UPFLOW/HORIZONTAL 2-STAGE, VARIABLE SPEED GAS-FIRED FURNACE
XV80
MODELS TUD2B060A9V3VB, TUD2B080A9V3VB TUD2C080A9V4VB, TUD2C080B9V4VB TUD2B100A9V3VB, TUD2C100A9V5VB TUD2C100B9V5VB, TUD2D120A9V5VB TUD2D120B9V5VB, TUD2D140A9V5VB
Two-Stage FanAssisted CombustionSystem
© 2011 Trane
PUB. NO. 22-1650-13
General Features
NATURAL GAS MODELS
Central Heating furnace designs are cer­tified by the American Gas Association for both natural and L.P. gas. Limit setting and rating data were established and approved under standart rating condi­tions using American National Standards Instirute standards.
SAFE OPERATION
The Integrated System Control has solid state devices, which continuously monitor for presence of flame, when the system is in the heaating mode of operation. Dual solenoid combination gas valve and regulator provide extra safety.
QUICK HEATING
Durable, cycle tested, heavy gauge aluminized steel heat exchanger quickly transfers heat to provide warm condi­tioned air to the structure. Low energy power vent blower, to increase efficiency and provide a positive discharge of gas fumes to the outside.
BURNERS
Multiport In-shot burners will give years of quiet and efficient service. All models can be converted to L.P. gas.
INTEGRATED SYSTEM CONTROL
Exclusively designed operational program provides total control of furnace limit sensors, blowers, gas valve, flame control and includes self diagnostics for ease of service. Also contains connection points for E.A.C./humidifier.
AIR DELIVERY
The variable speed, direct drive blower motor, has sufficient airflow for most heating and cooling requirements, will switch from heating to cooling speeds on demand from room thermostat. The blower door safety switch will prevent or terminate furnace operation when the blower door is removed. Some models are available with high efficiency blowers.
STYLING Heavy gauge steel and “wrap-around” cabinet construction is used in the
cabinet with baked-on enamel finish for strength and beauty. The heat exchanger section of the cabinet is completely lined with foil faced fiberglass insulation. This results in quiet and efficient opera­tion due to the excellent acoustical and insulating qualities of fiberglass. Built-in bottom pan and alternate bottom, left or right side return air connection provision.
FEATURES AND GENERAL OPERA­TION
The XV80 High Efficiency Gas Furnaces employ a Hot Surface Ignition system, which eliminates the waste of a constant burning pilot. The integrated system control lights the main burners upon a de­mand for heat from the room thermostat. Complete front service access. a. Low energy power venter b. Vent proving pressure switch.
© 2011 Trane
2
22-1650-13
Contents
Feature Summary
Features and Benefits
Standard Equipment Optional Equipment
General Data
TUD2B060A9V3VB TUD2B080A9V3VB TUD2C080A9V4VB TUD2C080B9V4VB TUD2B100A9V3VB TUD2C100A9V5VB TUD2C100B9V5VB TUD2D120A9V5VB TUD2D120B9V5VB TUD2D140A9V5VB
Performance Data
2
4
4 5
6
9
22-1650-13
Electric Data
Field Wiring Diagrams
Dimensions
3
19
19
24
Features and Benefits
XV80 STANDARD EQUIPMENT
•Upow/Horizontaland
•Powersupply115/1/60
•2-stagegasvalve
•2-speedventer
•Variablespeedblowermotor
•SiliconNitridehotsurfaceigniterwith
adaptive heat up
•Integratedsolidstatecontrol
•Attractivecoloraccents
•Heavygaugealuminizedsteelheat
exchanger
•Multi-portIn-shotburners
•Completefrontserviceaccess
•Alternatebottom/left/rightreturnair
•Slideoutblowerassembly
•Hingedblowerdoor
•Perfecttdoorcatches
•Insulatedblowerdoor
•Gasketedblowerdoor
•Internallterrack
•Standardltersizes
•Two-tonecolor
•Directdrive,variablespeedmotor
•Integratedsolidstatecontrolwith
self-diagnostics
•Commonventcapability
•Cleanableframedlters
•OptionalL. P.conversionkit
•Left/rightgasconnection
•Accessoryhook-upcapability
•Selectablecoolingfanoffdelay
eliminates need for BAY24X045 time delay kit
•Enhancedcoolingcontrol
4
22-1650-13
Features and Benefits
XV80 OPTIONAL EQUIPMENT
Thermostat, Mechanical 2-Stage Heating/1-Stage Cooling ........................................................................................ TAYSTAT241 [ ]
Thermostat, Mechanical Heating Only With Fan Switch ............................................................................................. BAYSTAT303 [ ]
Thermostat, Mechanical Heating Only ....................................................................................................................... BAYSTAT388 [ ]
Thermostat, Heating/Cooling Single Stage (Mounts Horizontally) .................................................................................AY28X092 [ ]
Thermostat, Electronic Non-programmable 1-Stage Heating/1-Stage Cooling .......................................................... BAYSTAT370 [ ]
Thermostat, Electronic Programmable (5-2) 1-Stage Heating/1-Stage Cooling ......................................................... BAYSTAT340 [ ]
Thermostat, Heating/Cooling Single Stage (Mounts Vertically) .................................................................................. BAYSTAT305 [ ]
Thermostat, Electronic Programmable 2-Stage Heating/2-Stage Cooling ............................................................... TAYSTAT302C [ ]
