TransAct Ithaca 8000 Programmer's Manual
®
Ithaca
Programmer’s Guide
8000
PN 100-06908
Rev D
November 2010
This page intentionally left blank
Revision
Description of change
Date
A
Initial Release
June 2006
B
Added periodic status back.
Sept 2007
C
Removed Paper Specifications
Nov 2008
D
Pg 27 Replaced the Cash Drawer Pin Assignment table
Nov 2010
Change History
100-06908 Rev D Page i
Federal Communications Commission Radio
Frequency Interference Statement
The Ithaca® 8000 Printer complies with the limits for a Class A computing device in
accordance with the specifications in Part 15 of FCC rules. These regulations are
designed to minimize radio frequency interference during installation; however, there is
no guarantee that radio or television interference will not occur during any particular
installation. Interference can be determined by turning the equipment off and on while
the radio or television is on. If the printer causes interference to radio or television
reception, try to correct the interference by one or more of the following measures:
1. Reorient the radio or television receiving antenna
2. Relocate the printer with respect to the receiver
3. Plug the printer and receiver into different circuits
If necessary, the user should consult their dealer or an experienced radio/television
technician for additional suggestions. The user may find the following booklet prepared
by the Federal Communications Commission helpful: How to Identify and Resolve
Radio/TV Interference Problems. This booklet is available from the US Government
Printing Office, Washington, DC 20402. Ask for stock number 004-000-00345-4.
Canadian Department of Communications Radio
Interference Statement
The Ithaca® 8000 Printer does not exceed Class A limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Regulatory Compliance
FCC Class A
ULc
CE Mark
UL 1950
TUV
Page ii Rev D 100-06908
Disclaimer
NOTICE TO ALL PERSONS RECEIVING THIS DOCUMENT:
The information in this document is subject to change without notice. No part of this
document may be reproduced, stored or transmitted in any form or by any means,
electronic or mechanical, for any purpose, without the express written permission of
TransAct Technologies, Inc. ("TransAct"). This document is the property of and contains
information that is both confidential and proprietary to TransAct. Recipient shall not
disclose any portion of this document to any third party.
TRANSACT DOES NOT ASSUME ANY LIABILITY FOR DAMAGES INCURRED,
DIRECTLY OR INDIRECTLY, FROM ANY ERRORS, OMISSIONS OR
DISCREPANCIES IN THE INFORMATION CONTAINED IN THIS DOCUMENT.
TransAct cannot guarantee that changes in software and equipment made by other
manufacturers, and referred to in this publication, do not affect the applicability of
information in this publication.
Copyright
© 2006 TransAct Technologies, Inc. All rights reserved.
Revision D
November 2010
Printed in USA
Trademarks
Some of the product names mentioned herein are used for identification purposes only
and may be trademarks and/or registered trademarks of their respective companies.
BANKjet, 50Plus, Insta-Load, Ithaca, "Made to Order. Built to Last", Magnetec, PcOS,
POSjet, PowerPocket, Ithaca and TransAct are registered trademarks and Epic 950,
Flex-Zone, imPort, IthaColor, KITCHENjet, Momentum, QDT and TicketBurst are
trademarks of TransAct Technologies, Inc.
