T
T
T
S
S
S
0
0
0
M
M
M
F
F
F
L
L
L
R
R
R
D
D
D
6
6
6
A
A
A
USB2.0 6-in-1 Card Reader
Description
TS0MFLRD6A is a USB2.0 6-in-1 Card Reader with 4
slots, which are for CompactFlash Card / IBM
Microdrive, SmartMedia Card, MultiMediaCard / Secure
Digital Card and Memory Stick / Memory Stick PRO
respectively.
Placement
A
B
System Requirements
Desktop or notebook computer with USB port
•
One of following operating systems:
•
®
Win
98SE, Win® Me, Win® 2000, Win® XP, Mac™ OS,
and Linux.
Features
100% Compatible with USB Interface in Windows and
•
Mac
• Single Power Supply: 3.3V / 5V ± 10%
• Durability of Connector: 10,000 times
• Recommended Operating Temperature : 0 – 70 ℃
Compliant with USB specification version 2.0
•
• High-speed with transfer rate up to 480Mbit/sec
• Support CompactFlash™ Card, IBM Microdrive,
SmartMedia Card, MultiMediaCard, Secure Digital
®
Card, and Memory Stick
/ Memory Stick PRO
Transcend Information, Inc.
• No external power needed
• Supports Resume Suspend and Low Power modes
LEDs indicate card insertion and data traffic
•
Dimensions
C
Side Millimeters Inches
1
A 125.00 ± 1.00 4.92± 0.04
B 84.00 ± 1.00 3.31 ± 0.04
C 21.00
1.00 0.83 ± 0.04
±
T
S
0
M
F
T
S
0
S
0
M
M
T
Block Diagram
F
F
L
L
L
R
R
R
D
D
D
6
6
6
A
A
A
USB2.0 6-in-1 Card Reader
Pinouts
SM
Connector
Connector
USB
D+ / D-
FC1320 Controller
CF/Microdrive
Connector
Crystal
12MHz
MS/MS PRO
Connector
Pin Identification
MMC/SD
Connector
Pin No. Pin Name
01 VCC
02 USB-
03 USB+
04 VSS
Transcend Information, Inc.
Symbol Function
USB-
USB+
VSS Ground
VCC USB Power Input
2
USB differential signal:
The pairs are used to transmit
Data/Address/Command
T
S
0
M
F
L
R
D
6
T
S
0
M
F
L
T
S
0
M
Absolute Maximum Ratings
F
L
R
R
D
D
6
6
A
A
A
USB2.0 6-in-1 Card Reader
Recommended Operating Conditions
DC Characteristics
Transcend Information, Inc.
3
T
S
0
M
F
L
R
T
S
0
M
F
T
S
0
M
DC Electrical Characteristics
F
L
L
R
R
D
D
D
6
6
6
A
A
A
USB2.0 6-in-1 Card Reader
AC Characteristics
Above technical information is based on industry standard data and tested to be reliable. However, Transcend makes no
warranty, either expressed or implied, as to its accuracy and assumes no liability in connection with the use of this
product. Transcend reserves the right to make changes in specifications at any time without prior notice.
Transcend Information, Inc.
4