Thermostat, Electronic Programmable 1-Stage Heating/1-Stage Cooling ............................................................... TAYSTAT300C [ ]
Propane Conversion Kit ........................................................................................................................................... BAYLPKT210A [ ]
Electronic Air Filter, “Perfect Fit” High Efficiency (17-1/2" Wide Gas Furnace) ........................................................ TFM175A9FR0 [ ]
Electronic Air Filter, “Perfect Fit” High Efficiency (21" Wide Gas Furnace) .............................................................. TFM210A9FR0 [ ]
Electronic Air Filter, “Perfect Fit” High Efficiency (24-1/2" Wide Gas Furnace) ........................................................ TFM245A9FR0 [ ]
Electronic Air Filter, “Perfect Fit” Standard Efficiency (17-1/2" Wide Gas Furnace)..................................................TFP175A9FR0 [ ]
Electronic Air Filter, “Perfect Fit” Standard Efficiency (21" Wide Gas Furnace) ........................................................TFP210A9FR0 [ ]
Electronic Air Filter, “Perfect Fit” Standard Efficiency (24-1/2" Wide Gas Furnace)..................................................TFP245A9FR0 [ ]
Coil Enclosure (17-1/2" Wide Cabinets) ............................................................................................................BAYCLE17A1722A [ ]
Coil Enclosure (21" Wide Cabinets) ..................................................................................................................BAYCLE21A2130A [ ]
Coil Enclosure (24-1/2" Wide Cabinets) ............................................................................................................BAYCLE24A2430A [ ]
Side Filter Rack .......................................................................................................................................................... BAYFLTR200 [ ]
High Altitude Switch ....................................................................................................................................................BAYHALT249 [ ]
Masonry Chimney Vent Kit (Upflow models only) ....................................................................................................BAYVENT800B [ ]
Filter Rack Kit 1 .................................................................................................................................................... BAYRACK960A [ ]
1 Available for models with 1800 CFM or greater which require an additional side return.
22-1650-13
5
MODEL
TYPE RATINGS 2
1st Stage Input BTUH 1st Stage Capacity BTUH (ICS) 3
2nd Stage Input BTUH 2nd Stage Capacity BTUH (ICS) 3
Temp. rise (Min.-Max.) °F.
BLOWER DRIVE
Diameter - Width (In.)
No. Used
Speeds (No.)
CFM vs. in. w.g.
Motor HP
R.P.M.
Volts / Ph / Hz
COMBUSTION FAN - Type
Drive - No. Speeds
Motor HP - RPM
Volts / Ph / Hz
FLA
FILTER — Furnished?
Type Recommended
Hi Vel. (No.-Size-Thk.)
VENT — Size (In.)
HEAT EXCHANGER
Type -Fired
-Unfired
Gauge (Fired)
ORIFICES — Main
Nat. Gas. Qty. — Drill Size
L. P. Gas Qty. — Drill Size
GAS VALVE
PILOT SAFETY DEVICE
Type
BURNERS — Type
Number
POWER CONN. — V / Ph / Hz 4
Ampacity (In Amps)
Max. Overcurrent Protection (Amps)
PIPE CONN. SIZE (In.)
DIMENSIONS
Crated (In.)
WEIGHT
Shipping (Lbs.) / Net (Lbs.)
TUD-R9V PRODUCT SPECIFICATIONS1
TUD2B060A9V3VB
Upflow / Horizontal
39,000
31,200
60,000
48,000
30 - 60
Direct
10 x 7
1
Variable
See Airflow Table
1/2
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
0.7
Ye s
High Velocity
1 - 17x25 - 1in.
4 Round
Alum. Steel - Type 1
20
3 — 45
3 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
3
115/1/60
10.5
15
1/2
H x W x D
41-3/4 x 19-1/2 x 30-1/2
136 / 126
TUD2B080A9V3VB
Upflow / Horizontal
52,000
41,600
80,000
64,000
30 - 60
Direct
10 x 7
1
Variable
See Airflow Table
1/2
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
0.7
Ye s
High Velocity
1 - 17x25 - 1in.
4 Round
Alum. Steel - Type 1
20
4 — 45
4 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
4
115/1/60
10.5
15
1/2
H x W x D
41-3/4 x 19-1/2 x 30-1/2
142 / 132
TUD2C080A9V4VB
Upflow / Horizontal
52,000
41,600
80,000
64,000
30 - 60
Direct
10 x 10
1
Variable
See Airflow Table
3/4
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
0.7
Ye s
High Velocity
1 - 20x25 - 1in.
4 Round
Alum. Steel - Type 1
20
4 — 45
4 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
4
115/1/60
12.9
20
1/2
H x W x D
41-3/4 x 23 x 30-1/2
166 / 155
1 Central Furnace heating designs are certified to ANSI Z21.47 / CSA 2.3 2 For U.S. applications, above input ratings (BTUH) are up to 2,000 feet, derate 4% per 1,000 feet for elevations above 2,000 feet above sea level. For Canadian applications,
above input ratings (BTUH) are up to 4,500 feet, derate 4% per 1,000 feet for elevations above 4,500 feet above sea level.
3 Based on U.S. government standard tests. 4 The above wiring specifications are in accordance with National Electrical Code; however, installations must comply with local codes.
6 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
TUD-R9V PRODUCT SPECIFICATIONS1
MODEL
TYPE RATINGS 2
1st Stage Input BTUH 1st Stage Capacity BTUH (ICS) 3
2nd Stage Input BTUH 2nd Stage Capacity BTUH (ICS) 3
Temp. rise (Min.-Max.) °F.