100-06908 Rev D Page iii
Table of Contents
Change History ................................................................................................................ i
Federal Communications Commission Radio Frequency Interference Statement ........... ii
Canadian Department of Communications Radio Interference Statement ....................... ii
Regulatory Compliance ................................................................................................... ii
Disclaimer ...................................................................................................................... iii
Copyright ........................................................................................................................ iii
Trademarks .................................................................................................................... iii
Table of Contents ................................ ........................................................................... iv
Figures ........................................................................................................................... ix
Tables ............................................................................................................................ ix
Introducing your Ithaca® 8000 Printer ................... 1
About your Ithaca® 8000 Printer ...................................................................................... 3
Who Should Read This Guide? ....................................................................................... 4
What Is Included in This Guide? ...................................................................................... 4
Warranty Options ............................................................................................................ 4
Technical and Sales support ........................................................................................... 5
On-line Technical Support ....................................................................................... 5
Telephone Technical Support .................................................................................. 5
Return Materials Authorization and Return Policies ................................................. 6
Service Programs .................................................................................................... 6
Sales Support .......................................................................................................... 6
Contact Information ................................................................................................. 6
Ithaca® 8000 Specifications and Requirements ....... 9
Ithaca® 8000 Specifications and Requirements ............................................................. 11
Ithaca® 8000 Thermal Printer Models ........................................................................... 11
Standard Features ........................................................................................................ 11
Optional Features .......................................................................................................... 13
General Specifications .................................................................................................. 14
Printing Specifications ........................................................................................... 14
Character Pitch ...................................................................................................... 14
Character Generation ............................................................................................ 15
Physical Characteristics ................................................................................................ 18
Dimensions ............................................................................................................ 18
Weight ................................................................................................................... 18
Electrical Characteristics ............................................................................................... 19
Internal AC Powered ............................................................................................. 19
External Powered DC ............................................................................................ 19
Thermal Print Head ....................................................................................................... 19
Linerless Label Receipt Paper ............................................................................... 20
Buzzer ........................................................................................................................... 22
Cover Interlock .............................................................................................................. 22
Display Pass Through ................................................................................................... 22
Communications Interface ............................................................................................. 23
Parallel Interface.................................................................................................... 23
RS-232 Serial Interface ......................................................................................... 24
Page iv Rev D 100-06908
USB Interface ........................................................................................................ 24
Ethernet 10-Base-T adapter .................................................................................. 25
802.11b Wireless Interface .................................................................................... 25
Cash Drawer ......................................................................................................... 26
Interface Description .............................................................................................. 26
Cash Drawer Pin Assignments .............................................................................. 26
Setup Procedures ..............................................28
Verifying the Configuration ............................................................................................ 30
Verify the Communications Interface Card............................................................. 30
Changing Interface Cards ...................................................................................... 30
Removing the Old Interface Card .......................................................................... 30
Cash Drawer Configuration ................................................................................... 31
Configuring the Cash Drawer Interface .................................................................. 31
Installing Cables ............................................................................................................ 32
Connecting power .................................................................................................. 32
Connecting Communications Cables ..................................................................... 33
Verify the Firmware Configuration ......................................................................... 34
Installing Paper ............................................................................................................. 34
Installing Windows® Printer Drivers ................................................................................ 35
Printer Driver Installation for WIN95, 98, Me .......................................................... 35
Printer Driver Installation for NT4.0, 2000 .............................................................. 35
OPOS drivers Installation Instructions ................................................................... 36
To Install the USB drivers ...................................................................................... 36
How to Operate the Ithaca® 8000 Printer..............37
How to Operate the Ithaca® 8000 Printer ....................................................................... 39
* Button ......................................................................................................................... 39
FEED Button ................................................................................................................. 39
Indicator Lights (LED) .................................................................................................... 40
Power Indicator (LED) ........................................................................................... 40
Error Indicator (LED) ............................................................................................. 40
Paper Indicator (LED) ............................................................................................ 40
