Trackmate mini Installation Manual

WELCOME!

Welcome to a new dimension of safety and security for your
vehicles with your purchase of the TrackmateGPS MINI and its
advanced technology. You are now able to have control of your
vehicles, whether you operate a business with company cars, a
fleet of limousines, or you are a parent of a teenage driver. The
MINI lets you know where your car is at all times. It can even
signal you if someone exceeds your pre-determined speed limit
or enters an area you you’d rather him/her not be there.

The MINI is ideal for commercial or personal use, simple to
install and easy to use.

*Read this Registration / Installation Guide carefully before
installing your new MINI.

STEP ONE: Registration and Activation

Before you turn on or install your MINI, you must create an
account, and register your device(s) on our website. At the
account setup page, you will be prompted to fill out the account
information form. Next you will be prompted to select one of
the service plans: saver, basic, premium or platinum. After
selecting a service plan you will be prompted to enter your
credit card information.
You will now be redirected to the homepage where you will be
able to enter the device’s serial number which can be found on
the device.

STEP TWO: Installation

Estimated time required for installation: 30 to 45 minutes for
experienced installer – 1 to 2 hours for novice.

 It is recommended you use a professional car electrician

to install your tracker. However, if you're handy, you may
choose to install it on your own. Tools needed for
installation: voltage tester/meter, wire stripper, electrical
tape, wire connectors, fuse taps (optional)

 The tracker has to be connected to a power source

providing 9V-30V DC. The wiring must be connected to
constant power for correct tracking. The power
consumption is minimal (<30mA), and should not affect
your vehicle battery, unless the vehicle is not used for an
extended period (several weeks)or the vehicle battery is
in poor condition.

 The wiring harness has four wires(approximately 3ft

long).Plug the wiring harness to the device. Strip the
blackwire and ground it securely. The red wire should be
connected to a constant power source (fuse or wire)
providing between 9V and 30V. Finally, the green wire
has to be connected to ignition/accessory or any
fuse/wire which is powered by ignition. The white wire is
currently not enabled and should be ignored.

 LED lights indicators: the MINI tracker has three LED

lights, green, blue and red. The green light indicates the
status of the GSM (cellular) connection. It will go through
various sequences, such as solid light, rapid flashing,
reduced flashing and finally flashing every few seconds.
This indicates that the device has successfully connected
to the GSM network (it is not tracking yet). The red light
indicates that the device is connected to a power source
and is being charged. Finally, the blue light indicates the