BLOWER DRIVE
Diameter - Width (In.)
No. Used
Speeds (No.)
CFM vs. in. w.g.
Motor HP
R.P.M.
Volts / Ph / Hz
COMBUSTION FAN - Type
Drive - No. Speeds
Motor HP - RPM
Volts / Ph / Hz
FLA
FILTER — Furnished?
Type Recommended
Hi Vel. (No.-Size-Thk.)
VENT — Size (In.)
HEAT EXCHANGER
Type -Fired
-Unfired
Gauge (Fired)
ORIFICES — Main
Nat. Gas. Qty. — Drill Size
L. P. Gas Qty. — Drill Size
GAS VALVE
PILOT SAFETY DEVICE
Type
BURNERS — Type
Number
POWER CONN. — V / Ph / Hz 4
Ampacity (In Amps)
Max. Overcurrent Protection (Amps)
PIPE CONN. SIZE (In.)
DIMENSIONS
Crated (In.)
WEIGHT
Shipping (Lbs.) / Net (Lbs.)
TUD2C080B9V4VB 5
Upflow / Horizontal
52,000
41,600
80,000
64,000
30 - 60
Direct
10 x 10
1
Variable
See Airflow Table
3/4
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
0.7
Ye s
High Velocity
1 - 20x25 - 1in.
4 Round
Alum. Steel - Type 1
20
4 — 45
4 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
4
115/1/60
12.9
20
1/2
H x W x D
41-3/4 x 23 x 30-1/2
166 / 155
TUD2B100A9V3VB
Upflow / Horizontal
65,000
52,000
100,000
80,000
40 - 70
Direct
10 x 7
1
Variable
See Airflow Table
1/2
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
0.87
Ye s
High Velocity
1 - 17x25 - 1in.
4 Round
Alum. Steel - Type 1
20
5 — 45
5 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
5
115/1/60
10.8
15
1/2
H x W x D
41-3/4 x 19-1/2 x 30-1/2
142 / 132
TUD2C100A9V5VB
Upflow / Horizontal
65,000
52,000
100,000
79,000
35 - 65
Direct
10 x 10
1
Variable
See Airflow Table
1
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
0.87
Ye s
High Velocity
1 - 20x25 - 1in.
4 Round
Alum. Steel - Type 1
20
5 — 45
5 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
5
115/1/60
14.9
20
1/2
H x W x D
41-3/4 x 23 x 30-1/2
166 / 155
1 Central Furnace heating designs are certified to ANSI Z21.47 / CSA 2.3 2 For U.S. applications, above input ratings (BTUH) are up to 2,000 feet, derate 4% per 1,000 feet for elevations above 2,000 feet above sea level. For Canadian applications,
above input ratings (BTUH) are up to 4,500 feet, derate 4% per 1,000 feet for elevations above 4,500 feet above sea level.
3 Based on U.S. government standard tests. 4 The above wiring specifications are in accordance with National Electrical Code; however, installations must comply with local codes. 5 Model uses high efficiency blower.
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 7
MODEL
TYPE RATINGS 2
1st Stage Input BTUH 1st Stage Capacity BTUH (ICS) 3
2nd Stage Input BTUH 2nd Stage Capacity BTUH (ICS) 3
Temp. rise (Min.-Max.) °F.
BLOWER DRIVE
Diameter - Width (In.)
No. Used
Speeds (No.)
CFM vs. in. w.g.
Motor HP
R.P.M.
Volts / Ph / Hz
COMBUSTION FAN - Type
Drive - No. Speeds
Motor HP - RPM
Volts / Ph / Hz
FLA
FILTER — Furnished?
Type Recommended
Hi Vel. (No.-Size-Thk.)
VENT — Size (In.)
HEAT EXCHANGER
Type -Fired
-Unfired
Gauge (Fired)
ORIFICES — Main
Nat. Gas. Qty. — Drill Size
L. P. Gas Qty. — Drill Size
GAS VALVE
PILOT SAFETY DEVICE
Type
BURNERS — Type
Number
POWER CONN. — V / Ph / Hz 4
Ampacity (In Amps)
Max. Overcurrent Protection (Amps)
PIPE CONN. SIZE (In.)
DIMENSIONS
Crated (In.)
WEIGHT
Shipping (Lbs.) / Net (Lbs.)
TUD-R9V PRODUCT SPECIFICATIONS1
TUD2C100B9V5VB 5
Upflow / Horizontal
65,000
52,000
100,000
79,000
35 - 65
Direct
10 x 10
1
Variable
See Airflow Table
1
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
0.87
Ye s
High Velocity
1 - 20x25 - 1in.
4 Round
Alum. Steel - Type 1
20
5 — 45
5 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
5
115/1/60
14.9
20
1/2
H x W x D
41-3/4 x 23 x 30-1/2
166 / 155
TUD2D120A9V5VB
Upflow / Horizontal
78,000
62,400
120,000
97,000
35 - 65
Direct
10 x 10
1
Variable
See Airflow Table
1
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
1.14
Ye s
High Velocity
1 - 24x25 - 1in.
4 Round
Alum. Steel - Type 1
20
6 — 45
6 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
6
115/1/60
15.3
20
1/2
H x W x D
41-3/4 x 26-1/2 x 30-1/2
193 / 181
TUD2D120B9V5VB 5
Upflow / Horizontal
78,000
62,400
120,000
97,000
35 - 65
Direct
10 x 10
1
Variable
See Airflow Table
1
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
1.14
Ye s
High Velocity
1 - 24x25 - 1in.
