Transcom TS-1000-11-SFP User Manual

Gigabit Ethernet Converter 1 Tx port &1 SFP slot

Copyright Statement

This publication may not be reproduced as a whole or in part, in any way whatsoever unless prior consent has been
obtained .

FCC Warning

This series converters have been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These standards are designed to provide reasonable protection against harmful interference
when these devices are operated in a commercial environment. These devices generate, use, and can radiate radio
frequency energy and may cause harmful interference to radio communications unless installed in accordance with this
User’s Guide. Operation of these devices in a residential area is likely to cause harmful interference which will make
the user responsible for the appropriate remedial action at his / her own expense.

CE Mark Warning

These are Class A products. In a domestic environment these products may cause radio interference in which case the
user will need to consider adequate preventative methods.

1. Packing list

The box should contain the following items:

- Gigabit ethernet converter 1 Tx port & 1 SFP slot

- AC-DC Power Adapter (for external power units)

- User’s guide

- Warranty Card

Please notify your sales representative immediately if any items are missing or damaged.

2. Overview

This series converters are designed to meet the massive needs for Gigabit network deployment and able to extend a

SHENZHEN TRANSCOM TEHCNOLOGY LIMITED / 303, Building 4, Fantasia MIC Plaza,Nanshan District,Shenzhen,China.

Tel: [phone] / Fax: [phone] / Web: www.sz-transcom.com

1000Base-T to 1000BASE-SX/LX Converter

Standard : IEEE 802.3z & 802.3ab

Interface: 1 x RJ-45 connector
1 x SFP Slot

MDI/MDIX Auto-Crossover supported

LED: Power , DUP,FP-LINK,RX,1000,TX

Plug-and-Play installation

Support Link Alarm

Support Jumbo Frame (64-9216 Byte)

Support Voltage Monitor

copper based Gigabit network via fiber cable to a maximum distance up to 80KM.
This series converters are fully compliant with IEEE802.3z & 802.3ab standards. It can be installed into a Standard
Converter Chassis. The installation & operation procedures are simple & straightforward. Operation status can be locally
monitored through a set of Diagnostic LED located in the front panel.
Features

3. Installation

• Attach fiber cable from the converter to the fiber network. The fiber connections must be matched – transmit
socket to receive socket.

• Attach a UTP cable from the 1000BASE-T network to the RJ-45 port on the converter.

• Connect the power adapter to the converter and check that the Power LED lights up. The TP-Link and RX LEDs will

light up when all the cable connections are satisfactory.
