Page 1
33” x 22” Charlotte
kitchen sinks
FEATURES
• 33” x 22” x 8
• Top mount self-rimming kitchen sink.
• Solid surface material is non-porous. Scratches and stains like
coffee, juice, berries and burns are easily removed with
abrasivecleaners,restoringandrenewingoriginalnish.
• Transolid sinks are durable, withstand impact and heat resistant
up to 375°.
• 10 Year Limited Residential Warranty
3 Year Commercial Warranty
COLORS
• 3 Solid Colors
• 3 Matrix Colors
Specied Model
1
⁄4” Gourmet equal double bowls.
KDT3322C
Model KDT3322C
Overall
Dimensions
Bowl
Dimensions
Faucet Holes up to 7 - must specify number
Shipping Weight 28 lbs.
Material Solid Surface
Installation countertop mounted
Required 2 basket strainers
To Be Specied:
COLOR (Solid)
r
00 White
r 05 Almond
r 08 Biscuit
COLOR (Matrix)
r
60 Matrix Sand
r 67 Matrix Khaki
r
68 Matrix Summit
L33” x W22” x D81⁄4”
L1315⁄16” x W157⁄8” x D71⁄4”
of holes and hole location(s)
not supplied
To Be Specied:
Faucet Hole Drillings
r
0 Holes
r 1 Hole
r 2 Holes
r
3 Holes
r 4 Holes
r
5 Holes
r
6 Holes
r
7 Holes
A B C D E F G
IMPORTANT: Circle Letter(s) above to indicate location(s) for
faucet hole drillings (there is a 4” spread between
hole locations).
Transolid P.O. Box 30, Warren, OH 44482-0030 www.transolid.com 1-800-766-2452
11/01/2013