4 Round
Alum. Steel - Type 1
20
6 — 45
6 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
6
115/1/60
15.3
20
1/2
H x W x D
41-3/4 x 26-1/2 x 30-1/2
193 / 181
TUD2D140A9V5VB
Upflow / Horizontal
91,000
72,800
140,000
111,000
40 - 70
Direct
10 x 10
1
Variable
See Airflow Table
1
Variable
115/1/60
Centrifugal
Direct - 2
1/50 - 3000
115/1/60
1.16
Ye s
High Velocity
1 - 24x25 - 1in.
4 Round
Alum. Steel - Type 1
20
7 — 45
7 — 56
Redundant - Two Stage
Hot Surface Ignition
Multi-port In-shot
7
115/1/60
15.3
20
1/2
H x W x D
41-3/4 x 26-1/2 x 30-1/2
197 / 185
1 Central Furnace heating designs are certified to ANSI Z21.47 / CSA 2.3 2 For U.S. applications, above input ratings (BTUH) are up to 2,000 feet, derate 4% per 1,000 feet for elevations above 2,000 feet above sea level. For Canadian applications,
above input ratings (BTUH) are up to 4,500 feet, derate 4% per 1,000 feet for elevations above 4,500 feet above sea level.
3 Based on U.S. government standard tests. 4 The above wiring specifications are in accordance with National Electrical Code; however, installations must comply with local codes. 5 Model uses high efficiency blower.
8 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
*UD2B060A9V3VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2B060A9V3VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
1.5
2
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
LOW
(350 CFM/ TON)
NORMAL
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
LOW
(350 CFM/ TON)
NORMAL
(400 CFM/ TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW7 SW8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW1 SW2 SW3 SW4 0.1 0.3 0.5 0.7 0.9
ON ON OFF ON
ON ON OFF OFF
ON ON ON OFF
OFF ON OFF ON
OFF ON OFF OFF
589
49 65
663
44 75
775
37
105
813
55
110
907
49
140
1038
43
190
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
604
48 95
694
42
120
781
37
145
818
54
150
919
48
200
1066
42
260
499
605
649
680
798 105
50
60
75
80
619
125
684
145
776
180
818
185
942
240
1086
325
537
80
610
80
681 110
722 125
804 145
47
42
37
54
47
41
520 110
610 120
665 145
680 150
809 170
604
48
160
681
42
185
805
36
230
837
53
240
958
46
300
1089
41
365
520 145
597 155
665 180
696 190
823 235
607
200
686
220
811
270
842
280
959
330
1079
415
48
42
36
53
46
41
500 175
593 180
672 220
696 225
818 280
HIGH
(450 CFM/ TON)
LOW
(350 CFM/ TON)
2.5
3 **
NOTES:
1. *FIRST LETTER MAY BE "A" OR "T"
2. **FACTORY SETTING.
3. CONTINUOUS FAN SETTING: HEATING OR COOLING AIRFLOW IS APPROXIMATELY 50% OF SELECTED COOLING VALUE.
4. LOW 350 CFM/TON IS RECOMMENDED FOR VARIABLE SPEED APPLICATION FOR COMFORT & HUMID CLIMATE SETTING: NORMAL IS 400 CFM/TON: HIGH 450 CFM/TON IS FOR DRY CLIMATE SETTING.
NORMAL
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
LOW
(350 CFM/ TON)
NORMAL **
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
884 145
858 125
984 170
1125
245
1035
205
1208
300
1380
440
896 180
863 175
1017
225
1138
315
1056
265
1247
360
1410
500
924 240
882 220
1038
295
1150
370
1076
330
1268
440
1402
550
931 280
894 275
1017
330
1161
435
1076
370
1278
485
1350
550
931 330
895 320
1017
375
1161
475
1076
430
1200
490
1235
525
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 9
*UD2B080A9V3VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2B080A9V3VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
2.5
3.0
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM **
HIGH OFF OFF
AIRFLOW
SETTING
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 7 SW 8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
ON OFF
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 1 SW 2 SW 3 SW 4 0.1 0.3 0.5 0.7 0.9
OFF ON OFF ON
OFF ON OFF OFF
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
800
48
100
910
43
130
1060
37
188
1110
54
210
1245
48
300
1415
42
410
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
790
49
135
890
44
170
1020
38
220
1090
55
260
1240
48
355
1400
42
470
880 120
1020
170
1110
210
1040
190
1200
250
1340
355
1215
265
765
50
155
875
44
210
1010
39
265
1090
55
310
1240
48
410
1400
42
530
875 155
1000
205
110 260
1010
220
1200
320
1340
425
1210
330
860 190
990 240
1110
320
1000
260
1190
370
1330
475
1210
375
750
52
200
860
45
240
1010
39
310
1080
55
350
1230
48
460
1375
43
580
845 225
980 280
1100
350
1000
310
1190
415
1320
530
1200
430
1000
1065
1215
1320
730
53
230
820
47
280
39
350
56
400
49
500
45
590
840 245
960 320
1100
385
990 340
1175
450
1300
570
1185
465
3.5 **
NOTES:
1. * First Letter may be "A" or "T"