Fault Indicators .............................................................................................................. 40
Testing the Printer Overview ......................................................................................... 42
Using Self-Test, Configuration, and Hex Dump Mode ............................................ 42
Hex-dump Mode .................................................................................................... 44
Level 0 Diagnostics ............................................................................................... 45
Boot Loader Mode ................................................................................................. 45
Configuring Your Ithaca® 8000 Printer ..................47
Configuration Mode Overview ....................................................................................... 49
Most Frequent Configuration Incompatibilities ....................................................... 49
How to Change Configuration Settings .......................................................................... 49
Entering into Configuration Mode .......................................................................... 49
Using Configuration Mode ............................................................................................. 50
Remote Configuration ................................................................................................... 53
Setting up for Color Paper ............................................................................................. 53
Custom Color ........................................................................................................ 53
Programming Codes ...........................................55
Control Codes Overview ............................................................................................... 57
Nomenclature ................................................................................................................ 57
100-06908 Rev D Page v
Standard Emulation ............................................................................................... 58
IPCL Codes ........................................................................................................... 58
EPOS Emulation.................................................................................................... 58
Axiohm .................................................................................................................. 58
Ithaca® Microline Emulation ................................................................................... 58
Application Development ............................................................................................... 58
Ithaca Control Codes and Commands ........................................................................... 59
PcOS Printer Control Codes .................................................................................. 59
Quick PcOS Reference Chart ................................................................................ 60
Quick PcOS Reference Chart (Alphabetic) ............................................................ 67
Low Level Paper Motion Control ............................................................................ 73
Horizontal Motion Control ...................................................................................... 74
Vertical Motion Control .......................................................................................... 76
Feed to Black Dot .................................................................................................. 82
Character Pitch ...................................................................................................... 84
Character Font ...................................................................................................... 87
Print Rotation Commands .................................................................................... 104
Rotated Print Summary ....................................................................................... 107
Ithaca® 8000 Page Mode ..................................................................................... 110
Graphic Mode ...................................................................................................... 114
Graphics Compression ........................................................................................ 120
User Store (Graphic Save) .................................................................................. 120
User Macros ........................................................................................................ 128
Bar Codes ........................................................................................................... 130
Electronic Journal ................................................................................................ 141
Unicode and Downloaded Fonts .......................................................................... 153
Unicode Encoding ............................................................................................... 153
Miscellaneous Control ......................................................................................... 158
Remote Power Control ........................................................................................ 166
Documented Extended Control commands .......................................................... 167
Printer Status ....................................................................................................... 168
Inquire Commands .............................................................................................. 169
ESC/POSTM Codes ...................................................................................................... 178
Differences between Epson TM T90 and Ithaca® 8000 ........................................ 178
Supported TM-T88 Commands ................................................................................... 180
Undocumented TM-T88 Commands ........................................................................... 183
Supported TM-T90 Commands ................................................................................... 184
TM-T88 / TM-T90 and ESC/POSTM Command Descriptions ........................................ 188
Print and Feed Commands.......................................................................................... 188
Line Spacing Commands ............................................................................................ 190
Character Commands ................................................................................................. 190
Panel Button Commands ............................................................................................ 199
Paper Sensor Commands ........................................................................................... 200
Print Position Commands ............................................................................................ 202
Bit-Image Commands .................................................................................................. 206
Status Commands ....................................................................................................... 207
Printing Paper Command ............................................................................................ 213
Page Mode .................................................................................................................. 214
Bar Code Commands .................................................................................................. 217
Mechanism Control Commands .................................................................................. 220
Miscellaneous Commands .......................................................................................... 222
Page vi Rev D 100-06908
Macro Function Commands ........................................................................................ 228
User-defined Images and Graphics Commands .......................................................... 229
Ithaca® Specific Ithaca® 8000 Commands ................................................................... 234
Panel Button Commands ..................................................................................... 234
Paper Out/Low Sensor Commands ..................................................................... 234
Ithaca® Citizen Emulation ............................................................................................ 236
Ithaca® Star Emulation ................................................................................................ 236
Ithaca® Axiohm Emulation ........................................................................................... 236
Ithaca® 8000 Color Graphics ............................. 237
