Transolid SBSW9830 Specifications

FEATURES

Wattage

40

Connector

 Compatible with standard "legacy" dimmer switches

 Preserves long life of LEDs

ML

Lifespan

50,000 hours

Certication

UL

SA40651

24V 40W Dimmable Driver with 12 Port ML Block - Use this driver with GREEN color coded products. This is a unique LED Driver that allows the user to dim their LED

cabinet lighting at the same time as their overhead lighting using existing "legacy" dimmer switches. These drivers are compatible with standard Triac or ELV dimmer switches available in most DIY stores. One other great feature of the driver is because it dims on the high voltage side of the current, it preserves the long life of the LEDs it dims. Multiple drivers may be tied into the same dimmer switch allowing the whole kitchen to be dimmed o of one switch.

SPECIFICATIONS

Product Code Voltage Max Load Min Load IP Rating Input Voltage Input Freq. Length Width Depth

SA40651

 24V

40W 0W IP20 AC120V 60Hz 7” (178mm) 1.75” (45mm) 1.125” (29mm)