2. ** Factory setting
3. Continuous Fan Setting: Heating or Cooling airflow is approximately 50% of selected Cooling value.
4. LOW 350 cfm/ton is recommended for Variable Speed application for COMFORT & HUMID CLIMATE setting; NORMAL is 400 cfm/ton; HIGH 450 cfm/ton is for DRY CLIMATE setting
NORMAL **
(400 CFM/TON)
HIGH
(450 CFM/TON)
OFF OFF OFF OFF
OFF OFF ON OFF
CFM
WATTS
CFM
WATTS
1430
415
1430
415
1415
457
1415
475
1410
520
1410
520
1385
575
1385
575
1330
580
1330
580
10 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
*UD2C080A9V4VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2C080A9V4VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
2.5
3.0
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 7 SW 8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 1 SW 2 SW 3 SW 4 0.1 0.3 0.5 0.7 0.9
ON ON OFF ON
ON ON OFF OFF
ON ON ON OFF
OFF ON OFF ON
OFF ON OFF OFF
782
49 75
870
44 90
962
40
110
1091
54
145
1211
49
190
1371
43
255
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
762
51
110
865
45
125
974
40
155
1092
54
190
1243
48
255
1388
43
325
1101
1031
1163
863
90
995 115
150
125
170
751
51
145
861
45
175
963
40
200
1087
55
245
1243
48
310
1392
43
395
865 130
1005
170
1112
200
1031
175
1178
230
858 175
989 210
1111
255
1026
215
1188
285
748
51
185
848
45
215
938
41
245
1092
54
305
1244
48
370
1385
43
455
843 220
973 260
1107
305
1013
270
1183
345
737
225
831
255
914
290
1077
355
1235
430
1377
515
52
46
42
55
48
43
831 255
956 305
1101
360
1003
320
1178
405
HIGH
(450 CFM/TON)
3.5
4 **
NOTES:
1. * First Letter may be "A" or "T"
2. ** Factory setting
3. Continuous Fan Setting: Heating or Cooling airflow is approximately 50% of selected Cooling value.
4. LOW 350 cfm/ton is recommended for Variable Speed application for COMFORT & HUMID CLIMATE setting; NORMAL is 400 cfm/ton; HIGH 450 cfm/ton is for DRY CLIMATE setting
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL **
(400 CFM/TON)
HIGH
(450 CFM/TON)
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
1319
240
1182
200
1380
255
1553
350
1386
255
1590
360
1791
360
1337
305
1206
240
1401
325
1566
425
1401
330
1593
440
1808
615
1344
365
1211
295
1402
390
1557
500
1408
395
1591
515
1810
615
1340
420
1211
350
1402
460
1558
560
1402
460
1588
575
1808
775
1336
485
1211
420
1399
515
1559
645
1390
520
1576
650
1726
800
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 11
*UD2C080B9V4VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2C080B9V4VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
2.5
3.0
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 7 SW 8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 1 SW 2 SW 3 SW 4 0.1 0.3 0.5 0.7 0.9
ON ON OFF ON
ON ON OFF OFF
ON ON ON OFF
OFF ON OFF ON
OFF ON OFF OFF
974
49
133
1102
43 93
1194
40
119
1189
58
142
1346
51
141
1460
47
186
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
968
49
285
1112
43
144
1217
39
180
1210
57
209
1388
49
207
1516
45
263
842
71
956
90
1071
113
1002991000
1140
128
949
202
1103
201
1215
243
1209
276
1398
274
1536
335
819 114
948 140
1078
171
152
1155
191
50
43
39
57
49
45
789 163
928 196
1067
233
983 210
1150
256
925
51
254
1083
44
255
1200
40
304
1193
58
341
1390
49
339
1533
45
407
756 207
901 248
1045
292
958 265
1132
319
1066
1182
1175
1372
1515
906
52
304
45
305
40
362
58
404
50
401
45
477
740 249
884 298
1028
348
942 318
1114
379
HIGH
(450 CFM/TON)
3.5
4 **
NOTES:
1. * First Letter may be "A" or "T"
2. ** Factory setting
3. Continuous Fan Setting: Heating or Cooling airflow is approximately 50% of selected Cooling value.
4. LOW 350 cfm/ton is recommended for Variable Speed application for COMFORT & HUMID CLIMATE setting; NORMAL is 400 cfm/ton; HIGH 450 cfm/ton is for DRY CLIMATE setting
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL **
(400 CFM/TON)
HIGH
(450 CFM/TON)
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
1278
165
1163
134
1324
179
1485
234
1324
179
1508
243
1691
322
1311
238
1181
199
1363
255
1544
319
1363
255
1570
329
1777
416
1316
308
1177
265
1372
326
1566
396
1372
326
1594
407
1816
499
1305
377
1161
328
1363
397
1565
472
1363
397
1593
483
1824
579
1287
444
1143
389
1345
466
1546
550
1345
466
1575
562
1805
669
12 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
*UD2B100A9V3VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 7 SW 8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
751
64 86
796
61
132
817
59
175
832
58
218
838
57
263
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2B100A9V3VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
1.5
2.0
2.5
3.0**
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL **
(400 CFM/TON)
HIGH
(450 CFM/TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 1 SW 2 SW 3 SW 4 0.1 0.3 0.5 0.7 0.9
ON ON OFF ON
ON ON OFF OFF
ON ON ON OFF
OFF ON OFF ON
OFF ON OFF OFF
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
862
56
121
959
50
148
1099
67
227
1286
58
365
1399
53
465
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
921
52
185
1002
48
210
1124
66
287
1321
56
450
1419
52
570
1121
1061
1185
1351
516
50
583
59
681
70
680
75
769 103
882 130
831 180
979 167
245
210
278
425
953
233
1036
280
1149
355
1313
455
1347
545
536
75
615
92
697 110
726 120
819 145
938 190
903 180
1036
240
1147
310
1081
265
1223
364
1372
503
51
46
64
56
55
551 105
633 127
701 140
735 150
843 190
961 245
928 230
1053
295
1176
383
1095
320
1251
435
1343
535
967
50
285
1036
46
325
1157
64
415
1215
61
475
1265
59
520
954
322
1003
355
1055
395
1119
450
1163
485
547 135
621 157
709 180
741 190
858 235
975 300
935 275
1053
345
1167
442
1101
382
1205
455
1248
505
50
48
70
66
64
530 165
618
18
712 215
745 230
865 286
970 345
935 320
1015
368
1055
396
1032
380
1101
426
1168
480
NOTES:
1. * First Letter may be "A" or "T"