Printing Graphics ......................................................................................................... 239
Character Graphics ............................................................................................. 239
APA Graphics ...................................................................................................... 242
Ithaca® 8000 Universal Color Graphics ....................................................................... 245
Print File Graphics ............................................................................................... 246
Store Graphics in the printer: ............................................................................... 247
How universal graphics is done ........................................................................... 248
How to use IPCL commands in text strings .......................................................... 248
Cautions .............................................................................................................. 249
Universal Color Command Descriptions .............................................................. 250
Ithaca® 8000 Coupon-Cut-Logo Feature ..................................................................... 252
Unicode .......................................................... 253
Unicode – A Software Font Solution ............................................................................ 255
About Unicode ............................................................................................................. 256
Memory ............................................................................................................... 256
TransAct‘s implementation of Unicode in the Ithaca
®
8000. ......................................... 256
Ithaca® 8000 Extended Printer Control ............... 259
Communications .............................................. 267
Protocol and Print Buffers ........................................................................................... 269
USB ............................................................................................................................ 272
USB Support ....................................................................................................... 272
TCP/IP ........................................................................................................................ 273
Print Server Features Standard Ethernet Connection .......................................... 273
Supported Protocols ............................................................................................ 273
User Interface/Configuration ................................ ................................................ 273
Other ................................................................................................................... 273
Parallel Port ................................................................................................................ 274
Parallel Port Protocol ........................................................................................... 274
Printer Buffer Size ............................................................................................... 275
Parallel Port Inquire and IEEE 1284 .................................................................... 275
Parallel Port Plug and Play .................................................................................. 277
Serial Port ................................ ................................................................................... 279
Serial Port Protocol .............................................................................................. 279
Print Buffer Flow .................................................................................................. 281
Printer Buffer Size ............................................................................................... 283
Serial Mode Plug and Play .................................................................................. 283
Using DSR ........................................................................................................... 283
Serial Device Identification .................................................................................. 284
Serial Port Inquire ................................................................................................ 285
Display Pass Through ................................................................................................. 286
100-06908 Rev D Page vii
Remote Power Control ................................................................................................ 286
Remote Printer Reset .................................................................................................. 287
Reset in Serial Mode ........................................................................................... 287
Reset in Parallel Mode......................................................................................... 287
Miscellaneous Communication Features ..................................................................... 288
Power-cycle Recovery ......................................................................................... 288
Data Pass-through ............................................................................................... 288
Multi-drop Configuration ...................................................................................... 288
Off-line Active ...................................................................................................... 289
Recovery from Mechanical Errors ............................................................................... 290
Programmer‘s Notes ................................................................................................... 291
Applications and Linerless paper ......................................................................... 291
Appendix A: Code Page Definition Table ..................................................................... 293
Appendix B - ASCII Code Table .................................................................................. 295
Appendix C: Ordering Supplies ................................................................................... 297
Index ............................................................. 299
Page viii Rev D 100-06908
Figures
Figure 1 Receipt Printing, Tear off Position ................................................................... 21
Figure 2 Cash Drawer Pin Definitions ............................................................................ 26
Figure 3 Cash Drawer Selection .................................................................................... 31
Figure 4 3-pin mini DIN plug .......................................................................................... 33
Figure 5 Page Mode entry Orientations ....................................................................... 110
Figure 6 Code 39 full 128 character encoding ............................................................. 132
Figure 7 Expanded Function coding ............................................................................ 134
Figure 8 Code 128 encoding values ............................................................................ 136
Figure 9 Example of Character Graphics ..................................................................... 239
Figure 10 Example Commands for a Sample Receipt ................................................. 240
Figure 11 Sample Receipt ........................................................................................... 241
Figure 12 Receipt with graphics .................................................................................. 245
Figure 13 Typical POS System ................................................................................... 269
Figure 14 Host to Printer Link ...................................................................................... 270
Figure 15 Printer Communications Buffer Flow ........................................................... 271
Figure 16 Parallel-port Data Timing ............................................................................. 274
Figure 17 Parallel Port ACK Timing Options ................................................................ 275
Figure 18 Serial Port Flow Control Using DTR ............................................................ 279
Figure 19 XON/XOFF Serial Port Flow Control ............................................................ 280
Tables
Table 1 Possible Character Pitches ............................................................................... 14
Table 2 Requested CPI and Resulting CPI .................................................................... 15
