Page 1
USER MANUAL
Bedienungsanleitung | Manuale dell’Utente | Mode d’emploi
Manual de Usuario | Manual do Usuário
Page 2
2
QUICKSTART
www.tractive.com/activate
Download Tractive® GPS app
2h
TRACKER ID
abcdefgh
Page 3
3
ENGLISH
User Manual
FUNCTIONS AND USE
In order to locate your pet with Tractive® GPS 3G, a PC with internet connection or a
smartphone (iPhone, Android) is required. The Tractive® GPS app can be downloaded
from the Apple App Store for iOS and the Google Play Store for Android.
The Tractive® GPS 3G device can only be used after successful activation on your
smartphone or through a web browser.
GETTING STARTED
1. CHARGING THE DEVICE
We recommend to fully charge the Tractive® GPS 3G device before its rst use.
• Connect Tractive® GPS 3G to a power outlet by plugging the included USB charger
into the USB power adapter or
• connect to a high-power USB 2.0 port using the included USB charger.
The LED on the Tractive® GPS 3G device will turn red while the device is charging. Once
the device is fully charged, the red light will disappear.
Some USB ports and accessories do not provide enough power and Tractive
®
GPS 3G
will charge more slowly.
Page 4
4
2. DEVICE ACTIVATION
Activation of the Tractive® GPS 3G device requires the device to be turned on. Keep
the power button on the device pressed for around 3 seconds. Once you hear 2 short
ascending beeps and see a green light, the device has succesfully been turned on.
Holding the button again for 3 seconds will turn off the device. In order to get GPS
reception, ensure that the device is located outside of buildings and under clear sky.
Enter the link below into the address bar of your browser to access the Tractive®
website, which will guide you through the step by step activation of your Tractive®
GPS 3G device: tractive.com/activate
3. DOWNLOAD TRACTIVE® GPS APP
The Tractive® GPS app will guide you through the rst steps of adding a pet and
assigning a new Tractive® GPS 3G device to the pet.
Note: After turning on the Tractive® GPS 3G device for the rst time or after a period
of inactivity, it can take a few minutes until the device is ready to use. To speed up
this process, turn on the device and make sure it’s placed under clear sky away from
buildings, trees and electrical towers.
4. ATTACHING TRACTIVE® GPS 3G TO A PET COLLAR
Clip the Tractive® GPS 3G device on the harness or the collar of your pet by using the
included clips.
Page 5
5
LED WARNINGS
The LED located on the top of the Tractive® GPS 3G device indicates the current status
of the device.
Battery is low
(red LED ashes 3 times every 15 seconds)
The battery level of the Tractive® GPS 3G device is low. Fully recharge the device
to get the best tracking results.
LIVE Tracking
(white LED ashes)
During a LIVE tracking activity the LED ashes in white. This allows you to locate
your pet easier at night time.
DEVICE STATUS
By pressing the on/off button once, the cellular network and GPS status of the device will
be shown using 2 consecutive ashes.
cellular network available - GPS available
cellular network available - no GPS
no cellular network - GPS available
no cellular network - no GPS
In case of an error, please bring the device into an area with Tractive® coverage. In
order to get GPS reception, ensure that the device is fully charged and located outside
of buildings and under clear sky. It might take a few minutes for the device to get a GPS
connection after it has been turned on.
EN
Page 6
6
SUPPORT
If you have a question or would like to submit a comment, you have the following options:
Read through the frequently asked questions (FAQs)
help.tractive.com
Contact your point of sale
PLEASE NOTE THAT DUE TO ORGANIZATIONAL REASONS TRACTIVE
®
WILL NOT
ACCEPT ANY UNANNOUNCED PACKAGES SENT VIA CARRIAGE FORWARD.
PACKAGE CONTENT
Page 7
7
ELECTROMAGNETIC COMPATIBILITY
Very strong magnetic elds (e.g. transformers) should always be avoided as this may result in variations in
the transmission. Failure to follow these instructions may lead to malfunctions or damage to your Tractive®
GPS 3G device.
RISKS FOR CHILDREN AND PEOPLE IN NEED OF CARE
The use of this device is not intended for people (including children) with limited physical, sensory or
mental abilities or lack of experience and/or lack of knowledge, unless they are supervised by a person
responsible for their safety or have been instructed on the use of the device.