2. ** Factory setting
3. Continuous Fan Setting: Heating or Cooling airflow is approximately 50% of selected Cooling value.
4. LOW 350 cfm/ton is recommended for Variable Speed application for COMFORT & HUMID CLIMATE setting; NORMAL is 400 cfm/ton; HIGH 450 cfm/ton is for DRY CLIMATE setting
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 13
*UD2C100A9V5VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2C100A9V5VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
3.0
3.5
4.0
5.0 **
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL **
(400 CFM/TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 7 SW 8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 1 SW 2 SW 3 SW 4 0.1 0.3 0.5 0.7 0.9
ON ON OFF ON
ON ON OFF OFF
ON ON ON OFF
OFF ON OFF ON
OFF ON OFF OFF
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
900
53
100
1125
43
150
1300
37
220
1270
59
200
1575
47
355
1870
40
560
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
890
54
130
1090
44
200
1300
37
290
1290
58
260
1600
46
445
1890
39
665
1075
135
1220
185
1390
245
1214
185
1430
310
1640
370
1405
270
1670
395
1870
540
1775
480
2065
755
870
175
1060
235
1320
365
1290
335
1610
520
1860
710
1055
185
1200
240
1390
320
1210
240
1460
355
1665
460
1430
310
1675
490
1880
635
1800
580
2020
840
55
46
36
58
46
40
1015
220
1210
295
1410
391
1215
295
1470
430
1650
540
1440
375
1670
550
1880
730
1820
680
1945
900
850
57
220
1070
45
300
1350
36
430
1290
58
400
1600
46
575
1870
40
830
1000
265
1210
350
1410
470
1210
350
1460
500
1640
615
1440
480
1655
630
1845
800
1800
750
1805
880
1070
1340
1280
1580
1730
835
58
270
45
340
36
490
58
460
47
650
43
760
990 325
1210
410
1400
510
1210
415
1440
555
1610
660
1420
550
1630
700
1670
640
1680
740
1623
800
HIGH
(450 CFM/TON)
NOTES:
1. * First letter may be "A" or "T"
2. ** Factory setting
3. Continuous Fan Setting: Heating or Cooling airflow is approximately 50% of selected Cooling value.
4. LOW 350 cfm/ton is recommended for Variable Speed application for COMFORT & HUMID CLIMATE setting; NORMAL is 400 cfm/ton; HIGH 450 cfm/ton is for DRY CLIMATE setting
OFF OFF ON OFF
CFM
WATTS
2310 1000
2100 1000
2100
950
1965
890
1800
825
14 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
*UD2C100B9V5VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2C100B9V5VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
3.0
3.5
4.0
5.0 **
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL **
(400 CFM/TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 7 SW 8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 1 SW 2 SW 3 SW 4 0.1 0.3 0.5 0.7 0.9
ON ON OFF ON
ON ON OFF OFF
ON ON ON OFF
OFF ON OFF ON
OFF ON OFF OFF
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
953
50 93
1142
42
135
1258
38
169
1312
52
188
1577
44
301
1739
39
392
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
944
50
146
1141
42
200
1260
38
240
1317
52
261
1592
43
387
1761
39
486
1056
114
1199
151
1342
198
1223
158
1389
217
1556
291
1389
217
1580
303
1770
411
1723
382
1961
546
936
193
1135
255
1256
302
1314
326
1592
468
1762
575
1050
173
1199
219
1348
273
1224
227
1397
294
1570
376
1397
294
1595
389
1793
507
1744
475
1991
652
51
42
38
52
43
39
1044
225
1194
277
1345
340
1219
287
1395
363
1570
455
1395
363
1595
469
1795
598
1754
564
1996
751
908
52
243
1112
43
322
1236
38
378
1294
53
406
1597
43
563
1753
39
675
1019
284
1172
349
1326
422
1198
361
1377
449
1556
549
1377
449
1582
565
1787
698
1735
663
1991
850
1098
1227
1287
1582
1762
887
54
292
43
377
39
437
53
468
43
644
39
774
1002
336
1161
405
1320
486
1187
418
1373
515
1559
629
1373
515
1585
647
1797
801
1744
760
2010
981
HIGH
(450 CFM/TON)
NOTES:
1. * First letter may be "A" or "T"