Table 3 Cell Size for Small, Medium and Large Fonts ................................................... 15
Table 4 Standard Power Input Requirements ................................................................ 19
Table 5 Power Input Requirements with the 24-volt DC Power ..................................... 19
Table 6 Parallel Interface Pin-outs ................................................................................. 23
Table 7 Serial Interface Pin-outs ................................................................................... 24
Table 8 Cash Drawer Pin Assignment ........................................................................... 27
Table 9 Serial interface pin out ...................................................................................... 33
Table 10 Parallel interface pin out ................................................................................. 33
Table 11 Error Blink Codes ........................................................................................... 41
Table 12 Character Pitch ............................................................................................... 85
Table 13 Inter-character Spacing ................................ .................................................. 86
Table 14 Language Table ID‘s ...................................................................................... 90
Table 15 Code Page Definition Table ............................................................................ 91
Table 16 Euro Character Substitution Matrix ................................................................. 92
Table 17 OCR MA-3 ...................................................................................................... 97
Table 18 Paper Sensor Commands ............................................................................ 162
Table 19 Paper Sensor Commands ............................................................................ 163
Table 20 Supported TM-T90 Commands .................................................................... 182
Table 21 Undocumented TM-T90 Commands ............................................................. 183
Table 22 Supported EPOS Commands ....................................................................... 184
Table 23 Select Character Font Table ......................................................................... 191
Table 24 International Character Sets ......................................................................... 192
100-06908 Rev D Page ix
Table 25 Character Code Pages ................................................................................. 194
Table 26 Character Code Table .................................................................................. 195
Table 27 Print Modes .................................................................................................. 196
Table 28 Rotation Modes ............................................................................................ 197
Table 29 Paper Sensor Commands ............................................................................ 200
Table 30 Paper Sensor Commands ............................................................................ 201
Table 31 Print Density Selection.................................................................................. 206
Table 32 Automatic Status Back (ASB) Values for <n> ............................................... 207
Table 33 Automatic Status Back (ASB) First Byte (Printer Information) ....................... 208
Table 34 Automatic Status Back (ASB) Second Byte (Error Information) .................... 208
Table 35 Automatic Status Back (ASB) Third Byte (Paper Sensor Information) ........... 209
Table 36 Automatic Status Back (ASB) Fourth Byte (Paper Sensor Information) ........ 209
Table 37 Paper Sensor Status (<n> = 1, 49) ............................................................... 209
Table 38 Drawer Kick-out Connector Status (<n> = 2, 50) .......................................... 210
Table 39 Values for the Status Function, <n> .............................................................. 210
Table 40 Printer Status (<n> = 1) ................................................................................ 210
Table 41 Off line Status (<n> = 2) ............................................................................... 211
Table 42 Error Status (<n> = 3) ................................................................................... 211
Table 43 Paper Roll Sensor Status (<n> = 4) .............................................................. 211
Table 44 Peripheral Status (<n> = 0, 48) ..................................................................... 212
Table 45 Paper Status ................................................................................................. 212
Table 46 Bar Code System Based on <m> ................................................................. 218
Table 47 Printing Position of HRI Characters .............................................................. 219
Table 48 Font for Human Readable Interpretation (HRI) Characters ........................... 219
Table 49 Horizontal size of the bar code ..................................................................... 219
Table 50 Printer ID ...................................................................................................... 222
Table 51 Type ID (<n> = 2 or 50) ................................................................................ 222
Table 52 Peripheral Device Bit Definitions ................................................................... 224
Table 53 Macro Control Bit Definitions ........................................................................ 228
Table 54 User-defined Bit-image Resolutions.............................................................. 233
Table 55 Parallel-port Timing ...................................................................................... 275
Page x Rev D 100-06908
100-06908 Rev D Page xi
chapter 1
Introducing your Ithaca® 8000 Printer
100-06908 Rev D Page 1
This page intentionally left blank
Page 2 Rev D 100-06908
About Your Ithaca® 8000 Printer Ithaca® 8000 Programmer’s Guide
About your Ithaca® 8000 Printer
The Ithaca Ithaca® 8000 printer represents the very latest technology for use for thermal
receipt printing for point-of-sale and retail environments. It builds upon the architecture of
Ithaca‘s proven thermal printers, together with a host of features specifically designed to
improve the performance of your receipt-printing applications, including:
Crisp, clear receipt printing in either one or two colors
Fast 6 inches per second print speed
Compatible with linerless label Receipt paper.
Rugged spill-resistant cover
Large 4-inch paper roll capacity with drop-in loading
Protected internal power supply
Ethernet and USB interfaces
Application-controllable buzzer
Configurable cash drawer functionality
The Ithaca® 8000 also offers a wide range of programmable features, including color and
font control, APA graphics support, bar codes, and support for over 60 language
character sets. These features let you quickly and easily integrate more layout and
printing options than ever – while giving you the reliability, durability and uptime you
have come to expect from Ithaca printers.
100-06908 Rev D Page 3
About Your Ithaca® 8000 Printer Ithaca® 8000 Programmer’s Guide
Who Should Read This Guide?
This document provides information and programming specifications for operators who
will integrate the Ithaca® 8000 printer into their kitchen operations.
What Is Included in This Guide?
This Programmer‘s Guide includes information on the features and programming
interface of the Ithaca® 8000 printer. It provides the following information to support your
programming and implementation efforts:
Warranty and technical support information.
Specifications and functionality description.
Programming information, including documentation of low-level and high-level
command interfaces, as well as sample scripts to guide your own implementation
efforts.
We want you to have a trouble-free implementation with your Ithaca printer. For any
issues not covered in this guide, quality technical support is available on-line at
www.transact-tech.com, or by telephone at (607) 257-8901 or (877) 7ithaca. Consult
the following pages for more details about our support services.
Warranty Options
All Ithaca® 8000 printers come with a standard 24-month standard warranty covering
both parts and labor that starts upon shipment from the factory. An optional extended
warranty, covering both parts and labor for an additional 12 months, may be purchased
separately. For more information concerning the warranty options, please contact the
Sales Department at TransAct‘s Ithaca facility. You are responsible for insuring any
product returned for service, and you assume the risk of loss during shipment to Ithaca.