Note: Some countries, states or regions have laws related to location based tracking of people,
animals and objects. It’s the sole responsibility of the owner and user to abide by the law and rules in
the area the Tractive® GPS 3G device is used.
SAFETY ADVICE
Important: The Tractive® GPS 3G device might be too large or heavy for small or injured pets.
If you are unsure whether you can use this device with your pet, we highly recommend consulting a pet
doctor or veterinarian.
BATTERY OPERATION
Your transmitter is operated by a rechargeable lithium polymer battery. Below you will nd some advice on
the use of rechargeable batteries:
•
The battery of the Tractive® GPS 3G device cannot be replaced and must not be removed.
• Batteries may not be disassembled, thrown into re or short-circuited.
•
Never expose the Tractive® GPS 3G device to excessive heat such as sunshine, re or the like! This
increases the danger of battery leakage.
•
Only use the USB cable that came with your Tractive® GPS 3G device. The use of other cables might
overcharge the battery and can lead to re or explosion.
Disregarding these instructions can cause damage and possibly even cause the battery to explode.
EN
Page 8
8
DISPOSAL
Batteries are hazardous waste. For the correct disposal of batteries, appropriate
containers are provided at the premises of commercial battery dealers as well as
local council waste disposal facilities. If you want to dispose of your Tractive® GPS 3G
device, follow the current local provisions at the time. Information may be obtained from
the local council waste disposal facility.
Tractive GmbH, Randlstrasse 18a, 1. Stock, 4061 Pasching, Austria
DECLARATION OF CONFORMITY
Directive 2014/53/EU:
Short text of the Declaration of conformity: Tractive GmbH here
by declares that the Tractive
®
GPS 3G
device (item no. TRATR3G) conforms to the fundamental requirements and other relevant provisions of
directive 2014/53/EU.
The full text of the declaration of conformity can be viewed on our website: tractive.com/doc
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
WARNING: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
Page 9
9
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Consult the dealer or an experienced radio/TV technician for help.
© 2017 Tractive GmbH
All rights reserved.
The most up to date version of this manual can be found at help.tractive.com
EN
Page 10
10
Specific Absorption Rate (SAR) information
SAR tests are conducted using standard operating positions accepted
by the FCC with the device transmitting at its highest certified power
level in all tested frequency bands, although the SAR is determined at
the highest certified power level, the actual SAR level of the device
while operating can be well below the maximum value.
Before a new model device is a available for sale to the public, it must
be tested and certified to the FCC that it does not exceed the exposure
limit established by the FCC, Tests for each samples are performed in
positions and locations (e.g. worn on the body)as
required by the FCC.
For body worn operation, this model device has been tested and meets
the FCC RF exposure guidelines when used with an accessory
designated for this product or when used with an accessory that
Non-compliance with the above restrictions may result in violation of RF
exposure guidelines
Page 11
ISEDC WARNING
This device complies with Innovation, Science, and Economic Development Canada
licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d' Innovation, Sciences et Développement
économique Canada applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Radio apparatus containing digital circuitry which can function separately from the operation of
a transmitter or an associated transmitter, shall comply with ICES-003. In such cases, the
labeling requirements of the applicable RSS apply, rather than the labelling requirements in
ICES-003.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
SAR tests are conducted using standard operating positions accepted by the ISEDC with the
phone transmitting at its highest certified power level in all tested frequency bands, although
the SAR is determined at the highest certified power level, the actual SAR level of the sample
while operating can be well below the maximum value, in general, the closer you are to a
wireless base station antenna, the lower the power output.
Before a new model sample is a available for sale to the public, it must be tested and certified to
the ISEDC that it does not exceed the exposure limit established by the ISEDC, Tests for each
samples are performed in positions and locations (e.g. worn on the body)as
required by the ISEDC.
For body worn operation, this sample has been tested and
meets the
ISEDC
RF exposure
guidelines when used with an accessory designated for this product
Non-compliance with the above restrictions may result in violation of RF exposure guidelines.
Le présent appareil est conforme
Après examen de ce matériel aux conformité aux limites DAS et/ou aux limites
d’intensité de champ RF,les utilisateurs peuvent sur l’exposition aux radiofréquences
et la conformité