2. ** Factory setting
3. Continuous Fan Setting: Heating or Cooling airflow is approximately 50% of selected Cooling value.
4. LOW 350 cfm/ton is recommended for Variable Speed application for COMFORT & HUMID CLIMATE setting; NORMAL is 400 cfm/ton; HIGH 450 cfm/ton is for DRY CLIMATE setting
OFF OFF ON OFF
CFM
WATTS
2199
754
2217
875
2217
983
2197 1067
1987
943
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 15
*UD2D120A9V5VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2D120A9V5VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
3.5
4
5 **
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
(See Notes)
LOW
(350 CFM/ TON)
NORMAL
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
LOW
(350 CFM/ TON)
NORMAL
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
LOW
(350 CFM/ TON)
NORMAL **
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW7 SW8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW1 SW2 SW3 SW4 0.1 0.3 0.5 0.7 0.9
OFF ON OFF ON
OFF ON OFF OFF
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
1007
57
114
1154
50
167
1288
45
208
1387
64
250
1589
56
350
1771
50
475
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
1062
54
177
1211
48
230
1319
44
273
1421
63
320
1637
54
440
1788
50
560
1195
150
1353
210
1554
315
1356
200
1565
320
1766
450
1708
420
1994
665
2247
975
1084
285
1211
277
1310
330
1455
400
1666
535
1804
650
1243
225
1403
290
1572
410
1391
280
1584
410
1799
550
1758
530
2018
775
2152
925
53
48
44
61
53
49
1235
275
1417
370
1615
480
1399
370
1633
475
1810
650
1759
585
1971
785
2019
860
1063
54
303
1221
47
344
1349
43
410
1488
60
460
1678
53
600
1751
51
675
1251
325
1437
425
1634
570
1433
420
1639
560
1784
685
1775
675
1814
725
1861
765
1063
1212
1358
1495
1541
1554
54
350
48
417
43
460
59
540
58
575
57
590
1251
410
1458
485
1567
575
1454
510
1554
575
1590
600
1575
585
1618
625
1693
680
NOTES: "CONTINUOUS FAN SETTING" IS THERMOSTAT FAN SWITCH "ON" AND DIP SWITCHS 5 AND 6 "ON".
1. *FIRST LETTER MAY BE "A" OR "T"
2. **FACTORY SETTING.
3. CONTINUOUS FAN SETTING: HEATING OR COOLING AIRFLOW IS APPROXIMATELY 50% OF SELECTED COOLING VALUE.
4. LOW 350 CFM/TON IS RECOMMENDED FOR VARIABLE SPEED APPLICATION FOR COMFORT & HUMID CLIMATE SETTING: NORMAL IS 400 CFM/TON: HIGH 450 CFM/TON IS FOR DRY CLIMATE SETTING.
16 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
*UD2D120B9V5VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2D120B9V5VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
3.5
4.0
5.0 **
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
(See Notes)
LOW
(350 CFM/ TON)
NORMAL
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
LOW
(350 CFM/ TON)
NORMAL
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
LOW
(350 CFM/ TON)
NORMAL **
(400 CFM/ TON)
HIGH
(450 CFM/ TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
S4-3 S4-4 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
S3-1 S3-2 S3-3 S3-4 0.1 0.3 0.5 0.7 0.9
OFF ON OFF ON
OFF ON OFF OFF
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
1050
45 99
1214
39
129
1288
37
147
1429
48
191
1672
41
310
1782
39
385
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
1044
46
146
1216
39
188
1293
37
212
1440
48
267
1695
40
402
1809
38
480
1208
128
1343
162
1477
210
1343
162
1496
218
1650
296
1612
274
1858
403
1871
585
1035
208
1217
262
1298
293
1453
363
1722
528
1890
623
1209
186
1350
232
1491
290
1350
232
1511
300
1671
387
1631
363
1902
533
2126
711
46
39
37
47
40
36
1210
260
1358
318
1507
391
1358
318
1528
403
1698
511
1655
482
1907
624
2110
797
1005
47
252
1192
40
252
1275
37
309
1435
48
340
1711
40
409
1835
37
565
1185
306
1337
365
1490
436
1337
365
1511
447
1686
548
1642
521
1906
714
2098
888
980
48
310
1169
41
310
1254
38
373
1416
48
406
1697
40
480
1871
37
644
1162
370
1317
433
1472
508
1317
433
1494
520
1671
626
1627
598
1871
755
2001
953
NOTES: "CONTINUOUS FAN SETTING" IS THERMOSTAT FAN SWITCH "ON" AND DIP SWITCHS 5 AND 6 "ON".
1. *FIRST LETTER MAY BE "A" OR "T"
2. **FACTORY SETTING.
3. CONTINUOUS FAN SETTING: HEATING OR COOLING AIRFLOW IS APPROXIMATELY 50% OF SELECTED COOLING VALUE.
4. LOW 350 CFM/TON IS RECOMMENDED FOR VARIABLE SPEED APPLICATION FOR COMFORT & HUMID CLIMATE SETTING: NORMAL IS 400 CFM/TON: HIGH 450 CFM/TON IS FOR DRY CLIMATE SETTING.