C.O.D. packages are not accepted and warranty repairs are subject to the terms and
conditions as stated on the Ithaca warranty policy.
Page 4 Rev D 100-06908
About Your Ithaca® 8000 Printer Ithaca® 8000 Programmer’s Guide
Technical and Sales support
Your Ithaca printer is backed by the resources of TransAct Technologies, a global
technology firm with dedicated technical support and sales assistance. Here is how we
can help you:
On-line Technical Support
Our web site at www.transact-tech.com is your on-line portal to obtaining technical
assistance with your Ithaca printer. Click on Ithaca link and then the Technical Support
link to find documentation for your Ithaca® 8000 printer, including a current copy of this
Programmer‘s Guide featuring:
o Command codes and descriptions.
o Character fonts.
o Printer features.
o Communication specifics.
Other utilities available include a font utility, a color converter and a terminal application
for communicating with your printer, as well as the following drivers and utilities:
Windows 95/98/Me Print Driver with Documentation Part No. 100-9167
Windows NT 4.0 2K and XP Print Driver with Documentation Part No. 100-9170
OPOS Drivers with Documentation Part No. 100-9732
Master Character Set Definitions Part No. 100-9785
Our on-line support site also includes a convenient e-mail assistance request form,
where you can submit support requests 24 hours a day, and receive a return contact
from a TransAct support technician during regular business hours.
Telephone Technical Support
Live telephone support is available Monday through Friday from 8 AM to 5 PM Eastern
US time, excluding holidays. We can provide general information about programming for
your Ithaca® 8000 printer, technical support, documentation, or assistance in sending a
printer for service. To obtain telephone support, call TransAct's Ithaca Facility at (607)
257-8901 and ask for Technical Support. To help us serve you faster, please have the
following information ready when you call:
The Model Number and Serial Number of the printer.
A list of any other peripheral devices attached to the same port as the printer.
What application software, operating system, and network (if any) you are using.
What happened and what you were doing when the problem occurred.
How you tried to solve the problem.
100-06908 Rev D Page 5
About Your Ithaca® 8000 Printer Ithaca® 8000 Programmer’s Guide
Return Materials Authorization and Return Policies
If the technical support person determines that the printer should be serviced at our
facility, and you want to return the printer for repair, we will issue you the Returned
Materials Authorization (RMA) number that is required before returning the printer.
Repairs are warranted for 90 days from the date of repair or for the balance of the
original warranty period, whichever is greater. Please prepare the printer being returned
for repair as follows:
Pack the printer to be returned in the original packing material.
Packing material may be purchased from TransAct's Ithaca Facility.
Do not return any accessories unless asked to do so by a support technician.
Write the RMA number clearly on the outside of the box.
Service Programs
TransAct Technologies Incorporated has a full service organization to meet your printer
service and repair requirements. If your printer needs service, please contact your
service provider first. If any problems still persist, you can directly contact the Ithaca
facility‘s Technical Support Department at (607) 257-8901 or (877) 7ithaca for a return
authorization. International customers should contact your distributor for services.
TransAct offers the following service programs to meet your needs.
Extended Warranty.
Depot Repair.
Maintenance Contract.
Internet Support.
Sales Support
To order supplies, receive information about other Ithaca products, or obtain information
about your warranty, contact our Sales Department at the contact telephone or fax
numbers listed below. To receive information on International distribution, visit our web
site at www.transact-tech.com.
Contact Information
TransAct Technologies Incorporated
Ithaca Facility
20 Bomax Drive
Ithaca, NY 14850 USA
Telephone (877) 7ithaca or (607) 257-8901
Main fax (607) 257-8922
Page 6 Rev D 100-06908
About Your Ithaca® 8000 Printer Ithaca® 8000 Programmer’s Guide
Sales fax (607) 257-3868
Technical Support fax (607) 257-3911
Web site www.transact-tech.com
100-06908 Rev D Page 7
chapter 2
Ithaca® 8000 Specifications and Requirements
100-06908 Rev D Page 9
This page intentionally left blank
Page 10 Rev D 100-06908
Ithaca® 8000 Specifications and Requirements
Ithaca® 8000 Thermal Printer Models
Ithaca® 8000-P: parallel interface printer
Ithaca® 8000-S: serial interface printer
Ithaca® 8000-USB: USB interface printer
Standard Features
The following features are common to the entire family of thermal printers:
Print Speed for text is 6 inches per second (150 mm/sec) (monochrome)
Linerless Label Receipt paper support.
