Portable Multi-Card Reader
User Manual
16 pgs436.66 Kb0

Transcend Portable Multi-Card Reader, Multi-Card Reader M1, Compact Card Reader, Compact Card Reader S1 User Manual

Transcend Multi-Card Reader
User’s Manual
Table of Contents
Introduction ............................................................................................ 1
Safety....................................................................................................... 2
Safety Precautions.................................................................................................................2
Use with a Computer.............................................................................. 3
Driver Installation...................................................................................................................3
Driver Installation for Windows® 98/98SE, 2000 (SP1 and SP2).......................................................3
Driver Installation for Windows® Me, 2000 (SP3, or later) and XP ....................................................4
Driver Installation for Mac™ OS 9.x....................................................................................................5
Driver Installation for Mac™ OS 10.1.2, or Later ................................................................................5
Connecting to a Computer ....................................................................................................6
Disconnecting from a Computer...........................................................................................7
Removing the Multi-Card Reader in Windows® 98/98SE ..................................................................7
Removing the Multi-Card Reader in Windows® Me, 2000 and XP ....................................................7
Removing the Multi-Card Reader in Mac™ OS 9.x, or Later...............................................................7
Remove the Multi-Card Reader in Linux™ Kernel 2.4, or Later ..........................................................7
Troubleshooting..................................................................................... 8
Specifications......................................................................................... 9
Multi-Card Reader M1 Specifications ...................................................................................9
Portable Multi-Card Reader Specifications........................................................................ 10
Compact Card Reader Specifications.................................................................................11
Compact Card Reader S1 Specifications...........................................................................12
Warranty................................................................................................ 13
Terminology.......................................................................................... 14
Introduction
Introduction Introduction
Thank you for purchasing Transcend’s Multi-Card Reader, a small device specifically designed for fast, easy data transfer and exchange using many different types of Memory Cards and without the need for an adapter. Transcend’s Multi-Card Reader plugs into the USB port on your Desktop, or Notebook computer and accepts the direct input of the most popular Memory Cards (see “
Specifications” for details) . In
addition, Transcend’s Multi-Card Reader also accepts the input of a large number of reduced sized memory cards when they are combined with their adapter. Transcend’s Multi-Card Reader uses a Hi-Speed USB 2.0 connection for extremely fast data transfer speeds and its small compact design will enhance your Photo, Music and Data transfer experience.
Features
Fully Compliant with the Hi-Speed USB 2.0 specification Supports many different types of Memory Cards, please see “Specifications” for details Hi-Speed Data transfer rates up to 480Mbit/sec USB powered (no external power or battery needed)
System Requirements
Desktop or notebook computer with a working USB port. One of the following Operating Systems (OS):
Windows
®
98/98SE
Windows
®
Me
Windows
®
2000
Windows
®
XP
Mac
™
OS 9.x, or later
Linux
™
Kernel 2.4, or later
1
Safety Precautions
Safety
These usage and safety guidelines are IMPORTANT! Please follow them carefully.
General Use
Carefully unpack the contents of the Multi-Card Reader package. Do not allow your Multi-Card Reader to become damp or wet from water or any other liquids. Do not use a damp/wet cloth to wipe or clean the exterior case. Do not use or store your Multi-Card Reader in any of the listed environments:
o Direct sunlight o Next to an air conditioner, electric heater, or other heat sources o In a closed car that is in direct sunlight
Transferring Data
Transcend does NOT take any responsibility for data loss, or damage during operation.
Reminders
Follow the procedures in the “Disconnecting from a Computer” section to remove your Multi-Card
Reader from a computer.
T o avoid damage to your Reader and Memory Cards. Do NOT attempt to insert two Memory cards into your Multi-Card Reader at the same time.
2
Driver Installation
Use with a Computer
Driver Installation for Windows® 98/98SE, 2000 (SP1 and SP2)
1. Put the Driver CD into the CD-ROM (Auto-Run supported). Click on the “Driver Installation” button.
Figure 1. Windows 98/98SE/2000 (SP1 & SP2) Driver Installation
2. The InstallShield Wizard will guide you through the installation process. Follow the on-screen
instructions to complete the driver installation.
Figure 2. Driver Installation InstallShield Wizard
3