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 17
*UD2D140A9V5VB FURNACE HEATING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
AIRFLOW
SETTING
LOW ON ON
HEATING
1ST
STAGE
HEATING
2ND
STAGE
*UD2D140A9V5VB FURNACE COOLING AIRFLOW (CFM) AND POWER (WATTS) VS. EXTERNAL STATIC PRESSURE WITH FILTER
OUTDOOR
UNIT SIZE
(TONS)
3.5
4.0
5.0 **
MEDIUM ** ON OFF
HIGH OFF OFF
LOW ON ON
MEDIUM ** ON OFF
HIGH OFF OFF
AIRFLOW
SETTING
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL
(400 CFM/TON)
HIGH
(450 CFM/TON)
LOW
(350 CFM/TON)
NORMAL **
(400 CFM/TON)
HIGH
(450 CFM/TON)
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 7 SW 8 0.1 0.3 0.5 0.7 0.9
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
CFM
TEMP. RISE
WATTS
DIP SWITCH SETTING EXTERNAL STATIC PRESSURE
SW 1 SW 2 SW 3 SW 4 0.1 0.3 0.5 0.7 0.9
OFF ON OFF ON
OFF ON OFF OFF
OFF ON ON OFF
ON OFF OFF ON
ON OFF OFF OFF
ON OFF ON OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
1090
62
130
1230
55
180
1380
49
235
1545
67
320
1760
59
435
2000
52
615
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
1100
61
175
1265
53
235
1405
48
290
1550
67
385
1790
58
545
2010
52
715
1175
165
1345
225
1525
295
1320
220
1550
310
1735
430
1700
415
1980
616
2190
835
1070
63
215
1280
53
315
1425
47
375
1560
67
475
1810
58
620
2000
52
790
1165
200
1370
285
1565
390
1330
275
1580
400
1735
510
1725
470
1980
710
2150
870
1180
265
1400
360
1585
470
1335
355
1590
475
1710
600
1730
560
1950
770
2075
890
1080
62
255
1300
52
380
1430
47
415
1560
67
540
1800
58
695
1950
54
820
1170
320
1405
440
1575
515
1300
435
1555
540
1670
675
1725
640
1885
780
1905
800
1060
1300
1450
1575
1725
1800
63
290
52
455
47
520
66
605
60
725
58
775
1150
400
1380
490
1530
585
1240
490
1460
610
1590
710
1690
700
1735
735
1735
735
NOTES:
1. * First Letter may be "A" or "T"
2. ** Factory setting
3. Continuous Fan Setting: Heating or Cooling airflow is approximately 50% of selected Cooling value.
4. LOW 350 cfm/ton is recommended for Variable Speed application for COMFORT & HUMID CLIMATE setting; NORMAL is 400 cfm/ton; HIGH 450 cfm/ton is for DRY CLIMATE setting
18 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
WIRING DIAGRAM
PRODUCT DATA
From Dwg. D344249P02
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 19
PRODUCT DATA
SCHEMATIC DIAGRAMS
From Dwg. D344249P02
20 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
PRODUCT DATA
TO 115 V 1 PH., 60 HZ., POWER SUPPLY PER LOCAL CODES
HUM SEE NOTE 5
EA
C SEE
NO
TE 5
TO 115 V 1 PH., 60 HZ., PO
WER
SUPPL
Y PER
LOCAL CODES
HUM SEE NOTE 5
EA
C SEE
NO
TE 5
FIELD WIRING DIAGRAM FOR SINGLE STAGE HEATING ONLY
From Dwg. 21B341127 Rev. 0
FIELD WIRING DIAGRAM FOR TWO STAGE HEATING
From Dwg. 21B341126 Rev. 0
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 21
PRODUCT DATA
FIELD WIRING DIAGRAM FOR SINGLE STAGE HEATING WITH SINGLE STAGE COOLING
(OUTDOOR SECTION WITHOUT TRANSFORMER)
From Dwg. 21B341125 Rev. 1
FIELD WIRING DIAGRAM FOR TWO STAGE HEATING WITH SINGLE STAGE COOLING
(OUTDOOR SECTION WITHOUT TRANSFORMER)
From Dwg. 21B341124 Rev. 1
22 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
PRODUCT DATA
TO 115 V 1 PH., 60 HZ., PO
WER
SUPPL
Y PER
LOCAL CODES
HUM SEE NO
TE 5
EAEC SEE NOTE 5
FIELD WIRING DIAGRAM FOR TWO STAGE HEATING WITH TWO STAGE COOLING
(OUTDOOR SECTION WITHOUT TRANSFORMER)
From Dwg. 21B341128 Rev. 0
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 23
PRODUCT DATA
From Dwg. C341699
(ALL DIMENSIONS ARE IN INCHES)
TUD-9V OUTLINE DRAWING
17-1/2" 9-5/8" 16-1/4" 16"
MODEL A B C D
*UD2B060A9V3V**
*UD2B080A9V3V**
21" 13-1/16" 19-3/4" 19-1/2"
*UD2B100A9V3V**
*UD2C080A9V4V**
*UD2C100A9V5V**
24-1/2" 15-5/16" 23-1/4" 23"
*UD2C080B9V4V**
*UD2C100B9V5V**
*UD2D120A9V5V**
*UD2D140A9V5V**
*UD2D120B9V5V**
* - First Letter May Be "A" or "T"
** - Suffix Letters May Be "K" (0 Through 9)
24 DATA SUBJECT TO CHANGE WITHOUT NOTICE 22-1650-13
22-1650-13 DATA SUBJECT TO CHANGE WITHOUT NOTICE 25
PRODUCT DATA
Since the manufacturer has a policy of continuous product and product data improvement, it reserves the right to change the design and specifications without notice.
Technical Literature - Printed in U.S.A.
Trane
6200 Troup Highway Tyler, TX 75707
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