3.15 inch (80 mm.) print zone
44/57 characters per line
Built-in self-ranging External Power supply
Clam-shell paper loading
Single RJ11 cash drawer driver with status (Single RJ12)
Parallel (25 or 36 pin), serial (9 or 25 pin) RS232C, and USB interface
Configurable receiver buffer
Self diagnostics
Set up and configuration utility program
100-06908 Rev D Page 11
CPI selections from 8 to 30 CPI1
Paper Out sensor
Multiple printer emulations: Ithaca M80/M80+, Ithaca M50/M151 Micro-line,
Epson Extended, Epson TM-T88II/III, TM-T90, U200, U300, Axiohm
A793/4/5, Citizen and Star
Maximum 8K buffer (adjustable)
2 Megabytes Flash Memory
2 Megabytes RAM
APA and Epson graphics
Bar Codes: Code 39, Code 93, Code 128, Interleaved 2 of 5, UPC-A, UPC-
E, EAN-8, EAN-13, EAN-14, PDF417 stacked symbology and Codabar
65 Language sets (including Euro symbol)
Metal receipt tear off
8 dots/mm. thermal print head resolution
ON/OFF button located on front of printer
Cable routing strain relief
Power/Error/Paper LEDs
Paper feed button
Cover open button
Settable cash drawer configurations (Ithaca, Epson, or Star)
Spill proof design- vertical main PCB mounting
58 mm. or 80 mm. paper width – factory-settable
4.0 inch (101 mm.) Paper roll diameter
Portrait/landscape printing under Windows
Page mode printing
Cover Open sensor
Electronic journal capability
Internal counters for hours on, cuts, print lines and errors
100 km print head life
60 million print line printer MCBF (excluding knife)
Strong break-away paper cover
1,000,000 cuts cutter life (partial cut)
Buzzer
1
Character spacing is adjustable from 1 to 30 CPI. Typical values will be between 8 and 20 CPI
depending on the font selected. Values of 13.3, 14.86, or 17.3 are typical for each resident font.
2
CPI‘s greater than 16 will not be supported in NLQ fonts
Page 12 Rev D 100-06908
Optional Features
The following options are available on some of the models:
Custom interfaces and emulations
DC powered version through Hosiden type connector
100-06908 Rev D Page 13
Character Cell (H x W)
10 x 24 Font
(W x H)
13 x 24 Font
(W x H)
15 x 24 Font
(W x H)
Horizontal Width
10 Dots
0.0493 inches
13 Dots
0.0640 inches
15 Dots
0.0739 inches
Vertical Height
24 Dots
0.118 Inches
24 Dots
0.118 Inches
24 Dots
0.118 Inches
Character spacing in Characters per Inch (CPI)
Pitch at native cell size
20.30
15.62
13.5
5 dot Removed
40.60
25.38
20.30
4 dot Removed
33.83
22.56
18.45
3 dot Removed
29.00
20.30
16.92
2 dot Removed
25.38
18.45
15.62
1 dot Removed
22.56
16.92
14.50
0 dot added
20.30
15.62
13.53
1 dot added
18.45
14.50
12.69
2 dots added
16.92
13.53
11.94
3 dots added
15.62
12.69
11.28
4 dots added
14.50
11.94
10.68
5 dots added
13.53
11.28
10.15
6 dots added
12.69
10.68
9.67
General Specifications
Printing Specifications
Printing method: Thermal Sensitive Line Dot System
Vertical/Horizontal dot pitch: 0.125 mm.
Resolution: 8 dots per mm (203 DPI)
Line feed pitch: 3.2 mm. (.125 inches)
Print zone (maximum) 80 mm (3.15 inch)
Print speed (monochrome): 6 inches per second
Print Speed (two color): 3 inches per second
Number of print elements: 640 dots in-line
Character Pitch
The Ithaca® 8000 has 3 basic resident fonts, as well as downloadable fonts. The
smallest internal font is a 10 x 24 font and is typically printed in pitches from 16 to 20
characters per inch (CPI). The next larger font is 13 x 24, and is typically printed in
pitches from 14 to 16 CPI. The largest font is 15 x 24 and is typically printed in pitches
from 10 to 14 CPI.
