleaning work
finshed N-shape or Z-shape
cleaning path
alarm 0.1s /
press the button of robot
and remote
valid press
Blue lamp: normal
Red lamp: abnormal
Model no. WA6
Battery lasting time
Size
Suitable for cleaning area
1.46kg
90W
20mins
248 x 248 x 95 mm
60 x 40 cm
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.?
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1)This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