The printer always prints at 203 dots per inch (dpi). Adding or subtracting space between
characters achieves different character pitches. As each dot has a fixed size and
position, only specific pitches are possible. The following table defines the fonts and
pitches possible with each.
NOTE: Shaded Pitches are not recommended.
Table 1 Possible Character Pitches
Page 14 Rev D 100-06908
Requested CPI
Character
Width
Resulting CPI
Requested CPI
Character
Width
Resulting CPI
1
203
1.00
16
12
16.92
2
101
2.01
17
12
18.45
3
67
3.03
18
11
18.45
4
50
4.06
19
10
20.30
5
40
5.08
20
10
20.30
6
33
6.15
21 9 22.56
7
29
7.00
22 9 22.56
8
25
8.12
23 8 25.38
9
22
9.23
24 8 25.38
10
20
10.15
25 8 25.38
11
18
11.28
26 7 29.00
12
16
12.69
27 7 29.00
13
15
13.53
28 7 29.00
14
14
14.50
29 7 29.00
15
13
15.62
30 6 33.83
Requested CPI
Character
Width
Resulting CPI
Requested CPI
Character
Width
Resulting CPI
1
203
1.00
16
12
16.92
2
101
2.01
17
12
18.45
3
67
3.03
18
11
18.45
4
50
4.06
19
10
20.30
5
40
5.08
20
10
20.30
6
33
6.15
21 9 22.56
7
29
7.00
22 9 22.56
8
25
8.12
23 8 25.38
9
22
9.23
24 8 25.38
10
20
10.15
25 8 25.38
11
18
11.28
26 7 29.00
12
16
12.69
27 7 29.00
13
15
13.53
28 7 29.00
14
14
14.50
29 7 29.00
15
13
15.62
30 6 33.83
NOTE: Shaded Pitches are not recommended.
Table 2 Requested CPI and Resulting CPI
Character Generation
Standard Print
There are three resident fonts in the printer: Small, Medium, and Large. The cell size for
each is different.
NOTE: Shaded Pitches are not recommended.
Table 3 Cell Size for Small, Medium and Large Fonts
100-06908 Rev D Page 15
Small 10 x 24 Font
The 10 x 24 small font is defined in a 10 x 24 cell. The characters are typically 22 dots
high and 8 dots wide; however to provide readable international characters, some
characters are wider. In most cases this font can be printed at 22.5 CPI without having
the characters touch. This font is recommended for printing from 16 to 20 CPI.
.
01 ...00.....
02 ..0000....
03 ..0000....
04 .00..00...
05 .00..00...
06 .00..00...
07 .00..00...
08 .00..00...
09 00....00..
10 00....00..
11 00....00..
12 00....00..
13 00....00..
14 00000000..
15 00000000..
16 00....00..
17 00....00..
18 00....00..
19 00....00..
20 00....00..
21 00....00..
22 00....00..
23 ..........
24 ..........
Medium 13 x 24 Font
The 13 x 24 medium font is defined in a 13 x 24 cell. The characters are typically 22 dots
high and 11 dots wide; however to provide readable international characters, some
characters are wider. In most cases this font can be printed at 16.9 CPI without having
the characters touch. This font is recommended for printing from 14 to 16 CPI.
01 ....000......
02 ....000......
03 ....000......
04 ...00.00.....
05 ...00.00.....
06 ...00.00.....
07 ...00.00.....
08 ..00...00....
09 ..00...00....
10 ..00...00....
11 ..00...00....
12 .00.....00...
13 .00.....00...
14 .00.....00...
15 .000000000...
16 .000000000...
17 00.......00..
18 00.......00..
19 00.......00..
20 00.......00..
21 00.......00..
22 00.......00..
23 .............
24 .............
Large 15x 24 Font
The 15 x 24 medium font is defined in a 15 x 24 cell. The characters are typically 22
dots high and 14 dots wide; however to provide readable international characters, some
characters are wider. In most cases this font can be printed at 13.5 CPI without having
the characters touch. This font is recommended for printing from 10 to 14 CPI. This font
is only available in the Ithaca emulation, and provides a bigger and darker character for
better readability.
Page 16 Rev D 100-06908
Loading...
